Compex Systems WLU108G User Manual

Quick Install Guide

Wireless 108Mbps Super-G

TM

XR

USB 2.0 Adapter

WLU108G

Table of Contents

1: Introduction ................................................................................... 1

Packaging Content................................................................................ 1

2: Drivers & Utility Installation............................................................ 3

3: Remove USB Adapter from the System ................................... 12

4: Un-install Compex WLU108G Utility ........................................... 14

Warranty Registration Card .............................................................. 19

i

Chapter 1 Introduction

1: Introduction

Compex WLU108G is a thumb-sized USB
adapter with Super-G advantage, which
enhances the performance of IEEE

802.11b/g more powerfully and efficiently.
With its plug and play operation, easy-to­use configuration utility and small size, it
not only eliminates the usual hassle of
hardware installation but also gives you fast reliable Internet access.

Packaging Content

Actual product appearance may slightly differ depending on the hardware
version.

1 x Compex WLU108G

1 x Product CD

1 x External USB cable

1 x Read-Me-First Note

1

Chapter 1 Introduction

Important notes to remember:

! Designed with a USB2.0 interface, the Compex WLU108G can provide 40

times higher throughput when connected to the USB2.0 slot of your
PC/notebook. It is also backwards compatible with USB1.1 through the
throughput will then be limited to the 12Mbps of the USB1.1 standard.

! The router/AP that you are connecting to using the WLU108G must be

enabled with Super G technology in order to achieve higher throughput.

2

Chapter 2 Drivers & Utility Installation

2: Drivers & Utility Installation

The following installation process is based on Windows XP.

Insert Compex WLU108G directly
into the USB slot of your
PC/notebook.

Or

Use the USB external cable
provided to attach the WLU108G
to the USB slot on your
PC/notebook.

Next, insert the Product CD into your computer CD-ROM drive. Click on
Driver/Utility and the system will run the

setup.exe

automatically.

3

Chapter 2 Drivers & Utility Installation

Next, the Atheros Client Installation Program screen appears. Click on the
Next> button to proceed.

When the License Agreement screen appears, you are required to read and
accept the agreement to continue. Click on the Next> button to proceed.

4

Chapter 2 Drivers & Utility Installation

Select your preferred setup:

Install Client Utilities and Driver (Recommended) option
You are recommended to select this setup type. This option will install both the
drivers and utility that support your USB adapter.

Install Driver Only option (For Windows XP user only)
Select this option if you are going to use the Wireless Zero Configuration Utility
to configure your USB adapter. Note that only Windows XP comes with the
Wireless Zero Configuration Utility.

Make Driver Installation Diskette(s)
Select this option if you wish to make a duplicate copy of the drivers and store
in the diskette/s.

Click on the Next> button and follow the instructions stated on the screen.

5
