Crestron CNXMIDI User Manual

CRESTRON

Contents

CNX MIDI Interface Expansion Card: CNXMIDI 0

Description 0

Functional Description 0

Physical Description 0
Leading Specifications 0
Setup 0

Installation 0

Preparation for Use 0
Programming with SIMPL Windows 0

How the Program Works 0

How to Create the Program 0
Problem Solving 0

Troubleshooting 0

Further Inquiries 0
Return and Warranty Policies 0

Merchandise Returns / Repair Service 0

CRESTRON Limited Warranty 0

Operations Guide - DOC. 8128 Contents •• i

CRESTRON

CNX MIDI Interface Expansion
Card: CNXMIDI

Description

Functional Description

The CNXMIDI, a MIDI Interface Expansion Card provides MIDI IN, OUT, and

THRU interface. Use with devices such as mixers and lighting equipment.

Physical Description

The CNXMIDI, shown below, is a circuit board fastened to an aluminum faceplate.

The card is manufactured to easily fit into an unoccupied slot in a Crestron CNX

Generation Control System.

CNXMIDI Faceplate

5.000 in

(127.00 mm)

0.980 in

The faceplate contains three female 5-pin DIN connectors. These are standard MIDI

connectors. Silk screening is applied to the faceplate; jacks are labeled THRU, IN,

and OUT from left to right, as shown above.

THRU

CNXMIDI MIDI INTERFACE

IN

OUT

Operations Guide - DOC. 8128 CNX MIDI Interface Expansion Card: CNXMIDI •• 1

CRESTRON

DETAILS

SPECIFICATIONS

Leading Specifications

The table below provides a summary of leading specifications for the CNXMIDI.
Dimensions and weight are approximations rounded to the nearest hundredth unit.

Leading Specifications of the CNXMIDI

Setup

Connectors
Power Requirements 24VDC, network power; 4 Watts
SIMPL™ Windows® Version 1.21.03 or later
CNX Operating System Version 5.01.29x or later
CNX Monitor Version 2.05x or later

Dimensions:

Height 0.98 in (24.9 mm)
Width 5.00 in (127 mm)
Depth 6.58 in (167.1 mm)

As of the date of manufacture, the unit has been tested and found to comply with
specifications for CE marking.

(3) 5-pin DIN connectors

Installation

Items required to install the CNXMIDI are already attached to the unit. The only
tools required are a Phillips tip screwdriver and a grounding strap. Follow the
assembly procedure below.

CAUTION: The CNXMIDI contains electrostatic sensitive devices (ESD); observe
precautions for handling ESDs to avoid damaging the card.

NOTE: If installing the CNXMIDI into a CNMSX-AV, it is assumed that the
CNXCAGE has been installed.

1. Disconnect power from the CNMSX.

2. Use the Phillips tip screwdriver and remove two screws and blank

faceplate from the control system.

3. Align the CNXMIDI with the card guides in the open slot and slide

the expansion card into position.

4. Firmly press both ends of the CNXMIDI faceplate to seat the

expansion card into the control system connector.

5. Tighten the thumb screws to secure the CNXMIDI to the control

system.

6. Reapply power to the CNMSX.

2 •• CNX MIDI Interface Expansion Card: CNXMIDI Operations Guide - DOC. 8128

CRESTRON

MIDI IN

MIDI

OUT & MIDI THRU

PIN

ASSIGNMENT

PIN

ASSIGNMENT

Preparation for Use

The three female connectors on the CNXMIDI accept standard MIDI male cables.

Refer to the pinout table below if the connecting cable is to be made.

Standard MIDI 5-Pin Male DIN Pinout

1 No Connection 1 No Connection
2 No Connection 2 Ground
3 No Connection 3 No Connection
4 Current Source 4 Current Sink
5 Current Sink 5 Current Source

1 3

4 5

2

Programming with SIMPL Windows

SIMPL (Symbol Intensive Master Programming Language) is an easy-to-use

programming language that is completely integrated and compatible with all

Crestron system hardware. The objects that are used in SIMPL are called symbols.

SIMPL Windows offers drag and drop functionality in a familiar Windows®

environment.

SIMPL Windows is Crestron Electronics' software for programming Crestron

control systems. It provides a well-designed graphical environment with a number

of workspaces (i.e., windows) in which a programmer can select, configure,

program, test, and monitor a Crestron control system.

The next two subsections describe a sample SIMPL Windows program that utilizes

the CNXMIDI. The first subsection details how the sample program works with a

textual description and block diagram. The second subsection provides a broad

description of how to actually create the SIMPL Windows program.

NOTE: The following description assumes that the reader is familiar with SIMPL

Windows. If not, please refer to the extensive help information provided with the

software.

NOTE: There is no need to recreate the sample SIMPL Windows program. A copy

of this program is available from Crestron’s ControlCD (Version 5.1 or later).

Search for the CNXMIDI.SMW project in the SIMPL Windows Example Base.

Operations Guide - DOC. 8128 CNX MIDI Interface Expansion Card: CNXMIDI •• 3

CRESTRON

How the Program Works

A basic CNXMIDI SIMPL program is shown in block diagram form below. For this
example, the CNXMIDI occupies slot #1 of a CNMSX-PRO. This example plays
three notes on a MIDI keyboard. A note is turned on for 0.05s and then there is
silence for 0.05s before the next note is played. The sequence is triggered when a
certain note is received from the keyboard, and stopped at the end of the sequence.

Block Diagram of CNXMIDI

4 •• CNX MIDI Interface Expansion Card: CNXMIDI Operations Guide - DOC. 8128

CRESTRON

How to Create the Program

Configuration Manager

Use the Configuration Manager workspace in SIMPL Windows to select and

configure all the devices that need to be included into the system. For this example,

add a CNXMIDI to slot #1 of the control system, shown below.

NOTE: SIMPL Windows v1.21.03 or later is required to program the CNMSX-AV

or PRO with a CNXMIDI card. If using an earlier version of SIMPL Windows,

Crestron recommends a SIMPL Windows and operation system upgrade. The latest

version can be obtained from the Software Downloads page of Crestron’s website

(www.crestron.com). New users are required to register in order to obtain access to

the FTP site.

Graphical System View of CNXMIDI in SIMPL Windows’ Configuration Manager

Programming Manager

Use the Programming Manager workspace in SIMPL Windows to select symbols

and assign their respective signals. Expand the Network Module folder and expand

the CNXMIDI. Double click on the ST-LT/MIDI serial driver to view it in detail

view (alternatively CTRL+D), as shown on the next page.

Operations Guide - DOC. 8128 CNX MIDI Interface Expansion Card: CNXMIDI •• 5

CRESTRON

Graphical Detail View of ST-LT/MIDI in SIMPL Windows’ Programming Manager

Expand the Logic folder to display the logic symbols used in this program. They
include Oscillator, Set Reset Latch, and Ring Counter symbols. Some logic symbols
are shown in optional sub system folders. Assign the signals as shown.

Graphical Detail View of Oscillator in SIMPL Windows’ Programming Manager

Graphical Detail View of Ring Counter in SIMPL Windows’ Programming Manager

Graphical Detail View of Set/Reset Latch in SIMPL Windows’ Programming Manager

6 •• CNX MIDI Interface Expansion Card: CNXMIDI Operations Guide - DOC. 8128

CRESTRON

CAUSE(S)

Cable from CNXMIDI to

controlled equipment is

Verify wiring. Connect only the required pins

Controlled device is not

Problem Solving

Troubleshooting

The table below provides corrective action for possible trouble situations. If further

assistance is required, please contact a Crestron technical support representative.

CNXMIDI Troubleshooting

TROUBLE

POSSIBLE

CORRECTIVE ACTION

CNXMIDI
does not
function. Circuit card is not

CNX Control System is
not receiving power.

properly seated in slot.

incorrect.
Programming error. Check SIMPL Windows program.

accepting commands.

Verify power to CNX Control System.

Verify CNXMIDI is properly inserted into
CNX Control System slot per procedures in
this Operations Guide.

for each communication type.

Use manufacturer-supplied diagnostic tool
to verify that controlled device is operating
properly.

Further Inquiries

If after reviewing this Operations Guide for the CNXMIDI, you cannot locate

specific information or have questions, please take advantage of Crestron's award

winning technical support team by calling:

• In the US and Canada, call Crestron’s corporate headquarters at

1-888-CRESTRON [1-888-273-7876] or 1-201-767-3400.

• In Europe, call Crestron International at [phone].

• In Asia, call Crestron Asia at [phone].

Operations Guide - DOC. 8128 CNX MIDI Interface Expansion Card: CNXMIDI •• 7

• In Latin America, call Crestron Latin America at [phone].

For local support from exclusive Crestron factory-trained personnel call:

• In Australia, call Soundcorp at [phone].

• In New Zealand, call Amber Technologies at [phone].

CRESTRON

Return and Warranty Policies

Merchandise Returns / Repair Service

1. No merchandise may be returned for credit, exchange, or service without

prior authorization from CRESTRON. To obtain warranty service for
CRESTRON products, contact the factory and request an RMA (Return
Merchandise Authorization) number. Enclose a note specifying the nature of
the problem, name and phone number of contact person, RMA number, and
return address.

2. Products may be returned for credit, exchange, or service with a CRESTRON

Return Merchandise Authorization (RMA) number. Authorized returns must
be shipped freight prepaid to CRESTRON, Cresskill, N.J., or its authorized
subsidiaries, with RMA number clearly marked on the outside of all cartons.
Shipments arriving freight collect or without an RMA number shall be
subject to refusal. CRESTRON reserves the right in its sole and absolute
discretion to charge a 15% restocking fee, plus shipping costs, on any
products returned with an RMA.

3. Return freight charges following repair of items under warranty shall be paid

by CRESTRON, shipping by standard ground carrier. In the event repairs are
found to be non-warranty, return freight costs shall be paid by the purchaser.

CRESTRON Limited Warranty

CRESTRON ELECTRONICS, Inc. warrants its Cresnet products, denoted by a
"CN" prefix model number, to be free from manufacturing defects in materials and
workmanship for a period of three (3) years from the date of shipment to purchaser.
Disk drives and any other moving or rotating mechanical parts are covered for a
period of one (1) year. CRESTRON warrants all its other products for a period of
one year from the defects mentioned above, excluding touchscreen display
components which are covered for 90 days. Incandescent lamps are completely
excluded from Crestron's Limited Warranty. CRESTRON shall, at its option, repair
or replace any product found defective without charge for parts or labor. Repaired or
replaced equipment and parts supplied under this warranty shall be covered only by
the unexpired portion of the warranty.

CRESTRON shall not be liable to honor warranty terms if the product has been
used in any application other than that for which it was intended, or if it has been
subjected to misuse, accidental damage, modification, or improper installation
procedures. Furthermore, this warranty does not cover any product that has had the
serial number altered, defaced, or removed.

This warranty shall be the sole and exclusive remedy to the purchaser. In no event
shall CRESTRON be liable for incidental or consequential damages of any kind
(property or economic damages inclusive) arising from the sale or use of this
equipment. CRESTRON makes no other warranties nor authorizes any other party
to offer any warranty, expressed or implied, including warranties of merchantability
for this product. This warranty statement supersedes all previous warranties.

Trademark Information

All brand names, product names, and trademarks are the sole property of their
respective owners. Windows is a registered trademark of Microsoft Corporation.
Windows95, Windows98 and WindowsNT are trademarks of Microsoft Corporation

8 •• CNX MIDI Interface Expansion Card: CNXMIDI Operations Guide - DOC. 8128
