QuickSpecs
Overview
Models
Model N900
230050-001
Model C900
258123-001
Model N900s
230051-001
Model C900s
258124-001
Product Highlights
Compaq, the leader in Network Storage, delivers the
StorageWorks™ NAS B3000 by Compaq – the entry-point
into NAS/SAN fusion solutions bringing enterprise-level
availability, scalability and performance in a turnk ey
package
•
Entry-point to the fusion of NAS and SAN – Universal
Network Storage – provides the best utilization of
storage investment. Consolidate NAS a nd SAN into a
single, managed storage infrastructure
•
Enterprise level scalability – to 27 TB
•
Highly available solution – including clustering, RAID
ADG, fully integrated software packages, no-singlepoint-of-failure configurations available
•
Turnkey package – configurations include all of th e
components to provide high performance block- and
file-serving
Key Benefits
Maximized Return on Storage Investment
•
Multi-protocol file serving – support for Microsoft
Windows (CIFS), UNIX/Linux (NFS), Novell
NetWare (NCP), Apple (AppleTalk), HTTP and F TP
•
Minimize ongoing operational expenses associated with
file serving
•
Enable client s and applic ations to easily access dat a
over the existing network, while also r educing the cost
of accessing SAN based storage
•
Save money an d resources with centraliz ed storage and
system management
Unlimited Scalability
•
Grow your stor age capacity as your busines s growswithout downtime and without compromising
performance
•
Up to 27 TB capacity scalability, higher capacity can be
reached with external swit ches
•
The B3000 supports both 1 Gb/sec and 2 Gb/sec Fibre
channel fabri cs to ensure that your investment in
infrastruc ture is protect ed.
•
DAS to SAN means file data that is currently stored on
1″ Universal di sk drives using newer Compaq Smart
Array controllers, as well as file data on an RA4100 can
easily be migrated to the B3 000. Simply remove the
drives from the older systems and insert them i nto the
B3000. All configuration information and data will be
preserved allowing migration to be compl eted in
minutes, not hours or days.
Continuous Data Availability
•
Ensure that data is always available enabling business
continuance through:
•
Cluster Configurations
•
Advanced Dat a Guarding
•
Hardware redundancy
•
File replication
•
Backup support
•
Antivirus support
StorageWorks NAS B3000 by Compaq
DA-11339 Canada — Version 7 — September 24, 2002 1
QuickSpecs
NAS B3000 Base Configurations
StorageWorks NAS B3000 by Compaq
NAS B3000
Model N900
230050-001
NAS B3000
Model C900
258123-001
The clustered offerings of the
StorageWorks NAS B3000 include two (2)
server heads & one (1) MSA1000 SAN.
The specifications shown are
representative of what is included in each
individual server head.
Processor
Cache Memory
Memory
Network Controller
Host Bus Adapter
Storage Controller Integrated Smart Array Controller (Two channel, one channel for
Hard Drive
Power Supply
Optical Drive
External Storage One (1) MSA1000 with controller and 4 x 72-GB Ultra3 10K 1″ drives
Form Factor
Processor
Cache Memory
Memory
Network Controller
Host Bus Adapter
Storage Controller
Hard Drive
Power Supply
Optical Drive
External Storage
Form Factor
Two (2) 900-MHz Intel Pentium III Xeon Processors standard (up
to 4 supported)
2-MB Level 2 writeback cache per processor
2 GB (Standard, 4x 512-MB ECC SDRAM) to 4 GB (Maximum)
Integrated Compaq NC3134 and NC3135 Fast Ethernet NIC 64 PCI
Dual Port 10/100 in a slot
(4 total 10/100 ports standard)
One (1) FCA2101 Host Adapter
external SCSI backup)
Two (2) 36.4-GB Ultra3 10K 1″ drives for redundant system software
Two (2) hot pluggable 450 W Power Supplies
24x IDE CD-ROM Drive
Rack 8U
Two (2) Intel Pentium III 900-MHz Xeon Processors standard (up to 4
supported)
2MB Level 2 writeback cache per processor
2GB (Standard, 4 x 512-MB ECC SDRAM) to 4 GB (Maximum)
Integrated Compaq NC3134 and NC3135 Fast Ethernet NIC 64 PCI
Dual Port 10/100 in a slot
(4 total 10/100 ports standard)
Two (2) FCA2101 Host Adapters
Integrated Smart Array Controller (Two channel, one channel is SCSI
only for backup)
Two (2) 36.4GB Ultra3 10K 1″ for redundant system software
Two (2) Hot pluggable 450W Power Supplies
24x IDE CD-ROM Drive
One (1) MSA1000 with two controllers and 6 x 72-GB Ultra3 10K 1″
drives
Rack 12U
DA-11339 Canada — Version 7 — September 24, 2002 2
QuickSpecs
NAS B3000 Base Configurations
StorageWorks NAS B3000 by Compaq
NAS B3000
Model N900s
230051-001
NAS B3000
Model C900s
258124-001
The clustered offerings of the
StorageWorks NAS B3000 include two (2)
server heads & one (1) MSA1000 SAN.
The specifications shown are
representative of what is included in each
individual server head.
Processor
Cache Memory
Memory
Network Controller
Host Bus Adapter
Storage Controller
Hard Drive
Power Supply
Optical Drive
External Storage One (1) MSA1000 with controller and 4 x 72-GB Ultra3 10K 1″ drives
Embedded Switch
Form Factor
Processor
Cache Memory
Memory
Network Controller
Host Bus Adapter
Storage Controller
Hard Drive
Internal Storage
Power Supply
Optical Drive
External Storage
Embedded Switch
Form Factor
Two (2) Intel Pentium III 900-MHz Xeon Processors standard (up to 4
supported)
2-MB Level 2 writeback cache per processor
2 GB (Standard, 4 x 512-MB ECC SDRAM) to 4 GB (Maximum)
Integrated Compaq NC3134 and NC3135 Fast Ethernet NIC 64 PCI
Dual Port 10/100 in a slot
(4 total 10/100 ports standard)
One (1) FCA2101 Host Adapter
Integrated Smart Array Controller (Two channel, one channel is SCSI
only for backup)
Two (2) 36.4-GB Ultra3 10K 1″ for redundant system software
Two (2) Hot pluggable 450 W Power Supplies
24x IDE CD-ROM Drive
One (1) 6 port embedded 2-Gb switch
Rack 8U
Two (2) Intel Pentium III 900-MHz Xeon Processors standard (up to 4
supported)
2MB Level 2 write back cache per processor
2GB (Standard, 4x 512MB ECC SDRAM) to 4GB (Maximum)
Integrated Compaq NC3134 and NC3135 Fast Ethernet NIC 64 PCI
Dual Port 10/100 in a slot
(4 total 10/100 ports standard)
Two (2) FCA2101 Host Adapters
Integrated Smart Array Controller (Two channel, one channel is SCSI
only for backup)
Two (2) 36.4-GB Ultra3 10K 1″ for redundant system software
Two (2) Hot pluggable 450 W Power Supplies
24x IDE CD-ROM Drive
Two (2) Intel Pentium III 900-MHz Xeon Processors standard (up to 4
supported)
One (1) MSA1000 with two controllers and 6 x 72-GB Ultra3 10K 1″
drives
Two (2) 6 port embedded 2 Gb switches
Rack 12U
DA-11339 Canada — Version 7 — September 24, 2002 3
QuickSpecs
Standard Features
StorageWorks NAS B3000 by Compaq
Processor
Cache Memory
Memory
Upgradabili ty
Network Con troller
Host Adapter s
Expansion Slots
Model N900, C900, N900s, C900s
Two (2) Intel Pentium III Xeon 900-MHz processors (upgradeable to 4)
2-MB level 2 write back cache per processor standard
Standard 2 GB (512 x 4 PC100MHz ECC SDRAM Memory with Advanced ECC functionality)
Maximum 4 GB
NOTE: Advanced ECC Memory Technology protects the data even in the event of an entire SDRAM component
failure. Embedded in the chipset design, this feature allows the use of Industry-Standard Registered
DIMMs.
Upgradeable to four processors, upgradeable to 4 GB of ECC SDRAM, upgradeable storage capacity
Integrated Compaq NC3134 Fast Ethernet NIC 64 PCI Dual Base 10/100 in a slot and a Compaq NC3135 Fast
Ethernet NIC 64 PCI dual 10/100 daughter card (total 10/100 ports is 4) (Gigabit options available)
FCA2101 Host Bus Adapter
I/O (6 Total, 2 Available) PCI Voltage:
Two (2) 64-bit/66-MHz PCI Hot Plug 1 available 3.3 Volt Only
Two (2) 64-bit/33-MHz PCI Hot Plug 0 available 5 Volt or 3.3 Volt
One (1) 64-bit/33-MHz PCI Non-Hot Plug 0 available 5 Volt or 3.3 Volt
One (1) 32-bit/33-MHz PCI Non-Hot Plug 1 available 5 Volt Only
NOTE: One 64-bit/66-MHz PCI Hot Plug slot available and one 32-bit/33-MHz PCI Non-Hot Plug slot available
Storage Con troller
Internal Storag e
External Stor age
Interfaces
Integrated Smart Array Controller (Two channel) (supports Internal RAID 0, 1, 0+1, 5 and external tape devices)
Diskette Drives 1.44 MB
CD-ROM 24x IDE CD-ROM Drive (slim line)
Hard Drives Two 1″ 36.4-GB Ultra3 10K rpm hot plug drives (contain operating system in a
RAID 1 configuration)
Maximum Internal Storage 78.2 GB (2 x 36.4-GB Wide Ultra3 1″ drives)
Minimum External Storage MSA1000 (4 (for non-clustered) to 6 (for clustered) x 72-GB drives depending on
model)
Parallel Not supported
Serial 1
NOTE: You can configure a second serial device to your NAS B3000 server by
installing the auxiliary serial connector that ships with the server. The
auxiliary connector attaches to a serial port B on the peripheral board
and exits the rear of the server through the auxiliary serial knockout
located directly above the dual power feeds.
Pointing Device (Mouse) 1
Graphics Available through the “Remote Insight Board” only
Hot Plug Keyboard 1
External Wide Ultra2 SCSI 1
DA-11339 Canada — Version 7 — September 24, 2002 4
QuickSpecs
A
)
Standard Features
StorageWorks NAS B3000 by Compaq
Graphics
Form Factor
Compaq Softw are
NAS B3000 customers who desire to
activate NAS Data Copy after the 30 day
trial will need to order the license part
number 278546-001
Integrated 1280 x 1024, 16 M colour on PCI local bus, 4-MB video memory
NOTE: The integrated video card is disabled, video is provided by the Integrated Remote Insight Board
Rack (8U = 14 inches), 4U for the Server component and 4U for the storage enclosure. Ships with sliding rails and
cable management arm
SANworks™ Virtual Replicator
by Compaq
SANworks Secure Path
NAS Data Copy
Rapid Start Compaq designed rapid deployment and configuration tool
Compaq Insight Manager XE
Compaq Management Agents
Compaq SmartStart™
rray Configuration Utility (ACU
with Smart Array Controllers
Array Configurat ion Utility (ACU-
XE) with Smart Array Controllers
SANworks Virtual Replicator combines a rich set of innovative capabilities that
enhance and simplify storage management. Customers can pool physical
storage and create virtual disks of up to a terabyte each. Virtual disk space can
be allocated as needed, allowing customers to respond quickly to changing
storage capacity requirements. Through virtualization, online volume growth,
snapshot and management features, the software complements the standard
capabilities within the operating system. By utilizing industry-standard server,
storage, and network-interconnect components, an organization's current and
future storage investments are protected.
Secure Path software is included in the base system image. SANworks Secure
Path is a high availability m ulti-pathing softwar e that provides continuous data
access
NAS Data Copy is a host-based data replication package that allows data to be
replicated over TCP/IP in either a synchronous or asynchronous mode. One-toone, one-to-many, many-to-many replication is supported along with failover and
failback capabilities.
Compaq Insight Manager XE leverages the power of the Internet to provide webbased systems management, and plays a key role in Compaq’s strategy to
simplify IT management. Compaq Insight Manager XE reduces systems
management cost, improves operational efficiency and effectiveness, and
minimizes systems downtime.
The Compaq Management Agents
(http://www.compaq.com/products/servers/management/agents.html) form the
foundation for Compaq's Intelligent Manageability strategy. They provide direct,
browser-based access to in-depth instrumentation built into Compaq servers,
workstations, desktops, and portables, and send alerts to Compaq Insight
Manager XE and other management consoles in case of subsystem or
environmental failures. For additional information about the Compaq
Management Agents and other management product from Compaq, please visit
the management Web site at http://www.compaq.com/manage
NOTE: These Web sites are available in English only.
The server configuration and software integration tool from Compaq.
Minimum SmartStart version supported 5.3
Same easy to use yet powerful graphical user interface (GUI) configuration utility
and easy to navigate wizards for all Smart Array Controllers
Compaq Configuration Utility XE (ACU-XE) web-based software for Smart Array
products and the StorageWorks RAID Array 4x00 systems allows for ease of
configuration and expandability for your disk arrays, remote configuration
capabilities, and multi-platform support.
Industry Standard
Compliance
DA-11339 Canada — Version 7 — September 24, 2002 5
ACPI 2.0 Compliant
PCI 2.2 Compliant
PXE Support (Optional when configured with a PXE-enabled slot-based NIC)
WOL Support
Physical Address Extension (PAE) Support
Microsoft Logo certifications
QuickSpecs
Standard Features
StorageWorks NAS B3000 by Compaq
Intelligent M anageability
Availability
Serviceability
Compaq Remote Insight Lights-Out Edition Included
Automatic Server Recovery-2 (ASR-2)
Compaq Insight Manager
Compaq Insight Manager XE
Integrated Remote Console (IRC)
Integrated Management Log (IML)
Off-Line Backup Processor capability
Dynamic sector repairing and drive parametre tracking (with Smart Array controllers)
Redundant/adaptive load balancing NIC Support
Advanced Data Guarding
PCI Hot Plug with push button functionality
Continuous cooling provided by 8 Hot Plug Redundant System Fans
Integrated Smart Array Controller for RAID data protection/performance and maximum data bandwidth
Advanced Error Checking and Correcting (ECC) Technology
NOTE: Advanced ECC Memory Technology protects the data even in the event of an entire SDRAM component
failure. Embedded in the chipset design, this feature allows the use of Industry-Standard Registered
DIMMs.
Hot Plug Ultra2/Ultra3 Drive Bays
2 Redundant Hot Plug Power Supplies Standard
Redundant NIC support
Pre-Failure Warranty (covers processors, hard drives, and memory)
Internal Diagnostics Display (IDD) numerically indicates specific DIMM or processor failure.
LED display on front panel indicates power/interlock, fan, and memory/microprocessor health
Spring-loaded memory board release latches prevent unseating incidents
PCI Card Guide locks full length PCI cards in place during transit
Customer driven interior system fan design (all system fans interior to chassis)
Removable, internal centre panel eases access to the power supply and hard drive backplane boards
Optional High Voltage PDU cable exits chassis at a right angle to simplify cable management at rear of chassis
Security
Server Power Supply
OS Support
Service and Support
Power-on password
Hot plug keyboard password
Diskette drive control
Diskette boot control
Network Server Mode
Security Provision
Parallel and serial interface control
Administrator’s password
Disk configuration lock
Hot plug access security
450-Watt Hot Plug Power Supply
NOTE: Two 450-Watt Hot Plug Power Supplies ship standard with the system
Windows Powered OS (OS and all software needed for storage management is pre-configured from the factory)
NOTE: For an up-to-date listing of the latest drivers available for the StorageWorks NAS B3000, please see:
http://www.compaq.com/storage/nas/B3000.
NOTE: This Web site is available in English only.
Compaq Services provides a wide range of service offerings, including a three-year, limited warranty that is fully
supported by a worldwide network of resellers and service providers, toll-free 7 x 24 hardware technical phone
support and Pre-Failure Warranty coverage of hard drives, memory and processors.
NOTE: Certain restrictions and exclusions apply. Consult the Compaq Customer Support Centre.
DA-11339 Canada — Version 7 — September 24, 2002 6
QuickSpecs
StorageWorks NAS B3000 by Compaq
B3000 External Storage Components
With the following components, your storage capacity and performance can be scaled to new levels:
Modular SAN Array 1000
The 4U cabinet houses up to fourteen 1″ Compaq Universal hot pluggable Ultra2 and/or Ultra3 drives.
The modular design of the MSA1000 makes it possible to add redundant controllers, redundant single port Fibre Channel I/O Modules or Fabric Switches
and storage expansion enclosures.
MSA1000 Controller
The MSA1000 Controller is an integrated RAID controller with an integrated LCD/LED status display and 128-MB read/write battery-backed cache
(expandable to 256 MB per controller). Redundant MSA1000 controllers are an option.
Key Features
• Redundant controller support
• Fabric, Private Loop & Public Loop Support
• Auto Negotiated F, FL & L Port Login
• RAID 0, 1, 1+0, 5 and ADG
• 2Gb/1Gb Frequency Agile
• Primary & Secondary Inter-Controller Link (ICL)
• Host based configuration via ACU
• Remote configuration and monitoring via ACU XE (offline and remote) & CIM XE
MSA1000 Controller Management Features
• Selective Storage Presentation: allows multiple hosts to access a single MSA1000 storage system. Host access can be defined all the way down
to a logical volume level.
• Online RAID Level Migration: allows for online post-configuration change to RAID level without destroying data or volume information.
• Online Capacity Expansion: lets you add storage to an operational MSA1000 — reducing expensive server downtime.
• Online Volume Extension: allows for the capacity growth of existing logical volumes.
• Global Online Spare: reduces the risk of data loss by facilitating automatic rebuilds after a drive failure.
Fault Tolerance
Several fault tolerant configurations, which keep data available and servers running while drives are being replaced, are supported including:
• Advanced Data Guarding (RAID ADG): Allocates the equivalence of 2 parity drives across multiple drives and allows simultaneous write
operations.
• Distributed Data Guarding (RAID 5): Allocates parity data across multiple drives and allows simultaneous write operations.
• Drive Mirroring (RAID 1, (1+0 Striped Mirroring)): Allocates half of the drive array to data and the other half to mirrored data, providing two copies
of every file.
Fault Recovery
Minimizes downtime, reconstructs data, and facilitates a quick recovery from drive failure
• On-Line Spares: If a failure occurs, recovery begins with an on-line spare and data is reconstructed automatically. One on-line spare can be
assigned per array and used across multiple arrays. It is also possible to assign different on-line spares across different arrays.
• Array Accelerator: Onboard, battery-backed cache memory protects data in the event of a power failure. In the unlikely event of a controller failure,
the battery-backed cache will save critical user d ata for up to three days.
MSA1000 Fibre Channel I/O Module
The Fibre Channel I/O module provides a 2 Gb/s Fibre Channel connection from the host side into the MSA1000. The MSA1000 Fibre Channel I/O
Module includes one 2 Gb/s, Short Wave, Small Form Factor Pluggable Transceiver (SFP). A second MSA1000 Fibre Channel I/O Module can be
installed for redundancy when a redundant controller is used.
MSA Fabric Switch 6
The MSA1000 Fabric Switch 6 is a six port, 2 Gb/s Fibre Channel Fabric Switch. The MSA1000 Fabric Switch 6 replaces the standard single port Fibre
Channel connection provided by the MSA1000 Fibre Channel I/O Module. There are a total of five external fibre channel ports. Four of the external fibre
channel ports are Small Form Factor Fixed (SFF) short wave transceivers and are not removable. The fifth port requires the installation of a Small Form
Factor Pluggable (SFP) transceiver. One port is used internally by the MSA1000 controller.
DA-11339 Canada — Version 7 — September 24, 2002 7
Loading...
