Crestron BB-1550CW Wall Mount Back Box for SmarTouch
Contents
Wall Mount Back Box for STX-1550CW: BB-1550CW 1
Description 1
Installation 2
Installation During Construction 2
Installation After Construction 5
Further Inquiries 9
Future Updates 9
Appendix: Cutout Detail of Supplied Template 10
Return and Warranty Policies 11
Merchandise Returns / Repair Service 11
CRESTRON Limited Warranty 11
Installation Guide - DOC. 5848 Contents •• i
Crestron BB-1550CW Wall Mount Back Box for STX-1550CW
Metal, Bracket, Mounting Support
MTBK02578-1
1
Screw, 6-32, ¼ “L Steel
SR06-32-0R2500-2
8
Washer, Flat, Steel, B Regular
WA06FL-2
8
Overlay, Template, Wall Cutout
OV40053-1
1
Wall Mount Back Box for
STX-1550CW: BB-1550CW
Description
The BB-1550CW back box is wall-mounted hardware that is used to secure the
DA-1550CW docking assembly (sold separately). When used with the BB-1550CW,
the docking assembly provides operating power, hard-wire communications with
standard Crestron remote control system (herein referred to as the Cresnet system),
and recharges the Crestron High Performance Rechargeable Power Pack (ST-BTP)
of a Crestron SmarTouch STX-1550CW compact color touchpanel.
Supplied Components
DESCRIPTION PART NUMBERS QUANTITY
Metal, Enclosure MTEN02571-1 1
Metal, Bracket, Mounting MTBK02577-1 1
A diagram of the two installation brackets is shown below and three views of the
back box enclosure are shown on the next page.
Installation Brackets
MOUNTING
BRACKET
Installation Guide - DOC. 5848 Wall Mount Back Box for STX-1550CW: BB-1550CW •• 1
SUPPORT
BRACKET
