Crestron CP2 User Manual
Crestron CP2 & CP2E
2-Series Compact Control System
Operations Guide
This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON
All brand names, product names and trademarks are the property of their respective owners.
©2006 Crestron Electronics, Inc.
Crestron CP2 & CP2E 2-Series Compact Control System
Contents
2-Series Compact Control System: CP2 & CP2E 1
Introduction ...............................................................................................................................1
Features and Functions................................................................................................ 1
Specifications ..............................................................................................................3
Physical Description.................................................................................................... 4
Industry Compliance ...................................................................................................8
Setup .......................................................................................................................................... 9
Network Wiring........................................................................................................... 9
Identity Code ............................................................................................................... 9
Hardware Hookup .......................................................................................................9
Programming Software............................................................................................................12
Earliest Version Software Requirements for the PC .................................................12
Programming with Crestron SystemBuilder.............................................................. 12
Programming with SIMPL Windows........................................................................ 12
Example Program...................................................................................................... 13
Uploading and Upgrading........................................................................................................ 14
Establishing Communication.....................................................................................14
Programs and Firmware ............................................................................................15
Operation .................................................................................................................................16
Problem Solving ......................................................................................................................17
Troubleshooting......................................................................................................... 17
Check Network Wiring..............................................................................................18
Reference Documents................................................................................................19
Further Inquiries........................................................................................................19
Future Updates ..........................................................................................................20
Software License Agreement................................................................................................... 21
Return and Warranty Policies.................................................................................................. 23
Merchandise Returns / Repair Service ......................................................................23
CRESTRON Limited Warranty.................................................................................23
Operations Guide – DOC. 5980A Contents • i
Crestron CP2 & CP2E 2-Series Compact Control System
2-Series Compact Control
2-Series Compact Control
System: CP2 & CP2E
System: CP2 & CP2E
Introduction Introduction
Features and Functions
• 2-Series engine
• 36 MB of Internal Memory
• Powerful 257 MIPS, 32-bit Motorola Coldfire
• Cresnet
• 10/100 Ethernet with SSL encryption
• Crestron e-Control
• RoomView
• Three Com ports (RS-232/422/485)
• Eight IR/serial ports
• Eight Versiport I/O ports
• Eight Low-voltage relay ports
• Single-space EIA rack-mountable
1. For more information on internal memory, refer to “2-Series Memory & Directory Structure” in the
latest version of the Crestron 2-Series Control System Reference Guide (Doc. 6256), which is available
from the Crestron website (http://www.crestron.com/manuals
2. CP2E only.
®
port – master/slave selectable
®
®
enabled2
2-Series Engine
At the heart of the CP2 & CP2E is the powerful 32-bit Freescale ColdFire®
processor. Crestron's exclusive enhanced real-time operating system makes the CP2
& CP2E the fastest, most reliable control systems available.
1
2 enabled2
®
Processor
2
).
Cresnet®
Cresnet is the communications backbone for many Crestron touchpanels, keypads,
lighting controls and other devices. The Cresnet bus is a simple, yet flexible 4-wire
network that provides rock-solid bidirectional communication and power for up to
252 Cresnet devices.
Operations Guide – DOC. 5980A 2-Series Compact Control System: CP2 & CP2E • 1
2-Series Compact Control System Crestron CP2 & CP2E
Cresnet Slave Mode
Selectable Cresnet Slave Mode enables the CP2 & CP2E to be configured as Cresnet
slave devices, effectively transforming them into Cresnet expansion modules. Such
flexibility can offer a cost-effective solution for system expansion, providing a host
of additional control ports in a single module.
Ethernet (CP2E only)
Crestron pioneered the IP-based control system to harness the vast possibilities of
Ethernet and the Internet for remote control, monitoring, programming and
diagnostics. The CP2E is designed to deliver the world's most advanced IP control
solution. A choice of single or dual port Ethernet cards enables a full-duplex 10/100
Ethernet connection with built-in Web server and email client and support for both
static and dynamic IP addressing.
Crestron e-Control®2 (CP2E only)
Crestron's award-winning e-Control 2 XPanel solutions offer the most flexible range
of IP control possibilities available. Using a Windows® computer or CE/PocketPC™
PDA device, e-Control 2 provides an amazing control GUI that looks and behaves
just like a Crestron Isys® touchpanel.
Crestron RoomView® (CP2E only)
Every Ethernet-enabled 2-Series control system works directly with Crestron's
exclusive RoomView Help Desk software for the industry's most comprehensive
facility-wide asset management solution.
SSL (CP2E only)
All Ethernet-enabled 2-Series control systems support SSL (Secure Sockets Layer),
the industry standard for protecting sensitive network communications.
2 • 2-Series Compact Control System: CP2 & CP2E Operations Guide – DOC. 5980A
Crestron CP2 & CP2E 2-Series Compact Control System
Specifications
Specifications for the CP2 & CP2E are listed in the following table.
CP2 & CP2E Specifications
SPECIFICATION DETAILS
Processor
CPU
Processing Speed 257 MIPS (Dhrystone 2.1 benchmark)
Memory
SDRAM 32 MB
NVRAM 256 kB
Flash 4 MB
Operating System
Ethernet (CP2E only)
Power Requirements
Available Cresnet Power
Cresnet Power Usage
Environmental
Temperature 41º to 113ºF (5º to 45ºC)
Humidity 10% to 90% RH (non-condensing)
Enclosure
Dimensions
Height 1.70 in (4.32 cm)
Width
Depth 6.64 in (16.86 cm)
Weight 3.54 lbs (1.61 kg)
Available Accessories
PW-2420RU 50 Watt Regulated Universal Power Supply
C2N-HBLOCK Cresnet Network Distribution Block
CNSP-XX Custom Serial Interface Cable
IRP2 IR Probe
32-bit Freescale Coldfire
Real-time preemptive multithreaded/multitasking kernel; FAT32 file
system with long names; supports SIMPL
Windows and SIMPL+
10/100BaseT, auto-negotiating, full/half
duplex, static IP or DHCP/DNS, SSL,
TCP/IP, UDP/IP, CIP, SMTP, built-in Web
server and e-mail client; supports Crestron
e-Control2 Xpanel and RoomView
applications
24 Watts (1 Amp) @ 24 Volts DC
(PW-2420RU power supply sold separately)
26 Watts using PW-2420RU
(sold separately)
24 Watts (1 Amp @ 24 Volts DC) with no
power supply connected to the 24VDC
connector
Black metal, 1U 19” rack-mountable
(rack ears included)
19.00 in (48.26 cm) with ears;
17.03 in (43.25 cm) without ears
Microprocessor
Operations Guide – DOC. 5980A 2-Series Compact Control System: CP2 & CP2E • 3
2-Series Compact Control System Crestron CP2 & CP2E
Physical Description
This section provides information on the connections, controls and indicators
available on your CP2 & CP2E.
CP2 Physical Views
CP2E Physical Views
4 • 2-Series Compact Control System: CP2 & CP2E Operations Guide – DOC. 5980A
Crestron CP2 & CP2E 2-Series Compact Control System
CP2 & CP2E Overall Dimensions
32211
4
19.00 in
(48.26 cm)
1.70 in
(4.32 cm)
17.03 in
(43.25 cm)
55
6.64 in
(16.86 cm)
6 12 13
77
111098
Connectors, Controls & Indicators
#
CONNECTORS
1
,
DESCRIPTION
CONTROLS & INDICATORS
1 PWR LED Indicates 24 Volts DC power supplied from Cresnet control network.
2 NET LED Indicates communication with Cresnet System.
3 MSG LED2
4 LAN LEDs3
(Continued on following page)
Operations Guide – DOC. 5980A 2-Series Compact Control System: CP2 & CP2E • 5
Illuminates when a message is detected. To decipher content,
examine the message through the Crestron Toolbox™.
LNK – Indicates when there is a connection to the rear panel LAN
port.
ACT – Indicates communication (activity) at the rear panel LAN port.
