JT-30 COLD BEVERAGE DISPENSER
WITH JWT-300 SERIES ALTERNATE PARTS
MODEL NO.
A8530
A8540
A8560
A8531
A8541
IMI CORNELIUSINC.
One Cornelius Place
Anoka,MN.55303--6234
Telephone 1-800-238-3600
Facsimile 1-800-258-0255
www.cornelius.com
ILLUSTRATED PARTS LIST
A8532
A8542
A8533
A8543
JT-30
1of4
Manual Part No. 18488
10-13-2001
ãIMI Cornelius Co., 2001
IMI CORNELIUSINC.
One CorneliusPlace
Anoka,MN.55303--6234
Telephone 1-800-238-3600
Facsimile 1-800-258-0255
www.cornelius.com
ILLUSTRATED PARTS LIST
JT-30 COLD BEVERAGE DISPENSER
WITH JWT-300 SERIES ALTERNATE PARTS
Manual Part No. 18488
10-13-2001
ãIMI Cornelius Co., 2001
FIGURE 1. GENERAL ASSEMBLY
2of4
JT-30
IMI CORNELIUSINC.
One Cornelius Place
Anoka,MN.55303--6234
Telephone 1-800-238-3600
Facsimile 1-800-258-0255
www.cornelius.com
ILLUSTRATED PARTS LIST
JT-30 COLD BEVERAGE DISPENSER
WITH JWT-300 SERIES ALTERNATE PARTS
Item
No.
10 S6901 Gasket Bowl Spout
11 S6600 GasketBowl
12 S4381 Handle Push Asy
13 720721601 Label Oper Push Handle
14 S4363 Tube Pinch Spring
15 S4576 Rivet Spr Ret (Pack of 6)
16 Item Not used
17 Item Not used
18 18546 Capac 208/230V 60HZ
19 S6657 Thermostat 120V 60HZ
20 18334 Switch On-Off
21 A1753 Motor Asy Spray Drive 120V
22 18874 Magnet Asy
23 A8364 Kit Comp 1/3HP 120V 60HZ
24 A1839 MotorAsyFan8”DiaFanBlade
Part No. Name
1 S6670 Tube Spray
2 S6677 Housing Pump Asy120V 60HZ
S7046 Pump Asy 220/240V 50HZ
3 A3058 Impeller and Support Pin
120V 60HZ
A3192 Impeller and Support Pin
220/240V 50HZ
4 A2549 Pin Support Impeller
5 S6676 Cover Bowl 5 Gallon
A2162 Cover Bowl 3 Gallon
6 S6562 Bowl 5 Gallon
A0791 Bowl 3 Gallon
7 S6737 Impeller Circ Asy (Replace of
Pump Housing Ass’y No. S6677
for Certain Drinks)
8 A1620 Impeller Circ Asy
A3036 Lock Devise
A3791 Kit Extension Leg
9 S4206 Tube Pinch
A2739 Thrmst Asy 220/240V 50HZ
60HZ
A2072 Spray Drive Asy 220/240V 50HZ
A8365 Kit Comp 1/3HP 230V 50HZ
A8366 Kit Comp 1/3HP 230V 50/60HZ
120V 60HZ
A4493 Motor Asy Fan 8 3/4” Dia Fan
Blade 120V 60HZ
A2148 MotorAsyFan8”DiaFanBlade
220/240V 50HZ (No Longer
Available)
A4446 Motor Fan 9W 120V 60HZ
A4451 Blade Fan
17898 Cond
18449 Dryer
Item
No.
25 S3194 Motor Fan 5W 120V 60HZ
26 S1249 Cord Serv 120V 60HZ
27 12086 Relay Start 120V 60HZ
28 18369 Overld,120V 60HZ
29 18334 Switch On-Off
30 Item Not used
31 A7319 Panel Back Asy Vnt Cvr
32 A7316 Panel Back Asy Wht
33 S3159 Leg Set Replacement
34 Item Not used
35 S7683 Switchand CoverPlate
36 S9267 Panel Fnt
37 S9266 Panel Side Asy
38 A7310 Drip Tray Asy
39 A7296 Drip Tray Asy
40 18747002 Cup Rest
41 S4554 Screw Panel (Pack of 12)
42 A3060 Screw Side Clip (Pack of 4)
43 S7289 Drain Asy Condensate
44 A2081 Spacer Cover Mntg Hdwr
45 A7317 Panel Back with Filter
46 A7305 Frame Side
Part No. Name
14512 Fan Ass’y, 8 3/4” Dia Fan Blade,
220/240V 50HZ (No Longer
Available)
A4448 Motor Fan 9W 230V 50HZ
3714 Brkt Fan
A4446 Motor Fan 9W 120V 60HZ
S3195 Motor Fan 6W 230V 50HZ
A4448 Motor Fan 9W 230V 50HZ
7215130 Cord, Asy 230V 50HZ
12576 Relay Start 230V 50HZ
18545 Relay 208/230V 60HZ
350106 Overld 230V 50HZ
18547 Overld 208/230V 60HZ
S9281 Plate Switch Cover (No Longer
Available)
(Serial No. below 315270)
18720 Panel Fnt
(Serial No. 315270 and above)
A2011 Filter Side Panel
(Serial No. below 315270)
18747 Drip Tray Asy
(Serial No. 315270 and above)
(Serial No. below 315270)
18747001 Drip Tray
(Serial No. 315270 and above)
A2013 Filter
JT-30
3of4
Manual Part No. 18488
10-13-2001
ãIMI Cornelius Co., 2001
IMI CORNELIUSINC.
One CorneliusPlace
Anoka,MN.55303--6234
Telephone 1-800-238-3600
Facsimile 1-800-258-0255
www.cornelius.com
ILLUSTRATED PARTS LIST
JT-30 COLD BEVERAGE DISPENSER
WITH JWT-300 SERIES ALTERNATE PARTS
FIGURE 2. JWT ALTERNA TE P ARTS
Item
No.
10 A2567 Motor Asy Whipper 120V 60HZ
11 A2410 Magnet Asy Double
Manual Part No. 18488
10-13-2001
ãIMI Cornelius Co., 2001
Part No. Name
1 A2746 Housing Whipper
2 A2566 Magnet Whipper Impeller
3 A0116 Pin Whipper Impeller
4 A0938 Union Whipper Outlet
5 S7395 Outlet Tube
6 A2569 Chamber Whipper
7 A0423 Clip Impeller Support
8 S7394 Tube Vent Asy 5-Gallon
A2791 Tube Vent Asy 3-Gallon
9 A2256 Motor Whipper 120V 60HZ
S7512 Motor Whipper 230V 50HZ
A2645 Motor Whp Asy 230V 50HZ (No
Longer Available)
4of4
Item
No.
12 S8465 Switch Motor White
13 S8469 Kit Screen and Washr (Pack of 4)
14 13927 Plate Cover Switch
15 A2269 Cover Switch Asy White(No
16 S8467 Switch Support Asy White (No
17 S9570 Cover Plate Switch Non Whipper
Part No. Name
A2754 Switch Motor Black
8468 Washer Star No. 10
8469 Screw No. 10-32 x 1/4
S9412 Plate Cover Switch (No Longer
Available)
Longer Available)
A4509 Cover Switch Asy Black (No
Longer Available)
Longer Available)
A4434 Switch Support Plate Black (No
Longer Available)
(No Longer Available)
JT-30
