SER’S GUIDE
U
Compaq TFT5010 Flat Panel Monitor
Notice
The information in this guide is subject to change without notice.
COMPAQ COMPUTER CORPORATION SHALL NOT BE
LIABLE FOR TECHNICAL OR EDITORIAL ERRORS OR
OMISSIONS CONTAINED HEREIN; NOR FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES RESULTING FROM THE
FURNISHING, PERFORMANCE, OR USE OF THIS MATERIAL.
This guide contains information protected by copyright. No part of
this guide may be photocopied or reproduced in any form without
prior written consent from Compaq Computer Corporation.
1999 Compaq Computer Corporation.
All rights reserved.
Compaq and Deskpro are registered in the U. S. Patent and
Trademark Office.
Microsoft, MS-DOS, Windows, Windows NT, and other names of
Microsoft products referenced herein are trademarks or registered
trademarks of Microsoft Corporation.
E
NERGY STAR
Product names mentioned herein may be trademarks and/or
registered trademarks of their respective companies.
is a U.S. registered mark.
The software described in this guide is furnished under a license
agreement or nondisclosure agreement. The software may be used
or copied only in accordance with the terms of the agreement.
User’s Guide
Compaq TFT5010 Flat Panel Monitor
First Edition (October 1999)
Part Number 157253-001
Compaq Computer Corporation
English
Product Features
The Compaq TFT5010 Flat Panel Monitor has an active matrix, thinfilm transistor (TFT), liquid crystal display (LCD). The monitor
features include:
15-inch (38.1-cm) viewable area display
■
1024 × 768 resolution, plus full-screen support for lower
■
resolutions
Wide viewing angle to allow viewing from a sitting or standing
■
position, or when moving side-to-side
Tilt and swivel capabilities
■
Removable base for flexible mounting solutions
■
Includes DVI signal connector (two DVI cables included - one
■
digital and one analog); a digital connection requires a special
digital-compatible graphics adapter card
Plug and Play capability if supported by your system
■
On-Screen Display (OSD) adjustments in six different languages:
■
English, Dutch, French, German, Italian, and Spanish for ease of
set-up and screen optimization
Programmable Sleep Timer
■
CD-ROM includes an information file (INF), Image Color
■
Matching file (ICM), Colorific Software package, the Compaq
LCD Display Assistant setup and configuration utility, the
Compaq Display LiteSaver utility, and product documentation
Model with additional protective panel available
■
Security lock slot
■
AssetControl
■
Energy Saver feature for Energy Star compliance
■
Monitor base includes a housing space for an optional USB hub
■
English 1
Compliance with the following regulated specifications:
■
❏
❏
❏
❏
NERGY STAR
EPA E
European Union CE Directives
Swedish MPR II 1990
Swedish TCO '99
Universal Driver Manager
This monitor may require a graphics driver (and/or .INF file) that is
compatible with your computer’s graphics adapter. The CD-ROM
included with this monitor contains an .INF file (see the section on
Information Files). Compaq has also created a Universal Driver
Manager (UDM) release that supports all graphics adapters found on
Compaq Deskpro and Compaq Workstation products. The UDM eases
graphics driver deployment across Compaq platforms ensuring crosscompatibility and backward-compatibility. The resulting solution
enables customers to manage and control ongoing software
maintenance costs. The UDM is available on the
Software CD
for Compaq Desktop, Portable, and Workstation
Compaq Support
Products and the Compaq World Wide Web site (www.compaq.com).
Information Files
This monitor includes a CD-ROM with two information files to be
installed onto your computer—an .INF file and an .ICM file.
The .INF file defines monitor resources and provides
■
specifications used by Microsoft Windows 95 and Windows 98
to install support software for certain hardware devices. The .INF
file ensures monitor compatibility and optimization with your
computer’s graphics adapter.
The .ICM file provides color matching consistency from monitor
■
screen to printer and is activated from within the graphics
programs that have this feature.
To install these files on your computer, follow the instructions on the
CD-ROM or on the “Configuring Your Compaq LCD Monitor” card
located in the Program License Agreement packet along with the CDROM. INF file updates are downloadable by clicking on:
www.compaq.com/products/monitors/index.html
2 English
Setting Up the Monitor
To set up the monitor, ensure that the power is turned off to the
monitor, computer system, and other attached devices, then follow
these steps:
1. Place the monitor in a convenient, well-ventilated location near
your computer.
2. Connect the DVI-I monitor signal cable to the VGA connector
on the rear panel of the computer.
1
The monitor is shipped with the DVI-I cable already
✎
connected to the monitor. When the monitor is connected
to the computer using the DVI-I signal cable, it is using an
analog signal interface.
3. Connect one end of the AC power cord to the AC adapter 2 and
the other end 3 to an electrical outlet that is easily accessible
and close to the monitor.
English 3
CAUTION:
AC adapter supplied with the monitor. Failure to use this
AC adapter may result in damage to the monitor.
WARNING:
!
to your equipment:
„#
„#
„#
„#
✎
For security purposes, this monitor has been fitted with a
slot 4 for use with a security cable lock that can be
purchased separately at most computer stores.
After you turn on the monitor, install the Compaq LCD
✎
Display Assistant utility included on the CD-ROM. Use
the on-screen instructions to adjust the picture quality of
your monitor. To install this utility onto your computer,
follow the instructions on the “Configuring Your Compaq
LCD Monitor” card located in the Program License
Agreement packet.
When connecting the monitor, be sure to use the
To reduce the risk of electric shock or damage
Do not disable the power cord grounding plug. The
grounding plug is an important safety feature.
Plug the power cord into a grounded (earthed)
electrical outlet that is easily accessible at all times.
Disconnect power from the monitor by unplugging
the power cord from the electrical outlet.
Do not place anything on power cords or cables.
Arrange them so that no one may accidentally step on
or trip over them. Do not pull on a cord or cable.
When unplugging from the electrical outlet, grasp the
cord by the plug.
IMPORTANT:
mable sleep timer, the Compaq Display LiteSaver utility, or turn off
the monitor when it is not in use for a prolonged period of time. All
LCD monitors that display the same static image on the screen for a
prolonged period of time may exhibit screen image retention. Please
note that image retention is not a permanent condition and will fade
over a period of time. Image retention is a condition that may occur on
all LCD screens.
4 English
Always activate a screen saver program, the program-
Connecting the DVI-D Cable
To connect the DVI-D (Digital Visual Interface-Digital) cable to the
DVI-I (Digital Visual Interface-Integrated) connector on the back of
the monitor, you must first remove the monitor base cover and the
monitor back panel and disconnect the DVI-I connector.
Before beginning to disassemble the monitor, be
CAUTION:
sure the monitor is turned off and the power and signal
cables are both disconnected
The DVI-D cable supplied with this monitor is for digital
✎
to digital connection only. Your computer must have a
DVI-compatible graphics card installed for use with this
cable. When connecting the DVI-D signal cable to the
DVI connector on the monitor, you must connect the other
end of the DVI-D cable to the DVI connector on the
computer.
To remove the monitor base cover and back panel, complete the
following steps:
1. Lay the front bezel down on a soft area to prevent it from
getting scratched, defaced, or broken.
2. Remove the cover 1 from the monitor base by placing your
fingers in the opening on the bottom of the base and pulling
upward, then pulling out to remove the cover.
.
3. Remove the back panel 2 from the monitor by pushing the
bottom tabs upward and pulling out to remove the panel.
English 5
4. Connect the DVI-D cable to the DVI-I connector 1 on the back
panel of the monitor by threading the cable through the neck
yoke on the monitor base to the DVI-I connector, then connect
the other end of the cable 2 to the DVI connector on the back
panel of the computer.
6 English
5. Replace the monitor back panel and monitor base cover.
6. Reconnect the power cable and power on the monitor and
computer.
The DVI connector on this monitor uses digital video information to
provide higher speed for higher display resolution. The results are
more precise video displays without manually adjusting screen display
quality.
DVI Cables included
DVI-I Cable (Analog) to VGA Connector (15 pin)
DVI-D Cable (Digital only) to Digital Connector
English 7
Adding a Compaq Powered USB Hub
The monitor base is designed to house an optional Compaq Powered
USB hub. The Compaq Powered USB hub is not included with the
monitor. It is sold separately. For information on purchasing the
Compaq Powered USB hub (part no. 138638-xxx), call your Compaq
authorized dealer, seller, or reseller. To locate a reseller near you, call
Compaq at 1-800-AT-COMPAQ or visit the Compaq web site at
http://www.compaq.com .
To remove the housing cap from the base:
1. Press down on the top of the cap.
2. Pull the cap outwards to remove it.
The following are required to operate the Compaq Powered USB hub:
Your computer must be fitted with a USB port.
■
Your computer must have Microsoft Windows 95 OSR2.1 or
■
later, or Microsoft Windows 98 as the operating system.
USB connectors are used to connect USB-compatible Plug and Play
devices such as a keyboard, mouse, or joystick to the USB hub using
Plug and Play install procedures. Plug and Play install procedures
consist of plugging in the USB device while the system is turned on
and using it without reconfiguring your computer.
8 English
Removing the Monitor Base
Before you can mount the monitor onto a swing arm or other mounting
fixture, you must remove the monitor from the base.
Before beginning to disassemble the monitor, be
CAUTION:
sure the monitor is turned off and the power and signal
cables are both disconnected.
To remove the monitor from the base, complete the following steps:
1. Lay the front bezel down on a soft area to prevent it from
getting scratched, defaced, or broken.
2. Remove the cover 1 from the monitor base by placing your
fingers in the opening on the bottom of the base and pulling
upward, then pulling out to remove the cover.
3. Remove the back panel 2 from the monitor by pushing the
bottom tabs upward and pulling out to remove the back panel.
4. Disconnect and remove the signal and power cables from the
back of the monitor.
5. Remove the four screws 3 as shown in the following
illustration.
English 9
Ensure that the bottom of the monitor base is
CAUTION:
positioned over a table or desktop before removing the
base from the monitor.
6. Remove the monitor base from the monitor.
When the base is removed, four threaded mounting holes are exposed
on the monitor panel to be used for mounting purposes. These
mounting holes are spaced 75 mm apart and are compliant with the
Video Electronics Standards Association (VESA) standard for
mounting flat panel displays.
To mount the monitor on a swing arm or other mounting fixture,
follow the instructions included with the mounting fixture to be used.
10 English
Operating the Monitor
Front Panel Controls
No./Icon Control Function
1.
1
2
3
4
5
Menu button
−
+
Minus button 1. Selects and adjusts the functions.
Plus button Selects and adjusts the functions.
Power switch Turns the monitor on and off.
Power LED 1. Green indicates monitor is turned on.
Launches 1st and 2nd-level on-screen menus.
2. Exits menus and on-screen display.
2. Activates Auto Adjust when the OSD menu is
inactive.
2. Yellow indicates Suspend mode.
3. Amber indicates Sleep mode.
4. Blinking Amber indicates Sleep Timer*.
*Sleep Timer enables you to set a time for the monitor to
power on and power off at the same time every day. It
eliminates the need to turn off the monitor at the end of the
day and conserves energy. To set this mode, refer to the
Sleep Timer in the on-screen display.
English 11
On-Screen Display Settings
The adjustments for screen settings are located in the on-screen display
(OSD) and can be viewed in one of six available languages. The
following menus show the functions at each level:
Main Menu
Menu Level 1 Menu Level 2 Menu Level 3
Brightness Adjustment scale
Contrast Adjustment scale
Auto Adjust
Advanced Menu
Exit
Advanced Menu
Brightness Adjustment scale
Contrast Adjustment scale
Auto-Adjustment
Position Horizontal Position
Vertical Position
Cancel
Save and Return
Digital Conversion Clock
Clock Phase
Cancel
Save and Return
Color 9300 K
6500 K
Custom Color
Cancel
Save and Return
Language Deutsch
English
Espanol
Francais
Italiano
Nederlands
Cancel
Save and Return
Adjustment scale
Adjustment scale
Adjustment scale
Adjustment scale
Color adjustment scale
12 English
Advanced Menu (Continued)
Management Full Screen
Power Saver
Mode Display
Serial No.
Sleep Timer
Basic Menu
Cancel
Save and Return
Factory Reset Cancel Reset
Exit
How to Adjust Settings
1. Launching the on-screen display Menus:
❏
To display the Basic Menu on the monitor screen: Press
the Menu button 1 on the monitor front panel.
Yes No
Yes No
Yes No
Displays Serial No.
Set Time and On/Off Times
❏
To display the Advanced Menu: Press the Menu button
on the monitor front panel to display the Basic Menu, use
the Minus 2 or Plus 3 buttons to scroll to and highlight
the Advance Menu selection, then press the Menu button
1
again.
Monitor with On-Screen Display
1
English 13
✎
After the Advanced Menu has been selected, it remains
the default on-screen display each time the monitor is
powered on until the Basic Menu option is re-selected.
2. To select an item from the Main Menu, scroll down and
highlight an item by pressing the Minus (-) button 2 located on
the monitor front panel. To reverse or back up, press the Plus
(+) button 3.
3. Highlight your choice and press the Menu button 1 again.
4. Adjust the second-level menu displays using the same
procedures as the first level.
✎
The second-level menus for Brightness and Contrast
displays an adjustment screen. Use the Minus button to
decrease and the Plus button to increase the screen
brightness and contrast.
5. Access the third level menu by selecting a function and pressing
the Menu button. Adjust the third level menu displays using the
same procedures as the second level.
6. To exit from the on-screen menu, select
Menu. If the display is a second or third-level menu, select
and Return
Menu.
The on-screen display is easy to use, just follow the instructions on the
screen.
14 English
or
Cancel,
then select
from the Advanced
Exit
from the Advanced
Exit
Save
Special OSD Messages
Special OSD messages will appear on the monitor screen when
identifying the following monitor conditions:
Input Signal Out of Range
■
—Indicates the monitor is unable to
access the appropriate input signal.
Going to Sleep
■
—Indicates the screen display is entering a sleep
mode.
Check Video Cable
■
—Indicates the video cable may not be
plugged into the computer or the computer may not be turned on.
Sleep Timer Mode
The Sleep Timer mode is an energy-saving feature that enables you to
set a time for the monitor to power on and off at the same time every
day. This also extends the life of the backlight bulbs in the monitor.
The Sleep Timer has five settings:
Set Current Time
■
Set Sleep Time
■
Set On Time
■
Timer: On/Off
■
Sleep Now
■
To set the timer:
1. Press the Menu button on the monitor front panel to display the
Advanced Menu.
2. Scroll down and highlight
3. Press the Menu button to select
4. Scroll down and highlight and select
.
Time
✎
You must set the current local time before you reset the
time for
Sleep Time
or
Management.
Management.
Sleep TimerÆ Set Current
On Time.
English 15
5. Press the Menu button once to enter the adjustment mode for
hours.
6. Press the Minus or Plus buttons to adjust the hour.
7. Press the Menu button again to enter the time for minutes.
8. Press the Minus or Plus buttons to adjust the minutes.
9. Press the Menu button to lock in the time chosen.
10. After setting the current time, the highlight automatically skips
to
Set Sleep Time
“hours.” Repeat steps 6 through 9 to set
Sleep
Time.
If you do not want to set
twice, then select
Save and Return
Sleep Time,
press the Menu button
to exit the menu.
11. After setting Sleep Time, the highlight automatically skips to
Set On Time
“hours.” Repeat steps 6 through 9 to set
On Time
12. Set the Timer mode to On to activate the Sleep Timer settings.
13. When you are finished, select
The fifth selection
Sleep Now
turns the monitor backlights off
Save and Return
immediately and stays in sleep mode until the next
to exit the menu.
On Time
activates
or a monitor button is pressed.
.
16 English
Adjusting Screen Quality
Allow the monitor to warm up for 20 minutes before performing the
following procedures.
The Auto Adjustment feature in the OSD automatically fine-tunes the
image quality each time a new video mode is utilized. If additional
improvement is desired, select "Auto Adjust" in the Basic Menu.
For more precise adjustments, use the Compaq LCD Display Assistant
utility included on the CD-ROM. This utility graphically illustrates
how to adjust the Clock and Clock Phase controls explained in the
Optimizing Digital Conversion
✎
The Compaq LCD Display Assistant utility is used to adjust the
screen quality of your monitor. This utility provides on-screen
instructions. To install this utility onto your computer, follow the
instructions on the “Configuring Your Compaq LCD Monitor”
card located in the Program License Agreement packet.
Optimizing Digital Conversion
This monitor contains advanced circuitry that allows the flat panel
screen to function like a standard monitor. Two controls in the onscreen display can be adjusted to improve image performance: Clock
and Clock Phase.
section below.
IMPORTANT:
Phase settings are dependent on the main Clock setting.
Clock—Increase/decrease the value to minimize any vertical bars
■
or stripes visible on the screen background.
Clock Phase—Increase/decrease the value to minimize video
■
distortion or video jitter.
✎
The Clock must first be set correctly since the Clock
When adjusting the Clock and Clock Phase values, if the
monitor images become distorted, continue adjusting the
values until the distortion disappears. To restore the factory
settings, select Yes from the
screen display.
Factory Reset
menu in the on-
English 17
Display Resolutions
The display resolutions listed below are the most commonly used
modes and are set as factory defaults. This monitor automatically
recognizes these preset modes and they will appear properly sized and
centered on the screen.
Display Resolutions
Preset Modes
1. Industry Standard 640 × 350 at 31.5 kHz/70 Hz
2. Industry Standard 640 × 480 at 31.5 kHz/60 Hz
3. VESA 640 × 480 at 37.5 kHz/75 Hz
4. VESA 640 × 480 at 43.3 kHz/85 Hz
5. Industry Standard 720 × 400 at 31.5 kHz/70 Hz
6. VESA 800 × 600 at 37.9 kHz/60 Hz
7. VESA 800 × 600 at 46.9 kHz/75 Hz
8. VESA 800 × 600 at 53.7 kHz/85 Hz
9. Macintosh-compatible 832 × 624 at 49.7 kHz/75 Hz
10. VESA 1024 × 768 at 48.4 kHz/60 Hz
11. VESA 1024 × 768 at 56.5 kHz/70 Hz
12. VESA 1024 × 768 at 60 kHz/75 Hz
Resolutions
User Modes
The video controller signal may occasionally call for a mode that is not
preset if:
You are not using a Compaq standard graphics adapter.
■
You are not using a preset mode.
■
If this occurs, you may need to readjust the parameters of the monitor
screen by using the on-screen display. User changes can be made to
any or all of these modes and saved in memory. The monitor
automatically stores the new setting, then recognizes the new mode
just as it does a preset mode. In addition to the 12 factory preset
modes, there are four user modes that can be entered and stored.
18 English
Energy Saver Feature
The energy saver feature has four different modes of operation:
Full power
■
Suspend/Standby
■
Sleep
■
Programmable Sleep
■
By selecting settings in the computer's Energy Saver utility, you are
able to determine the length of the inactivity period before the monitor
goes into sleep or programmable sleep mode.
The following table describes the monitor energy saver levels available
during the different modes of operation.
Energy Saver Levels
Mode Power Usage Description
Full Power Less than
45 watts
Suspend/Standby Less than
8 watts
Sleep Less than
5 watts
Programmable
Sleep
Less than
5 watts
ON = Normal operation
Power LED is green.
Monitor screen is blanked. Backlights are
turned off. Power LED turns yellow. There
is a brief warm-up period before returning
to full power mode.
Monitor screen is blanked. Backlights are
turned off. Power LED turns amber. There
is a brief warm-up period before returning
to full power mode.
Monitor screen is blanked. Backlights are
turned off. Power LED blinks amber. There
is a brief warm-up period before returning
to full power mode.
Refer to your computer manual for instructions on setting energy saver
features (sometimes referred to as power management features).
✎ The energy saver features for monitors only work when
connected to computers that have energy saver features.
English 19
Care and Maintenance
This section explains how to care for and maintain your Compaq
monitor during normal everyday use.
Protecting the Monitor
To protect your monitor from overheating and other types of damage,
follow these suggestions:
Use only a power source and connection appropriate for this
■
monitor, as indicated on the marking label/back plate and the AC
adapter.
If an extension cord or power strip is used, make sure that the
■
cord or strip is rated for the product and that the total ampere
ratings of all products plugged into the extension cord or power
strip do not exceed 80% of the extension cord or strip ampere
ratings limit.
Do not overload an electrical outlet, power strip, or convenience
■
receptacle. The overall system load must not exceed 80% of the
branch circuit rating. If power strips are used, the load should not
exceed 80% of the power strip input rating.
Install the monitor near an outlet that you can easily reach.
■
Disconnect the product by grasping the plug firmly and pulling it
from the outlet. Never disconnect it by pulling the cord.
Unplug the monitor from the wall outlet before cleaning. Do not
■
use liquid cleaners or aerosol cleaners.
Slots and openings in the cabinet are provided for ventilation.
■
These openings must not be blocked or covered. Never push
objects of any kind into cabinet slots or other openings.
Do not drop the monitor or place it on an unstable surface.
■
Do not allow anything to rest on the power cord. Do not walk on
■
the cord.
20 English
Keep the monitor in a well-ventilated area, away from excessive
■
light, heat, and moisture. Keep the monitor away from high
capacity transformers, electric motors, and other strong magnetic
fields.
Do not open the monitor cabinet or attempt to service this
■
product yourself. Adjust only those controls that are covered by
the operating instructions. If the monitor is not operating
properly or has been dropped or damaged, contact your Compaq
authorized dealer, reseller, or service provider.
Cleaning the Monitor
To clean the monitor, follow these steps:
1. Turn off the monitor and the computer.
2. Dust the monitor by wiping the screen and the cabinet with
a soft, clean cloth.
If the screen requires additional cleaning, use a clean cloth dampened
with isopropyl alcohol.
CAUTION:
Do not use benzene, thinner, ammonia, or any
volatile substance to clean the monitor screen or cabinet.
These chemicals may damage the monitor. Never use water
to clean an LCD screen.
Shipping the Monitor
Keep the original packing box in a storage area. You may need it later
if you move or ship your monitor.
English 21
appendix
Agency Regulatory Notices
Federal Communications Commission Notice
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
■
Increase the separation between the equipment and the
■
receiver.
Connect the equipment into an outlet on a circuit different
■
from the circuit that the receiver is connected.
Consult the dealer or an experienced radio or television
■
technician for help.
Modifications
The FCC requires the user to be notified that if any changes or
modifications are made to this device, not expressly approved by
Compaq Computer Corporation, this may void the user's authority
to operate the equipment.
Cables
Connections to this device must be made with shielded cables with
metallic RFI/EMI connector hoods to maintain compliance with
FCC Rules and Regulations.
Spcifications 1-22
Declaration of Conformity for products marked
with the FCC logo - United States only
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
For questions regarding your product, contact:
Compaq Computer Corporation
P.O. Box 692000, Mail Stop 530113
Houston, Texas 77269-2000
Or, call 1-800-652-6672 (1-800-OK COMPAQ)
For questions regarding this FCC declaration, contact:
Compaq Computer Corporation
P.O. Box 692000, Mail Stop 510101
Houston, Texas 77269-2000
Or, call (281) 514-3333
To identify this product, refer to the Part, Series, or Model number
found on the product.
Canadian Notice
This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Avis Canadien
Cet appareil numérique de la classe B respecte toutes les exigences
du Règlement sur le matériel brouilleur du Canada.
European Notice
Products with the CE Marking comply with both the EMC
Directive (89/336/EEC) and the Low Voltage Directive
(73/23/EEC) issued by the Commission of the European
Community.
Compliance with these directives implies conformity to the
following European norms:
EN55022 (CISPR 22) - Radio Frequency Interference
■
EN50082-1 (IEC801-2, IEC801-3, IEC801-4) -
■
Electromagnetic Immunity
EN60950 (IEC950) - Product Safety
■
1-23 Specifications
Japanese Notice
NERGY STAR
EPA E
Monitors that are marked with the E
requirements of the EPA E
S
Partner, Compaq Computer Corporation has determined that
TAR
this product meets the E
Compliance
NERGY STAR
NERGY STAR
NERGY STAR
guidelines for energy
Logo meet the
program. As an E
NERGY
efficiency. Specific details on using the Energy Saving features can
be found in the energy saver or power management section of the
computer manual.
Spcifications 1-22
Specifications
Compaq TFT5010 Flat Panel Monitor
Display
Type Flat panel, Active matrix-TFT LCD
Viewable Image Size
Face Treatment
Maximum Weight
(Unpacked)
Maximum Dimensions
Height 15.8 in 40.0 cm
Depth 8.6 in 21.8 cm
Width 15.4 in 39.1 cm
Maximum Graphics
Resolution
Text Mode
Pixel Pitch
Horizontal Frequency
Vertical Frequency
Environmental Requirements
Temperature (Independent of Altitude)
Operating Temperature
Storage Temperature
Humidity
(Noncondensing)
Operating
Nonoperating
Power Source
Power Consumption
Input Terminal
15-in 38.1 cm
15-in diagonal 38.1 cm
3H hardness coating with antiglare treatment
16.3 lb 7.4 kg
1024 × 768 at 75 Hz Refresh Rate
720 × 400
0.28 mm
32 to 60 kHz
57 to 85 Hz
50 to 104°F
-22 to 140°F
20 to 80%
5 to 95%
90 - 132/195 - 264 VAC, 50-60 Hz
< 45 watts
29-contact DVI connector with 2 cables included
10 to 40°C
-30 to 60°C
Color Display Values
CIE* Chromaticity Coordinates
x (+/- 0.030) y (+/- 0.030)
Red
Green
Blue
White Point
Gamma: 2.1
*Commission International d’Eclairage, 1931 Standard.
1-23 Specifications
0.61 0.34
0.29 0.62
0.14 0.13
0.31 0.34
Power Cord Set Requirements
If you were not provided with a power cord for your monitor, you
should purchase a power cord that is approved for use in your
country. The power cord must be rated for the product and for the
voltage and current marked on the product's electrical ratings label.
The voltage and current rating of the cord should be greater than
the voltage and current rating marked on the product. In addition,
the diameter of the wire must be a minimum of 0.75 mm2 or
18AWG, and the length of the cord must be between 6 feet (1.8 m)
and 12 feet (3.6 m). If you have questions about the type of power
cord to use, contact your Compaq authorized service provider.
A power cord should be routed so that it is not likely to be walked
on or pinched by items placed upon it or against it. Particular
attention should be paid to the plug, electrical outlet, and the point
where the cord exits from the product.
Spcifications 1-22
Loading...
