Preface

Using This Guide

The User's Guide includes general information about your

projector, troubleshooting and diagnostics, and technical

specifications.

Symbols and Conventions

The following words and symbols mark special messages

throughout this guide:

Text set off in this manner presents clarifying

✎

information, specific instructions, commentary,
sidelights, or interesting points of view

WARNING:

!

failure to follow directions could result in bodily harm
or loss of life.

Text set off in this manner indicates that

.

CAUTION:

failure to follow directions could result in damage to
equipment or loss of information.

Text set off in this manner indicates that

Preface ix

Warning Messages

Before operating the projector, please read the following

messages.

!

WARNING:

!"

!"

!"

!"

To reduce the risk of harm to your eyes, do not
look directly into the bright light of the
projection lens.

To reduce the risk of fire or electric shock, do
not expose this product to rain or moisture.

To reduce the risk of electric shock, do not
disassemble the projector other than to replace
the lamp module.

To reduce the risk of personal injury, allow the
unit to cool down before changing the lamp, and
always unplug the power cord first.

x Preface

Chapter 1

Getting Started

Product Features

The Compaq MP1800 Microportable Projector generates crisp,
clear images onto a projection screen by using Digital Light
Processing (DLP) technology. The MP 1800 Microportable
Projector is Compaq’s “Flagship” product offering the latest in
portable projection technology, including:

!"

1024 × 768 native XGA resolution

!"

Maximum resolution: 1280 × 1024 compression

!"

User replaceable 120 watt high-efficiency, long-life lamp

!"

Manual 1.3:1 zoom lens

!"

Electronic zoom to 32×

!"

Weighs 4.6 pounds (2.08 kg)

!"

Convenient auto-image adjustment

!"

16.7 million displayable colors

!"

Flash ROM upgradeable

!"

Connector options:

■

Standard analog VGA

■

Digital DFP

■

S-video (with Multimedia Adapter) [optional use]

■

Composite video (with Multimedia Adapter) [optional use]

■

DVI (with Multimedia Adapter) [optional use]

!"

Multimedia Adapter with speaker [optional use]

!"

Full-featured remote control with remote mouse capabilities
[optional use]

!"

Multilingual on-screen adjustment menu

!"

Plug and Play capability

!"

Dual projector and compact computer carrying case and
carrying handle

!"

Compaq Presentation utility allows quick setup with
portable computers

!"

Compaq Projector Display Assistant utility to adjust
screen settings

!"

Security lock slot

Getting Started 1-1

Introduction

Before setting up your Compaq MP1800 Microportable Projector,
be sure your shipping box includes the following items:

1-2 Getting Started

1

Projector and lens cap

2

10-foot power cable

3

Seven signal cables and one upgrade adapter:

!"

One VGA signal cable for use with computers, portables, and
some handheld products

!"

One digital DFP (digital flat panel) to DVI signal cable for
use with compatible digital sources

!"

S-video cable

!"

Audio cables (2; one cable has mini connectors on both ends
and is used to connect the Multimedia Adapter to a
computer; the other cable has an RCA connector on one end
and a mini connector on the other end and is used to connect
a videocassette recorder to a computer)

!"

RCA cable
8-pin to USB/RS232 Y-cable used to connect the Multimedia

Adapter to a computer. When using the Y-cable, do not
connect both the USB and RS232 connectors to a computer at
the same time. The USB connector is the preferred connector.

NOTE:

The remote control Page Up and Page Down

functions work only when the USB connection is used.

!"

One RS232 (serial) to DVI upgrade adapter

4

Compaq Multimedia Adapter

5

Remote control (includes three AAA batteries)

6

Carrying case and separate projector carrying handle

7

Phillips screwdriver

8

Two Quick Setup cards

9

CD-ROM containing the Compaq Presentation utility program,
Compaq Projector Display Assistant utility, and the

User’s Guide

If your shipping box does not contain all of the listed items, please
contact your Compaq authorized dealer, reseller, or service
provider.

Getting Started 1-3

Setting Up the Projector

Follow the instructions below and on the following pages to set up
the projector. Separate setup instructions are described for the
following products:

!"

Portable and desktop computers

!"

Handheld computers with VGA capability

!"

videocassette recorder, DVD, or camcorder (requires optional
Multimedia Video Adapter)

✎

IMPORTANT:

distance
not less than 4.92 feet (1.5 meters) and not greater than 16.4 feet
(5 meters) from the projection screen.

The projector is hot pluggable and can be

connected to any video input source while

the source is in use.

Place the projector on a stable desk or table at a

WARNING:

!

shock or damage to your equipment:

!"

To reduce the risk of electric

Do not disable the power cord
grounding plug. The grounding plug
is an important safety feature.

Plug the power cord into a grounded

!"

(earthed) electrical outlet that is
easily accessible at all times.

Disconnect power from the projector

!"

by unplugging the power cord from
the electrical outlet.

Do not place anything on power

!"

cords or cables. Arrange them so that
no one may accidentally step on or
trip over them. Do not pull on a cord
or cable. When unplugging from the
electrical outlet, grasp the cord by
the plug.

1-4 Getting Started

Balancing the Projector

The projector has a built-in elevator foot used to balance and
elevate the projector. Always balance the projector before
connecting any device to it.

Turn the elevator foot sideways to balance the projector.

WARNING:

!

tipping or overturning, always turn the elevator foot

90 degrees from its original position before pressing

the elevator button. Refer to the “Adjusting the

Projector Height” section later in this chapter.

Getting Started 1-5

To reduce the risk of the projector

Connecting the Projector to a Portable Computer

1. Rotate the elevator foot to balance the projector.

2. Connect one end of the projector signal cable to the projector
and the other end to the VGA connector
connector

A

on the portable computer and tighten the screws.

➊

B

or the DFP

➊

✎

3. Connect one end of the power cord ➋ into the back of the

Be sure the signal cable aligns with the connector.
Do not force the cable onto the connector or you
may damage the signal cable or the projector.

projector, and the other end to an electrical outlet that is easily
accessible and close to the projector.

4. Turn on the projector first, then turn on the computer. Refer to
the “Powering On the Projector” section later in this chapter for
instructions on turning on the projector.

For security purposes, this projector has been fitted

✎

with a security lock slot ➌ (located on the left, front
side) for use with a security cable lock that can be
purchased separately at most computer stores.

1-6 Getting Started

Connecting the Projector to a Desktop Computer

1. Rotate the elevator foot to balance the projector.

2. Connect one end of the projector signal cable
projector and the other end to the VGA connector on the
desktop computer and tighten the screws.

➊

B

to the

✎

✎

3. Connect one end of the power cord ➋ into the back of the

If your computer has a digital connector,
connect one end of the digital flat panel
(DFP) signal cable
connector on the projector and the other
end to the digital connector on the
computer.

Be sure the signal cable aligns with the
connector. Do not force the cable onto the
connector or you may damage the signal
cable or the projector.

projector, and the other end to an electrical outlet that is easily
accessible and close to the projector.

to the digital

A

➊

Getting Started 1-7

For security purposes, this projector has been fitted

✎

with a security lock slot ➌ (located on the left, front
side) for use with a security cable lock that can be
purchased separately at most computer stores.

4. Turn on the projector first, then turn on the computer. Refer to the
“Powering On the Projector” section later in this chapter for instructions
on turning on the projector.

1-8 Getting Started

Connecting the Projector to a Compaq PC Companion

To connect the projector to a Compaq PC Companion, the PC
Companion must have a male connector adapter and a VGA-out PC
Card with a 15-pin connector.

✎

1. Rotate the elevator foot to balance the projector.

2. Connect one end of the signal cable ➊ to the projector and

✎

The VGA-out PC Card with the 15-pin
connector is not included with the Compaq
PC Companion. It is sold separately. For
information on purchasing this card, call
your Compaq authorized dealer or reseller.
To locate a reseller near you, call Compaq
at 1-800-AT-COMPAQ or visit the
Compaq web site at
http://www.compaq.com.

connect the other end to the VGA-out PC Card. The VGA-out
PC Card may be inserted into the PC slot on the Compaq PC
Companion before or after connecting the signal cable.

Be sure the signal cable aligns with the
connector. Do not force the cable onto the
connector or you may damage the signal
cable or the projector.

Getting Started 1-9

3. Connect one end of the power cord ➋ into the back of the
projector, and the other end to an electrical outlet that is easily
accessible and close to the projector.

✎

4. Turn on the projector first, then turn on the computer. Refer to

For security purposes, this projector has
been fitted with a security lock slot
(located on the left, front side) for use with
a security cable lock that can be purchased
separately at most computer stores.

the “Powering On the Projector” section later in this chapter for
instructions on turning on the projector.

1-10 Getting Started

➌

Connecting the Projector to Other Video Sources

The optional Compaq Multimedia Adapter must be used to connect
the projector to a camcorder, DVD player, or videocassette
recorder. This adapter converts signals from the camcorder, DVD
player, or videocassette recorder for compatibility with the
projector.

Refer to Chapter 3, “Using the Compaq Multimedia Adapter,” for
information on attaching and using the Compaq Multimedia
Adapter.

Powering On the Projector

Follow these instructions to power on the projector:

1. Make sure the computer and projector power cords and the
signal cable are securely connected.

✎

2. Remove the lens cap ➊ by pulling it straight out.

3. Turn on the main power switch ➋ on the back of the projector

When the projector has warmed up, the Compaq startup screen

Make sure the projector is perpendicular to
the projection screen.

and allow the projector to warm up for one to two minutes.

displays and the LED on the

Standby

button ➌ turns green.

Getting Started 1-11

4. Turn on the video source (computer, PC Companion,
videocassette recorder, etc.) and launch the software application
being used to display images on the projection screen.
If applicable, press the Function key on the computer
designated for external display.

If there is a long delay between the time the startup

✎

screen displays and the time the presentation software
is launched, the lamp may shut off and the projector
will automatically go into standby mode. If this
happens, press the
lamp.

When the startup screen disappears, the video from

✎

the attached computer displays. If there is no
incoming video, the “Check Video Cable” message
will display on the projection screen.

Standby

button to power on the

Powering Off the Projector

1. Press the

The message “Going to Standby” displays and the LED on the

Standby
IMPORTANT:

five to ten minutes before turning it off.

2. Turn off the main power switch on the back of the projector.

3. Disconnect the power cord from the electrical outlet and the
projector.

1-12 Getting Started

Standby

button blinks amber.

CAUTION:

least one minute before turning the projector back on.
Failure to follow this caution can result in damage to
the projector.

button to turn off the projector lamp.

Allow the projector to cool down for about

After the projector is turned off, wait at

Adjusting the Projected Image

There are three ways to adjust the projected image:

!"

Adjusting the projector height

!"

Adjusting the projector focus

!"

Adjusting the projector zoom

Adjusting the Projector Height

The projector has a built-in elevator foot that can raise the projector
approximately 1 inch. To adjust the height:

1. Ensure the foot is turned 90° to balance the projector.

2. Raise the projector to the desired display angle, then press the

elevator button ➊ to release the elevator foot ➋.

3. To lower the display angle, press the elevator button again and

press down on the projector to lower it.

Getting Started 1-13

CAUTION:

before adjusting the elevator foot can result in damage
to the elevator mechanism.

To fine-tune the leveling of the projector, rotate the

✎

knobs ➌ on either side of the foot and adjust the
leveling.

Failure to press the elevator button

Adjusting the Projector Focus

To focus the projected image, rotate the focus ring ➊ until the
image is clear. The projector will focus at distances from 4.92 (1.5
meters) to 16.4 feet (5 meters).

If vertical bars appear on the display after adjusting the focus, press

Resync

the
display. If the button does not correct the display, use the Digital
Conversion feature in the on-screen menu to manually adjust the
synchronization and tracking. Refer to the “Adjusting the On­Screen Menus” section in Chapter 2.

button ➋ to automatically synchronize and track the

1-14 Getting Started

Adjusting the Projector Zoom

To adjust the size of the projected image, rotate the zoom lever until
the projected image is the desired size.

Getting Started 1-15
