Cortelco 2740 User Manual
OWNER’S INSTRUCTION
MANUAL
CALLER ID TYPE II
Four Line TELEPHONE SYSTEM
MODEL 2740
1
Table of Contents
IMPORT A NT SAFETY INSTRUCTIONS ................................. 5
Unpacking and Installation.......................................................... 6
Box Contents ................................................................................. 6
T elephone Part Identification.............................................................................................................. 7
Installation ........................................................................................................................................... 8
SYSTEM PROGRAMMING..................................................... 10
Station Number Assignment.............................................................................................................. 10
Station Name Assignment ................................................................................................................. 11
Line Configuration ............................................................................................................................. 12
Loop V oltage Detector ...................................................................................................................... 12
Ringer Configuration ......................................................................................................................... 13
Intercom Call Response and Paging................................................................................................. 14
Automatic Line Selection .................................................................................................................. 15
T oll R estriction .................................................................................................................................. 16
System Privacy .................................................................................................................................. 18
Dialing Mode ..................................................................................................................................... 18
Memory Settings ......................................................................... 19
Area Codes ..................................................................................................................... ................... 19
Memory Features.............................................................................................................................. 19
T o store a memory dial number ........................................................................................................ 20
T o store a personal directory dial number........................................................................................ 20
T o Stor e Caller ID Calls.................................................................................................................... 21
T o S tore the Centr ex prefix............................................................................................................... 21
Miscellaneous Settings................................................................ 22
Time and Date ................................................................................................................................... 22
Message Waiting Lamp .................................................................................................................... 22
Caller ID on Call W aiting (CIDCW) Sensitivity .............................................................................. 23
Held Call Reminder ........................................................................................................................... 23
Adjusting Auto Hold Dr op Time........................................................................................................ 23
Adjusting Flash Length...................................................................................................................... 23
Erase Numbers Stor ed in Memory ................................................................................................... 24
Erase T oll Restrictions...................................................................................................................... 24
Erase All Feature Settings ................................................................................................................ 24
TELEPHONE OPERATION..................................................... 24
Making and Answering Calls ............................................................................................................ 24
2
Hold .................................................................................................................................................... 25
Conference ......................................................................................................................................... 26
Transfer.............................................................................................................................................. 26
Caller ID ............................................................................................................................................ 27
Volume Levels ................................................................................................................................... 28
Voice Mail (Message Waiting) ......................................................................................................... 28
Flash ................................................................................................................................................... 29
Mute................................................................................................................................................... 29
Do Not Disturb (DND)...................................................................................................................... 29
Line Reserve ..................................................................................................................................... 30
Call Privacy ........................................................................................................................................ 30
T oll Restriction .................................................................................................................................. 30
Timer .................................................................................................................................................. 31
Headset .............................................................................................................................................. 31
Directory Card ................................................................................................................................... 31
Memory Dial...................................................................................................................................... 31
Personal Directory............................................................................................................................. 32
Predialing ........................................................................................................................................... 32
Intercom Calls.................................................................................................................................... 32
Paging ................................................................................................................................................. 33
Room Monitoring .............................................................................................................................. 33
Using standard telephones ......................................................... 34
Line Status and Calls on Hold........................................................................................................... 34
Call Privacy ........................................................................................................................................ 34
Intercom ............................................................................................................................................. 34
Fax Machines and Modems.............................................................................................................. 34
Batteries....................................................................................... 35
Battery Replacement ........................................................................................................................ 35
Power Failure Operation ................................................................................................................... 35
Appendex A ................................................................................. 36
Menu Tree.................................................................................... 36
FCC Information......................................................................... 40
3
THANK YOU
FOR PURCHASING THE
2740 CALLER ID TYPE II
FOUR LINE TELEPHONE SYSTEM
We want you to know all about your new Telephone, how to install it, the features it provides, and the
services you can expect from its use. We have included this information in your Owner’s Instruction Manual.
PLEASE READ BEFORE INSTALLING AND USING YOUR NEW
TELEPHONE EQUIPMENT.
4
IMPORT ANT SAFETY INSTRUCTIONS
Always follow basic safety precautions when using your telephone equipment to reduce the risk of fire,
electrical shock, and injury .
1. Read and understand all instructions in the Owner’s Instruction Manual.
2. Read all warnings and follow all instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Use a damp cloth for cleaning. Do
not use liquid or aerosol cleaners.
4. Do not use the telephone near water. For example, do not use near a bathtub, wash bowl,
kitchen sink, laundry tub, swimming pool, or in a wet basement.
5. Do not place this product on an unstable cart or stand. The product may fall causing serious
damage to the product.
6. Use only the type power source indicated on the label. If you are not sure of the type power
supply to your home, consult your dealer or local power company .
7. Do not place any objects on the telephone line cord. Do not locate the telephone where the line
cord will be walked on.
8. Do not block or cover ventilation slots and openings in the bottom of the telephone. The
openings should never be blocked by placing the telephone on a bed, sofa, rug, or other similar
surfaces. The telephone should never be placed near or over a radiator or heat register . The telephone should never be placed in a built-in installation unless proper ventilation is provided.
9. Never spill liquid on the telephone or push objects of any kind through ventilation slots.
Liquid or objects may touch dangerous voltage points or short out parts that could result in a risk of
fire or electrical shock.
10. Do not disassemble this product. Opening or removing covers may expose you to dangerous
voltages or other risks. Incorrect reassembly can cause electrical shock when the product is subsequently used.
11. Do not overload outlets and extension cords. Some telephones require AC power from an
outlet. Overloading the outlets can result in the risk of fire or electric shock.
12. A void using a telephone during a local thunderstorm. There may be a remote risk of electrical
shock from lightning.
13. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in
a fire. They may explode. Check with local codes for possible special disposal instructions.
14. Do not use a telephone to report a gas leak in the vicinity of the leak.
5
1.0 Unpacking and Installation
1.1 Box Contents
The following items should be packed with your 2740. Please contact your delaer if any of them is missing.
)ydoBniaM(enohP0472scp1
tesdnaHscp1
)droCdelioC(droCtesdnaHscp1
droCeniLscp2
droCeniLtrohSscp1
dnatSkseDscp1
)rem
rofsnarT(retpadArewoPscp1
6
1.2 T elephone Part Identification
1snottuByromeM01snottuBeniL91nottuBlaideR
2nottuBuneM11nottuBmocretnI02nottuBdloH
3nottuBeteleD21kcaJtesdaeHmm5.212sno
4DCLelgnA-itluM31nottuBegaP22nottuBpUemuloV
5pmaLegasseM41nottuBecnerefnoC32nottuBrekaepS
6nottuBnwoD/pUwe
iveR51nottuBrefsnarT42nottuBnwoDemuloV
7nottuBtceleS61nottuBhsalF52tesdnaH
8nottuBsllaC71nottuBetuM62kcaJtesdnaH
9pirtS
ogoL/yrotceriD81nottuBtesdaeH72rekaepS
7
ttuBlaiD
1.3 Installation
1.3.1 Identify Y our Existing Wiring System
For you to properly connect your 2740 4-Line T elephone System to an existing wiring system, it is
important that you understand its configuration. The following are the most common multiple line situations.
They consist of either one or both types of standard telephone jacks: The RJ11 Single Line Jack and the
RJ14 Double Line Jack. Your system should match one of them.
1.3.2 Plan Y our Installation
Up to 16 2740 4-Line T elephone System telephones may be connected to form your office/home con-
figuration. Each phone must be assigned a different station number , from 01 to 16. Until a telephone is
assigned a station number, the telephone will not operate. To assign this telephone a station number , simply
press the soft key under CHANGE repeatedly until the desired station number is displayed.
NOTE: Each 2740 telephone must be connected to the same Line 1 telephone number for proper opera-
tion. The remaining lines may or not be connected to each station.
1.3.3 Standard Installation:
Y our 2740 telephones come factory-set for a standard installation, which is also called “square” in tele-
phone terminology . This means that Line 1 is to be connected to the same Line 1 telephone number at all the
stations, Line 2 is to be connected to the same Line 2 telephone number at all the stations, and so on for
Lines 3 and 4. This is the desired setup for most installations, and if this is how you will be connecting your
2740, you do not need to change any of the line connection settings in the telephones. You need only
connect the phones to the telephone lines.
1.3.4 Installations with Private Lines and Unconnected Lines:
Y ou may wish to connect private lines to Lines 2, 3 or 4 at some or all of your telephones. A private line is a
telephone number that is connected to only one of the 2740 4-Line T elephone System, and is not shared
with any other station.
1.3.5 Desk Mount
1. Select the desired viewing angle and install the desk stand. The desk stand can be installed in two
positions to give a choice of viewing angle.
2. Connect the power adapter to the jack on the bottom of the phone. Plug the large part of the adapter
into a wall outlet which is not controlled by a wall switch. Use only a 9V DC 500mA, center positive
Class 2 adapter .
3. Connect the line cords. See Section 1.3.9.
4. Plug the coiled cord into the handset jack, and then plug the other end of the cord into the base.
5. Place the handset on the base.
1.3.6 Wall Mount
1. Remove the desk stand. The unit will then mount directly on a standard wall telephone jack.
2. Connect the power adapter and the line cords. See Steps 2 and 3 above.
8
3. Rotate the handset hook into the wall mount position.
4. Plug the coiled cord into the handset, and then plug the other end of the cord into the base.
5. Place the handset on the base.
1.3.7 Assign a Station Number
Refer to Section 2.1 for detailed instructions on assigning a station number.
1.3.8 Install Batteries (Optional)
While it is not necessary for you to install batteries in your 2740 telephone for it to function normally , we do
recommend that they be installed. The batteries are not needed to preserve your memory dial numbers,
because all memory dial numbers are stored in static memory . The purpose of having batteries installed is so
that the telephone itself can function for up to two hours in the event of a power failure. The telephone uses
3 AAA size batteries. W e recommend using alkaline batteries.
1. Make sure the AC cord remains attached to the telephone and to an electrical outlet
2. Turn the telephone over.
3. Remove the desk stand if attached.
4. Remove the battery door by using the tip of a ball point pen, paper clip, or similar object to release
the battery door tab.
5. Remove the old batteries.
6. Insert 3 pieces of new size AAA 1.5V alkaline batteries. Please note the “+” and “-” markings in
the battery compartment for the orientation of the batteries.
7. Close the battery cover.
Use caution when disposing of old batteries. Do not dispose of them in a fire. They may explode.
9
1.3.9 Connect Cords to T elephone
If the wall jack is labeled Lines 1 & 2, connect the short telephone line cord to the jack on the telephone
labeled L1/L2. If the wall jack is labeled Lines 3 & 4, connect the short cord to the jack on the telephone
labeled L3/L4. Connect the long telephone line cord to the other line jack on the telephone and thread it
through its long groove on the bottom of the phone, then plug the AC power cord into the adapter jack on
the bottom of the telephone, threading the power cord through its long groove on the bottom of the phone.
Thread the short telephone cord through the square hole in the center of the wall mount bracket, and then
attach the wall mount bracket to the base of the telephone.
1.3.10 Verify Proper Installation
The following procedure should be used at each telephone to check for proper installation. Also use this
procedure any time you are experiencing difficulty . The phone must be connected to the AC power supply ,
line 1 must be connected to the line 1 jack, and the phone must have been assigned an intercom station
number.
First, verify that line 1 is connected to the same telephone number at all the telephones. T o do this, press the
line 1 button at one of the telephones. The line 1 LED should be green, the speakerphone LED should be
red, and dial tone should be heard from the speaker. Now go to each of the other stations and make sure
that each line 1 LED is red. Next, make sure that lines 2, 3 and 4 are connected the same at all the phones
by performing the following steps at each telephone:
1. Press the line 1 button. The line 1 LED should be green, the speakerphone LED should be red, and
dial tone should be heard from the speaker.
2. Dial the telephone number for line 2. The line 2 LED should flash slowly. If the line 2 LED does not
flash, then line 2 is improperly connected to this telephone.
3. If this telephone utilizes line 3 and/or line 4, repeat steps 1 and 2, substituting the respective phone
number(s) in step 2.
2. SYSTEM PROGRAMMING
2.1 Station Number Assignment
Each station must be assigned a different station number .
T o assign a number to a station:
a. Press MENU. The display will read “Phone Setting”
b. Press the soft key under ENTER. The display will show the currently assigned station number.
c. Press the soft key under CHANGE repeatedly, until the desired station number is displayed. The
choices are S tation #01 through Station #16.
d. Press MENU to exit.
Until a telephone is assigned a station number , the telephone will not operate. T o assign this tele-
phone a station number, simply press the soft key under CHANGE repeatedly until the desired station
number is displayed.
Note: One phone in the system must be set as Station #01 in order for all the system features,
such as shared directory dial, to function.
10
2.2 Station Name Assignment
If you wish, you may give a name to each of your 2740 telephones, so that people can see the names along
with the station numbers when they place intercom calls. For example, you might name station #02 “Mary”
and station #05 “Conference Room.”
T o assign a number to a station:
At Station #01:
a. Press MENU. The display will read “Phone Setting”
b. Press ENTER.
c. Press the Down Arrow repeatedly until the display reads “S tation Naming”
d. Press ENTER. The display will show the currently stored name for station #01, or indicate “No
Name” if no name has yet been given to station #01.
e. Press soft Key under CHANGE if you wish to store a new name for station #01, or press DOWN
ARROW repeatedly until you see the station number that you want to name, and then press
CHANGE.
f . Use the dialpad numbers to enter the name for the desired station.
g. Press the soft key under SA VE.
Repeat steps a - g for any additional stations you wish to name.
The table below shows which dialpad numbers to press for all the different letters and special characters.
Note that you can press the 0, *, and # buttons if you want those characters, and you can press the down
arrow button below the display to leave an empty space. Press the DELETE button to make corrections.
00
1,-'& .()1
2A B C a b c 2
3DE F d e f3
4G H Ig h i4
5JKLjk l5
6MNOm no6
7PQRS pq rs7
8T UV tu v 8
9W XYw xy9
**
##
11
2.3 Line Configuration
While you must share the same Line 1 telephone number at all the stations, you may choose to leave some
lines unconnected at particular stations or to connect private or auxiliary lines to Lines 2, 3 or 4 at particular
stations.
2.3.1 COMMON
This is the factory setting for all lines. This setting assumes that the line is connected to the same telephone
number at all stations.
2.3.2 PRIVATE
Use this setting at any telephone that is connected to a different telephone number than the corresponding
line at the other stations.
For example, you may connect your private telephone number to Line 3 at your station instead of connecting your station to the shared Line 3. In this example, you would set Line 3 at your station as PRIV ATE.
2.3.3 UNCONNECTED
Use this setting at any telephone that is not physically connected to all of its lines. For example, you may
install a 2740 4-line telephone in a room that is currently wired for only lines 1, 2 and 3. In this example, you
would set Line 4 at this station as UNCONNECTED.
a. Press MENU. The display will read “Phone Setting.”
b. Press ENTER.
c. Press the DOWN ARROW repeatedly until the display reads ”Line Connections.”
d. Press ENTER. The display will show the curr ent line connection setting for Line 2.
e. Press the soft key under CHANGE repeatedly , until the desired line connection setting for Line 2 is
displayed. The choices are:
i . L2: COMMON (factory setting)
i i. L2: PRIV A TE
i i i . L2: UNCONNECTED
f . Press the soft key under NEXT to see the current setting for Line 3, and repeat steps c, d, and e to
change the settings for Lines 3-4.
g. Press MENU to exit.
2.4 Loop V oltage Detector
a. Press MENU.
b. Press DOWN ARROW repeatedly until “Advanced Setting” appears in the display .
c. Press ENTER.
d. Press DOWN ARROW repeatedly until “Loop Detect:” appears in the display , along with the
current setting
e. Press the soft key under CHANGE repeatedly until the desired loop detect setting is displayed.
The choices are:
i . Loop Detect: 48V (factory setting)
i i . Loop Detect: 24V (24 volts)
iii. Loop Detect: 12V
i v. Loop Detect: OFF
f. Press MENU to exit.
12
Y our 2740 telephone will light up its line status indicators when a non-2740 telephone such as a fax machine, modem, or standard telephone is using a line.
Note: If the line status indicators of your 2740 telephones do not function properly, either failing to light up
when a standard telephone uses a line, or staying lit even though no telephone is using a line, the loop
voltage detector setting needs to be adjusted.
The factory setting of 48 volts is appropriate for most installations. If this is not suitable, try setting
your phone to 24 volts. If that does not work, then set it to 12 volts. You can also turn this feature OFF if
you prefer.
If a line indicator at your 2740 telephone stays lit because there is no telephone line connected,
and you wish to turn it off, do not use this feature, but set this line at this station to UNCONNECTED
2.5 Ringer Configuration
The ringers for each outside line are controlled individually at each telephone. There are three possible
settings for each line ringer:
RINGER ON: The line will ring normally .
DELA YED RING: The line will start ringing after the first 20 seconds. This is useful for an office where the
phone is normally answered at a central location.
RINGER OFF: The line will not ring.
In all these cases, the line indicators will flash to signal an incoming call. Y ou can always answer a ringing
line, whether or not it is ringing audibly at your telephone, by pressing the corresponding flashing line button.
2.5.1 T o choose how each line will ring:
a. Press MENU. The display will read “Phone Setting”
b. Press ENTER.
c. Press the Down Arrow repeatedly until “Ringer Settings” appears in the display .
d. Press ENTER. The display will show the current ringer setting for Line 1.
e. Press the soft key under CHANGE repeatedly , until the desired ringer setting for Line 1 is dis-
played. The choices are:
i . L1 Ringer: ON (factory setting)
i i. L1 Ringer: DELAY
i i i. L1 Ringer: OFF
f . Press the soft key under DOWN ARROW to see the current ringer setting for Line 2. Repeat
steps c - e to change the ringer settings for Lines 2-4.
g. Press MENU to exit.
2.5.2 Setting Distinctive Ringing
All lines are initially set to ring with Ring Sound #1. If you prefer, you may assign each outside line one of
seven other distinctive ringer tones. T o assign distinctive rings to one or more lines:
a. Press MENU. The display will read “Phone Setting”
b. Press the DOWN ARROW repeatedly until ”Distinctive Ring” appears in the display.
c. Press ENTER. The display will show the distinctive ring setting for Line 1.
13
Loading...
