Crestron PMK-17L User Manual

Crestron PMK-17L
Pre-Construction Mount Kit
Installation Guide

This document was prepared and written by the Technical Documentation department at:

Crestron Electronics, Inc.

15 Volvo Drive

Rockleigh, NJ 07647

1-888-CRESTRON

All brand names, product names and trademarks are the property of their respective owners.

©2005 Crestron Electronics, Inc.

Crestron PMK-17L Pre-Construction Mount Kit

Pre-Construction Mount Kit:
PMK-17L

Description

The PMK-17L is a pre-construction mount kit for the Crestron Isys® TPS-17L wall
mounted touchpanel. The PMK-17L can also be used with the Isys i/O™
TPMC-17-CH-L and TPMC-17-QM-L wall mounted touchpanels. The PMK-17L is
used for installation on two studs with a 16¼-inch (minimum) space between the
studs. For custom touchpanel placement in a lectern, use the WMKT-17L. The
PMK-17L includes an 18 AWG bus wire to secure touchpanel cabling prior to
drywall installation and to avoid damaging the cables when the opening is routed.
Refer to the physical views (bottom, side, and front) of the PMK-17L, shown after
this paragraph. The table that follows lists all parts included with the PMK-17L.

PMK-17L Physical Views

FOR DRYWALL SCREW
(PROVIDED BY OTHER)

FOR DRYWALL NAIL

(PROVIDED BY OTHER)

SECURE 18 AWG BUS WIRE
IN NOTCH TO HANG CABLES
AWAY FROM DRYWALL
CUTTING TOOLS.

19.00 in

(48.26 cm)

PRE-CONSTRUCTION PLATE COVER PLATE

NOTE: This mounting kit is to be used only with the TPS-17L, TPMC-17-CH-L,
and TPMC-17-QM-L series of touchpanels.

16.00 in

(40.64 cm)

0.06 in

(0.15 cm)

16.40 in

(41.64 cm)

13.56 in

(34.44 cm)

0.03 in

(0.08 cm)

Installation Guide - DOC. 6368 Pre-Construction Mount Kit: PMK-17L • 1

Pre-Construction Mount Kit Crestron PMK-17L

Supplied Components

DESCRIPTION PART NUMBER QUANTITY

Metal, Plate, Mounting 2013468 1

Metal, Plate,Cover 2013467 1

Screw, #6-32, 1-1/2”L, Pan, Phil 2007254 8

Jumper wire, 12”L, 18AWG, Black 2007838 1

Installation

CAUTION: A 24-inch air gap above and below the plate is required when
positioning the PMK-17L.

NOTE: To maintain optimum structural integrity, Crestron recommends installing
header and footer studs around the PMK-17L and the required air gap.

NOTE: The PMK-17L requires a 16¼-inch wide space between the studs where it
is to be placed. The touchpanel will not fit otherwise.

The PMK-17L consists of a single metal plate, which fastens to the studs of a framed
wall prior to hanging drywall (shown after this paragraph). To accommodate the
touchpanel, the space between the studs must be 16¼ inches (minimum). Standard
drywall nails or screws to attach the PMK-17L are not supplied (length can vary).

Metal Plate Secured to Studs

16"

HEADER

16"

AIR

GAP

16.25 min

STUD

PMK-17L

24"

AIR

GAP

24"

FOOTER

16"

2 • Pre-Construction Mount Kit: PMK-17L Installation Guide - DOC. 6368

16"

Crestron PMK-17L Pre-Construction Mount Kit

NOTE: Use the inside edge of PMK-17L for cutting drywall

The plate is designed to provide the necessary support for a single touchpanel and
must mount to the right and left studs. Confirm that the PMK-17L is level before
application of drywall. A rectangular opening with the dimensions shown in the
illustration after this paragraph must be made in the drywall. Verify that the opening
exposes the eight #6-32 tapped holes.

Dimensions for Drywall Cutout

5

~13

(338 mm Max)

EXCEED THIS

DIMENSION

13

~13

in

94

(335 mm Max)

in

16

DO NOT

5

~1

in

64

(29 mm Max)

TYP (4X)

1

~5

in

32

(127 mm Max)

13 in

(330 mm Max)

3

in

~6

16

(157 mm Max)

1

~16

in

4

(412 mm Max)

3

in

Ø

16

(5 mm Max)

TYP (4X)

5

~

in

32

(44 mm Max)

3

~

in

64

(11 mm Max)

If the opening for the touchpanel in the drywall is too large, two pre-construction
accessories are available to make adjustments. Use the optional TMK-17L (Trim
Ring Kit) to provide a smooth edge at the opening. This option provides a finished
appearance and is preferred when wallpaper is hung. Use the optional MMK-17L
(Mud Ring Kit) to fill in larger irregularities around the opening (requires
plastering).

Complete the installation by either installing the touchpanel, leaving the hole open (if
permitted by local building codes), or installing the supplied cover plate with the
included #6-32 x 1½” screws (shown after this paragraph). If the touchpanel is to be
installed, refer to the latest revision of the TPS-12L/15L/17L Operations Guide (Doc.

6355) or the TPMC-15/17-L Series Operations Guide (Doc. 6354) for installation
instructions.

Installation Guide - DOC. 6368 Pre-Construction Mount Kit: PMK-17L • 3

Pre-Construction Mount Kit Crestron PMK-17L

Attaching Cover

PRE-CONSTRUCTION PLATE

(2013468) MUST BE LEVEL BEFORE

APPLICATION OF SHEET ROCK.

DRYWALL

METAL COVER PLATE (2013467 SUPPLIED)

USED TO COVER CUTOUT IN THE DRYWALL

IF TOUCHPANEL IS NOT INSTALLED.

(IF REQUIRED BY LOCAL BUILDING CODES)

SCREW, #6-32, 1-1/2"L

PAN HEAD SCREW

(2007254) QTY. 8

STUDS

NOTE: Prior to mounting the touchpanel, ensure that the PMK-17L is flush with
the drywall (no kinks or bends in the metal). Any separation may make screwing in
the touchpanel more difficult. One can purchase and attach a TMK-17L or
MMK-17L to keep the PMK-17L straight.

4 • Pre-Construction Mount Kit: PMK-17L Installation Guide - DOC. 6368

Crestron PMK-17L Pre-Construction Mount Kit

Further Inquiries

If you cannot locate specific information or have questions after reviewing this
guide, please take advantage of Crestron's award winning customer service team by
calling the Crestron corporate headquarters at 1-888-CRESTRON [1-888-273-7876].
For assistance in your local time zone, refer to the Crestron website
(www.crestron.com) for a listing of Crestron worldwide offices.

You can also log onto the online help section of the Crestron website to ask
questions about Crestron products. First-time users will need to establish a user
account to fully benefit from all available features.

As of the date of manufacture, the PMK-17L has been tested and found to comply
with specifications for CE marking.

Future Updates

As Crestron adds improvements to the PMK-17L, additional information may be
made available as manual updates. These updates are solely electronic and serve as
intermediary supplements prior to the release of a complete technical documentation
revision.

Check the Crestron website periodically for manual update availability and its
relevance. Updates are identified as an “Addendum” in the Download column.

Installation Guide - DOC. 6368 Pre-Construction Mount Kit: PMK-17L • 5
