INSTALLATION AND OPERATIONS MANUAL
Worktop and Undercounters
Worktop/Undercounters & Sandwich Units
Refrigerators & Freezers
Please fill in the following information for your NEW unit, carefully
read the instructions in this manual and file it for future reference.
MODEL NO.
SERIAL NO.
PURCHASED FROM
INSTALL DATE
1-800-523-7138
Continental Refrigerator
A Division of National Refrigeration
& Air Conditioning Products, Inc.
539 Dunksferry Road
Bensalem, PA 19020-5908
P 215-244-1400
F 215-244-9579
www.continentalrefrigerator.com
Page 2
Page
Receiving Your New Model .............................................................................................................................. 3
General Information and Important Operating Facts ....................................................................................... 3
Uncrating Your New Model ............................................................................................................................... 3
Installation and Location .................................................................................................................................. 4
Ventilation ........................................................................................................................................... 4
Floor Loads ......................................................................................................................................... 5
Installing Casters and Leveling ............................................................................................................ 5
Installing Legs and Leveling ................................................................................................................ 6
Condensate Removal ........................................................................................................................... 6
Removal of Doors and Door Adjustment ............................................................................................. 7
Removal of Drawers and Drawer Adjustments .................................................................................... 7
Mounting Self-Closing Hinge Mechanism ........................................................................................... 8
Removal and Replacement of Hinge Mechanism ................................................................................ 8
Re-Hinging Doors ................................................................................................................................ 9
Removing Lid and Hood (Sandwich Units Only) ................................................................................. 9
Initial Cleaning Procedure ............................................................................................................................... 10
Start-Up Procedure .......................................................................................................................................... 10
Electrical Connections ........................................................................................................................... 10
115 Volt, 60 Hz, 1 Phase Connection ..................................................................................... 10
115/208-230 Volt, 60 Hz, 1 Phase Connection ...................................................................... 10
Special Voltage Connections .................................................................................................. 10
Start-Up Checklist .............................................................................................................................. 10
Remote Applications .......................................................................................................................... 11
Operation .......................................................................................................................................................... 11
Thermometer Calibration .................................................................................................................... 11
Refrigeration System and Adjustment ................................................................................................ 11
Evaporator Assembly .......................................................................................................................... 11
Freezer System and Adjustment ......................................................................................................... 12
Defrost Operation ................................................................................................................. 12
Interior Accessories ............................................................................................................................ 12
Shelving Installation ............................................................................................................. 12
Maintenance .................................................................................................................................................... 13
Periodic Cleaning Procedure .............................................................................................................. 13
General Preventative Maintenance ...................................................................................................... 13
Parts and Service ............................................................................................................................................. 14
Optional Accessories ....................................................................................................................................... 15
Installing Overshelf or Double-Overshelf ............................................................................................ 15
Installing Stacking Collar Adapter Kit ................................................................................................. 15
Installing Front Breather Kit ................................................................................................................ 16
Installing Drawer Cage ....................................................................................................................... 17
Mounting Caster Support Plates ......................................................................................................... 17
Installing Electric Condensate Vaporizer ............................................................................................. 18
Remote Set-Up and Installation Guidelines ........................................................................................ 19
Troubleshooting and Servicing Guide ............................................................................................................. 20
Wiring Diagrams .............................................................................................................................................. 22
Limited Extended Protection Warranty ........................................................................................................... 24
OPERATIONS MANUAL
Page 3
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
RECEIVING YOUR NEW MODEL
Congratulations on your purchase of Continental Refrigerator
superior foodservice equipment! When your shipment arrives,
thoroughly examine the packaging for any punctures, dents, or
signs of rough handling. It is in your best interest to partially
remove or open the shipping container in order to examine the
contents for any missing accessories, or concealed damage
which may have occurred during shipment. If the cabinet is
damaged, it must be noted on the carrier’s delivery slip or bill
of lading (see “Filing a Damage Claim” under “Warranty”
section).
GENERAL INFORMATION AND
IMPORTANT OPERATING FACTS
This manual has been compiled to aid in the installation, operation and maintenance of your new equipment. Please take the
time to read it and familiarize yourself with your equipment and
its operation, to enjoy optimum performance.
Continental Refrigerator offers a variety of accessories for your
model (see “Optional Accessories” section towards the back
of this manual or contact your dealer for more information).
SERIAL DATA TAG
A serialized data tag is permanently attached to the inside righthand wall of your unit. (see Figure 1). In addition to identifying
the specific product, this label provides important information
regarding electrical requirements and refrigeration charge, as
well as agency listings and factory contacts.
FIGURE 1: Data Tag
IMPORTANT NOTE: The model and serial number should
be noted on the front cover of this manual, in the spaces
provided. If parts or service are ever needed for your unit,
this information will be required to verify warranty status
and to properly identify any parts that may be needed.
All cabinets must be given sufficient time to reach normal
operating temperature before placing any food inside cabinet
or pans (if equipped). For refrigerators, approximately 1 hour
of operation is required to lower the cabinet and pan temperature to 40°F (4°C). During pull-down of open top models, pans
should be in place and top lid should be kept closed. Freezers
require approximately 2 hours of operation to lower the cabinet
temperature to 0°F (-18°C) (see “Operation” section for further
information).
Prior to factory shipping, all products are performance-run
tested for a minimum of 12 hours providing a highly sophisticated temperature recording exclusive to each individual
cabinet. This recording is supplied within this manual packet. A
final evaluation, including analysis of cabinet performance, leak
check, vibration, noise level and visual examination is made by a
qualified quality control team to assure a superior product. The
carrier signs to this effect when they accept the product for shipping. To insure the maximum in safety and sanitation, all models
are listed under the applicable of Underwriters Laboratories and
National Sanitation Foundation standards.
UNCRATING YOUR NEW MODEL
The shipping container should remain on your cabinet to protect against dents or scratches while transporting to the actual
set-up location. Remove the shipping container only at the last
possible moment by using a pry bar to take out all the staples
from around the bottom of the crate. Slide the cardboard carton
up and off the unit, being careful not to rub against the cabinet.
Remove any accessories or boxes on the skid or in the cabinet.
Four (4) bolts secure the cabinet to the wooden skid. The bolts
are located at each end on the underside of the skid. In order to
remove these bolts, tilt the cabinet backwards and place wooden
blocks at each end in order to hold it in its tilted position. Using
a ¾” socket or open end wrench, remove the bolts and carefully
slide the model off of the skid. After skid removal, the cabinet
should never be moved without dollies or rollers to avoid damage to the cabinet bottom or floor.
OPERATIONS MANUAL
3
Page 4
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
IMPORTANT NOTE: Do not under any circumstances, lay
your new model on its front or sides. For a brief period
of time, you may lay the cabinet on its back, but only
when its properly blocked so as not to crush the louvered
venting panel and also to allow provision for your hands,
in order to set it in its upright position without damaging
the cabinet. Do not plug in and operate model for at
least three (3) hours after cabinet is set upright from
being on its back as this can damage the compressor.
INSTALLATION AND LOCATION
For optimum performance, “SW” series models should be
installed on casters or legs (see “Installing Casters” or
Installing Legs”) and a mini mum 3” clearance should be
provided on each side and the rear of the cabinet (see Figure
2). Your model has been designed to also operate sufficiently
without legs or casters and directly on the floor as long as a
minimum clearance of 8” is provided from the rear venting
louvers and the rear wall (see Figure 2). Cabinet side clearance
is not required when mounting your model directly on the floor,
without legs or casters. If any of the above conditions can not be
achieved, the installer should provide special venting or air supply ducts, or a Front-Breather Kit (see “Optional Accessories”)
can be ordered by contacting the factory.
Before moving the cabinet to its final point of installation, measure all doorways or passages to assure clearance. If additional
clearance is needed, you can remove the cabinet doors (see
“Removal of Doors and Door Adjustment”) and lids (when
equipped) (see “Removing Lid and Hood”).
“UC” series models and units provided with the Front-Breather
Option do not require any clearance around the the sides or
back of the cabinet, since they take in and exhaust air under the
cabinet and through the front grill, under the door. The air flow
under the cabinet and through the front grill cannot be restricted.
(see “Front Breather Kit” under “Optional Accessories”).
VENTILATION
The final location site of your air cooled refrigerator or freezer
must provide a large quantity of cool, clean air. All refrigeration
systems operate most efficiently and trouble-free with cool,
dry air circulation. Avoid locations near heat and moisture
generating equipment including ovens, cooking ranges, fryers,
dishwashers, steam kettles, etc., or in direct sunlight (where
temperatures can exceed 100°F). Do not select a location in an
unheated room or area where temperatures may drop below
55°F. Air supply to the condensing unit is equally important.
Restricting the air places an excessive heat load on the condensing unit and adversely effect its operation.
FIGURE 2: Minimum Clearance Dimensions for Optimum Conditions
IMPORTANT NOTE: To assure maximum operating effi-
ciency, your new cabinet should be located where an
unrestricted air supply can circulate underneath and
behind the cabinet. Do not at any time obstruct the grill
area in the rear of the cabinet in any way, and never place
or store anything inside of the cabinet machine compartment. These rules are essential for maximum cooling
capacity and long life of refrigeration parts.
4
OPERATIONS MANUAL
Page 5
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
OPTIONAL CASTER SHIM
(Reference #CM1-2476)
CASTER
FLOOR LOADS
The floor at the final location site must be level, free of vibration
and strong enough to support the total combined weights of
your new model plus the maximum product load which might
be placed into it. Keep in mind that all the weight is concentrated
at the caster or leg locations. A fully loaded reach-in model may
reach 2,000-3,000 pounds. To estimate the possible product
weight, assume that each cubic foot of storage space weighs
approximately 35 pounds. Multiply 35 pounds by the amount of
cubic feet in the cabinet to obtain the product load weight.
For example, a 20 cubic foot refrigerator can hold approximately
700 pounds of product (35 x 20). Assuming the cabinet itself
weighs 300 pounds, the total combined weight of cabinet and
product is approximately 1000 pounds. Therefore, the floor in
this example must be able to support up to 1000 pounds.
INSTALLING CASTERS AND LEVELING
If your new unit is supplied with swivel casters, they will be
packed in the accessory box that came with your cabinet.
Casters should be installed only when the cabinet is close to
it’s final installation site. To install casters on your new model,
carefully tip the unit back and position (4) 2” thick wood blocks
underneath. Locate the large threaded holes on the bottom of
the cabinet and screw the threaded caster studs into the mounting holes, closest to the front of the unit. Repeat this procedure
by tilting the cabinet in the opposite direction and installing
the remaining casters. Make sure the casters are tightened
extremely well (see Figure 3b). If the casters are not installed
tightly, the cabinet will be unstable and may sway or rock, which
can damage the cabinet.
FIGURE 3a: Installing Casters
FIGURE 3b: Casters Must Be Tight to Cabinet Bottom
If the height of a caster needs to be raised, shims must be
installed under the casters which need leveling. Extra large
washers, available at most hardware or furniture stores, can be
used to shim casters, or contact the factory for caster shims.
Do not attempt to level casters by unscrewing them
from the cabinet and leaving them loose, as this will
cause damage to the cabinet and leg hole threads,
voiding all warranties.
IMPORTANT NOTE: It is extremely important that your
cabinet is perfectly level for proper operation. If it is not
level, the following adverse conditions may occur:
1. The door(s) will not be properly aligned and
consequently will not provide a good seal.
2. Your unit may run excessively.
3. An excessive amount of ice will accumulate inside
the cabinet, around the door opening(s) and on the
finned evaporator coil. If allowed to continue, ice will
eventually block the coil and the unit will fail. This
can result in the loss of all food stored in the cabinet.
4. Defrost water will fail to drain properly and will
overflow the evaporator coil drain pan and into the
cabinet of both refrigerator and freezer models.
OPERATIONS MANUAL
5
Page 6
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
CONDENSATE PAN
DRAIN LINE
LEG
TURN END OF LEG
COUNTERCLOCKWISE
TO INCREASE HEIGHT,
OR CLOCKWISE
TO REDUCE HEIGHT.
UP
THREADED
END
INSTALLING LEGS AND LEVELING
Your new is supplied with adjustable legs for leveling purposes.
Each model has four leg mounting holes on the bottom of the
cabinet. Legs are packed in the accessory carton from which
they must be removed and installed on the cabinet bottom
(see Figure 3). In order to install the legs, carefully tip the
cabinet back, adding four (4) 2” wood blocks underneath, and
simply screw the threaded leg studs into the case bottom front
leg holes. Repeat this procedure by tilting the cabinet in the
opposite direction and install the remaining legs. Make sure the
legs are tightened extremely well or the entire model will sway
or rock with each opening or closing of the doors, possibly
causing damage to the case bottom. This procedure should be
performed close to the final installation site and allow access
to the rear of the cabinet for condensate evaporator installation
(see “Installing Condensate Evaporator” under “Installation
and Location” section).
To assure your cabinet is level, all legs are equipped with bullettype leveling bolts. These bolts can be turned by hand or by
wrench, clockwise or counterclockwise to level the cabinet.
FIGURE 4: Leg Installation
CONDENSATE REMOVAL
No floor drains or plumbing connections are required since all
models use an automatic condensate water evaporating system
(see Figure 5). All models utilize a unique hot air condensate
water evaporating system which is completely self-contained
and no further assembly or maintenance is required. In some
adverse conditions such as high ambient temperature, high
humidity, extremely heavy usage, frequent loading for prolonged
periods of time, or heavy pan loading, the amount of condensate water generated could overflow the pan. If this occurs,
the plastic drain tube from the cabinet can be diverted directly
to a floor drain, bypassing the condensate pan. Alternatively,
an optional electric condensate vaporizer may be purchased
as an accessory. An electric condensate vaporizer is also supplied with all remote models. To install the optional condensate
vaporizer, follow the steps for (“Installing Electric Condensate
Vaporizer” in the “Optional Accessories” section) towards the
back of this manual.
FIGURE 5: Condensate Pan Location
6
OPERATIONS MANUAL
Page 7
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
ADJUST
BRACKET
MOUNTING
SCREWS
PIVOT PIN
BRACKET
LEFT-HAND DOOR
(SPRING CARTRIDGE
AT BOTTOM)
CABINET TOP
BUSHING
REMOVAL OF DOORS AND DOOR ADJUSTMENT
During installation, it may become necessary to remove the
cabinet doors to facilitate passage through narrow doorways
or hallways. Depending on the age of your cabinet, the springloaded hinge cartridge is located either on the top or the bottom of the door. To remove a door, verify the location of the
spring-loaded cartridge (see Figure 8). Swing the door to the
open position (90°) and remove the mounting screws securing
the the hinge cartridge bracket to the cabinet (either above or
below the door).
CAUTION: THE HINGE CARTRIDGE IS SPRING LOADED
AND MAY SNAP TOWARDS THE DOOR WHEN THE
MOUNTING SCREWS ARE REMOVED. BE SURE TO HOLD
DOOR FULLY OPEN BEFORE REMOVING MOUNTING
SCREWS.
For doors with the spring cartridge on the bottom: after removing the bracket mounting screws below the door, carefully
lower the door straight down, and free of the pivot pin bracket
above the door. (For doors with the spring cartridge on top:
after removing the bracket mounting screws above the door,
carefully lift the door straight up, and off the pivot pin bracket
below the door).
All doors are aligned at the factory, however vibration during
transit may cause them to shift and realignment may be necessary. If the door(s) require realignment, proceed as follows:
Open the door (90°) and loosen, but 1. do not remove the
mounting screws securing both the top and bottom hinge
brackets to the cabinet.
Adjust the door to the desired position by hand or by tap-2.
ping on the edge with a rubber mallet.
Securely tighten all of the mounting screws, above and 3.
below the door.
Check the door alignment and repeat adjustment if neces-4.
sary.
FIGURE 6: Hinge Adjustment
REMOVAL OF DRAWERS
AND DRAWER ADJUSTMENTS
To remove the drawers from the cabinet, slide each drawer
out until it stops. Unhook the stop clip at the front of the left
and right-hand drawer slide (see Figure 7) by pushing the clip
forward and pressing down on the top back edge as shown.
Lift the drawer slightly as you pull it the rest of the way out.
The center member, with the wheels attached, will remain in
the cabinet. To remove a drawer center member for cleaning or
maintenance, pull it out and push up on the release lever at the
back, as shown.
To install a drawer, identify the correct parts and orient the
center members so the plastic clips are in the front and at the
top. Insert one of the center members into the front of the correct cabinet member (which is permanently attached to the
inside of the cabinet) and slide it in, until it stops. Push up on
the release lever (located toward the rear and top of the center
member) to allow the center member roll the rest of the way
into the cabinet member, in the “drawer closed” position. Repeat
for the opposite side center member. Pull each center member
out a few inches, press down on the rear of each stop clip, and
pull forward so the hook on the front of the clip rotates up, into
the “unlocked” position. Lift the drawer body into place, resting
the drawer members (the channels welded to the sides of the
drawers) on the front wheels of the center member, and slide
the drawer into the cabinet. Once the drawer goes in all the way
and slides smoothly, open it enough to access the stop clips.
Lift the back of each clip and push in at the front, so the hook
portion snaps into the “locked” position. The drawers are now
OPERATIONS MANUAL
7
Page 8
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
SELF-CLOSING SPRING-LOADED HIINGE
BRACKET ATTACHMENT
SCREW
SPRING-LOADED
MECHANISM
CARTRIDGE MOUNTING
SCREWS (2)
SPRING-LOADED
CARTRIDGE
BOTTOM
OF DOOR
HINGE CARTRIDGE IN BOTTOM OF LEFT-HAND DOOR
(CARTRIDGE IN BOTTOM OF LEFT-HAND DOOR OPPOSITE)
CARTRIDGE
BRACKET
LOCKWASHER
SPRING CLIP
TIGHTEN
SLIDE CLIP FORWARD
& PRESS HERE
TO DISENGAGE
PUSH UP ON
LEVER TO
DISENGAGE
DRAWER MEMBER
CABINET MEMBER
CENTER MEMBER
STOP CLIP
(EXPLODED VIEW)
RELEASE LEVER
LEFT-HAND SHOWN (RIGHT-HAND OPPOSITE)
secured, so they cannot accidentally be lifted out of the cabinet.
Check that the drawer is properly aligned, rolls smoothly and
the drawer gasket seals firmly.
If the drawer fronts needs adjustment (once all drawers are
installed and closed), loosen the five screws that hold the
drawer front to the drawer body. Move the drawer front into
position desired and re-tighten all screws.
FIGURE 7: Drawer Slide
If the hinge does not work as described, follow these steps:
1. Using the hinge upside down as a wrench, turn the
mechanism in the door 180° in either direction. The
mechanism should snap to a null point.
2. Remount the hinge as shown in Figure 8.
3. Repeat the test procedure as described above until the
hinge snaps back when it is moved from the open-door
position towards the closed-door position.
FIGURE 8: Spring Loaded Hinge Mounting
MOUNTING SELF-CLOSING HINGE MECHANISM
(For doors with hinge cartridge on bottom)
For proper operation of the self-closing doors on all sandwich
unit models, the hinge mechanism must be mounted to apply
tension in the proper direction (see Figure 8). When the hinge
is moved to the open-door position, it should be tension-free.
However, when the hinge is moved back into the closed position, it should snap back.
CAUTION SHOULD BE TAKEN WHEN CHECKING THE
SPRING LOADING AS THE HINGE COULD SNAP BACK
ON FINGERS.
8
REMOVAL AND REPLACEMENT
OF HINGE MECHANISM
To remove the hinge mechanism from the door, remove the door
from the cabinet as explained previously. As shown in Figure 8,
remove the hinge plate from the hinge mechanism by removing
the hinge pin screw. Also remove the horseshoe spring. Reinstall
the hinge pin screw only partially leaving about 1/8” of exposed
screw threads. Now, the hinge mechanism mounting screws
can be removed thus allowing the mechanism to be removed by
pulling on the hinge pin screw. If the mechanism does not readily slide out of the door, slide a claw hammer or forked prybar
under the hinge pin screw head and using a block of wood for
leverage, lift the entire mechanism out of the door. To install the
new hinge mechanism, reverse the above procedure.
OPERATIONS MANUAL
Page 9
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
PLUG
BUTTON
PIVOT PIN
BRACKET
BUSHING
HINGE
CARTRIDGE
LEFT-HAND
DOOR
HINGE
BRACKET
RIGHT-HAND
DOOR
PLUG BUTTON
HINGE
BRACKET
BUSHING
PIVOT PIN
BRACKET
HINGE
CARTRIDGE
(TYPICAL UNIT WITH 1/6-SIZE PANS SHOWN)
HOOD
LID
FOOD PANS
CUTTING
BOARD
PIVOT PIN (2)
PAN DIVIDERS
LID HANDLE
RE-HINGING DOORS
IMPORTANT NOTE: The doors are field reversible,
but different hinge brackets are required. HAVE YOUR
MODEL SERIAL NUMBER READY AND CONTACT THE
CONSULT FACTORY FOR THE PARTS NEEDED FOR
YOUR UNIT.
Detach the door and remove the hinge mechanism, as previously described. Remove the hinge from the cabinet by loosening
the (2) mounting screws. Remove the plug button and bushing
out of the top of the door (see Figure 9 for parts identification).
A flat-blade screwdriver or putty knife may be used to carefully
pry them out, if required.
To re-assemble the reverse-hinged door, select the proper
“opposite-hand” top and bottom hinge brackets and cartridge
insert (see Figure 9 for parts identification). Follow the steps
above, in reverse order.
FIGURE 9: Door Re-Hinging
REMOVING LID AND HOOD
(Sandwich Top Units Only)
To remove the lid covering the food pan area (see Figure 10),
lift it 1/2 way up and carefully push in on the left end at the bottom corner, so the pivot pin comes out of the mating hole in the
hood. Swing the end of the lid forward, so it clears the end of
the hood. Slide the entire lid to the left, so the pivot pin on the
opposite end is free from the hood. If you have an insulated lid,
to take out the liner and insulation, remove the screws along the
back edge, let the back of the liner drop down and rotate it, so
the front edge of the liner disengages from the front edge of the
lid. To remove the hood, take out the screws located inside each
end and along the back edge.
FIGURE 10: Sandwich Top Lid Open
OPERATIONS MANUAL
9
Page 10
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
INITIAL CLEANING PROCEDURE
Prior to start-up and before placing any product inside of your
new model, the interior of the cabinet should be thoroughly
cleaned. Washing with a mild soap and warm water solution
is recommended for cleaning the aluminum and stainless steel
surfaces of your cabinet. This should be followed by cleaning
with a baking soda solution (three (3) tablespoons of baking
soda to each quart of warm water). Rinse thoroughly with clear
water and dry with a clean, soft cloth.
IMPORTANT NOTE: Never use harsh detergents, cleaners, scouring powders or chemicals when cleaning your
model. Failure to dry the interior surfaces after cleaning
may result in a streaking or staining of the metal.
Complete cleaning procedures and precautions are listed in the
(“Periodic Cleaning Procedure” under the “Maintenance”).
START-UP PROCEDURE
ELECTRICAL CONNECTIONS
To insure proper operation, your new model must be connected
to an individual circuit that can supply the full voltage as stated
on the cabinet serial data plate. For correct voltage, power draw,
and wire accommodations, check the data on the serial data
plate located on the inner right wall of your new model. Verify
that this information exactly matches the electrical characteristics at the installation location. An electrical wiring diagram,
located on the inside compressor compartment rear, next to
the electrical console box, should also be consulted during
connection. For reference, a copy of each electrical wiring diagram is located towards the back of this manual (see “Wiring
Diagrams” section).
IMPORTANT NOTE: The condensing unit supplied with
all self-contained models is designed to operate with a
Rrange of +/-10% of the voltage indicated on the cabinet
serial data plate. Full voltage of the correct rating, on an
isolated line, not affected by the operation of other electrical appliances, must be available to the refrigeration unit
at all times. Burnout of the compressor due to exceeding
high or low voltage limits is easily detected and will void
the factory warranty.
115 VOLT, 60 HZ, 1 PHASE CONNECTION
All 115 volt models are provided with
a factory installed, UL approved power
cord and polarized plug. To insure proper
operation, this equipment must be plugged
into a NEMA 5-15r compatible, grounded
receptacle that can supply the full voltage
as stated on the serial data plate.
WARNING: ANY ALTERATIONS TO THIS CORD AND
PLUG COULD CAUSE AN ELECTRICAL HAZARD AND
WILL VOID THE FACTORY WARRANTY.
115/208-230 VOLT, 60 HZ, 1 PHASE CONNECTION
All 115/208-230 volt models are provided with three (3) supply wires, which exit the electrical box located in the machine
compartment rear, next to the compressor. The cabinet circuitry
is 115 volts and the condensing unit operates on 208-230 volts.
A permanently connected, 3-wire (plus ground) power supply is
required, consisting of (2) hot conductors and (1) neutral wire,
plus (1) ground wire. The supply leads must be connected to
the appropriate leads from the cabinet and the supply ground
wire must be attached to the electrical box with a ground lug
to provide proper grounding of the metal cabinet and chassis.
All wiring and connections should only be made by a qualified
electrician and must conform to all local electrical codes.
SPECIAL VOLTAGE CONNECTIONS
When models are ordered from the factory with special, optional
voltages, connections should be made as required on the electrical wiring diagram provided on the inside compressor compartment rear next to the electrical console box.
START-UP CHECKLIST
After your model has been installed, leveled, cleaned, and electrically connected in accordance with this manual, please take
the time before start-up to observe the following precautions to
assure trouble free operation:
1. Check that all exposed refrigeration lines are free of severe
dents or kinks.
2. Check the condenser fan and evaporator fans for freedom to
rotate without any obstructions.
3. Make sure that the cabinet is properly leveled (see
“Leveling” under “Installation and Location” section).
10
OPERATIONS MANUAL
Page 11
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
The system should run smoothly and quietly in accordance
with generally accepted commercial standards. If any unusual
noises are heard, turn the unit off immediately and check for any
obstructions of the condenser or evaporator fans. Fan motors,
fan blades, or fan housings can be jarred out of position through
rough handling in transit or during installation.
CAUTION: IF UNIT IS UNPLUGGED OR DISCONNECTED
FOR ANY REASON, ALLOW 5-6 MINUTES BEFORE
TURNING THE UNIT BACK ON TO ALLOW THE SYSTEM
TO EQUALIZE. DISREGARDING THIS PROCEDURE
COULD CAUSE AN OVERLOAD AND PREVENT THE UNIT
FROM OPERATING.
REMOTE APPLICATIONS
All models are available for purchase as remote models in which
case the condensing unit is purchased separately and installed
at the time of installation. All remote models are equipped with
an expansion valve located within the evaporator coil housing,
and both liquid and suction lines stubbed and extending out
from the cabinet rear behind the rear cover. Installation of the
refrigeration accessories, condensing unit, and electrical hookup should be performed by qualified refrigeration personnel of
a competent refrigeration company only (see “Remote Set-Up
and Installation Guidelines” under “Optional Accessories”).
cabinet product compartment, on the right back wall next to the
evaporator coil (see Figure 11). If an adjustment is necessary
to maintain temperature within the range noted above, place a
screwdriver into the thermostat slot and turn clockwise for a
colder cabinet temperature or counterclockwise for a warmer
cabinet temperature. Further adjustments out of the factory
design temperature range should only be made by a qualified
refrigeration mechanic.
IMPORTANT NOTE: Turning a thermostat fully counterclockwise turns the refrigeration compressor “off.”
EVAPORATOR ASSEMBLY
All undercounter refrigerators and freezers have an easily accessible, easily serviceable, performance-rated, forced-air evaporator assembly which utilizes a plasticized fin coil for extended life.
All models utilize a full length, extra large evaporator coil with a
uniquely directed air flow distribution which keeps compartment
product at uniformly constant temperatures (see Figure 11).
FIGURE 11: Evaporator Assembly
OPERATION
All cabinets must be given sufficient time to reach normal operating temperature before placing any product inside cabinet.
Refrigerators are designed to maintain an ideal cabinet temperature of 38° to 40°F (3.3° to 4.4°C), approximately 1 hour
of operation is required to reach this temperature. During pulldown of open top models, pans should be in place and top lid
should be kept closed. Freezers are designed to maintain an ideal
cabinet temperature of -4° to 0°F (-20° to -18°C), approximately
2 hours of operation are required to reach this temperature.
THERMOMETER CALIBRATION
Your new model has a non adjustable hanging thermometer
located inside the cabinet, mounted on the coil housing cover
(see Figure 11). This thermometer is maintenance-free and
needs no further calibration.
REFRIGERATION SYSTEM AND ADJUSTMENT
All self-contained refrigerators are designed and factory set to
maintain an average cabinet temperature of 38° to 40°F (3.3°
to 4.4°C). The temperature control is accessible inside of the
IMPORTANT NOTE: All refrigerators are designed with an
automatic, “off-cycle” defrost system which means that
defrosting occurs automatically when the compressor is
not operating during an off-cycle. Do not set the thermostat too cold where the cabinet temperature will fall below
35°F (1.7°C) because the evaporator will become blocked
by ice since the compressor off-cycle will be considerably
shortened. This will result in loss of product stored within
the cabinet and require service to defrost the evaporator
and re-adjust the thermostat.
OPERATIONS MANUAL
11
Page 12
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
PILASTER
STRIP
PILASTER CLIP
INSTALLED
PILASTER CLIP
INSTALLING
SHELF
INSTALLING
DEFROST
TIMER
FREEZER SYSTEM AND ADJUSTMENT
All self-contained sandwich unit freezers are designed and factory set to maintain an average cabinet temperature of -4° to
0°F (-20° to -18°C). All freezers are designed for the purpose
of holding pre-frozen product and although they are capable of
freezing small quantities of fresh product, they are not designed
to be blast chillers or ice-cream freezers. Do not attempt to freeze
bulk quantities of fresh food or ice-cream. The temperature control is accessible inside of the cabinet product compartment, on
the right back wall next to the evaporator coil (see Figure 11 for
thermostat location). If an adjustment is necessary to maintain
the above temperature range only, place a screwdriver into the
thermostat slot and turn clockwise for a colder cabinet temperature or counterclockwise for a warmer cabinet temperature.
Further adjustments out of the factory design temperature range
must be made by a qualified refrigeration mechanic only.
IMPORTANT NOTE: Turning a thermostat fully counterclockwise turns the refrigeration compressor “off.”
DEFROST OPERATION
All freezer models are equipped with an automatic, electric
defrost system consisting of electric evaporator coil and drain
pan heaters, a defrost time clock and an automatic defrost limit
switch. The defrost system is time initiated by the time clock and
temperature terminated by the automatic limit switch. The time
clock is preset for three (3) defrost periods per day at eight (8)
hour intervals and a fail safe cut-off time of 20 minutes. Please
note that defrost settings are not programmable.
FIGURE 12: Defrost Timer
INTERIOR ACCESSORIES
Your new unit is shipped with (1) shelf per section and (4) pilaster clips for each shelf.
SHELVING INSTALLATION
Pilaster strips which support the shelving are secured to the
cabinet walls with special pilaster screws which allow the strips
to be readily removed for cleaning without the use of tools. Shelf
clips are easily installed by inserting them into the pilasters at
the desired shelf location and shelf installation is as simple as
placing the shelf on the (see Figure 13).
FIGURE 13: Standard Shelf Pilaster
The defrost time clock is located in front of the electrical console box in the rear machine compartment of your freezer (see
Figure 12). If desired, to pre-set the initiation of the defrost
cycle to the time of day on the defrost time clock, turn the knob
on the center dial of timer face clockwise until the unit defrost
cycle begins (compressor and all fans will terminate). Defrost
will begin at this same time every day at eight (8) hour intervals.
For example, if an 8:00 am defrost is desired, at 8:00 am turn
the defrost manual set knob to initiate defrost and a defrost cycle
will start every day at 8:00 am, 4:00 pm, 12:00 am. It will be
necessary to reset the time of defrost on the timer if the freezer
is turned off or has loss of power.
12
OPERATIONS MANUAL
Page 13
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
CONDENSER COIL
REMOVE SCREWS
AT BOTTOM OF BACK PANEL
AND SLIDE DOWN TO REMOVE
ACCESSING CONDENSER COIL
FOR CLEANING
MAINTENANCE
SAFETY PRECAUTIONS
THE FOLLOWING SAFEGUARDS SHOULD BE FOLLOWED
WHEN OPERATING ANY APPLIANCES: DISCONNECT
THE POWER CORD BEFORE ATTEMPTING TO WORK ON
OR CLEAN EQUIPMENT. DISCONNECT POWER WHEN
THE APPLIANCE WILL BE IDLE FOR A LONG PERIOD OF
TIME. DO NOT ATTEMPT TO REMOVE ANY COVERS OR
PARTS YOURSELF, AS THIS CAN EXPOSE DANGEROUS,
HIGH VOLTAGE WIRING. SERVICE SHOULD ONLY
BE PERFORMED BY A QUALIFIED TECHNICAIN.
ALWAYS ROUTE POWER CORDS AWAY FROM AREAS
WHERE THEY CAN BE WALKED ON OR DAMAGED BY
OTHER EQUIPMENT. NEVER USE EXTENSION CORDS
OR PLUG MORE THAN ONE APPLIANCE INTO THE
SAME CIRCUIT. THIS CAN OVERLOAD THE POWER
SUPPLY, WHICH CAN RESULT IN ELECTRICAL SHOCK
OR FIRE. YOUR APPLIANCE IS EQUIPPED WITH A
POLARIZED, GROUNDED POWER PLUG. NEVER
ATTEMPT TO REMOVE THE GROUND POST OR USE
A NON-POLARIZED ADAPTER, WITHOUT PROPERLY
GROUNDING THE EQUIPMENT. IF A REPLACEMENT
PART IS REQUIRED, ALWAYS INSIST ON FACTORY
AUTHORIZED COMPONENTS.
PERIODIC CLEANING PROCEDURE
It is best to clean your refrigerator or freezer when the product
load in your cabinet is as its lowest level. To clean the interior or
exterior cabinet surfaces, follow these procedures:
1. Disconnect your model from its power supply and remove
all product from inside.
2. Open all doors and allow the cabinet to reach room temp-
erature. Remove all accessories (shelves, racks, pilasters,
clips, etc.) from within the model, wash with a baking soda
and warm water solution, and rinse thoroughly with clear
water. Dry all of the accessories completely with a soft
clean cloth.
3. Once the cabinet has reached room temperature, wash the
inside and outside with a solution of warm water and bak ing soda. For slightly more difficult cleanups, ammonia
or vinegar in warm water can be used. Rinse thoroughly
with clear water and dry with a soft clean cloth. Failure to
dry all surfaces completely may cause water stains or
streaking on the aluminum or stainless steel finish.
4. Return all accessories to their respective positions and
return electric supply power to the model.
PRECAUTIONS
NEVER USE HARSH DETERGENTS, CLEANERS,
SCOURING POWDERS, OR CHEMICALS WHEN
CLEANING YOUR UNIT. STRONG BLEACHES TEND TO
CORRODE MANY MATERIALS AND SHOULD NEVER
COME IN CONTACT WITH STAINLESS STEEL. TINCTURE
OF IODINE OR IRON SHOULD NOT COME IN CONTACT
WITH STAINLESS STEEL. THESE SOLUTIONS, WHICH
CAUSE STAINLESS STEEL TO DISCOLOR, SHOULD
BE RINSED OFF IMMEDIATELY IF CONTACT OCCURS.
GRITTY, HARD ABRASIVES WILL MAR THE FINISH
OF STAINLESS STEEL AND ALUMINUM AND ARE NOT
RECOMMENDED.
GENERAL PREVENTATIVE MAINTENANCE
Performance of the air cooled condensing unit located inside
of the compressor machine compartment of your new model,
depends exclusively upon the amount of air passing through
the condenser fins. Your refrigerator or freezer will run more
efficiently, consume less current, and provide a maximum of
trouble-free service throughout its lifetime if the condenser is
kept clean and an adequate supply of clean, cool air is provided
at all times. Periodically (at least once a month) inspect the condenser coil, which is located directly behind the rear panel grill,
to check for debris or blockage (see Figure 14).
If the condenser coil is dirty or blocked, disconnect the power
supply to your model and using a stiff brush, brush the dirt from
the condenser fins until the condenser is clear from any debris.
Using a vacuum cleaner with a brush attachment may aid in
this cleaning process. After cleaning, restore electrical service
to your model.
FIGURE 14: Accessing Coil Condenser
OPERATIONS MANUAL
13
Page 14
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
PARTS AND SERVICE
Continental Refrigerator is committed to providing the best customer service in the industry. All new units come with a Limited
Extended Protection Warranty (see “Warranty” section). If a
problem arises with your equipment, please contact our Service
Department at 1-800-523-7138 (extension 3301, 3302, or
3303). One of our Service Specialists will do everything possible
to solve the problem as quickly as possible.
ITEMS NOT COVERED UNDER WARRANTY INCLUDE, BUT ARE
NOT LIMITED TO:
Preventative maintenance:• cleaning condenser
coils and other components.
Consumables:• light bulbs, door gaskets, fuses
and batteries.
General hardware adjustments:• cabinet leveling,
casters/legs, doors/hinges.
Problems due to:• inadequate installation or sup-
ply power; improper maintenance, operation, or
abuse.
Compressor failure due to:• dirty condenser,
insufficient clearance/ventilation, excessive temperatures.
System adjustments and calibrations, including:•
temperature control, thermometer and expansion
valves.
Consult the Table of Contents in the front of this manual for detailed information on the items listed above.
Contact Continental’s Service Department with any
additional questions.
PLACING A SERVICE CALL
In order to receive prompt service, always be prepared to provide your: cabinet model and serial number; cabinet location
name and date installed; contact name and phone number; plus
a description of the problem.
During normal business hours (Monday to Friday, 8am to 5pm
Eastern) contact the Service Department at: 1-800-523-7138
(extension 3301, 3302, or 3303) prior to any warranty service
work being performed.
After normal business hours, or on weekends, notify our Service
Department by sending an email to: jcadwallader@nrac.com,
or leaving a voice message at: 1-800-523-7138 (extension
3301). Be sure to provide the information listed above. Contact
Continental the following business day, during normal business
hours, to verify the status of your call.
OBTAINING REPLACEMENT
PARTS UNDER WARRANTY
If replacement parts are required for a unit under warranty,
contact Continental’s Service Department. New parts will be
sent from the factory and, when applicable, a Return Goods
Authorization (RGA) number will be provided to return old parts.
The RGA number must appear on the packaging of any parts
returned, or they will not be accepted. If a service agent uses
a part from their stock, Continental will replace it with a factory
part.
OBTAINING REPLACEMENT
COMPRESSOR UNDER WARRANTY
If the compressor should fail within the first twelve (12) months
of use, or within twenty (20) months from the date code on the
compressor, an “over-the-counter” exchange must be made
at an authorized Copeland, Danfoss, Embraco, or Tecumseh
wholesaler.
After the first year of operation, the compressor motor is covered under an extended “parts only” warranty. The customer is
responsible for any labor charges and any additional parts that
may be required. Contact the Service Department to obtain a
replacement compressor through one of the following methods:
Continental will supply a replacement compressor •
at no charge and pay for regular freight. (If expedited freight is requested, the end user, dealer or
service agent is responsible for additional freight
charges and must provide credit card information.
A compressor can be purchased locally and •
Continental will either replace the stock unit with
a new factory compressor, or offer an allowance
towards the purchase of a replacement compressor, up to: $100 for 1/5hp to 1/3hp; $250 for
1/2hp to 3/4hp; $350 for 1hp to 2hp.
The data tag from the defective compressor (or the compressor model, serial number and date code, if the tag cannot be
removed) must be included with any request for reimbursement.
14
OPERATIONS MANUAL
Page 15
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
10-32 SCREWS
UPRIGHT
1/4-20 SCREWS
KEYHOLES
OPPOSITE
THESE HOLES
TOP SHELF
BOTTOM
SHELF
(NO NOTCHES IN BACK CORNERS)
OPTIONAL ACCESSORIES
Continental offers a variety of accessories for your unit.
INSTALLING OVERSHELF OR DOUBLE-OVERSHELF
IMPORTANT NOTE: Installing an overshelf is a two-per-
son job. Due to the weight, size and height of the shelf, do
not attempt to mount it alone, as this can cause injury.
To mount an overshelf to your cabinet, a phillips-head screwdriver (or a screw gun with phillips bit) is required. Before
starting to assemble the overshelf, identify the following parts
provided: ¼-20 screws, 10-32 screw, uprights, top shelf, and
bottom shelf (for double overshelves only). If applicable, determine the height you want the bottom to be located.
IMPORTANT NOTE: There are three pairs of holes provided in the iprights, so the shelf can be installed at a
height of 19”, 21”, or 23” above the top of the cabinet.
This height will also determine the distance between the
bottom shelf and the top shelf (13”, 15”, or 17”).
10-32 screws on each end. Drive the screws until snug, but do
not tighten them completely.
With one person supporting each end of the top shelf, list it
into position above the uprights and lower it down onto them.
Secure the shelf, using two 10-32 screws on each end, driving
them snugly but not tightly. Check the alignment of the shelves
and tighten all the screws. Double check that the shelves and
uprights are secured rigidly.
FIGURE 15: Overshelf Installation
From the back of your cabinet, locate the two holes with threaded inserts at each end of the Cabinet. (see Figure 15) Drive a
¼-20 screw into each of the (4) threaded inserts, until the bottom of the screw head is about ” away from the threaded insert.
Position the uprights at the back of the cabinet. Noting that
there are two keyhole slots on one face of each upright, locate
the keyholes at the bottom, facing the screws you just installed
in the cabinet. Lift the upright and place the large portion of
the keyhole slots over the screw heads and then lower it on to
the screws. Insert a philips screwdriver through the clearance
holes, on the opposite side of the keyhole slots (in the rear of
the uprights). Tighten the screws just until the upright is snug
against the unit, but leave a little play for alignment. Repeat this
procedure for the other upright.
To install a double overshelf (for single overshelf, skip to the
next paragraph) locate the bottom shelf, which has a large hole
in each rear corner. With one person holding each end of the
shelf, lift it above the top of the uprights and align it so the
large holes in the rear of the shelf fit over the uprights. Carefully
slide the shelf down, until the small holes on back of the shelf
line up with the correct holes in the uprights, depending on the
shelf height desired. Attach the shelf to the uprights, using two
INSTALLING STACKING COLLAR ADAPTER KIT
All models that are 48” wide or less and have a solid, flat top
can be stacked one on top of the other with the use of a heavy
duty, stainless steel stacking collar as shown in Figure 16. When
stacking a refrigerator and freezer, it is always best to place the
freezer model on the bottom for maximum efficiency. The front
grill which is attached to the stacking collar body is attached
with easily removable thumbscrews and should be removed
periodically for cleaning. The front grill should always be clean
and clear of debris and never blocked.
To stack your models, the following instructions should be followed:
1. Decide which unit is to be on “top” & “bottom”.
2. On “top” unit, remove screws at the bottom of the back
cover. In “bottom” unit, remove screws, joggle clips and
bumpers aloing the top back of the cabinet.
OPERATIONS MANUAL
15
Page 16
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
STACKING
COLLAR
GRILL
3. Install the legs on the “top” unit and adjust all four bullet
feet out (CCW) three full turns. Carefully lift the cabinet and
set it on top of the “bottom” unit.
4. Install stacking collar as shown in Figure 16, making sure
all rear screw hole slots line up on both top and bottom
models where screws were removed from in Step 2. If
screw hole slots do not line up (left to right) with screw
holes then the stacking collar has been mounted upside
down. Remove and re-install correctly.
5. Adjust the height and level of the “top” cabinet by reaching
in through the front opening of the stacking collar and turn ing the bullet feet on the legs in (CW) until the bottom of
the cabinet is snug against the stacking collar. Once snug,
install the rear screws that were removed in Step 2 and
peel off the adhesive tape backing strip around the side
flanges of the stacking collar so that both units are bonded
together.
6. Align the front grill holes with the stacking collar holes and
secure both thumbscrews.
FIGURE 16: Stacking Collar
INSTALLING FRONT BREATHER KIT (Skirt and Grill)
IMPORTANT NOTE: You may CAREFULLY lay the cabinet
on it’s back, but only FOR A BRIEF PERIOD OF TIME.
Caution must be taken to ensure you DO NOT DAMAGE
the louvered back panel, refrigeration system components, or copper tubing located behind the panel. The
cabinet must be properly blocked, to allow room to get
your hands in to lift without damaging the cabinet or
crushing the vents on the back panel. DO NOT PLUG-IN
OR OPERATE THE REFRIGERATION SYSTEM FOR AT
LEAST THREE (3) HOURS AFTER THE UNIT HAS BEEN
RETURNING IT TO AN UPRIGHT POSITION, AS THIS
CAN DAMAGE THE COMPRESSOR.
Position the left hand air duct/skirt (see Figure 17) as shown.
Attach the front left caster by inserting threaded end through the
slot in the air duct/skirt and screwing it into the threaded hole in
the bottom of the cabinet. Do not tighten completely. Repeat for
the back left caster. Follow these steps for the right hand air/duct
skirt and remaining casters. Position the front grill as shown
and attach it to the front edge of the air duct/skirts using the
thumbscrews provided. Adjust the position of the air duct/skirts
and the front grill as needed. Tighten the thumbscrews and all 4
casters completely. Carefully lift the cabinet upright and check
that the grill and casters are secure.
Your refrigerator or freezer is now front breathing and can be
completely enclosed on the sides, back and top. The refrigeration system will take in fresh air through one side of the front
grill, pull it under the cabinet, through compressor compartment
to cool the condenser, back out under the cabinet and exhaust it
through the other side of the front grill.
ANY RESTRICTIONS TO THE AIR FLOW THROUGH THE
FRONT GRILL OR UNDER THE CABINET CAN DAMAGE
THE REFRIGERATION SYSTEM AND WILL VOID ALL
WARRANTIES.
16
OPERATIONS MANUAL
Page 17
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
(2) THUMBSCREWS
FRONT GRILL
LEFT HAND
AIR DUCT/ SKIRT
RIGHT HAND
AIR DUCT/ SKIRT
(4) 3" CASTERS
NOTE: INSTALL
AIR DUCT/SKIRTS
WITH CUT-OUTS
TOWARD BACK
OF CABINET
CROSS
MULLION
FASTENERS
CAGE MOUNTING HOLES
SLOT
BREAKER CORNERS
NOTCHES WILL BE
SURROUNDING
BREAKER CORNERS
FIGURE 17: Front Breather Kit
INSTALLING DRAWER CAGE
To convert your cabinet from doors to drawers, you will need a
drill with a 1/8” bit, a Phillips bit (or a Phillips-Head screwdriver
(or drill/driver with Phillips bit), and a rubber mallet. Take the
door off the section you want to convert, by following instructions in the “Removal of Doors” section of this manual. Take the
drawers out of the mounting cage, by following instructions in
the “Removal of Drawers” section of this manual.
ing the front of the cage to the inside of the opening, and tighten
them snugly, without stripping the screws or the pilot holes.
Drive a sheet metal screw through each of the two slots located
at the lower the rear of the cage and into the back wall step of
the Cabinet.
IMPORTANT NOTE: These screws should NOT be tight!
The purpose of these screws is to limit the side-to-side
movement of the rear of the cage, not to rigidly secure the
cage to the cabinet.
To re-install the drawers into the cabinet, follow the instructions
in the “Removal of Drawers” section of this manual. Note that
the top drawer slides are longer than the bottom slides.
FIGURE 18: Drawer Cage
Position the drawer mounting cage in front of the cabinet opening as shown (see Figure 18). Lift the cage above the trim along
the bottom of the opening, so it is aligned to go straight into the
cabinet. Carefully slide the drawer cage into the unit opening. It
is a snug fit and some pressure may be need to be applied at
the corners, to clear the breaker around the opening. A rubber
mallet can be used to gently tap on the ends of the drawer cage
cross mullion, to force the fasteners past the side breakers. The
straighter the cage is pushed in, the easier it will be to install.
When the cage is in as far as it will go, the notches at the front
of the cage should surround the breaker corners at the bottom.
The face of the drawer cross mullion should be relatively flush
with the front face of the cabinet, to provide an even surface for
the drawer gaskets to seal properly around the openings. The
cage should sit relatively flat on the floor and against the back
wall step inside the cabinet.
With the cage properly in place, use the holes along the front
sides of the cage assembly as a template to drill (6) 1/8” pilot
holes through side breakers and the metal underneath. Drive a
sheet metal screw into each of the front mounting holes, secur-
MOUNTING CASTER SUPPORT PLATES
If the standard stem casters on a cabinet are not properly maintained and tightened, or if the unit is excessively overloaded and
moved around, the threaded inserts in the bottom of the cabinet
can become stripped, twisted or collapsed. If this occurs and
the stem casters cannot be mounted securely, rigid caster support plates can be fitted to provide the strength needed to safely
use your cabinet. Each caster support plate assembly is made
of heavy gauge galvanized steel, with (2) casters permanently
welded to it, for maximum rigidity. The plate has a series of
holes that will allow you to fasten the plate assembly to the bottom of the cabinet with sheet metal screws and bolts. Contact
the factory to obtain the correct parts for your model.
OPERATIONS MANUAL
17
Page 18
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
SUPPORT ASSEMBLY
WITH PLATE CASTER
1/2-13 BOLT
(2 PER PLATE)
FLAT WASHER
(2 PER PLATE)
REMOVE OLD
STEM CASTERS
BOTTOM
OF CABINET
IMPORTANT NOTE: Always wear proper work gloves and
use appropriate safety equipment. You may CAREFULLY
lay the cabinet on it’s back, but only FOR A BRIEF
PERIOD OF TIME. Caution must be taken to ensure you
DO NOT DAMAGE the louvered back panel, refrigeration
system components, or copper tubing located behind the
panel. The cabinet must be properly blocked, to allow
room to get your hands in to lift without damaging the
cabinet or crushing the vents on the back panel. DO NOT
PLUG-IN OR OPERATE THE REFRIGERATION SYSTEM
FOR AT LEAST THREE (3) HOURS AFTER THE UNIT HAS
BEEN RETURNING IT TO AN UPRIGHT POSITION, AS
THIS CAN DAMAGE THE COMPRESSOR.
To install caster support plate assemblies, you will need a 3/4”
open end wrench (or a large adjustable wrench), a drill with a
1/8” bit and a Phillips bit (or a Phillips-Head screwdriver) plus
work gloves. A 1/2-13 thread tap is also recommended, to repair
any damage to the threaded inserts in the cabinet. Unload all
product and carefully lay the cabinet on its back. Remove the old
stem casters by unscrewing them from the cabinet. If a caster or
threaded insert has been stripped or cross-threaded, it may be
necessary to use a wrench to loosen the caster.
system back on, and at least another 30 minutes for the cabinet
to come down to temperature and stabilize, before reloading
with product.
FIGURE 19: Caster Support Plates
Hold one of the support plate assemblies under the cabinet as
shown (see Figure 19). Position it so the slotted holes at the end
of the plate line up with the threaded inserts in the bottom of the
cabinet (where the stem casters were attached). Attach the plate
assembly to the cabinet by putting a 1/2” x 1-3/4” long bolts and
flat washer through the slot in the support plate and screwing
into each of the threaded inserts in the bottom of the cabinet.
Snug the bolts down, but do not tighten them completely. If
one of the threaded inserts is stripped or damaged, a thread tap
should be used to clean the threads.
Using the small holes in the plate as a template, drill 1/8 pilot
holes in the bottom of the cabinet. (Note: drill only until you
penetrate the metal bottom of the cabinet. Do not continue
to drill into the insulation, or you may damage the cabinet.)
Secure the caster support plate assembly to the cabinet with a
sheet metal screw in each of the drilled holes. Tighten the 1/2”
bolts. Repeat these steps to attach the other plate assembly to
the opposite end of the cabinet.
Check that both plates are secure and that the casters turn
and swivel freely. Carefully lift the cabinet upright and double
check that the caster support plates are secure and the cabinet
is stable. Wait at least 3 hours before turning the refrigeration
INSTALLING ELECTRIC CONDENSATE VAPORIZER
The electric condensate vaporizer has a power cord attached and
is provided with a mounting bracket and two hold-down clips. To
install the vaporizer, remove the screws securing the back cover
to the cabinet (see Figure 20) and set the cover aside. Remove
the old drain pan and install the vaporizer mounting bracket on
the rail next to the compressor. Slide the vaporizer pan onto
the bracket and carefully place the end of the plastic drain tube
into the pan. Make sure the tubing is not blocked or kinked and
that the end is located securely, so any water running out of the
tube will go into the pan. Secure the pan with the clips provided
and plug the power cord into the receptacle labeled “Vaporizer”
on the lower back wall of the cabinet. Secure any excess power
cord with a wire tie, so it does not fall into the pan or under the
cabinet. Reattach the cover to the back of the cabinet.
IMPORTANT NOTE: It is extremely important to ensure
the condensate pan is plugged into the receptacle labeled
“vaporizer” and that the condensing unit is plugged into
the receptacle labeled “condensing unit.”
18
OPERATIONS MANUAL
Page 19
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
ELECTRIC VAPORIZER
CAN BE PLUGGED INTO
THE SUPPLIED OUTLET
LABELED "VAPORIZER"
VAPORIZER PAN
RESTS ON RAILS,
NEXT TO COMPRESSOR
FIGURE 20: Electric Condensate Vaporizer
REMOTE SET-UP AND INSTALLATION GUIDELINES
All remote refrigerators and freezers are shipped with an expansion valve, thermostat and defrost timer (freezer only), installed
from the factory. The installer is responsible for connecting all
refrigerant lines, liquid line drier, sight glass, solenoid, head
pressure control, hi/low pressure safety, crankcase heater, condensing unit and any other accessories as well as wiring. The
evaporator section has been factory leak checked with helium,
however; due to vibration in transit, the entire system must be
thoroughly leak checked after installation and prior to start-up.
The final leak inspection of the entire completed refrigeration
system and all of its components as well as start-up and the
operation of the refrigeration system is the sole responsibility
of the installer.
All refrigerant lines and components must be clean, free of 1.
burrs and purged with nitrogen prior to and during brazing
or soldering connections. Nitrogen purging during brazing or soldering will eliminate carbon or foreign matter
contamination. Any system restrictions or contamination is
the responsibility of the installer.
Condensing unit or compressor shall not be left open to 2.
the atmosphere for more than five (5) minutes.
No refrigeration component, tubing or fitting shall be left 3.
open to the atmosphere for more than ½ hour without
being soldered, capped or plugged.
Each completed refrigeration system shall be purged with 4.
150psi of dry nitrogen for at least six (6) seconds, then
pressurized with at least 165psi of nitrogen for pressure
check (making sure to energize any solenoid valves to
assure access). Leak-check all joints, flare fittings and
valves and make sure there is no pressure drop within the
system.
System evacuation is of the utmost importance with NON-5.
CFC refrigerant systems. System must be evacuated to a
minimum of 200 microns. In addition, a vacuum decay
test is strongly recommended to assure there is not a
large pressure differential between the system and the
vacuum pump. System must be evacuated from both high
and low sides of the system using heavy duty vacuum
hoses.
Each system should be charged with the refrigerant type 6.
as specified on the cabinet data tag. This refrigerant type
should match the type listed on the condensing unit being
used. The refrigerant charge should be held to the minimum required for the satisfactory pull down and operation. For an accurate indication of refrigerant charge, the
sight glass will show a full column of liquid.
The superheat reading taken 6” from the compressor suc-7.
tion valve should be 30° +/- 5°. Expansion valve adjustment may be necessary to achieve this superheat.
Installation of the electric condensate vaporizer is also 8.
the responsibility of the installer (see “Installing Electric
Condensate Vaporizer” under “optional Accessories”).
The CFC-Free refrigerant used in standard remote and self-contained models is R-134a for refrigerators and R-404a for freezers. All compressors and systems designed for these refrigerant
utilize polyolester oil as their main lubricant, which absorbs
moisture from the ambient surroundings extremely fast and
in much greater quantity than conventional mineral oils. Since
moisture levels greater than 100 PPM will result in system corrosion and ultimate failure, it is imperative that the compressor,
components and entire system be kept sealed.
CAUTION: EXTREME CARE MUST BE USED WHEN
ACCESSING THE SYSTEM DURING INSTALLATION. DUE
TO THE COMPLEXITY OF REMOTE REFRIGERATION
SYSTEMS AND THE POTENTIAL FOR IMPROPER
INSTALLATION, ANY RESTRICTIONS, LEAKS, FAILED OR
DAMAGED COMPONENTS CAUSED BY CONTAMINANTS
ARE NOT THE RESPONSIBILITY OF CONTINENTAL
REFRIGERATOR.
OPERATIONS MANUAL
19
Page 20
TROUBLESHOOTING GUIDE
PROBLEM PROBABLE CAUSE CORRECTION
Condensing unit will not
start - no hum.
Condensing unit will not
start - hums but trips on
overload protector.
Condensing unit starts
and runs, but short
cycles on overload
protector.
Condensing unit starts,
but fails to switch off of
“start” winding.
Condensing unit runs,
but short cycles on:
Condensing unit runs,
but for prolonged periods or continuous.
1. Line disconnected, switch open.
2. Fuse removed or blown.
3. Overload protector blown.
4. Control “Off” due to cold location.
5. Control stuck in open position.
6. Wiring improper or loose.
1. Improperly wired.
2. Low voltage to unit.
3. Starting capacitor defective.
4. Relay failing to close.
5. Compressor motor has a shorted or open
winding.
6. Internal mechanical trouble in compressor.
7. Insufficient air supply.
1. Additional current passing through overload
protector.
2. Low voltage unit.
3. Overload protector defective.
4. Run capacitor defective.
5. Excessive discharge pressure.
6. Excessive suction pressure.
7. Insufficient air supply.
1. Improperly wired.
2. Low voltage to unit.
3. Relay failing to open.
4. Run capacitor defective.
5. Excessively high discharge pressure.
6. Compressor motor has a shorted or open
winding.
7. Internal mechanical trouble in compressor.
1. Overload protector.
2. Thermostat.
3. High pressure cut-out due to:
(a) Insufficient air supply.
(b) Overcharge.
(c) Air in system.
4. Low pressure cut-out due to:
(a) Valve leak.
(b) Undercharge.
(c) Restriction in expansion device.
1. Shortage of refrigerant.
2. Control contacts stuck closed.
3. Excessive heat load placed into cabinet.
4. Prolonged or too frequent door openings.
5. Evaporator coil iced.
6. Restriction in refrigeration system.
7. Dirty condenser.
8. Filter drier clogged.
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
1. Close start or disconnect switch.
2. Replace Fuse.
3. Determine reason and correct/replace.
4. Relocate control.
5. Repair or replace control.
6. Check wiring against diagram.
1. Check wiring against diagram.
2. Determine reason and correct.
3. Determine reason and replace.
4. Determine reason and replace.
5. Replace compressor.
6. Replace compressor.
7. Clear condenser and allow compressor
to cool down.
1. Check wire diagram. Check for added
components connected to wrong side of
overload protector.
2. Determine reason and correct.
3. Check current, replace protector.
4. Determine reason and replace.
5. Check ventilation, restrictions in cooling
medium or refrig. system.
6. Check for misapplication.
7. Clear condenser and allow compressor
to cool down.
1. Check wiring against diagram.
2. Determine reason and correct.
3. Determine reason and replace.
4. Determine reason and replace.
5. Check discharge shut-off valve, possible
overcharge.
6. Replace compressor.
7. Replace compressor.
1. See Problem 3
2. Differential must be widened.
3.
(a) Check air supply to condenser.
(b) Evacuate and re-charge.
(c) Evacuate and re-charge.
4.
(a) Replace, evecuate and re-charge.
(b) Evacuate and re-charge.
(c) Replace expansion device.
1. Fix leak, evacuate and re-charge.
2. Clean contacts or replace control.
3. Allow unit sufficient time for removal of latent
heat.
4. Plan or organize schedule to correct condition.
5. Defrost evaporator coil.
6. Determine location and remove.
7. Clean condenser coil.
8. Replace, evacuate and re-charge.
20
OPERATIONS MANUAL
Page 21
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
TROUBLESHOOTING GUIDE
PROBLEM PROBABLE CAUSE CORRECTION
Start capacitor open,
shorted or blown.
Run capacitor open,
shorted or blown.
Relay defective or blown
out.
Product zone
temperature too high.
Suction line frosted or
sweating.
Liquid line frosted, cold
or sweating.
Noisy condensing unit. 1. Loose parts or mounting.
Thermometer reads
different than actual
temperature.
Water leak inside unit. 1. Condensate drain pan not installed properly.
Doors misaligned. 1. Shifted during shipping. 1. Refer to Operation Manual for hinge
1. Relay contact not opening properly.
2. Prolonged operation on start cycle:
(a) Low voltage to unit.
(b) Improper relay.
(c) Starting load too high.
3. Excessive short cycling.
4. Improper capacitor.
1. Improper capacitor.
2. Excessively high line voltage, over 110%
of rated maximum.
1. Incorrect Relay.
2. Incorrect mounting angle.
3. Voltage too low or too high.
4. Excessive short cycling.
5. Loose or vibrating mounting position.
6. Incorrect run capacitor.
7. Loose wiring on relay or overload.
1. Control setting too high.
2. Inadequate air circulation.
3. Dirty condenser.
1. Overcharge of refrigerant.
2. Evaporator fan not running.
3. Expansion valve stuck open.
4. Expansion valve superheat too low.
1. Restriction in drier strainer.
2. Liquid line service valve partially closed.
2. Tubing rattle or vibration.
3. Bent fan blade causing excessive vibration.
4. Fan bearings worn.
1. Calibration.
2. Defective.
2. Unit not level.
3. Drain pan misaligned.
4. Defective drain pan.
1. Clean contacts or replace relay.
2.
(a) Determine reason and correct.
(b) Replace with correct relay.
(c) Correct by using pump down.
3. Determine reason for short cycle, see Problem
5 and correct.
4. Determine correct size and replace.
1. Check size and replace.
2. Determine reason and correct.
1. Check relay and replace.
2. Remount relay in correct position.
3. Determine reason and correct.
4. Determine reason and correct (see Problem 5).
5. Remount rigidly.
6. Replace with proper capacitor.
7. Tighten all wiring screws.
1. Adjust T-stat.
2. Rearrange product load to improve air
circulation.
3. Clean condenser coil.
1. Evacuate and re-charge.
2. Determine reason and correct.
3. Clean valve, evacuate and re-charge.
4. Adjust superheat to required setting.
1. Replace drier, evacuate and re-charge.
2. Open valve fully or replace if necessary.
1. Tighten all mounting parts and shroud cover.
2. Reform tubing to be free of contact.
3. Replace fan blade.
4. Replace fan motor.
1. Consult Operations Manual and calibrate.
2. Replace.
1. Consult Operations Manual for install
instructions.
2. Make sure unit is level or pitched back slightly.
3. Make sure drain pan is aligned properly.
4. Replace.
adjustment.
OPERATIONS MANUAL
21
Page 22
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
SELF-CONTAINED UNDERCOUNTER REFRIGERATOR
WIRING DIAGRAM
115/60/1
22
OPERATIONS MANUAL
Page 23
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
SELF-CONTAINED UNDERCOUNTER FREEZER
WIRING DIAGRAM
115/60/1
OPERATIONS MANUAL
23
Page 24
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
LIMITED EXTENDED PROTECTION WARRANTY
This Continental Refrigerator product is warranted to be free from all manufacturing defects, material or workmanship, for a
period of one (1) year from date of original installation, or fifteen (15) months from date of shipment, whichever occurs first. All
motor-compressor assemblies are warranted to be free from defects, material and workmanship, for a period of five (5) years
from date of installation. The term “motor-compressor assembly” does not include unit base, air or water cooled condenser,
receiver, electrical accessories such as relay, capacitors, pressure control or condenser fan/motor assembly, etc.
Continental Refrigerator will not be responsible for the costs of transportation or mileage, costs of labor for removal or installation, and costs of parts supplied by third parties. This warranty does not apply to damage or failure resulting from normal wear
and tear, (including failure to clean and/or maintain product), to damage due to misuse and abuses or resulting from tampering
or unauthorized alterations or service, to damage in transit by accident or neglect, or to replacement of breakable components
such as glass, plastics or porcelain.
THERE ARE NO OTHER WARRANTIES, EITHER WRITTEN, ORAL OR IMPLIED. CONTINENTAL MAKES NO
WARRANTY OF MERCHANTABILITY OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE.
THIS WARRANTY IS FREE OF CHARGE. THIS INCLUDES THE ONE (1) YEAR PARTS AND LABOR AND FIVE
(5) YEAR COMPRESSOR.
THE OBLIGATION OF CONTINENTAL REFRIGERATOR UNDER THIS WARRANTY IS LIMITED TO THE
REPLACEMENT OR REPAIR OF ANY DEFECTIVE PART WHICH, UPON INSPECTION BY CONTINENTAL
REFRIGERATOR, IS DEEMED TO BE DEFECTIVE.
THIS WARRANTY IS FOR THE BENEFIT OF THE ORIGINAL PURCHASER-USER ONLY, AND CANNOT BE
ASSIGNED. THIS WARRANTY APPLIES ONLY TO A UNIT INSTALLED IN THE CONTINENTAL UNITED
STATES. THE ORIGINAL PURCHASER-USER SHALL BE DEEMED TO MEAN THE PERSON, FIRM,
ASSOCIATION, OR CORPORATION FOR WHOM THE EQUIPMENT WAS ORIGINALLY INSTALLED.
OTHER LIMITATIONS - ALL WARRANTY CLAIMS MUST INCLUDE THE FOLLOWING INFORMATION
ABOUT THE PRODUCT COVERED BY THIS WARRANTY: MODEL NUMBER, SERIAL NUMBER, PROOF OF
PURCHASE, INSTALLATION DATE, AND ALL PERTINENT INFORMATION SUPPORTING THE ALLEGATION
OF DEFECT. UPON THE REQUEST OF CONTINENTAL, PURCHASER-OWNER SHALL RETURN THE PART OR
PARTS TO CONTINENTAL, FREIGHT PREPAID, FOR INSPECTION. THE MOTOR-ASSEMBLY WARRANTY
SHALL ONLY APPLY TO REFRIGERATORS AND FREEZERS PURCHASED WITH AN INSTALLATION
CONTRACT AND MINIMUM OF ONE-YEAR SERVICE CONTRACT BY A REPUTABLE REFRIGERATION
SERVICE ORGANIZATION.
24
A Division of National Refrigeration & Air Conditioning Products, Inc.
539DunksferryRoad•Bensalem,PA19020-5908
P215-244-1400•1-800-523-7138•F215-244-9579
www.continentalrefrigerator.com
OPERATIONS MANUAL
Page 25
WORKTOP/UNDERCOUNTERS & SANDWICH UNITS
MODEL # __________________________________________SERIAL # _______________
Notes: ______________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
OPERATIONS MANUAL
25
Page 26
Page 27
Page 28
®
A Division of National Refrigeration & Air Conditioning Products, Inc.
539DunksferryRoad•Bensalem,PA19020-5908
P215-244-1400•1-800-523-7138•F215-244-9579
www.continentalrefrigerator.com
Manual #50185 - Rev 06/10
Loading...
