QuickSpecs
Overview
Compaq Evo Notebook N1005v
What's New
• Mobile AMD
Processor – up to 1700+
• 266-MHz bus
• 4X AGP Graphics
• MultiPort wireless communication
options
• Sophisticated design elements
• 1394 Digital inter face
At A Glance
• Mobile AMD
Processor – up to 1800+
• 15-inch XGA, SXGA+ and
14.1-inch XGA display
• Magnesium enclosure for the
15-inch panels
• Configurations as light as
6.6 lb/2.99 kg weight
(14-inch panel)
• 1.55 in/3.95 cm t hin
• 256-MB DDR SDRAM
(266 MHz), Upgradeable to
1024 MB
• Up to 40-GB/5400 rpm SMART
hard drives
• Mini PCI modem and integrated
NIC
• Full-size keyboard
• Microsoft
Home preinstalled and support
for Windows 2000
• Includes a One-y ear, Worldwide
Warranty—Certain restrictions
and exclusions appl y. Consult
the Compaq Customer Support
Center for details .
Athlon XP
Athlon XP
Windows XP Pro or
What’s Special
• All-in-one convenient design
• High-end ATI Radeon graphics
and large panel
• 1394 Digital Inter face
• Large hard drives
• Wireless features through
Award-Winning MultiPort
DA-11388 World Wide — Version 2 — September 16, 2002 1
QuickSpecs
Standard Features
Compaq Evo Notebook N1005v
Processor and Panel
One of the following:
Memory
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend Compaq
Communications 10/100 NIC is integrated on the system board (LOM)
NOTE: Designed only to allow faster downloads from V.92 compliant sources. Maximum achievable download
NOTE: Modem availability is subject to country regulatory approval
Keyboard 102-key compatible keyboard with isolated, inverted-T cursor control keys, and right-control key, special feature
Easy Access Internet
Buttons
Pointing Device
PC Card Slots One Type II PC Card Slot which supports both 32-bit CardBus
Storage Primary Hard Dive 40-GB 4200 RPM
Diskette Drives 1.44 MB Floppy Drive
Optical Drives DVD/CD-RW Combo Drive
15-inch color TFT SXGA+ with 1400 x 1050 resolution (up to 16.7M colors internal)
15-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)
14.1-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)
AMD Athlon XP 1800+ (Quanti speed architecture running at 1.53 GHz) with 256-KB L2 cache
AMD Athlon XP 1700+ (Quanti speed architecture running at 1.47 GHz) with 256-KB L2 cache
AMD Athlon XP 1600+ (Quanti speed architecture running at 1.40 GHz) with 256-KB L2 cache
AMD Athlon XP 1500+ (Quanti speed architecture running at 1.30 GHz) with 256-KB L2 cache
AMD Athlon XP 1500+ (Quanti speed architecture running at 1.30 GHz) with 256-KB L2 cache
NOTE: Mobile AMD Athlon XP supports enhanced AMD’s PowerNow™ technology.
Standard/Maximum
branded memory to ensure compatibility.
Type III Mini PCI 56K (V.92) modem
transmission rates currently do not reach 56 KB/s, and will vary with line conditions.
hotkeys for instant access to power conservation, toggle between internal and external, or simultaneous displays,
and control brightness and contrast.
The Evo Notebook N1005v features three Easy Access Buttons (EAB) designed to increase customer
productivity by providing one-touch access to helpful Compaq information, favorite Internet destinations, or default
e-mail application. The EAB portion of the keyboard deck also includes dedicated hardware volume control and a
quick-launch button for CD/DVD play.
TouchPad with 4-way scroll
128 MB (266 MHz) DDR SDRAM
256 MB (266 MHz) DDR SDRAM
512 MB (266 MHz) DDR SDRAM
1024 MB (266 MHz) DDR SDRAM
30-GB 4200 RPM
20-GB 4200 RPM
8X DVD-ROM Drive or
24X CD-ROM Drive
and 16-bit PC Cards
DA-11388 World Wide — Version 2 — September 16, 2002 2
QuickSpecs
Standard Features
Compaq Evo Notebook N1005v
Multimedia JBL Pro Speakers with bass reflex and 16-bit stereo sound
Interfaces PC Card One Type II
Enhanced Parallel EPP/ECP 1
S-Video 1
VGA 1
1394 1
Headphone/Line-out 1
Microphone in 1
DC Power 1
RJ-11 (modem) 1
RJ-45 (NIC) 1
Infrared Port 1 (4 Mb/s support)
USB Port 2
LED status indicators 6
Graphics ATI Radeon IGP video graphics with user configurable 16-, 32- or 64-MB VRAM video memory for increased
Display (External)
Display (Internal)
Operating System Microsoft Windows XP Pro or Home preinstalled with support for Windows
Software
Dedicated Hardware volume controls
Headphone-out port
Microphone in port
Software MPEG1 support, MPEG2 and DVD
8X DVD/CD-RW Combination Drive (on select models)
8X DVD-ROM Drive with movie playback software (on select models)
24X CD-ROM Drive (on select models)
S-video Port
IEEE 1394 Port
4X AGP graphics
(IrDA 4 MB compliant. IR performance will vary depending on performance of IR
peripherals and application used.)
color depth and graphics performance
Up to 32-bit per pixel color depth
Supports 640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, 1400 x 1050, 1600 x 1200 resolutions up to 160-Hz
refresh rate, dependent upon monitor capability, resolution and color depth settings
15-inch color TFT SXGA+ with 1400 x 1050 resolution (up to 16.7M colors internal)
15-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)
14.1-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)
Diagnostics for Microsoft Windows
DVD Playback Software
Compaq Power Management
Compaq Security Management
Safety and Comfort Guide
Acrobat
Reference Guide
Norton Internet Security
Compaq Easy Access Button Software
Reader
DA-11388 World Wide — Version 2 — September 16, 2002 3
QuickSpecs
Standard Features
Compaq Evo Notebook N1005v
System Recovery
Security Configuration Control Hardware
Power Supply
Battery The Evo Notebook N1005v provides up to three hours of battery life using the standard 8-cell Lithium-Ion battery.
NOTE: Actual results may vary with product model, configuration, and individual usage. Compaq results of 3:01
NOTE: This test was performed without independent verification by eTesting Labs Inc. eTesting Labs Inc. makes
Power Conservation Hibernation
MultiPort
Service and Support Compaq Services includes a one-year, Worldwide Limited Warranty, pick-up or carry in; upgraded warranty and
NOTE: Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center for details.
Each unit is shipped with a series of CD’s kit for quick OS recovery (erases hard disk and restores manufacturer
installed image) and software recovery (installs only selected standard software).
Memory Change Alert
Ownership Tag
Set-up Password
Power-On Password
Enabled for PC SmartCard options
Kensington Lock
External AC adapter, 6-foot/1.8-meter power cord included. Total length including External AC adapter is 12
feet/3.66 meter
(hr:min) were achieved running the Business Winstone 2001 Battery Mark 1.0.1 on a N1005v with a
AMD Athlon XP 1600+ CPU, 15-inch XGA panel, 128-MB RAM, 20-GB HDD, 8X DVD, 8-cell Lithium-Ion
battery, and NIC/modem. System parameters were set according to eTesting Labs’ recommendations:
panel brightness 50%, power management timers turned off.
no representations or warranties as to the result of the test. BatteryMark is a trademark of Ziff Davis
Publishing Holdings Inc., and affiliate of eTesting Labs Inc., in the U.S. and other countries.
Instant-on via Standby
Pop-ups with three presets
One custom level of power conservation
ACPI compliant
MultiPort is a flexible, innovative solution providing customers the ability to connect to their choice of wireless
standards such as 802.11b or Bluetooth™. This can be achieved by simply changing out the high-performance
wireless module, which is integrated in the top of the notebook. The award-winning MultiPort offers a cost
effective means to migrate to future wireless standards as they become available.
toll-free 7 x 24 hardware technical phone support is available.
DA-11388 World Wide — Version 2 — September 16, 2002 4
QuickSpecs
Standard Features
Compaq Evo Notebook N1005v
Naming Convention
The Etymology of a Model name:
DA-11388 World Wide — Version 2 — September 16, 2002 5
QuickSpecs
Standard Features
MODELS
Compaq Evo Notebook N1005v
N1005VA147X520DC25E0
N1005VA147X530DC250
Display
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Communications
Graphics
Video Memory
Audio
Operating System
Pointing Device Touchpad
Display
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Communications
Graphics
Video Memory
Audio
Operating System
Pointing Device Touchpad
15-inch color TFT XGA
Athlon XP 1700+ (1.4 GHz)
256-KB L2 Cache
Standard 256 MB (133 MHz) DDR SDRAM
Maximum 1024 MB (133 MHz) DDR SDRAM
DVD
20-GB SMART
Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC
ATI Mobility Radeon
16-MB shared VRAM memory
JBL Pro Speakers with bass reflex and 16-bit stereo sound
Microsoft Windows XP PRO
15-inch color TFT SX GA+
Athlon XP 1800+ (1.53 GHz)
256-KB L2 Cache
Standard 256 MB (133 MHz) DDR SDRAM
Maximum 1024 MB (133 MHz) DDR SDRAM
DVD/CD-RW
30-GB SMART
Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC
ATI Mobility Radeon
16-MB shared VRAM memory
JBL Pro Speakers with bass reflex and 16-bit stereo sound
Microsoft Windows XP PRO
DA-11388 World Wide — Version 2 — September 16, 2002 6
QuickSpecs
Compaq Evo Notebook N1005v
Options
Memory 512-MB (266 MHz) DDR SDRAM Memory Upgrade 269087-B25
256-MB (266 MHz) DDR SDRAM Memory Upgrade 269086-B25
128-MB (266 MHz) DDR SDRAM Memory Upgrade 269085-B25
Monitors TFT8030 Flat Panel Color 18-inch (carbon/silver) 234362-xxx
TFT7020 Flat Panel Color 17-inch with integrated speakers (carbon/silver) 253217-xxx
TFT5015 Flat Panel Color 15-inch (carbon/silver) 234044-xxx
TFT5030 Flat Panel Color 15-inch (carbon/silver) 228134-xxx
V720 17-inch CRT (carbon/silver) 232944-xxx
S720 17-inch CRT (carbon/silver) 239287-xxx
V570 15-inch CRT (carbon/silver) 228113-xxx
Other Storage Devices
Connectivity
Wireless Connectivity 802.11b MultiPort Wireless LAN module 233412-001
CDPD WWAN PC Card (U.S. Only) 238111-001
Expansion Bases Targus USB Port Replicator 239172-001
Power Evo Notebook N1005v 8-cell primary battery (4 Ah) 291369-B21
Common Power Solutions External Battery Charger 265603-xxx
AC Adapter 65W 265602-xxx
Auto Power Adapter/Charger 65W 265649-B25
Aircraft Power Adapter 386504-B21
AC Line Cord (10-ft/3.1 m) 217932-xx2
Input Devices External Enhanced III Keyboard (carbon) 118003-008
Compaq 2 Button Mouse (carbon) 103180-B21
USB 2 Button Scroll Mouse (carbon) 195255-B25
External 10-Key Numeric Keypad (carbon) 294317-B21
USB EZ Access Keyboard 222726-xxx
Wireless Keyboard and Mouse 251385-xx8
IBM
1-GB Microdrive (PC card Device) 217390-B25
USB Disk-on-Key – 8 MB 249552-B25
USB Diskette Drive 230330-B25
Compaq Type III Mini PCI 56K (V.90) Modem 225640-B31
Compaq Type III Mini PCI 56K (V.90) Modem plus 10/100 NIC Combo 225642-B31
100BaseTX Ethernet Upgrade 225435-001
1394 PC Card 177593-B25
NOTE: Designed only to allow faster downloads from V.90 compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions.
Bluetooth MultiPort module 228057-B21
Compaq WL110 Wireless LAN PC Card 191808-B21
Compaq WL510 Wireless Enterprise Access Point 216709-001
Compaq WL410 Wireless SMB Access Point 191811-001
Compaq WL310 Home Office Access Point 191813-001
Compaq Range Extender Antenna 230268-B21
DA-11388 World Wide — Version 2 — September 16, 2002 7
