“Quick Install Guide”
Compex MicroHubâ/6, 6-Port
RJ-45 Ethernet Hub
TP1006C
Compex MicroHubâ/8, 8-Port
RJ-45 + BNC Ethernet Hub
TP1008C
Compex MicroHubâ/16, 16-Port
RJ-45 + BNC + AUI/Fiber
Optic
Ethernet Hub
TP1016C/ TP1016F
Version 1.4C
•
|
|
† |
|
|
|
|
|
|
„ ‚ |
… |
|
|
|
ƒ |
|||||
|
|
|
|
|
Figure 1: TP1016F Front Panel |
||||
|
|
‰ ˆ |
|
‡ |
|
|
|
|
|
Figure 2: TP1016F Back Panel (Magnify) |
|
… |
|
|
† |
|
• |
|
|
|
|
||
|
|
|
|
|
|
ƒ „ ‚
Figure 3: TP1016C Front Panel
‰ |
ˆ |
‡ |
Figure 4: TP1016C Back Panel
Figure 5: TP1006C and TP1016C Hubs in a network
Figure 6: Expanding long distance network using Fiber Optic Link of TP1016F
• ‚ |
ƒ |
|
• |
‚ ƒ |
Figure 7: Front Top Panel View of MicroHub TP1008C & TP1006C |
||||
|
|
|
† |
|
|
Figure 8: Back Panel View of MicroHub TP1006C |
|||
‡ |
|
† |
|
|
|
Figure 9: Back Panel View of MicroHub TP1008C |
|||
|
… |
ˆ |
Š |
|
Figure 10: Side Panel of MicroHub TP1006C & TP1008C |
||||
Contents
³Diagrams
³English Text
³German Text
³Russian Text
³French Text
³Notes
³Technical Support
Front Flap
Page 1
Page 5
Page 9
Page 13
2nd Last Page
Last Page
“Quick Install Guide”
♦ Compex MicroHubâ/6, 6-Port RJ-45
Ethernet Hub (TP1006C);
♦ Compex MicroHubâ/8, 8-Port RJ-45 + BNC
Ethernet Hub (TP1008C);
♦ Compex MicroHubâ/16, 16-Port RJ-45 +
BNC/AUI/Fiber Optic**
Ethernet Hub (TP1016C/ TP1016F**)
±Introduction
The Compex MicroHubâ/8 (TP1008C); Compex MicroHubâ/6 (TP1006C); and Compex MicroHubâ/16; (TP1016C/ TP1016F) are multi-port Ethernet hubs that bring unmatched flexibility to LAN environments. There are multi-wiring connections for up to 6 (TP1006C); or 8 (TP1008C); or 16 (TP1016C/TP1016F) UTP ports. In addition, there is: a BNC (TP1008C); or a BNC/AUI (TP1016C); or a Fiber Optic (TP1016F) port for easy, direct connection to different LAN media segments. The TP1006C/TP1008C;/ TP1016C/TP1016F hubs constantly monitor each port for signal quality and will automatically disconnect a device producing noise or excessive collisions. The disconnected device will be reconnected automatically when the error condition is cleared.
± |
Hub Features (see diagrams on inner cover) |
|
||
|
|
|
|
|
• |
Power LED |
♦ ON indicates hub is receiving power. |
|
|
‚ |
Collision LED |
♦ BLINKS to indicate collision of transmitted |
|
|
|
|
|
packets occuring. |
|
ƒ |
Link/Activity LED |
♦ STEADY LIGHT indicates a good cable link |
|
|
|
(TP1006C/TP1008C/TP1016C/ |
between adapter and hub; |
|
|
|
TP1016F) |
♦ BLINKS to indicate network activity present. |
|
|
„ |
Jabber LED |
♦ BLINKS to indicate transmission of packet/s |
|
|
|
(TP1016C/TP1016F) |
exceeding the specified time. |
|
|
… |
Uplink Button (TP1016C): |
♦ Uplink mode when button is released OUT. |
|
|
|
|
(TP1006C/TP1008C): |
♦ Uplink mode (button shift Left). |
|
† |
6 |
RJ-45 Ports (TP1006C) ; |
♦ Configurable as 6; /8; / 16 UTP ports or 5; /7; / |
|
|
8 |
RJ-45 Ports (TP1008C) or |
15 UTP ports plus 1 UTP Uplink Port (Port #1). |
|
|
16 RJ-45 Ports (TP1016C/F) |
|
|
|
‡ |
1 BNC;/ 1 BNC-1 AUI;/ |
♦ BNC or AUI or Fiber Optic for connection to a |
|
|
|
1 BNC-1 Fiber Optic Port; |
different LAN media segment. |
|
|
ˆ |
DC Power Socket |
♦ Jack for connection to an external Output |
|
|
|
(TP1006C/TP1008C);/ |
Power adapter (DC 7.5V @ 1 Amp); |
|
|
|
AC Power Socket |
♦ Flexible power input (range 90VAC to |
|
|
|
(TP1016C/ TP1016F) |
250VAC) meets every country requirement. |
|
|
‰ |
ON/OFF Power Switch |
♦ Provides a convenient means to power-up or |
|
|
|
(TP1016C/TP1016F) |
shutdown the hub. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
English Compex MicroHubâ/6 (TP1006C); 1
Compex MicroHubâ/8 (TP1008C);
Compex MicroHubâ/16 (TP1016C/ TP1016F)
|
|
|
Š |
Socket (TP1006C/TP1008C -- |
♦ Optional jack for tapping keyboard’s 5V power |
|
connect to keyboard) |
supply. |
Caution: Compex will not be liable for any damage arising from using the hub operated from either the keyboard power tap or mouse port tap. Please check with your
computer equipment vendor on the availability of not less than 300mAmp at 5V DC on your mouse or keyboard socket.
± Features:
♦Cost effective, unmanaged hub allowing interconnection of different media such as Fiber Optic or Thin (BNC) or Thick (AUI) with UTP segments within a single device.
♦Connects up to 6;/ 8;/ 16 UTP 10Base-T link; and one Thin (BNC) and/or one Thick (AUI) Ethernet link or one Multi-mode Fiber Optic Link.
♦Detects network collisions and alerts all participating host devices. Amplifies and re-times received signals and transmits the signals to attached host devices in the event of a collision.
♦Preamble regeneration, signal retiming and restoration, extension of fragmented packets and jabber function for automatic partitioning to isolate network failure.
♦Global power, collision, jabber LEDs and individual port Link/Activity LED to aid network diagnosis and management.
♦Performs full 10Mbps Ethernet multi-port repeater functions and complies with IEEE802.3 standard for 10Base-T Unshielded Twisted Pair (UTP); and 10Base-2 Thin Coaxial (BNC) or 10Base-5 Thick Coaxial (AUI) or 10Base-F (Fiber Optic).
♦TP1016F has 10Base-FL Port that support long distances up to 2km.
±Specifications:
♦ |
Industry |
Complies with IEEE802.3, 10Base-T and 10Base-2, |
|
|
|
Standards: |
10Base-5 or 10Base-FL standard, FCC Class A, CE |
|
|
|
|
Mark. |
|
|
♦ |
Interface: |
Supports 6;/ or 8;/ or 16 station ports for either clients, |
|
|
|
|
servers or downlink hubs. A designated Uplink port |
|
|
|
|
provides easy cascading to another hub: Port #1 (button |
|
|
|
|
shift Left) for TP1008C or TP1006C; and Port #1 (button |
|
|
|
|
released OUT) for TP1016C or TP1016F. |
|
|
|
|
|
|
|
♦ |
Link Distance |
♣ |
10Base-T : Requires UTP (3,4 or 5) cable. |
|
|
|
|
Maximum segment length is 100m. |
|
|
|
♣ 10Base-FL : Requires Multi-mode fiber Optic cable |
|
|
|
|
|
with wave length 820nm. Maximum length is 2 km. |
|
|
|
|
|
|
♦ |
Uplink and |
Requires 2 twisted-pairs UTP cable (Category 3, 4, and |
|
|
|
Downlink ports: |
5). |
Segment length can be up to a maximum of 100 |
|
|
|
meters. When cascading using the Uplink port, the |
|
|
|
|
segment length can be up to a maximum of 100 meters. |
|
|
|
|
|
|
|
|
|
|
|
|
2 Compex MicroHubâ/6 (TP1006C); English
Compex MicroHubâ/8 (TP1008C);
Compex MicroHubâ/16 (TP1016C/ TP1016F)
