Computer Tech Link 910TF User Manual

S/N : 9978626520

Model No : 910TF

COLOR MONITOR

USER’S GUIDE

CTL

1. Read all of these instructions.

2. Save these instructions for later use.

3. Unplug this monitor from the
wall outlet before cleaning. Do not
use liquid cleaners or aerosol
cleaners. Use a damp cloth for
cleaning.

4. Do not use attachments not recommended by
the monitor manufacturer as they may cause
hazards.

5. Do not use this monitor near water, e.g., near a
bathtub, washbowl, kitchen sink, or laundry tub,
in a wet basement, or near a swimming pool, etc.

6. Do not place this monitor on an
unstable cart, stand, or table. The
monitor may fall, causing serious
injury to a child or adult, and
serious damage to the appliance.

7. Slots and openings in the
cabinet and the back or bottom are
provided for ventilation, to ensure
reliable operation of the monitor,

and to protect it from overheating.
These openings must not be blocked or covered.
The openings should never be blocked by
placing the monitor on a bed, sofa, rug, or other
similar surface. This monitor should never be
placed near or over a radiator or heat register.
This monitor should not be placed in a built-in
installation such as a bookcase unless proper
ventilation is provided.

8. This monitor should be operated
only from the type of power source
indicated on the marking label. If
you are not sure of the power
supplied to your home, consult

your monitor dealer or local power company.

9. This monitor is equipped with a
3-wire grounding-type plug, That
is, a plug having a third
(grounding) pin. This plug will

only fit into a grounding-type
power outlet. This is a safety feature. If you are
unable to insert the plug into the outlet, contact
your electrician to replace your obsolete outlet.
Do not defeat the purpose of the grounding-type
plug.

10. Do not allow anything to rest

on the power cord. Do not locate

this monitor where the cord will be

abused by people walking on it.

11. Follow all warnings and instructions marked
on the monitor.

IMPORTANT SAFEGUARDS

12. For added protection for this
monitor during a lightning storm,
or when it is left unattended and
unused for long periods of time,
unplug it from the wall outlet. This

will prevent damage to the monitor and/or the
computer due to lightning and power line surges.

13. Do not overload wall outlets and extension
cords as this can result in fire or electric shock.

14. Never push objects of any kind into this
monitor through cabinet slots, as they may touch
dangerous voltage points or short out parts that
could result in a fire or electric shock. Never spill
liquid of any kind on the monitor.

15. Do not attempt to service this
monitor yourself, as opening or
removing covers may expose you
to dangerous voltages or other
hazards. Refer all servicing to

qualified service personnel.

16. Unplug this monitor from the wall outlet and
refer servicing to qualified service personnel
under the following conditions:

a. When the power cord or plug is damaged or
frayed.

b. If liquid has been spilled into the monitor.
c. If the monitor has been exposed to rain or

water.
d. If the monitor does not operate normally by

following the operating instructions. Adjust only
those controls that are covered by the operating
instructions, as improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore normal operation.

e. If the monitor has been dropped or the cabinet
has been damaged.

f. When the monitor exhibits a distinct change in
performance, this indicates a need for service.

17. When replacement parts are
required be sure the service
technician has used replacement
parts specified by the manufacturer

that have the same characteristics as
the original part. Unauthorized substitutions
may result in fire, electric shock, or other
hazards.

18. Upon completion of any service or repairs to
this monitor, ask the service technician to
perform routine safety checks to determine that
the monitor is safe to operate.

FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT

NOTE : This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures :

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.

- Consult the dealer or an experienced radio or TV technician for help.

CAUTION : Any changes or modifications not expressly approved by the

party responsible for compliance could void the user

’s authority

to operate the equipment.

CANADIAN NOTICE

AVIS CANADIEN

This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.

Cet appareil numérique de la Class B respecte toutes les exigences du
Règlement sur le matériel brouilleur du Canada.

The power cord is used as a main disconnect device. Disconnect the
power cord before servicing. The outlet must be installed near the monitor
and must be easily accessible.

As an ENERGY STAR Partner, Computer Technology Link, Inc. has
determined that this product meets the Energy Star guidelines for energy
efficiency.

Introduction ............................................................................. 1

Product Features ................................................................. 2

Setup ......................................................................................... 3

Connecting the Signal Cable and Power Cord..................... 3

Operation & Adjustment ...................................................... 4

Specifications ........................................................................... 9

Factory Preset Timings ........................................................... 9

Troubleshooting ..................................................................... 10

Description for D-sub Connector ......................................... 11

This manual explains how to correctly install, operate and get the
best performance from your monitor. Please read this user’s
guide carefully before installing your monitor, then keep it near
your monitor for quick reference.

First, please check that the contents of the box corresponds with
the following checklist :

• Color monitor

• Power cord

• User’s Guide

• Warranty Handbook

• Registration Card

If any item is missing or damaged, please contact your dealer.
Please keep the box and packing materials so that you may
properly store or transport your monitor.

English - 1
