Corsair CH-9101014-UK User Manual

VENGEANCE K70 RGB
KEYBOARD MANUAL
TABLE OF CONTENTS
OVERVIEW
PROFILES
MODES
1
8
19
Introduction ���������������������������������������������������������������������������������������������������������� 2
Profiles: Settings for a Particular Program ����������������������������������������������� 3
Actions: Automating Steps ����������������������������������������������������������������������������4
Lighting: Control Device Lights �������������������������������������������������������������������� 5
Settings: Control Corsair Gaming Software ��������������������������������������������� 6
Creating a New Profile ������������������������������������������������������������������������������������� 9
Automatic Profile Switching ������������������������������������������������������������������������ 10
Activating a Profile ������������������������������������������������������������������������������������������� 12
Working with Profiles ��������������������������������������������������������������������������������������15
Modes ������������������������������������������������������������������������������������������������������������������ 20
Creating a Mode ������������������������������������������������������������������������������������������������21
Duplicating a Mode �����������������������������������������������������������������������������������������22
Editing a Mode ��������������������������������������������������������������������������������������������������23
Reordering Modes �������������������������������������������������������������������������������������������24
Resetting All Mode Settings ������������������������������������������������������������������������25
Deleting a Mode �����������������������������������������������������������������������������������������������26
Exporting a Mode ��������������������������������������������������������������������������������������������27
Importing a Mode ��������������������������������������������������������������������������������������������28
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
ii
TABLE OF CONTENTS
CONTROL ASSIGNMENTS
ACTIONS EDITOR
OVERVIEW
ACTIONS EDITOR
MACROS
ACTIONS EDITOR TEXT
ACTIONS EDITOR
KEYSTROKE
ACTIONS EDITOR
SHORTCUTS
29
34 36
43 46
49
Selecting Controls and Control Buttons ������������������������������������������������ 30
Remapping Keys ������������������������������������������������������������������������������������������������31
Assigning Keys with the Control Menu ����������������������������������������������������32
Assigning Keys with the Actions List �������������������������������������������������������33
Action Types ������������������������������������������������������������������������������������������������������35
Creating Macros ������������������������������������������������������������������������������������������������37
Setting Macro Options ���������������������������������������������������������������������������������� 39
Editing Macros �������������������������������������������������������������������������������������������������� 41
Text Actions ������������������������������������������������������������������������������������������������������� 44
Keystroke Actions ��������������������������������������������������������������������������������������������47
Shortcut Actions����������������������������������������������������������������������������������������������50
ACTIONS EDITOR TIMER
ACTIONS EDITOR MOUSE
ACTIONS EDITOR
MEDIA CONTROLS
Timer Actions ����������������������������������������������������������������������������������������������������52
51
Mouse Actions ���������������������������������������������������������������������������������������������������55
54
Media Control Actions ������������������������������������������������������������������������������������58
57
iii
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
TABLE OF CONTENTS
MODE SWITCHING
PERFORMANCE:
KEYBOARD
LIGHTING ASSIGNMENTS
PART ONE
LIGHTING ASSIGNMENTS
PART TWO
59
63
66 80
Mode and Profile Switching ������������������������������������������������������������������������60
Configuring Performance Options ����������������������������������������������������������� 64
Configuring Keyboard Performance �������������������������������������������������������� 65
Lighting Overview �������������������������������������������������������������������������������������������67
Working with Lighting Groups ���������������������������������������������������������������������81
Creating a Custom Lighting Group �����������������������������������������������������������82
Customizing Keys in a Lighting Group ����������������������������������������������������83
Deleting a Lighting Group ��������������������������������������������������������������������������� 84
Restoring a Pre-Defined Lighting Group ������������������������������������������������85
Editing a Custom Lighting Group ������������������������������������������������������������� 86
Cloning Lighting to Other Modes ��������������������������������������������������������������87
Assigning Background Lighting ���������������������������������������������������������������� 88
Type Lighting ���������������������������������������������������������������������������������������������������� 98
ACTIONS
100
Actions ����������������������������������������������������������������������������������������������������������������101
Filtering Actions ���������������������������������������������������������������������������������������������102
Creating a New Action ��������������������������������������������������������������������������������� 103
Editing an Action������������������������������������������������������������������������������������������� 104
Deleting an Action �����������������������������������������������������������������������������������������105
iv
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
TABLE OF CONTENTS
Duplicating an Action �����������������������������������������������������������������������������������106
Exporting a Single Action ��������������������������������������������������������������������������� 107
Exporting All Actions �����������������������������������������������������������������������������������108
Importing Actions ������������������������������������������������������������������������������������������109
HELP
PROGRAM SETTINGS
DEVICE SETTINGS
SUPPORT
SYSTEM TRAY MENU
110
113
121
123 125
Help ����������������������������������������������������������������������������������������������������������������������� 111
More Resources ����������������������������������������������������������������������������������������������� 112
General Settings ����������������������������������������������������������������������������������������������114
On-Screen Display Settings ������������������������������������������������������������������������ 115
Reset Messages �����������������������������������������������������������������������������������������������116
Macro Options �������������������������������������������������������������������������������������������������� 117
Updating Firmware and Software ������������������������������������������������������������ 118
Media Players ���������������������������������������������������������������������������������������������������� 119
Device Settings ����������������������������������������������������������������������������������������������� 122
Technical Support ������������������������������������������������������������������������������������������ 124
System Tray Menu ����������������������������������������������������������������������������������������� 126
Profiles ���������������������������������������������������������������������������������������������������������������� 127
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
v
TABLE OF CONTENTS
OSD Visibility ��������������������������������������������������������������������������������������������������� 128
Resources ���������������������������������������������������������������������������������������������������������� 129
Utilities ���������������������������������������������������������������������������������������������������������������130
Quit ����������������������������������������������������������������������������������������������������������������������� 131
ON-SCREEN DISPLAY
HARDWARE
On-Screen Display ����������������������������������������������������������������������������������������� 133
132
Keyboard Hardware �������������������������������������������������������������������������������������� 135
134
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
vi
OVERVIEW
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
1
OVERVIEW

INTRODUCTION

The Corsair Gaming Software allows you to create profiles and modes, define actions and lighting effects, and adjust settings�
There are several key concepts discussed in the documentation that can be useful when getting started with the Corsair Gaming Software:
Key– Your device inputs� These are assigned actions in the Corsair Gaming Software�
Profile – A profile is associated with a specific game or program, and allows you to configure lighting effects, actions, and settings for that specific program�
Mode – Within a single profile, you can have several different modes� Each mode allows you to change settings for a specific task within a program� For example, you may have one profile for a game, and then have separate modes for types of characters you might play, like a medic or sniper, so that you can customize each mode to suit your needs�
Action – A highly customizable behavior, an action connects your keys to outputs and lighting effects�
STARTING THE CORSAIR GAMING SOFTWARE
To start the Corsair Gaming Software, go to the system tray and double-click the Corsair Gaming Software icon�
The Corsair Gaming Software has four main menus:
• Profiles – The Profiles menu allows you to create and modify profiles, modes, key assignments, performance settings, and lighting assignments�
• Actions – The Actions menu allows you to create custom actions like macros, keystrokes, shortcuts, and timers�
• Lighting – The Lighting menu allows you to create custom lighting effects that you can assign to modes and actions�
• Settings – The Settings menu provides device and system information, and allows you to check for software and firmware updates and set options for the Corsair Gaming Software�
Lighting – Used to create visual effects on your keyboard, lighting effects can be attached to actions� You can create variations between profiles and roles�
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
2
OVERVIEW
PROFILES: SETTINGS FOR
A PARTICULAR PROGRAM
A profile is a group of settings associated with a specific game or other program� Each profile can have multiple modes, which store specific device configurations� You can define multiple profiles, and each profile can have multiple modes that store device configurations, such as:
• Key assignments;
• Keyboard lighting and lighting effects; and
• Actions like macros, timers, and text input�
The Profiles menu allows you to create and manage your profiles; import and export profiles; and assign profiles, modes, actions, and lighting to keys� You can switch profiles manually at any time, or enable automatic profile switching�
Automatic profile switching: enable a profile when the application starts
Automatic profile switching assigns a profile to a program� When you start that program, the device profile activates automatically�
melee combatant� Change modes as needed during gameplay to activate key assignments relevant to a particular role�
For more information on profiles and modes, see
Profile Section and Modes Section
Modes: quickly switch configurations
Within each profile, you can also define multiple modes, each with unique key assignments, performance settings, and lighting� For example, you could define modes within a profile for each role you might play in a game: a medic, a sniper, or a
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
3
OVERVIEW
ACTIONS:
AUTOMATING STEPS
The Actions menu allows you to create and edit actions for automating steps within a program� For example, you might create an action in a real-time strategy game that would deploy units periodically� That macro could be made up of mouse clicks, keyboard strokes, and delays�
Through the Actions menu, you can record, edit, and delete actions for macros, text input, and sending keystrokes or mouse clicks, as well as many other functions� You can also change key assignments and change how macros will be played back�
For more information about actions, see Actions
Section
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
4
OVERVIEW
LIGHTING: CONTROL
DEVICE LIGHTS
The Corsair Gaming Software allows you to create several different lighting styles and effects on your keyboard, from solid colors that can highlight key groupings to gradients and ripple patterns that can give you a visual cue that a macro is finished or a timer is finished�
Lighting effects can be assigned to specific modes and actions� The Lighting menu allows you to define lighting scenes for the keyboard and then assign them to modes and actions�
For more information about lighting, see Lighting
Section
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
5
OVERVIEW
SETTINGS: CONTROL
CORSAIR GAMING
SOFTWARE
The Settings menu allows you to perform software updates, view device and system information, change settings for the on-screen display (OSD) and media players, and view documentation and support information�
For more information about settings and options, see
Settings Section
DEVICE SELECTOR
The device selector appears in the lower right­hand corner of the Corsair Gaming Software and provides you important information about the Corsair Vengeance K70 RGB�
When the Corsair Vengeance K70 RGB is connected to your computer, the device selector will show an image with an icon and the name of the device� If no devices are detected, a warning dialog box appears� Ensure all your devices are connected properly� For additional support information, see Support Section
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
6
OVERVIEW
SETTINGS: CONTROL
CORSAIR GAMING
SOFTWARE (Continued)
DEVICE STATUS
The device icon may change based on the status of the keyboard�
• If the device icon has a blue icon in the upper right corner, a firmware update is available�
• If the device icon has a red icon in the upper right corner, a firmware update may be required�
• If Corsair Gaming Software detects a malfunction, the icon may also be red� See
Support Section
To learn how to update your device firmware, see
Updates Section
ASSIGNING PROFILES
You can assign actions to keys in the Profiles menu� To learn how to make key assignments, see Profiles
Section
HELP
Help for the Corsair Gaming Software is available in the bottom bar of the screen� You can click the triangle in the lower left to show or hide the Help bar�
The help bar contains links to the online version of the user manual and Corsair’s user forum, as well as links to Corsair’s Facebook page and Twitter profile, so you can stay in touch with the latest news and announcements from Corsair�
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
7
PROFILES
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
8
PROFILES
CREATING A NEW
PROFILE
1� In the Corsair Gaming Software, click Profiles
and then click New
2� The Profile Settings dialog box appears� In the
Name field, type a name for the profile�
3� In the Notes field, type any optional notes you
want to make about the profile�
4� Configure any optional profile settings you
want�
– To link the profile to a specific program,
see Automatic Profile Switching
– To configure the On-Screen Display (OSD)
settings, see On-Screen Display Settings
5� When you are finished, click OK
Once you have created a profile, you can modify the modes within the profile to suit your preferences� Go to modes to learn more�
Note: If you type the name of a profile that already exists, the new profile name will have a numerical suffix, such as “(2)” added when you save the profile�
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
9
PROFILES
AUTOMATIC PROFILE
SWITCHING
Automatic profile switching enables you to automatically start a profile when a specific game or other application starts�
Note: You can also switch profiles manually by clicking the profile name in the Corsair icon in the system tray�
To use automatic profile switching for a profile, you need to link the profile to a program�
In the Corsair Gaming Software, in the Profile menu,
1� In the profile list, click the profile�
2� To the right, click the menu button, and then
click Edit Profile
3� The Profile Settings dialog box appears�
Select the Link profile to program check box�
4� Click the Browse button to locate the
program�
5� The Choose Application dialog box appears�
Browse to the path of the application you want to link to this profile, click it, and then click Open
Note: If an application is associated with another profile, a warning dialog box will appear� You cannot link an application to more than one profile�
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
10
PROFILES
ON-SCREEN DISPLAY
SETTINGS (OSD)
Profiles can also display information on-screen about the current mode and timer status�
In the Corsair Gaming Software, in the Profile menu,
1� In the profile list, click the profile�
2� To the right, click the menu button, and then
click Edit Profile
3� The Profile Settings dialog box appears� Click
OSD Settings
4� The On-Screen Display (OSD) dialog box
appears� Choose the options you want in order to configure the length of the on-screen display for each feature�
– For the Mode drop-down box, you can click
Never Show, Always Show, or specify a time between 0�5 and 5 seconds� If you specify a time, the mode name will appear on screen for the specified time then fade out�
– For the Timer drop-down box, select
Never Show or Always Show
When you are finished defining the profile settings, click OK to save it�
5� After choosing the desired OSD settings, click
OK
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
11
PROFILES

ACTIVATING A PROFILE

There are three ways to activate a profile:
Option 1: Use automatic profile switching and start the linked program�
Option 2: Right-click the system tray icon, then click the profile name�
Option 3: Assign a profile to a key� (Note: This is a legacy option included for gamers familiar with other gaming hardware� To get the most out of your Corsair hardware and software, it is recommended that you use one of the first two options�)
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
12
PROFILES
IMPORTING AND
EXPORTING PROFILES
With the Corsair Gaming Software, you can export the profiles and modes you create, so that you can back them up, take them to another computer to retain all the settings for your games, or share them with other people� You can export a single profile at a time, or export all your profiles at once�
You can also import profiles that you have exported, or that another user has shared with you� When you run the import, the Corsair Gaming Software will import all the profiles that it finds in the file�
EXPORTING ALL PROFILES
To export all your Corsair Gaming Software profiles into a single file, in the Profiles menu,
1� Click Import/Export Profiles
2� In the drop-down list, click Export All
3� The Export All Profiles dialog box appears�
Browse to the location where you want to save the file�
4� In the File Name field, type the name you
want to give your profile export file and then click Save
The exported profile will be saved in the location you specified with the name [filename]�prf�
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
EXPORTING A SINGLE PROFILE
To export a single profile, in the profile drop-down list,
1� Click the profile you want to export�
2� Click the profile menu button and then click
Export
3� The Export Profile dialog box appears� Browse
to the location where you want to save the exported profile�
4� In the Name field, type the name of the
exported file and then click Save�
The exported profile will be saved in the location you specified with the name [filename]�prf�
IMPORTING CUSTOM PROFILES
To import one or more profiles from a file, in the Profiles menu,
1� Click Import/Export Profiles
2� In the drop-down list, click Import
3� The Select file to import dialog box appears�
Browse to the location where the profile file is stored�
13
PROFILES
IMPORTING AND
EXPORTING PROFILES
(Continued)
4� Click the file to import, and then click Open
If you attempt to import a profile with a duplicate name, a warning dialog box will appear, asking if you would like to update the profile�
• If you click Update, the existing profile will be replaced with the profile you’re importing�
• If you click Add as New, the existing profile will stay the same, and the profile you’re importing will be imported and renamed with a number in parentheses�
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
14
PROFILES
WORKING WITH
PROFILES
PROFILE SELECTION
The Profile menu provides a screen where you can view and customize the profiles and modes for your Corsair Vengeance K70 RGB�
SELECTING A PROFILE
In the Profiles menu, you can click the drop-down list to view a list of all the profiles you have, and click the name of the profile you wish to view or edit�
To search for a specific profile, you can click inside the drop-down list, start typing to find profiles that match your input, then click the profile name you wish to view or edit�
Note: If you have not defined any custom profiles, the default profile called Default is loaded� The default profile can be renamed, but not deleted�
VIEWING MODES
When a profile is loaded through the profile selector, below it you can see the list of all the modes defined for the profile�
Once a profile is selected, you can click the name of a mode to view or edit key assignments, performance settings, and lighting� For more information, see Modes Section
EDITING PROFILES
You can change the settings for a profile, including the profile name, notes, linked program, and on­screen display (OSD) settings�
• To edit a profile, click the profile you want to edit, click the profile menu button, and then click Edit Profile
For more information about modifying profile settings, see Profile Settings Section
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
15
PROFILES
WORKING WITH
PROFILES
(Continued)
DELETING PROFILES
• To delete a custom profile, select the profile from the drop-down menu, click the profile menu button, and then click Delete Profile
When you delete a custom profile, a warning dialog box will appear with the name of the profile you are about to delete�
• Click OK to delete the profile, or click Cancel to keep it�
Note: When you delete a profile, you also delete all the modes in that profile� If there are any modes you wish to keep, make sure to export them first� For more information, see Modes Section
The default profile cannot be deleted�
DUPLICATING PROFILES
If you want to duplicate a profile to apply its settings and modes to another game, you can do so through the Profiles menu� Duplicating a profile will duplicate all the modes, assignments, and performance settings for the profile�
• To duplicate a profile, click the profile you want to duplicate, click the profile menu
button, and then click Duplicate Profile
You can create a new name for the profile and change other optional settings, as well� For more information about the settings you can change, see
Profile Settings Section
Note: If the duplicate profile contains a link to the same program, a warning dialog box will appear� You cannot link two profiles to the same program�
EXPORTING A SINGLE PROFILE
With the Corsair Gaming Software, you can export the profiles and modes you create to back them up, move them to another computer to retain all the settings for your games, or share them with other people�
To export a single profile, in the Profiles menu, in the profile drop-down list,
1� Click the profile you want to export�
2� Click the profile menu button, and then click
Export
3� The Select file to export dialog box appears�
Browse to the location where you want to save the exported profile�
4� In the Name field, type the name of the
exported file, and then click Save
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
16
PROFILES
WORKING WITH
PROFILES
(Continued)
The exported profile will be saved in the location you specified with the name [filename]�prf�
SETTING THE DEFAULT PROFILE
The Corsair Gaming Software provides a default profile called Default� The default profile contains no custom modes, key assignments, custom performance settings, or custom lighting� You can make one of your custom profiles the default profile that Windows uses when your computer starts and the Corsair Vengeance K70 RGB is connected�
• To set a profile as the default profile, click the profile you want to duplicate, click the profile menu button, and then click Set As Default
Profile
Note: If you set a custom profile as your default
profile, you cannot delete it while it is the default�
CONFIGURING THE ON-SCREEN DISPLAY
For each profile, you can configure custom on­screen display (OSD) settings, so that you can see the name of the active profile mode and active timers�
To customize the OSD settings for a profile, in the profile drop-down list,
1� Click the profile you want to edit�
2� Click the profile menu button, and then click
Edit Profile
3� The Profile Settings dialog box appears� Click
OSD Settings
4� The On-Screen Display (OSD) dialog box
appears� In the drop-down lists, click the desired options, and then click OK
5� Click OK again to save the profile�
There are three options you can change for the OSD�
• Mode: This shows the name of the active profile mode�
• DPI: Reserved for future use�
• Timer: This shows the time remaining for the
active timer�
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
17
PROFILES
WORKING WITH
PROFILES
(Continued)
For the Mode option you can choose from the following settings:
• Never show: The OSD will never show the active mode, even when switching modes�
• 0.5 Sec, 1 Sec, 2 Sec, 5 Sec: The OSD will show the active mode for the indicated time and then fade out�
• Always Show: The OSD will always show the active mode�
For the Timer option, you can choose to always show the timer or never show the timer�
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
18
MODES
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
19

MODES

MODES
Profiles may be customized with modes, which allow you to change device behavior quickly�
Modes are shown on the left hand side of the screen, beneath the Profiles drop-down box� When you select a profile in the Profiles drop-down box, all modes created for the profile are listed beneath it� You can switch modes by assigning a key to mode selection�
Each profile has a default mode that you can customize to fit your needs, and you can create your own modes, as well�
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
20
MODES

CREATING A MODE

You can create a new mode if you want to customize device settings for a particular game role� For example, you could create a mode to utilize unique in-game abilities with macro actions or to rearrange hotkeys for games that don’t have built-in support for key assignment�
In the Corsair Gaming Software, in the Profiles menu,
1� In the list of modes, click the + button�
2� The Mode Settings dialog box appears� In the
Name field, type a name for the mode�
3� In the Notes field, you can type any notes
about the mode�
4� When you are finished, click OK.
If you create a mode that shares a name with an existing mode, a unique number will be appended, such as ‘(2)’�
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
21
MODES

DUPLICATING A MODE

You can duplicate an existing mode� This is useful if you want to preserve most of a mode’s settings, but need another with slight variations�
In the Corsair Gaming Software, in the Profiles menu,
1� To the right of the mode you want to
duplicate, click the menu button, and then click Duplicate Mode
2� The Mode Settings dialog box appears� In the
Name field, type a name for the mode�
3� In the Notes field, you can type any notes
about the mode�
4� When you are finished, click OK
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
22
MODES

EDITING A MODE

You can make changes to an existing mode’s name, and notes by editing it�
In the Corsair Gaming Software, in the Profiles menu,
1� To the right of the mode you want to edit,
click the menu button, and then click Edit Mode
2� The Mode Settings dialog box appears� In the
Name field, type a name for the mode�
3� In the Notes field, you can type any notes
about the mode�
4� When you are finished, click OK
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
23
MODES

REORDERING MODES

You can change the order of modes by clicking and dragging them to the position you want in the modes list� This allows you to control the order of mode switching� For keyboards with predefined mode keys, your modes may be assigned to respective keys with this operation�
CORSAIR VENGEANCE K70 RGB KEYBOARD MANUAL
24
Loading...
+ 112 hidden pages
