Insulated
Hot Cabinet
FL-2382-TB
5925 Heisley Road • Mentor, OH 44060-1833
OPERATING and MAINTENANCE INSTRUCTIONS
Taco Bell Hot Cabinet
Full Size Model: H137S27D1TB & H137S27D1LTB
Half Size Model: H137S273D1TB & H137S273D1LTB
Rev. 2 (1/16) Page 1 of 5
H137S27D1TB
H137S27D1LTB
Cabinet model number:
Cabinet serial number:
Authorized Service Agency:
Ph: Fax:
Keep this manual for future reference.
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
H137S273D1TB
H137S273D1LTB
Insulated
Hot Cabinet
FL-2382-TB
Rev. 2 (1/16) Page 2 of 5
5925 Heisley Road • Mentor, OH 44060-1833
OPERATING and MAINTENANCE INSTRUCTIONS
Taco Bell Hot Cabinet
Model: H137S27DITB
ELECTRICAL SPECIFICATIONS:
Model No. Volts Watts Amps Hertz Phase NEMA
H137S27D1TB
H137S27D1LTB
H137S273D1TB
H137S273D1LTB
120 2000 16.7 60 1 5-20P
120 1500 12.5 60 1 5-20P
INSTALLATION:
1. Remove all paper, packing materials and parts
from inside of cabinet.
2. Remove protective paper and vinyl material from
outside surfaces of cabinet.
3. Place the cabinet in a well-ventilated area.
4. Place cabinet on level oor. Cabinet legs are
adjustable by turning bottom of foot to level the
cabinet.
5. Install tunnels. Note that there is a right hand and
left tunnel. Check t.
6. Install hot unit on cabinet top and insert angles
into slots on tunnels.
7. Plug cord end into proper wall outlet.
Air is VERY HOT
WARNING
FIRST TIME START-UP:
when door is opened.
NOTE: DO NOT PUT FOOD INTO CABINET!
This step is to burn off manufacturing oils and excess
adhesive.
2. Let the cabinet cool and wipe inside clean with
detergent and hot water before rst use.
3. Let the cabinet cool and wipe inside clean with
detergent and hot water before rst use.
HOW TO HOLD:
1. Push POWER switch to “ON.” POWER LIGHT
will come on.
2. The control is preset to maintain an average
temperature of 165°F(74°C). Displayed
temperatures will change during loading and
unloading of product.
3. Preheat cabinet for 45 minutes.
4. Put product into cabinet.
NOTE: Proper food holding temperature is
140°F/60°C or higher.
1. Push the POWER switch to “ON”, and run the
unit for one hour.
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
HOW TO SET TIMER:
See FL-2383 for instructions.
Insulated
Hot Cabinet
FL-2382-TB
5925 Heisley Road • Mentor, OH 44060-1833
OPERATING and MAINTENANCE INSTRUCTIONS
Taco Bell Hot Cabinet
Full Size Model: H137S27D1TB & H137S27D1LTB
Half Size Model: H137S273D1TB & H137S273D1LTB
WARNING
BEFORE CLEANING CABINET:
1. Allow the cabinet to cool.
2. Do NOT use abrasives or harsh chemicals.
Be sure your cleaner is suitable to use on
stainless steel.
HOW TO CLEAN THE UNIT:
Soil Cleaner Method
Mild Detergent* and hot water, or
mild abrasive cleaner.
Dirt
Steam (no strong alkaline additive)
Mild abrasive cleaner.
Oily or waxy cleaner.
Fingerprints, grease, oil
Chemical oven cleaner.
Cleaning hints:
1. Wipe up spills as soon as possible.
2. Clean cabinet regularly to avoid heavy dirt build-up.
3. Make a test spot with cleaner.
4. Follow manufacturer’s directions on cleaner.
5. Do not mix cleaners.
6. Avoid drips and splashes.
7. Do not use “Cres Clean” on plastic parts or labels.
1. Wipe with soft, damp cloth.
2. Rinse with hot water.
3. Wipe Dry.
1. Rinse after steam cleaning.
2. Wipe Dry
Apply with soft, clean cloth.
Follow oven cleaner manufacturer’s
instructions
Rev. 2 (1/16) Page 3 of 5
Water Spots Mild abrasive cleaner.
*Mild detergent includes soaps and non-abrasive cleaners.
NOTE: Gaskets are removable for cleaning.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
REPAIR SHOULD BE DONE BY AUTHORIZED SERVICE
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
1. Apply with soft, clean cloth.
2. Wipe with damp cloth.
WARNING
RISK OF FIRE OR ELECTRIC SHOCK
DO NOT OPEN
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
PERSONNEL ONLY
Insulated
Hot Cabinet
FL-2382-TB
Rev. 2 (1/16) Page 4 of 5
5925 Heisley Road • Mentor, OH 44060-1833
OPERATING and MAINTENANCE INSTRUCTIONS
Taco Bell Hot Cabinet
Model: H137S27DITB
TROUBLE-SHOOTING CHART:
FAILURE: POSSIBLE CAUSE:
1. Switch light or control display does NOT
light up.
2. Unit gets too hot or won’t shut off. 2a. Relay or control defective.
3. Unit does not heat. 3. Defective heater, relay, blower or control.
4. Thermostat control reads (356) or (-99). 4. Temperature probe defective.
5. Thermostat control reads (888). 5. Transformer defective.
1a. Circuit breaker/fuse to wall outlet is blown
1b. Cord is unplugged from wall outlet.
1c. Switch is “OFF.”
1d. Switch or control defective.
UNPLUG UNIT FROM WALL OUTLET
6. Blower does not work or makes noise. 6. Defective blower.
ELECTRICAL REPLACEMENT PARTS:
CABINET REPLACEMENT PARTS:
Blower Kit 0769-203-K
Fan Guard 0769-167
Heater Kit (2000 Watt) 0811-022-K
Heater Kit (1500 Watt) 0811-019-K
High Limit 0848-033
Power Cord 0810-065-10-K
Relay, Solid State 0857-136
Strain Relief 0818-048
Switch, Power 0808-125
Thermostat Control
(Full Size)
Thermostat Control
(Half Size)
0848-075-TB
0848-075-TBH
Thermostat Probe 0848-075-01
DESCRIPTION
Door, Complete 1221-644-K 1221-659-K
Gasket, Door 0861-291 0861-293
Hinge, Door 0519-087-K 0519-087-K
Latch, Door 1006-120-01-K 1006-120-01-K
Leg Kit, 6” 1206-075-K -
Caster Kit - 0569-313-K
Caster w/ Brake Kit - 0569-313-BK
Wire Angles
(2 per kit)
Wire Shelf 1170-247 1170-247
Hot Unit HU671198 HU671199
Terminal Block 0852-119
Terminal Block (Rear) 0852-091
Timer, Event 0849-101
Transformer 0769-197
Vent Fan 0769-165
H137S27D1LTB &
H137S27D1TB
FULL SIZE
H137S273D1LTB &
H137S273D1TB
HALF SIZE
0621-363-K 0621-363-K
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Insulated
Hot Cabinet
FL-2382-TB
5925 Heisley Road • Mentor, OH 44060-1833
WIRING DIAGRAM
8
7
L
N
N
L
(REAR VIEW)
H137S27D1TB
120V
TEMPERATURE
POWER SWITCH
CONTROL
15 14
9
10
t°
AIR
PROBE
Rev. 2 (1/16) Page 5 of 5
FAN
VENT
17 16
15
A2(-)
A1(+)
14
T1 L1
5
6
*MUST HAVE THERMAL GREASE
OR THERMAL PAD INSTALLED
SURFACE
BETWEEN RELAY AND MOUNTING
G
*LOCKWASHER AND
NUT (OR DOUBLE
NUTS) IS REQUIRED
TO HOLD GROUND
TERMINAL TO
GROUND STUD
RED/YELLOW
YELLOW/GREY
TRANSFORMER
WIRE COLORS: TRIAD/HAMMOND
BROWN/BROWN
BLUE/ORANGE
GREY/RED
PURPLE/BLUE
WHITE/WHITE
BLACK/BLACK
6
HIGH LIMIT 400F
AIR HEATER
SOLID STATE RELAY 1
3
7
8
5
3
10
AIR HEATER
4
1
2
TB1
11
12
13
1
2
17
16
11
5
3
9
12 13
TIMER
EVENT
1 2
BLOWER
MOTOR
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
