Powerbase 70-T2i
Instruction Manual
Switronix, Inc.
265 Sunrise Highway Tel: 1-800-613-7948, 516-750-9675
Suite 346 Fax: 516-594-1414
Rockville Centre, NY 11570 Website: http://www.switronix.com
1. Using conversion box GP-DV-T2i the Powerbase 70
can supply 7.2V for Canon T2i cameras with a faux
battery. It can also supply 12V for accessories through
the conversion box PT socket.
2. Included conversion box/cable applicable camera
models:
1. Can be used as normal V type brick battery
2. Built-in PT port can supply power for accessories
or charging.
3. Quick release plate can be used to install wireless
reciever, hard drive or other equiptment or to connect
two batteries.
Canon T2i
Specifications
Rated Voltage: 14.8V
Rated Capacity: 70Wh
Charge Time: 3~5 hrs
Dimensions: 6.25in x 3.4in x 2in
Weight: 1.5lbs
Four step LED power indication
4. Both sides have a 1/4” 20 insert for installing other
equipment
