QuickSpecs
Overview
What's New
•
AMD K6-2+ 550MHz Global
Processor
•
AMD PowerNow! ™ Technology
•
13.3˝ XGA Display Panels
At A Glance
•
AMD K6-2+ 550MHz Global
Processor
•
Choice of eit her 12.1˝ High
Performance Addressing (HPA)
SVGA, 12.1˝ TFT SVGA, or 13.3˝
TFT XGA displays
•
Full set of system ports
•
Microsoft Windows 98SE
•
Integrated 5 6K modem available
•
Upgradable to 160/192MB
memory (depending upon
standard configuration)
•
Full-size keyboard user
•
One Type I, Type II or Type III
CardBus PC Card slot
•
Between 6.7 a nd 6.8 lbs., or 3 to
3.1 kg
•
USB port expansion options
available
•
Lightweight /Ex t en ded Ca pac it y
Lithium Ion b attery available
•
Protected by a one-year Warr anty
— Certain restrictions and
exclusions apply. Consult the
Compaq Customer Su pp ort
Center for details.
Compaq Armada 100S
DA-10695 World Wide — Version 7 — July 16, 2001
1
QuickSpecs
Standard Features
Compaq Armada 100S
Processor
Cache Memor y 192KB total internal cache
Memory
One of the following required
Communications
PC Card Slots One Type I, II or III PC Card Slot which supports both 32-bit CardBus (Full support in Windows 9.x) and 16-bit PC
Storage
Multimedia
Interfaces
Graphics Trident CyberBlade 7 with AGP 2X support
Mobile AMD K6
• Leading-edge Super7™ platform features, including 100MHz front side bus
• 3DNow!™ technology with new DSP Instructions
• AMD PowerNow! Technology
• 2X AGP Graphics
• High speed 128K on-chip L2 cache
• Compatible with Windows 2000 and Windows 98
• Internal split, two-way set associative, 64KB L1 Cache
•
•
•
• Internal full-speed, four-way set associative, 128KB, L2 Cache
Standard
Maximum
Standard
Maximum
56K AC97 Link
Note: Designed only to allow faster downloads from v.90 compliant sources. Maximum achievable download
transmission rates currently do not reach 56KB/s, and will vary with line conditions.
Cards
Diskette Drives 1.44MB
Hard Drives 5GB (9.5 mm height)
Integrated 16-bit Sound Blaster Pro-compatible stereo audio
Integrated speakers and microphone
Software and hardware volume controls
Headphone-out Jack
Microphone-in Jack
Hardware assisted MPEG2 support
PC Card Slot One Type I, II or Type III
Enhanced Parallel Port 1
PS/2 1
Serial Port 1
External Monitor Port 1
Speaker Out (Headphone) Jack 1
Microphone In Jack 1
AC Power Connector 1
RJ-11 Jack 1 (with modem only)
Infrared Port 1 (”Fast IR” compliant, IR performance will vary depending on performance
USB Port 1
-2+ 550MHz Global Processor
32KB instruction cache with additional 20KB of predecode cache
32KB writeback dual-ported data cache
MESI protocol support
32MB (HPA) (4MB allocated to frame buffer)
160MB
64MB (TFT) (8MB allocated to frame buffer)
192MB
of IR peripherals and application used)
DA-10695 World Wide — Version 7 — July 16, 2001
2
QuickSpecs
Standard Features
Compaq Armada 100S
Display (Internal)
One of the following
Display (External)
Operating System
Software
Security Cable lock support
Power Supply External AC Adapter; 6-foot power cord included
Battery
Power Conservation
Service and Support
12.1-inch color HPA with 800 x 600 SVGA resolution
12.1-inch color TFT with 800 x 600 SVGA resolution
13.3-inch color TFT with 1024 x 768 XGA resolution
16 Million colors supported
640x480, 800x600, 1024x768 or 1280x1024 up to 60,75,85 Hz refresh rate
Windows 98SE
Microsoft Word 2000 available on select models
Microsoft Office Small Business available on select models
Online Safety and Comfort Guide
Online Reference Guide
Norton AntiVirus 2000 available on select models
Power-on password
Setup passwords
Ability to disable serial port, parallel port, diskette drive, diskette drive boot capability
A 9-cell NiMH battery ships standard and provides over two hours of battery life using ZD BattMark 3.0. An optional
8-cell Li-ION battery is also available.
Note: Actual results may vary with individual usage. When tested in standard configuration, using the Ziff-Davis
BatteryMark Test version 3.0, the battery life of the Armada 100S will exceed 2.0 hours using “max
performance” mode in PowerNow!. Standard configuration at time of announce is considered to be one
battery, a 800x600 (High color – 16-bit color) panel set at 50percent brightness, 32MB or 64MB RAM, and no
drives other than the hard drive active.
Hibernation
Instant-On via Standby
Five power consumption levels available through AMD PowerNow!™ Technology
Pop-ups with three presets
One custom level of power conservation
Compaq Services includes a one-year limited warranty, whole-unit replacement via second business day, pick-up
and delivery. (Eligibility depends on geographic location.) Optional services include a one-year warranty extension
CarePaq (FM-AMMAI-36 or 400514-002).
Note: Certain restrictions and exclusions apply. See the Limited Warranty Statement for details.
DA-10695 World Wide — Version 7 — July 16, 2001
3
QuickSpecs
Standard Features
Models
A2+/550/64/1 3T/5/M/WD Display
219677-xx4 Processor
Cache Memory
Memory Standard
Maximum
Optical Drive
Hard Drive
Modem
Graphics
Audio
Software
A2+/550/64/1 3T/5/M/SB Display
219678-xx4 Processor
Cache Memory
Memory Standard
Maximum
Optical Drive
Hard Drive
Modem
Graphics
Audio
Software
A2+/550/64/1 3T/5/M/2 Display
219679-xx4 Processor
Cache Memory
Memory Standard
Maximum
Optical Drive
Hard Drive
Modem
Graphics
Audio
Software
A2+/550/64/1 3T/5/M/PS Display
219680-xx4 Processor
Cache Memory
Memory Standard
Maximum
Optical Drive
Hard Drive
Modem
Graphics
Audio
Software
13.3-inch color TFT/XGA
AMD K6-2+ 550MHz
Internal 64KB L1 Cache Internal 128KB, L2 Cache
64MB SDRAM
192MB SDRAM
24X CD-ROM
5GB
56K
Trident CBI7 4MB UMA RAM(Shared RAM)
16-bit SoundBlaster Pro compatible
Windows 98SE, MS Word 2000
13.3-inch color TFT/XGA
AMD K6-2+ 550MHz
Internal 64KB L1 Cache Internal 128KB, L2 Cache
64MB SDRAM
192MB SDRAM
24X CD-ROM
5GB
56K
Trident CBI7 4MB UMA RAM(Shared RAM)
16-bit SoundBlaster Pro compatible
Windows 98SE, Office 2000 Small Business
13.3-inch color TFT/XGA
AMD K6-2+ 550MHz
Internal 64KB L1 Cache Internal 128KB, L2 Cache
64MB SDRAM
192MB SDRAM
24X CD-ROM
5GB
56K
Trident CBI7 4MB UMA RAM(Shared RAM)
16-bit SoundBlaster Pro compatible
Windows 98SE
13.3-inch color TFT/XGA
AMD K6-2+ 550MHz
Internal 64KB L1 Cache Internal 128KB, L2 Cache
64MB SDRAM
192MB SDRAM
24X CD-ROM
5GB
56K
Trident CBI7 4MB UMA RAM(Shared RAM)
16-bit SoundBlaster Pro compatible
Windows 98SE, Office 2000 Personal Edition
Compaq Armada 100S
DA-10695 World Wide — Version 7 — July 16, 2001
4
QuickSpecs
Standard Features
Models (continued)
A2+/550/64/1 2T/5/M/WD Display
219675-xx4 Processor
Cache Memory
Memory Standard
Maximum
Optical Drive
Hard Drive
Modem
Graphics
Audio
Software
A2+/550/64/1 2T/5/M/2 Display
219674-xx4 Processor
Cache Memory
Memory Standard
Maximum
Optical Drive
Hard Drive
Modem
Graphics
Audio
Software
A2+/550/64/1 2T/5/M/NA Display
219674-xx5 Processor
(NAFTA) Cache Memory
Memory Standard
Maximum
Optical Drive
Hard Drive
Modem
Graphics
Audio
Software
A2+/550/64/1 2T/5/M/WD Display
219673-xx4 Processor
Cache Memory
Memory Standard
Maximum
Optical Drive
Hard Drive
Modem
Graphics
Audio
Software
12.1-inch color TFT/SVGA
AMD K6-2+ 550MHz
Internal 64KB L1 Cache Internal 128KB, L2 Cache
64MB SDRAM
192MB SDRAM
24X CD-ROM
5GB
N/A
Trident CBI7 4MB UMA RAM(Shared RAM)
16-bit SoundBlaster Pro compatible
Windows 98SE, MS Word 2000
12.1-inch color TFT/SVGA
AMD K6-2+ 550MHz
Internal 64KB L1 Cache Internal 128KB, L2 Cache
64MB SDRAM
192MB SDRAM
24X CD-ROM
5GB
56K
Trident CBI7 4MB UMA RAM(Shared RAM)
16-bit SoundBlaster Pro compatible
Windows 98SE
12.1-inch color TFT/SVGA
AMD K6-2+ 550MHz
Internal 64KB L1 Cache Internal 128KB, L2 Cache
64MB SDRAM
192MB SDRAM
24X CD-ROM
5GB
56K
Trident CBI7 4MB UMA RAM(Shared RAM)
16-bit SoundBlaster Pro compatible
Windows 98SE
12.1-inch color TFT/SVGA
AMD K6-2+ 550MHz
Internal 64KB L1 Cache Internal 128KB, L2 Cache
64MB SDRAM
192MB SDRAM
24X CD-ROM
5GB
56K
Trident CBI7 4MB UMA RAM(Shared RAM)
16-bit SoundBlaster Pro compatible
Windows 98SE, MS Word 2000
Compaq Armada 100S
DA-10695 World Wide — Version 7 — July 16, 2001
5
QuickSpecs
Standard Features
Models (continued)
A2+/550/64/1 2T/5/M/SB Display
219676-xx4 Processor
Cache Memory
Memory Standard
Maximum
Optical Drive
Hard Drive
Modem
Graphics
Audio
Software
A2+/550/64/1 2H/5/M/WD Display
219669-xx4 Processor
Cache Memory
Memory Standard
Maximum
Optical Drive
Hard Drive
Modem
Graphics
Audio
Software
A2+/550/64/1 2H/5/M/2 Display
219670-xx4 Processor
Cache Memory
Memory Standard
Maximum
Optical Drive
Hard Drive
Modem
Graphics
Audio
Software
A2+/550/64/1 2H/5/M/NA Display
219670-xx5 Processor
(NAFTA) Cache Memory
Memory Standard
Maximum
Optical Drive
Hard Drive
Modem
Graphics
Audio
Software
12.1-inch color TFT/SVGA
AMD K6-2+ 550MHz
Internal 64KB L1 Cache Internal 128KB, L2 Cache
64MB SDRAM
192MB SDRAM
24X CD-ROM
5GB
56K
Trident CBI7 4MB UMA RAM(Shared RAM)
16-bit SoundBlaster Pro compatible
Windows 98SE, Office 2000 Small Business
12.1-inch color HPA/SVGA
AMD K6-2+ 550MHz
Internal 64KB L1 Cache Internal 128KB, L2 Cache
64MB SDRAM
192MB SDRAM
24X CD-ROM
5GB
56K
Trident CBI7 4MB UMA RAM(Shared RAM)
16-bit SoundBlaster Pro compatible
Windows 98SE, MS Word 2000
12.1-inch color HPA/SVGA
AMD K6-2+ 550MHz
Internal 64KB L1 Cache Internal 128KB, L2 Cache
64MB SDRAM
192MB SDRAM
24X CD-ROM
5GB
56K
Trident CBI7 4MB UMA RAM(Shared RAM)
16-bit SoundBlaster Pro compatible
Windows 98SE
12.1-inch color HPA/SVGA
AMD K6-2+ 550MHz
Internal 64KB L1 Cache Internal 128KB, L2 Cache
64MB SDRAM
192MB SDRAM
24X CD-ROM
5GB
56K
Trident CBI7 4MB UMA RAM(Shared RAM)
16-bit SoundBlaster Pro compatible
Windows 98SE
Compaq Armada 100S
DA-10695 World Wide — Version 7 — July 16, 2001
6
QuickSpecs
Standard Features
Models (continued)
A2+/550/64/1 2H/5/M/PS Display
219671-xx4 Processor
Cache Memory
Memory Standard
Maximum
Optical Drive
Hard Drive
Modem
Graphics
Audio
Software
A2+/550/64/1 2H/5/M/2 Display
219672-xx4 Processor
Cache Memory
Memory Standard
Maximum
Optical Drive
Hard Drive
Modem
Graphics
Audio
Software
12.1-inch color HPA/SVGA
AMD K6-2+ 550MHz
Internal 64KB L1 Cache Internal 128KB, L2 Cache
64MB SDRAM
192MB SDRAM
24X CD-ROM
5GB
56K
Trident CBI7 4MB UMA RAM(Shared RAM)
16-bit SoundBlaster Pro compatible
Windows 98SE, Office 2000 Personal Edition
12.1-inch color HPA/SVGA
AMD K6-2+ 550MHz
Internal 64KB L1 Cache Internal 128KB, L2 Cache
64MB SDRAM
192MB SDRAM
24X CD-ROM
5GB
56K
Trident CBI7 4MB UMA RAM(Shared RAM)
16-bit SoundBlaster Pro compatible
Windows 98SE
Compaq Armada 100S
DA-10695 World Wide — Version 7 — July 16, 2001
7
QuickSpecs
Options
Compaq Armada 100S
Memory
Monitors
Docking Solutions
Connectivity
Wireless Connectivity
Power
Input Devices
Useful Accessories
32MB Memory Upgrade
64MB Memory Upgrade
128MB Memory Upgrade
TFTs
Compaq TFT8020 Monitor (18-inch, Carbon)
Compaq TFT5010 Monitor (15-inch, Carbon)
CRTs
Standard Series
Compaq S710 CRT Monitor (17-inch, Carbon)
Compaq S510 CRT Monitor (15-inch, Carbon)
Ultra3 (Ultra 160) SCSI Controller
Xircom PortStation USB Port Expansion Solution w/NIC 180947-xx1
Compaq Microcom 420 56K
(Designed only to allow faster downloads from v.90 compliant sources. Maximum
achievable download tr ansmission rates currently do not re ach 56KB/s, and will vary
with line conditions.)
10/100 TX PC Card UTP Controller
100BaseTX Ethernet Upgrade
Compaq WL100 11MB/s Wireless LAN PC Card (Industry-Standard Wireless
Technology)
Compaq WL400 11MB/s Wireless LAN Hardware Access Point
Compaq WL Software Access Point 11Mb/s
For more information on Compaq WLAN Wireless LAN solutions visit:
http://www.compaq.com/products/wlan/wl100-specifications.html
Note: This Web site is available in English only.
Li-Ion (8-cell) 175103-B25
AC Adapter (50W) 175101-xx1
Auto Adapter 188200-B21
External Enhanced III Keyboard (carbon) 118003-xx8
Compaq 2-Button Mouse (carbon) 103180-B21
USB 2-Button Mouse (carbon) 195255-B25
10 Key Numeric Keypad 294317-B21
Security Cable Lock 294316-B21
Biometric PC Card 146805-B25
Compaq Smart Card PC Card Read 135646-B25
Armada Headset with Microphone 220460-001
MP1800 Microportable Projector
MP1600 Microportable Projector
MP1400 Microportable Projector
Global Modem
179863-B21
179864-B21
179865-B21
159244-xxx
154486-xxx
154499-xx2
168636-xx2
144387-B21
317900-001
335506-B21
225435-001
146927-001
158603-001
157209-B21
180226-xx1
386202-xx1
174626-xx4
DA-10695 World Wide — Version 7 — July 16, 2001
8
QuickSpecs
Options
Compaq Armada 100S
Carrying Cases
Compaq Ultralight Case
Compaq Value Case
Compaq Workstation Case
Compaq Global Case
Compaq Executive Case
Compaq Professional N Case
Compaq Professional L Case
For additional Compaq Brand cases, call 1-800-888-5903.
167336-B21
294266-B21
294267-B21
294268-B21
294269-B21
401366-B21
401367-B21
DA-10695 World Wide — Version 7 — July 16, 2001
9
QuickSpecs
y
y
Memory
Compaq Armada 100S
S
TANDARD MEMORY
32MB onboard (1 slot available)
Standard 32MB 32MB Empt
64MB 32MB 32MB
96MB 32MB 64MB
64MB onboard (1 slot available)
Standard 64MB 64MB Empt
96MB 64MB 32MB
128MB 64MB 64MB
Following are memory options available from Compaq:
(AMD K6-2+ 550MHz Models)
Memory Onboard Slot 1
160MB 32MB 128MB
Memory Onboard Slot 1
192MB 64MB 128MB
Compaq Armada 100S
•
32MB Memory Upgrade 179863-B21
•
64MB Memory Upgrade 179864-B21
•
128MB Memory Upgrade 179865-B21
DA-10695 World Wide — Version 7 — July 16, 2001
10
QuickSpecs
Storage
D
RIVE SUPPORT
System Drive Support
Media
24X CD-ROM Up to 1 Fixed
1.44MB Diskette Drive Up to 1 Fixed
Hard Drive s
5GB Hard Drive Up to 1 Fixed
1. CD-ROM
2. HDD
3. FDD
Quantity
Supported
Drive Bay
Supported
Compaq Armada 100S
DA-10695 World Wide — Version 7 — July 16, 2001
11
QuickSpecs
Technical Specifications
Compaq Armada 100S
System Unit
Dimensions (HxWxD)
Weight
Stand-Alone Power
Requirements
Temperature
Relative Humidity
Shock
Vibration
Maximum Altitude
(unpressurized)
1.6 x 11.7 x 9.4 in/4.1 x 29.7 x 23.9 cm
AMD K6-2+ 550MHz 6.6 lbs/3 kg to 6.8 lbs/3.1 kg
Nominal Operating Voltage
(Li-Ion)
Nominal Operating Voltage
(NiMH)
Maximum Operating Power 20W
Peak Operating Power 26W
Operating 50° to 95°F/10° to 35°C
Non-operating –4° to 140°F/–20° to 60°C
Operating 10% to 90% relative humidity, non-condensing
Non-operating 5% to 95% relative humidity, 101.6°F/38.7°C
Operating 10 G, 11 ms, half-sine
Non-operating 60 G, 11 ms, half-sine
Operating 0.5 G zero-to-peak, 10 to 500 Hz, at 0.5 oct/min
Non-operating 1.0 G, zero-to-peak, 10 to 500 Hz, at 0.5 oct/min
Operating 0 to 10,000 ft/0 to 3,048 m
Non-operating 0 to 40,000 ft/0 to 9,144 m
14.8 VDC
10.8 VDC
Maximum wet bulb temperature
sweep rate
sweep rate
DA-10695 World Wide — Version 7 — July 16, 2001
12
QuickSpecs
Technical Specifications
Compaq Armada 100S
12.1-Inch Color HPA SVGA
Display
12.1-Inch Color TFT SVGA
Display
Dimensions (HxW) 8.17 x 10.83 in/20.25 x 27.5 cm
Diagonal Size 12.1 in/30.74 cm
Mounting Internal
Number of Colors 65K
Contrast Rat io 40:1
Brightness 70+ nit
Pixel Resolution Pitch 0.1021 x 0.306 mm
Format 800 x 600
Backlight Cold cathode fluorescent, 1 tube
Character Display 80 x 25
Total Power Consumption 2.75W
Refresh 60 Hz
Dimensions (HxW) 7.83 x 10.83 in/19.9 x 27.5 cm
Diagonal Size 12.1 in/30.74 cm
Mounting Internal
Number of Colors 262K
Contrast Rat io 200:1
Brightness 115+ nit
Pixel Resolution Pitch 0.3075 x 0.3075 mm
Backlight Cold cathode fluorescent, 1 tube
Character Display 80 x 25
Total Power Consumption 4.5W
Refresh 60 Hz
Configuration RGB Stripe
Format 800 x 600
Configuration RGB Vertical Stripe
DA-10695 World Wide — Version 7 — July 16, 2001
13
QuickSpecs
Technical Specifications
Compaq Armada 100S
13.3-Inch Color TFT XGA
Display
5GB Hard Drive
Average 13 ms (read)
Diskette Drive
Dimensions (HxW) 7.83 x 10.83 in/19.9 x 27.5 cm
Diagonal Size 13.3 in/33.78 cm
Mounting Internal
Number of Colors 262K
Contrast Rat io 200:1
Brightness 140+ nit
Pixel Resolution Pitch 0.264 x 0.264 mm
Format 1024 x 768
Backlight Cold cathode fluorescent, 1 tube
Character Display 80 x 25
Total Power Consumption 5W
Refresh 60 Hz
Capacity
Height
Width
Interface
Transfer Rate
Seek Time (typical reads,
including settling)
Rotational Speed
Physical Configuration
Operating Temperature
Diskette Size 3.5 in
Activity Indicator On system
Height 0.5in/12.7 mm
Bytes per Sector 512
Sectors per track High density 18 (1.44MB)/15 (1.2MB)
Low density 9
Tracks per side
Read/Write heads 2
Access Times Track-to track (high/low) 3 ms/6 ms
Configuration RGB Vertical Stripe
5GB
0.37 in/9.5 mm
2.5 in/63.5 mm
ATA-5
Media
Interface UDMA 33.3MB/s
Single Track 3 ms
Full-Stroke 24 ms
4200 rpm
Bytes/sector
41° to 131°F/5° to 55°C
High density 80 (1.44MB)/80 (1.2MB)
Low density 80
Average (high/low) 94 ms/174 ms
Settling time 15 ms
Latency average 100 ms
86.4-153.3MB/s
512
DA-10695 World Wide — Version 7 — July 16, 2001
14
QuickSpecs
Technical Specifications
External AC Adapter Weight 0.45 lb/0.21 kg
Li-Ion Battery Pack
Temperature
NiMH Battery Pack
Temperature
Power Supply (Input) Operating Voltage 100 to 240 VAC RMS Nominal
Dimensions (HxWxD) 0.58 x 5.91 x 2.76 in/1.48 x 15.02 x 7.02 cm
Weight 0.93 lb/0.42 kg
Cells 8 Li-Ion
Energy Voltage 14.8 V
Dimensions (HxWxD) 0.58 x 5.91 x 2.76 in/1.48 x 15.02 x 7.02 cm
Weight 1.25 lb/0.57 kg
Cells 9 NiMH
Energy Voltage 10.8 V
Operating Current 1.5 A RMS
Operating Frequency Range 50 to 60 Hz AC Nominal
Maximum Transient 4/50 kV
Amp-hour capacity 3.2 Ah
Watt-hour capacity 47.36Wh
Operating 50° to 104°F/10° to 40°C
Non-operating –12° to 140°F/–30° to 60°C
Amp-hour capacity 3.8 Ah
Watt-hour capacity 41.04Wh
Operating 50° to 104°F/10° to 40°C
Non-operating –12° to 140°F/–25° to 60°C
Compaq PCs use genuine Microsoft Windows
www.Microsoft.com\piracy\howtotell
Microsoft and Windows are trademarks of Microsoft Corporation in the U.S. and other countries.
Compaq Armada 100S
DA-10695 World Wide — Version 7 — July 16, 2001
15
Loading...
