The RMK-15L is a complete rack mount kit that has been developed for the Crestron
E
TPS-15L, TPS-15G-L, TPMC-15-CH-L, and TPMC-15-QM-L series of wall mounted
touchpanels. Use the supplied hardware to attach the touchpanel to the rack mount kit.
Supplied Hardware
The RMK-15L consists of a mounting plate and screws to secure the touchpanel to the plate.
These items along with the touchpanel produce an assembly that can be attached to a 19”
EIA Equipment rack. The RMK-15L is 15.72 inches (39.93 cm) high x 19 inches (48.26 cm)
wide, and is designed to occupy nine rack spaces. Rack-mounting hardware is not supplied.
DESCRIPTION PART NUMBER QUANTITY
Rack Mounting Plate, 9 RU High 2013033 1
Screw, 6-32, 1/4"L, Pan, Phil, Blk 2007213 8
Assembly View
Assembly of the RMK-15L to the
touchpanel is illustrated to the right.
Exercise caution when handling the
touchpanel to avoid damaging the
exposed components. After attaching
the plate to the rack, use a #2 Phillips
head screwdriver to secure the
touchpanel to the rack mounting plate
with the eight supplied screws (do not
use the screws supplied with the
touchpanel). Torque should not
exceed 11 in-lbs (1.243 N*m). Use
caution when handling the touchpanel
as not to damage or scratch the view
screen. After the touchpanel is
secured to the rack plate, install the
buttons and the touchpanel faceplate.
Rack Mount Kit: RMK-15L
RACK MOUNTING PLAT
(2013033)
TOUCHPANEL
FACEPLATE
TOUCHPANEL
1/4" MOUNTING SCREWS, QTY. 8
(SUPPLIED BY CRESTRON)
Further Inquiries
If you cannot locate specific information or have questions after reviewing this guide, please
take advantage of Crestron's award winning customer service team by calling the Crestron
corporate headquarters at 1-888-CRESTRON [1-888-273-7876]. For assistance in your local
time zone, refer to the Crestron website (www.crestron.com) for a listing of Crestron
worldwide offices.
You can also log onto the online help section of the Crestron website to ask questions about
Crestron products. First-time users will need to establish a user account to fully benefit from
all available features.
As of the date of manufacture, the RMK-15L has been tested and found to comply with
specifications for CE marking.
Crestron Electronics, Inc. Installation Guide – DOC. 6366
15 Volvo Drive (2013142)
Rockleigh, NJ 07647 07.05
Tel: 888.CRESTRON Specifications subject to change without notice.
Fax: 201.767.7576 www.crestron.com
Return and Warranty Policies
Merchandise Returns / Repair Service
1. No merchandise may be returned for credit, exchange, or service without prior authorization
from CRESTRON. To obtain warranty service for CRESTRON products, contact the factory
and request an RMA (Return Merchandise Authorization) number. Enclose a note specifying
the nature of the problem, name and phone number of contact person, RMA number, and
return address.
2. Products may be returned for credit, exchange, or service with a CRESTRON Return
Merchandise Authorization (RMA) number. Authorized returns must be shipped freight
prepaid to CRESTRON, 6 Volvo Drive, Rockleigh, N.J., or its authorized subsidiaries, with
RMA number clearly marked on the outside of all cartons. Shipments arriving freight collect
or without an RMA number shall be subject to refusal. CRESTRON reserves the right in its
sole and absolute discretion to charge a 15% restocking fee, plus shipping costs, on any
products returned with an RMA.
3. Return freight charges following repair of items under warranty shall be paid by CRESTRON,
shipping by standard ground carrier. In the event repairs are found to be non-warranty, return
freight costs shall be paid by the purchaser.
CRESTRON Limited Warranty
CRESTRON ELECTRONICS, Inc. warrants its products to be free from manufacturing defects in materials
and workmanship under normal use for a period of three (3) years from the date of purchase from
CRESTRON, with the following exceptions: disk drives and any other moving or rotating mechanical
parts, pan/tilt heads and power supplies are covered for a period of one (1) year; touchscreen display and
overlay components are covered for 90 days; batteries and incandescent lamps are not covered.
This warranty extends to products purchased directly from CRESTRON or an authorized CRESTRON
dealer. Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if
any.
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any
application other than that for which it was intended, or if it has been subjected to misuse, accidental
damage, modification, or improper installation procedures. Furthermore, this warranty does not cover any
product that has had the serial number altered, defaced, or removed.
This warranty shall be the sole and exclusive remedy to the original purchaser. In no event shall
CRESTRON be liable for incidental or consequential damages of any kind (property or economic damages
inclusive) arising from the sale or use of this equipment. CRESTRON is not liable for any claim made by a
third party or made by the purchaser for a third party.
CRESTRON shall, at its option, repair or replace any product found defective, without charge for parts or
labor. Repaired or replaced equipment and parts supplied under this warranty shall be covered only by the
unexpired portion of the warranty.
Except as expressly set forth in this warranty, CRESTRON makes no other warranties, expressed or
implied, nor authorizes any other party to offer any warranty, including any implied warranties of
merchantability or fitness for a particular purpose. Any implied warranties that may be imposed by law are
limited to the terms of this limited warranty. This warranty statement supercedes all previous warranties.
