Cub cadet CCT410 User Manual

Power Lok™ Trimmer Attachment

CCT410

Instruction Manual

PRODUCT SPECIFICATIONS

Trimmer Mechanism: Bump Head Trimming Line Diameter: 0.095 in. (2.41 mm) Weight: (without Power Cell) 8 Lbs Weight: (with Power Cell) 11 Lbs

Need Assistance?

For assistance regarding the assembly, operation or maintenance of the unit, please call 1-877-282-8684 (in the United States) or 1-800-668-1238 (in Canada). Additional information can be found at www.cubcadet.com (in the United States) or www.cubcadet.ca (in Canada).

769-11428 / 00 01/16

TABLE OF CONTENTS

Product specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Table of contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

General safety warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

General power tool safety warnings . . . . . . . . . . . . . . . . . . . . . . . . . 5-6

Specific safety rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10

Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Know Your Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Assembly and operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13–19

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-22

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . *

* Please refer to the separate Warranty Supplement.

GENERAL SAFETY WARNINGS

CAUTION: Before using this tool or any of its accessories, read this

manual and follow all Safety Rules and Operating Instructions.

This instruction manual includes the following:

• General Safety Rules

• Specific Safety Rules and Symbols

• Functional Description

• Assembly

• Operation

• Maintenance

• Accessories

WARNING: Retain this manual for future reference.

Provide this manual to all operators and be certain that they have read and understand all the Safety Rules and Operating Instructions prior to their using this tool.

EYE AND FACIAL PROTECTION

ALWAYS WEAR EYE PROTECTION THAT CONFORMS WITH THE MOST RECENT ANSI Z87.1 or CAN/CSA – Z94.3 SAFETY STANDARDS.

FLYING DEBRIS can cause permanent eye damage. Prescription eyeglasses ARE NOT a replacement for proper eye protection. The usage of a safety standard compliant face shield placed over proper safety glasses or goggles can reduce the risk of facial injury.

WARNING: Non-compliant eyewear can cause serious injury

if broken during the operation of a power tool.

Please register your product online at www.cubcadet.com (in the United States) or www.cubcadet.ca (in Canada).

WARNING: To avoid electrical hazards, fire hazards or damage to

the tool, use proper circuit protection.

The charger for this tool is wired at the factory for 120 V operation. It must be connected to a 120 V, 15 A circuit that is protected by a time-delayed fuse or circuit breaker. To avoid shock or fire, replace the power cord immediately if it is worn, cut or damaged in any way.

OWNER’S REGISTRATION

ELECTRICAL SAFETY

HEARING PROTECTION

WARNING: Use hearing protection if the surrounding

environment of the area of operation is loud.

BODY PROTECTION

WARNING: Always wear non-slip gloves that fit properly to

protect your hands and to help you grip the tool.

WARNING: Always wear sturdy clothing with long sleeves

and long pants. Never operate the tool while wearing shorts, short sleeve shirt or while shirtless.

WARNING: Always wear non-slip safety boots to prevent foot

injuries and slipping that could cause loss of control of the tool.

SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

GENERAL SAFETY WARNINGS

GENERAL POWER TOOL SAFETY WARNINGS

WARNING: Read all safety

warnings and all instructions. Failure

to follow the warnings and instructions may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

General Power Tool Safety Warnings – Work Area Safety

Keep work area clean and well lit.

Cluttered or dark areas invite accidents.

Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create

sparks which may ignite the liquids, fumes or dust.

Keep children and bystanders away while operating a power tool.

Distractions can cause you to lose control.

General Power Tool Safety Warnings – Electrical Safety

Charger plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) chargers.

Unmodified plugs and matching outlets will reduce risk of electric shock.

Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators.

There is an increased risk of electrical shock if your body is earthed or grounded.

Do not expose power tools, chargers or Power Cells to rain or wet conditions. Water entering the tool,

chargers or Power Cells will increase the risk of electric shock.

Do not abuse the cord. Never use the power cord for carrying, pulling or unplugging the charger. Keep the power cord away from heat, oil, sharp edges, and moving parts. Damaged or

entangled cords increase the risk of electric shock.

When operating a charger outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for

outdoor use reduces the risk of electric shock.

If operating a charger in a damp location is unavoidable, use a residual current device (RCD) protected supply. An RCD is also known as a ground fault circuit interrupter (GFCI) or earth leakage circuit breaker (ELCB). Use of an RCD

reduces the risk of electric shock.

General Power Tool Safety Warnings – Personal Safety

Stay alert, be aware of your surroundings, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of inattention

while operating a power tool may result in serious personal injury.

GENERAL POWER TOOL SAFETY WARNINGS

Use personal protective equipment. Always wear eye protection.

Protective equipment such as dust mask, non-skid safety shoes or boots, sturdy gloves, durable long pants and durable long sleeve shirt, [and hard hat, or hearing protection used for appropriate conditions] will reduce personal injuries.

Prevent unintentional starting. Ensure the trigger switches are in the offposition before connecting the Power Cell to the power tool, and never pick up or carry the tool by the trigger switches. Carrying power tools with

your finger on the switch or energizing power tools that have the switch on invites accidents.

Remove any adjustment key or wrench before turning the power tool on. A wrench or a key left attached to a

rotating part of the power tool may result in personal injury.

Do not overreach. Keep proper footing and balance at all times. This

enables better control of the power tool in unexpected situations.

Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from moving parts. Loose clothing, jewelry or long

hair can be caught in moving parts.

General Power Tool Safety Warnings – Power tool use and care

Do not force the tool. Use the correct tool for the application. The correct

power tool will do the job better and safer when used at the rate for which it was designed.

Do not use a power tool if the switch does not turn it on or off. Any power tool

that cannot be controlled using the switch is dangerous and must be repaired.

Remove the Power Cell before making any adjustments, replacing or repairing parts, cleaning the tool, leaving the tool idle or unattended, transporting or storing the tool. Such

preventive safety measures reduce the risk of starting the power tool accidentally.

Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.

Power tools are dangerous in the hands of untrained users.

Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by

poorly maintained power tools.

Use the power tool and accessories in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for

operations different from those intended could result in a hazardous situation.

General Power Tool Safety Warnings – Service

Have your power tool or charger serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of

the power tool or charger is maintained.

SPECIFIC SAFETY RULES

WARNING: Know

your Power Lok™ trimmer accessory. Do not install an

accessory, plug in the charger or install the Power Cell into the tool until you have read and understand this Instruction Manual. Learn the tool’s applications and limitations, as well as the general and specific potential hazards related to this tool. Following these instructions

will reduce the risk of electric shock, fire or serious injury.

WARNING: Always

wear appropriate eye protection. Any power tool

can throw foreign objects into your eyes and cause permanent eye damage. ALWAYS wear appropriate safety goggles or properly fitted safety glasses that comply with OSHA standards and the most recent version of ANSI Z87.1 or CAN/CSA – Z94.3 safety standards [or other applicable national standard]. Ordinary vision or sun glasses generally do not provide adequate impact or side shield / wrap around penetration protection. Ordinary glasses ARE NOT safety glasses. To reduce the risk of injury to your face, also wear a face shield or face screen over your safety goggles or safety glasses.

WARNING: Glasses, goggles or face

shields not in compliance with ANSI Z87.1 or CAN/CSA – Z94.3 could cause serious injury if they break upon impact.

WARNING: Prevent

foot injuries! Never operate

when barefoot, or wearing

open toed shoes, or sandals. Always, wear sturdy protective shoes or boots with non-slip soles when operating the tool. Steel-toed safety boots are recommended.

WARNING: Protect

your hands by wearing heavy-

duty, non-slip gloves and to improve your grip and control when handling the tool.

WARNING: Clothing must be

durable and snug-fitting, yet allow for freedom of movement. Avoid loose clothing such as scarves, neckties, jewelry, flared or cuffed pants, loosefitting shirts or jackets, unconfined long hair or anything that can get caught in brush or branches, or become entangled in the tool. Secure hair to above shoulder level. Wear long pants of durable material to protect your legs. Cover as much of your body as possible to help protect you from debris and pieces of toxic and allergenic plants being thrown by the tool.

SPECIFIC SAFETY RULES

WARNING: Never use

fixed blades or metal saw blades with this trimmer.

Serious injury may result. Never use wire or metal-reinforced line or other material in place of the polymer trimmer line. Pieces of wire or metal reinforced line can break off and can be thrown with great force striking against and injuring the operator or bystanders.

WARNING: The

rotating trimmer line and trimmer head will throw objects and debris violently

and the objects and debris will ricochet in all directions. You or bystanders can be blinded or injured. Keep children, bystanders, pets and other animals at least 50 feet (15 meters) away from the operating trimmer. Turn the trimmer OFF immediately if approached, or if you are approaching such bystanders. Bystanders should be encouraged to wear eye protection, even if they are kept at a distance. The debris shield on the trimmer is designed to reduce the danger. The debris shield provided with your trimmer may not protect the operator or bystanders from all objects or debris thrown by the rotating polymer line or trimmer head.

Thrown objects may also ricochet and strike the operator or bystander.

Utilize extra caution, when the trimmer is being used as an Edger or Sweeper, especially near, or on paved or hard surfaces, as pieces of metal, concrete, brick, stones, gravel, sand, glass, sticks and other objects can be thrown at high speed and force by the rotating line and such objects can be thrown, skip along or ricochet long distances off of hard surfaces. Do not use this trimmer for sweeping debris that may contain hard objects, e.g. pebbles, stones, sticks, glass, metal, etc. as such hard objects can be thrown with great force and cause injury to the operator or bystanders, and / or damage property, e.g., screens, windows, building siding, glass doors, or vehicles.

NOTICE: Avoid operating the trimmer near property that can be easily damaged by thrown or ricocheting objects such as screens, windows, building siding, glass doors and vehicles.

WARNING: To reduce

the risk of ricochet / rebound injury, or property damage

work by going away from any nearby solid object such as wall, steps, large stones, tree, etc. Use great care when working close to solid objects. Where hazardous conditions warrant, do not use the power tool, rather do trimming, edging, mowing or sweeping by hand.

Min. 50 ft

15 m

SPECIFIC SAFETY RULES

WARNING: Inspect

the area to be trimmed for hazards before each use.

Remove any foreign objects such as sticks, rocks, broken glass, nails, wire, tools, toys, etc. which can be thrown by or become entangled in the trimmer line. Always locate, and then avoid cutting near electrical power lines, power conduit, or extension power cords. Avoid contacting hard objects with the trimmer head as the objects can damage the trimmer head and / or the objects can be thrown causing serious injury.

Use this trimmer only for trimming, scalping, mowing of grass and weeds, and for light edging of lawns, and for sweeping of only light lawn debris on paved areas. Do not use this trimmer for brush cutting, pruning or hedge trimming. Never use this trimmer on gravely or sandy areas.

WARNING: To reduce

the potential of serious

injury, cut only from your left

toward your right, in the direction of the arrow on the deflector shield. Cutting on the right side of the deflector shield and moving directionally towards your right will cause the debris and objects to be thrown predominately away from the operator thereby reducing the risk of personal injury to the operator, although the risk of injury due to ricochet is not lessened. Whereas cutting on the left-side of the deflector shield or moving directionally towards your left will cause for comparatively more debris to be thrown towards the operator thereby increasing the risk of personal injury.

Hold the trimmer firmly with both hands to ensure proper control. Never operate the trimmer with one hand.

Keep the trimmer head below waist level and away from all parts of your body. Do not draw the trimmer head towards your feet or legs.

WARNING: Always remove the

Power Cell when making adjustments, changing accessories, replacing the polymer trimmer line, removing or untangling debris, leaving the tool idle or unattended, cleaning, servicing, storing or transporting the tool. Such

preventive measures reduce the risk of starting the tool accidentally and causing serious injury.

Never use the trimmer with the deflector shield removed, damaged or incorrectly positioned. Serious injury may result.

Maintain firm footing and balance at all times. Do not overreach or use the trimmer from unstable surfaces such as ladders, trees, steep slopes, slippery surfaces, rooftops, etc.

Inspect the trimmer head before each use. If any parts are worn or damaged, replace them before using the trimmer.

Only use the polymer line size and type recommended for the trimmer. Use of any other type could result in serious injury.

Use only in daylight or in good quality artificial light.

Never use the trimmer for anything other than its intended purpose. Use for anything other than trimming grass and weeds can be dangerous. It may also damage the trimmer.

SPECIFIC SAFETY RULES

WARNING: Dust created by use

of this product may contain chemicals known to the State of California and medical experts to cause cancer, respiratory injuries, birth defects or other reproductive harm. Some examples of these chemicals are:

• Compounds in fertilizers

• Compounds in insecticides,

herbicides and pesticides

• Arsenic and chromium from

chemically treated lumber.

• Commercial and household

chemicals.

To reduce your exposure to these chemicals, wear approved safety equipment such as dust and / or vapor masks that are specifically designed to filter out microscopic particles or gaseous components. Additionally, dust created by this product may contain allergens, bacteria and viruses, PM 10 and / or PM 2.5 particulates, exposure to such hazardous airborne matter can be reduced by wearing approved safety equipment such as dust masks that are specifically designed to filter out the microscopic particles.

SYMBOLS

WARNING: Some of the following symbols may appear on the Power Lok™

Trimmer Attachment, Power Lok™ Drive Unit, Power Cell or Power Cell chargers, or this manual. Study these symbols and learn their meaning. Proper interpretation of these symbols will allow for more efficient and safer operation of this tool.

Volts

Amperes

Hertz

Watts

Hours

Direct current

No load speed

Alternating or direct current

.../min

Revolutions or reciprocations per minute

Arrow direction

Warning symbol

Shock hazard

Striking hazard

No fixed blades.No saw blades.

Keep bystanders back at least 50' (15m)

Read the manual

Wear safety glasses. Wear safety goggles. Wear hearing protection.

Wear safety gloves

Wear safety boots

Handle position

Min. 50 ft

15 m

KNOW YOUR UNIT

ACCESSORIES

AVAILABLE ACCESSORIES

WARNING: Use only accessories

that are recommended for this Power Lok™ trimmer attachment. Follow the instructions that accompany the accessories. The use of improper accessories may result in injury to the operator or damage to the Power Lok™ trimmer attachment.

Before using any accessory, carefully read the instructions or the owner’s manual for the accessory.

• See chart below

WARNING: If any part is missing

or damaged, do not plug the charger into the power source or install the Power Cell in the tool until the missing or damaged part is replaced.

Cutting Head

Cutting Head Shield

Line Cutting Blade

Front Handle

Motor

Part # Description

CFC6500 Power Cell CRC8000 1-Hour rapid charger CCU410 Power Lok™ drive unit

ASSEMBLY AND OPERATING

Instructions for charging the Power Cell are packed with the charger.

WARNING: Read all safety warnings and charging instructions included with

the charger.

INSTALLING THE DRIVE UNIT ON AN ATTACHMENT

NOTE: The Power Lok™ Drive Unit

must be installed on the Trimmer Attachment. If the unit you purchased does NOT include the drive unit, one must be purchased separately. Refer to the Accessories section.

WARNING: Remove the Power

Cell from the drive unit before installing it on the attachment.

1. Pull the locking lever (1) outward

from the locking collar (2). Align the groove (3) in the locking collar with the matching key (4) on the end of the attachment shaft (5) (Fig. 1).

2. Insert the attachment shaft into the

locking collar until the installation mark (6) meets the locking collar (Fig. 1).

NOTE: Make sure the attachment shaft is fully inserted into the locking collar. If it is not fully inserted, the electrical connection will not be made and the attachment will not function properly.

3. When the attachment shaft is fully

inserted into the locking collar, push the locking lever back toward the locking collar to lock the assembly together (Fig 2).

Fig. 1

Fig. 2

ASSEMBLY AND OPERATING

ADJUSTING THE FRONT HANDLE

The front handle can be adjusted to suit the operator (Fig. 3).

1. Using a Torx® screwdriver (1), turn

the four handle clamp screws (2) counter clockwise until the handle (3) will rotate on the trimmer outer shaft (4) (Fig. 3).

2. Slide the handle up or down and/or

rotate it to a comfortable position. Make sure the handle is positioned beyond the end of the safety label (5).

3. Re-tighten the handle clamp screws

to hold the handle in the desired position.

NOTE: Do not over tighten the clamp screws. You will break the clamp.

NOTE: Make sure the locking lever is fully pressed toward the locking collar. This is important to ensure the assembly is properly locked together.

Fig. 3

ASSEMBLY AND OPERATING

STARTING INSTRUCTIONS

To prevent the motor from starting accidentally, the lock-off button and throttle control must both be engaged to start the unit.

1. Install the power cell. Refer to

Installing the Power Cell in the Drive Unit manual.

2. Push the lock-off button (2) into the

throttle control (1) and hold it in place (Fig. 4).

3. While continuing to hold the lock-off

button, squeeze and hold the throttle control to start the unit (Fig. 4).

4. Continue to squeeze the throttle

control for operation.

STOPPING INSTRUCTIONS

1. Release the throttle control (1) and

wait for all moving parts to come to a complete stop (Fig. 4).

USING THE POWER CONTROL BUTTON

The power control button (1) allows the operator to switch between Boost (2) and Eco (3) modes, as needed (Fig. 5):

• Boost mode provides maximum

power for tough jobs.

• Eco mode conserves energy for

maximum run time. Eco mode is appropriate for most jobs.

Push the power control button forward for Boost mode (Fig. 5). Push the power control button back to return to Eco mode (Fig. 5).

Fig. 5

Fig. 4

ASSEMBLY AND OPERATING

For safety reasons, the operator must read the sections of this Owner’s Manual entitled "GENERAL SAFETY WARNINGS", "GENERAL POWER TOOL SAFETY WARNINGS", "SPECIFIC SAFETY RULES", and "SYMBOLS" before using this trimmer accessory.

Verify the following every time the trimmer accessory is used:

1. Safety glasses, and all required safety clothing are being worn.

2. Appropriate length of trimmer line is exposed beyond the bump head eyelets.

3. The area to be trimmed is cleared of all debris.

4. Bystanders are at least 50' (15 m) away from the trimming area.

Failure to observe these safety rules will significantly increase the risk of injury.

WARNING

OPERATING POSITION

WARNING: Never operate the

trimmer with one hand. Always hold the trimmer with one hand on the forward handle and the other hand on the rear handle to operate the switches. Operate the trimmer below waist height at all times. Always wear appropriate personal protective equipment. Never operate the trimmer on its edge while trimming grass. The trimming line should always be near and parallel to the ground to avoid scalping and throwing debris.

ASSEMBLY AND OPERATING

CUTTING METHODS

WARNING: Be extremely careful

when cutting around hard objects such as rock, gravel, fence posts etc. that can be contacted by the line or the bump head (Fig. 6). Contacting these items with the line or bump head may cause pieces of the trimmer line and debris to be violently thrown. It may also cause the line to become entangled and damage both the line and the bump head.

When trimming, do not feed the line into the work area too quickly and crowd the line. Only the tip of the line does the cutting (Fig. 7). Feeding the line into the work area too quickly will reduce the head speed, slow the cutting action and overload the motor. It will also reduce the Power Cell capacity before requiring recharging.

NOTE: The trimming line will easily remove grass and weeds from around walls, fences, trees and flower beds, but it can also cut the tender bark of trees or shrubs, scar fences, etc. Be extremely careful when trimming near objects that can be easily damaged by the trimmer line.

Fig. 7

Fig. 6

ASSEMBLY AND OPERATING

Trimming

Position the bottom of the bump head about 3" (8 cm) above the ground and at a slight angle (Fig. 8). Allow only the tip of the line to make contact with the grass.

NOTE: Allowing more than just the tip of the line to do the trimming will result in rougher cutting action and excessive wear on the line.

Scalping

Scalping an area will remove all unwanted vegetation down to the ground. When scalping, position the bottom of the bump head about 3" (8 cm) above the ground and at a slight angle (Fig. 9). Allow only the tip of the line to make contact with the ground.

NOTE: Scalping is ideal for use around trees, shrubs, posts, ornaments, etc. Be aware that scalping will increase trimmer line wear considerably.

Mowing

Use the trimmer to mow small or rough areas where a conventional lawn mower cannot be used. When mowing, keep the line parallel to the ground at the desired height (Fig. 10). Move the trimmer from left to right while cutting. This cutting motion will throw grass and debris predominantly away from the operator.

NOTE: Be careful not to allow the bump head to contact the ground, as this could result in scalping and/or releasing more trimmer line from the spool.

Fig. 9

Fig. 8

Fig. 10

3“ (8 cm)

Scalping

Mowing

ASSEMBLY AND OPERATING

Sweeping

Use the trimmer for sweeping cut grass and debris from walkways and driveways. Position the line parallel to and above the surface to be swept (Fig.

11). Swing the trimmer from side to side in a fanning motion. The air flow from the rotating line will blow the grass and debris from the surface being swept.

NOTE: Be careful not to allow the bump head to contact the ground, as this could result in damage to the bump head and/or releasing more trimmer line from the spool.

Edging

Use the trimmer for edging around walkways and flower beds.

WARNING: Always use long

pants, long sleeve shirt, gloves and safety goggles and a face shield when edging. Debris being thrown from the trimmer at high speed can injure your eyes and any exposed skin.

Hold the trimmer in a similar manner to trimming, but with the trimmer head rotated away from your body by 90° (Fig. 12).

ADVANCING THE POLYMER LINE

As the trimmer is used, the polymer line will wear down or the tips will break off. To advance the polymer line and expose a greater length, simply tap the bump head on the ground while the trimmer is turned ON.

Fig. 12

Fig. 11

Sweeping

MAINTENANCE

GENERAL

WARNING: When servicing, use

only original equipment replacement parts. The use of any other parts may create a hazard or cause product damage.

WARNING: DO NOT use

solvents for cleaning your tool, charger or Power Cell. Solvents could catch fire or even explode due to exposure to electric sparks and / or degrade and make unsafe the electrical components. Additionally,

plastics are susceptible to damage from various types of commercial solvents and may be damaged by their use. Use a clean cloth to remove dirt, dust, oil, grease etc.

WARNING: Do not allow brake

fluids, gasoline, petroleum-based products, penetrating oils, etc. to come into contact with plastic parts. They contain chemicals that can damage, weaken or destroy plastic.

DO NOT abuse power tools. Abusive practices can damage the tool.

WARNING: DO NOT attempt to

modify tools or create accessories. Any such alteration or modification is misuse and could result in a hazardous condition leading to possible serious injury. It will also void the warranty.

LUBRICATION

All of the bearings in this tool are lubricated with a sufficient amount of high-grade lubricant for the life of the unit under normal conditions. Therefore, no further lubrication is required.

MAINTENANCE

RELOADING THE BUMP HEAD WITH TRIMMER LINE

The trimmer accessory comes with trimmer line already installed. When the trimmer line is used up, you will have to reload the bump head with trimmer line.

WARNING: Avoid Injury! To

prevent accidental start up: Always remove the Power Cell before reloading the bump head.

1. Cut a length of line 12 to 16 feet long.

2. Align the arrows (1) on the head with the eyelets (2) (Fig. 13).

3. Thread one end of line into an eyelet and push it through the head and out the other eyelet (Fig. 14).

4. Pull both ends of the line until an equal amount is extending from both eyelets (Fig. 15).

5. Turn the knob clockwise until all but 6 inches of line are extending from both sides of the trimmer head. (Pull lightly on the line after every 6-8 clicks).

6. Cut the longer end so that both strips are the same length.

7. Install a charged Power Cell and begin trimming vegetation.

Fig. 13

Fig. 14

Fig. 15

MAINTENANCE

OPENING THE BUMP HEAD TO RECOVER LINE

WARNING: Avoid Injury! To

avoid accidental start up: Always remove the Power Cell before removing or reinstalling the spool.

The trimmer line may break off at the eyelet due to hitting debris. It may also become entangled within the bump head spool. In either case, you will have to remove the spool from the bump head as follows:

1. Press in the two tabs (1) (Fig. 16).

2. Gently twist the bump knob clockwise to separate the two halves, be careful not to lose the spring (1) (Fig. 17).

3. Remove any line from spool (2) (Fig. 17).

4. Use a clean rag to clean all debris from the bump head shaft (3), inside the bump head and from the spool (Fig. 17).

NOTE: If the bump head and spool are not properly cleaned, the bump head will not work properly.

5. Align the two black tabs (4) with the openings (5) in the main housing and press together until both sides click into place (Fig. 17). Hint: Gently twist the bump knob clockwise while pressing together.

6. Load trimmer line.

Fig. 16

Fig. 17

+ 50 hidden pages
