Table of contents
enInstruction manual
8 Intended use . . . . . . . . . . . . . . . . 5
( Safety instructions. . . . . . . . . . . . 5
Before you switch ON
the appliance . . . . . . . . . . . . . . . . . . 5
Delivery. . . . . . . . . . . . . . . . . . . . . . . . 5
Installation. . . . . . . . . . . . . . . . . . . . . . 6
In daily use . . . . . . . . . . . . . . . . . . . . . 7
Door lock . . . . . . . . . . . . . . . . . . . . . . 7
Button lock . . . . . . . . . . . . . . . . . . . . . 8
Damage . . . . . . . . . . . . . . . . . . . . . . . 9
Disposal . . . . . . . . . . . . . . . . . . . . . . . 9
7 Environmental protection . . . . . 10
Packaging. . . . . . . . . . . . . . . . . . . . . 10
Old appliances . . . . . . . . . . . . . . . . . 10
* Getting to know
your appliance . . . . . . . . . . . . . . 11
Control panel . . . . . . . . . . . . . . . . . . 11
Appliance interior . . . . . . . . . . . . . . . 11
Overview of menu. . . . . . . . . . . . . . . 12
+ Water softening system /
special salt . . . . . . . . . . . . . . . . . 13
Water hardness table . . . . . . . . . . . . 13
Adjusting the
water softening system . . . . . . . . . . . 13
Using special salt . . . . . . . . . . . . . . . 13
Detergent with a salt component . . . 14
Switching off water softening unit . . . 14
, Rinse aid . . . . . . . . . . . . . . . . . . . 14
Setting amount of rinse aid. . . . . . . . 15
Detergent with a
rinse aid component. . . . . . . . . . . . . 15
Switching off
rinse aid refill indicator . . . . . . . . 15
en
- Utensils. . . . . . . . . . . . . . . . . . . . 16
Not suitable . . . . . . . . . . . . . . . . . . . . 16
Glass and utensil damage. . . . . . . . . 16
Loading the dishwasher . . . . . . . . . . 16
Upper basket. . . . . . . . . . . . . . . . . . . 16
Lower basket. . . . . . . . . . . . . . . . . . . 17
Cutlery basket . . . . . . . . . . . . . . . . . . 17
Cutlery drawer . . . . . . . . . . . . . . . . . . 17
Etagere . . . . . . . . . . . . . . . . . . . . . . . 18
Folding spikes . . . . . . . . . . . . . . . . . . 19
Small items holder. . . . . . . . . . . . . . . 19
Knife rack . . . . . . . . . . . . . . . . . . . . . 19
Baking sheet spray head. . . . . . . . . . 20
Unloading the dishwasher . . . . . . . . . 20
Adjusting the height of the basket. . . 20
. Detergent . . . . . . . . . . . . . . . . . . 22
Adding detergent. . . . . . . . . . . . . . . . 22
Combination detergent . . . . . . . . . . . 23
/ Overview of programmes . . . . . 25
Programme selection . . . . . . . . . . . . 26
Information for test institutes . . . . . . . 26
0 Additional functions . . . . . . . . . 27
Save time (VarioSpeedPlus) . . . . . . . 27
Half load . . . . . . . . . . . . . . . . . . . . . . 27
hygienePlus (HygienePlus) . . . . . . . . 27
intensiveZone . . . . . . . . . . . . . . . . . . 27
extraDry . . . . . . . . . . . . . . . . . . . . . . . 27
Shine and Dry . . . . . . . . . . . . . . . . . . 27
Energy Save . . . . . . . . . . . . . . . . . . . 27
3
en
1 Operating the appliance . . . . . . 28
Programme data . . . . . . . . . . . . . . . . 28
AquaSensor . . . . . . . . . . . . . . . . . . . . 28
Switching on the appliance . . . . . . . . 28
Remaining running time display. . . . .28
Time preselection . . . . . . . . . . . . . . .29
Programme end. . . . . . . . . . . . . . . . . 29
Auto Power Off . . . . . . . . . . . . . . . . .29
Switching off the appliance . . . . . . . . 30
Interrupting the programme . . . . . . . . 30
Terminating the programme . . . . . . .30
Changing the programme . . . . . . . . .30
ExtraDry . . . . . . . . . . . . . . . . . . . . . . . 31
2 Cleaning and maintenance . . . 31
Overall status of the dishwasher . . . . 31
Machine Care . . . . . . . . . . . . . . . . . .32
Special salt and rinse aid . . . . . . . . .33
Filters. . . . . . . . . . . . . . . . . . . . . . . . .33
Spray arms . . . . . . . . . . . . . . . . . . . .34
3 Fault, what to do? . . . . . . . . . . .34
Waste water pump . . . . . . . . . . . . . . 35
Fault table . . . . . . . . . . . . . . . . . . . . 36
4 Customer service . . . . . . . . . . . .45
5 Installation and connection. . . .45
Contents of package . . . . . . . . . . . . 45
Safety instructions . . . . . . . . . . . . . . 45
Delivery . . . . . . . . . . . . . . . . . . . . . . 46
Technical specifications . . . . . . . . . . 46
Installation . . . . . . . . . . . . . . . . . . . . 46
Drainage connection . . . . . . . . . . . . 46
Drinking water connection . . . . . . . . 47
Hot water connection . . . . . . . . . . . . 47
Electrical connection . . . . . . . . . . . . 48
Removal . . . . . . . . . . . . . . . . . . . . . . 48
Transporting . . . . . . . . . . . . . . . . . . . 49
Protection against frost
(Emptying the appliance) . . . . . . . . . 49
4
Intended use en
8 Intended use
I nt ended use
■ This appliance is intended
for use in the home and
domestic environments.
■ Use the dishwasher only in
the home and only for its
designated purpose: for
washing domestic dishes.
■ This appliance is intended
for use up to a maximum
altitude of 4000 metres
above sea level.
( Safety instructions
Safety instructions
This appliance may be used by
children over the age of 8 years
old and by persons with
reduced physical, sensory or
mental capabilities or by
persons with a lack of
experience or knowledge if they
are supervised or are instructed
by a person responsible for
their safety how to use the
appliance safely and have
understood the associated
hazards.
Children must not play with, on,
or around the appliance.
Children must not clean the
appliance or carry out general
maintenance unless they are at
least 8 years old and are being
supervised.
Keep children below the age of
8 years old at a safe distance
from the appliance and power
cable.
Before you switch ON the
appliance
Please read the instructions for
use and installation carefully.
They contain important
information on how to install,
use and maintain the appliance.
Retain all documents for later
use or for the subsequent
owner.
You can download the
instructions for use from our
website free of charge. The
relevant Internet address can
be found overleaf on these
instructions for use.
Delivery
1. Check the packaging and
dishwasher immediately for
damage caused in transit.
Do not switch on a damaged
appliance, but contact your
supplier.
2. Please dispose of the
packaging material in an
environmentally friendly
manner.
3. Do not let children play with
packaging and its parts.
There is a risk of suffocation
from collapsible boxes and
film.
5
en Safety instructions
Installation
■ Following installation, ensure
that the back of the
dishwasher is not freely
accessible (protection
against contact due to hot
surface).
■ Install and connect the
appliance according to the
installation and assembly
instructions.
■ Prior to installation,
disconnect the dishwasher
from the power supply.
■ Ensure that the protective
conductor system of the
domestic supply has been
correctly installed.
■ The electrical connection
conditions must correspond
with the specifications on the
dishwasher rating plate 9:.
■ If the power cord of this
appliance is damaged, it
must be replaced with a
particular power cord.
To prevent injury, the power
cord may be purchased from
customer service only.
■ If the dishwasher is installed
in a high-sided unit, the unit
must be secured properly.
■ If the dishwasher is installed
below or above other
domestic appliances, follow
the information for
installation in combination
with a dishwasher in the
installation instructions for
the particular appliances.
■ Also follow the installation
instructions for the
dishwasher to ensure that all
appliances are operated
safely.
■ If there is no information or if
the installation instructions
do not include the
appropriate information,
contact the manufacturer of
these appliances to ensure
that the dishwasher can be
installed above or below
these appliances.
■ If you cannot obtain any
information from the
manufacturer, you must not
install the dishwasher above
or below these appliances.
■ If you install a microwave
oven above the dishwasher,
the microwave oven may be
damaged.
■ Install built-under or
integratable appliances only
under continuous worktops
which have been screwed to
adjacent cupboards to
ensure stability.
■ Do not install the appliance
near heat sources (radiators,
heat storage tanks, cookers
or other appliances which
generate heat) and do not
install under a hob.
6
Safety instructions en
■ Please note that the
insulation material of the
dishwasher power cord may
melt next to heat sources
(e.g. heating / hot water
installations) or hot
appliance parts. Make sure
that the power cord of the
dishwasher never comes into
contact with heat sources or
hot appliance parts.
■ After installing the appliance,
ensure that the plug is easily
accessible. ~ "Electrical
connection" on page 48
■ For some models:
The plastic housing on the
water connection contains an
electric valve. The supply
hose contains electrical
connection cables. Do not
cut through the supply hose.
Do not immerse the plastic
housing in water.
In daily use
Read and observe the safety
information and instructions for
use on the packaging for
cleaning and rinsing agents.
Childproof lock (door lock) *
Door lock
The child-proof lock (door lock)
protects children from potential
hazards which the dishwasher
poses.
:Warning
Risk of suffocation!
Children may become locked in
the dishwasher and suffocate.
Always completely close the
appliance door when leaving
the dishwasher.
Activate the child-proof lock
(door lock) as follows:
1. Pull the catch of the
child-proof lock towards
yourself (1).
2. Close the door (2).
The child-proof lock is
activated.
7
en Safety instructions
Open the door with activated
child-proof lock (door lock) as
follows:
1. Press the catch of the
child-proof lock to the right
(1).
2. Open the door (2).
Deactivate the child-proof lock
(door lock) as follows:
1. Press the catch of the
child-proof lock to the right
(1).
2. Press the catch of the
child-proof lock backwards
(2).
The childproof lock is
deactivated.
Childproof lock (button lock)
But to n lock
You can prevent your
dishwasher being switched off
inadvertently (e.g. by children
pressing the buttons).
Here’s how to activate the
button lock:
1. Start the desired
programme.
2. Press and hold the F button
for about 4 seconds.
In the display window you
will see ’–.
The button lock has now been
activated.
If any of the buttons are
pressed while the programme
is running, ’– will appear in the
display window. It is not
possible to cancel the
programme (Reset).
To deactivate the button lock,
hold down the F button for
about 4 seconds until ’–
disappears from the display
window.
The button lock is cancelled
automatically at the end of the
programme. In the event of a
power failure, the button lock
will be maintained. You need to
reactivate the button lock at the
beginning of every programme.
* depending on the features of
your dishwasher
8
Safety instructions en
Damage
■ The appliance may be
repaired and opened up by a
technician only. To do this,
disconnect the appliance
from the power supply. Pull
out the mains plug or switch
off the fuse. Turn off the tap.
■ If the appliance is damaged,
especially the control panel
(cracks, holes, broken
buttons), or the door function
is impaired, stop operating
the appliance. Pull out the
mains plug or switch off the
fuse. Turn off tap, call
customer service.
Disposal
1. Make redundant appliances
unusable to prevent
subsequent accidents.
2. Dispose of the appliance in
an environmentally friendly
manner.
:Warning
Risk of injury!
■ To prevent injuries, e.g.
caused by stumbling, open
the dishwasher only briefly in
order to load and unload the
dishwasher.
■ Knives and other utensils
with sharp points must be
placed with the points
downwards in the cutlery
basket*1b or horizontally
on the knife shelf* or in the
cutlery drawer*1*.
■ Do not lean or sit on the
open door.
■ In the case of free-standing
appliances, ensure that the
baskets are not overloaded.
The appliance could tip.
■ If the appliance is not in a
cavity and a side panel is
accessible, the door hinge
area must be covered at the
side for reasons of safety
(risk of injury). The covers
are available as optional
accessories from customer
service or specialist outlets.
* depending on the features of
your dishwasher
:Warning
Risk of explosion!
Do not add any solvents to the
rinsing compartment. Danger of
explosion!
:Warning
Risk of scalding!
Open the door carefully when
the programme is still running.
There is a risk of hot water
spraying out of the appliance.
:Warning
Risk to children!
■ If fitted, use the childproof
lock.
■ Do not allow children to play
with or operate the
appliance.
9
en Environmental protection
■ Keep children away from
detergents and rinse aid.
These may cause chemical
burns in the mouth, throat
and eyes or asphyxiation.
■ Keep children away from
open dishwasher. There may
be small parts in the
dishwasher which children
could swallow and the water
inside the dishwasher is not
drinking water as it may
contain detergent residue.
■ Ensure that children do not
place fingers in the tablet
collecting tray 1B. Small
fingers could become caught
in the slots.
■ When opening and closing
the door on an eye-level
appliance, ensure that
children do not become
jammed or crushed between
the appliance door and the
cupboard door below.
■ Children could become
locked in the appliance
(danger of suffocation) or get
into another dangerous
situation.
Redundant appliances: Pull
out the mains plug, sever
and dispose of the power
cord. Destroy the door lock
so that the door can no
longer be closed.
7 Environmental
protection
Envi r on ment al prot ecti on
Both the packaging of new appliances
and the old appliances themselves
contain valuable raw materials and
recyclable materials.
Please dispose of the individual parts
separated according to type.
Please ask your dealer or inquire at
your local authority about current means
of disposal.
Packaging
All plastic parts of the appliance are
identified with internationally
standardised abbreviations (e.g. PS
polystyrene). Therefore, plastic waste
can be sorted out when the appliance is
being disposed of.
Please follow the safety instructions
under “Delivery” ~ Page 5.
Old appliances
Please follow the safety instructions
under “Disposal of your appliance”
~ Page 9.
This appliance has been
identified in accordance with the
European Directive 2012/19/EU
on Waste Electrical and
Electronic Equipment (WEEE).
The directive provides a
framework for the collection and
recycling of old appliances,
which is valid across the EU.
10
Getting to know your appliance en
* Getting to know your
appliance
Gett i ng to know your appl i ance
Diagrams of the control panel and the
interior of the appliance can be found at
the front of the manual. Individual
positions are referred to in the text.
Control panel
See Fig. ~ Page 2
( On/off switch
0 Programme buttons **
8 Door opener
@ Time preselection
H Additional functions/programme
buttons **
P START button
X Display "Check water supply"
` Salt refill indicator
h Rinse aid refill indicator
)" Display window
* depending on the features of your
dishwasher
** number depending on the features of
your dishwasher
Appliance interior
See Fig. ~ Page 2
1" Interior light *
1* Cutlery drawer *
12 Top basket
1: Upper spray arm
1B Tablet collecting tray
1J Lower spray arm
1R Dispenser for special salt
1Z Filters
1b Cutlery basket *
1j Bottom basket
9" Dispenser for rinse aid
9* Detergent dispenser
92 Lock for detergent dispenser
9: Rating plate
* depending on the features of your
dishwasher
11
en Getting to know your appliance
Overview of menu
The settings can be found in the
individual chapters. You can change
The dishwasher has been preset with
these factory settings.
certain settings for your convenience.
Setting up Factory setting Description
• Water hardness
•:‹… Setting water hardness. When using
Multitabs, select the lowest setting.
•:‹‹ - •:‹ˆ
§ Rinse aid
§:‹† Amount of rinse aid affects drying. When
using Multitabs, select setting 0.
§:‹‹ - §:‹‡
š ExtraDry
š:‹‹ / Off Improved drying for glasses and plastic
tableware.
š:‹‹ - š:‹‚
‘ Hot water *
‘:‹‹ / Off The dishwasher can be connected to
either hot (40-60°C) or cold water
‘:‹‹ - ‘:‹‚
˜ Auto Power Off
˜:‹‚ Appliance automatically switches off at
(<40°C).
the end of each wash.
˜:‹‹ - ˜:‹ƒ
* depending on the configuration of your specific dishwasher
--------
12
Water softening system/special salt en
+ Water softening
system / special salt
Wat er sof teni ng syst em/special sal t
To ensure good rinsing results, the
dishwasher requires soft water, i.e.
water which is low in lime, otherwise
limescale will be deposited on the
utensils and interior container. Tap
water above 7° dH (1.2 mmol/l) must
be softened. The water is softened with
special salt (regeneration salt) in the
water softening system
of the dishwasher. The setting and
therefore the required amount of salt
depends on the degree of hardness of
your tap water (see following water
hardness table).
Water hardness table
:DWHU
KDUGQHVV
YDOXH
&ODUNH
Ȣ
Ȣ
Ȣ
Ȣ
Ȣ
Ȣ
Ȣ
Ȣ
+DUGQHVV
UDQJH
VRIW
VRIW
PHGLXP
PHGLXP
PHGLXP
KDUG
KDUG
KDUG
PPROO
Ȣ
Ȣ
Ȣ
Ȣ
Ȣ
Ȣ
Ȣ
Ȣ
6HWYDOXH
RQWKH
PDFKLQH
¯¯
¯³
¯
¯´
¯
¯
¯±
¯Å
Adjusting the water softening
system
You can set the amount of salt that
should be added to a value between
•:‹‹ and •:‹ˆ. No salt is needed with
the setting •:‹‹.
Here’s how to set up the amount of
added salt:
1. Ask your local water utility company
for the water hardness value of the
tap water.
2. Required setting can be found in the
water hardness table.
3. Switch on ON/OFF switch (.
4. Hold down the programme button
# and then repeatedly press the
START button P until •:‹...
appears in the display window.
5. Release both buttons.
The LED of the # button flashes
and the digital display )" shows
the factory setting •:‹….
6. Press the programme button 3.
Each time the button is pressed, the
set value increases by one level;
when it reaches the value •:‹ˆ the
display jumps back to •:‹‹ (Off).
7. Press START button P.
The chosen setting has now been
stored in your dishwasher.
Using special salt
Top up the special salt as soon as the
salt refill indicator ` lights up in the
control panel. Always top up the special
salt immediately before switching on the
dishwasher. This ensures that overrun
special salt solution is immediately
rinsed out and that corrosion in the
washing tank cannot occur.
Caution!
Detergent will destroy the water
softening unit! Never pour detergent into
the dispenser for special salt.
13
en Rinse aid
Top up the special salt as follows:
1. Undo the screw plug on the
dispenser 1R.
2. Fill the dispenser with water
(required only when switching on the
appliance for the first time).
3. Add special salt as illustrated (do
not use table salt or tablets).
The water is displaced and runs out.
*
*Depending on the features of your
dishwasher
Using detergent with a salt
component
Det er ge n t wi t h a salt component
In general, you can use detergent with
a salt component up to a water
hardness level of 21 °dH (37 °fH, 26
°Clark, 3.7 mmol/L) without adding
special salt. Above a water hardness
value of 21 °dH, use additional special
salt.
, Rinse aid
Ri ns e ai d
The rinse aid ensures stain-free dishes
and clear glasses. Use only rinse aid
for domestic dishwashers. As soon as
the rinse aid refill indicator h lights up
in the control panel, there is still a rinse
aid reserve of 1-2 rinse cycles. Top up
the rinse aid.
Top up the rinse aid as follows:
1. Open dispenser 9"; press lug on
the lid (1) and lift (2).
2
1
2. Add rinse aid up to the max. mark.
Switching off salt refill
indicator/water softening unit
Swi t ch i ng of f wa t er sof t eni ng uni t
If the salt refill indicator ` bothers
you (e.g. if you are using a combination
detergent with a salt component), you
can switch off the salt refill indicator.
Proceed as described under "Setting
water softening unit" and set the value
to •:‹‹. The water softening unit and
the salt refill indicator are switched off.
14
PD[
3. Close the lid.
The lid "clicks" into position.
4. Remove overflowed rinse aid with a
cloth.
This prevents excessive frothing
during the next rinse cycle.
Rinse aid en
Setting amount of rinse aid
You can set the amount of rinse aid that
should be added to a value between
§:‹‹ and §:‹‡. Setting the amount of
rinse aid to be dispensed to §:‹† will
give you a very good drying result. The
factory setting is §:‹†. Do not change
the amount of rinse aid unless there are
streaks or water stains on the utensils.
Set a lower level to avoid streaks. Set a
higher level to avoid water stains.
Here’s how to set the amount of rinse
aid:
1. Switch on ON/OFF switch (.
2. Hold down the programme button
# and then repeatedly press the
START button P until •:‹...
appears in the display window.
3. Release both buttons.
The LED of the # button flashes
and the digital display )" shows
the factory setting •:‹….
4. Press the programme button #
repeatedly until the factory setting
value §:‹† appears in the display
window )".
5. Press the programme button 3.
Each time the button is pressed, the
set value increases by one level;
when it reaches the value §:‹‡ the
display jumps back to §:‹‹ (Off).
6. Press START button P.
The set value is saved.
Using detergent with a rinse
aid component
Det er ge n t wi t h a rinse ai d component
In general, you can use detergent with
a rinse aid component up to a water
hardness level of 21 °dH (37 °fH, 26
°Clark, 3.7 mmol/L) without adding
rinse aid. Above a water hardness value
of 21 °dH, use additional rinse aid.
Switching off rinse aid refill
indicator
If the rinse aid refill indicator h
bothers you (e.g. if you are using a
combination detergent with a rinse aid
component), you can switch off the
rinse aid refill indicator.
Proceed as described under "Setting
rinse aid quantity" and set the level to
§:‹‹. The rinse aid refill indicator h is
switched off.
15
en Utensils
- Utensils
Utensi l s
Not suitable
■ Cutlery and utensils made of wood.
■ Delicate decorative glasses, craft
and antique utensils. These decors
are not dishwasher-proof.
■ Plastic parts not resistant to heat.
■ Copper and tin utensils.
■ Utensils which are soiled with ash,
wax, lubricating grease or ink.
Aluminium and silver parts have
a tendency to discolour and fade during
the wash cycle. Even some types of
glass (e.g. crystal glass objects) may
turn cloudy after many wash cycles.
Glass and utensil damage
Causes:
■ Glass type and glass production
process.
■ Chemical composition of the
detergent.
■ Water temperature of the wash
programme.
Recommendation:
■ Use only glasses and porcelain
which the manufacturer designates
as dishwasher-proof.
■ Use a detergent which protects
utensils.
■ Take glass and cutlery out of
the dishwasher as soon as possible
after the programme ends.
Loading the dishwasher
1. Remove large food remnants. It
is not necessary to prerinse utensils
under running water.
2. Place the utensils so that
– they are secure and cannot tip
over.
– all utensils with their openings
face down.
– parts with curves or indentations
are at an angle, thereby allowing
water to drain.
– does not obstruct rotation of the
two spray arms 1: and 1J.
Very small utensils should not be
washed in the machine, as they may fall
out of the baskets.
Upper basket
Arrange cups and glasses in the upper
basket 12.
16
* depending on the features of your
dishwasher
Utensils en
Note: Utensils must not be placed
above the tablet collecting tray 1B.
These may block the lid of the detergent
dispenser and prevent it from opening
fully.
Lower basket
Arrange pots and plates in the lower
basket 1j.
Tip: Heavily soiled utensils (pans)
should be placed in the lower basket.
The more powerful spray jet provides a
better dishwashing result.
Tip: Other examples, such as the best
way of loading your dishwasher, can be
found on our homepage. These can be
downloaded free of charge. The
corresponding Internet address can be
found on the back page of these
instructions for use.
Cutlery basket *
Cut l er y basket
Place cutlery, always unsorted with the
tips face down, in the cutlery basket *.
To prevent injuries, place long, pointed
implements and knives on the knife
shelf *.
* depending on the features of your
dishwasher
* depending on the features of your
dishwasher
Cutlery drawer *
Cut l er y drawer
Arrange the cutlery in the cutlery drawer
1* as illustrated. Separately arranged
utensils are easier to remove after
washing.
17
en Utensils
You can take out the cutlery drawer.
Depending on the features of your
dishwasher, you can fold down the side
shelves to provide more room for taller
items of cutlery. The front rows of
prongs can be folded down to provide
room for wider handles.
Etagere *
Etager e
The etagere and the space underneath
can be used for small cups and glasses
or for larger items of cutlery, such as
wooden spoons or serving cutlery. If
you do not require the etagere, it can be
folded up.
&/,&.
* Depending on the features of your
dishwasher, you can adjust the etagere
3 times the height.
Adjust the height of the etagere as
follows:
1. Position the etagere vertically and
pull upwards.
2. Push etagere at a slight angle
downwards to the required height
(1, 2, or 3).
3. Engage etagere.
Etagere “clicks” into position.
CLICK
* depending on the features of your
dishwasher
18
Utensils en
Folding spikes *
Fol di ng spi kes
* Depending on the features of your
dishwasher, the spikes can be folded
down. This facilitates arrangement of
pots, bowls and glasses.
Fold down the spikes as follows:
1. Press lever forwards (1).
2. Fold down spikes (2).
Small items holder *
Smal l items hol der
* Depending on the features of your
dishwasher, the upper basket is fitted
with small items holders. The small
items holders can be used to securely
attach light plastic parts.
Knife rack *
Kni f e rack
* Depending on the features of your
dishwasher, the upper basket is fitted
with a knife shelf. Long knives and other
utensils can be placed in the knife shelf.
19
en Utensils
Baking sheet spray head *
Bak i ng s heet spray head
* depending on the features of your
dishwasher
Large trays or grilles as well as large
plates (gourmet plates, pasta plates,
dinner plates) can be cleaned with this
spray head.
Insert the spray head as follows:
1. Remove upper basket 12.
2. Insert spray head as illustrated and
turn to the right.
Spray head is engaged.
To ensure that the spray jet can reach
all parts, arrange the baking sheets as
illustrated (max. 2 baking sheets and 2
grilles).
Note: Ensure that the dishwasher is
always operated with upper basket 12
or baking tray spray head.
Unloading the dishwasher
To prevent water from dripping off the
upper basket onto the utensils in the
lower basket, it is recommended
to empty the appliance from the bottom
up.
Tip: Hot utensils are sensitive to shock!
Therefore, when the programme ends,
leave the utensils to cool down in the
dishwasher until they can be handled.
Note: When the programme ends,
water droplets can still be seen inside
the appliance. This does not affect the
drying of the utensils.
Adjusting the height of the
basket *
Adj ust i n g the hei ght of the basket
* depending on the features of your
dishwasher
If required, the height of the upper
basket 12 can be adjusted to create
more space for taller utensils either in
the upper or lower basket.
Appliance height 81.5 cm
With cutlery basket Upper
basket
Setting 1 max. ø 22 cm 31 cm
Setting 2 max. ø 24.5 cm 27.5 cm
Setting 3 max. ø 27 cm 25 cm
With cutlery drawer Upper
basket
Setting 1 max. ø 16 cm 31 cm
Setting 2 max. ø 18.5 cm 27.5 cm
Setting 3 max. ø 21 cm 25 cm
Lower
basket
Lower
basket
20
Utensils en
Appliance height 86.5 cm
With cutlery basket Upper
basket
Setting 1 max. ø 24 cm 34 cm
Setting 2 max. ø 26.5 cm 30.5 cm
Setting 3 max. ø 29 cm 28 cm
With cutlery drawer Upper
basket
Setting 1 max. ø 18 cm 34 cm
Setting 2 max. ø 20.5 cm 30.5 cm
Setting 3 max. ø 23 cm 28 cm
Arrange large plates up to a diameter of
31/34* cm in the lower basket 1j as
illustrated.
Lower
basket
Lower
basket
Upper basket with side levers
1. Pull out upper basket 12.
2. Hold the sides of the basket along
the upper edge.
This prevents it from suddenly
dropping.
3. To lower the upper basket; press in
both levers on the left and right on
the outside of the basket. The upper
basket lowers.
4. To lift the upper basket; grip the
sides of the upper basket along the
upper edge and lift.
5. Ensure that both sides of the upper
basket are at the same height.
6. Push in upper basket.
* depending on the features of your
dishwasher
Upper basket with upper and
lower pairs of rollers
1. Pull out upper basket 12.
2. Remove upper basket.
3. Re-attach upper basket to the upper
(Setting 3) or lower (Setting 1)
rollers.
4. Push in upper basket.
21
en detergent
. Detergent
det er gent
You can use tablets as well as powder
or liquid detergents for dishwashers, but
never use washing-up liquid. The
dosage can be individually adjusted
with powder or a liquid detergent
according to the degree of soiling.
Tablets contain an adequately large
amount of active ingredients for all
cleaning tasks. Modern, powerful
detergents predominantly use a
low-alkaline formulation with enzymes.
Enzymes break down starch and
remove protein. To remove coloured
stains (e.g. tea, ketchup), oxygen-based
bleaching agents are generally used.
Note: To ensure a good washing result,
always follow the instructions on the
detergent packaging!
If you have further questions,
we recommend that you contact
the detergent manufacturers’ helplines.
:Warning
Risk of injury and damage due to
non-observance of the safety
instructions for detergent and
rinse-aid products!
Always follow the safety instructions for
detergent products and rinse-aid
products.
Adding detergent
1. If the detergent dispenser 9* is still
closed, actuate locking bar 92 to
open it.
2. Pour detergent into the dry detergent
dispenser 9* only (insert tablet flat,
not on its edge).
3. Dosage: see manufacturer’s
instructions on the packaging. Use
graduated detergent dispenser.
Usually 20 ml–25 ml are adequate
for normal soiling. If using tablets,
one tablet is adequate.
50 ml
25 ml
15 ml
22
detergent en
4. Close cover on the detergent
dispenser.
Cover “clicks” into position.
CLICK
The detergent dispenser opens
automatically at the optimum time
depending on the programme. The
powder or liquid detergent is
distributed in the appliance and is
dissolved, the tablet falls into the
tablet collecting tray where it
dissolves in doses.
Tip: If the utensils are only lightly
soiled, slightly less than the indicated
amount of detergent is usually
adequate.
Suitable detergents and care products
can be purchased online via our
website or via customer service (see
back page).
Combination detergent
Apart from conventional detergents
(Solo), a number of products are offered
with additional functions. These
products contain not only the detergent
but also rinse-aid and salt replacement
substances (3in1) and, depending on
the combination (4in1, 5in1, ...),
additional components such as glass
protection or stainless steel cleaner.
Combination detergents function only
up to a specific degree of hardness
(usually 21°dH). Over this limit salt and
rinse-aid must be added.
As soon as combined detergents are
used, the rinse programme is adjusted
automatically to ensure the best
possible rinsing and drying result.
23
en detergent
Notes
■ If you want to add more utensils after
the programme has started, do not
use the tablet collecting tray 1B as
a handle for the upper basket. The
tablet could already be there and
you will touch the partially dissolved
tablet.
■ Do not place small parts for washing
in the tablet collecting tray 1B; this
prevents the tablet from dissolving
evenly.
■ You will obtain optimum rinsing and
drying results by using solo
detergents and applying salt
and rinse aid separately.
■ If programmes are short, tablets may
not have full cleaning effect due to
different dissolving properties and
there may even be undissolved
detergent residue. It is
recommended to use washing
powder for these programmes.
■ The dosing of a tablet is adequate
for the “Intensive” programme (for
some models). When using washing
powder, you can apply some of this
cleaning agent to the inside of the
appliance’s door.
■ Even if the rinse-aid and/or salt refill
indicator is lit, the rinse programme
will run correctly with combined
detergents.
■ If using detergents in a water-soluble
protective cover: Take hold of the
cover with dry hands only and put
the detergent into an absolutely dry
detergent dispenser only, otherwise
the detergent may stick.
■ If you switch from combined
detergents to solo detergents,
ensure that the water softening
system and amount of rinse aid have
been set to the correct value.
■ Biological/eco detergents: Detergent
products identified as “Bio” or “Eco”
(to protect the environment) usually
use lower quantities of active agents
or completely dispense with certain
substances. The cleaning effect of
such products may occasionally be
restricted.
24
Overview of programmes en
/ Overview of programmes
Over vi ew of pr ogr ammes
The max. possible number of programmes is illustrated in this overview. The
corresponding programmes and their arrangement can be found on the fascia.
Type of dish Type of soiling Programme Possible
pots and pans,
non-sensitive
utensils and
cutlery
mixed utensils
and cutlery
mixed utensils
and cutlery
mixed utensils
and cutlery
sensitive
utensils, cutlery,
temperature-sen
sitive plastic and
glasses
mixed utensils
and cutlery
very stubborn burned
or dried-on food
remains containing
starch or protein
part dried, common
household food
remnants
part dried, common
household food
remnants
part dried, common
household food
remnants
lightly adhering, fresh
food remains
part dried, common
household food
remnants
± / °
Intensive 70°
Á / Ù
Auto 45° - 65°
â / à
Eco 50°
’/´
Silence 50°
é / è
Glass 40°
ñ / ð
Quick 65°
additional
options
all
all
all
intensiveZone
Half load
HygienePlus
ExtraDry
Shine and Dry
intensiveZone
VarioSpeedPlus
Half load
ExtraDry
Shine and Dry
Extra Dry
Shine and Dry
Programme sequence
Intensive:
Pre Rinse
Cleaning 70°
Intermediate rinse
Final rinse 69°
Drying
Sensor-controlled:
Is optimised according
to the soiling with the aid
of sensors.
Most economical:
Pre Rinse
Cleaning 50°
Intermediate rinse
Final rinse 63°
Drying
Reduced noise:
Pre Rinse
Cleaning 50°
Intermediate rinse
Final rinse 63°
Drying
Particularly gentle:
Pre Rinse
Cleaning 40°
Intermediate rinse
Final rinse 60°
Drying
Time-optimised:
Cleaning 65°
Intermediate rinse
Final rinse 70°
Drying
25
en Overview of programmes
Type of dish Type of soiling Programme Possible
mixed utensils
and cutlery
sensitive
utensils, cutlery,
temperature-sen
sitive plastic and
glasses
all types of
dishes
- -
--------
part dried, common
household food
remnants
lightly adhering, fresh
food remains
cold rinsing,
intermediate cleaning
Œ
65°
ñ / ð
Quick 45°
ù / ø
Pre Rinse
‰ / Š
Machine Care
Programme selection
You can select a suitable programme
according to the type of utensils and
type of soiling.
additional
options
Extra Dry
Shine and Dry
Extra Dry
Shine and Dry
None
None
Information for test institutes
Test institutes receive the information for
comparability tests (e.g. according to
EN60436).
These are the conditions for conducting
the tests, however these are not the
results or consumption values.
Request by e-mail to:
dishwasher@test-appliances.com
The product number (E no.) and the
production number (FD) are required
which you can find on the rating plate
9: on the appliance door.
Programme sequence
Time-optimised:
Cleaning 65°
Intermediate rinse
Final rinse 70°
Drying
Time-optimised:
Cleaning 45°
Intermediate rinse
Final rinse 55°
Cold rinse
Pre Rinse
Machine cleaning
cycle 70°
26
Additional functions en
0 Additional functions
Addit i onal func t i ons
* Depending on the features of your
dishwasher, you can select different
additional functions H.
Å Save time
(VarioSpeedPlus) *
Sav e time ( Vari oSpeedPl us)
The “Save time” function can reduce
the running time by approx. 20% to 66%
depending on the selected rinse
programme. To obtain optimum
cleaning and drying results at a
reduced running time, water and energy
consumption are increased.
§ Half load *
Hal f l oad
If you have only a few items to wash
(e.g. glasses, cups, plates), you can
switch to “half load”. This will save
water, energy and time. It is
recommended to put a little less
detergent in the detergent dispenser
than for a full load.
μ hygienePlus
(HygienePlus) *
hygi enePl us ( Hygi enePl us)
This function increases the
temperatures and retains them for an
extra long time to obtain a defined
disinfection performance. Continuous
use of this function increases the
hygiene status. This additional option is
ideal for cleaning e.g. chopping boards
and baby bottles.
Ï intensiveZone *
i nt ens i v eZone
Perfect for a mixed load. You can wash
very soiled pots and pans in the lower
basket together with normally soiled
utensils in the upper basket. The spray
pressure in the lower basket
is intensified, the rinsing temperature
is increased slightly.
¿ extraDry *
ext r aDry
An increased temperature during the
final rinse and an extended drying
phase ensure that even plastic parts dry
better. There is a slight increase in the
energy consumption.
ï Shine and Dry *
Shi ne and Dr y
By increasing the amount of water
during the rinse cycle and extending the
drying phase, stains are prevented and
the drying result is improved. There is a
slight increase in the energy
consumption. Rinse aid is
recommended for the high gloss drying
function (even when using combination
detergents).
ß Energy Save *
Energy Sav e
The “Energy Save” function can be
used to reduce water and energy
consumption. The running time
is extended for optimum cleaning and
drying results.
27
en Operating the appliance
1 Operating the
appliance
Operat i ng the appl i ance
Programme data
The programme data (consumption
values) can be found in the quick
reference guide. They refer to normal
conditions and the set water hardness
value •:‹…. Different influencing factors
such as water temperature or line
pressure may result in deviations.
AquaSensor *
AquaSensor
* depending on the features of your
dishwasher
The Aqua sensor is an optical
measuring device (light barrier) which
measures the turbidity of the rinsing
water.
The AquaSensor is used according
to the programme. If the AquaSensor is
active, “clean” rinsing water can be
transferred to the next rinse bath and
water consumption can be reduced by
3–6 litres. If the turbidity is greater,
the water is drained and is replaced
with fresh water. In the automatic
programmes the temperature
and running time can also be adjusted
to the degree of soiling.
Switching on the appliance
1. Turn tap fully on.
2. Switch on ON/OFF switch (.
The Eco 50° programme has been
preset for environmentally friendly
operation whenever the appliance
starts. This programme remains
selected if no other programme
button 0 is pressed.
3. Press START button P.
Programme sequence starts.
Note:
For ecological reasons the Eco 50°
programme is preset whenever the
appliance starts. This conserves
environmental resources and not least
saves you money.
The Eco 50° programme is a
particularly environmentally friendly
programme. According to EU
regulation 1016/2010 it is the
“Standard programme” which is the
most efficient standard cleaning cycle
for cleaning normally soiled utensils in
terms of the combined energy and
water consumption for cleaning these
types of utensils.
Remaining running time
display
When the programme is selected, the
remaining programme time is indicated
in the display window )".
The running time is determined during
the programme by the water
temperature, the quantity of dishes as
well as the degree of soiling and may
vary (depending on the selected
programme).
28
Operating the appliance en
Time preselection *
Ti me presel ect i on
* depending on the configuration of
your specific dishwasher
You can delay the start of the
programme in hourly steps by up to 24
hours.
Here’s how to set up the delay:
1. Switch on ON/OFF switch (.
2. Press the timer programming button
@ + repeatedly until )" œ ‹‚
appears in the display window.
3. Keep pressing the timer
programming button @ - or + until
the desired time is displayed.
4. Press START button P.
The delay timer has been activated.
5. To clear the specified delay, press
the button @ - or + repeatedly until
)" œ ‹‹ appears in the display
window.
Until the programme has started, you
can change your selection in any way
you like.
Programme end
The programme has finished when the
value ‹:‹‹ appears in the display
window )".
Auto Power Off (Automatic
switch off after end of
programme) or interior
lighting *
Aut o Power Off
To save power you can set the
dishwasher to switch off automatically
from 1 minute to 120 minutes after the
end of its programme. You can choose
a setting from ˜:‹‹ to ˜:‹ƒ.
˜:‹‹ Appliance does not switch off
automatically.
The interior light 1" comes on
when the door is opened
irrespective of whether the
ON/OFF switch ( is switched
on or off. When the door is closed
the light is off. If the door remains
open for longer than 60 minutes
the light will switch off
automatically. The interior light
1" switches on only if the setting
˜:‹‹ has been selected.
˜:‹‚ Appliance switches off after 1
minute.
˜:‹ƒ The appliance switches off after
120 minutes.
29
en Operating the appliance
Here’s how to change the setting:
1. Switch on ON/OFF switch (.
2. Hold down the programme button
# and then repeatedly press the
START button P until •:‹...
appears in the display window.
3. Release both buttons.
The LED of the # button flashes
and the digital display )" lights up
to show the value •:‹....
4. Press the programme button #
repeatedly until the value ˜:‹...
appears in the display window )".
5. Press the programme button 3.
Each time the button is pressed, the
set value increases by one level;
when it reaches the value ˜:‹ƒ the
display jumps back to ˜:‹‹.
6. Press START button P.
The set value is saved.
* depending on the features of your
dishwasher
Switching off the appliance
Shortly after the end of the
programme:
1. Switch off ON/OFF switch (.
2. Turn off water supply (does not
apply to appliances with Aqua-Stop).
3. Remove the utensils when they have
cooled down.
Note: When the programme ends,
leave the appliance to cool down a
while before opening it. This will prevent
steam from escaping and causing
long-term damage to your built-in
furniture.
Interrupting the programme
Caution!
Expansion (overpressure) may cause
the appliance door to jump open and/or
water to escape! If the door was opened
on an appliance which has a hot water
connection or is heated, always leave
the door ajar for several minutes and
then close it.
1. Switch off ON/OFF switch (.
The LEDs go out. The programme is
saved.
2. Switch on the ON/OFF switch (
again to continue the programme.
Terminating the programme
(Reset)
Ter minating the progr amme
1. Press the START button P and
hold it down for about 3 seconds.
The value ‹:‹‚ appears in the
display window )". The
programme sequence lasts about
1 minute. The value ‹:‹‹ appears in
the display window )".
2. Switch off ON/OFF switch (.
Changing the programme
When the START button P has been
pressed, the programme cannot be
changed. The only way a programme
can be changed is by Cancel
programme (Reset).
30
Cleaning and maintenance en
ExtraDry
The final rinse uses a higher
temperature which improves the drying
result. The running time may increase
slightly. (Be careful if you have delicate
tableware)
Here’s how to change the setting:
1. Switch on ON/OFF switch (.
2. Hold down the programme button
# and then repeatedly press the
START button P until •:‹...
appears in the display window )".
3. Release both buttons.
The LED of the # button flashes
and the digital display )" shows
the factory setting •:‹….
4. Press the programme button #
repeatedly until the factory setting
value š:‹‹ appears in the display
window )".
5. By pressing the 3 button you can
switch intensive drying on š:‹‚ or
off š:‹‹.
6. Press START button P.
The set value is saved.
2 Cleaning and
maintenance
Cl eani ng and mai nt enance
A regular inspection and maintenance
of your machine will help to prevent
faults. This saves time and prevents
problems.
Overall status of the
dishwasher
*The interior of your dishwasher is
predominantly self-cleaning. In order to
remove deposits, your dishwasher
automatically changes the running of
the programme (such as by increasing
the cleaning temperature) at certain
intervals. This will lead to higher
consumption values when running this
programme.
*Depending on the features of your
dishwasher
If you should find deposits in the
interior of the dishwasher in spite of
this, remove these deposits as
follows:
1. Fill the detergent dispenser 9* with
detergent.
2. Select the programme with the
highest temperature.
3. Start the programme without dishes.
:Warning
Health hazard due to detergents
containing chlorine!
Always use chlorine-free detergents.
31
en Cleaning and maintenance
Notes
■ Only clean the appliance with
special detergents/appliance
cleaners which are suitable for use
with dishwashers.
■ Regularly wipe the door seals using
a damp cloth and a little washing-up
liquid. This will keep the door seal
clean and hygienic.
■ Leave the door open slightly if the
appliance will not be used for a
while. This will prevent an unpleasant
odour from developing.
■ Never clean the dishwasher using a
steam cleaner. The manufacturer
is not liable for any consequential
damage.
■ Wipe the front of the dishwasher and
the control panel regularly using a
damp cloth and a little washing-up
liquid.
■ Do not use sponges with a rough
surface or abrasive detergents.
These could scratch the surface.
■ For dishwashers with a stainless
steel front, avoid using sponge
cloths, or rinse these thoroughly
several times before using them for
the first time. This will prevent
corrosion.
Machine Care ‰ *
Machine Ca r e
Machine Care used in combination with
commercially available machine
cleaning detergent is a suitable
programme for cleaning your
dishwasher. Deposits such as grease
and limescale can cause your
dishwasher to malfunction. In order to
avoid such faults and to reduce the
development of odours, we recommend
cleaning the dishwasher at regular
intervals.
* As soon as the Machine Care display
lights up in the control panel, or you are
advised to do so on the front display,
run the Machine cleaning programme
Machine Care without loading any
tableware. After you have run the
Machine Care the display in the control
panel will go out.
If your dishwasher does not have a
reminder function, follow the instructions
for use on the machine cleaning
detergents.
32
Cleaning and maintenance en
Notes
■ Remove any coarse soiling in the
interior using a damp cloth.
■ Run the programme without dishes,
and in combination with a machine
cleaning detergent.
■ Use a special machine cleaning
detergent, and not dishwasher
detergent.
■ Observe the safety instructions and
the instructions for use on the
machine cleaning detergent
packaging.
■ *After three rinse cycles, the display
in the control panel will go out
automatically, even if you have not
run the Machine cleaning cycle
programme.
* depending on the features of your
dishwasher
Special salt and rinse aid
Top up the salt and/or rinse aid as soon
as either of the refill indicators on the
control panel ` or h lights up.
Filters
The filters 1Z keep large foreign
objects in the rinsing water away from
the pump. hese foreign objects may
occasionally block the filters.
The filter system consists of
■ a coarse filter
■ a flat fine filter
■ a microfilter
1. After each washing cycle check
the filters for residue.
2. Unscrew filter cylinder as illustrated
and take out filter system.
3. Remove any residue and clean
filters under running water.
4. Re-install filter system in reverse
sequence and ensure that the arrow
marks are opposite each other after
closing the filter system.
33
en Fault, what to do?
Spray arms
Limescale and contaminants in the
rinsing water may block nozzles and
bearings on the spray arms 1: and
1J.
1. Check outlet nozzles on the spray
arms for blockages.
2. Unscrew the upper spray arm 1:
(1) and remove downwards (2).
3. Remove the lower spray arm 1J
upwards.
3 Fault, what to do?
Faul t , wh a t to do?
Experience has shown that you can
rectify most faults which occur in daily
operation yourself. This ensures that the
appliance is quickly available to you
again. In the following overview you can
find possible causes of malfunctions
and helpful information for rectifying
them.
Note: If the appliance stops during
dishwashing or does not start for no
obvious reason, first run the Abort
programme function (Reset)
~ "Operating the appliance"
on page 28.
:Warning
Improper
repairs or use of non-original spare
parts may cause considerable damage
and put the user at considerable risk!
Always have repairs carried out by
technicians. If a component has to be
replaced, always use original spare
parts.
4. Clean spray arms under running
water.
5. Re-engage or screw on spray arms.
34
Fault, what to do? en
Waste water pump
Large food remnants or foreign objects
which were not captured by the filters
may block the waste water pump. The
rinsing water will then be above the
filter.
:Warning
Danger of cutting!
Sharp and pointed objects or glass
fragments may block the waste water
pump.
Always carefully remove foreign objects.
Clean the waste water pump as
follows:
1. Disconnect the dishwasher from the
power supply.
2. Take out top basket 12 and bottom
basket 1j.
3. Remove the filters 1Z.
4. Scoop out water, use a sponge if
required.
5. Prise off the pump cover (as shown)
using a spoon. Grip the pump cover
by the crosspiece and lift diagonally
inwards (1). Remove cover
completely.
6. Check impeller wheel and remove
any foreign objects.
7. Place pump cover in the original
position (2) and press down until it
engages (3).
CLICK
8. Install filters.
9. Re-insert baskets.
1
35
en Fault, what to do?
Fault table
Fault Reason Remedial action
“Check water supply”
display lights up.
Fault code “:‹ˆ is lit. Intake opening (on right inside of
Fault code “:‚ƒ is lit. Heating element calcified or
Fault code “:‚… is lit. Water protection system
Fault code “:‚† is lit.
Fault code “:‚‡ is lit. Constant water supply.
Fault code “:ƒƒ is lit. Filters 1Z are soiled or
* depending on the configuration of your specific dishwasher
Supply hose kinked. Install supply hose without kinks.
Tap turned off. Turn on water supply.
Tap jammed or calcified. Turn on water supply.
Filter in the water supply blocked. Switch off the appliance and pull out the
appliance) covered by utensils.
soiled.
activated.
blocked.
Flow rate must be at least 10 l/min. when
water supply is open.
mains plug. Turn off water supply.
Unscrew water connection.
Clean filter in the supply hose. Screw
water connection on again. Check for
leaks. Reconnect power supply. Switch on
the appliance.
Arrange utensils so that the intake
opening is not obstructed.
Clean appliance with dishwasher cleaning
agent or descaler. Operate the dishwasher
with water softening system and check the
setting.~ " Water softening
system/special salt" on page 13
Turn off water supply.
Call customer service and quote the fault
code.
Clean filters. ~ "Filters" on page 33
36
Fault, what to do? en
Fault Reason Remedial action
Fault code “:ƒ… is lit. Waste-water hose kinked or
Fault code “:ƒ† is lit. Waste water pump blocked or
Fault code “:ƒˆ is lit. Mains voltage too low. No appliance fault, have the mains voltage
A different fault code is
indicated on the digital
display.
(“:‹‚ to “:„‹)
p or • appears on the
digital display )". *
Refill indicator for salt `
and/or rinse aid h is lit.
Refill indicator for salt `
and/or rinse aid h is not
lit.
Water is left in the
appliance at the end of the
programme.
* depending on the configuration of your specific dishwasher
blocked.
Siphon connection still sealed. Check connection to siphon and open if
Cover on the waste water pump
loose.
cover on the waste water pump is
not locked in position.
A technical fault has probably
occurred.
Not a fault! See turboSpeed 20 min. in the chapter
No rinse aid. Refill rinse aid.
No salt. Refill with special salt.
Sensor does not detect salt
tablets.
Refill indicator switched off. Activation/deactivation (see chapter
There is still enough special
salt/rinse aid available.
Filter system or area under the
filters 1Z is blocked.
Programme has not yet finished Wait until programme ends or reset.
Install hose without kinks, remove any
residue.
required.
Lock cover correctly. ~ "Waste water
pump" on page 35
Clean pump and lock cover correctly.
~ "Waste water pump" on page 35
and electrical installation checked.
Switch off the appliance with the ON/OFF
switch (. After a short time restart the
appliance.
If the problem recurs, turn off water supply
and pull out the mains plug.
Call customer service and quote the fault
code.
“Overview of programmes”. *
Use different special salt.
“Water softening system/Special salt”
~ Page 13 or “Rinse aid” ~ Page 14).
Check refill indicator, levels.
Clean filters and area underneath.
37
en Fault, what to do?
Fault Reason Remedial action
Utensils not dry. Not enough rinse aid in the
dispenser, or none at all.
Programme without drying was
selected.
Water collecting in depressions
on the utensils and cutlery.
Refill rinse aid.
Select programme with drying.
~ "Overview of programmes"
on page 25
Arrange utensils in a sloping position,
arrange affected utensils as sloping as
possible.
The combined detergent used
has a poor drying performance.
The extra drying option to
increase drying was not
activated.
Utensils were removed too early
or drying process had not ended
yet.
The eco rinse aid used has a
limited drying performance.
Plastic utensils not dry. Special properties of plastic. Plastic has a lower heat storage capacity
Cutlery not dry. Cutlery not arranged properly in
Appliance interior wet after
wash cycle.
* depending on the configuration of your specific dishwasher
the cutlery basket.
Cutlery not arranged properly in
the cutlery drawer.
No appliance fault. On account of the “Condensation drying”
Use different combination detergent with
better drying performance. Use of rinse
aid also improves the drying performance.
Activate intensive drying. ~ "Operating
the appliance" on page 28
Wait until the programme ends, or wait
until 30 minutes after the end of the
programme before removing the utensils.
Use a proprietary rinse aid. Eco products
may have limited effectiveness.
and therefore dries less well.
Separate cutlery if possible, prevent
contact points.
Arrange cutlery properly and separate if
possible.
principle, water droplets are physically
induced and required in the container. The
humidity in the air condenses on the inner
walls of the dishwasher, drains and is
pumped out.
38
Fault, what to do? en
Fault Reason Remedial action
Food remnants on the
utensils.
Food remnants on the
dishes when pause
function is used. *
* depending on the configuration of your specific dishwasher
Utensils placed too closely
together, utensils basket
overfilled.
Spray arm rotation obstructed. Arrange utensils so that the spray arm can
Spray arm nozzles are blocked. Clean the spray arm nozzles.
Filters 1Z dirty. Clean filters. ~ "Cleaning and
Filters 1Z inserted incorrectly
and/or not engaged.
Wash programme too weak. Select a more intensive wash programme.
Utensils precleaned too intensely;
sensors therefore decide on
weak programme sequence.
Stubborn soiling cannot be
completely removed.
Tall narrow receptacles in corner
areas are not rinsed adequately.
Top basket 12 on right and left
not set to same height.
Dishes added too late. Only interrupt the rinse programme in the
Arrange utensils with adequate clearance
between them ensuring that the spray jets
can reach the surface of the utensils.
Prevent contact points.
rotate without obstruction.
~ "Cleaning and maintenance"
on page 31
maintenance" on page 31
Insert and engage filters correctly.
Increase sensitivity of the sensors.
Do not prerinse utensils. Remove only
large food remnants.
Increase sensitivity of the sensors.
Recommended programme Eco 50° or
Intensive.
Do not place hollow receptacles too
obliquely and do not place in the corner
area.
Set top basket to same height using side
levers.
initial phase to add more dishes.
39
en Fault, what to do?
Fault Reason Remedial action
Detergent residue Detergent dispenser cover 9*
Water stains on plastic
parts.
Washable or water-soluble
coatings in the container or
on the door.
* depending on the configuration of your specific dishwasher
blocked by utensils and therefore
does not open fully.
Detergent dispenser cover 9*
blocked by the tablet.
Tablets used in the quick or short
programme.
Dissolving time of the detergent
is not reached in the selected
short programme.
Washing effect and dissolving
performance are reduced after a
prolonged storage time or
detergent is very lumpy.
Droplet formation on plastic
surface is physically unavoidable.
After drying, water stains are
visible.
Detergent substances are
deposited. These coatings cannot
usually be removed with
chemicals (appliance cleaner, ...).
If there is a “white coating” on the
container floor, the water
softening system has been set
marginally.
Salt dispenser cover 1R not
closed.
Only for glasses: Initial glass
corrosion – can only apparently
be wiped off.
Utensils must not be placed above the
tablet collecting tray 1B. These may
block the lid of the detergent dispenser
and prevent it from opening fully.
~ "Upper basket" on page 16
Do not place utensils or fragrance
dispenser in the tablet collecting tray.
Tablet must be inserted flat and not
upright.
Dissolving time of tablets too long for a
quick or short programme.
Use a detergent powder or select a more
intensive programme.
Change detergent.
Use a more intensive programme (more
water changes).
Arrange utensils in a sloping position.
Use rinse aid.
If required, increase softening setting.
Change detergent brand.
Clean appliance mechanically.
Increase softening setting and change
detergent if required.
Close salt dispenser cover correctly.
See “Glass and utensil damage”
~ Page 16.
40
Fault, what to do? en
Fault Reason Remedial action
White, stubborn coatings;
limescale on the utensils,
container or door.
Tea or lipstick residue on
the utensils.
Coloured (blue, yellow,
brown), difficult to remove
to non-removable coatings
in the appliance or on
stainless steel utensils.
Coloured (yellow, orange,
brown), easily removable
deposits inside the
appliance (mainly in the
floor area).
Discolouration of the
plastic parts inside the
appliance.
* depending on the configuration of your specific dishwasher
Detergent substances are
deposited. These coatings cannot
usually be removed with
chemicals (appliance cleaner, ...).
Hardness range incorrectly set or
water hardness greater than 8.9
mmol/l.
3 in 1 detergent or bio/eco
detergent not effective enough.
Underdosing of detergent. Increase detergent dosage or change
Too gentle wash programme
selected.
Too low rinsing temperature. Select programme with higher washing
Too little or unsuitable detergent. Use suitable detergent at correct dosage.
Utensils precleaned too intensely;
sensors therefore decide on
weak programme sequence.
Stubborn soiling cannot be
completely removed.
Film formation consisting of
ingredients from vegetables (e.g.
cabbage, celery, potatoes,
noodles, ...) or the tap water (e.g.
manganese).
Film formation caused by metallic
components on silver or
aluminium utensils.
Film formation consisting of
ingredients from food remnants
and substances from the tap
water (limescale), “soapy”
Plastic parts inside the appliance
may become discoloured during
the service life of the dishwasher.
Change detergent brand.
Clean appliance mechanically.
Set water softening system according to
instructions for use or top up salt.
Set water softening system according to
instructions for use or use separate
detergents (proprietary detergent, salt,
rinse aid).
detergent.
Select a more intensive wash programme.
temperature.
Do not prerinse utensils. Remove only
large food remnants.
Increase sensitivity of the sensors.
Recommended programme Eco 50°
Can be partly removed with machine
cleaner or by mechanical cleaning.
Coatings are harmless.
Can be partly removed with machine
cleaner or by mechanical cleaning.
Check function of the water softening
system (refill with salt) or, if using
combined detergents (tablets), activate
water softening system.
Discolouration is normal and will not
impair the function of the dishwasher.
41
en Fault, what to do?
Fault Reason Remedial action
Plastic parts discoloured. Too low rinsing temperature. Select programme with higher washing
Utensils precleaned too intensely;
sensors therefore decide on
weak programme sequence.
Stubborn soiling cannot be
completely removed.
Removable streaks on
glasses, glasses with
metallic appearance and
cutlery.
Initial or existing,
irreversible clouding of
glass.
Rust spots on the cutlery. Cutlery is not sufficiently
* depending on the configuration of your specific dishwasher
Too much rinse aid. Set rinse aid amount to lower setting.
No rinse aid added or setting too
low.
Detergent residue in the final
rinse. Detergent dispenser cover
blocked by utensils (cover does
not open fully).
Utensils precleaned too intensely;
sensors therefore decide on
weak programme sequence.
Stubborn soiling cannot be
completely removed.
Glasses not dishwasher-proof,
only suitable for dishwasher.
rust-resistant. Knife blades are
frequently more severely
affected.
Cutlery will also rust if rusting
parts are rinsed at the same time
(pan handles, damaged utensil
baskets, etc.).
Salt content in the rinsing water
too high, as salt dispenser lock
not fastened firmly or salt was
spilled while being refilled.
temperature.
Do not prerinse utensils. Remove only
large food remnants.
Increase sensitivity of the sensors.
Recommended programme Eco 50°
Add rinse aid and check dosage
(recommended setting 4–5).
Detergent dispenser cover must not be
obstructed by utensils.
Do not place utensils or fragrance
dispenser in the tablet collecting tray.
Do not prerinse utensils. Remove only
large food remnants.
Increase sensitivity of the sensors.
Recommended programme Eco 50°
Use dishwasher-proof glasses.
Avoid long steam phase (standing time
after wash cycle ends).
Use wash cycle at lower temperature.
Set water softening system according to
the water hardness (if required one setting
lower).
Use detergent with glass protection
component.
Use rust-resistant cutlery.
Do not wash rusting parts.
Fasten salt dispenser lock firmly or
remove spilled salt.
42
Fault, what to do? en
Fault Reason Remedial action
Appliance cannot be
switched on or operated.
Appliance does not start. The mains fuse has tripped. Check mains fuse.
Programme starts
automatically.
The door is difficult to
open.
Door cannot be closed. Door lock has been activated. Close door with increased force.
Cover on the detergent
dispenser cannot be
closed.
Detergent residue in the
detergent dispenser 9*
or in the tablet collecting
tray 1B.
Appliance stops in the
programme or programme
is interrupted.
* depending on the configuration of your specific dishwasher
Malfunction. Disconnect appliance from the power
Power cord not inserted. Ensure that the power cord is plugged all
The appliance door has not been
shut properly.
Pause function is active. * Press the Start button P. *
You did not wait until programme
ended.
Child-proof lock is activated. Deactivate childproof lock.
Door cannot be closed due to
installation.
Detergent dispenser or cover
guide blocked by sticky detergent
residue
Spray arms blocked by utensils,
therefore detergent is not rinsed
out.
The detergent dispenser was
damp when filled.
Door not closed properly. Close the door.
Do not place utensils or fragrance
dispenser in the tablet collecting
tray.
Top basket presses against the
door and prevents door from
being closed securely.
Power and/or water supply
interrupted.
supply; pull out the mains plug or switch
off the fuse. Wait at least 5 seconds, then
connect the appliance to the power
supply.
the way into the back of the appliance and
into the socket. Check that the socket
functions.
Close the door.
Perform reset.
Check appliance installation: Door or
attached parts must close without
obstruction.
Remove detergent residue.
Ensure that the spray arms can rotate
freely.
Pour detergent into the dry detergent
dispenser only.
Check whether rear panel is being
pressed in, e.g. by socket or by hose
holder which has not been removed.
Restore power and/or water supply.
43
en Fault, what to do?
Fault Reason Remedial action
Filling valves making
striking noises.
Depends on domestic installation,
as no appliance fault. No effect on
No remedial action possible.
appliance function.
Knocking or rattling noise. Spray arm strikes the utensils,
utensils not positioned correctly.
If there is a low load, the water
jets strike the washing tank
directly.
Light utensils move during the
Position utensils so that the spray arms do
not strike the utensils.
Load the appliance with more utensils or
distribute the utensils more evenly in the
dishwasher.
Arrange light utensils securely.
wash cycle.
Unusual foam formation. Hand washing-up liquid in the
rinse aid dispenser.
Immediately refill rinse aid dispenser with
rinse aid.
Rinse aid spilled. Remove rinse aid with a cloth.
* depending on the configuration of your specific dishwasher
--------
44
Customer service en
4 Customer service
Cus t o mer serv i ce
If you are unable to rectify the fault,
please contact your customer service.
We will always find an appropriate
solution in order to avoid unnecessary
visits by engineers. Contact information
for your nearest customer service can
be found on the back of these
instructions for use or on the enclosed
customer service list. When calling,
please state the appliance number
(E-Nr. = 1) and the production number
(FD = 2) which can be found on the
rating plate 9: on the appliance door.
(1U
Trust the expertise of the
manufacturer. Contact us for
assistance. You can therefore be sure
that the repair is carried out by trained
service technicians who carry original
spare parts for your domestic
appliances.
)'
5 Installation and
connection
Instal lation and c onnect i on
The dishwasher must be connected
correctly, otherwise it will not function
properly. The specifications for the inlet
and outlet as well as the electrical
connected loads must correspond with
the required criteria as
specified in the following paragraphs
or in the installation instructions.
Install the appliance in the correct
sequence:
1. Checking appliance on delivery
2. Installation
3. Drainage connection
4. Drinking water connection
5. Electrical connection
Contents of package
If you have any complaints, contact the
dealer from whom you purchased the
appliance or our customer services.
■ Dishwasher
■ User manual
■ Installation instructions
■ Quick reference guide*
■ Warranty*
■ Installation materials
■ Steam guard plate*
■ Rubber apron*
■ Power cord
* depending on the features of your
dishwasher
Safety instructions
Please follow the safety instructions
under ~ "Installation" on page 6.
45
en Installation and connection
Delivery
Your dishwasher has been checked
thoroughly in the factory to ensure that
it is in working order. This may cause
small water stains. These will disappear
after the first wash cycle.
Technical specifications
■ Weight:
up to 60 kg
■ Voltage:
220–240 V, 50 Hz or 60 Hz
■ Connected load:
2000 - 2400 W.
■ Fuse:
10/16 A (UK 13 A).
■ Power input:
Off mode (Po)* 0.10 W.
Left On mode (Pl)* 0.10 W.
*according to regulations (EU) nos.
1016/2010 and 1059/2010.
Additional functions and settings
may increase the power
consumption.
■ Water pressure:
at least 0.05 MPa (0.5 bar),
maximum 1 MPa (10 bar).
At a higher water pressure:
connect pressure-reducing valve
ahead.
■ Inlet rate:
minimum 10 litres/minute
■ Water temperature:
cold water.
Hot water:
Maximum temperature 60 °C.
■ Capacity:
12–15 place settings (depending on
the features of your dishwasher).
Installation
The required installation dimensions
can be found in the installation
instructions. Level the appliance with
the aid of the height-adjustable feet.
Ensure that the appliance is situated
securely on the floor.
■ A built-under or integrated appliance
which is installed subsequently as a
free-standing appliance must be
secured to prevent it from
overturning, e.g. by screwing it to the
wall or by installing it under a
continuous worktop which is
screwed to adjacent cupboards.
■ The appliance can easily be installed
in a fitted kitchen between wooden
and plastic walls.
Drainage connection
1. The required work sequence can be
found in the installation instructions.
If required, fit a siphon with an
drainage connection.
2. Connect the waste-water hose
to the drainage
connection of the siphon with
the enclosed parts.
Ensure that the drainage hose is not
kinked, crushed or twisted and that
there is no cover
plate in the drainage to prevent
the waste water from flowing out!
46
Installation and connection en
Drinking water connection
1. Fasten the drinking water connection
to the tap according
to the installation instructions using
the enclosed parts.
Ensure that the drinking water
connection is not kinked, crushed
or twisted.
2. When replacing the appliance,
always use a new water supply
hose.
Water pressure:
at least 0.05 MPa (0.5 bar), maximum 1
MPa (10 bar).
At a higher water pressure:
connect pressure-reducing valve ahead.
Inlet rate:
minimum 10 litres/minute
Water temperature:
cold water.
Hot water:
Maximum temperature 60 °C.
Warm water connection*
Hot wat er connect i on
* depending on the configuration of
your specific dishwasher
The dishwasher can be connected to
cold or hot water up to max. 60°C.
Connection to hot water is
recommended if the hot water can be
supplied by energetically favourable
means and from a suitable installation,
e.g. solar heating system with
circulation line. This will save energy
and time. The hot water setting ‘:‹‚
allows you to adjust your appliance
optimally to operation with hot water. It
is recommended to have a water
temperature (temperature of the
incoming water) of at least 40 °C and
no more than 60 °C. It is not
recommended to connect the appliance
to hot water if the water is supplied from
an electric boiler.
Here’s how to change the hot water
setting:
1. Switch on ON/OFF switch (.
2. Hold down the programme button
# and then repeatedly press the
START button P until •:‹...
appears in the display window.
3. Release both buttons.
The LED of the # button flashes
and the digital display )" lights up
to show the value •:‹....
4. Press the programme button #
repeatedly until the factory setting
value ‘:‹‹ appears in the display
window )".
5. By pressing the 3 button, you can
switch the hot water setting off ‘:‹‹
or on ‘:‹‚.
6. Press START button P.
The set value is saved.
47
en Installation and connection
Electrical connection
■ Connect the appliance to an
alternating current only, ranging from
220 V to 240 V and 50 Hz or 60 Hz
via a correctly installed socket with
protective earth conductor. See
rating plate for required fusing 9:.
■ The socket must be near the
appliance and freely accessible
following installation.
If the plug is not freely accessible, an
allpole disconnector with a contact
opening of at least 3 mm must be
fitted on the installation side to
satisfy the relevant safety
instructions.
■ The connection may be modified
by technicians only.
■ A power cord extension may be
purchased from customer service
only.
■ Use only a residual current operated
circuit-breaker which features the
symbol ‚. Only this extension
guarantees compliance with
the currently valid regulations.
■ The appliance features a water
damage protection system. Please
note the system will function only
when the power supply
is connected.
Removal
Also observe
the sequence of worksteps here.
1. Disconnect the appliance from the
power supply.
2. Turn off the tap.
3. Undo the waste water and drinking
water connection.
4. Loosen fastening screws for the
furniture parts.
5. If fitted, remove the base panel.
6. Pull out the appliance, carefully
pulling the hose behind.
48
Installation and connection en
Transporting
Empty the dishwasher and secure loose
parts.
Drain the appliance according to the
following steps:
1. Turn on water supply.
2. Switch on ON/OFF switch (.
3. Select programme with the highest
temperature.
The estimated programme duration
appears in the display window )".
4. Press START button P.
Programme sequence starts.
5. After about 4 minutes, repeatedly
press the START button P until
‹:‹‚ appears in the display window.
After about 1 minute the display
window will show ‹:‹‹.
6. Switch off ON/OFF switch (.
7. Turn off water supply, disconnect
supply hose and drain water.
Note: Always transport the dishwasher
upright. This prevents residual water
from getting into the machine’s controls
and causing the programme sequence
to malfunction.
Protection against frost
Prot ec t i on agai ns t frost (Empt yi ng the appl i ance)
If the appliance is in a room where
there is a risk of frost (e.g. holiday
home), empty the appliance completely
(see Transportation).
6XEMHFWWRFKDQJHV
49
$48$6723JXDUDQWHH
GRHVQRWDSSO\WRDSSOLDQFHVZLWKRXW$TXD6WRS
,QDGGLWLRQWRZDUUDQW\FODLPVDJDLQVWWKHVHOOHUEDVHGRQWKHSXUFKDVHFRQWUDFW
DQGLQDGGLWLRQWRRXUDSSOLDQFHZDUUDQW\ZHZLOOSD\GDPDJHVXQGHUWKHIROORZLQJ
FRQGLWLRQV
,IRXU$TXD6WRSV\VWHPLVGHIHFWLYHDQGFDXVHVZDWHUGDPDJH
ZHZLOOPDNHJRRGWKHGDPDJHIRUSULYDWHXVHUV
7RHQVXUHZDWHUGDPDJHSURWHFWLRQWKHDSSOLDQFHPXVWEHFRQQHFWHG
WRWKHSRZHUVXSSO\
7KLVOLDELOLW\JXDUDQWHHLVYDOLGIRUWKHVHUYLFHOLIHRIWKHDSSOLDQFH
$SUHUHTXLVLWHIRUWKHZDUUDQW\FODLPLVWKDWWKHDSSOLDQFHKDVEHHQFRUUHFWO\
LQVWDOOHGDQGFRQQHFWHGZLWK$TXD6WRSDFFRUGLQJWRRXULQVWUXFWLRQV
7KLVDOVRLQFOXGHVWKHFRUUHFWLQVWDOODWLRQRIWKH$TXD6WRSH[WHQVLRQ
RULJLQDODFFHVVRU\2XUZDUUDQW\GRHVQRWH[WHQGWRGHIHFWLYHIHHGOLQHV
RUILWWLQJVXSWRWKH$TXD6WRSFRQQHFWLRQRQWKHWDS
,I\RXUDSSOLDQFHLVILWWHGZLWK$TXD6WRS\RXFDQOHDYH\RXUDSSOLDQFHXQDWWHQGHG
GXULQJRSHUDWLRQDQGOHDYHWKHWDSWXUQHGRQDIWHUZDUGV7KHWDSVKRXOGRQO\
EHWXUQHGRIILI\RXDUHDEVHQWIURPKRPHIRUDSURORQJHGSHULRGHJVHYHUDO
ZHHNVKROLGD\
HQ
&RQVWUXFWD*PE+
&DUO:HU\6WUDH
0QFKHQ
7RERRNDQHQJLQHHUYLVLWDQGSURGXFWDGYLFH
3OHDVHILQGWKHFRQWDFWGDWDRIDOOFRXQWULHVLQWKHHQFORVHG
FXVWRPHUVHUYLFHOLVW
&216758&7$1())9(575,(%6*0%+
3RVWIDFK
0QFKHQ
*9001300951*
9001300951
(9708) 642 MA
Loading...
