Crosley CR1702A User Manual
910-102020-0010-200
Crosley Radio, Inc. warrants the product to be free from defects in material and
workmanship under normal use for a period of one year from the original date of
purchase. This warranty is not transferable. If the product is determined to be defective
during the warranty period, the unit will be repaired or replaced at Crosley Radios sole
discretion. This warranty covers manufacturing defects and normal consumer use and
does NOT cover damage or failure as a result of abuse, accident, alterations, misuse,
neglect, abnormal wear and tear, inadequate maintenance, commercial or unreasonable
use, damage caused by power surges, mishandling, accident, acts of God or attempted
repair by an unauthorized service agent. Also not covered are cosmetic damages,
cords and antennas.
Should this product fail to function in a satisfactory manner, it is best to first return it
to the store or retailer where it was originally purchased. If additional service is still
needed, the original purchaser must FIRST contact our offices to obtain an RA (Return
Authorization) Number.
TO OBTAIN AN RA NUMBER
CALL: 1.888.CROSLEY
(1.888.276.7539)
Send the unit prepaid to the address below in the original packaging (or reasonable
substitute to prevent damage). Clearly mark your RA number on the outside packaging
and include the original sales receipt (or a copy) indicating date of purchase, amount
paid, and place of purchase. You must also include your full name, shipping address
and daytime contact number. Please include a check or money order in the amount
of $19.95, made payable to Crosley Radio, to cover handling and return shipping
charges. Returned products will not be shipped to PO Boxes. Crosley Radio will not
be responsible for delays or unprocessed claims resulting from a purchasers failure
to provide any or all of the necessary information.
CROSLEY RADIO
ATTN: RETURNS DEPT
2001 PRODUCTION DRIVE
Louisville, KY 40299
For additional support: Crosley Radio Consumer Service Department
24 hours a day / 7 days a week
Telephone: 1.888.CROSLEY (1.888.276.7539)
There are no express warranties except as listed above.
The purchasers bill of sale is the only proof of warranty entitlement.
This warranty gives the purchaser specified legal rights in addition to any rights which
may vary from state to state.
In accordance with the Moss-Magnuson Warranty Act of July 10, 1975, this is termed
a limited warranty which in no way compromises Crosley Radios high standards of
quality and workmanship.
LIMITED MANUFACTURERS WARRANTY
iJuke Premier
CR1702A
Instruction Manual
www.crosleyradio.com
CD Player
1 Make sure the power is on.
2 Press CD / iPod BUTTON (22). The CD
display (- -) will flash, then show (0 0) .
3 Press OPEN / CLOSE BUTTON (24) to open
CD DRAWER (11) .
4 Insert CD in tray with the label side of CD
facing up.
5 Press the OPEN / CLOSE BUTTON (24) again
to close the CD DRAWER (11).
6 Press PLAY / PAUSE BUTTON (23) to begin
playing the CD.
7 To stop playing, press the STOP BUTTON
(19).
8 To skip to a different track, press the BACK
SKIP (18) or the FORWARD SKIP (26) button.
9 By pressing and holding either the BACK SKIP
(18) or FORWARD SKIP BUTTON (26), you
can rewind or fast forward through each
individual tack. The track will fast forward or
rewind as long as you are holding the button.
Once you let off the button, regular playback
resumes.
10 During playback, you can use the repeat
function to repeat a single song or the whole
CD.
11 While the song you want to repeat is playing,
press the REPEAT (20) button once. You will
see the REPEAT INDICATOR (5) on the
jukebox start to flash. The song will start over
once it is finished.
12 Press the REPEAT (20) button a second time
to repeat the whole CD. The REPEAT
INDICATOR (5) will stay on without flashing.
CD Operation
Programmed CD Playback
This CD player is programmable which allows you
to program it to play only selected tracks. To program,
follow the steps below.
1 Insert disc and close CD DRAWER (11). Do
not press play yet.
2 Press the PROGRAM (21) button. The
PROGRAM INCICATOR (4) on the jukebox
will start to flash.
3 Use the BACK SKIP (18) or FORWARD SKIP
BUTTON (26) to select a track you want to
program.
4 Once you have selected a track, press the
program button again. This stores the track
into memory.
5 Use the BACK SKIP (18) or FORWARD SKIP
BUTTON (26) to select the next track you want
to program. Once selected, press the program
button again.
6 Repeat step number 5 until you have
programmed all desired tracks.
7 Press PLAY / PAUSE BUTTON (23) to begin
playing the selected tracks. The program light
will stop flashing and the selected tracks will
begin playing. They will play in the order that
they were programmed.
8 Using the BACK SKIP (18) or FORWARD
SKIP BUTTON (26) will only skip through the
programmed tracks.
9 To clear programmed tracks, press the stop
button twice until the program light goes out.
10 Programmed tracks will also be erased from
memory when the CD DRAWER (11) is opened
or when the power is turned off.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE. DO NOT REMOVE COVER.
PILOT LAMPS SOLDERED IN PLACE. NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lighting flash with
arrowhead symbol, within
an equilateral triangle, is
intended to alert user to
the presence of uninsulated
"dangerous voltage" within
the product's enclosure
that may be of sufficient
magnitude to constitute
risk of electric shock
to persons.
CAUTION: TO REDUCE
THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE
COVER (OR BACK). NO
USER - SERVICEABLE
PARTS INSIDE. REFER
SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
For Compact Disc Units Only:
INVISBLE LASER RADIATION WHEN OPEN AND INTERLOCK FAILED
OR DEFEATED. AVOID DIRECT EXPORSURE TO LASER BEAM.
Specification
Power Source : AC 120V ~ 60Hz
Power Consumption : 30W
Speaker : 4 Dynamic Type x 2
Speaker Wattage : 5 W
Speaker Ohm : 4 Ohm
Output Wattage : 2W per channel
The exclamation point
within an equilateral
triangle is intended to
alert user to the
presence of important
operating and
maintenance (servicing)
instruction in the
literature accompanying
the appliance.
13 Pressing the REPEAT (20) button a third time
will disable the repeat function.
9
* DESIGN AND SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
