Crestron electronic AudioExpander User Manual
Crestron Adagio™ AAE
Audio Expander
Operations Guide
Important Safety Instructions
This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
• Do not defeat the safety purpose of the polarized or groundingtype plug. A polarized plug has two blades with one wider than
the other. A grounding-type plug has two blades and a third
grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the
obsolete outlet.
• Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
• Only use attachments/accessories specified by the
manufacturer.
• Unplug this apparatus during lightning storms or when unused
for long periods of time.
• Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
• Disconnect power prior to connecting or disconnecting
equipment.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE. THE APPARATUS SHALL NOT BE
EXPOSED TO DRIPPING OR SPLASHING. OBJECTS
FILLED WITH LIQUIDS, SU CH AS VASES, SHOULD
NOT BE PLACED ON THE APPARATUS.
WARNING:
TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE
COVER. THERE ARE NO USER SERVICEABLE PARTS
INSIDE. ONLY QUALIFIED SERVICE PERSO NNEL
SHOULD PERFORM SERVICE.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING:
THIS IS AN APPARATUS WITH CLASS I
CONSTRUCTION. IT SHALL BE CONNECTED TO AN
ELECTRICAL OUTLET WITH AN EARTHING GROUND
TERMINAL.
• Do not install in direct sunlight.
• The apparatus must be installed in a way that the power cord
can be removed either from the wall outlet or from the device
itself in order to disconnect the mains power.
• Prevent foreign objects from entering the device.
IMPORTANT:
The AAE can be used with Class 2 output wiring.
All brand names, product names and trademarks are the property of their respective owners.
©2006 Crestron Electronics, Inc.
Crestron Adagio™ AAE Audio Expander
Contents
Audio Expander: Adagio AAE 1
Introduction ...............................................................................................................................1
Features and Functions................................................................................................1
Applications.................................................................................................................1
Specifications ..............................................................................................................2
Physical Description....................................................................................................3
Industry Compliance ...................................................................................................5
Setup..........................................................................................................................................6
Network Wiring...........................................................................................................6
Identity Code...............................................................................................................6
Hardware Hookup .......................................................................................................6
Programming Software..............................................................................................................9
Earliest Version Software Requirements for the PC ...................................................9
Programming with Adagio Composer.........................................................................9
Programming with Crestron SystemBuilder..............................................................10
Programming with SIMPL Windows........................................................................10
Uploading and Upgrading........................................................................................................12
Establishing Communication.....................................................................................12
Programs and Firmware ............................................................................................12
Problem Solving......................................................................................................................13
Troubleshooting.........................................................................................................13
Check Network Wiring..............................................................................................13
Reference Documents................................................................................................14
Further Inquiries........................................................................................................14
Future Updates ..........................................................................................................14
Return and Warranty Policies..................................................................................................15
Merchandise Returns / Repair Service ......................................................................15
CRESTRON Limited Warranty.................................................................................15
Operations Guide – DOC. 6460A Contents • i
Crestron Adagio™ AAE Audio Expander
Audio Expander: Adagio AAE
Introduction
Features and Functions
• High performance audio distribution, multi-channel amplifier
• Out-of-the-box functionality (no programming required) if used with
the Adagio Entertainment System
• Multi-room audio routing for up to six amplified room outputs from as
many of 10 stereo sources
• Independent software-driven room select, room on-off, volume, bass,
treble, balance, loudness, stereo/mono and mute controls available on
every room output
• 1 2 ch annel power amplifier
• 45 watts per channel supports up to six pairs of speakers
• Co mpatible with any Crestron 2-Series control system
• Six powered built-in Cresnet
• LOOP-THRUs for connection to Adagio control unit or 2-Series
control system and additional AAE units
• Av ailable in both domestic (AAE) and international (AAEI) versions
®
ports
Applications
The following diagram shows how an Adagio home entertainment system, using outof-the-box functionality, might be configured to include the Adagio AAE Audio
Expander.
Adagio System Showing the AAE in a Typical Application
Operations Guide – DOC. 6460A Audio Expander: Adagio AAE • 1
Audio Expander Crestron Adagio™ AAE
Specifications
Specifications for the Adagio AAE Audio Expander are listed in the following table.
Adagio AAE Audio Expander Specifications
SPECIFICATION DETAILS
Audio
Controls
Volume Gain -80 to +20dB in 1dB steps
Mute
Input Compensation ±10dB
Bass Gain Range ±12dB @ 100Hz (2dB increments)
Treble Gain Range ±12dB @ 10kHz (2dB increments)
Frequency Response 20Hz to 20kHz ±0.75dB
S/N Ratio 100dB, 20 Hz to 20kHz A-weighted
THD+N 0.05%, 20Hz to 20kHz
Stereo Separation >75dB
Power
Internal (consumption)
Available Cresnet Power
(output)
Heat Dissipation
8-ohm impedance
4-ohm impedance
Default NET ID 31
Operating Environment
Enclosure
Dimensions
Volume, Balance, Bass, Treble, Loudness,
Mute, On/Off, Room On/Off, Source Select,
Mono/Stereo and Input Compensation
-100dB (electronic),
-120dB (amp output relay)
7 Amps, 120 Volts AC @ 60Hz (AAE)
3.5 Amps, 230 Volts AC @ 50Hz (AAEI)
50 Watts (2.08 Amps @ 24 Volts DC)
700 BTU/hr
800 BTU/hr
41° to 104°F (5° to 40°C)
10% to 90% RH (non-condensing)
Black metal with molded ABS/PC front
panel; freestanding
Height: 5.64 in (14.33 cm)
Width: 17.16 in (43.59 cm)
Depth: 18.08 in (45.92 cm)
Weight: 36.6 lbs (16.2 kg)
NOTE: Cable connections can extend the overall depth of the AAE by
approximately two to three inches.
