Crestron Isys™ TPS-3000L
6.4 Inch Lectern/Wall Mounted Touchpanel
Operations Guide
This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON
All brand names, product names and trademarks are the property of their respective owners.
©2002 Crestron Electronics, Inc.
Crestron Isys™ TPS-3000L 6.4" Lectern/Wall Mounted Touchpanel
Contents
6.4 Inch Lectern/Wall Mount Touchpanel: Crestron Isys™ TPS-3000L 1
Introduction ...............................................................................................................................1
Features and Functions................................................................................................ 1
Specifications ..............................................................................................................3
Physical Description.................................................................................................... 5
Industry Compliance ...................................................................................................7
Setup .......................................................................................................................................... 7
Network Wiring........................................................................................................... 7
Identity Code ............................................................................................................... 8
Screen Orientation....................................................................................................... 8
Configuring the Touchpanel...................................................................................... 11
Hardware Hookup .....................................................................................................17
Mounting Options......................................................................................................21
Touchpanel Mounting ...............................................................................................21
Touchpanel Removal................................................................................................. 22
Recommended Cleaning............................................................................................ 23
Programming Software............................................................................................................23
Programming with the Crestron AppBuilder.............................................................24
Programming with SIMPL Windows......................................................................24
Programming with VisionTools™ Pro-e................................................................... 28
“Quick” Pushbuttons ................................................................................................. 32
Reserved Join Numbers............................................................................................. 32
MultiByte International Characters ...........................................................................36
Uploading and Upgrading........................................................................................................ 36
Communication Settings ...........................................................................................37
Uploading a SIMPL Windows Program.................................................................... 39
Uploading a VT Pro-e Project ................................................................................... 40
Firmware Upgrade..................................................................................................... 42
Problem Solving ......................................................................................................................44
Troubleshooting......................................................................................................... 44
Further Inquiries........................................................................................................45
Future Updates ..........................................................................................................45
Appendix: RS-232 Protocol..................................................................................................... 46
Software License Agreement................................................................................................... 48
Return and Warranty Policies.................................................................................................. 50
Merchandise Returns / Repair Service ......................................................................50
CRESTRON Limited Warranty.................................................................................50
Operations Guide – DOC. 6077 Contents • i
Crestron Isys™ TPS-3000L 6.4" Lectern/Wall Mounted Touchpanel
6.4 Inch Lectern/Wall Mount
Touchpanel: Crestron Isys™
TPS-3000L
Introduction
Features and Functions
The TPS-3000L series packs all the power and performance of an Isys panel in a
stylish lectern or wall-mount model. Its compact stature makes the TPS-3000L series
perfect for the home, especially in locations like home theaters, bedrooms and the
home office.
These touchpanels are available in three colors: almond, black, and white. The suffix
‘A’, ‘B’, and ‘W’ respectively denotes color, i.e. TPS-3000LB is a black unit. For
simplicity within this guide, color suffix is omitted.
Featuring a 6.4" active matrix display that provides the finest quality video and
graphics available on a screen of its size, the TPS-3000L features the 65,536-color
Isys engine which allows all graphics to be displayed with incredible brightness and
depth. A light sensor automatically brightens or dims the display with room light for
easy viewing.
TPS-3000L Functional Summary
• 6.4" (1.26cm) Active Matrix Color Display
• 640x480 Screen Resolution
• 16 Bit Non-Palette Graphics, over 64,000 Colors
• 8 Mb of Flash & 8 Mb of DRAM Memory
• Built-in Time-Based Correction for Stable Video & Graphics
• Balanced/Unbalanced Composite Video Input; Supports NTSC/PAL
Formats
• Full Screen Video Capability
(continued on next page)
Operations Guide – DOC. 6077 6.4 Inch Lectern/Wall Mount Touchpanel: Crestron Isys™ TPS-3000L • 1
6.4" Lectern/Wall Mounted Touchpanel Crestron Isys™ TPS-3000L
TPS-3000L Functional Summary (Continued)
• Up to 4,000 Digital and Analog Signal Joins; Up to 999 Serial Signal
Joins
• Built-in Microphone & 2 Speakers (Half Duplex Intercom Capable)
• Stores WAV Sound Files
• Automatic Light Sensor
• Capable of Inverting Image for optimum viewing whether mounting in
a lectern or wall.
• Pop-up sub panels to reduce memory requirements, providing optimal
speed and performance
• Up to 4,000 functions and unlimited screens
• Multiple button, slider control, and icon configurations, including
multi-mode objects
• Fast graphics performance: imported photographs, drawings, and icons
• Support for downloadable fonts – proportional and non-proportional
• Foreign language text
• Five Pushbuttons that can be programmed for quick access to regularly
used functions*
* Custom engraved keys can be ordered separately by using the Crestron Engraver Software. Version
2.0.0.9 or later is available from the Downloads | Software Updates section of the Crestron website
(www.crestron.com
).
Multiple graphics can be displayed on the TPS-3000L without any shift in color
depth or quality. The newest Isys panel also supports real-time video as standard and
can accommodate balanced or unbalanced video, S-Video or composite.
The TPS-3000L's audio capabilities include stereo audio speakers that offer built-in
volume control, a built-in microphone and built-in WAV sound file capability.
This touchpanel also features five engraveable pushbuttons that are backlit for easy
viewing. These buttons can be programmed to access regularly used functions. Each
button also features LED feedback with adjustable brightness to indicate operation.
The purpose of the TPS-3000L touchpanel is to replace large, complicated hardwired panels in either a Cresnet system or an RS-232 system with a series of simpler
screens each specific to the control problem at hand. Thus, a very large number of
functions can be made available to the user without the confusion associated with
hardware panels of that complexity. Icons, graphics, and text can dramatically
increase any user's comprehension of the control environment. Devices, functions,
and control zones are quickly organized and more easily accessed.
The TPS-3000L has a "Dynamic range" compression feature. When enabled, the
audio amplifier gain is reduced dynamically for loud signal levels, thus eliminating
most distortion at the speakers. For quiet audio signals, the gain is not reduced.
When "Dynamic range" compression is turned off (default), the audio amplifier gain
remains fixed for all signal levels at the given volume setting. Refer to the "Audio
Menu" section of "Configuring the Touchpanel" on page 13 for instructions on
selecting this feature.
The TPS-3000L has the ability to transmit touch coordinates when "RS-232 Port for
Touch Output" is selected. Currently Telestrator devices are supported on the
TPS-3000L. Refer to the "RS-232 Menu" section of "Configuring the Touchpanel"
on page 17 for instructions on selecting this feature.
2 • 6.4 Inch Lectern/Wall Mount Touchpanel: Crestron Isys™ TPS-3000L Operations Guide – DOC. 6077
Crestron Isys™ TPS-3000L 6.4" Lectern/Wall Mounted Touchpanel
Specifications
The table below and on the next page provides a summary of specifications for the
TPS-3000L touchpanel.
Specifications for the TPS-3000L Touchpanel
SPECIFICATION DETAILS
Power Requirements 20 Watts (0.83 Amp @ 24 VDC)
Default NET ID 03
Timeout
Signal Join Maximums 4000 Digital and Analog, 999 Serial
Control System Update
1,2,3
Files
2-Series Control System Version C2-2004.CUZ or later
CEN/CN-TVAV Version 5.13.12V.UPZ or later
CNMSX-AV/PRO Version 5.12.63X.UPZ or later
CNRACKX/-DP Version 5.07.06W.UPZ or later
ST-CP Version 4.02.04S.UPZ or later
Acceptable File Extensions4
SIMPL Windows
.smw
.spz
.bin
.csz
VT Pro-e
.vtp
.vtz
Firmware
.csf
Audio
Adjustable from 0 to 120 minutes (Default = 10
min.)
projectname.smw (source file)
projectname.spz (compiled file for 2-Series)
projectname.bin (compiled file for CNX generation)
projectname.csz
(compiled file for CNX generation with SIMPL+)
projectname.vtp (source file)
projectname.vtz (compiled file)
TPS-3000xxxxxx.csf (panel firmware)
• Balanced (20 kΩ) & unbalanced (10 kΩ) line
level stereo input through 6-position miniphoenix.
• Maximum input level 2Vrms single ended,
4Vrms differential with internal volume
control and two speakers.
• Balanced line level microphone with AGC
output via 3-position mini-phoenix.
• Maximum output level 1Vrms single ended,
2Vrms differential
• Built-in WAV file (8bit 8kHz mono PCM type)
& key click capability
• Speaker amplification: 2 Watts per channel
(continued on next page)
Operations Guide – DOC. 6077 6.4 Inch Lectern/Wall Mount Touchpanel: Crestron Isys™ TPS-3000L • 3
6.4" Lectern/Wall Mounted Touchpanel Crestron Isys™ TPS-3000L
Specifications for the TPS-3000L Touchpanel (Continued)
SPECIFICATION DETAILS
Video
• Composite/S-Video input through 6-position
mini-phoenix (Balanced 100 Ω: cable run not
to exceed 500 feet (152.4 meters)), or BNC
(Unbalanced 75 Ω: cable run not to exceed
100 feet (30.5 meters)).
• Built-in time base correction for stable video
and graphics
• Video can be displayed full screen or in a
window
• NTSC and PAL supported
• De-interlaced (still) and line doubled (motion)
modes are supported
• Adjustments for brightness, contrast, hue
and saturation available
Memory
8MB internal flash memory (7MB for user display
lists), 8MB of DRAM
Screen Dimensions 6.4"/16.3 cm diagonal
Screen Viewing Angles: Y Dir. (X=0o): +40o (from top), -55o (from bottom)
X Dir. (Y=0o): +60o (from right), -60o (from left)
Screen Resolution 640 x 480 pixels
Color
16 Bit non-palette graphics with color key video
window capability, 65,536 colors
Display Type Touch-sensitive active matrix color LCD
Enclosure
Black metal enclosure with injection-molded
plastic faceplate in black, white, or almond.
CPU
63MIPs Coldfire processor running Isys generation
firmware
Cresnet Via 4-position mini-phoenix connector
RS-232 RJ11 connector for console, telestrator, etc.
Default settings: 115200, 8 bit, parity none, stop
bit 1.
Operating Temperature
and Humidity
Dimensions and Weight
(with faceplate)
50º to 113º F (10º to 45º C),
10 to 90% Relative Humidity (non-condensing)
Height: 7.65 in (19.43 cm)
Width: 9.36 in (23.77 cm)
Depth: 2.74 in (6.95 cm)
Weight: 2.8 lbs (1.3 kg)
Programmable
Pushbuttons
5 with fixed join numbers. Join numbers are 1 to 5
(top to bottom) regardless of screen orientation.
Custom engraved buttons can be ordered
separately from Crestron.
1. The latest versions can be obtained from the Downloads | Software Updates section of the Crestron
website (www.crestron.com)
2. Crestron 2-Series control systems include the AV2, CP2, CP2E, MP2, MP2E, PAC2, PRO2, and
RACK2.
3. CNX update files are required for either CNMSX-AV/Pro or CNRACKX/-DP. Filenames for CNX
update files have a UPZ extension and ST-CP files are in one EXE or zipped UPZ file. To avoid program
problems, make certain you are using the update file with the correct suffix letter (e.g., S, V, W, X).
. Refer to NOTE after last footnote.
4 • 6.4 Inch Lectern/Wall Mount Touchpanel: Crestron Isys™ TPS-3000L Operations Guide – DOC. 6077
Crestron Isys™ TPS-3000L 6.4" Lectern/Wall Mounted Touchpanel
4. Extension requires a prefix specific to the touchpanel type. In DETAILS, projectname represents the
assigned project name, and xxxxxx represents a version number.
NOTE: Crestron software and any files on the website are for Authorized Crestron
dealers only. New users may be required to register to obtain access to certain areas
of the site (including the FTP site).
Physical Description
The 6.4 inch (16.26 cm) touch sensitive viewing screen is located on the front of the
TPS-3000L touchpanel with five engraveable pushbuttons on the side. A faceplate
conceals two speakers, a photosensor and a microphone. The electronic hardware is
housed in a metal enclosure, with a colored faceplate as shown after this paragraph.
All audio, video, RS-232, network, and power connections are made at the rear of
the unit.
This touchpanel is designed for placement in a wall or on a lectern/podium. When
placing in a wall, the touchpanel should be installed with the pushbuttons on the left
side of the screen for optimum viewing. If the touchpanel is to be mounted in a
lectern or podium, the touchpanel should be installed with the pushbuttons located on
the right side of the screen for optimum viewing. Refer to "Screen Orientation" on
page 8 for more information.
TPS-3000L Shown with Optional Engraved Buttons (Unit Ships with Colored Blanks)
Operations Guide – DOC. 6077 6.4 Inch Lectern/Wall Mount Touchpanel: Crestron Isys™ TPS-3000L • 5
6.4" Lectern/Wall Mounted Touchpanel Crestron Isys™ TPS-3000L
Physical Views of the TPS-3000L Touchpanel (Top, Front, and Side)
8.60 in
(21.84 cm)
8.45 in
(21.46 cm)
2.81 in
(7.29 cm)
9.36 in
(23.77 cm)
2.67 in
(6.78 cm)
2.30 in
(5.84 cm)
Physical View of the TPS-3000L Touchpanel (Back)
8.05 in
(20.45 cm)
7.65 in
(19.43 cm)
(1.00 cm)
0.32 in
(0.81 cm)
6.57 in
(16.69 cm)
0.40 in
7.00 in
(17.79 cm)
6 • 6.4 Inch Lectern/Wall Mount Touchpanel: Crestron Isys™ TPS-3000L Operations Guide – DOC. 6077
Crestron Isys™ TPS-3000L 6.4" Lectern/Wall Mounted Touchpanel
Industry Compliance
As of the date of manufacture, the touchpanel have been tested and found to comply
with specifications for CE marking and standards per EMC and
Radiocommunications Compliance Labelling (N11785).
NOTE: This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that
may cause undesired operation.
Setup
Network Wiring
NOTE: When installing network wiring, refer to the latest revision of the wiring
diagram(s) appropriate to your specific system configuration, available from the
Downloads | Product Manuals | Wiring Diagrams section of the Crestron website
(www.crestron.com).
When calculating the wire gauge for a particular Cresnet run, the length of the run
and the power factor of each Cresnet unit to be connected must be taken into
consideration. If Cresnet units are to be daisy-chained on the run, the power factor of
each network unit to be daisy-chained must be added together to determine the
power factor of the entire chain. The length of the run in feet and the power factor of
the run should be used in the following resistance equation to calculate the value on
the right side of the equation.
Resistance Equation
40,000
Where:
R <
L x PF
The required wire gauge should be chosen such that the resistance value is less than
the value calculated in the resistance equation. Refer to the table after this paragraph.
Wire Gauge Values
RESISTANCE (R) WIRE GAUGE
4
6
10
15
13
8.7
R = Resistance (refer to table below).
L = Length of run (or chain) in feet.
PF = Power factor of entire run (or chain).
16
18
20
22
Doubled CAT5
Tripled CAT5
Operations Guide – DOC. 6077 6.4 Inch Lectern/Wall Mount Touchpanel: Crestron Isys™ TPS-3000L • 7
6.4" Lectern/Wall Mounted Touchpanel Crestron Isys™ TPS-3000L
NOTE: All network wiring must consist of two twisted pairs. One twisted pair is
the +24V conductor and the GND conductor. The other twisted pair is the Y and Z
conductors.
NOTE: When daisy-chaining Cresnet units, strip the ends of the wires carefully to
avoid nicking the conductors. Twist together the ends of the wires that share a pin on
the network connector, and tin the twisted connection. Apply solder only to the ends
of the twisted wires. Avoid tinning too far up the wires or the end becomes brittle.
Insert the tinned connection into the Cresnet connector and tighten the retaining
screw. Repeat the procedure for the other three conductors.
NOTE: For larger networks (i.e., greater than 28 network devices), it may become
necessary to add a Cresnet Hub/Repeater (CNXHUB) to maintain signal quality
throughout the network. Also, for networks with lengthy cable runs, it may be
necessary to add a Hub/Repeater after only 20 devices.
Identity Code
Every equipment and user interface within the network requires a unique Cresnet
identity code (NET ID). These codes are recognized by a two-digit hexadecimal
number ranging from 03 to FE. Refer to “Interface Menu” on page 13 for
instructions on setting the unit's NET ID. The NET ID of the unit must match the
NET ID specified in the SIMPL Windows program. Refer to “Setting the Net ID in
Device Settings” on page 26 for information about changing the ID in a SIMPL
Windows program.
Screen Orientation
When installing the TPS-3000L into a wall or lectern, the screen must be properly
oriented for optimum viewing. Incorrect orientation of the screen will not allow the
screen to be viewed at its brightest during operation.
Wall Mounting
The TPS-3000L ships in the default “Upright” configuration for mounting in a wall.
The “Upright” configuration provides optimum viewing when installed into a wall.
In this setting, the pushbuttons are located on the left side of the screen, and the
screen orientation is set to “Upright” (refer to the “Orientation” section of “Screen
Settings” which begins on page 15 for instructions) with the connectors located on
the bottom of the touchpanel. Refer to the following diagram.
Pushbutton Layout and Join Number Assignment Wall Mount
1
2
3
4
5
8 • 6.4 Inch Lectern/Wall Mount Touchpanel: Crestron Isys™ TPS-3000L Operations Guide – DOC. 6077
Crestron Isys™ TPS-3000L 6.4" Lectern/Wall Mounted Touchpanel
Lectern Mounting
If the touchpanel is to be installed into a lectern, the touchpanel must be set to the
“Inverted” configuration. The “Inverted” configuration provides optimum viewing
when installed into a lectern. This configuration requires the pushbuttons to be
placed on the right side of the screen the screen orientation set to “Inverted”
operation (refer to “Screen Settings” on page 15 for instructions), and the connectors
to be located at the top of the touchpanel. Refer to the following diagram. Before
installing the touchpanel in the “Inverted” configuration, the pushbuttons must be
reoriented to match the position of the touchpanel. Follow the instructions below to
reorient the pushbuttons.
Pushbutton Layout and Join Number Assignment-Lectern Mount
1
2
3
4
5
NOTE: This Procedure should be done before installing the touchpanel.
Required Tools
#1 Phillips tip screwdriver
1. Place the touchpanel on a flat surface.
2. Remove the faceplate (if installed) and the pushbuttons from the
touchpanel. Number the pushbuttons 1 through 5 (with 1 being the button in
the top position) as they are removed.
3. Use a #1 Phillips screwdriver to remove the two screws that hold down the
pushbutton circuit board. Refer to the following diagram for screw
locations.
Pushbutton Circuit Board (Top View)
+
J2
Screws
J1
Ribbon Cable
+
Operations Guide – DOC. 6077 6.4 Inch Lectern/Wall Mount Touchpanel: Crestron Isys™ TPS-3000L • 9
6.4" Lectern/Wall Mounted Touchpanel Crestron Isys™ TPS-3000L
4. Lift and turn over the pushbutton circuit board to view the cable connecting
the circuit board to the touchpanel. Refer to the following diagram.
Pushbutton Circuit Board (Bottom View)
J2
Screw
Holes
J1
Ribbon Cable
5. Release the tension clip on the ZIF connector (labeled J1) by gently sliding
the clip approximately 1/16” toward the pushbutton circuit board edge and
remove the ribbon cable from the connector. Refer to the pictures after this
step for a detailed view.
NOTE: Do not pull the cable before releasing the tension clip.
Release the Tension Connector: Connector Locked (left) & Unlocked (right)
10 • 6.4 Inch Lectern/Wall Mount Touchpanel: Crestron Isys™ TPS-3000L Operations Guide – DOC. 6077
Crestron Isys™ TPS-3000L 6.4" Lectern/Wall Mounted Touchpanel
Remove the Ribbon Cable
6. Rotate the pushbutton circuit board 180º and slide the ribbon cable into the
open connector (labeled J2). Insert the cable with the leads facing away
from the pushbutton circuit board.
7. Secure the ribbon cable by gently sliding the tension clip toward the
connector body.
8. Turn over the circuit board in its new orientation and install the two
pushbutton circuit board screws to finger-tight. Using a #1 Phillips
screwdriver, tighten each screw an additional 1/8-turn.
9. While holding a finger gently on the touchscreen, connect the power cable
to the NET connector on the touchpanel. This will place the touchpanel in
the setup mode.
10. Set the screen to inverted operation. Refer to “Screen Settings” on page 15
for instructions.
11. Rotate the touchpanel so the pushbuttons are located on the right side of the
touchpanel. If custom engraved button caps exist, install them to match
programming.
12. With the faceplate buttons on the right, place the supplied Crestron label on
the faceplate over the molded Crestron logo (which is now upside down).
13. The touchpanel is now ready for installation in a lectern. Refer to
“Touchpanel Mounting” on page 21 for mounting instructions.
NOTE: The sequence of digital join numbers is (top to bottom) 1 through 5 whether
the touchpanel is mounted with the buttons on the left side or right side.
Configuring the Touchpanel
NOTE: The only connection required to configure the touchpanel is power. Refer to
“Hardware Hookup” on page 17 for details.
Operations Guide – DOC. 6077 6.4 Inch Lectern/Wall Mount Touchpanel: Crestron Isys™ TPS-3000L • 11
6.4" Lectern/Wall Mounted Touchpanel Crestron Isys™ TPS-3000L
MAIN MENU
This menu can also be obtained via
digital reserved join number, 17242.
CALIBRATION MENU
To configure the unit, it may be necessary to access a series of setup screens prior to
viewing run-time screens that are loaded into the touchpanel for normal operation.
The MAIN MENU for configuring the touchpanel appears when a finger is held to
the touchscreen as power is applied. Remove your finger when the message “SETUP
MODE” appears on the touchscreen.
NOTE: The SETUP MODE can also be accessed through the Viewport Utility if the
touchpanel is connected directly to a PC.
Upon entering SETUP MODE, the MAIN MENU, shown to the left, displays four
buttons: Touch Screen Calibration, Exit and Run Program, Setup, and
Diagnostics.
The Exit and Run Program button verifies that all of the setup information has
been saved to EEPROM and displays the main page that has been programmed into
your system. The remaining buttons on the MAIN MENU open other menus, which
are discussed in subsequent paragraphs.
Calibration Menu
Calibration of the touchscreen is required if the active touch area of a button does
not coincide with the button's image. Select the Touch Screen Calibration button to
display the CALIBRATION MENU, shown to the left. The CALIBRATION MENU
offers the choice to initiate calibration with the Perform Calibration button or
return to the previous screen with the Return button. Choose an option by touching
the correct button.
SETUP MENU
If you proceed to calibrate the touchpanel, the screen displays the message "Touch
Upper Left" centered on the panel with a cross hair in the corner. Touch the cross
hair in the corner of the screen to initiate calibration. Another message, "Touch
Upper Right", appears with a cross hair in the correct corner. Touch the corner of the
screen. A final message, “Touch Lower Right”, appears with a cross hair in the
correct corner. Touch the corner of the screen to conclude calibration and return to
the MAIN MENU.
NOTE: When touching the screen during calibration, be as accurate as possible.
Use the tip of a capped pen or the eraser end of a pencil. To cancel calibration and
return to the CALIBRATION MENU without saving calibration data, create a
calibration error by touching the screen in an area that is opposite from the instructed
area.
Setup Menu
To obtain the SETUP MENU, shown to the left, press the Setup button from the
MAIN MENU. The SETUP MENU offers a series of buttons, which opens
additional menus and displays, which are detailed in subsequent paragraphs. After
setup parameters have been set, select the Return button to return to the MAIN
MENU.
NOTE: For convenience, the current CRESNET ID setting is displayed in the lower
left corner.
NOTE: All touchpanel settings are automatically saved in non-volatile memory.
12 • 6.4 Inch Lectern/Wall Mount Touchpanel: Crestron Isys™ TPS-3000L Operations Guide – DOC. 6077
Crestron Isys™ TPS-3000L 6.4" Lectern/Wall Mounted Touchpanel
Interface Menu
INTERFACE MENU
AUDIO MENU
The touchpanel communicates with a control system to activate commands or to
display feedback from components within the system. The communication interface
must be correctly specified or communication will not occur. To set communication
parameters select the Interface button located on the SETUP MENU and display the
INTERFACE MENU, shown to the left.
The Cresnet network identity number (CRESNET ID) is displayed on the
INTERFACE MENU. CRESNET ID is the two-digit hexadecimal number. The
hexadecimal number can range from 03 to FE and must correspond to the NET ID
set in the SIMPL Windows program of the Cresnet system. Matching IDs between
touchpanel and SIMPL Windows program is required if data is to be successfully
transferred. NET ID for the TPS-3000L is factory set to 03, and no two devices in
the same system can have the same ID.
Two buttons adjacent to the hexadecimal display, UP and DOWN, increase and
decrease the CRESNET ID by one, respectively.
Select the Return button located on the INTERFACE MENU to accept the changes
and return to the SETUP MENU.
Audio Menu
Audio is a useful feedback tool and it can be used to enhance a custom interface. To
obtain the AUDIO MENU, shown to the left, press the Audio button from the
SETUP MENU. The AUDIO MENU offers a series of buttons, which opens
additional screens and each is detailed in a table after this paragraph. Two of the
buttons on the AUDIO MENU perform a function directly. The Restore Default
Settings button returns all audio parameters to their default factory settings when the
button is selected. After audio parameters have been set, select the Return button to
accept the changes and return to the SETUP MENU.
The button text shown demonstrates the default audio setting for the given button.
The items in parenthesis are also default values, but are seen in subsequent screens.
Audio Setup Details
AUDIO
MENU
BUTTON
Master
88%
WAV 88%
(On)
AUDIO
SETUP
SCREEN
Master
Volume
WAV
*
DESCRIPTION
The volume of all audio types (WAV, line, and key
click) is affected by the Master Volume control. If the
Master Volume control is set to 100%, the volume for
any type of audio is at maximum. If the Master
Volume is set to 0%, the value of all audio types is
overridden and the touchpanel is silent. If Master
Volume is a percentage (say 50%), then all audio
types can only achieve half their value.
Enable WAV files with the WAV On button. WAV Off
disables this feature. Adjust the volume with the UP
and DOWN buttons. Select the Play WAV File to
sample and adjust the volume as a pre-loaded WAV
file plays.
(continued on next page)
Operations Guide – DOC. 6077 6.4 Inch Lectern/Wall Mount Touchpanel: Crestron Isys™ TPS-3000L • 13
Loading...
