Crestron C2N-DVP4DI
Digital Video Processor
The C2N-DVP4DI is an advanced multi-window digital video
processor, touchpanel interface and 2-Series Ethernet control
system.Ideal for multi-image displays in videoconference rooms,
training rooms,command centers,sports bars,home theaters,and
kiosks,the “DVP4DI”combines a unique set of features to deliver a
complete presentation solution.
Digital Video Processor—The DVP4DI displays up to four
simultaneous scalable video windows on a single plasma display
or projector.Up to 12 video inputs and 4 RGB/computer inputs
may be selectively routed to any of the four onscreen windows.
A built-in 12 x 4 seamless matrix switcher accepts inputs from
NTSC/PAL composite,S-Video, and component video sources.In
addition, four DVI-I inputs support high-resolution analog RGB and
DVI digital sources.The output of the DVP4DI may be fed to any
RGB or DVI display device through a single DVI-I output.
The DVP4DI supports non-interlaced input and output resolutions
up to 1600 x 1200 RGB and 1280 x 1024 DVI.The output may be
formatted as either 4:3 or 16:9 aspect ratio.
Each video window is processed by a discrete video scaler with
motion adaptiv
y minimizing visible sc
b
source identification assigns the optimum deinterlacing algorithm,
with 3:2 (NTSC) and 2:2 (PAL) pulldown detection.
The DVP4DI’s 24-bit color depth and 8-bit alpha transparency
combine with Crestron’s Isys® graphics engine to enable the
creation of astounding 3D graphics and dynamic text.An exclusive
Synapse™ image-rendering algorithm delivers crisp,sharp antialiased objects and text, high-resolution images, 3D effects,
animations,and more.
ideo windo
V
onscreen, with digital transition effects possible including pan,
dissolve,reveal,stretch, cut,and zoom.Translucent objects
,
fade
y b
ma
e deinterlacing,bringing out the highest detail
an lines and motion ar
eely sized and positioned anywhere
e fr
y b
s ma
w
ated in combination with the video windows.
or
p
or
e inc
ts. Automatic
tifac
Touchpanel Interface—The DVP4DI can be used to transform
a third-party touchscreen monitor or plasma display into a fullfeatured Isys touchpanel,unleashing a host of possibilities for
special control and presentation applications such as interactive
kiosks,museum or tradeshow displays, training rooms,command
centers,and more.
Crestron’s exclusive “Touch-the-PC”technology allows for true
real-time touchscreen navigation of any connected Windows® PC.
Built-in annotation capability enables presenters to draw freely
over any video,computer,and other graphic background.The
DVP4DI also integrates perfectly with third-party telestrators.
In lieu of a touchscreen,users may also navigate the DVP4DI’s
graphical interface using a pointing device like Crestron’s CNWM
wireless presentation remote,or a serial mouse (included).
trol System—
on
C
powerful 2-Series engine, providing fully programmable control
system capability compatible with Crestron’s complete line of
touchpanels,keypads,and other Cresnet devices. The onboard Web
server delivers full e-Control®2 XPanel support to enable complete
control of the DVP4DI and any connected peripherals using a
Windows® PC or PocketPC™ 2000 PDA device.
The four built-in RS-232 ports provide touch coordinate output
ta for up to four PC’s or telestrators, or may be configured
da
t control of display devices,DVD players, etc.
ec
vide dir
o
o pr
t
Additional control ports of any type may be added easily using
resnet expansion modules or additional 2-Series control systems.
C
tile C2N-D
ersa
he v
T
Ethernet master or slave as part of a larger system.
To accommodate large programs,project files,Web pages,and
graphics,a memory card slot accessible on the rear panel allows
for easy expansion of the DVP4DI’s internal memory by up to 4 GB
using any Type II Compact Flash memory card or IBM Microdrive®
hard disk drive.A 32MB Compact Flash card is included.
VP4DI incorporates Crestron’s
he D
T
VP4DI ma
y be configured as a Cresnet or
All brand names, product names and trademarks are the property of their respective owners.
©2004 Crestron Electronics, Inc.
Crestron C2N-DVP4DI Digital Video Processor
Processor
CPU: 32-bit Motorola ColdFire® Microprocessor
Processing Speed: 257 MIPS (Dhrystone 2.1 benchmark)
Memory
Onb
4MB F
oard:
C
ompact Flash card included
Expandable: Compact Flash slot up to 4 Gb (accepts standard
Type II Compact Flash or IBM Microdrive®, not included)
Operating System
Real-time, preemptive,multitasking kernel, multi-threaded,
FAT32 file system with long names; supports SIMPL™
W
indows® and SIMPL+®
Ethernet Support
10/100BaseT,static IP or DHCP/DNS, SSL protection, autonegotiating,full/half duplex TCP/IP, UDP/IP, SMTP, built-in Web
server and e-mail client; supports Crestron e-Control 2 XPanel
and R
Graphics Engine
Isys engine,24 Bit non-palette graphics + 8 Bit alpha
(transparency) and video,16.7 million colors,Synapse image
rendering algorithm
Video Processor
Digital Sampling: 24 bits per pixel, 8 bits per color
Resolution: 24 bit video/graphics
Output Color Depth: 32 bits per pixel consisting of 24-bit color
+ 8-bit alpha (transparency) channel
Effects: pan, fade, dissolve, reveal, stretch,cut, zoom
Video Switcher and Scalers
Seamless Matrix Switcher: Up to 12 inputs routed to 4 scalers;
accommodates versatile combinations of composite, S-Video
and component sources; automatically routes signals based
upon scaler availability
Scalers: (4) built-in scalers provide motion adaptive
deinterlacing and line doubling of video sources and scaling
of RGB sources
Connectors
VIDEO INPUT 1 - 4: (12) BNC female
(4) sets of (3) inputs,
(1) Component (Y/Pb/Pr,480i/576i) video input,or
(3) Composite (NTSC/PAL) video inputs, or
(1) S-Video (Y/C) input and (1) Composite input
inimum/maximum le
M
DC restoration;
edanc
Imp
Horizontal frequency: 15.75 kHz (NTSC);15.625 kHz (PAL)
Vertical frequency: 50-60 Hz
GB 1 - 4:
VI/R
D
GB (
(4) R
included;
Analog formats: RGBHV, RGBS and RGsB
Digital formats:TMDS (DVI)
EDTV/HDTV: 480p,720p, 1080i (requires component-to-VGA
adapter,not included);
Input r
x 1200 maximum (RGB), or 1280 x 1024 maximum (DVI)
[60 Hz limit a
inimum/maximum le
M
DC restoration;
Impedance: 75 ohms
lash, 32MB SDRAM,256KB NVRAM,and 32MB
oomView applications
each set configurable as:
o 1.5 Volts p-p with built-in
.5 t
els:
v
e: 75 ohms
emale
VI-I f
(4) D
VGA) or DVI inputs,(4) DB15HD VGA adapters
ed: 640 x 400 minimum to 1600
lac
er
t
esolution,
non-in
t 1600 x 1200];
vels: .5 to 1.5 Volts p-p with built-in
Sync input type: Autodetect RGBHV, RGBS,RGsB
Sync input level:3.0 to 5.0 Volts p-p
Sync input impedance: 1K ohms
Maximum Sync input: 5.0 Volts p-p
Horizontal frequency: 31.5 to 100 kHz (RGB);31.5 to
64 kHz (D
VI);
Vertical Frequency: 50 to 85 Hz (RGB); 60 to 75 Hz (DVI)
DVI/RGB OUTPUT: (1) DVI-I female
RGB (VGA) or DVI output, DB15HD VGA adapter included
Connects to analog (RGB/DVI-A) or digital (DVI-D) display
device;
Analog formats: RGBHV, RGBS
Digital formats:TMDS (DVI)
EDTV/HDTV: 480p and 720p output as RGB
A
spect ratio: Software programmable 4:3 or 16:9
Output resolution: 800 x 600 min.to 1600 x 1200 max. (RGB)
or 1280 x 1024 max. (DVI) [60 Hz limit at 1600 x 1200];
Sync output type: RGBHV, RGBS
Sync output level:TTL,5.0 Volts p-p
Polarity: Composite sync,negative
Vertical Frequency: 60 to 85 Hz (RGB); 60 to 75 Hz (DVI)
[60 Hz limit at 1600 x 1200]
COM: (4) DB9 male
(4) Bidirectional RS-232 ports
Up to 115.2k baud
Hardware and software handshaking support
TOUCHSCREEN/MOUSE: (1) DB9 female
RS-232 connection for touchscreen, touch-sensitive overlay,
or pointing device; Contact Crestron to confirm compatibility
COMPUTER: (1) DB9 female
RS-232 computer console port
LAN: (1) 8-wire RJ45 with 2 LED indicators
10/100BaseT Ethernet port
Green LED indicates link status
Yellow LED indicates Ethernet activity
NET: (1) 4-pin 5mm detachable terminal block
Cresnet port, Master/Slave selectable
Expandable via C2N-NPA8 Network Poll Accelerator
24 Volt DC power input
LED Indicators
PWR: (green) indicates 24 Volts DC is applied to the unit
NET: (yellow) indicates communication with Cresnet network
Power Requirements
50
Watts (2.0 Amps @ 24 Volts DC) - CNPWS-75 or
C2N-SPWS300 power supply required (sold separately)
Available Cresnet power: 0 Watts
Environmental
Temperature: 41° to 113°F (5° to 45°C)
:
y
Humidit
Enclosure
lack metal,
B
Dimensions
Height: 3.47 in (8.82 cm)
idth:
W
without ears;
Depth: 12.10 in (30.74 cm)
eigh
W
7.8 lbs (3.5 kg)
o 90% RH (non-c
10% t
rack mountable (rack ears included)
2U 19”
19.0 in (48.26 cm) with ears
t
ondensing)
, 17.03 in (43.24 cm)
Specifications subject to change without notice. Doc.6207A 7/04
Crestron C2N-DVP4DI Digital Video Processor
AVAILABLE ACCESSORIES
CNPWS-75
75 Watt Cresnet Power Supply
C2N-SPWS300
300 Watt Cresnet Power Supply
Front View
C2N-HBLOCK
Cresnet Network Distribution Block
CNSP-XX
Custom Serial Interface Cable
Rear View
Specifications subject to change without notice. Doc.6207A 7/04
