Crestron CHV-TSTAT, CHV-THSTAT User Manual

Crestron CHV-TSTAT & CHV-THSTAT Thermostats Operations and Installation Guide
This document was prepared and written by the Technical Documentation department at:
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON
All brand names, product names and trademarks are the property of their respective owners.
©2004 Crestron Electronics, Inc.
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Contents
Quick Installation Reference ....................................................................................................iii
Thermostats: CHV-TSTAT and CHV-THSTAT 1
Introduction ...............................................................................................................................1
Functions and Features................................................................................................ 1
Specifications ..............................................................................................................3
Physical Description.................................................................................................... 4
Industry Compliance ...................................................................................................6
Setup .......................................................................................................................................... 7
Network Wiring........................................................................................................... 7
System Connections .................................................................................................... 8
Identity Code ............................................................................................................... 8
Wiring Diagrams .....................................................................................................................12
Separately Powered Two Wire Heat (Powered by an Independent Transformer).... 13
Single Stage Heat Only .............................................................................................13
Single Stage Heat with Fan Control .......................................................................... 14
Single Stage Cool Only ............................................................................................. 14
Single Stage Heat/Cool with Integrated Control Unit ............................................... 15
Single Stage Heat/Cool with Separate Systems......................................................... 16
Single Stage Heat Pump ............................................................................................17
Two Stage Heat Pump............................................................................................... 18
Slab 1, Slab 2, and Slab 3 Systems (Floor Warming and/or Space Heating) ............19
Slab 4A Two Stage Heat/Single Stage Cool Systems,
Slab 5A Floor Warming with Single Stage Space Heat/Cool.................................... 20
Slab 4B Two Stage Heat/Single Stage Cool System,
Slab 5B Single Stage Heat/Cool with Floor Warming ..............................................21
General Humidifier Connections............................................................................... 22
Installation ............................................................................................................................... 23
Thermostat Setup and Operation .............................................................................................25
Setup Procedure......................................................................................................... 25
Setup Notes................................................................................................................25
System Types and Definitions................................................................................... 26
Heat/Cool, 1 or 2 Stages, Forced Air or Radiant....................................................... 28
Heat Pump, 1 or 2 Stages, Aux Heat or Dual Fuel.................................................... 31
Slab 1 – Floor Warming Only ................................................................................... 34
Slab 2 – Single Stage Space Heat with Slab Maximum ............................................ 37
Slab 3 – Single Stage Heat with Slab Minimum/Maximum...................................... 40
Slab 4A – Two Stage Heat/One Stage Cool with Slab Maximum.............................43
Slab 4B – 2 Stage Heat/1 Stage Cool with Slab Maximum (Heat Pump) ................. 46
Slab 5A – 1 Stage Heat/Cool with Floor Warming ................................................... 49
Slab 5B – 1 Stage Heat/Cool with Floor Warming (Heat Pump).............................. 52
Operating the Thermostat ........................................................................................................55
Programming Software............................................................................................................59
Programming with Crestron D3 Pro.......................................................................... 60
Programming with SIMPL Windows........................................................................ 60
Viewport ID String.................................................................................................... 81
Operations and Installation Guide – DOC. 8163C Contents i
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Viewport Error Log Message Formats ...................................................................... 83
Local Error Messages................................................................................................ 84
Problem Solving ...................................................................................................................... 85
Troubleshooting......................................................................................................... 85
Further Inquiries........................................................................................................ 87
Firmware Upgrades ...................................................................................................87
Future Updates ..........................................................................................................87
Appendix A: Glossary .............................................................................................................88
Appendix B: About Heat Pumps..............................................................................................90
Return and Warranty Policies.................................................................................................. 91
Merchandise Returns / Repair Service ......................................................................91
CRESTRON Limited Warranty.................................................................................91
ii Contents Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Quick Installation Reference

1. Select a suitable location and run the connecting wires from the heating/cooling system and the Cresnet system. Refer to page 5 for a description of the thermostat connectors. Refer to page 7 for Network wiring details. Use the appropriate wiring diagram:
Separately Powered Two Wire Heat (Powered by an Independent Transformer) (Refer to page 13)
Single Stage Heat Only (Refer to page 13)
Single Stage Heat with Fan Control (Refer to page 14)
Single Stage Cool Only (Refer to page 14)
Single Stage Heat/Cool with Integrated Control Unit (Refer to page 15)
Single Stage Heat/Cool with Separate Systems (Refer to page 16)
Single Stage Heat Pump (Refer to page 17)
Two Stage Heat Pump (Refer to page 18)
Slab 1, Slab 2, and Slab 3 Systems (Floor Warming and/or Space Heating) (Refer to page 19)
Slab 4A Two Stage Heat/Single Stage Cool Systems,
Slab 5A Floor Warming with Single Stage Space Heat/Cool (Refer to page 20)
Slab 4B Two Stage Heat/Single Stage Cool System, Slab 5B Single Stage Heat/Cool with Floor Warming (Refer to page 21)
General Humidifier Connections (Refer to page 22)
2. Separate the thermostat from the backplate to expose the connections and mounting holes.
3. Mount the thermostat backplate (60 inches above the finished floor) directly to the wall with wall anchors (not provided) and screws (not provided) or to a single-gang box (not provided) mounted horizontally, and connect the wiring. Refer to page 23 for detailed mounting instructions and page 8 for detailed connector information. If using a five-sided box, fill with insulation material to minimize wall air ingress.
4. Install the thermostat on the backplate (Refer to page 23).
5. Setup the thermostat (Refer to page 25).
Heat/Cool Radiant and Forced Air Systems Setup on page 28. Heat Pump Systems on page 31. Slab Systems begin on page 34.
6. Configure the thermostat (Refer to “Operating the Thermostat” on page 55).
Operations and Installation Guide – DOC. 8163C Contents iii
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Thermostats: CHV-TSTAT and CHV-THSTAT

Introduction

Functions and Features

The CHV-TSTAT and CHV-THSTAT series are wall-mounted universal thermostats that can be part of a Crestron Home capable of controlling one or two-stage heating and cooling systems. Each thermostat is available in three colors: almond, black and white. The suffix ‘A’, ‘B’, and ‘W’, respectively denotes color, e.g., CHV-TSTATB is a black unit. For simplicity within this guide, color suffix is omitted and the designations CHV­TSTAT and CHV-THSTAT are used except where noted.
Functional Summary
User adjustable temperature and/or humidity control of one and two-stage heating and cooling systems
Supports seven slab system configurations
128 x 64 transflective 2.75 inch (6.99 cm) LCD display
Fahrenheit or Celsius indication
Four-front panel buttons for setup, configuring and temperature/humidity
adjustments
Back light (with each button press) for night viewing
Supports up to four remote temperature and/or temperature/humidity sensors.
Operates as a stand-alone device or in a Cresnet
Extended functionality as a Cresnet device for lighting control, alarms, etc.
The CHV-TSTAT provides temperature control, while the CHV-THSTAT provides temperature and humidity control. Temperature and humidity information is provided through a transflective LCD display. Four front panel buttons and the LCD display provide temperature and/or humidity indication and control, current system status, and current fan mode. The LCD also provides status indicators denoting when heat, cool, humidity or fan outputs are energized; a message indicator, so users know when a message is waiting to be read; a net indicator to denote when the network is active and a hold indicator that identifies when the thermostat is overriding the Cresnet temperature set point commands.
®
total control system. The thermostats are
®
system
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 1
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Firmware Versions
The new features, and consequent changes to the SIMPL Windows symbol programming, for firmware version 2.0 and later make it incompatible for use with X-generation control processors. In addition, upgrading to release 2.0 and later from a previous release will require a complete re-programming of the thermostat.
Remote Sensors
Firmware version 2.0 and later supports up to four optional remote sensors, two for each input channel: temperature only (CHV-RTS), temperature/humidity (CHV­RTHS), and slab sensor (CHV-RSS) for both thermostats. Information from two sensors that share an input channel is averaged together in the temperature/humidity calculations.
Outdoor conditions, -40º to 170º F (-40º to 77º C), can be imported from the CHV­RSS slab sensor.
For additional information about the sensors, refer to the latest revision of the CHV­RTS & CHV-RTHS Installation Guide (Doc. 8189), and the CHV-RSS Installation Guide (Doc.6229) which are available from the Crestron website (www.crestron.com).
NOTE: The CHV-TSTAT and CHV-THSTAT allow the user to set a temperature that the heating and/or cooling system maintains. This is called the “Set Point”. Refer to “Operating the Thermostat” on page 55 for more information.
Heating and Cooling Systems
The CHV-TSTAT can control the following heating and cooling systems:
One stage heat
One stage heat, one stage cool
One stage heat, one stage cool (heat pump with auxiliary heat)
Two stage heat
Two stage heat, one stage cool
One stage heat, two stage cool
Two stage heat, two stage cool
Two stage heat, two stage cool (heat pump with auxiliary heat)
Wide range cool option suitable for wine cellars or other chilling processes*
Slab settings for heating and floor warming systems*
*Firmware version 2.0 or higher.
NOTE: Two Stage Heating – Unlike traditional furnaces that turn on and run at full capacity with each demand for heating, two-stage heat operates like two separate furnaces to maintain more consistent comfort in your home. The unit starts out running in its first stage, and operates at a fraction of its heating capacity. This reduced capacity is sufficient to warm your home on mild winter days. But when the temperature outside goes very low, the furnace adjusts to full capacity (second stage) to meet the demand for heat within the home.
Two Stage Cooling – In warm weather, the first stage of the cooling equipment operates at a fraction of the total cooling capacity. On very hot days, the second stage of the cooling equipment energizes, and the cooling system operates at full capacity.
2 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Specifications

The following table provides a summary of specifications for the CHV-TSTAT and CHV-THSTAT.
CHV-TSTAT and CHV-THSTAT Specifications
SPECIFICATION DETAILS
Power Requirements
Crestron power factor
Default Network ID 2A
Control System Update Files
2-Series Control System Version 3.080.CUZ or later
LCD Display 128 x 64 Transflective 2.75 in (6.99 cm)
Screen Viewing Angles
Humidity Measurement Range 0 – 100%
Auto Setpoint Range (union of heat and cool setpoint ranges)
Heat Only Setpoint Range 38 –- 89°F (3 – 32°C)
Cool Only Setpoint Range 59 –- 99°F (15 – 37°C)
Temperature Measurement Range 0 – 110°F (-18 – 43°C)
Firmware Update Files3
CHV-TSTAT/CHV-THSTAT
Dimensions and Weight Height: 3.75 in (9.50 cm)
1,2
2 Watts (24 VAC @ 83mA) Heating or Cooling System Supplied
<1 Watt (required for Cresnet communication only)
Y Dir. (X=0º): +50º (from top) –50º (from bottom)
X Dir. (X=10º): +50º (from right) –50º (from left)
38 –- 99°F (3 – 37°C)
CHV-TxSTAT.v2.40.UPG or later
Width: 5.00 in (12.70 cm)
Depth: 1.04 in (2.63 cm)
Weight: 5.80 oz (165 g)
1. The latest versions can be obtained from the Downloads | Software Updates section of the Crestron website (www.crestron.com)
2. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product Catalog for a complete list of 2-Series control systems.
3. Filenames for CHV update files have a UPG extension and are in one zipped UPG file. Firmware version 2.0 is for 2-series control systems only. X-generation series systems may use earlier versions. Refer to revision B of this document for features.
NOTE: Crestron software and any files on the website are for Authorized Crestron dealers
. Refer to NOTE after last footnote.
only. New users may be required to register to obtain access to certain areas of the site (including the FTP site).
NOTE: The SIMPL Windows thermostat symbol associated with firmware release 2.0 and later requires a 2-Series system and does not work with X-Generation systems.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 3
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
R

Physical Description

Refer to the following illustrations. The CHV-TSTAT and CHV-THSTAT are in a plastic enclosure with four buttons and an LCD display on the front. The back of the unit has ventilation slots, and holes for mounting the unit and wiring. The ventilation slots must be unobstructed for airflow to the unit.
Physical View of CHV-TSTAT and CHV-THSTAT
Current Set Point (indicates
Current Temperature
Current Humidity
66
43
o
%
F
o
68
HEATING HEAT ONLY ON LINE
H1 H2 AX
F
desired temperature, or temperature range in auto mode)
Current Activity Current Function System Information
- ON LINE (Cresnet on)
- HOLD (Cresnet off)
- NET FAULT (Net down)
- VIEW MSG (view
message)
- LOCKOUT (Network lockout)
Internal Relay Status
Front and Side Views
1.75 in
(4.44 cm)
3.75 in
(9.50 cm)
ear View
MODE
VIEW
5.00 in
(12.70 cm)
4.630 in
(11.76 cm)
0.47 in
(1.18 cm)
1.04 in
(2.63 cm)
3.38 in
(8.59 cm)
3.27 in
(8.29 cm)
4 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Connection View (Backplate, view from the front with cover removed)
TOP
Y
Z
24V
RS1
RS2
24(C)
RSR
Y2
O
24(R)
W/W1
B
W2
NETWORK
RH
HUM
RC
RSR
RHU
Y/Y1
G
Ports
The CHV-TSTAT and CHV-THSTAT have four types of connections on the inside back plate (refer to graphic above).
G
NETWORK (Optional) – provides communication to the control system and Cresnet power to the CHV-TSTAT and CHV-THSTAT. If making network connections to Cresnet peripherals, refer to “Network Wiring” on page 7.
Cresnet Connections (optional)
PIN DESCRIPTION
24 +24VDC
Y Cresnet Data
Z Cresnet Data
G Ground
Remote Sensing Connections (optional)
PIN DESCRIPTION
RSR Remote Sensor Returns – Common sensor terminal
RS1 Remote Sensor terminal – Connect the sensor from RS1 to RSR
RS2 Remote Sensor terminal – Connect the sensor from RS2 to RSR
Power Connections (Required)
PIN
24 (C)
24 (R)
DESCRIPTION (refer to “System Connections” on page 8)
24 VAC common terminal supplies remote 24 VAC power to thermostat
24 VAC reference terminal. Can be connected to RH or RC by P4 jumper setting, or tied directly to power source (refer to System Connections on page 8)
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 5
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Control Connections (System Dependent)
PIN DESCRIPTION
HUM Energized to RHU during humidity call
RHU Reference for humidifier
RH Reference Heat, used for calls to heating system
RC Reference Cool, used for calls to cooling system
G Fan, energized to RC during call for fan
Y/Y1
Y2
O Changeover control, energized to RC during cooling modes
B Energized to RC during non-cooling modes
W/W1
W2
Compressor (stage one), energized to RC when compressor (or first stage) is run
Compressor (stage two), energized to RC on two-stage systems on call for second stage
Heat (single stage)/heat (stage one) energized to RH during a call for heat in heat/cool systems or aux heat in heat pump systems
Heat (stage two), energized to RH during a call for second stage heat in heat/cool systems
Buttons
There are four buttons used to setup and adjust the thermostat.
MODE
MODE – Access to the user controls (System Mode, Fan Mode, Humidifier, Crestron System, and Global Update)
VIEW
VIEW – Access to Humidity reading, Outdoor Temperature reading, and System Messages.
NOTE: When MODE and VIEW are pressed together and held for five seconds, the thermostat enters the system setup mode (refer to “Thermostat Setup and Operation” on page 25).
T
UP – Selects user modes and increments selection in setup modes
DOWN – Selects user modes and decrements selection in setup modes
T

Industry Compliance

As of the date of manufacture, this unit has been tested and found to comply with
s
pecifications for CE marking and standards per EMC and Radio Communications
Compliance Labeling (N11785).
NOTE: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
6 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Setup

Network Wiring

NOTE: When installing network wiring, refer to the latest revision of the wiring diagram(s) appropriate for your specific system configuration, available from the Downloads | Product Manuals | Wiring Diagrams section of the Crestron website (www.crestron.com)
When calculating the wire gauge for a particular Cresnet run, the length of the run and the power factor of each network unit to be connected must be taken into consideration. If Cresnet units are to be daisy-chained on the run, the power factor of each unit to be daisy-chained must be added together to determine the power factor of the entire chain. If the unit is a home-run from a Crestron system power supply network port, the power factor of that unit is the power factor of the entire run. The length of the run in feet and the power factor of the run should be used in the following resistance equation to calculate the value on the right side of the equation.
Resistance Equation
R <
40,000
L x PF
.
R = Resistance (refer to table below).
Where:
L = Length of run (or chain) in feet . PF = Power factor of entire run (or chain).
The required wire gauge should be chosen such that the resistance value is less than the value calculated in the resistance equation. Refer to the table below.
Wire Gauge Values
RESISTANCE WIRE GAUGE
4 16
6 18
10 20
15 22
13 Doubled CAT5
8.7 Tripled CAT5
NOTE: All Cresnet wiring must consist of two twisted-pairs. One twisted pair is the +24V conductor and the GND conductor and the other twisted pair is the Y conductor and the Z conductor.
NOTE: For larger networks (i.e., greater than 28 network devices), it may be necessary to add a Cresnet Hub/Repeater to maintain signal quality throughout the network. Also, for networks with lengthy cable runs or varying types of network equipment, it may be desirable to add a hub/repeater after only 20 network devices.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 7
Thermostats Crestron CHV-TSTAT and CHV-THSTAT

System Connections

NOTE: Installers should have a strong working knowledge of HVAC systems.
Backplate - view from the front with the cover removed
HUM - Energized (connected) to RHU during humidity call
RHU - Reference for humidifier RSR - Remote Sensor Returns - Common sensor terminal RS1 - Remote Sensor terminal - Connect the sensor from RS1 to RSR
RS2 - Remote Sensor terminal - Connect the sensor from RS2 to RSR 24(C) - 24 VAC common terminal supplies remote 24 VAC power
to thermostat 24(R) - 24 VAC reference terminal. Can be connected to RH or RC by P4 jumper setting (refer to following page), or tied directly to power source
Network Connection
TOP
Y
Z
RS1
RS2
HUM
RSR
RSR
RHU
24(C)
24(R)
24V
NETWORK
G
for Crestron
Installer Only
RH
RC
Y/Y1
Y2
G
W/W1
B
O
W2
Backplate
W2 - Heat (stage two), energized (connected) to RH during a call for second stage heat in heat/cool systems
W/W1 - Heat (single stage)/heat (stage one) energized to RH during a call for heat in heat/cool systems or aux heat in heat pump systems or Slab Heat in Slab Systems.
B - Energized to RC during non-cooling modes
O - Changeover control, energized to RC during cooling modes
Y2 - Compressor (stage two), energized to RC on two-stage
systems on call for second stage Y/Y1 - Compressor (stage one), energized to RC when
compressor (or first stage) is run
G - Fan, energized to RC during call for fan
RC - Reference Cool, used for calls to cooling system
RH - Reference Heat, used for calls to heating system

Identity Code

Every equipment and user interface within the network requires a unique identity code (Net ID). These codes are two-digit hexadecimal numbers from 03 to FE. The Net ID of each unit must match an ID code specified in the SIMPL Windows program. Refer to “Setting the Net ID in Device Settings” on page 61 for details of
8 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
the SIMPL Windows procedure. The Net ID of the Thermostats has been factory set to 2A. The Net IDs of multiple thermostats in the same system must be unique. Net IDs are changed from a personal computer (PC) via the Crestron Viewport.
NOTE: The Crestron Viewport is available as a pull-down command from SIMPL Windows and VisionTools® Pro-e (Tools | Viewport) or as a standalone utility. The Viewport utility performs multiple system tasks, primarily via an RS-232 or TCP/IP connection between the control system and a PC. It is used to observe system processes, upload new operating systems and firmware, change system and network parameters, and communicate with network device consoles and touchpanels, among many other tasks. Viewport can function as a terminal emulator for generic file transfer. All of these functions are accessed through the commands and options in Viewport menus. Therefore, for its effectiveness as a support and diagnostic tool, the Crestron Viewport may be preferred over development tools when uploading programs and projects.
NOTE: For detailed information on establishing communication between the PC and control system, refer to “Communication Settings” in the Operations Guide of the control system. If communication cannot be established, refer to the “Troubleshooting Communications” section in the respective Operations Guide for the control system.
NOTE: The NET ID can also be changed using the setup screens.
NOTE: Firmware version 2.40 and later supports Touch Settable ID.
There are two different methods—Method A or Method B—for setting the Net ID:
Method A (Cresnet address-settable ID), described as follows, applies to devices in a Cresnet system with a 2-Series control system and requires that a single unit be the only network device connected to the control system.
Method B (Touch Settable ID or TSID), which begins on page 10, applies to all TSID-ready devices in a Cresnet system with 2-Series control system upgrade file (CUZ) version 3.029 or later. TSID functionality makes it possible for the control system to recognize a network device via its serial number, which is stored in the device’s memory. This method does not require that any devices be disconnected from the network; Net IDs may be set with the entire Cresnet system intact. This method requires the use of the Crestron Viewport version 3.35 or later.
Use the appropriate method to set the Net ID.
Method A (Cresnet address-settable ID)
1. Ensure that the device requiring a Net ID change is the only unit connected to the control system.
2. Open the Crestron Viewport.
3. From the Viewport menu, select Functions | Set Network ID. The software checks the baud rate and then opens the "Set Network ID" window.
4. In the "Set Network ID" window, select the device requiring a Net ID change from the Current Network Devices text window.
5. Select the new Net ID for the device from the Choose the new network ID for the selected device (Hex): text box.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 9
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
6. Click Set ID to initiate the change. This will display the "ID command has been sent" window.
7. In the "Command Complete" window, click OK.
8. In the Current Network Devices text window, verify the new Net ID code.
9. In the "Set Network ID" window, click Close.
NOTE: The new Net ID code may also be verified by selecting Diagnostic | Report Network Devices in the Viewport (alternately, select F4).
10. Repeat this procedure for each additional network device requiring a Net ID change.
Method B (Touch Settable ID)
Before using this method, you should have a list of all current network devices and their Net IDs, to avoid assigning duplicate IDs.
Set Net ID by TSID
These procedures are for TSID-enabled network devices during the initial configuration of a Cresnet system or when such devices are being added/replaced.
1. Ensure that all network devices are connected to the control system.
2. Open the Crestron Viewport version 3.35 or later.
3. From the Viewport menu, select Functions | Assign Cresnet ID by Serial Number. The “Set Net ID by TSID” window appears. The window is first displayed with the data fields empty.
4. Click on the Search for Touch Settable Devices button. The system searches the network and lists all TSID-enabled devices found. The list is similar to the report produced by pressing F4 (Report Network Devices); the first eight digits of each line constitute the TSID number (hexadecimal form of the serial number).
“Set Net ID by TSID” Window
5. Enter either the serial number or TSID number of the device that requires a change. The list scrolls to and highlights the device listing. The listing
10 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
should show the device’s default Cresnet ID (a.k.a. Net ID).
6. Enter the Cresnet ID that the device should be set to and click OK. The number you enter should appear on the list.
CAUTION: This function does not prevent you from setting duplicate IDs. Be sure to check current assignments before entering the desired Cresnet ID number.
Serial Number to TSID Conversion
This utility is useful in a case where there are multiple devices of the same type on a network, you need to locate a particular one, you know the TSID but not the serial number, and your site installation list is based on device serial numbers. In this (or the reverse) situation, do the following:
1. Open the Crestron Viewport.
2. From the Viewport menu, select Functions | Serial Number ÅÆ TSID Conversion Tool. The “Serial Number ÅÆ TSID Conversion Tool” window is displayed.
“Serial Number to TSID Conversion Tool” Window
3. Enter the serial number or TSID number as instructed; press the appropriate button to obtain the corresponding number.
NOTE: Enter serial numbers, including spaces, exactly as they appear on the unit label. Alpha characters in serial numbers or TSID numbers may be entered in upper or lower case.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 11
Thermostats Crestron CHV-TSTAT and CHV-THSTAT

Wiring Diagrams

The wiring diagrams that follow show connections for the CHV-TSTAT and CHV­THSTAT. The heating or cooling system can supply power to the thermostat, or a separate transformer can supply it. In many installations, spare conductors are available to supply 24 VAC to the thermostat, using the C (24 VAC common) connection on the HVAC equipment.
The P4 jumper internally connects either the RH (Reference Heat system) or RC (Reference Cooling system), relieving the installer from connecting a jumper from the 24(R) terminal to the RH or RC terminal.
If power is available from the HVAC system, follow the diagrams for the proper P4 jumper connection.
When power is not available from the HVAC system, a separate transformer, connected between 24(R) and 24(C) terminals, can provide power to the thermostat. When powered by a separate transformer, ensure that the P4 jumper is connected across pins 2 and 3 (No Connection) to prevent damage to the thermostat and the HVAC system.
CAUTION: The P4 Jumper Position on the Circuit Board is critical to proper operation. Improper P4 jumper position can cause equipment damage. The P4 jumper connects the 24(R) terminal to the RH, or RC connector. Refer to the following illustration.
P4
1
Connects 24(R) to RH
2
No Connection
3 4
NOTE: Ensure that the power circuits are shut off at the source before connecting the thermostat. Provide disconnect means and overload protection as required for the power supply.
NOTE: Ensure that the transformer has sufficient power for all the thermostats in the system, or use multiple transformers. Refer to the power requirements in “Specifications” on page 3.
The following diagrams are examples of connections for heat, heat/cool and one­stage and two-stage heat pump systems, and various slab systems.
NOTE: Use either connector O or B as required, for changeover control.
Connects 24(R) to RC
12 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Separately Powered Two Wire Heat
(Powered by an Independent Transformer)
Independent Transformer Connection – P4 Jumper Connects Pins 2 and 3

Single Stage Heat Only

Single Stage Heat Only System Powered – P4 Jumper Connects Pins 1 and 2
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 13
Thermostats Crestron CHV-TSTAT and CHV-THSTAT

Single Stage Heat with Fan Control

Single Stage Heat with Fan Control – P4 Connects Pins 1 and 2 – Additional Jumper Connects RH to RC

Single Stage Cool Only

Single Stage Cool Only – P4 Jumper Connects Pins 3 and 4
14 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Single Stage Heat/Cool with Integrated Control Unit

Single Stage Heat/Cool with Integrated Control Unit – P4 Jumper Connects Pins 1 and 2 – Additional Jumper RH to RC
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 15
Thermostats Crestron CHV-TSTAT and CHV-THSTAT

Single Stage Heat/Cool with Separate Systems

Single Stage Heat/Cool with Separate Systems – Heating System Powered – P4 Jumper Connects Pins 1 and 2
16 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Single Stage Heat Pump

Single Stage Heat Pump – P4 Jumper Connects Pins 3 and 4– Additional Jumper RH to RC
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 17
Thermostats Crestron CHV-TSTAT and CHV-THSTAT

Two Stage Heat Pump

Two Stage Heat Pump System – P4 Jumper Connects Pins 3 and 4 – Additional Jumper RH to RC
18 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Slab 1, Slab 2, and Slab 3 Systems (Floor Warming and/or Space Heating)

Slab 1, Slab 2, and Slab 3 Systems (Floor Warming and/or Space Heating) – P4 Jumper Connects Pins 1 and 2
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 19
Thermostats Crestron CHV-TSTAT and CHV-THSTAT

Slab 4A Two Stage Heat/Single Stage Cool Systems, Slab 5A Floor Warming with Single Stage Space Heat/Cool

Heat/Cool Style Connections
Slab 4A – P4 Jumper Connects Pins 1 and 2 – Jumper Connects RH to RC
20 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Slab 4B Two Stage Heat/Single Stage Cool System, Slab 5B Single Stage Heat/Cool with Floor Warming

Heat Pump Style Connections
Slab 4B – P4 Jumper Connects Pins 3 and 4 – Additional Jumper Connects RH to RC
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 21
Thermostats Crestron CHV-TSTAT and CHV-THSTAT

General Humidifier Connections

22 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Installation

The location of the thermostat can affect its performance and efficiency. Install the thermostat away from direct sunlight, drafts, doorways, skylights, and windows. Also make sure the thermostat is conveniently located for programming, and do not mount on an exterior wall. The thermostats may be mounted directly to drywall or to a single-gang box.
Thermostats and sensors are mounted 60 inches (152.4 cm) above the finished floor (HVAC industry standard).
Refer to the following illustrations. Do the following to install the CHV-TSTAT or the CHV-THSTAT.
NOTE: When installing directly on drywall, use anchoring screws and hardware. Make sure the back of the thermostat is flush with drywall and the unit is level.
Required Hardware
Thermostat
Phillips screwdriver (not supplied)
Two 6/32 x 1 inch panhead screws (supplied) for mounting to a
single-gang box
Single-gang box (not supplied)
Wall anchors (not supplied) and screws (not supplied) for
mounting directly to drywall
1. Separate thermostat front plate from back plate (you may need to exert force when removing the faceplate).
2. Turn off the circuit breaker when connecting power to the thermostat, and connect wiring as required (wiring goes through center hole on back plate).
NOTE: Ensure the correct position of the P4 jumper; refer to pages 12 through 21.
3. Attach back plate to drywall with screws and anchors (anchor hardware not provided) 60 inches above the finished floor. Thermostat may also be mounted to a single-gang box mounted horizontally, using the two 6/32 x 1 inch panhead screws provided. If using a five-sided single-gang box, fill with insulation material to minimize wall air ingress. Ensure that the thermostat is level and the ventilation holes in the backplate are not blocked.
4. Note orientation of front plate connection leads and reattach the front plate on the back plate (make sure front plate snaps in place and no wires are pinched).
NOTE: If replacing an existing thermostat, make note of the wire colors and positions before removing the old thermostat.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 23
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Installation View – Single gang electrical box – horizontal mounting
NOTE: Install insulation in the gang box to prevent inaccurate readings.
Stud
Single-gang
electrical box Panhead 6/32 x 1 in
(not provided)
Installation view – Direct mount to wall
Mounting Screws (not provided)
Wall Anchors (not provided)
Backplate
24 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Thermostat Setup and Operation

Setup Procedure

After the thermostat is installed, it is necessary to set it up for a particular heating/cooling system. There are nine types of heating and cooling systems. Each system type is setup using nine screens. The available choices displayed on the setup screens depend on the type of system selected. Follow these directions to access the setup screens.
1. Press and hold the MODE and VIEW buttons simultaneously for five seconds to access the setup menus.
2. Press VIEW to select the parameter. A box appears around the selected parameter.
3. Press the Arrow keys (▲▼) to choose the value of the selected parameter.
4. Use the MODE button to advance to the next setup screen.
Press and Hold
MODE and VIEW
to Enter and Exit
Setup Mode
Advance to
next Setup
Screen
Step to next selection on
current Setup
Screen
MODE
VIEW
CRESTRON
T
T
Select System Type and Change Value of Selected Parameter

Setup Notes

The following are general setup notes.
NOTE: Refer to “System Connections” on page 8 for remote sensor connections to the thermostat.
NOTE: The Offset option permits recalibration of the room temperature sensor. There are various reasons why users may want to adjust the temperature. The selection number is the number of degrees added or subtracted to the actual temperature. The range is -6° to +6°F. Factory default is 0°. This adjustment changes the actual regulated temperature, not just the display.
NOTE: The sensors are used for temperature and humidity averaging. Choose USE to include each sensor, or OMIT to exclude each sensor in the averaging equation. Sensors that have the same designation (for example, outdoor) are averaged together.
NOTE: The thermostat will not leave the setup mode unless a valid sensor selection is made.
NOTE: When the Reverse SMODE Dir (reverse system mode direction) selection is set to Yes on the Screen Options page, the arrow keys (▲ ▼) can be used to select
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 25
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
system mode functions in both directions.
NOTE: If an out-of-range setpoint is entered, the setpoint is assigned its limit value in that direction.
NOTE: The Screen Options selected in setup are seen when the view key is pressed in normal operation.

System Types and Definitions

The first setup choice is the heat system type. There are three main types of heating/cooling systems.
1. Heat/Cool, Radiant Heat or Forced Air Heating/Cooling, 1 or 2 Stages
2. Heat Pump, 1 or 2 Stages, Auxiliary Heat or Dual Fuel
3. Slab System (Slab1 through Slab 5B)
1. Heat/Cool Systems Definitions
Radiant Heat systems: Radiant heat is a form of hydronic (hot water) heat
that circulates hot water through pipes (baseboard radiation systems) or special tubing and installs on the perimeter of the house or underneath floors. Forced Air systems: In a ducted heating/cooling system, a large fan (blower) forces heated air from the furnace into the ducts and enters the rooms through a register or grill in the floor or wall. One or Two Stages: Unlike traditional furnaces that turn on and run at full capacity with each demand for heating, two-stage furnaces operate like two separate furnaces. The unit begins to run in its first stage, and operates at a fraction of its heating capacity. This reduced capacity is sufficient on mild winter days. On very cold days, the furnace adjusts to full capacity (second stage) to meet the demand for heat.
Heat/Cool system setup begins on page 28.
2. Heat Pump Systems Definitions
A heat pump extracts available heat from one area and transfers it to another. Even cold air contains some heat, and heat pumps can extract heat from the outside air on a cold day and transfer it indoors to maintain a comfortable temperature. A heat pump also works in reverse during the summer, extracting heat from indoors and transferring it outdoors. Dual Fuel: A dual fuel system combines an energy-efficient air-source heat pump with a new or existing oil, gas or propane furnace. The furnace runs in place of the heat pump in cold weather. Aux (Auxiliary) Heat: When the a heat pump can no longer efficiently transfer heat from the outside air, the thermostat automatically turns on a secondary heat source, such as electric resistive heat.
Heat pump system setup begins on page 31.
26 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
3. Slab Systems
Slab heating works from the ground up. The heating components are installed below the floor or are embedded in a concrete slab. Heat radiates from the floor to warm the space above. The CHV-TSTAT and CHV-THSTAT support seven variations of slab heat systems.
SLAB 1: Floor warming only. Operates the slab heat to maintain a particular
slab temperature. System mode is enabled/disabled with Floor Warming Heat and OFF inputs. Slab is maintained at the slab setpoint temperature value. Connection to the slab output relay is terminal W1. Refer to setup on page 34.
SLAB 2: One stage space heat with slab maximum. Maintains a particular air
temperature using the slab to heat the space. Will not heat over the slab maximum temperature even if this results in the space being under-heated. Connection to the slab output relay is terminal W1. Refer to setup on page 37.
SLAB 3: One stage space heat with slab maximum and slab minimum.
Performs the same operation as SLAB 2, and also keeps the slab at least as warm as slab setpoint. This may result in the space being overheated to maintain the slab minimum temperature. Connection to the slab output relay is terminal W1. Refer to setup on page 40.
SLAB 4A: Two-stage space heat with slab maximum and one stage cool.
Maintains the air temperature using the slab for heat, up to the slab maximum. Augments the air heating by using a second stage of heat (generally a forced air system). Allows the second stage to operate by itself should the slab reach is maximum temperature and shut off. Cools the space with cooling call. Intended for heat-cool type forced air systems, with relay output connections to terminal W1 for slab, terminal W2 for 2
nd
stage heat, and terminal Y1 for cooling. Refer to
setup on page 43.
SLAB 4B: Same operation as SLAB4A, but intended for a heat pump type
second stage. Relay output connections are terminal W1 for slab heat, with heat pump-type connections on terminals Y1/O/G for cooling and heating calls. Aux heat is on terminal W2. Refer to setup on page
46.
SLAB 5A: One stage space heat and cool with floor warming. Combines the
operation of a space heating/cooling thermostat with a floor-warming thermostat. Maintains the slab at slab setpoint, and maintains the space at the heat, cool, or auto setpoints. Systems effectively operate independently. Heat/Cool/Auto/Off sets the space control modes, and Floor Warming HEAT/OFF sets the slab mode. Intended for heat­cool style systems, with slab connection on terminal W1, space heat on terminal W2, and space cool on terminal Y1. Refer to setup on page 49.
SLAB 5B: Same as SLAB5A, but for heat pump space systems, with slab heat
on terminal W1, and space heat/cool on terminals Y1/O/G. Aux heat is on terminal W2. Refer to setup on page 52.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 27
Thermostats Crestron CHV-TSTAT and CHV-THSTAT

Heat/Cool, 1 or 2 Stages, Forced Air or Radiant

Press and hold the MODE and VIEW buttons simultaneously for five seconds to enter setup.
SETUP SYSTEM
SETUP: SYSTEM
Heat Sys Type: # Heat Stages: # Cool Stages: Radiant / F. Air:
SEPARATE HEAT AND COOL
H/C 2 2 F.Air
System Type: H/C Heat/Cool. One or two heat and cool stages. Radiant or Forced Air Heat.
HUMIDIFIER OPTIONS
SYSTEM PERFORMANCE
Anticipators: (1 through 6)
Low number = more frequent cycles and faster response (tighter regulation). High number = less frequent cycles and slower response (looser regulation). Interstage Differential: 0.5 to 8.0ºF. The proportional temperature error to trigger the second stage.
SETUP: SYSTEM PERF
Heat Anticipator: Cool Anticipator: Intrstg Differential:
5 2
2.0
0
SETUP: HUM OPTS
Show Hum Mode Pg: Show Hum View Pg: Cold Weather Comp:
SYSTEM ENABLE/DISABLE PAGE
Y Y N
Show Hum Mode Pg and Show Hum View Pg: Select Y to show humidity page in normal operation. Cold Weather Compensation: Modifies the humidifier output to prevent condensation on the windows. Requires an outdoor temperature source (CHV-THSAT, or CHV-TSTAT with CHV-RTHS, CHV-RTS, or CHV-RSS).
Continued on following page.
28 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Heat/Cool, 1 or 2 Stages, Forced Air or Radiant (continued)
DEVICE OPTIONS
SETUP: DEVICE OPTS
Network ID: LCD Contrast
2A 5
CHV-THSTAT [v2.0, #D8000000]
Select Network ID: Valid entries are 03 to FE in Hex to match the network ID set for the thermostat in SIMPL Windows. LCD Screen Contrast: 1 Lighter through 10 Darker. Displays Model number, Firmware version and TSID.
DISPLAY OPTIONS
SETUP: DISP OPTIONS
Temperature Units: Temp Disp Offset: Dual Setpoint Auto: Main Scn Lwr Obj: Use 0.5 Deg C Step:
°F or °C – Display in Fahrenheit or Celsius. Offset (-6 to +6°F) Allows the user to adjust the
displayed and regulated temperature.
Dual Setpoint Auto – enables two-point auto mode. Main Screen Lower Object:
SB – Slab OD – Outdoor HM – Humidity NA – None °C may be displayed in 0.5 units.
F
0
0 Y HM Y
SCREEN OPTIONS
Options seen when VIEW is pressed: Global Page – Temperature & humidity selection for entire house (if part of a Cresnet system). Outdoor Page – Temperature & humidity of the outside sensor. Display Remote Function Page 1, 2 – Allows remote control of other functions (for example: lights, alarms, etc.). Reverse SMODE Dir – Allows arrow keys to select mode functions in both directions.
SETUP: SCRN OPTIONS
Disp Global Page: Disp Outdoor Page: Disp Rem Func Pg1: Disp Rem Func Pg2: Reverse SMODE Dir
Continued on following page.
Y Y Y Y N
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 29
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Heat/Cool, 1 or 2 Stages, Forced Air or Radiant (continued)
OTHER SETTINGS
SETUP: OTHER SETTINGS
Wide Range Cool: Run Fan in Ht Calls: Auto DdBand Deg: Disable Auto Mode:
EXTENDED COOL SETPOINT RANGE 38-99F (3-37C)
N N
0
2 N
Wide Range Cool: Extends cool setpoint to full auto range of 38 to 99 degrees F. Run Fan in Heat Calls: Most heating systems run the fan automatically. If your heating system requires fan control, select Yes. Auto Mode Dead Band: (valid selections are 2 through 6) The minimum differential between heating and cooling setpoints (Dual Setpoint Auto set to Yes in Display Options). Disable Auto Mode: Will not display Auto on System Mode screen and will not permit entering the auto mode even from Cresnet commands.
SENSORS
SETUP: SENSORS Sensor
Internal: Remote 1:
DETECTED: 1 x T
Remote 2:
>TEMP HUM USE OMIT SLAB
Choose USE or OMIT (Built-in Sensors Only). Choose Use to permit temperature averaging. Sensor Temp/Humidity can be output to network even if Omit is chosen.
Choose USE, OMIT, OD (outdoors), or SLAB (Remote Sensors Only)
NOTE: Remote 1 and Remote 2 options do not appear on this screen if these sensors are not connected. NOTE: Thermostat auto-detects connected remote sensors.
SERVICE/TEST
SETUP: SERVICE/TEST Heat Call:
Cool Call:
OFF OFF
Press MODE button to return to the first screen
Or
Press and hold the MODE and VIEW buttons
Humidifier Call: Fan Run Call:
NOTE: This screen bypasses all system delays and is used by the installer to manually operate
OFF OFF
simultaneously for five seconds to exit Setup.
NOTE: You cannot exit if the sensor setup does not meet system requirements.
the HVAC system. Only one system can be run at a time.
30 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Heat Pump, 1 or 2 Stages, Aux Heat or Dual Fuel

Press and hold the MODE and VIEW buttons simultaneously for five seconds to enter the setup mode.
SYSTEM SETUP
SETUP: SYSTEM
Heat Sys Type: # of Stages:
HP/AUX or DF:
HEATPUMP SYSTEM
HPump 2 HP/Aux
Heat System Type: Heatpump 1 or 2 Stages HP/Aux or Dual Fuel – Dual fuel runs either
the heat pump or the aux output, depending on outdoor temperature. The heat pump with aux can stage the heat when required to improve performance.
Dual Fuel: A dual fuel system combines an energy-efficient air-source heat pump with a new or existing oil, gas or propane furnace. The furnace runs in place of the heat pump in cold weather.
Aux (Auxiliary) Heat: When the a heat pump can no longer efficiently transfer heat from the outside air, the thermostat automatically turns on a secondary heat source, such as electric resistive heat.
SYSTEM PERFORMANCE
NOTE: You can set the HP or Aux Balance Point
from 0º to 90º, or select OFF to disable heat pump, Aux lockouts.
HUMIDIFIER OPTIONS
SETUP: HUM OPTS
Show Hum Mode Pg: Show Hum View Pg: Cold Weather Comp:
SYSTEM ENABLE/DISABLE PAGE
Y Y N
Show Hum Mode Pg and Show Hum View Pg: Select Y to show humidity page in normal operation. Cold Weather Compensation: Modifies the humidifier output to prevent condensation on the windows. Requires an outdoor temperature source (CHV-THSAT, or CHV-TSTAT with CHV­RTHS, CHV-RTS, or CHV-RSS).
SETUP: SYSTEM PERF
Heat Anticipator: Cool Anticipator: Intrstg Differential: HP Balance Pt: AUX Balance Pt:
5 2
2.0 Off Off
0
Anticipators: (1 - 6) Low number = more frequent cycles, faster response. High number = less frequent cycles, slower response. Interstage Differential: 0.5 to 8.0ºF. The proportional temperature error to trigger the second stage. HP Balance Point - Minimum outdoor temperature at which the heat pump runs (requires an outdoor temperature source). AUX Balance Point - Maximum outdoor temperature at which Aux heat system supplements the heat pump (requires an outdoor temperature source)
Continued on following page.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 31
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Heat Pump, 1 or 2 Stages, Aux Heat or Dual Fuel (Continued)
DEVICE OPTIONS
SETUP: DEVICE OPTS
Network ID: LCD Contrast
CHV-THSTAT [v2.0, #D8000000]
2A 5
Select Network ID: (03 to FE in Hex) match the network ID set for the thermostat in SIMPL Windows. LCD Screen Contrast: 1 Lighter through 10 Darker
Displays Model number, Firmware version and TSID.
SCREEN OPTIONS
SETUP: SCRN OPTIONS
Disp Global Page: Disp Outdoor Page: Disp Rem Func Pg1: Disp Rem Func Pg2: Reverse SMODE Dir
Y Y Y Y N
Options seen when VIEW is pressed:
DISPLAY OPTIONS
SETUP: DISP OPTIONS
Temperature Units: Temp Disp Offset: Dual Setpoint Auto: Main Scn Lwr Obj: Use 0.5 Deg C Step:
F
0
0 Y HM Y
°F or °C – Display in Fahrenheit or Celsius. Offset (-6 to +6°F) Allows the user to adjust the
displayed and regulated temperature. Dual Setpoint Auto – enables two-point auto mode.
Main Screen Lower Object:
SB – Slab OD – Outdoor HM – Humidity NA – None
°C may be displayed in 0.5 units.
Global Page – Temperature & humidity selection for entire house (Cresnet system only). Outdoor Page – Temperature & humidity of the
outside sensor. Remote Function Page 1, 2 – Allows remote control of other functions (for example: lights, alarms, etc.). Reverse SMODE Dir – Allows arrow keys to select mode functions in both directions.
Continued on the following page.
32 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Heat Pump, 1 or 2 Stages, Aux Heat or Dual Fuel (Continued)
OTHER SETTINGS
SETUP: OTHER SETTINGS
Wide Range Cool: Run Fan in Ht Calls: Auto DdBand Deg: Disable Auto Mode:
EXTENDED COOL SETPOINT RANGE 38-99F (3-37C)
N N 2 N
0
Wide Range Cool: Extends cool setpoint to full auto range of 38 to 99 degrees F. Run Fan in Heat Calls: Most heating systems run the fan automatically. If your heating system requires fan control, select Yes. Auto Mode Dead Band: (valid selections are 2 through 6) The minimum differential between heating and cooling setpoints (Dual Setpoint Auto set to Yes in Display Options). Disable Auto Mode: Will not display Auto on System Mode screen and will not permit entering the auto mode even from Cresnet commands.
SENSORS
SETUP: SENSORS
Sensor Internal: Remote 1:
DETECTED: 1 x T
>TEMP HUM USE OMIT SLAB
Remote 2:
Choose USE or OMIT (Built-in Sensors Only). Choose Use to permit temperature averaging. Sensor Temp/Humidity can be output to network even if Omit is chosen. Choose USE, OMIT, OD (outdoors), or SLAB (Remote Sensors Only) NOTE: Remote 1 and Remote 2 options do not appear on this screen if these sensors are not connected. Thermostat auto-detects connected remote sensors.
SERVICE/TEST
SETUP: SERVICE/TEST Heat Call:
Cool Call: Aux Heat Call: Humidifier Call: Fan Run Call:
OFF OFF OFF OFF OFF
Press MODE button to return to the first screen
Or
Press and hold the MODE and VIEW buttons simultaneously for five seconds to exit Setup.
NOTE: This screen bypasses all system delays and is used by the installer to manually operate
NOTE: You cannot exit if the sensor setup does not
meet system requirements. the HVAC system. Only one system can be run at a time.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 33
Thermostats Crestron CHV-TSTAT and CHV-THSTAT

Slab 1 – Floor Warming Only

Press and hold the MODE and VIEW buttons simultaneously for five seconds to enter the setup mode.
SYSTEM SETUP
SETUP: SYSTEM Heat Sys Type: Slab Reg:
FLOOR WARMING ONLY (W1)
Heat System Type: SLAB 1
Slab Regulation: (1 – 6)
1= Narrow temperature regulation 6= Wide temperature regulation
NOTE: Slab mode 1 requires a slab remote sensor (CHV-RSS).
SLAB 1 6
SYSTEM PERFORMANCE
SETUP: SYSTEM PERF
NO APPLICABLE SETTINGS
HUMIDIFIER OPTIONS
SETUP: HUM OPTS
Show Hum Mode Pg: Show Hum View Pg: Cold Weather Comp:
SYSTEM ENABLE/DISABLE PAGE
Show Hum Mode Pg and Show Hum View Pg: Select Y to show humidity page in normal
operation. Cold Weather Compensation: Modifies the humidifier output to prevent condensation on the windows. Requires an outdoor temperature source (CHV-THSAT, or CHV-TSTAT with CHV-RTHS, CHV-RTS, or CHV-RSS).
34 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Y Y N
Continued on the following page.
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slab 1 – Floor Warming Only (Continued)
DEVICE OPTIONS
SETUP: DEVICE OPTS
Network ID: LCD Contrast
CHV-THSTAT [v2.0, #D8000000]
Select Network ID: Valid entries are 03 to FE in Hex to match the network ID set for the thermostat in SIMPL Windows.
LCD Screen Contrast: 1 Lighter through 10 Darker
Displays Model number, Firmware version and TSID.
2A 5
SCREEN OPTIONS
SETUP: SCRN OPTIONS
Disp Global Page: Disp Outdoor Page: Disp Rem Func Pg1: Disp Rem Func Pg2: Reverse SMODE Dir
Options seen when VIEW is pressed:
Y Y Y Y N
Global Page – Temperature & humidity selection for entire house (if part of a Cresnet system). Outdoor Page – Temperature & humidity of the outside sensor. Remote Function Page 1, 2 – Allows remote control of other functions (for example: lights, alarms, etc.). Reverse SMODE Dir – Allows arrow keys to select mode functions in both directions.
DISPLAY OPTIONS
SETUP: DISP OPTIONS
Temperature Units: Temp Display Offset:
Main Scn Lwr Obj: Use 0.5 Deg C Step:
°F or °C – Display in Fahrenheit or Celsius.
Offset (-6 to +6°F) Allows the user to adjust
the displayed/regulated temperature.
Main Screen Lower Object
SB – Slab OD – Outdoor HM – Humidity NA – None
°C may be displayed in 0.5 units
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 35
F 0
SB Y
0
Continued on the following page.
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slab 1 – Floor Warming Only (Continued)
OTHER SETTINGS
SETUP: OTHER SETTINGS
NO APPLICABLE SETTINGS
SENSORS
SETUP: SENSORS
Sensor Internal: Remote 1:
DETECTED: 1 x T
>TEMP HUM OMIT USE SLAB
Remote 2:
NOTE: Built-in temperature sensor signal locked out in Floor Warming mode for Slab 1 system type.
SERVICE/TEST
SETUP: SERVICE/TEST Slab Heat Call:
Humidifier Call: Fan Call:
NOTE: This screen bypasses all system delays and is used by the installer to manually operate the HVAC system. Only one system can be run at a time.
Press MODE button to return to the first screen. Simultaneously press and hold the MODE and VIEW buttons to return to normal operation mode.
OFF
OFF OFF
Choose SLAB (Remote Sensors Only)
NOTE: Remote 1 and Remote 2 options do not appear on this screen if these sensors are not connected.
Press MODE button to return to the first screen
Or
Press and hold the MODE and VIEW buttons
simultaneously for five seconds to exit Setup.
NOTE: You cannot exit if the sensor setup does not meet system requirements.
36 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slab 2 – Single Stage Space Heat with Slab Maximum
Press and hold the MODE and VIEW buttons simultaneously for five seconds to enter the setup mode.
SYSTEM SETUP
SETUP: SYSTEM Heat Sys Type: Slab MAX T:
1 STG SPACE HEAT BY SLAB WITH SLAB MAX (W1)
SLAB 2
o
122
Heat System Type: SLAB 2
Slab Maximum Temperature:
39 to 122° F (39 – 50° C). Used to prevent the floor from becoming too hot on long heat calls.
NOTE: Slab mode 2 requires a slab remote sensor and an air temperature sensor.
HUMIDIFIER OPTIONS
SYSTEM PERFORMANCE
Heat Anticipator:
(valid selections are 1 through 6) Low number = more frequent cycles and faster response (tighter regulation). High number = less frequent cycles and slower response (looser regulation).
SETUP: SYSTEM PERF
Heat Anticipator:
5
SETUP: HUM OPTS
Show Hum Mode Pg: Show Hum View Pg: Cold Weather Comp:
SYSTEM ENABLE/DISABLE PAGE
Y Y N
Show Hum Mode Pg and Show Hum View Pg: Select Y to show humidity page in normal
operation. Cold Weather Compensation: Modifies the humidifier output to prevent condensation on the windows. Requires an outdoor temperature source (CHV-THSAT, or CHV­TSTAT with CHV-RTHS, CHV-RTS, or CHV­RSS).
Continued on the following page.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 37
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slab 2 – Single Stage Space Heat with Slab Maximum (Continued)
DEVICE OPTIONS
SETUP: DEVICE OPTS
Network ID: LCD Contrast
CHV-THSTAT [v2.0, #D8000000]
Select Network ID: Valid entries are 03 to FE in Hex to match the network ID set for the thermostat in SIMPL Windows.
LCD Screen Contrast: 1 Lighter through 10 Darker
Displays Model number, Firmware version and TSID.
DISPLAY OPTIONS
2A 5
SCREEN OPTIONS
Global Page – Temperature & humidity selection for entire house if part of a Cresnet system. Outdoor Page – Temperature & humidity of the
outside sensor. Remote Function Page 1, 2 – Allows remote control of other functions (for example: lights, alarms, etc.). Reverse SMODE Dir – Allows arrow keys to select mode functions in both directions.
SETUP: SCRN OPTIONS
Disp Global Page: Disp Outdoor Page: Disp Rem Func Pg1: Disp Rem Func Pg2: Reverse SMODE Dir
Y Y Y Y N
SETUP: DISP OPTIONS
Temperature Units: Temp Display Offset:
Main Scn Lwr Obj: Use 0.5 Deg C Step:
°F or °C – Display in Fahrenheit or Celsius.
Offset (-6 to +6°F) Allows the user to adjust the
displayed/regulated temperature.
Main Screen Lower Object
SB – Slab OD – Outdoor HM – Humidity NA – None
°C may be displayed in 0.5 units.
38 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
F 0
SB Y
0
Continued on the following page.
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slab 2 – Single Stage Space Heat with Slab Maximum (Continued)
OTHER SETTINGS
SETUP: OTHER SETTINGS
NO APPLICABLE SETTINGS
SERVICE/TEST
SETUP: SERVICE/TEST Slab Heat Call:
Humidifier Call: Fan Call:
NOTE: This screen bypasses all system delays and is used by the installer to manually operate the HVAC system. Only one system can be run at a time.
OFF
OFF OFF
SENSORS
SETUP: SENSORS
Sensor Internal: Remote 1:
DETECTED: 1 x T
>TEMP HUM USE OMIT SLAB
Remote 2:
Choose USE or OMIT (Built-in Sensors Only). Choose USE, OMIT, OD, or SLAB (Remote Sensors Only) NOTE: Remote 1 and Remote 2 options do not appear on this screen if these sensors are not connected.
Press MODE button to return to the first screen
Or
Press and hold the MODE and VIEW buttons simultaneously for five seconds to exit Setup.
NOTE: You cannot exit if the sensor setup does not meet system requirements.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 39
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slab 3 – Single Stage Heat with Slab Minimum/Maximum
Press and hold the MODE and VIEW buttons simultaneously for five seconds to enter setup mode.
SYSTEM SETUP
SETUP: SYSTEM Heat Sys Type:
Slab MAX T: Slab Reg:
1 STG SPACE HEAT BY SLAB WITH SLAB MIN/MAX (W1)
SLAB 3
o
122 6
Heat System Type: SLAB 3
Slab Maximum Temperature: 39 to 122° F
(39 – 50° C). Used to prevent the floor from becoming too hot on long heat calls. Slab Regulation: 1 = Narrow temperature regulation 6 = Wide temperature regulation NOTE: Slab mode 3 requires a slab remote sensor and an air temperature sensor.
SYSTEM PERFORMANCE
SETUP: SYSTEM PERF
Heat Anticipator:
5
HUMIDIFIER OPTIONS
SETUP: HUM OPTS
Show Hum Mode Pg: Show Hum View Pg: Cold Weather Comp:
SYSTEM ENABLE/DISABLE PAGE
Y Y N
Show Hum Mode Pg and Show Hum View Pg: Select Y to show humidity page in normal
operation. Cold Weather Compensation: Modifies the humidifier output to prevent condensation on the windows. Requires an outdoor temperature source (CHV-THSAT, or CHV-TSTAT with CHV-RTHS, CHV-RTS, or CHV-RSS).
Heat Anticipator: (valid selections are 1 through 6) Low number = more frequent cycles and faster response (tighter regulation). High number = less frequent cycles and slower response (looser regulation).
Continued on the following page.
40 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slab 3 – Single Stage Heat with Minimum/Maximum (Continued)
DEVICE OPTIONS
SETUP: DEVICE OPTS
Network ID: LCD Contrast
2A 5
CHV-THSTAT [v2.0, #D8000000]
Select Network ID: Valid entries are 03 to FE in Hex to match the network ID set for the thermostat in SIMPL Windows.
LCD Screen Contrast: 1 Lighter through 10 Darker
Displays Model number, Firmware version and TSID.
DISPLAY OPTIONS
SETUP: DISP OPTIONS
Temperature Units: Temp Display Offset:
F
0
0
SCREEN OPTIONS
SETUP: SCRN OPTIONS
Disp Global Page: Disp Outdoor Page: Disp Rem Func Pg1: Disp Rem Func Pg2: Reverse SMODE Dir
Y Y Y Y N
Global Page – Temperature & humidity selection for entire house if part of a Cresnet system. Outdoor Page – Temperature & humidity of the outside sensor. Remote Function Page 1, 2 – Allows remote control of other functions (for example: lights, alarms, etc.). Reverse SMODE Dir – Allows arrow keys to select mode functions in both directions.
Main Scn Lwr Obj: Use 0.5 Deg C Step:
SB Y
°F or °C – Display in Fahrenheit or Celsius.
Offset (-6 to +6°F) Allows the user to adjust the
displayed/regulated temperature.
Main Screen Lower Object
SB – Slab OD – Outdoor HM – Humidity NA – None
°C may be displayed in half units.
Continued on the following page.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 41
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slab 3 – Single Stage Heat with Minimum/Maximum (Continued)
OTHER SETTINGS
SETUP: OTHER SETTINGS
NO APPLICABLE SETTINGS
SENSORS
SETUP: SENSORS Sensor
Internal: Remote 1:
DETECTED: 1 x T
>TEMP HUM OMIT USE SLAB
Remote 2:
Choose USE or OMIT (Built-in Sensors Only)
Choose USE, OMIT, OD, or SLAB (Remote Sensors Only)
NOTE: Remote 1 and Remote 2 options do not appear on this screen if these sensors are not connected.
SERVICE/TEST
SETUP: SERVICE/TEST Slab Heat Call:
Humidifier Call: Fan Call:
NOTE: This screen bypasses all system delays and is used by the installer to manually operate the HVAC system. Only one system can be run at a time. Press MODE button to return to the first screen. Simultaneously press and hold the MODE and VIEW buttons to return to normal operation mode.
42 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
OFF
OFF OFF
Press MODE button to return to the first screen
Or
Press and hold the MODE and VIEW buttons simultaneously for five seconds to exit Setup.
NOTE: You cannot exit if the sensor setup does not meet system requirements.
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slab 4A – Two Stage Heat/One Stage Cool with Slab Maximum
Press and hold the MODE and VIEW buttons simultaneously for five seconds to enter setup mode.
SYSTEM SETUP
SETUP: SYSTEM Heat Sys Type: Slab MAX T:
2 STG SPACE HEAT - 1 STG COOL WITH SLAB MAX (H/C) SLAB = (W1), HT = W2, CL = Y1
SLAB 4A
o
122
Heat System Type: SLAB 4A
Slab Maximum Temperature: 39 to 122° F (39
to 50° C). Used to prevent the floor from becoming too hot on long heat calls.
NOTE: Slab mode 4A requires a slab remote sensor and an air temperature sensor.
HUMIDIFIER OPTIONS
SETUP: HUM OPTS
Show Hum Mode Pg: Show Hum View Pg: Cold Weather Comp:
SYSTEM ENABLE/DISABLE PAGE
Y Y N
Show Hum Mode Pg and Show Hum View Pg: Select Y to show humidity page in normal
operation. Cold Weather Compensation: Modifies the humidifier output to prevent condensation on the windows. Requires an outdoor temperature source (CHV-THSAT, or CHV-TSTAT with CHV-RTHS, CHV-RTS, or CHV-RSS).
SYSTEM PERFORMANCE
SETUP: SYSTEM PERF
Heat Anticipator: Cool Anticipator: Intrstg Differential:
5 2
2.0
0
Anticipators: (1 through 6) Low number = more frequent cycles and faster response. High number = less frequent cycles and slower response (looser regulation). Interstage Differential: 0.5 to 8.0ºF. The proportional temperature error to trigger the second stage.
Continued on the following page.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 43
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slab 4A – Two Stage Heat/One Stage Cool with Slab Maximum (Continued)
DEVICE OPTIONS
SETUP: DEVICE OPTS
Network ID: LCD Contrast
CHV-THSTAT [v2.0, #D8000000]
2A 5
Select Network ID: Valid entries are 03 to FE in Hex to match the network ID set for the thermostat in SIMPL Windows.
LCD Screen Contrast: 1 Lighter through 10 Darker
Displays Model number, Firmware version and TSID.
SCREEN OPTIONS
SETUP: SCRN OPTIONS
Disp Global Page: Disp Outdoor Page: Disp Rem Func Pg1: Disp Rem Func Pg2: Reverse SMODE Dir
Y Y Y Y N
Global Page – Temperature & humidity selection for entire house if part of a Cresnet system. Outdoor Page – Temperature & humidity of the outside sensor. Remote Function Page 1, 2 – Allows remote control of other functions (for example: lights, alarms, etc.). Reverse SMODE Dir – Allows arrow keys to select mode functions in both directions.
DISPLAY OPTIONS
SETUP: DISP OPTIONS Temperature Units:
Temp Display Offset: Dual Setpoint Auto: Main Scn Lwr Obj: Use 0.5 Deg C Step:
F
0
0 Y SB Y
°F or °C – Display in Fahrenheit or Celsius. Offset (-6 to +6°F) Allows the user to adjust the
displayed and regulated temperature. Dual Setpoint Auto – enables two-point auto mode.
Main Screen Lower Object:
SB – Slab OD – Outdoor HM – Humidity NA – None
°C may be displayed in 0.5 units.
Continued on the following page.
44 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slab 4A – Two Stage Heat/One Stage Cool with Slab Maximum (Continued)
OTHER SETTINGS
SETUP: OTHER SETTINGS
Wide Range Cool: Run Fan in Ht Calls: Auto DdBand Deg: Disable Auto Mode:
EXTENDED COOL SETPOINT RANGE 38-99F (3-37C)
N N 2 N
0
Wide Range Cool: Extends cool setpoint to full auto range of 38 to 99 degrees F. Run Fan in Heat Calls: Most heating systems run the fan automatically. If your heating system requires fan control, select Yes. Auto Mode Dead Band: (valid selections are 2 through 6) The minimum differential between heating and cooling setpoints (Dual Setpoint Auto set to Yes in Display Options). Disable Auto Mode: Will not display Auto on System Mode screen and will not permit entering the auto mode even from Cresnet commands.
SETUP: SENSORS
Sensor Internal: Remote 1:
DETECTED: 1 x T
SENSORS
>TEMP HUM OMIT USE SLAB
Remote 2:
Choose USE or OMIT (Built-in Sensors Only)
Choose USE, OMIT, OD, or SLAB (Remote Sensors Only)
NOTE: Remote 1 and Remote 2 options do not appear on this screen if these sensors are not connected.
SERVICE/TEST
Press MODE button to return to the first screen
SETUP: SERVICE/TEST
Slab Heat Call:
Space Heat Call:
Space Cool Call:
Humidifier Call:
Fan Call:
OFF OFF OFF OFF OFF
NOTE: This screen bypasses all system delays and is used by the installer to manually operate
Press and hold the MODE and VIEW buttons simultaneously for five seconds to exit Setup.
NOTE: You cannot exit if the sensor setup does not meet system requirements.
Or
the HVAC system. Only one system can be run at a time.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 45
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slab 4B – 2 Stage Heat/1 Stage Cool with Slab Maximum (Heat Pump)
Press and hold the MODE and VIEW buttons simultaneously for five seconds to enter setup mode.
SYSTEM SETUP
SETUP: SYSTEM Heat Sys Type:
Slab MAX T: HP/AUX or DF:
2 STG SPACE HEAT - 1 STG COOL WITH SLAB MAX (HP) SLAB = W1, HT/CL = Y1/O/G
SLAB 4B 122 HP/Aux
o
Heat System Type: SLAB 4B Slab Maximum Temperature: 39 to 122° F (39
to 50°C). Used to prevent the floor from becoming too hot on long heat calls.
Heat Pump/Aux or Dual Fuel NOTE: Slab mode 4B requires a slab remote
sensor and an air temperature sensor.
SYSTEM PERFORMANCE
SETUP: SYSTEM PERF
Heat Anticipator: Cool Anticipator: Intrstg Differential: HP Balance Pt: AUX Balance Pt:
5 6
0.5 Off 1
0
0
Anticipators: (1 - 6) Low number = more frequent cycles, faster response. High number = less frequent cycles, slower response. Interstage Differential: 0.5 to 8.0ºF. The proportional temperature error to trigger the second stage. HP Balance Point - Minimum outdoor temperature at which the heat pump runs (requires outdoor sensor) AUX Balance Point - Maximum outdoor temperature at which Aux Heat System supplements the heat pump (requires outdoor sensor)
HUMIDIFIER OPTIONS
SETUP: HUM OPTS
Show Hum Mode Pg: Show Hum View Pg: Cold Weather Comp:
SYSTEM ENABLE/DISABLE PAGE
Y Y N
Show Hum Mode Pg and Show Hum View Pg: Select Y to show humidity page in normal
operation. Cold Weather Compensation: Modifies the humidifier output to prevent condensation on the windows. Requires an outdoor temperature source (CHV-THSAT, or CHV-TSTAT with CHV-RTHS, CHV-RTS, or
Continued on the following page.
CHV-RSS).
46 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slab 4B – 2 Stage Heat/1 Stage Cool with Slab Maximum - Heat Pump (Continued)
DEVICE OPTIONS
SETUP: DEVICE OPTS
Network ID: LCD Contrast
CHV-THSTAT [v2.0, #D8000000]
2A 5
Select Network ID: Valid entries are 03 to FE in Hex to match the network ID set for the thermostat in SIMPL Windows. LCD Screen Contrast: 1 Lighter through 10 Darker
Displays Model Number, Firmware version, and TSID number.
SCREEN OPTIONS
SETUP: SCRN OPTIONS
Disp Global Page: Disp Outdoor Page: Disp Rem Func Pg1: Disp Rem Func Pg2: Reverse SMODE Dir
Y Y Y Y N
Global Page – Temperature & humidity selection for entire house if part of a Cresnet system. Outdoor Page – Temperature & humidity of the outside sensor. Remote Function Page 1, 2 – Allows remote control of other functions (for example: lights, alarms, etc.).
Reverse SMODE Dir – Allows arrow keys to select mode functions in both directions.
DISPLAY OPTIONS
SETUP: DISP OPTIONS
Temperature Units: Temp Display Offset: Dual Setpoint Auto: Main Scn Lwr Obj: Use 0.5 Deg C Step:
F 0 Y SB Y
0
°F or °C – Display in Fahrenheit or Celsius. Offset (-6 to +6°F) Allows the user to adjust the
displayed and regulated temperature. Dual Setpoint Auto – enables two-point auto mode.
Main Screen Lower Object:
SB – Slab OD – Outdoor HM – Humidity NA – None
Continued on the following page.
°C may be displayed in 0.5 units.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 47
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slab 4B – 2 Stage Heat/1 Stage Cool with Slab Maximum - Heat Pump (Continued)
OTHER SETTINGS
SETUP: OTHER SETTINGS
Wide Range Cool: Run Fan in Ht Calls: Auto DdBand Deg: Disable Auto Mode:
EXTENDED COOL SETPOINT RANGE 38-99F (3-37C)
N N
0
2 N
Wide Range Cool: Extends cool setpoint to full auto range of 38 to 99 degrees F. Run Fan in Heat Calls: Most heating systems run the fan automatically. If your heating system requires fan control, select Yes. Auto Mode Dead Band: (valid selections are 2 through 6) The minimum differential between heating and cooling setpoints (Dual Setpoint Auto set to Yes in Display Options). Disable Auto Mode: Will not display Auto on System Mode screen and will not permit entering the auto mode even from Cresnet commands.
SETUP: SENSORS
Sensor Internal: Remote 1:
DETECTED: 1 x T
Remote 2:
SENSORS
>TEMP HUM OMIT USE SLAB
Choose USE or OMIT (Built-in Sensors Only)
Choose USE, OMIT, OD, or SLAB (Remote Sensors Only)
NOTE: Remote 1 and Remote 2 options do not appear on this screen if these sensors are not connected.
SERVICE/TEST
SETUP: SERVICE/TEST
SLAB HEAT CALL:
SPACE HEAT CALL:
SPACE COOL CALL:
AUX HEAT CALL
HUMIDIFIER CALL:
FAN CALL:
OFF OFF OFF OFF OFF OFF
Press MODE button to return to the first screen
Or
Press and hold the MODE and VIEW buttons simultaneously for five seconds to exit Setup.
NOTE: This screen bypasses all system delays and is used by the installer to manually operate the HVAC system. Only one system can be run
NOTE: You cannot exit if the sensor setup does not meet system requirements.
at a time.
48 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Slab 5A – 1 Stage Heat/Cool with Floor Warming

Press and hold the MODE and VIEW buttons simultaneously for five seconds to enter setup mode.
SYSTEM SETUP
SETUP: SYSTEM Heat Sys Type: Slab Reg:
1 STG SPACE HEAT-COOL WITH FLOOR WARMING SLAB (W1) HT=W2 CL=Y1/G
SLAB 5A 2
Heat System Type: SLAB 5A
Slab Regulation: (1 – 6)
1 = Narrow temperature regulation 6 = Wide temperature regulation NOTE: Slab mode 5A requires a slab remote sensor and an air temperature sensor.
SYSTEM PERFORMANCE
SETUP: SYSTEM PERF
Heat Anticipator: Cool Anticipator:
5 2
Anticipators: (valid selections are 1 through 6) Low number = more frequent cycles and faster response (tighter regulation). High number = less frequent cycles and slower response (looser regulation).
HUMIDIFIER OPTIONS
SETUP: HUM OPTS
Show Hum Mode Pg: Show Hum View Pg: Cold Weather Comp:
SYSTEM ENABLE/DISABLE PAGE
Y Y N
Show Hum Mode Pg and Show Hum View Pg: Select Y to show humidity page in normal
operation. Cold Weather Compensation: Modifies the humidifier output to prevent condensation on the windows. Requires an outdoor temperature source (CHV-THSAT, or CHV-TSTAT with CHV-RTHS, CHV-RTS, or CHV-RSS).
Continued on the following page.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 49
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slab 5A – 1 Stage Heat/Cool with Floor Warming (Continued)
DEVICE OPTIONS
SETUP: DEVICE OPTS
Network ID: LCD Contrast
CHV-THSTAT [v2.0, #D8000000]
2A 5
Select Network ID: Valid entries are 03 to FE in Hex to match the network ID set for the thermostat in SIMPL Windows. LCD Screen Contrast: 1 Lighter through 10 Darker
Displays Model Number, Firmware version, and TSID number.
SCREEN OPTIONS
SETUP: SCRN OPTIONS
Disp Global Page: Disp Outdoor Page: Disp Rem Func Pg1: Disp Rem Func Pg2: Reverse SMODE Dir
Y Y Y Y N
Global Page – Temperature & humidity selection for entire house if part of a Cresnet system. Outdoor Page – Temperature & humidity of the outside sensor. Remote Function Page 1, 2 – Allows remote control of other functions (for example: lights, alarms, etc.). Reverse SMODE Dir – Allows arrow keys to select mode functions in both directions.
DISPLAY OPTIONS
SETUP: DISP OPTIONS Temperature Units:
Temp Display Offset: Dual Setpoint Auto: Main Scn Lwr Obj: Use 0.5 Deg C Step:
F 0 Y SB Y
0
°F or °C – Display in Fahrenheit or Celsius. Offset (-6 to +6°F) Allows the user to adjust the
displayed and regulated temperature. Dual Setpoint Auto – enables two-point auto mode.
Main Screen Lower Object:
SB – Slab OD – Outdoor HM – Humidity NA – None
Continued on following page.
°C may be displayed in 0.5 units.
50 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slab 5A – 1 Stage Heat/Cool with Floor Warming (Continued)
OTHER SETTINGS
SETUP: OTHER SETTINGS
Wide Range Cool:
Run Fan in Ht Calls:
Auto DdBand Deg:
Disable Auto Mode:
EXTENDED COOL SETPOINT
RANGE 38-99F (3-37C)
N N 2 N
0
Wide Range Cool: Extends cool setpoint to full auto range of 38 to 99 degrees F. Run Fan in Heat Calls: Most heating systems run the fan automatically. If your heating system requires fan control, select Yes. Auto Mode Dead Band: (valid selections are 2 through 6) The minimum differential between heating and cooling setpoints (Dual Setpoint Auto set to Yes in Display Options). Disable Auto Mode: Will not display Auto on System Mode screen and will not permit entering the auto mode even from Cresnet commands.
SETUP: SENSORS Sensor
Internal: Remote 1:
DETECTED: 1 x T
Remote 2:
SENSORS
>TEMP HUM OMIT USE SLAB
Choose USE or OMIT (Built-in Sensors Only)
Choose USE, OMIT, OD, or SLAB (Remote Sensors Only)
NOTE: Remote 1 and Remote 2 options do not appear on this screen if these sensors are not connected.
SERVICE/TEST
SETUP: SERVICE/TEST Slab Heat Call:
Space Heat Call: Space Cool Call: Humidifier Call: Fan Call:
OFF OFF OFF OFF OFF
NOTE: This screen bypasses all system delays and is used by the installer to manually operate the HVAC system. Only one system can be run
Press MODE button to return to the first screen
Or
Press and hold the MODE and VIEW buttons simultaneously for five seconds to exit Setup.
NOTE: You cannot exit if the sensor setup does not meet system requirements.
at a time.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 51
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slab 5B – 1 Stage Heat/Cool with Floor Warming (Heat Pump)
Press and hold the MODE and VIEW buttons simultaneously for five seconds to enter setup mode. Slab mode 5B requires a slab remote sensor and an air temperature sensor.
SYSTEM SETUP
SETUP: SYSTEM
Heat Sys Type: Slab Reg: HP/AUX or DF:
1 STG SPACE HEAT - COOL W/ FLOOR WARMING (HEATPUMP) SLAB=W1 HT/CL=Y1/O/G
SLAB 5B 6 HP/Aux
Heat System Type: SLAB 5B Slab Regulation: (1 – 6) 1 = Narrow temperature regulation 6 = Wide temperature regulation
Heat Pump/Aux or Dual Fuel
SYSTEM PERFORMANCE
SETUP: SYSTEM PERF
Heat Anticipator: Cool Anticipator: Intrstg Differential: HP Balance Pt: AUX Balance Pt:
5 6
0
0.5 Off
0
1
Anticipators: (valid selections are 1 through 6) Low number = more frequent cycles and faster response (tighter regulation). High number = less frequent cycles and slower response (looser regulation). Interstage Differential: 0.5 to 8.0ºF. The proportional temperature error to trigger the second (Aux) stage. HP Balance Point - Minimum outdoor temperature at which the heat pump runs (requires outdoor sensor). AUX Balance Point - Maximum outdoor temperature at which Aux Heat System supplements the heat pump (requires outdoor sensor).
HUMIDIFIER OPTIONS
SETUP: HUM OPTS
Show Hum Mode Pg: Show Hum View Pg: Cold Weather Comp:
SYSTEM ENABLE/DISABLE PAGE
Y Y N
Show Hum Mode Pg and Show Hum View Pg: Select Y to show humidity page in normal operation. Cold Weather Compensation: Modifies the humidifier
output to prevent condensation on the windows. Requires an outdoor temperature source (CHV-THSAT, or CHV-TSTAT with CHV-RTHS, CHV-RTS, or CHV-RSS).
52 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Continued on following page.
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slab 5B – 1 Stage Heat/Cool with Floor Warming (Heat Pump) (Continued)
DEVICE OPTIONS
SETUP: DEVICE OPTS
Network ID: LCD Contrast
CHV-THSTAT [v2.0, #D8000000]
2A 5
Select Network ID: Valid entries are 03 to FE in Hex to match the network ID set for the thermostat in SIMPL Windows.
LCD Screen Contrast: 1 Lighter through 10 Darker
Displays Model Number, Firmware version, and TSID number.
SCREEN OPTIONS
SETUP: SCRN OPTIONS
Disp Global Page: Disp Outdoor Page: Disp Rem Func Pg1: Disp Rem Func Pg2: Reverse SMODE Dir
Y Y Y Y N
Global Page – Temperature & humidity selection for entire house if part of a Cresnet system. Outdoor Page – Temperature & humidity of the outside sensor. Remote Function Page 1, 2 – Allows remote control of other functions (for example: lights, alarms, etc.).
Reverse SMODE Dir – Allows arrow keys to select mode functions in both directions.
DISPLAY OPTIONS
SETUP: DISP OPTIONS
Temperature Units: Temp Display Offset: Dual Setpoint Auto: Main Scn Lwr Obj: Use 0.5 Deg C Step:
F 0 Y SB Y
0
°F or °C – Display in Fahrenheit or Celsius. Offset (-6 to +6°F) Allows the user to adjust
the displayed and regulated temperature. Dual Setpoint Auto – enables two-point auto mode.
Main Screen Lower Object:
SB – Slab OD – Outdoor HM – Humidity NA – None
Continued on following page.
°C may be displayed in 0.5 units.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 53
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slab 5B – 1 Stage Heat/Cool with Floor Warming (Heat Pump) (Continued)
OTHER SETTINGS
SETUP: OTHER SETTINGS
Wide Range Cool: Run Fan in Ht Calls: Auto DdBand Deg: Disable Auto Mode:
EXTENDED COOL SETPOINT RANGE 38-99F (3-37C)
N N
0
2 N
Wide Range Cool: Extends cool setpoint to full auto range of 38 to 99 degrees F. Run Fan in Heat Calls: Most heating systems run the fan automatically. If your heating system requires fan control, select Yes. Auto Mode Dead Band: (valid selections are 2 through 6) The minimum differential between heating and cooling setpoints (Dual Setpoint Auto set to Yes in Display Options). Disable Auto Mode: Will not display Auto on System Mode screen and will not permit entering the auto mode even from Cresnet commands.
SETUP: SENSORS Sensor
Internal: Remote 1:
DETECTED: 1 x T
SENSORS
>TEMP HUM OMIT USE SLAB
Remote 2:
Choose USE or OMIT (Built-in Sensors Only)
Choose USE, OMIT, OD, or SLAB (Remote Sensors Only)
NOTE: Remote 1 and Remote 2 options do not appear on this screen if these sensors are not connected.
SERVICE/TEST
SETUP: SERVICE/TEST
SLAB HEAT CALL: SPACE HEAT CALL: SPACE COOL CALL: AUX HEAT CALL HUMIDIFIER CALL: FAN CALL:
OFF OFF OFF OFF OFF OFF
NOTE: This screen bypasses all system delays and is used by the installer to manually operate the HVAC system. Only one system can be run
Press MODE button to return to the first screen
Or
Press and hold the MODE and VIEW buttons simultaneously for five seconds to exit Setup.
NOTE: You cannot exit if the sensor setup does not meet system requirements.
at a time.
54 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Operating the Thermostat

After setup, configure the thermostat using the following screens.
Main Screen
F
%
o
F
68
HEATING HEAT ONLY ON LINE
H1
MODE
o
66
VIEW
This example shows:
The current temperature as 66
The current humidity as 43%
The Heating Setpoint as 68 oF
The heating system is running
The thermostat is on-line
System mode is HEAT ONLY
43
T
o
F
The Main Screen displays the Current Temperature, System Mode, Fan Mode, and Set Point temperatures. The CHV-THSTAT also displays
T
Relative Humidity. Press the up arrow button to increase the set point temperature. Press the down arrow button to decrease the set point temperature.
NOTE: If you selected Yes in setup screen Display Options for “Dual Setpoint Auto”, pressing MODE toggles between the Heat and Cool setpoints while they are flashing. Pressing Mode will not change the screen until the setpoint has stopped flashing.
This screen also indicates the system currently running:
H1 – Heat System or Stage 1 Heat System H2 – Stage 2 Heat System AX – Auxiliary Heating System C1 – Cooling System or Stage 1 Cooling System C2 – Stage 2 Cooling System SB – Slab heat system HM– Humidifier
System Mode Screen
MODE
VIEW
System Mode
HEAT COOL AUTO OFF
AUX HEAT ONLY
NOTE: System indicators flash to indicate short cycle timer protection (timer guards) engaged.
MODE
MODE Button
It may also be necessary to access the following series of screens. Pressing the MODE button allows the user to access the following screens:
1. System Mode screen and/or Slab System Mode screen(s)
2. Fan Mode screen
3. Humidifier screen
4. Crestron System screen
5. Global Update screen
1. System Mode or Slab System Mode
The “System Mode” screen appears when the MODE button is initially
T
pressed. Use the up and down arrow buttons to select HEAT, COOL, AUTO, OFF or AUX HEAT ONLY.
T
If your system is SLAB 1, SLAB 3, or SLAB 5, the Slab System Mode screens appear as described on the following page.
NOTE: The AUTO selection allows the system to switch between Heat and Cool automatically as needed to maintain the temperature.
NOTE: The AUX HEAT ONLY is for the backup heating system on Heat Pump based systems only. It allows the backup system to operate without operating the heat pump.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 55
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
NOTE: The Slab 2 System Mode screen offers HEAT and OFF choice only.
Slab System Mode Screens
Slab 1 System Mode
Press MODE button to continue to “2. Fan Mode” screen on the following page.
Slab 3 System Mode
Displays current floor warming temperature and setpoint. Press MODE button for System Mode screen.
Press MODE button to continue to “2. Fan Mode” screen on the following page.
Slab 5 System Mode
Displays current floor warming temperature and setpoint. Press MODE button to continue to Air System Mode screen.
Displays Air System Mode control. Press MODE button to continue to Slab System Mode screen.
Press MODE button to continue to “2. Fan Mode” screen on the following page.
To Fan Mode
56 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Fan Mode Screen
MODE
VIEW
Fan Mode
AUTO ON
Humidifier Screen
MODE
VIEW
Humidifier
ENABLED DISABLED
Crestron System Screen
MODE
VIEW
Crestron Sys
ONLINE HOLD
2. Fan Mode
T
T
Pressing the MODE button again displays the “Fan Mode” screen.
Use the up and downarrow buttons to select AUTO or ON.
NOTE: In AUTO, the fan runs only when the system calls for heat or cool. In ON, the fan runs continuously.
3. Humidifier
T
T
Pressing the MODE button displays the “Humidifier” screen. This screen appears if enabled in setup and the thermostat is equipped with a humidity sensor.
Use the up and down arrow buttons to select ENABLED or DISABLED.
4. Crestron System
T
T
Pressing the MODE button again displays the “Crestron Sys” screen. Use the up and downarrow buttons to select ONLINE or HOLD.
ONLINE – Data flows both ways, to and from the thermostat, enabling
adjustment from a remote location.
HOLD – Data flows one way, from the thermostat, blocking system
commands to change the temperature and humidity when you do not want the current settings reset. Restores to the last command sent when online is re-engaged.
Global Update Screen
MODE
VIEW
Global Update
SEND
5. Global Update
T
T
Pressing the MODE button again displays the “Global Update” screen. Allows a single thermostat location to update the current temperature settings to all other thermostats on the system, provided that this function has been defined in the Crestron program.
Press the down button to send the update.
Pressing the MODE button again returns you to the Main Screen
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 57
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Humidity Screen
MODE
VIEW
30
Humidity
%
24
VIEW
VIEW Button
The following screens are accessed by pressing the VIEW button:
1. Humidity (If enabled in Setup)
2. Outdoor (If enabled in Setup)
3. Messages
NOTE: If enabled, the VIEW button also allows access to the remote button function screens. When part of a Cresnet system, the up and down arrow buttons can be used to enable other functions (i.e., lighting control, alarm system, etc.).
1. Humidity
T
%
T
Press the VIEW button to display the “Humidity” screen. The setpoint adjustment range is 5 – 70%.
Use the up and down arrow buttons to adjust the Humidity Set Point level. This page only appears if enabled in the “HUM OPTS” setup screen and the thermostat is equipped with a humidity sensor.
NOTE: If a CHV-RTHS temperature/humidity sensor is installed, a CHV­TSTAT can import and display the humidity.
Outdoor Screen
MODE
VIEW
Messages Screen
MODE
<CLR
VIEW
Emergency Gen in Use
Outdoor
32
Messages
2. Outdoor
T
o
F
T
Press the VIEW button again to display the “Outdoor” screen. This allows the user to view the outdoor temperature (if an outdoor sensor has been installed) and outdoor humidity (if available). Outdoor temperature/humidity can come from an outdoor sensor wired directly to the thermostat or through the Cresnet system from another source. This page is only displayed if enabled in the “SCRN OPTIONS” setup screen.
NOTE: This is only a display and not for system activation. This display can be shown on either the CHV-TSTAT or the CHV-THSTAT.
3. Messages
T
T
Press the VIEW button again to display the “Messages” screen. This screen allows the user to view any text messages sent from the control system (only when part of a Cresnet system). Text messages are limited to four lines, approximately 20 characters per line (including spaces). Allow for word wrap by staying within the 20 characters/spaces per line maximum. The thermostat auto-hyphenates when nearing the end of a line. You may use carriage returns to force a line change.
NOTE: This page is only seen when a message has been sent to the thermostat.
Press the MODE button to clear (CLR) the message(s). Acknowledges to the control system that the message has been read.
58 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Programming Software

Have a question or comment about Crestron software?
Answers to frequently asked questions (FAQs) can be viewed in the Online Help section of the Crestron website (www.crestron.com). To post your own question or view questions you have submitted to Crestron’s True Blue Support, log in at http://support.crestron.com. First-time users will need to establish a user account.
The CHV-TSTAT and CHV-THSTAT thermostats do not require programming when used as stand alone devices. Programming as part of a Cresnet system allows additional functionality, including:
Global Update and Global Page display – Allows setting the temperature/humidity for an entire house in a multi-thermostat system.
Remote Function pages – Allows system control of other functions (lighting, alarms, etc.). Two pages, two functions per page.
System Messaging – Allows the control system to send text messages to the thermostat.
Setup is easy thanks to Crestron’s Windows Crestron D3 Pro software creates a complete project, with no special programming required. D3 Pro completes all necessary programming for a base system including the control system program. Once D3 Pro creates the project, the system interfaces and program logic can be customized. It can also be modified with Crestron development tools (i.e., SIMPL Windows) software, although this should rarely be necessary.
-based programming software. The
The program output of D3 Pro is a SIMPL Windows program with much of the functionality encapsulated in macros. Therefore, extending the capabilities of the system is very easy. Crestron D3 Pro and SIMPL Windows are intended for users with different levels of programming knowledge. The flexibility of each is proportional to the degree of programming expertise (i.e., the more flexible, the more a programmer needs to know and account for). Of course, one can begin programming using the easiest method (Crestron D3 Pro) and use advanced techniques that are available from SIMPL Windows to customize the job.
D3 Pro comes with templates for all supported interfaces. If a user wishes to create a touchpanel project using templates with a different look-and-feel this can be accomplished by making a custom template. This custom template can then be used by D3 Pro to create the final project files. The following are recommended software version requirements for the PC:
[Optional] D3 Pro version 1.1 or later. Requires SIMPL Windows.
SIMPL Windows version 2.05.22 or later with library update 297.
Requires SIMPL+ Cross Compiler version 1.1.
Crestron Database version 16.3.0 or later if using D3 Pro.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 59
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
p

Programming with Crestron D3 Pro

The easiest method of
rogramming, but does not offer as much flexibility as SIMPL Windows.
Crestron D3 Pro offers automatic programming for residential and commercial systems. The interface of this tool guides you through a few basic steps for designating rooms and specifying the control system, devices, and functionality. Crestron D3 Pro then programs the system, including all control system logic.
Crestron D3 Pro is fully integrated with the Crestron suite of software development tools and accesses these tools behind the scenes, enabling you to easily create robust systems. Both the older and newer versions of the thermostat models are supported.

Programming with SIMPL Windows

NOTE: The following assumes that the reader has knowledge of SIMPL Windows. If not, refer to the extensive help information provided with the software.
NOTE: In the following description, the PRO2 control system is used.
NOTE: The slotted thermostat symbol described in this section is for 2-Series only.
SIMPL Windows is Crestron's software for programming Crestron control systems. It provides a well-designed graphical environment with a number of workspaces (i.e., windows) in which a programmer can select, configure, program, test, and monitor a Crestron control system. SIMPL Windows offers drag and drop functionality in a familiar Windows® environment.
PRO2 System View
This section describes a sample SIMPL Windows program that includes a CHV­THSTAT.
Configuration Manager is where programmers “build” a Crestron control system by selecting hardware from the Device Library. In Configuration Manager, drag the PRO2 from the Control Systems folder of the Device Library and drop it in the upper pane of the System Views. The PRO2 with its associated communication ports is displayed in the System Views upper pane.
The System Views lower pane displays the PRO2 system tree. This tree can be expanded to display and configure the communications ports.
Expanded PRO2 System Tree
60 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
C2Net-Device Slot in Configuration Manager
To incorporate a CHV-TSTAT or CHV-THSTAT into the system, drag the symbol for the thermostat from the Crestron Sensing Modules folder of the Device Library and drop it on C2NET-Device slot in System Views. The PRO2 system tree displays the thermostat symbol in Slot 9, with a default Net ID of 2A as shown in the example graphic below.
C2Net Device, Slot 9
Setting the Net ID in Device Settings
Double-click the thermostat icon in the upper pane to open the “Device Settings” window. This window displays the device information. Select the Net ID tab to change the Net ID, as shown in the following graphic.
“Device Settings” Window for the CHV-THSTAT
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 61
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Thermostat Symbol in Programming Manager
Programming Manager is where programmers “program” a Creston control system by assigning signals to symbols.
This is a slotted symbol in which the functions are grouped together in six slots.
Slot 1 – Heat Cool Control
Slot 2 – Humidity Control
Slot 3 – Slab Control
Slot 4 – Current System State
Slot 5 – Display Functions
Slot 6 – System Configuration
NOTE: Because of changes to the symbol and other improved features, this version of the SIMPL Windows symbol is not compatible with previous firmware versions.
Program View of Slotted Symbol
NOTE: All temperatures, including setpoint values, are expressed in tenths of degrees. For example: sending 703 means 70.3.
The following are detail views of the six thermostat slots in the SIMPL windows symbol. Definitions of the symbol inputs and outputs follow each diagram.
62 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slot 1 Detail View - Heat/Cool Control
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 63
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slot 1- Heat/Cool Control Digital Joins
SIGNAL I/O SIGNAL
DEFINITION
TYPE
HeatSetpoint+
HeatSetpoint-
CoolSetpoint+
CoolSetpoint-
Auto(1pt)Setpoint+
Auto(1pt)Setpoint-
SysModeHeat
SysModeCool
SysModeAuto
SysModeOff
SysModeAuxHeatOnly
SysModeHeat_F
SysModeCool_F
SysModeAuto_F
SysModeOff_F
SysModeAuxHeatOnly_F
FanOn
FanAuto
FanOn_F
FanAuto_F
OutdoorTempInput Input Analog
Input Digital
Input Digital Selects the system mode on the rising edge of the input:
Output Digital Reports the current system mode.
Input Digital Selects the fan mode on the rising edge of the input.
Output Digital Reports the current fan mode.
Raises (+) or lowers (-) the temperature regulating setpoint for heat-only, cool-only and single point auto mode, on the rising edge of the input. The setpoint is adjusted in whole degrees Fahrenheit or Celsius, or half degrees Celsius if that option is selected. Thus if the analog value of the heat setpoint equals 700 (for 70°), a rising edge of <HeatSetpoint+> will raise the heat setpoint value to 710 (for 71°). Similarly, if the analog value of the cool setpoint equals 200 (for 20°) and the half­degree Celsius option is selected, a rising edge of <CoolSetpoint-> will lower the cool setpoint value to 195 (for
19.5° C). Continuing to assert the up or down inputs at the limits of each setpoint will not affect the setpoint. That is, the setpoint will hold at its maximum or minimum setting.
High/1 (rising edge) = Setpoint up or down; Low/0 = no effect
Heat-only Cool-only Auto (auto selects heat or cool) Off (no HVAC operation) Auxiliary heat-only mode for heat pump systems (no effect on a heat/cool system). The staging for a particular mode does not affect these inputs.
High/1 (rising edge) = Select system mode; Low/0 = no effect
High/1 = System mode running; Low/0 = System mode not running
In On mode, the fan runs continually. In Auto mode, the fan runs only when the system calls for heat or cool.
High/1 (rising edge) = Select fan mode; Low/0 = no effect
High/1 = Fan mode selected; Low/0 = Fan mode not selected
Input that allows the outdoor temperature value to be retrieved from Cresnet for display on the "outdoor" page, This value is ignored when a thermostat has a remote-outdoor sensor connected to it. The temperature value is in tenths of a degree with no Fahrenheit or Celsius conversion. That is, the value is assumed to be in the native unit of the thermostat that is transmitting the temperature reading. Thus a value of 30 would display a temperature of 3° regardless of the temperature scale. If a heat pump thermostat does not have its own outdoor sensor, it may use this value for balance point action.* This is useful for multi-thermostat heat pump systems without discrete sensors.
*The heat pump balance point is the outdoor temperature below which heat pump operation is locked out, and auxiliary heat runs in place of it. The auxiliary balance point is the outdoor temperature above which auxiliary heat is locked out.
Continued on the following page
64 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slot 1- Heat/Cool Control Digital Joins - continued
SIGNAL I/O SIGNAL
DEFINITION
TYPE
HeatSetpoint
CoolSetpoint
Auto(1pt)Setpoint
HeatSetpoint_F
CoolSetpoint_F
Auto(1pt)Setpoint_F
RegulationTemp Output Analog
LocalTemp Output Analog
Remote1Temp Output Analog
Remote2Temp Output Analog
Input Analog
Output Analog
Sets the temperature regulating setpoint for heat-only, cool­only and single point auto mode in tenths of a degree. The scale (Fahrenheit or Celsius) is based on the current setting in the unit. The displayed setpoint value is rounded to whole degrees Fahrenheit or Celsius, or half degrees Celsius if that option is enabled. This means that if the value 721 is presented on the heat setpoint input, the thermostat LCD will display a setpoint of 72°. Similarly, if the value 204 is presented on the cool setpoint input and the half degree Celsius option is enabled, the thermostat LCD will display a setpoint of 20.5°.
Valid analog values are as follows:
Heat setpoint: 380 to 890 (38° to 89°F); or 30 to 320 (3° to 32°C).
Cool setpoint: 590 to 990 (59° to 99°F); or 150 to 370 (15° to 37°C).
Cool setpoint (if wide-range cool mode is enabled): 380 to 990 (38° to 99°F); or 30 to 370 (3° to 37°C).
Auto (1pt) setpoint: 380 to 990 (38° to 99°F); or 30 to 370 (3° to 37°C).
The setpoints will saturate in both directions. Thus sending 0 will set the setpoint to its minimum value, while sending 1000 will set the setpoint to its maximum value.
Reports the temperature regulating setpoint for heat-only, cool­only and single point auto mode, in tenths of a degree.
The scale (Fahrenheit or Celsius) is based on the current setting in the unit.
Reports the mean (averaged) temperature reading of all internal and remote sensors set to "Use", in tenths of a degree. The scale (Fahrenheit or Celsius) is based on the current setting in the unit. Sensors are manually set to Use, Omit, OD (Outdoor) or Slab via the setup menus on the thermostat.
Reports the temperature reading of the internal temperature sensor, in tenths of a degree. The scale (Fahrenheit or Celsius) is based on the current setting in the unit. The internal sensor reading is reported regardless of the Use/Omit/OD designation.
Reports the temperature reading of the Remote 1 temperature sensor, in tenths of a degree. The scale (Fahrenheit or Celsius) is based on the current setting in the unit. If two temperature sensors are connected to the Remote 1 channel, this is the mean temperature. The Remote 1 sensor readings are reported regardless of the Use/Omit/OD/Slab designation.
Reports the temperature reading of the Remote 2 temperature sensor, in tenths of a degree. The scale (Fahrenheit or Celsius) is based on the current setting in the unit. If two temperature sensors are connected to the Remote 2 channel, this is the mean temperature. The Remote 2 sensor readings are reported regardless of the Use/Omit/OD/Slab designation.
Continued on the following page
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 65
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slot 1- Heat/Cool Control Digital Joins - continued
SIGNAL I/O SIGNAL
DEFINITION
TYPE
Outdoor Temp Output Analog
Reports the temperature reading of any sensors set to "OD" (Outdoor) in tenths of a degree. The scale (Fahrenheit or Celsius) is based on the current setting in the unit. If more than one sensor is set to OD, this is the mean outdoor temperature. Sensors are manually set to Use, Omit, OD (Outdoor) or Slab via the setup menus on the thermostat.
Slot 2 Detail View – Humidity Control
66 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slot 2 – Humidity Control
SIGNAL I/O SIGNAL
DEFINITION
TYPE
HumiditySetpoint+
HumiditySetpoint-
HumidifierEnable Input Digital Enables the humidifier on the rising edge of the input.
HumidifierEnable_F Output Digital Indicates that the humidifier is enabled.
HumidifierOff Input Digital Turns off the humidifier on the rising edge of the input.
HumidifierOff_F Output Digital Indicates that the humidifier is off.
IndoorHumidityInput Input Analog
OutdoorHumidityInput Input Analog
HumiditySetpoint Input Analog Sets the humidity regulating setpoint in whole numbers.
HumiditySetpoint_F Output Analog Reports the humidity regulating setpoint.
RegulationHumidity Output Analog
LocalHumidity Output Analog
Remote1Humidity Output Analog
Input Digital
Raises (+) or lowers (-) the humidity regulating setpoint on the rising edge of the input. Continuing to assert the up or down inputs at the limits of the setpoint will not affect the setpoint. That is, the setpoint will hold at its maximum or minimum setting. High/1 (rising edge) = Humidity setpoint up or down; Low/0 = no effect
High/1 (rising edge) = Enable humidifier; Low/0 = no effect
High/1 = Humidifier ready to run; Low/0 = Humidifier not enabled
High/1 (rising edge) = Turn off humidifier; Low/0 = no effect
High/1 = Humidifier off; Low/0 = Humidifier enabled
Receives the indoor relative humidity from a sensor that is not connected to the thermostat, for display on the Main page of the thermostat LCD (CHV-THSTAT only).
This value is ignored if a humidity sensor (CHV-RTHS) is connected to the CHV-TSTAT.
Receives the outdoor relative humidity from a sensor that is not connected to the thermostat, for display on the Outdoor page of the thermostat LCD.
This value is ignored if an outdoor humidity sensor (CHV-RTHS) is connected to the thermostat.
Valid values range from 5 to 70.
The humidity setpoint will saturate in both directions. Thus sending 0 will set the humidity setpoint to 5, and sending 80 will set the humidity setpoint to 70.
Reports the mean (averaged) humidity reading of all internal and remote humidity sensors set to "Use", in whole numbers. Only active when a thermostat setup has humidity sensing capability, either by being a CHV-THSTAT or a CHV-TSTAT with humidity remote.
Humidity sensors are manually set to Use, Omit, or Outdoor via the setup menus on the thermostat.
Reports the relative humidity reading of the built-in humidity sensor (CHV-THSTAT only) in whole numbers.
The internal humidity sensor reading is reported regardless of the Use or Omit designation.
Reports the humidity reading of the Remote 1 humidity sensor in whole numbers.
The Remote 1 humidity reading is reported regardless of the Use/Omit/OD designation.
Continued on the following page
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 67
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slot 2 – Humidity Control (continued)
SIGNAL I/O SIGNAL
DEFINITION
TYPE
Remote2Humidity Output Analog
OutdoorHumidity Output Analog
Slot 3 Detail View – Slab Control
Reports the humidity reading of the Remote 2 humidity sensor in whole numbers.
The Remote 2 humidity sensor reading is reported regardless of the Use/Omit/OD designation.
Reports the humidity reading of any humidity sensor set to "OD" (Outdoor) in whole numbers.
If more than one humidity sensor is set to OD, this is the mean outdoor humidity.
Humidity sensors are manually set to Use, Omit, or Outdoor via the setup menus on the thermostat.
68 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slot 3 – Slab Control
SIGNAL I/O SIGNAL
DEFINITION
TYPE
Slab(min)Setpoint+
Slab(min)Setpoint-
FloorWarmSysModeHeat
FloorWarmSysModeOff
FloorWarmSysModeHeat_F
FloorWarmSysModeOff_F
SlabSetpoint Input Analog
SlabSetpoint_F Output Analog
SlabTemp Output Analog
Input Digital
Input Digital
Output Digital Reports the status of the floor-warming system.
Raises (+) or lowers (-) the slab regulating setpoint on the rising edge of the input.
The setpoint is adjusted in whole degrees Fahrenheit or Celsius, or half degrees Celsius if that option is selected. Thus if the analog value of the slab setpoint equals 700 (for 70°), a rising edge of <Slab(min)Setpoint+> will raise the slab setpoint value to 710 (for 71°). Similarly, if the analog value of the slab setpoint equals 200 (for 20°) and the half-degree Celsius option is selected, a rising edge of <Slab(min)Setpoint-> will lower the setpoint value to 195 (for 19.5°C).
Continuing to assert the up or down inputs at the limits of each setpoint will not affect the setpoint. That is, the setpoint will hold at its maximum or minimum setting.
High/1 (rising edge) = Slab setpoint up or down; Low/0 = no effect
Turns the floor-warming system on or off on the rising edge of the input.
High/1 (rising edge) = Turn floor-warming system On/Off; Low/0 = no effect
High/1 = Floor-warming system On/Off
Sets the slab regulating setpoint in tenths of a degree. The scale (Fahrenheit or Celsius) is based on the current setting in the unit.
The displayed setpoint value is rounded to whole degrees Fahrenheit or Celsius, or half-degrees Celsius if that option is enabled. This means that if the value 721 is presented on the slab setpoint input, the thermostat LCD will display a slab setpoint of 72°. Similarly, if the value 204 is presented on the slab setpoint input and the half-degree Celsius option is enabled, the thermostat LCD will display a slab setpoint of 20.5°.
Valid analog values range from 380 to 1210 (38° to 121°F); or 3 to 495 (3° to 49.5°C).
The setpoints will saturate in both directions. Thus sending 0 will set the setpoint to its minimum value, while sending 1300 will set the setpoint to its maximum value.
Reports the slab regulating setpoint in tenths of a degree. The scale (Fahrenheit or Celsius) is based on the current setting in the unit.
Reports the temperature reading of any remote sensor set to "Slab", in tenths of a degree. The scale (Fahrenheit or Celsius) is based on the current setting in the unit.
If more than one sensor is set to "Slab", this is the mean slab temperature.
Sensors are set to Use, Omit, OD (Outdoor) or Slab via the setup menus on the thermostat.
Continued on the following page
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 69
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slot 3 – Slab Control (continued)
SIGNAL I/O SIGNAL
DEFINITION
TYPE
MaxSlabTemp Output Analog
Slot 4 Detail View – Current System State
Reports the maximum slab temperature value. The scale (Fahrenheit or Celsius) is based on the current setting in the unit.
Values range from 390 to 1220 (39° to 122°F); or 44 to 500 (4° to 50°C).
This value is always at least one degree higher than the slab setpoint, but is disabled in floor-warming system types (Slab1, 5A/5B).
Slot 4 – Current System State
SIGNAL I/O SIGNAL
DEFINITION
TYPE
Heat1Call Output Digital
Heat2Call Output Digital
AuxHeatCall Output Digital
Cool1Call Output Digital
Continued on the following page
Goes high when the system calls for heat or stage 1 heat. Remains high for as long as the heat system is running.
High/1 = Heat/Stage 1 heat running; Low/0 = System not running
Goes high when the system calls for stage 2 heat. Remains high for as long as the heat system is running.
High/1 = Stage 2 heat running; Low/0 = System not running
Goes high when the system calls for auxiliary heat. Remains high for as long as the emergency heat system is running.
High/1 = Aux heat running; Low/0 = System not running
Goes high when the system calls for cool or stage 1 cool. Remains high for as long as the cool system is running.
High/1 = Cool/Stage 1 cool running; Low/0 = System not running
70 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slot 4 – Current System State (continued)
SIGNAL I/O SIGNAL
DEFINITION
TYPE
Cool2Call Output Digital
FanCall Output Digital
HumidifierCall Output Digital
SlabHeatCall Output Digital
Slot 5 Detail View – Display Functions
Goes high when the system calls for stage 2 cool. Remains high for as long as the cool system is running.
High/1 = Stage 2 cool running; Low/0 = System not running
Goes high when the fan is running for any reason. Remains high for as long as the fan is running.
High/1 = Fan running; Low/0 = System not running
Goes high when the system calls for humidification. Remains high for as long as the humidifier is running.
High/1 = Humidifier running; Low/0 = System not running
Goes high when the system calls for slab heat. Remains high for as long as the slab system is running.
High/1 = Slab heat running; Low/0 = System not running
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 71
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slot 5 – Display Functions
SIGNAL I/O SIGNAL
DEFINITION
TYPE
MsgIconOn Input Digital
FrontPanelLockout Input Digital
RunBacklight Input Digital
HoldOn Input Digital
HoldOff Input Digital
Alternately flashes the text "View Msg" with "Online/Hold, Net Fault" on the Main page of the thermostat LCD, for as long as the input remains high. This alerts the user to check for a displayed message on the Messages page of the thermostat LCD.
High/1 = Flash message icon; Low/0 = No message icon
Locks out the four hard pushbuttons on the thermostat for as long as the input remains high. In this mode, pressing the buttons will have no effect. Automatically disabled in case of system error or failure.
High/1 = Lock out buttons; Low/0 = Enable button operation
Turns on the thermostat's backlight for eight seconds on the rising edge of the input.
High/1 (rising edge) = Turn on backlight; Low/0 = no effect
Turns on the Hold function on the rising edge of the input.
When "on hold", data flows one way, from the thermostat to Cresnet. All Cresnet commands to the thermostat are blocked except for the Hold Off command. While the thermostat is on hold it buffers all setpoint and mode changes (except for up/down inputs). The setpoints and mode inputs will take effect immediately when the hold is released.
High/1 (rising edge) = Enable Hold mode; Low/0 = no effect
Turns off the Hold function, on the rising edge of the input.
In this mode, the thermostat is put back online and data flows freely between the Cresnet network and the thermostat. While the thermostat is "on hold" it buffers all setpoint and mode changes (except for up/down inputs). The setpoints and mode inputs will take effect immediately when the hold is released.
High/1 (rising edge) = Restore Cresnet communication and buffered settings; Low/1 = no effect
MsgField Input Serial
BtnLabel1 Input Serial
BtnLabel2 Input Serial
Sends text string to the Messages page of the thermostat LCD.
Displayed text is limited to approximately 20 characters per line (including spaces) to a maximum of four lines. The thermostat supports word wrap and auto-hyphenation within the 20 characters/spaces per line maximum. (Carriage returns will force a line change.)
Sends text label for display next to the Remote Function Button 1 (Up pushbutton) on Remote Page 1 of the thermostat LCD.
The thermostat LCD provides two Remote pages in which the Up and Down pushbuttons operate as remote function buttons. In this mode the buttons can trigger non-HVAC functions such as AV control, lighting, or alarm activation.
Sends text label for display next to the Remote Function Button 2 (Down pushbutton) on Remote Page 1 of the thermostat LCD.
The thermostat LCD provides two Remote pages in which the Up and Down pushbuttons operate as remote function buttons. In this mode the buttons can trigger non-HVAC functions such as AV control, lighting, or alarm activation.
Continued on the following page
72 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slot 5 – Display Functions (continued)
SIGNAL I/O SIGNAL
DEFINITION
TYPE
BtnLabel3 Input Serial
BtnLabel4 Input Serial
GlobalPress Output Digital
Offline(HOLD) Output Digital
RemoteBtn1_Press Output Digital
RemoteBtn2_Press Output Digital
RemoteBtn3_Press Output Digital
Sends text label for display next to the Remote Function Button 3 (Up pushbutton) on Remote Page 2 of the thermostat LCD.
The thermostat LCD provides two Remote pages in which the Up and Down pushbuttons operate as remote function buttons. In this mode the buttons can trigger non-HVAC functions such as AV control, lighting, or alarm activation.
Sends text label for display next to the Remote Function Button 4 (Down pushbutton) on Remote Page 2 of the thermostat LCD.
The thermostat LCD provides two Remote pages in which the Up and Down pushbuttons operate as remote function buttons. In this mode the buttons can trigger non-HVAC functions such as AV control, lighting, or alarm activation.
Briefly pulses high whenever the Send button of the Global Update page is pressed.
This signal can be tied to logic in the program to trigger functions such as global updates of temperature or humidity values.
Indicates that the thermostat has been taken offline. In this mode, the thermostat is "on hold" and data flows one way, from the thermostat to Cresnet. All Cresnet commands to the thermostat are blocked except for the Hold Off command. While the thermostat is "on hold" it buffers all setpoint and mode changes (except for up/down inputs). The setpoints and mode inputs will take effect immediately when the hold is released.
Remains high for as long as the thermostat is offline.
High/1 = Offline; Low/0 = Online
Indicates that Remote Function Button 1 (Up pushbutton) has been pressed on Remote Page 1 of the thermostat LCD. Remains high for as long as the button is pressed.
The thermostat LCD provides two Remote pages in which the Up and Down pushbuttons operate as remote function buttons. In this mode the buttons can trigger non-HVAC "remote" functions such as AV control, lighting, or alarm activation.
Indicates that Remote Function Button 2 (Down pushbutton) has been pressed on Remote Page 1 of the thermostat LCD. Remains high for as long as the button is pressed.
The thermostat LCD provides two Remote pages in which the Up and Down pushbuttons operate as remote function buttons. In this mode the buttons can trigger non-HVAC "remote" functions such as AV control, lighting, or alarm activation.
Indicates that Remote Function Button 3 (Up pushbutton) has been pressed on Remote Page 2 of the thermostat LCD. Remains high for as long as the button is pressed.
The thermostat LCD provides two Remote pages in which the Up and Down pushbuttons operate as remote function buttons. In this mode the buttons can trigger non-HVAC "remote" functions such as AV control, lighting, or alarm activation.
Continued on the following page
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 73
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slot 5 – Display Functions (continued)
SIGNAL I/O SIGNAL
DEFINITION
TYPE
RemoteBtn4_Press Output Digital
MsgWaiting Output Digital
Indicates that Remote Function Button 4 (Down pushbutton) has been pressed on Remote page 2 of the thermostat LCD. Remains high for as long as the button is pressed.
The thermostat LCD provides two Remote pages in which the Up and Down pushbuttons operate as remote function buttons. In this mode the buttons can trigger non-HVAC "remote" functions such as AV control, lighting, or alarm activation.
Indicates that text has been sent to the Messages page of the thermostat LCD, via the <MsgField> input.
Remains high until the user presses the Clear button on the Messages page.
74 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slot 6 Detail View – System Configuration
Continued on following page
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 75
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slot 6 Detail View – System Configuration (continued)
76 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slot 6 – System Configuration
SIGNAL I/O SIGNAL
DEFINITION
TYPE
HeatCoolType
HeatPumpType
Slab1Type
Slab2Type
Slab3Type
Slab4AType
Slab4BType
Slab5AType
Slab5BType
RadiantSubtype
ForcedAirSubtype
DualFuelSubtype
CoolStages1
CoolStages2
HeatStages1
HeatStages2
DualSetpoints(AutoMode) Output Digital
NoAutoMode Output Digital
WideRangeCool Output Digital
RunFan(HeatCalls) Output Digital
Output Digital
Output Digital
Output Digital
Indicates the heat/cool or slab system type that has been selected. Remains high for as long as the corresponding system is selected.
The thermostats support single-stage and multi-stage heating and cooling systems, including conventional fossil fuel systems, heat pumps with auxiliary heat and slab heating systems.
High/1 = System selected; Low/0 = System not selected
Indicates the subtype for heating/cooling systems. Remains high for as long as the corresponding subtype is selected.
Radiant heating turns large areas (floor, walls, ceilings) into large surface radiators.
Forced air is a type of heating system that uses a blower motor to move air through the furnace and into the ductwork.
In dual-fuel setups, the auxiliary heat output runs in place of the heat pump in cold weather.
High/1 = Subtype selected; Low/0 = Subtype not selected
Indicates how many stages of cooling or heating there are in the system.
High/1 = One or two-stage system; Low/0 = System type not selected
Indicates that dual-point auto mode has been enabled. Remains high for as long as the mode is enabled.
High/1 = Dual-point auto mode enabled; Low/0 = Not enabled
Reports whether Auto Mode is permitted in the system. If enabled, the thermostat will not display Auto on the System Mode screen and will not permit the thermostat to enter the auto mode even from Cresnet commands.
High/1 = No Auto Mode; Low/0 = Auto Mode permitted
Indicates that wide range cool mode has been enabled. Remains high for as long as the mode is enabled.
Wide range cool extends the cool setpoint range to the full auto range of 38° to 99°F, or 3° to 37°C. This is suitable for wine cellars or other colder chilling processes.
High/1 = Wide range cool enabled; Low/0 = Not enabled
Indicates that Run Fan in Heat Calls has been enabled. Remains high for as long as the mode is enabled.
Run Fan in Heat Calls is a device setting that activates the fan output with W1/W2 heat calls. Does not enable operation on slab systems on the slab (W1) call.
High/1 = Run Fan in Heat Calls enabled; Low/0 = Not enabled
Continued on the following page
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 77
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slot 6 – System Configuration (continued)
SIGNAL I/O SIGNAL
DEFINITION
TYPE
ColdWeatherComp Output Digital
DispGlobalPage Output Digital
DispOutdoorPage Output Digital
DispRemoteBtnPage1
DispRemoteBtnPage2
DispHumidityModePage Output Digital
DispHumidityViewPage Output Digital
Temp(DegF)
Temp(DegC)
0.5_Steps Output Digital
MainScrnOb_NA
MainScrnOb_Outdoor
MainScrnOb_Humidity
MainScrnOb_SlabTemp
RevSmodeDir Output Digital
Output Digital
Output Digital Indicates the temperature scale: Fahrenheit or Celsius.
Output Digital
Indicates that cold weather compensation has been enabled. Remains high for as long as the mode is enabled.
Outdoor low-temperature compensation modifies the humidifier output to prevent condensation on windows in cold weather.
High/1 = Cold weather compensation enabled; Low/0 = Not enabled
Indicates that the Global page (consisting of the Global Send button) has been enabled for display on the thermostat LCD. Remains high for as long as the page is enabled.
High/1 = Global page enabled; Low/0 = Not enabled
Indicates that the Outdoor page has been enabled for display on the thermostat LCD. Remains high for as long as the page is enabled.
The Outdoor Page displays the temperature and relative humidity readings of outdoor sensors.
High/1 = Outdoor page enabled; Low/0 = Not enabled
Indicates that Remote page 1 or 2 has been enabled for display. Remains high for as long as the page is enabled.
The thermostats provide two Remote pages that can be used to trigger non-HVAC functions such as AV control, lighting, or alarm activation.
High/1 = Remote page enabled; Low/0 = Not enabled
Indicates that the Humidity Mode page has been enabled for display on the thermostat LCD. Remains high for as long as the page is enabled.
The Humidity Mode page allows the user to enable or disable the humidifier.
High/1 = Humidity Mode page enabled; Low/0 = Not enabled
Indicates that the Humidity View page has been enabled for display on the thermostat LCD. Remains high for as long as the page is enabled.
The Humidity View Page displays the relative humidity and setpoint values.
High/1 = Humidity View page enabled; Low/0 = Not enabled
Indicates that the temperature in Celsius will be displayed in half degrees if Celsius was selected.
Reports the reading that will be displayed under the current temperature on the Main page of the thermostat LCD.
The "Main screen object" can be outdoor temperature, slab temperature, indoor humidity, or none (NA).
Reverses the direction that the selection box moves for mode screens.
High/1 = Up arrow moves box to left; Low/0 = Moves box to right
Continued on the following page
78 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slot 6 – System Configuration (continued)
SIGNAL I/O SIGNAL
DEFINITION
TYPE
UseLocalTemp
UseLocalHumidity
OmitLocalTemp
OmitLocalHumidity
UseRem1Temp
UseRem1Humidity
OmitRem1Temp
OmitRem1Humidity
ODRem1Temp
ODRem1Humidity
SlabRem1Temp
UseRem2Temp
UseRem2Humidity
OmitRem2Temp
OmitRem2Humidity
ODRem2Temp
ODRem2Humidity
SlabRem2Temp
Output Digital Reports the designator assigned to the local (internal) sensors.
The CHV-TSTAT provides one internal temperature sensor; the CHV-THSTAT provides internal sensors for temperature and humidity. Each sensor must be designated as Use or Omit.
Readings from local and remote sensors that have the same designator are averaged together. Thus two temperature sensors set to Use are averaged for the air temperature control, while two humidity sensors set to Use are averaged to determine the humidity.
A sensor designated as “Omit” signifies that the reading will not be included in such averaging.
Output Digital
Reports the designator assigned to the remote sensors. The CHV-TSTAT and CHV-THSTAT provide two remote channels. Each channel supports two sensors, for a maximum of four remote sensors. Crestron manufacturers three sensor models:
CHV-RTS: temperature sensor CHV-RTHS: dual temperature/humidity sensor CHV-RSS: slab sensor
Each sensor must be designated as Use, Omit, OD (Outdoor) or Slab.
Readings from local and remote sensors that have the same designator are averaged together. Thus two sensors set to Use are averaged for the air temperature control, while two OD readings are averaged to determine the outdoor temperature, and two Slab readings are averaged for the floor temperature.
A sensor designated as "Omit" signifies that the reading will not be included in such averaging.
Reg_Temp_Invalid
OD_Temp_Invalid
Slab_Temp_Invalid
Local_Temp_Invalid
Rem1_Temp_Invalid
Rem2_Temp_Invalid
Reg_Hum_Invalid
OD_Hum_Invalid
Local_Hum_Invalid
Rem1_Hum_Invalid
Rem2_Hum_Invalid
HeatAnticipator
CoolAnticipator
Output Digital
Output Analog
Continued on the following page
These outputs show the state of the temperature or humidity measurement for their corresponding source. If the signal is high (1) then the value on the corresponding analog output should be considered invalid. This can happen due to unconnected sensors, communications problems, or other error conditions. If the signal is low (0), the corresponding analog value is assumed to be correct.
Reports the heat and cool anticipator values, from 1 to 6. Prevents overshooting the set temperature.
A lower number signifies more frequent cycles and faster response (tighter regulation), while a higher number signifies less frequent cycles and slower response (looser regulation).
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 79
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slot 6 – System Configuration (continued)
SIGNAL I/O SIGNAL
DEFINITION
TYPE
InterstageDifferential
HP_BalancePoint
AUX_BalancePoint
LCD_Contrast Output Analog Reports the LCD screen contrast.
TempDispOffset Output Analog
AutoDeadband Output Analog
SlabRegulation Output Analog
Output Analog
Output Analog
Reports the interstage differential in tenths of a degree. This is the proportional temperature error to trigger the second (Auxiliary) stage. The scale (Fahrenheit or Celsius) is based on the current setting in the unit.
Values range from 0.5 to 8.0 (5°F to 30°F); or 0.25 to 4.5 (3° to
4.5°C).
Reports the heat pump balance point and auxiliary balance point in tenths of a degree. The scale (Fahrenheit or Celsius) is based on the current setting in the unit.
HP values range from 0 to 890 (0 to 89 ˚F); 0r –180 to +310 (-18˚C to 31˚C).
The heat pump balance point is the outdoor temperature below which heat pump operation is locked out, and auxiliary heat runs in place of it.
The auxiliary balance point is the outdoor temperature above which auxiliary heat is locked out. Aux values range from 0 to 900 (0˚to 90˚F); or –170 to +320 (-17˚C to 32˚C).
Values range from 1 (lightest) to 10 (darkest).
Reports the temperature offset in tenths of a degree. The offset is the number of degrees added or subtracted from the actual sensed temperature. The scale (Fahrenheit or Celsius) is based on the current setting in the unit.
Values are as follows:
Fahrenheit: -60 to +60 (-6˚ to +6˚F) Celsius: -30 to +30 (-3.0˚to +3.0˚C)
This temperature offset changes the actual regulated temperature, not just the displayed temperature. The offset is set to “0” as shipped from the factory.
Reports the auto mode deadband value in tenths of a degree. The scale (Fahrenheit or Celsius) is based on the current setting in the unit.
Values are as follows:
Fahrenheit: 20 to 60 (2˚ to 6˚F)
Celsius: 10 to 30 (1˚ to 3˚C)
Half degrees Celsius mode: 10 to 35 (1˚ to 3.5˚C)
The deadband sets the minimum separation in auto mode between the heat and cool setpoints, or the changeover band in single point auto mode.
Reports the slab temperature regulation value. Values range from 1 to 6.
A lower number signifies more frequent cycles and faster response (tighter regulation), while a higher number signifies less frequent cycles and slower response (looser regulation).
Example Programs
The example program for the thermostat is available from the Crestron FTP site (ftp://ftp.crestron.com/Examples). Search for CHV-THSTAT_with_5­2_Scheduler_Sample_Program.zip.
80 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Viewport ID String

Using the Diagnostics | Report Network Devices (F4) command in Viewport, the thermostats output a string of characters that describe the setup and configuration of the thermostat. Refer to the following table for an explanation of this string. A semicolon separates each element of the setup string. Strings are contained within parenthesis, and follow one space after the PPN in the ID string. Refer to the following two examples of ID strings.
Example 1:
- SLAB 4B system with aux heat (SB4B-AX;)
- Slab max is 50C (SMX50;)
- Interstage differential is 2.0C (ID2.0;)
- Balance points are -10C, 0C, offset of 0C (HBP-10; ABP0; OS0.0;)
- Auto dead band 2C (ADB2.0;)
- Half C units (C05;)
2A: CHV-THSTATA [v2.0, #D8000000] (SB4B-AX;H1;C1;HA2;CA2;SMX50;ID2.0; HBP-10;ABP0;OS0.0;ADB2.0;DA;C05;OUSOOO;SETUP)
Example 2:
- SLAB 1 system with slab regulation index 3 (SB1;SRG3;)
- Offset of 0C (OS0.0;)
- Half C units (C05;)
2B: CHV-THSTATA [v2.0, #D8000000] (SB1;SRG3;OS0.0;C05;OUSOOO;SETUP)
Refer to the following chart for ID string definitions.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 81
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
ID Strings Description
FUNCTION OPTIONS DESCRIPTION
System Type H/C, HP, SB1,
SB2, SB3, SB4A, SB4B, SB5A, SB5B
System Type Suffix RD
FA
DF
AX
Heat Stages H1, H2 Number of heating stages, 1 or 2
Cool Stages C1, C2 Number of cooling stages, 1 or 2
Heat Anticipator HA1 - HA6 Heat anticipator setting, from 1-6
Cool Anticipator CA1 - CA6 Cooling anticipator setting, from 1 - 6
Slab Temperature Max SMX Maximum slab temperature for Slab2, Slab3, Slab4A ,and Slab4B types
Regulation Index SRG Floor warming regulation index for Slab1, Slab3, Slab5A, and Slab5B
Interstage Differential ID Differential for multistage heat/cool, heat pump, Slab4A, and Slab4B
Heat Pump Balance Point HBP Balance point for heat pump, Slab4B, and Slab 5B types followed by a
Aux Balance Point ABP Balance point for heatpump, Slab4B, and Slab5B types followed by a
Offset Temperature OS Offset temperature display value, followed by a number from -6 to 6
Auto Deadband ADB Minimum separation between heat and cool setpoints in auto mode,
Temperature Unit F
C10
C05
Sensor Usage Flags U, D, O Indicates the status of each sensor input: Use, outDoor, or Omit, sensor
Heat/cool, heat pump, or slab system
Radiant
Forced Air
Heat pump with Dual Fuel
Heat pump with Auxiliary
followed by a number (example: SMX100)
types followed by a number (example: SRG4)
types followed by a number (example: ID1.0)
number (example: HBP-10)
number (example: ABP70)
degrees (Example: OS-1)
degrees, 2 – 6, for systems containing cooling only (Example: ADB3)
Fahrenheit
Celsius whole units
Celsius half units
series is as follows:
Built-in-temp; built-humidity; remote 1 temp; remote1 hum; remote 2 temp; remote 2 hum.
NOTE: Depending on system type, not all of the ID String options listed above will be present.
NOTE: If you are in setup, the word SETUP appears in the string after the list of sensors.
NOTE: If you have restored a version 1.0 or 1.1 setup in this power cycle, an R appears after the word SETUP.
82 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Viewport Error Log Message Formats

When a remote sensor that has been designated as USE, SLAB, or OD in the Setup Sensors screen generates an error, a message is sent to the error log. Retrieve this message using Viewport, Function | 2-Series | Error Log | Show Error Log.
Error Message Format
Sensor <channel> type <designator> <CHA errors>, <CHB errors> Errors @ <cycle count>
Where:
channel is the sensor channel string designator is the sensor setup designation CHA errors/CHB errors are the number of errors on each sub-channel cycle count is the number of read cycles that have occurred.
NOTE: Both sub-channels have their error count reported, regardless of the sensors connected.
This message is sent upon the first error on the channel, as well as every 100 errors thereafter. The following is an example output, as seen in Viewport, when a single OD sensor on channel one fails.
Error: Message from device Slot-09.ID-2A: Sensor R1T type OD: 2,3 Errors @ 3922 (0056:0000:0056)
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 83
Thermostats Crestron CHV-TSTAT and CHV-THSTAT

Local Error Messages

When a critical sensor fails and prevents the safe or intended operation of the HVAC equipment, an error message flashes on the main screen.
This error message appears as a text message under the line that normally reads ON LINE and VIEW MSG. The thermostat messages are shown as follows in descending priority.
ERROR DESCRIPTION
ERR! NO AT SRC
ERR! NO SB SRC
ERR! NO HM SRC
ERR! NO OD SRC
Indicates that no air temperature source is present, because all available sensors designated USE have generated errors during the current read cycle. HVAC operation is suspended and relays are cleared, except on SLAB1 type. SLAB1 type cannot generate this error because it does not have an air temperature USE type.
Indicates that no slab temperature source is present, because all available sensors designated SLAB have generated errors during the current read cycle. HVAC operation is suspended on all slab modes (1, 2, 3, 4A, 4B, 5A, 5B).
Indicates that no humidity sources are present, because all available sensors designated USE have generated errors during the current read cycle. Humidifier operation is suspended and HUM relay is cleared.
Indicates that no outdoor source is present and the setup says at least one remote is supposed to be providing OD data (designated OD). This error does not disable HVAC operation because it is not absolutely essential. All heatpump modes that use outdoor temperature for balance point operation will eventually stage or switch to auxiliary heat and thus prevent the space from freezing.
NOTE: All of these conditions are self-healing if the sensor begins sending valid data.
84 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Problem Solving

Troubleshooting

The table below provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative.
CHV-TSTAT/CHV-THSTAT Troubleshooting
TROUBLE POSSIBLE
CAUSE(S)
No display
Heating/Cooling system not operating
Cannot change temperature setting
System cycles too quickly
High temperature variance
No power from system
Incorrect mounting to backplate
No power to thermostat
Flashing system indicator - Short cycle timer not satisfied
The upper or lower temperature limits were reached
Anticipator/Regulation setting too low
Anticipator/Regulation setting too high
CORRECTIVE ACTION
Check for +24V on pins 24(C) and 24(R)
Check circuit breaker powering furnace or boiler
Check P4 jumper on thermostat board
Check thermostat wiring
Check thermostat mounting
Check circuit breaker
Check 24V connection at thermostat and at furnace/air conditioner
Check circuit breaker powering furnace or boiler
Recheck wiring connections
Timer Guards are a safety feature that prevents rapid switching between different cycles H1, H2, C1, C2, SB, HM, and AX flash when the three­minute timer guards have not been satisfied Wait five minutes and/or consult HVAC contractor
Setpoint heat range is 38 – 90º F (3-38º C)
Setpoint cool range is 59-100º F (15 – 38º C)
Reprogram anticipator/regulator setting Refer to “Thermostat Setup”
Troubleshooting continued on following page
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 85
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Troubleshooting continued
TROUBLE POSSIBLE
CAUSE(S)
Wide temperature variance in single­setpoint auto mode
Heating/Cooling not operating in single­setpoint auto mode
Displays Error Message and equipment not operating
Wrong temperature displayed
Displays “NetDown”
Cannot leave setup
Cannot enter Auto mode
Cresnet Balance Point values out of range
Reports CHV-THSTATA or CHV-TSTATA in Viewport
Temperature offset value not affecting Cresnet outputs
Cannot change screens or setpoints
Auto deadband setting too high
20-minute system toggling lockout
Temperature sensors are disabled or have failed
Bad communications
Wrong units Select F or C as necessary
Incorrect sensor setup
Temperature Offset
Bad location
No Crestron program or the program does not have a device at this net address included in this system
Sensor configuration not valid
Auto mode disabled in setup
Values of -1, 91F represent "Off" settings
Running firmware version 2.x or higher
Offset is only added to "RegulationTemp"
Local operation locked out
CORRECTIVE ACTION
Adjust auto deadband setting in setup
Adjust auto deadband and anticipator settings for smoother operation
Refer to “Local Error Messages” on page 84
Check wiring – Use low capacitance twisted-pair wiring
Check sensor setup
Reset Temperature Offset
Ensure that thermostat is located out of direct sunlight, drafts, doorways, skylights, and windows
Check ID in program
Fix program, if one is needed
Ensure sensor setup meets system requirements. Refer to Sensor Setup screen
Select “N” for the Disable Auto Mode item on the “Other Settings” setup page
Verify intended balance point settings
None (name adjustment was required for SIMPL Windows)
Add offset in SIMPL program
Remove lockout from network
86 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Further Inquiries

If after reviewing this Operations and Installation Guide, you cannot locate specific information or have questions, please take advantage of Crestron's award winning customer service team by calling:
In the US and Canada, call Crestron’s corporate headquarters at 1-888-CRESTRON [1-888-273-7876].
In Europe, call Crestron International at +32-15-50-99-50.
In Asia, call Crestron Asia at +852-2341-2016.
In Latin America, call Crestron Latin America at +5255-5093-2160.
In Australia and New Zealand, call Creston Pacific at +613-9480-2999
You can also log onto the online help section of the Crestron website (www.crestron.com) to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features.

Firmware Upgrades

To take advantage of all the features, it is important that the unit contains the latest firmware available. Therefore, please check Crestron’s website (http://www.crestron.com/downloads/software_updates.asp) for the latest version of firmware. Not every product has a firmware upgrade, but as Crestron improves functions, adds new features, and extends the capabilities of its products, firmware upgrades are posted. If you have questions regarding upgrades procedures, contact Crestron customer service.
NOTE: Firmware version 2.40 is not compatible with SIMPL Windows programs that have used firmware version 1.1 and earlier.

Future Updates

As Crestron improves functions, adds new features, and extends the capabilities of this product, additional information may be made available as manual updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision.
Check the Crestron website (www.crestron.com availability and its relevance. Updates are available from the Download | Product Manuals section and are identified as an “Addendum” in the Download column.
) periodically for manual update
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 87
Thermostats Crestron CHV-TSTAT and CHV-THSTAT

Appendix A: Glossary

Anticipators – Used to anticipate the drop or rise in temperature and energize the
appropriate system before reaching the set point.
Auto Dead Band Degree (Auto DdBand Deg) – Sets the minimum separation in
auto mode between the heat and cool setpoints, or the changeover band in 1-point auto mode.
Balance Point – The lowest outdoor temperature at which the refrigeration cycle of
a heat pump will supply the heating requirements without the aid of a supplementary heat source.
Blower (Fan) – An air-handling device for moving air in a distribution system.
BTU - British Thermal Unit – In scientific terms, it represents the amount of
energy required to raise one pound of water one degree Fahrenheit. One BTU is the equivalent of the heat given off by a single wooden kitchen match.
Call – A call is when the thermostat requests the heating or cooling system to turn
on.
Damper – Found in ductwork, this movable plate opens and closes to control
airflow. Dampers are used effectively in zoning to regulate airflow to certain rooms.
Dead Band – The minimal differential between Heating and Cooling.
Dual Fuel – A heat pump used in conjunction with an existing furnace.
Dual Setpoint Auto – Enables the two-point auto mode.
Emergency Heat (Supplementary Electric Heat) – The auxiliary (AUX) or
emergency heat provided at temperatures below a heat pump's balance point. It is usually electrical resistance heat.
Forced Air – A type of heating system that uses a blower motor to move air through
the furnace and into the ductwork.
Furnace – Equipment used to convert heating energy, such as fuel, oil, gas or
electricity, to usable heat. It usually contains a heat exchanger, a blower and the controls to operate the system.
Heat Exchanger – A device for the transfer of heat energy from the source to the
conveying medium of air or water. Most common combinations are: Refrigerant to air or Refrigerant to water (DX), Water to air (hydronic), Steam to air, Steam to water.
Heat Pump – A unit that both cools and heats. A heat pump system can be either a
split system or a packaged system. A heat pump can be used in conjunction with a gas/oil/LP furnace (using the furnace instead of electric resistance heat when temperatures fall below about 35º F).
Humidity – The total amount of moisture in air. Relative humidity (RH) is the
amount of moisture in air, relative to its total capability based upon its temperature (dewpoint). Moisture will condense on surfaces that are below this dewpoint.
HVAC – Heating, ventilation and air conditioning.
Interstage Differential – The proportional temperature error (0.5 to 3.0º) to trigger
the second stage (2-stage only).
88 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Main Screen Lower Object (Main Screen Lwr Obj) – Selects the data item
displayed at the bottom of the main screen. Choice of: none, slab temperature, outdoor temperature, or indoor humidity.
Run Fan in Heat Calls (Run Fan in Ht Calls) –A device setting that activates the
fan output with W1/W2 heat calls. Does not enable operation on slab systems on the slab (W1) call.
Setpoint – The thermostat temperature set to begin heating or cooling.
Time Delay (Timer Guards) – Refers to a safety device or circuit that will not allow
restart for three minutes.
Two Stage Heating –The heating unit starts out running in its first stage, and
operates at a fraction of its capacity. When the temperature outside goes very low, the system adjusts to full capacity (second stage) to meet the demand.
Wide Range Cool – Extends the cool setpoint range to the full auto range of 38 to
99°F.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 89
Thermostats Crestron CHV-TSTAT and CHV-THSTAT

Appendix B: About Heat Pumps

A heat pump extracts available heat from one area and transfers it to another. Even cold air contains some heat, and heat pumps can extract heat from the outside air on a cold day and transfer it indoors to maintain a comfortable temperature. A heat pump also works in reverse during the summer, extracting heat from indoors and transferring it outdoors.
In the heating mode, the efficiency of a heat pump decreases as the outdoor air temperature decreases.
Heat Pump Operation
Heat flows naturally from a warm area to a cooler area, and the heat pump takes advantage of this principle. The heat pump essentially consists of a compressor, an inside coil and fan, and an outside coil and fan. A refrigerant flows inside the coils, under pressure applied by the compressor.
The refrigerant boils at a very low temperature (as low as -15° F) and becomes a vapor, just as water becomes a vapor (steam) when boiled. This vapor is sucked into the compressor where it becomes a high pressure, high temperature vapor.
When heating, the refrigerant is then forced through a coil within part of the heat pump located indoors. A fan blows cool air over the coil, the vapor cools, turns back to a liquid, releasing heat that is blown through a duct system to heat the house.
The cycle begins again as the cooled liquid refrigerant is pumped back outside after releasing it’s heat. On the way, it passes through an expansion valve, lowering the refrigerant's pressure and temperature again so it can boil more easily in the outdoor coil.
In its cooling mode the heat pump system works in reverse, extracting available heat from indoors and transferring it outside.
Heat pumps are most economical when they can be used year-round for both winter heating and summer cooling.
The efficiency of a heat pump varies significantly with the outdoor temperature. While a heat pump may be twice as efficient as a conventional heating system at 50°F. When the outdoor temperature drops to less than 30°F, the heat pump must be supplemented with an auxiliary heating system such as electric resistance. At temperatures of 15°F or less the heat pump may shut off and the backup heating system takes over. This is the heat pump balance point. In a dual-fuel system, the heat pump is supplemented with a standard furnace, which takes over when it becomes more efficient than the heat pump at very low temperatures.
90 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats

Return and Warranty Policies

Merchandise Returns / Repair Service

1. No merchandise may be returned for credit, exchange, or service without prior authorization from CRESTRON. To obtain warranty service for CRESTRON products, contact the factory and request an RMA (Return Merchandise Authorization) number. Enclose a note specifying the nature of the problem, name and phone number of contact person, RMA number, and return address.
2. Products may be returned for credit, exchange, or service with a CRESTRON Return Merchandise Authorization (RMA) number. Authorized returns must be shipped freight prepaid to CRESTRON, 6 Volvo Drive, Rockleigh, N.J. 07647, or its authorized subsidiaries, with RMA number clearly marked on the outside of all cartons. Shipments arriving freight collect or without an RMA number shall be subject to refusal. CRESTRON reserves the right in its sole and absolute discretion to charge a 15% restocking fee, plus shipping costs, on any products returned with an RMA.
3. Return freight charges following repair of items under warranty shall be paid by CRESTRON, shipping by standard ground carrier. In the event repairs are found to be non-warranty, return freight costs shall be paid by the purchaser.

CRESTRON Limited Warranty

CRESTRON ELECTRONICS, Inc. warrants its products to be free from manufacturing defects in materials and workmanship under normal use for a period of three (3) years from the date of purchase from CRESTRON, with the following exceptions: disk drives and any other moving or rotating mechanical parts, pan/tilt heads and power supplies are covered for a period of one (1) year; touchscreen display and overlay components are covered for 90 days; batteries and incandescent lamps are not covered.
This warranty extends to products purchased directly from CRESTRON or an authorized CRESTRON dealer. Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any.
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. Furthermore, this warranty does not cover any product that has had the serial number altered, defaced, or removed.
This warranty shall be the sole and exclusive remedy to the original purchaser. In no event shall CRESTRON be liable for incidental or consequential damages of any kind (property or economic damages inclusive) arising from the sale or use of this equipment. CRESTRON is not liable for any claim made by a third party or made by the purchaser for a third party.
CRESTRON shall, at its option, repair or replace any product found defective, without charge for parts or labor. Repaired or replaced equipment and parts supplied under this warranty shall be covered only by the unexpired portion of the warranty.
Except as expressly set forth in this warranty, CRESTRON makes no other warranties, expressed or implied, nor authorizes any other party to offer any warranty, including any implied warranties of merchantability or fitness for a particular purpose. Any implied warranties that may be imposed by law are limited to the terms of this limited warranty. This warranty statement supercedes all previous warranties.
Trademark Information
All brand names, product names, and trademarks are the sole property of their respective owners. Windows is a registered trademark of Microsoft Corporation. Windows95/98/Me/XP and WindowsNT/2000 are trademarks of Microsoft Corporation.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 91
Thermostats Crestron CHV-TSTAT and CHV-THSTAT
This page intentionally left blank.
92 Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
Crestron CHV-TSTAT and CHV-THSTAT Thermostats
This page intentionally left blank.
Operations and Installation Guide – DOC. 8163C Thermostats: CHV-TSTAT and CHV-THSTAT 93
Crestron Electronics, Inc. Operations and Installation Guide – DOC. 8163C
15 Volvo Drive Rockleigh, NJ 07647 08.04 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
Loading...
