Page 1
Combi steamer
Project ________________________________________
Item __________________________________________
Quantity _______________________________________
FCSI section ____________________________________
Approval _______________________________________
Date __________________________________________
C4eT 6.10 EB DD
Model
Convotherm 4 easyTouch
Standard features
ACS+ (Advanced Closed System +) operating modes:
Steam (30-130°C) with guaranteed steam saturation
Combi-steam (30-250°C) with automatic humidity adjustment
Convection (30-250°C) with optimized heat transfer
HygienicCare – food safety thanks to antibacterial surfaces:
easyTouch control panel
Door handle and recoil hand shower
easyTouch user interface:
9" full-touch screen
Press&Go – automatic cooking using quick-select buttons
TrayTimer – load management for different products at the same time
Regenerate+ – flexible multi-mode regenerating function
ecoCooking – energy-save function
Low-temperature cooking / Delta-T cooking
Cook&Hold – cooks and holds in one process
399 cooking profiles each containing up to 20 steps
On-screen help with topic-based video function
Start-time preset
Multi-point core temperature probe
Door handle with safety latch and sure-shut function
Data storage for HACCP and pasteurization figures
Preheat and cool down function
easyTouch
6+1 Shelves GN 1/1
Electric
Boiler
Disappearing door
Key features
ACS+ operating modes: Steam, Combi-steam, Convection
ACS+ Extra Functions:
Crisp&Tasty – 5 moisture-removal settings
BakePro – 5 levels of traditional baking
HumidityPro – 5 humidity settings
Controllable fan – 5 speed settings
easyTouch 9" full-touch screen
ConvoClean+ fully automatic cleaning system with eco, regular and
express modes, including optional single-measure dispensing
Ethernet interface (LAN)
HygienicCare
USB port integrated in the control panel
TriColor indicator ring – indicates the current operating status
Steam generated by high-performance boiler outside the cooking
chamber
Disappearing door: more space and greater safety at work (optionally
available for an extra charge)
Options
Steam and vapour removal – built-in condensation module (on request)
ConvoGrill with grease management function (on request)
ConvoSmoke – built-in food-smoking function
Marine version (see separate datasheet)
Prison version
Available in various voltages
Sous-vide probe, external connection
Core temperature probe, external connection
Accessories
ConvoLink – HACCP and cooking profile management PC software
ConvoVent 4 condensation hood with grease filter
ConvoVent 4+ condensation hood with grease and odour filter
Signal tower – external operating-state indicator
Banquet system (optionally as a package or individually): Plate rack,
mobile shelf rack, transport trolley, thermal cover
Stands in various sizes and designs
Racks, choice of GN or BM versions (BM = standard baking sheet size)
Stacking kits
Care products for the ConvoClean+ fully automatic cleaning system
(multiple and single-measure dispensing)
Convotherm Elektrogeräte GmbH
Ovens & Advanced Cooking EMEA
Manitowoc Foodservice
Talstrasse 35, 82436 Eglfing, Germany
Tel: +49(0)8847 67-0
Fax: +49(0)8847 414
www.convotherm.com
1
Page 2
Dimensions
Weights
Views
C4eT 6.10 EB DD
Front view
View from above with wall clearances
Connection positions
A Water connection (for boiler)
B Water connection (for cleaning, recoil hand shower)
C Drain connection DN 50
D Electrical connection
E Equipotential bonding
F Rinse-aid connection
G Cleaning-agent connection
H Air vent Ø 50 mm
I Ventilation port Ø 50 mm
M Safety overflow 80 mm x 25 mm
Installation instructions
Absolute tilt of unit in operation* max. 2° (3.5%)
* Adjustable feet included as standard.
Dimensions and weights
Dimensions including packaging
Width x Height x Depth 1110 x 1010 x 940 mm
Weight
Empty weight without options* / accessories 129 kg
Weight of packaging 25 kg
Safety clearances**
Rear 50 mm
Right-hand side (disappearing door pushed back) 130 mm
Left (larger gap recommended for servicing) 50 mm
Top*** 500 mm
* Weight of options 15 kg max.
** Minimum distance from heat sources: 500 mm.
*** Depends on type of air ventilation system and nature of ceiling.
2
9758117_03 ENG_GBR 08/15. © 2015 Manitowoc. Continuous improvements to the product may mean changes to the specification are made without explicit mention.
Page 3
Loading
Electrical supply
Water
C4eT 6.10 EB DD
Loading capacity
Max. number of food containers
GN 1/1* 6+1
600 x 400** baking tray 5
Plates max. Ø 32 cm,
Ring spacing 66 mm**
Plates max. Ø 32 cm,
Ring spacing 79 mm**
Maximum loading weight
GN 1/1 / 600 x 400
Per combi steamer 30 kg
Per shelf level 15 kg
* Matching rack included as standard.
** Matching rack available as an accessory.
20
15
Electrical supply
3N~ 400V 50/60Hz*
Rated power consumption 11.0 kW
Rated current 15.9 A
Fuse rating 16 A
RCD (GFCI), frequency converter (single phase) Type A
Recommended conductor cross-section 5G4
3~ 230 V 50/60Hz*
Rated power consumption 10.9 kW
Rated current 27.4 A
Fuse rating 35 A
RCD (GFCI), frequency converter (single phase) Type A
Recommended conductor cross-section 4G6
3~ 200 V 50/60Hz*
Rated power consumption 10.9 kW
Rated current 31.5 A
Fuse rating 35 A
RCD (GFCI), frequency converter (single phase) Type A
Recommended conductor cross-section 4G6
3~ 400 V 50/60Hz*
Rated power consumption 11.0 kW
Rated current 15.9 A
Fuse rating 16 A
RCD (GFCI), three-phase frequency converter Type B/F
Recommended conductor cross-section 5G4
* Connection to energy optimization system included as standard.
PLEASE NOTE: If the ConvoSmoke option is chosen, the only voltages
available are 3~ 230V 50/60Hz and 3N~ 400V 50/60Hz.
(recommended), type
B/F (optional)
(recommended), type
B/F (optional)
(recommended), type
B/F (optional)
(recommended)
Water connection
Water supply
Water supply 2 x G 3/4'' permanent connection, optio
Flow pressure 150 - 600 kPa (1.5 - 6 bar)
Appliance drain
Drain version Permanent connection (recommended)
Type DN50 (min. internal Ø: 46 mm)
Slope for waste-water pipe min. 3.5% (2°)
nally including connecting pipe (min.
DN13 / 1/2'')
or funnel waste trap
Water quality
Water-supply connection A* for boiler,
Water-supply connection B* for cleaning, recoil hand shower
General
requirements
Total hardness 4 - 20 °dh / 70 - 360 ppm /
pH value 6.5 - 8.5
Cl- (chloride) max. 60 mg/l
Cl2 (free chlorine) max. 0.2 mg/l
2-
SO
(sulphate) max. 150 mg/l
4
Fe (iron) max. 0.1 mg/l
Temperature max. 40 °C
Electrical conductivity min. 20 μS/cm
* See diagram of connection positions, page 2.
Drinking water, typically hard water
7 - 35 °TH / 5 - 25 °e
Water consumption
Water-supply connections A, B
Ø Consumption for cooking** 3.0 l/h
Max. water flow rate 15 l/min
** Including water used for cooling the wastewater.
PLEASE NOTE: See diagram of connection positions, page 2.
3
Page 4
Emissions
Accessories
C4eT 6.10 EB DD
Emissions
Heat output
Latent heat 2100 kJ/h / 0.58 kW
Sensible heat 2500 kJ/h / 0.69 kW
Waste water temperature max. 80 °C
Noise during operation max. 70 dBA
ACCESSORIES
(Please refer to the Accessories brochure for detailed information)
Stacking kit
Permitted combinations 6.10 on 6.10
6.10 on 10.10
For a combination of two electric appliances
Select "Stacking kit for Convotherm 4 electric appliances"
For a combination of one electric appliance and one gas appliance in
the stacking kit
Select "Stacking kit for Convotherm 4 electric appliances" if:
Bottom combi steamer EB/ES
Top combi steamer GB/GS
Select "Stacking kit for Convotherm 4 gas appliances" if:
Bottom combi steamer GB/GS
Top combi steamer EB/ES
Condensation hood ConvoVent 4*
Electrical supply
Rated voltage 1N~ 200-240V 50/60Hz
Rated power consumption 260 W
Rated current 1.9 A
Fuse rating 2.5 A
Dimensions excluding packaging
Width x Height x Depth 877 x 240 x 1085 mm
Weight excluding packaging 66 kg
Safety clearance above** 500 mm
* Condensation hoods specially designed for stacking kits are available.
** Depends on type of air ventilation system and nature of ceiling.
Please observe the following points:
This document is to be used solely for planning purposes.
Please refer to the Installation Manual for further technical data and
guidance on installation and positioning.
Convotherm Elektrogeräte GmbH
Ovens & Advanced Cooking EMEA
Manitowoc Foodservice
Talstrasse 35, 82436 Eglfing, Germany
4
Tel: +49(0)8847 67-0
Fax: +49(0)8847 414
Condensation hood ConvoVent 4+*
Electrical supply
Rated voltage 1N~ 200-240V 50/60Hz
Rated power consumption 260 W
Rated current 1.9 A
Fuse rating 2.5 A
Dimensions excluding packaging
Width x Height x Depth 877 x 373 x 1085 mm
Weight excluding packaging 85 kg
Safety clearance above** 500 mm
* Condensation hoods specially designed for stacking kits are available.
** Depends on type of air ventilation system and nature of ceiling.
9758117_03 ENG_GBR 08/15. © 2015 Manitowoc. Continuous improvements to the product may mean changes to the specification are made without explicit mention.
www.convotherm.com
