Physical Description
This section provides information on the connections, controls and indicators
available on your TPMC-8T.
4 BATTERY LED (1) Green/yellow dual color LED, not used
5 WIFI LED
6
7 HARD KEYS
8
9
THUMBPAD &
ARROWS2
BIOMETRIC
SCANNER
12V 3.5A
3
Used to “tap” or to do “select and drag”
functions just as you would using a mouse;
Also used to “type” on the input panel
“keyboard” when entering text or commands
(1) Green LED, indicates touchpanel power
status
(1) Green LED, indicates wireless network
connection status:
Solid green – communicating with a wireless
access point (WAP)
Blinking green – searching for a WAP
Off – no wireless communication (unit is in
power down mode or power is off)
(1) programmable 5-way thumbpad (4-way
navigation plus center “Enter” button) and (2)
programmable up/down pushbuttons
(4) Programmable pushbuttons below
touchscreen
AuthenTec EntraPad® 1610 fingerprint
scanner; identifies up to 30 users by
fingerprint
(2) 2.5 mm barrel DC power jacks (right side
and rear) (power supply included)
(1) 8-wire RJ-45 with two LED indicators;
10BASE-T/100BASE-TX Ethernet port;
Green LED indicates link status;
4
LAN
Yellow LED indicates Ethernet activity
PIN SIGNAL PIN SIGNAL
PIN 8
11
USB
4
3
2
1
PIN 1
12 POWER BUTTON
1 TX + 5 N/C
2 TX - 6 RC 3 RC+ 7 N/C
4 N/C 8 N/C
(3) USB 2.0 Type A female
USB 2.0 port for keyboard, mouse and
computer console5
PIN DESCRIPTION
1 +5 VDC
2 Data -
3 Data +
4 Ground
(1) pushbutton, initiates “Power On” and
Power Down”:
Press to turn touchpanel power on; Press
and hold for four seconds to turn power off
(The recommended method for shutting
down the touchpanel is to press the Shut Down button on the setup menu.)
13
HEADPHONES
(1) 3.5 mm TRS mini phone jack;
Stereo headphone output;
Output power: 12 mW per channel;
1. Refer to website or contact Crestron for a current list of compatible devices and embedded
applications. To ensure reliable performance, new device drivers and applications are available only
from Crestron through firmware updates.
2. For programming details, refer to “Hard Buttons” on page 31.
3. Crestron recommends using either the power jack on the base or on the side of the panel but not both
at the same time.
4. To determine which is pin 1 on the cable, hold the cable so that the end of the eight pin modular jack
is facing away from you, with the clip down and copper side up. Pin 1 is on the far left.
5. Only generic USB devices (i.e. simple keyboard, mouse and external storage) should be used with the
TPMC-8T. Any complex USB devices (e.g. a storage device with a built-in fingerprint scanner) will
not have the proper support on the panel.
As of the date of manufacture, the TPMC-8T has been tested and found to comply
with specifications for CE marking and standards per EMC and
Radiocommunications Compliance Labelling.
Federal Communications Commission (FCC) Compliance Statement
This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the manufacturer
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
When wiring the Ethernet network, consider the following:
• Use Crestron Certified Wire.
• Use Crestron power supplies for Crestron equipment.
• Provide sufficient power to the system.
CAUTION: Insufficient power can lead to unpredictable results or damage
to the equipment. Please use the Crestron Power Calculator to help calculate
how much power is needed for the system (www.crestron.com/calculators
Unlike other Crestron network devices, the TPMC-8T does not use Cresnet for
communications between the device and the control system. The TPMC-8T requires
the use of a high-speed Ethernet connection for control system communications.
).
For information on connecting Ethernet devices in a Crestron system, refer to the
latest version of the Crestron e-Control
available from the Crestron website (www.crestron.com/manuals
Reference Guide (Doc. 6052), which is
).
Identity Code
The IP ID is set within the TPMC-8T’s table using Crestron Toolbox™. For
information on setting an IP table, refer to the Crestron Toolbox help file. The IP IDs
of multiple TPMC-8T devices in the same system must be unique.
When setting the IP ID, consider the following:
• The IP ID of each unit must match an IP ID specified in the SIMPL™
Windows
• Each device using IP to communicate with a control system must have a
unique IP ID.
®
program.
Configuring the Touchpanel
NOTE: The only connection required to configure the touchpanel is power.
The TPMC-8T is configured from the setup menu.
NOTE: If no project has been loaded or if an invalid project has been loaded, the
touchpanel displays an error message and defaults to the setup menu screen.
If a project is running, the setup menu can be accessed using one of three methods.
Press the four hard keys at the bottom of the touchpanel in sequence, from left to
right and again from left to right (i.e. press 1, 2, 3, 4, 1, 2, 3, 4) within a 10 second
period.
1. Attach a USB keyboard (refer to “Hardware Hookup” on page 44 for
details).
2. Open the “Validate User Account Info” window (shown below) by pressing
Ctrl+Alt+Shift on the keyboard.
“Validate User Account Info” Window
3. Enter the user account tpmcadmin, and the password tpmcadminand touch
Validate.
NOTE: The password is case sensitive. After logging in, the password can be
changed from the “Security” window. Refer to “Security” on page 14 for more
information.
Via Crestron Toolbox
4. When the “TPMC-8X Debug Output” window appears (shown below),
select Project | Enter Setup Mode to enter the setup menu (refer to “Setup
Menu Details” which starts on page 14).
“TPMC-8X Debug Output” Window
1. Establish communication with the touchpanel (refer to “Establishing
Communication” on page 55 for details).
2. Right-click on the device and select Functions | Setup Mode….
3. Select Enter Setup Mode. The setup menu will be displayed as shown in
the following diagram.
NOTE: Select Exit Setup Mode to exit the setup menu.
TPMC-8T Setup Menu
NOTE: Another way to enter the setup menu (after a project has been loaded) is to
touch the screen during boot up when you see the “Preparing to Load Project”
message. Maintain touch until after the countdown, when the message will change to
“Loading Setup Screen”.
The setup menu provides access to all basic functions and parameters. It is divided
into Setup, Ethernet, Battery, Standby, Power Down, Screen Brightness, WiFi Status
and Docking Station Status sections. There are also buttons for Install, Save & Reboot, Shut Down and Exit.
NOTE: The Battery and Power Down sections of the setup menu are not applicable
to the TPMC-8T and are not used.
NOTE: To allow the touchpanel to upload projects, Standby is disabled until
approximately five minutes after the project is loaded.
NOTE: The Install button is reserved for future applications.
To exit the setup menu and return to the program, touch Exit, located at the bottom
of the setup menu. To save any changes and reboot the touchpanel, touch Save & Reboot, located at the bottom of the setup menu. Use the Shut Down button to turn
off the touchpanel.
Setup Menu Details
The setup menu allows configuration of the touchpanel’s settings for security, touch
screen calibration, runtime project, audio, embedded applications, diagnostics and
hard button programming. The setup menu also has a button that will toggle the onscreen keyboard on and off.
Security
The Security button opens the “Security Setup” window, which allows the user to
change the username and password of the system account, setup and close network
connections and clear cookies.
NOTE: To use the on-screen keyboard for security settings, touch Keyboard on the
setup menu before touching Security.
“Security Setup” Window
Touch Setup Connections… to open the “Network Connections” window. This
window is used to map to a network drive. A mapped network drive permits easy
access to embedded application files (Word, Excel, PowerPoint, etc.) and provides a
location to save files. To further customize the installation, network drives
containing compiled touchpanel project files can also be mapped.
“Network Connections” Window
To add a new network connection, touch Add.
“Configure Network Connection” Window
To add a network drive, touch
1. Map this connection by selecting a drive letter from the Map Drive Letter
drop box.
2. Enter a User Name and Password.
3. Touch the Remember and reconnect on startup checkbox if so desired.
4. Touch OK to enable the new network connection and return to the
“Network Connections” window.
to browse for the new network connection.
Once all changes to network connections have been completed, touch OK to return
to the “Security Setup” window.
The Certificates button can be used to install or uninstall certificates used for server
and/or user authentication when making a secure connection (for example, to a
secured wireless access point). In order to use certificates, the TPMC-8X Security
Pack must be installed (refer to “Appendix A: TPMC-8T Security Pack (Atheros)”
which starts on page 62 or “Appendix B: TPMC-8T Security Pack (Intel PROSet)”
which starts on page 66 for details).
Touch Close to return to the setup menu.
Touch Screen
When Touch Screen is touched, the calibration screen will be displayed. Touch the
screen to begin the calibration process. If the screen is not touched within 10
seconds, the calibration sequence will stop and the screen will again display the
setup menu.
If the screen is touched within the 10-second timeout, it displays a series of messages
indicating that you should touch the red square in five places around the screen.
These messages will appear sequentially starting with “Touch the red square” at the
top of the screen toward the upper left corner. Touch and hold the center of the red
square to initiate calibration. The message will say “Hold…” for a few seconds, then
change to “Lift off to proceed”. Touch the displayed squares as prompted
everywhere they appear around the screen until the calibration is complete and you
are returned to the setup menu.
NOTE: When touching the screen during calibration, be as accurate as possible.
Use the tip of the included stylus. To cancel calibration and return to the setup menu
without saving calibration data, ignore the “Touch the red square” message. After
about 10 seconds, the setup menu will be displayed. If a USB keyboard is attached to
the touchpanel, you can also press the Escape key (Esc) to cancel calibration and
return to the setup menu.
NOTE: The touchpanel’s calibration routine can also be accessed through Crestron
Toolbox if the touchpanel is connected to a control system via TCP/IP. From the
System Info page, select Functions | Setup Mode…. Select Enter Calibration Mode to begin calibration.
Update Panel
The Update Panel button permits the selection of the touchpanel program, a .vtz
file. The Project tab of the “Project and Firmware” window (refer to illustration on
the following page) displays the Current Loaded Project and also has a Load New
Project section.
Current Loaded Project displays the Name and Creation Time of the current project.
In the Load New Project section, touch Browse and select the compiled project (i.e.
the .vtz file) to be loaded from a network drive, USB device or flash drive. You can
choose the location where your uncompressed project files will be stored. The
default file location is the internal flash. Touch Load to uncompress the project file,
place it in the destination selected in Target Location to Load the Project to and
display it on the touchpanel.
NOTE: If there is a mapped network drive on the touchpanel, the first time you
select Browse, it may take some time for the “Open” window to appear.
NOTE: When selecting Browse, the contents of the “Recent” folder will not be
available.
NOTE: Projects can also be loaded via Crestron Toolbox.
NOTE: If External is checked, the display list cannot be viewed via Crestron
Toolbox.
“Project and Firmware” Window (Project Tab)
The Firmware tab of the “Project and Firmware” window (refer to illustration
below) displays the Current Loaded Firmware and also has a Load New Firmware
section.
Current Loaded Firmware displays the Version of the current firmware.
In the Load New Firmware section, touch Browse and select the firmware file (i.e.
the .csz or .zip file) to be loaded from a network drive, USB device or flash drive.
Touch Load to load the new firmware.
The Audio button opens the “Audio Setup” window. Overall All Audio volume and
balance controls and a Mute checkbox are available as well as volume and balance
controls and Mute checkboxes for Wave Out and Microphone In. The Microphone In
settings also include a Boost checkbox, which applies a 20 dB boost to the level of
the microphone input. The key click sound can be enabled or disabled with the Key ClickOn and Off radio buttons.
NOTE: The Audio Output section of the “Audio Setup” window is not applicable to
the TPMC-8T and is not used.
Touching Play Test plays a short internal audio file. Changes to audio settings are
made in real time.
The Embed Apps button opens a window that permits you to set internet security to
different levels for different types of internet sites.
“Embedded Apps” Window
Three security levels (High, Medium and Low) can be selected for each of the three
zones (Internet, Local Intranet, and Trusted Sites). The security levels are defined
as:
• High: The safest way to browse, but also the least functional. Less secure
features are disabled. Appropriate for sites that may have harmful content.
• Medium: Safe browsing and still functional. Prompts before downloading
potentially unsafe content. Unsigned ActiveX controls will not be
downloaded. Appropriate for most internet sites.
• Low: Minimal safeguards and warning prompts are provided. Most content
is downloaded and run without prompts. All active content can run.
Appropriate for sites you absolutely trust.
Touch Default to restore the default security settings. By default, security is set to
Medium for Internet and Local Intranet, and Low for Trusted Sites.
The “Embedded Apps” window also permits you to enable the popup windows
(child windows) that open when you are in Internet Explorer (not the popup windows
of the embedded applications).
NOTE: Refer to the Crestron website (www.crestron.com
4190, for information on the latest versions of the software.
Touch Close after all changes have been made. The touchpanel must be rebooted for
changes to take effect. Refer to “Save & Reboot and Shut Down Details” on page 43
for more information.
A list of trusted sites can be created and edited by touching Add/Remove Trusted
Sites. Touching this button will open the “Trusted Sites” window. From here, trusted
sites can be added and edited. Sites are listed by domain name or IP address. Once
all sites have been entered, touch Close.
“Trusted Sites” Window
NOTE:Save & Reboot on the setup menu must be selected for Embedded Apps
changes to take effect.
NOTE: While browsing the Internet with the TPMC-8T, clicking on a link may
cause a message box titled "Restrictions" to appear that contains the text "This
operation has been cancelled due to restrictions in effect on this computer. Please
contact your system administrator." If this message appears, checking Enable Popup Windows in the “Embedded Apps” window may correct this error. Other restrictions
may also cause this error, so this may not prevent all occurrences.
NOTE: The TPMC-8T Multi-Language Pack allows the user to view documents
written in any of 32 supported international languages by all the embedded apps in
the touchpanel. For details, refer to “Appendix C: TPMC-8T Multi-Language Pack”
on page 71.
NOTE: The TPMC-8T supports automatic connection to the VNC server when the
VNC View application is opened. For automatic connection without having to enter
the server location and password every time the VNC viewer is opened, launch the
application and using a USB mouse, right-click on the VNC viewer window, then
select Save configuration info as….
NOTE: Refer to the Crestron website (www.crestron.com
4627, for information on how to set up the VNC viewer. Refer to Answer ID 3345
for information on how to program the MJPEG viewer. Refer to Answer ID 4640 for
information about the default paths for embedded applications and dynamic graphics.
The built in fingerprint scanner makes user identification easy. Up to 10 fingers can
be scanned for each user. Each finger scan is able to trigger a join and/or an
automated action (such as entering setup mode, wake, sleep, etc.).
Touching Biometric will display the “Biometric Configuration Properties” window.
New users can be enrolled from here and the resulting join and/or action for each
finger can be edited. The Enabled button at the bottom of the window can be used to
turn the fingerprint scanner on and off.
