QuickSpecs
Overview
At A Glance
•
Intel 815E chipset
•
133 MHz Front Side Bus
•
One Intel Pentium III
processor up to 1.2 GHz
•
High-perfor m ance 10,000 rpm
and optional 15,000 rpm Ultra160
SCSI and Quiet Seek 7200 rpm
Ultra ATA hard drives
•
Choice of graphics controllers:
Matrox Millennium G4 50 du al,
NVIDIA Quadro2 EX, , ELSA
Synergy II, or NVIDIA Quadro2
MXR
•
Multi-display support
•
Convertible minitower form factor
with external drives that rotate
90°, easily c onverting from
minitower to desktop
•
Compaq Intelligent Manageability
•
Windows 2000 or Windows NT
4.0 pre-inst alled
•
Easy Access Keyboard
•
Protected by Compaq Services,
including a t hree-year, limi ted
warranty – Terms and conditions
vary by country. Certain
restrict ions and exclusions apply.
Compaq Deskpro Workstation AP230
DA-10843 North Americ a — Version 6 — October 1, 2001 1
QuickSpecs
Standard Features – Pre Configured Models
Chipset – Intel 815E
Processor and Speed
One of the following
Hard Drives
One of the following
Intel Pentium III Processors
1 GHz
20-GB 7200 rpm SMART III Ultra ATA/100 with Drive Protection System
20-GB 7200 rpm SMART III Ultra ATA/100 with Drive Protection System (Quite Seek and Idle HDD (EMEA Only)
40-GB 7200 rpm SMART III Ultra ATA/100 with Drive Protection System
18-GB Ultra160/10K RPM SCSI HDD
Adaptec 29160 U160 SCSI Controller on SCSI models
Compaq Deskpro Workstation AP230
Standard L2 Cache 256-KB Integrated ECC
Front Side Bus 133 MHz
Memory
One of the following
Removable S torage
Optical Storag e
One of the following
Keyboard/Mouse
Audio
Network Con troller
One of the following: ELSA Synergy II (AGP)
Expansion Capability Memory Expansion Slots (DIMMS) 3 DIMMS
Standard
Standard
Maximum
1.44-MB Diskette Drive
48X CD-ROM Drive
8X/4X/32X CD-RW
Easy Access Keyboard
3-Button Mouse
Integrated Intel Audio with Premium Internal Speaker
Integrated Intel PRO/100 VM Network Connection
Matrox G450 AGPGraphics
NVIDIA Quadro2 EX
NVIDIA Quadro2 MXR
Memory Type SDRAM
Maximum Memory 512MB
128 MB (PC133MHz SDRAM Memory)
256 MB (PC133MHz SDRAM Memory)
512 MB (PC133MHz SDRAM Memory)
Expansion Slots
Expansion Bays
Operating System
DA-10843 North Americ a — Version 6 — October 1, 2001 2
(Total/Available) 6/4
AGP 1/ up to 1 depending on model
PCI 5/ up to 4 depending on model
(Total/Available)
Internal
External
Dual Installation Windows 2000 with selectable Service Pack 1/Windows NT 4.0 with Service Pack 6a
Note: Dual Installation- End-user must make a one-time selection between Windows 2000 and Windows NT 4.0. If
end-user desires the rejected product(s) after selection is made, the end-user must acquire and pay for
rejected product separately.
5/2
2/1
3/1
QuickSpecs
Compaq Deskpro Workstation AP230
Standard Features – Pre Configured Models
Chipset – Intel 815E (continued)
Interfaces I/O Chip Socket 370, Coppermine 128K/256K FC-PGA 66/100/133 FSB
Serial Port / UART Type Yes
Parallel Port Yes
USB 2 ports
Infrared Port No
Network RJ-45 (with integrated LEDs)
Keyboard Yes
Mouse Yes; PS/2
Video Yes
Audio Yes
Power Conservation ‘Energy
Saver’
Boot Support Local Diskette Boot Yes (Windows 95, Windows 98.DOS)
Initial Configu ration and
Deployment
Energy Star Compliant Yes (on select models)
Power Consumption in ES Mode http://wwweng.hou.compaq.com/-agency/e-star.htm
Note: This Web site is available in English only.
APM Support Version 1.2
Screen Blanking Yes
Hard Disk ″Idle″ Mode Yes
System Idle Mode Yes
Cache Memory Power-Down No
CD-Rom Down Yes
System Environmental Specifications
Temperature, Acoustics, Shock,
Vibration, and Altitude
Remote Diskette Boot No
Network Boot Yes
Altiris eXpress http://www.compaq.com/im
PC Transplant/PC Transplant PRO http://www.compaq.com/im
System Software Management ver 1.4 http://www.compaq.com/im
Novel ZenWorks 2.0 http://www.compaq.com/im
IM LC ver 1.6 http://www.compaq.com/im
Support Software CD http://www.compaq.com/im
Compaq OS Restore CD Yes
http://envwebserver.eng.hou.compaq.com/envtestlab/prod02.htm
Note: This Web site is available in English only.
Note: These Web sites are available in English only.
Asset Contr ol Asset Tag Yes
DIMM Serial Presence Detect Yes
Hard drive serial number, model, and
manufacturer
Monitor serial number, model and
manufacturer
System serial number, model, and
manufacturer
ROM revision levels Yes
Systemboard revision level Yes
Compaq Fingerprint Identification
Technology
Configuration Control Hardware No
DMI BIOS Yes
Memory Change Alert Yes
Ownership Tag Yes
Kensington Lock Support Yes
DA-10843 North Americ a — Version 6 — October 1, 2001 3
Yes
Yes
Yes
Yes/Optional
QuickSpecs
Standard Features – Pre Configured Models
Chipset – Intel 815E (continued)
Standard Security Features Cable Lock Provision Yes
Power-On Password Yes
QuickBlank/QuickLock No
Serial, Parallel, USB Port Control Yes
Removable Media Write/Boot Control Yes
Setup Password Yes
Compaq Deskpro Workstation AP230
Software Updating and
Management
Fault Noti fication and
Recovery
Other Features ACPI-Ready Hardware Yes
Compaq Info Messenger Yes
Remote Security Management Yes
Remote ROM Flash Yes, requires CPQRS driver
Remote Wakeup/Remote Shutdown Yes
ROM-Based Setup and Diagnostics Yes
Support Software CD and WWW site Yes
DMI BIOS Yes
SMART Hard Drives, Fault Notification, and
Prefailure Warranty
Proactive Backup Yes
ECC Memory, Fault Notification, and Pre-
failure Warning
Processor Fault Notification and Prefailure
Warranty
Surge Tolerant Power Supply Yes
Thermal Sensor Yes
Ultra ATA Integrity Monitoring Yes
Compaq Insight Manager LC and XE
Agents
Altiris agent Yes
Compaq Management Solutions Partners
Program
Dual-State Power Button Yes
Compaq Management Solutions Partners
Program
Wired for Management Support Yes
Yes
Not Supported; 815E does not support ECC memory
Yes
Yes
Yes
Yes
Intelligent M anageability Compaq Intelligent Manageability, a key component of PC Lifecycle Solutions, is the broad set of manageability
DA-10843 North Americ a — Version 6 — October 1, 2001 4
features found on all Compaq Deskpro desktops, Armada portables, Des kpro W orks tation, Professional
Workstation, and ProLiant server products. These best-in-class features on PC clients comply with industry
standards, such as DMI and Wired for Management, while pioneering new ground in client manageability. Compaq
introduced the industry’s first line of manageable clients in 1995 and has been driving the industry ever since. With
Compaq’s lifecycle management philosophy, enterprises have all of the pieces for end-to-end management and
proven tools for hassle-free management of PCs and significantly lower total cost of ownership.
Intelligent Manageability offers solutions in the areas of Initial Configuration and Deployment, Asset Tracking and
Security, Software Updating and Management, and Fault Notification and Recovery. For more information, visit our
Web site: www.compaq.com/im. Note: This Web site is available in English only.
QuickSpecs
Standard Features – Pre Configured Models
Chipset – Intel 815E (continued)
Software Windows 3.1 No
Windows NT 4.X Yes
Windows 2000 Yes
Windows NT 4.X/Windows 2000 Yes
Computer Setup Utility Yes
Insight Personal Edition Yes
Diagnostics for Windows Yes
Microsoft Internet Explorer Yes
Compaq Information Center No
Intelligent Manageability Agent Yes
Power Supply Convertible Minitower
200 Watts
Compaq Deskpro Workstation AP230
Service and Support
On-site Warranty and ServiceNo
on-site, next business-day
coverage
will remain fully covered under the original warranty and service offering.
Note 1: Terms and conditions may vary by country. Certain restrictions and exclusions apply.
Note 2: On-site service may be provided pursuant to a service contract between Compaq and an authorized Compaq
Note 3: Technical telephone support applies only to Compaq-configured, Compaq and Compaq-qualified, third-party
Note 2
ensures that any product purchased in one country and transferred to another, non-restricted country
third-party provider, and is not available in certain countries. Global service response times are based on
commercially reasonable best effort and may vary by country.
hardware and software. Toll-free calling and 24 x 7 support may not be available in some countries.
Note 1
Note 2
: This three-year, limited warranty and service offering delivers three years of
service for parts and labor and includes free telephone support
Note 3
24 x 7. Global
DA-10843 North Americ a — Version 6 — October 1, 2001 5
QuickSpecs
Standard Features – Pre Configured Models
Compaq Deskpro Workstation AP230
D23/1.0/20A/256/2+C
470012-811
D23/1.0/18S/256/2XC
470012-856
D23/1.0/20A/256/2+C
470014-563
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Controller
Graphics
Audio
OS
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Controller
Graphics
Audio
OS
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Controller
Graphics
Audio
OS
1GHz Pentium III w/ 133MHz FSB
256-KB Integrated ECC
256MB PC133 SDRAM (1x256)
48X CD-ROM
20-GB Ultra ATA 7200 rpm
Integrated Ultra ATA/100
nVIDIA Quadro2 MXR
Integrated AC97 Premier•Sound
Dual Windows NT 4.0 SP6a/Windows 2000 SP1 pre-install
1GHz Pentium III w/ 133MHz FSB
256-KB Integrated ECC
256MB PC133 SDRAM (1x256)
48X CD-ROM
18.2-GB Ultra 160 SCSI (10,000 rpm)
Integrated Ultra ATA/100 and Ultra160 SCSI PCI
Matrox Millennium G450 (AGP)
Integrated AC97 Premier•Sound
Dual Windows NT 4.0 SP6a/Windows 2000 SP1 pre-install
1GHz Pentium III w/ 133MHz FSB
256-KB Integrated ECC
256MB PC133 SDRAM (1x256)
48X CD-ROM
20-GB Ultra ATA 7200 rpm
Integrated Ultra ATA/100
ELSA Synergy II
Integrated AC97 Premier•Sound
Dual Windows NT 4.0 SP6a/Windows 2000 SP1 pre-install
DA-10843 North Americ a — Version 6 — October 1, 2001 6
QuickSpecs
Compaq Deskpro Workstation AP230
Standard Features – Custom Configuration Models
Deskpro Works tation AP230-Fl exible Solutions Configured to Ord er
Order the Compaq Deskpro Workstation the way the customer wants it by selecting the processor, hard drive, memory, graphics controller, and more.
Purchase directly from Compaq or a Compaq Authorized Agent. Configurable components and Options change frequently. Check the Compaq Product
Bulletin or www.compaq.com for the latest options available from Compaq. Note: This Web site is available in English only.
Chipset – Intel 815E
Processor and Speed
One of the following
Hard Drive 18.2-GB 10,000 rpm Ultra160 SCSI with PCI Ultra160 Controller
One of the following 18.2-GB 15,000 rpm Ultra160 SCSI with PCI Ultra160 Controller
Memory 128-MB SDRAM (PC133) (utilizes one DIMM slot)
One of the following 256-MB SDRAM (PC133) (utilizes one DIMM slot)
Intel Pentium III Processors
1.2GHz
1 GHz
933 MHz
20-GB 7200 rpm SMART III Ultra ATA/100 with Drive Protection System
20-GB 7200 rpm SMART III Ultra ATA/100 with Drive Protection System (Quite Seek and Idle HDD (EMEA ONLY)
40-GB 7200 rpm SMART III Ultra ATA/100 with Drive Protection System
384-MB SDRAM (PC133) (utilizes two DIMM slots)
512-MB SDRAM (PC 133) (utilizes two DIMM slots)
Standard L2 Cache 256-KB Integrated ECC
Front Side Bus 133 MHz
Maximum Memory
512MB
Removable S torage 1.44-MB Diskette Drive
Optical Storag e 48X CD-ROM Drive
16X DVD-ROM Drive
8X/4X/32X CD-RW Drive
Keyboard/Mouse Easy Access Keyboard
Audio Integrated Intel Audio with Premium Internal Speaker
Network Con troller Integrated Intel PRO/100 VM Network Connection
V.90 56K PCI Modem
Graphics Matrox G450 Dual Head 32-MB AGP
One of the following:
Expansion Slots (Total/Available)
Expansion Capability Memory Expansion Slots (DIMMS) 3 DIMMS
ELSA Synergy II 32-MB AGP
NVIDIA Quadro2 EX
NVIDIA Quadro2 MXR
AGP 1/ up to 1 depending on model
PCI 5/ up to 4 depending on model
Memory Type SDRAM
Maximum Memory 512MB
Expansion Bays (Total/Available) 5/2
Internal 2
External 3
DA-10843 North Americ a — Version 6 — October 1, 2001 7
QuickSpecs
Compaq Deskpro Workstation AP230
Standard Features – Custom Configuration Models
Chipset – Intel 815E (continued)
Operating System
Interfaces I/O Chip Socket 370, Coppermine 128K/256K FC-PGA 66/100/133 FSB
Dual Installation Windows 2000 with selectable Service Pack 1/Windows NT4.0 with Service Pack 6a
Note: Dual Installation- End-user must
make a one-time selection between
Windows NT 4.0 and Windows 2000. If
end-user desires the rejected product(s)
after selection is made, the end-user
must acquire and pay for rejected
product separately.
Serial Port/UART Type Yes
Parallel Port Yes
USB 2 ports
Infrared Port No
Network RJ-45 (with integrated LEDs)
Keyboard Yes
Mouse Yes; PS/2
Video Yes
Audio Yes
Power Conservation ″″″″Energy
Saver″″″″
Boot Support Local Diskette Boot Yes (Windows 95, Windows 98.DOS)
Initial Configu ration and
Deployment
Energy Star Compliant Yes (on select models)
Power Consumption in ES Mode http://wwweng.hou.compaq.com/-agency/e-star.htm
APM Support Version 1.2
Screen Blanking Yes
Hard Disk ‘Idle’ Mode Yes
System Idle Mode Yes
Cache Memory Power-Down No
CD-ROM Down Yes
System Environmental Specifications
Temperature, Acoustics, Shock,
Vibration, and Altitude
Remote Diskette Boot No
Network Boot Yes
Altiris eXpress http://www.compaq.com/im
PC Transplant/PC Transplant PRO http://www.compaq.com/im
System Software Management ver 1.4 http://www.compaq.com/im
Novel ZenWorks 2.0 http://www.compaq.com/im
IM LC ver 1.6 http://www.compaq.com/im
Support Software CD http://www.compaq.com/im
Compaq OS Restore CD Yes
Note: This Web site is available in English only.
http://envwebserver.eng.hou.compaq.com/envtestlab/prod02.htm
Note: This Web site is available in English only.
Note: These Web sites are available in English only.
DA-10843 North Americ a — Version 6 — October 1, 2001 8
QuickSpecs
Compaq Deskpro Workstation AP230
Standard Features – Custom Configuration Models
Chipset – Intel 815E (continued)
Asset Contr ol Asset Tag Yes
DIMM Serial Presence Detect Yes
Hard drive serial number, model, and
manufacturer
Monitor serial number, model and
manufacturer
System serial number, model, and
manufacturer
ROM revision levels Yes
Systemboard revision level Yes
Compaq Fingerprint Identification
Technology
Configuration Control Hardware No
DMI BIOS Yes
Memory Change Alert Yes
Ownership Tag Yes
Kensington Lock Support Yes
Yes
Yes
Yes
Yes/Optional
Standard Security Features
Software Updating and
Management
Fault Noti fication and
Recovery
Cable Lock Provision Yes
Power-On Password Yes
QuickBlank/QuickLock No
Serial, Parallel, USB Port Control Yes
Removable Media Write/Boot Control Yes
Setup Password Yes
Compaq Info Messenger Yes
Remote Security Management Yes
Remote ROM Flash Yes, requires CPQRS driver
Remote Wakeup/Remote Shutdown Yes
ROM-Based Setup and Diagnostics Yes
Support Software CD & WWW site Yes
DMI BIOS Yes
SMART Hard Drives, Fault Notification,
& Prefailure Warranty
Proactive Backup Yes
ECC Memory, Fault Notification, and
Pre-failure Warning
Processor Fault Notification and
Prefailure Warranty
Surge Tolerant Power Supply Yes
Thermal Sensor Yes
Ultra ATA Integrity Monitoring Yes
Yes
Not Supported; 815E does not support ECC memory
Yes
DA-10843 North Americ a — Version 6 — October 1, 2001 9
QuickSpecs
A
r
Compaq Deskpro Workstation AP230
Standard Features – Custom Configuration Models
Chipset – Intel 815E (continued)
Other Features ACPI-Ready Hardware Yes
Compaq Insight Manager LC and XE
Agents
Altiris agent Yes
Compaq Management Solutions
Partners Program
Dual-State Power Button Yes
Compaq Management Solutions
Partners Program
Wired for Management Support Yes
Yes
Yes
Yes
Intelligent M anageability Compaq Intelligent Manageability, a key component of PC Lifecycle Solutions, is the broad set of manageability
Software Windows 3.1
Power Supply 200 Watts
Service and Support
features found on all Compaq Deskpro desktops,
and ProLiant server products. These best-in-class features on PC clients comply with industry standards, such as
DMI and Wired for Management, while pioneering new ground in client manageability. Compaq introduced the
industry’s first line of manageable clients in 1995 and has been driving the industry ever since. With Compaq’s
lifecycle management philosophy, enterprises have all of the pieces for end-to-end management and proven tools fo
hassle-free management of PCs and significantly lower total cost of ownership.
Intelligent Manageability offers solutions in the areas of Initial Configuration and Deployment, Asset Tracking and
Security, Software Updating and Management, and Fault Notification and Recovery. For more information, visit our
Web site: www.compaq.com/im. Note: This Web site is available in English only.
No
Windows NT 4.X
Windows 2000
Windows NT 4.X/Windows 2000
Computer Setup Utility
Insight Personal Edition
Diagnostics for Windows
Microsoft Internet Explorer
Compaq Information Center
Intelligent Manageability Agent
On-site Warranty and Service
site, next business-day
coverage
will remain fully covered under the original warranty and service offering.
Note 1: Terms and conditions may vary by country. Certain restrictions and exclusions apply.
Note 2: On-site service may be provided pursuant to a service contract between Compaq and an authorized
Note 3: Technical telephone support applies only to Compaq-configured, Compaq and Compaq-qualified, third-party
Note 2
ensures that any product purchased in one country and transferred to another non-restricted country
Compaq third-party provider, and is not available in certain countries. Global service response times are
based on commercially reasonable best effort and may vary by country.
hardware and software. Toll-free calling and 24 x 7 support may not be available in some countries.
Note 1
Note 2
service for parts and labor and includes free telephone support
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Yes
: This three-year, limited warranty and service offering delivers three years of on-
rmada portables, Deskpro Workstation, Professional Workstation,
Note 3
24 x 7. Global
DA-10843 North Americ a — Version 6 — October 1, 2001 10
QuickSpecs
After-Market Options
Compaq Deskpro Workstation AP230
Memory (DIMMs)
Monitors
133-MHz SDRAM DIMMs
256-MB Memory Kit (1 x 256-MB SDRAM DIMM, 133 MHz)
128-MB Memory Kit (1 x 128-MB SDRAM DIMM, 133 MHz)
Bulk
256-MB Memory Kit (1 x 256-MB SDRAM DIMM, 133-MHz)
128-MB Memory Kit (1 x 128-MB SDRAM DIMM, 133-MHz)
TFTs
Compaq TFT8020 Monitor (18-inch, Opal)
Compaq TFT8020 Monitor (18-inch, Carbon)
Compaq TFT5010 Monitor (15-inch, Opal)
Compaq TFT5010 Monitor (15-inch, Carbon)
Compaq TFT5005 Monitor (15-inch, Opal)
Compaq TFT5005 Monitor (15-inch, Carbon)
CRTs
Professional Series
Compaq P1210 CRT Monitor (21-inch, Opal)
Compaq P910 CRT Monitor (19-inch, Opal)
Compaq P710 CRT Monitor (17-inch, Opal)
Value Series
Compaq V1100 CRT Monitor (21-inch, Opal)
Compaq V710 CRT Monitor (17-inch, Opal)
174225-B21
174224-B21
174233-B21
174232-B21
326100-001
159244-001
104741-001
154486-001
201431-001
201430-001
210290-001
210254-001
210189-001
386472-001
187895-001
Standard Series
Compaq S910 CRT Monitor (19-inch, Opal)
Compaq S710 CRT Monitor (17-inch, Opal)
Compaq M710 CRT Monitor (17-inch, Opal)
Compaq S710 CRT Monitor (17-inch, Carbon)
Compaq S510 CRT Monitor (15-inch, Carbon)
Graphics
Tape Drives 33/66 GB VXA-1 SCSI Tape Drive (Opal) 237108-B21
Controller Cards
Matrox G450 32-MB AGP
ELSA Synergy II 32-MB AGP
NVIDIA Quadro2 EX
NVIDIA Quadro2 MXR
33/66 GB VXA-1 IDE Tape Drive (Opal) 237109-B21
33/66 GB VXA-1 Media (2-Pack) 237111-B21
VXA-1 Cleaning Cartridge 237110-B21
138485-001
152991-001
154499-005
154499-002
168636-002
202389-B21
103382-B21
232090-B21
221412-B21
DA-10843 North Americ a — Version 6 — October 1, 2001 11
QuickSpecs
After-Market Options
Compaq Deskpro Workstation AP230
Optical Drives
Hard Drives
Controllers/Cables/Adapters
Multimedia
DVD-ROM Drives
16X/40X DVD-ROM Drive
CD-ROM Drives
48X CD-ROM Drive 187217-B21
CD-RW Drives
8X/4X/32X CD-RW Drive
Ultra ATA/100 Hard Drives with Drive Protection System (DPS)
20-GB Ultra ATA 100 (7200 rpm) Hard Drive w/DPS - Quiet Seek and Quiet Idle
20-GB Ultra ATA 100 (7200 rpm) Hard Drive w/DPS - Quiet Seek
40-GB Ultra ATA 100 (7200rpm) Hard Drive w/DPS - Quiet Seek and Quiet Idle
SCSI Hard Drives
18-GB 10K rpm Ultra 160 SCSI Hard Drive
18GB 15K rpm Ultra 160 SCSI Hard Drive
Adaptec 29160N Ultra 160 Single Channel SCSI Controller
•
Sound PS330 Speakers
Premier
Altec Lansing ACS21 Speakers
Altec Lansing ACS33 Speakers
211055-B21
294407-B21
176275-021
176272-B21
201066-B21
159764-B21
191188-B21
157810-B21
160992-001
194839-001
203621-001
Communications
Input/Output Devices
Support Software CD
Other
Compaq V.90 56K PCI Modem
Compaq Easy Access Keyboard
Annual Subscription
Single CD-ROM (current month)
Rack Mount Conversion Kit, fixed Rails
Sliding Shelf Kit
Depth Adjustable Rails
171914-001
122660-006
183426-001
272505-001
303606-B21
332564-B21
332558-B21
DA-10843 North Americ a — Version 6 — October 1, 2001 12
QuickSpecs
yEmpty
Memory
815E chipset (128 MB)
Compaq Deskpro Workstation AP230
133-MHZ SDRAM DIMM M
S
TANDARD MEMORY
128-MB DIMM Standard
S
TANDARD MEMORY PLUS OPTIONAL MEMORY
Support for up to 512 MB of DIMM memory is available with the installation of optional SDRAM Memory Kits.
S
TANDARD MEMORY REPLACED WITH OPTIONAL MEMORY
Support for up to 512 MB of DIMM memory is available with the removal of the standard 128-MB DIMM and the installation of optional SDRAM
Memory Kits.
Memory Slot
Standard 128 MB
Optional 512 M B
Maximum 512 MB
Note: All Compaq Deskpro Workstation AP230 series contain three DIMM slots, but can only be upgraded to a maximum of 512 MB. The
limitation of 512 MB maximum is a limitation of the memory controller in the 815E chipset.
Note: It is not necessary to add memory in pairs or kits. Memory upgrades are accomplished by adding single or multiple DIMMs of the same or
varied sizes. This chart does not represent all possible memory configurations.
EMORY
12
128 MB Empt
128 MB 128 MB 256 MB
256 MB 256 MB Empty
3
DA-10843 North Americ a — Version 6 — October 1, 2001 13
QuickSpecs
y
Memory
815E chipset (256 MB)
Compaq Deskpro Workstation AP230
133-MHZ SDRAM DIMM M
S
TANDARD MEMORY
256-MB DIMM Standard
S
TANDARD MEMORY PLUS OPTIONAL MEMORY
Support for up to 512 MB of DIMM memory is available with the installation of optional SDRAM Memory Kits.
Memory Slot
Standard 256 MB
Optional 512 M B
Note: All Compaq Deskpro Workstation AP230 series contain three DIMM slots, but can only be upgraded to a maximum of 512 MB. The
limitation of 512 MB maximum is a limitation of the memory controller in the 815E chipset.
Note: It is not necessary to add memory in pairs or kits. Memory upgrades are accomplished by adding single or multiple DIMMs of the same or
varied sizes. This chart does not represent all possible memory configurations.
EMORY
12
256 MB Empt
256 MB 256 MB
DA-10843 North Americ a — Version 6 — October 1, 2001 14
QuickSpecs
Storage
D
ESKPRO WORKSTAT ION
C
ONVERTIBLE MINITOWER
Diskette Drives 1 3 Floppy
Floppy Drives 1 3 IDE
CD-ROM Drives 2 1,2 IDE
DVD-ROM Drives 2 1,2 IDE
CD-RW Drives 2 1,2 IDE
SMART III Ultra ATA Hard Drives Up to 2 4,5 Ultra ATA
SCSI Hard Drives Up to 2 4,5 SCSI
AP230 S
Quantity
Supported
ERIES DRIVE SUPPORT
Position
Supported Controller
Compaq Deskpro Workstation AP230
DA-10843 North Americ a — Version 6 — October 1, 2001 15
QuickSpecs
Technical Specifications
Compaq Deskpro Workstation AP230
System Unit
Chassis
Dimensions (HxWxD)
Weight (approximate)
Weight Supported
Power Supply Operating Voltage Range 90 to 132 VAC/180 to 264 VAC
Temperature
Humidity
Maximum Altitude Operating 0 to 10,000 ft/0 to 3,048 m
Color Opal
Architecture PCI/AGP
System Board Form Factor Standard ATX wit custom power supply
Flash ROM Yes
17.65 x 6.6 x 17.11 in/44.83 x 16.76 x 43.46 cm
26 lbs/11.8 kg
100 lbs/45.5 kg
Rated Voltage Range 100 to 127 VAC/200 to 240 VAC
Rated Line Frequency 50 to 60 Hz
Rated Input Current 6A/3A
Maximum Rated Power 200W
Power Supply Fan
Processor Fan
Chassis Fan
Operating 50° to 95°F/10° to 35°C
Non-operating –4° to 140°F/–20° to 60°C
Operating
Non-operating
Non-operating 0 to 30,000 ft/0 to 9,144 m
Maximum Rate of Change 1500 feet per minute/457 meters per minute
Variable speed fan integrated into power supply
Fixed Speed
Variable speed fan mounted to chassis
(Convertible Minitower and Slim Desktop only)
20% to 80%
10% to 90%
DA-10843 North Americ a — Version 6 — October 1, 2001 16
QuickSpecs
Technical Specifications
Compaq Deskpro Workstation AP230
Compaq Easy Access Keyboard Dimensions (HxWxD)
Weight
Electrical
Mechanical Languages
Environmental
18.3 x 6.3 x 1.4 in/465 x 160 x 36 mm
Approximately 2 lbs/0.9 kg
Operating Voltage
Power Consumption 50 mA maximum (with 3 LEDs on)
System Interface PS/2 mini-din connector
ESD CE level 4, 15 kV air discharge
EMI-RFI
PC98 Functionally compliant
Keycaps Low-profile design
Switch Actuation 55 g nominal peak force with tactile feedback
Switch Life 20 million keystrokes (using Hasco modified tester)
Switch Type Contamination resistant membrane
Key Leveling Mechanism For all double wide and greater length keys
Cable Length 6 ft/1.8 m
PC98-99 Mechanically compliant
Acoustics 50 dBA maximum sound pressure level
Operating Temperature
Non-operating Temperature
Operating Humidity 10% to 90% (non condensing at ambient)
Non-operating Humidity 20% to 80% (non condensing at ambient)
Operating Shock 40 g, 6 surfaces
Non-operating Shock 80 g, 6 surfaces
Operating Vibration 2 g peak acceleration
Non-operating Vibration 4 g peak acceleration
+5VDC ± 5%
Conforms to FCC rules for a Class B computing
device
30+ available
50° to 122° F/10° to 50° C
−22° to 140° F/−30° to 60° C
DA-10843 North Americ a — Version 6 — October 1, 2001 17
QuickSpecs
Technical Specifications
Compaq Deskpro Workstation AP230
Compaq 3-Button Mouse
Dimensions/Weight
Environmental
Mechanical Resolution
Regulatory Approvals
Height 1.42 in/3.6 cm
Length 4.17 in/10.7 cm
Width 2.87 in/7.4 cm
Weight 5.20 oz/150 g
Operating Temperature
Non-operating Temperature
Operating Humidity 10% to 90% (non condensing at ambient)
Tracking Speed 10 in/s Maximum
Tracking Mechanism Life 300 miles/483 km at average speed of 10 in/s
Switch Life 1,000,000 operations (using Hasco modified tester)
Switch Life 1,000,000 operations (using Hasco modified tester)
Switch Type Micro-switches
Tracking Mechanism Life 155 miles/250 km at average speed of 10 in/s
Cable Length 6 ft/1.8 m
PC98-99 Mechanically compliant
Compliant UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI,
32° to 104° F/0°C to 40° C
–4° to 140° F/–20° to 60°C
400 ± 20% DPI
BSMI, C-Tick
DA-10843 North Americ a — Version 6 — October 1, 2001 18
QuickSpecs
Technical Specifications
Compaq Deskpro Workstation AP230
1.44-MB Diskette Drive
Diskette Size
LED Indicators (front panel)
Read/Write Capacity per
Diskette (high/low density)
Drive Supported
Drive Height
Drive Rotation
Transfer Rate (high/low)
Bytes/Sector
Sectors/Track (high/low)
Tracks/Side (high/low)
Access Times
Cylinders (high/low)
Read/Write Heads
3.5 in
Green
1.44 MB/720 KB
One
One-third
300 rpm
500/250 Kb/s
512
18/9
80/80
Track-to-Track (high/low) 3/6 ms
Average (high/low) 169/94 ms
Settling Time 15 ms
Latency Average 100 ms
80/80
Two
DA-10843 North Americ a — Version 6 — October 1, 2001 19
QuickSpecs
y
y
y
y
Technical Specifications
Compaq Deskpro Workstation AP230
Ultra 160 SCSI Hard Drives
18.2 GB 10K Capacity 18,200 MB
Height 1 in/25.4 mm
Width
Interface
Transfer Rate S
(Maximum)
Seek Time
(typical reads, including
settling)
Rotational Speed 10,000 rpm
Physical Configuration
Operating Temperature
18.2 GB Capacity 18,200 MB
Height 1 in/25.4 mm
Width
Interface
Transfer Rate S
(Maximum)
Seek Time
(typical reads, including
settling)
Rotational Speed 15,0000 rpm
Physical Configuration
Operating Temperature
nchronous
nchronous
3.5 in/88.9 mm
Ultra 160 SCSI
160 MB/s
Single Track 0.6 ms
Average 4.7 ms
Full-Stroke 12 ms
Logical Blocks 35,566,000
50° to 95°F/10° to 35°C
3.5 in/88.9 mm
Ultra 160 SCSI
160 MB/s
Single Track 0.8 ms
Average 4.1 ms
Full-Stroke 7.7 ms
Logical Blocks 35,566,000
50° to 95°F/10° to 35°C
SMART III Ultra ATA/100
Hard Drives
40-GB capacity points include
Quiet Idle technology, which
reduces acoustic levels
approximately 5 decibels, and
ship worldwide.
20-GB 7200rpm drives shipping
in EMEA with Quiet Seek also
have Quiet Idle technology,
which reduces acoustic levels by
approximately 5 decibels
40 GB Capacity 40,000 MB
Height 1 in/25.4 mm
Width
Interface
Transfer Rate S
(Maximum)
Seek Time
(typical reads, including
settling)
Rotational Speed 7200 rpm
Physical Configuration Logical Blocks 78,165,360
Operating Temperature 41° to 131°F/5° to 55°C
20 GB Capacity 20,000 MB
Height 1 in/25.4 mm
Width
Interface
Transfer Rate S
(Maximum)
Seek Time
(typical reads, including
settling)
Rotational Speed 7200 rpm
Physical Configuration Logical Blocks 39,102,336
Operating Temperature 41° to 131°F/5° to 55°C
nchronous
nchronous
3.5 in/88.9 mm
Ultra ATA/100
100 MB/s
Single Track 1.2 ms (2.7 ms quiet seek)
Average 8 ms (10.1 ms quiet seek)
Full-Stroke 18 ms (21.1 ms quiet seek)
3.5 in/88.9 mm
Ultra ATA/100
100 MB/s
Single Track 1.2 ms (2.7 ms quiet seek)
Average 8 ms (10.1 ms quiet seek)
Full-Stroke 18 ms (21.1 ms quiet seek)
DA-10843 North Americ a — Version 6 — October 1, 2001 20
QuickSpecs
Technical Specifications
Compaq Deskpro Workstation AP230
48X CD-ROM Drive
Bus
Data Buffer
Data Transfer Rate Rate
(1 KB = 1,024 bytes)
Disk Rotation Technology
Access Time (ms)
Access Seek Time
Cache Buffer
Standard/Maximum
Interface
Disk Formats Read
Disk Formats Written
Disk
Audio Output Level
Startup Time
Operating Conditions
Dimensions
Approvals/Environmentals
OS support
MPEG playback graphics
solution support
Compaq Products
Supported
Other
16.6 MB/s
Sustained 150 KB/s Minimum (audio)
Variable CD: 3,000 to 7200 KB/s
CAV-Constant Angular Velocity
Random < 100 ms
Full-Stroke Seek < 150 ms
128 KB
ATAPI
Photo-CD/Multi-session, CD-ROM, Multi Read, CD TEXT, Audio CD, CD-I, CD-RW
and CD-R
CD-EXTRA and CD-ROM XA
None
Capacity CD: 650 MB
Block Size Mode 1 – 2,048 bytes
Mode 2 – 2,340, 2,336 bytes
CD-DA – 2,352 bytes
CD-XA – 2,328 bytes
Diameter 12 cm; 8 cm
Thickness 1.2 mm
Track Pitch 1.6 µm
Line-out 0.7 V @ 47 Kohm
Headphone 0.6 V @ 32 ohm
< 7 seconds (typical); < 30 seconds with multi-session
Temperature 41° to 113°F/5° to 45°C
Humidity 10% to 80% relative humidity
(HxWxD, maximum) 1.7 x 5.9 x 8.2 in/42.9 x 150.1 x 208 mm
Weight 2.6 lbs/1200 g
Windows NT 3.51/4.0
Windows 3.51/95/98/2000
OS/2
None
Deskpro 2000, 4000, 6000, and Deskpro EP and EN Series
Operates in horizontal or vertical position
DA-10843 North Americ a — Version 6 — October 1, 2001 21
QuickSpecs
Technical Specifications
Compaq Deskpro Workstation AP230
16X DVD-ROM Drive
Bus
Data Transfer Rate
(1 KB = 1024 bytes)
Disk Rotation Technology
Access Time (ms)
Cache Buffer Standard /
Max
ATAPI Interface
Disk Formats Read
Disk Formats Written
Disk Capacity CD = 650 MB
Audio Output Level
Operating Conditions
Ultra DMA 33
Sustained DVD = 8.1 MB/s to 21.6 MB/s
CD-ROM = 2.55 KB/s to- 6.00 KB/s
DVD: CAV -Constant Angular Velocity
CD: CAV - Constant Angular Velocity
Random DVD = <100 ms; CDROM = < 80 ms
Full Stroke Seek DVD = <240 ms; CDROM = <160 ms
512 KB
ATAPI
DVD-ROM Yes
DVD-Video Yes
DVD-R Yes
DVD-RW Yes
DVD-RAM No
Photo-CD/Multi-session Yes
CD-ROM Yes
CD TEXT Yes
Audio CD Yes
CD-I Yes
CD-RW Yes
CD-R Yes
CD-DA Yes
Video CD Yes
CD EXTRA Yes
CD-ROM XA Yes
MPEG Yes
MPC Level 2 Yes
None
DVD: 4.7 GB, 8.5 GB, 9.4 GB
Block Size Mode 0 2352 (bytes)
Mode 1 2352, 2340, 2336, 2048 (bytes)
Mode 2 2352, 2340, 2336, 2048 (bytes)
DVD – 2048 (bytes)
Diameter 12 cm, 8 cm
Thickness 1.2 mm (CD-ROM)
1.2 mm (DVD)
Track Pitch 1.6 µm (CD-ROM)
0.74 µm (DVD)
Line Out 0.7± 0.1 Vrms
Headphones
Temperature
Humidity 5% to 85% relative humidity
0.45 ± 0.2 Vrms
41° to 113°F/5° to 45°C
DA-10843 North Americ a — Version 6 — October 1, 2001 22
QuickSpecs
Technical Specifications
Compaq Deskpro Workstation AP230
16X DVD-ROM Drive (continued)
Dimensions (HxWxD)
Weight
Agency Approvals /
Environmentals
OS Support
MPEG Video playback
Compatibility
RPC2 (Regional Protection
Control)
Minimum CPU Supported
Mounting Orientation
Kit Contents
1.67 x 5.83 x 8.18 in/4.23 x 14.8 x 20.75 cm
2.22 lbs/1 kg
UL, CSA, TUV, FDA, FCC, CE, EMI
Windows 98/98SE, Windows ME, Windows 2000, and Windows NT 4.0 (for data
applications only)
Please refer to the platform for support
Yes
Pentium II 400 MHz or Celeron 466 MHz
Operates in horizontal or vertical position.
DVD-ROM Drive, MPEG playback software, IDE Cable, audio cable, installation
instructions, and warranty card.
DA-10843 North Americ a — Version 6 — October 1, 2001 23
QuickSpecs
Technical Specifications
Compaq Deskpro Workstation AP230
8X CD-RW Drive
Interface
Media formats read CD-RW CD-RW High-Speed
CD-ROM Yes Yes
CD-R Yes Yes
CD-Digital Audio Yes Yes
CD-Extra Yes Yes
CD-ROM XA Yes Yes
CD-I Yes Yes
Audio CD Yes Yes
Video CD Yes Yes
Photo CD Yes Yes
Multi Read Yes Yes
Multi-session Yes Yes
CD-Text Yes Yes
Media formats written
Media Capacity
Data Transfer Rates Read
Access Times
Disk Diameter
Disk loading mechanism
Operating Conditions
Dimensions
Mounting
Weight
Approvals/Environmental
Operating Systems Supported
Kit Contents
ATAPI EIDE
32X Max CD-R and 8X Max CD-RW Disc at once, Track at once, Fixed
650 MB
Sustained CD-R Write: 1,200 Kb/s (8X)
Variable
Random 120 ms (typical)
Full Stroke Seek 200 ms (typical)
12 cm, 8 cm (read only)
Tray
Temperature 5° to 45°C
Relative Humidity 10% to 80%
Fits in a Standard 5.25 inch Drive
Bay
Horizontal or Vertical
2.4 lbs
FCC Yes
UL Yes
CSA Yes
CE Yes
FDA Yes
EN6O 950 Yes
Windows 98/98SE and Windows NT 4.0
CD-RW Drive, IDE Cable, High-Speed CD-R Media, CD-RW Media, Roxio
Software (Easy CD Creator and Direct CD), Install Guide, Warranty Card
packet, Variable packet
CD-RW Write: 600 Kb/s (4X)
CD-RW Read: 1,200 Kb/s (8X)
CD-ROM and CD-R Read: up to 4,800
Kb/s (32X)
DA-10843 North Americ a — Version 6 — October 1, 2001 24
QuickSpecs
@
Technical Specifications
Compaq Deskpro Workstation AP230
Integrated Intel Audio with
Premier Internal Speakers
Card Type
Plug and Play
Stereo Codec
OPL3 FM Synthesis
Compatibility
Ports
Sampling
Compression
OS support
Wavetable Syntheses (software)
3D Positional Sound
Analog Audio
Number of Channels (mono/stereo)
Internal Audio Power Amp Rating
Number of Fixed Equalization Stages
Speaker (Internal)
PCI
Yes
Yes
128 WaveTable Synthesizer
Sound Blaster
Sound Blaster Pro
Full DOS Game Compatibility
Microphone in (10 Kohm)
Line-in (10 Kohm)
Line-out/Headphone-out (33 ohm)
(Note: Line out cannot drive external passive speakers.)
MIDI (playback only)
CD In
TAD
TV Tuner
48 KHz
ADPCM, CCITT A-law, CCITT u-law
Windows NT 4.0
Windows 95
Windows 98
DOS
Yes
Yes
Premier•Sound
Mono
Nominal: 1.5 Watts RMS
Maximum: 5 Watts RMS @ 8 ohms
6
1.57 x 2.76 in/40 mm x 70 mm
8 ohms
DA-10843 North Americ a — Version 6 — October 1, 2001 25
QuickSpecs
Technical Specifications
Compaq Deskpro Workstation AP230
Integrated Intel PRO/100 VM
Network Connection
Connectors RJ-45
Expansion Bus Architecture PCI 2.2
Network Transfer Rate 10Base-T (Half-Duplex) 10 Mb/s
10Base-T (Full-Duplex) 20 Mb/s
100Base-TX (Half-Duplex) 100 Mb/s
100Base-TX (Full-Duplex) 200 Mb/s
Standards Compliance IEEE VLAN Support (802.1A)
IEEE 802.2
IEEE 802.3 & IEEE 802.3u
(100-Mb/s Ethernet)
IEEE Intel Priority Packet (801.1p)
OS Driver Support Microsoft Windows NT 3.51 and 4.0
Microsoft Windows 95, 98 and
2000 Beta Novell Netware 3.11,
3.12 & 4.1x,
5 Server Sun Solaris
SCO UnixWare
OpenDesktop
OpenServer
Remote Wakeup Yes, (PME# and WAKE signals) - no cable required on 810 or
820 chipset platforms
Proactive Alert Technology
Boot PROM support Yes, Intel PRO/100 Boot Agent (PXE 2.0, RPL)
Yes, alert on LAN (transmit functionality only) requires
management console software, such as HP OpenView. It also
requires alert utilities for the management console, proxy client
software, and client configuration software.
F12 BIOS Support Yes
Environmental Requirements
Operating Temperature 32° to 131° F/0° C to 55° C
Humidity (non-condensing) 85% at 131° F/55° C
Altitude
Non-Operating Temperature –40° to 158° F/–40° to 70° C
Humidity (non-condensing)
Altitude
DA-10843 North Americ a — Version 6 — October 1, 2001 26
10,000 ft/3,048 m
5,000 ft/15,240 m
QuickSpecs
Technical Specifications
Compaq Deskpro Workstation AP230
Matrox Millennium G450
DualHead Graphics
Controller
Form Factor ATX
Bus Type AGP 1X, 2X, 4X
Standard Memory AGP: 32 MB
DAC Speed 360 MHz (secondary DAC: 200 MHz)
Data Path Ext e rn al 64-bit DDR
Internal 256-bit
Internal Bus Width 256-bit DualBus
Memory Interface 64-bit DDR Memory
Frame Buffer AGP : 32 MB
Two Integrated RAMDACS Yes
Color Space Conversion Yes
Scaling Yes
Quick Draw Support Yes
DCI & DirectX Video Playback Yes
MS DirectDraw Support Yes
3D Support Yes
Engine Acceleration 3 ROP bitBLT
Line Draw
Text
Color Expansion
Basic Video Color Conversion and Scaling
Triangle Setup Engine
Output Analog, 2 ports
OS Support Windows 2000/Windows NT 4.0, Win do ws 98, Linux, OS /2 Wa rp , a nd th e
upcoming Windows Millennium Edition
Other Texture mapping support
Flat and Gouraud shading
Direct 3D support
Anisotropic Filter
Perspectiv e t ex t u re
Specular highlighting
Wireframe
Dithering
Full-scene anti-aliasing
OpenGL support
Vertex fog
Dual Texture Mapping
Environment-Mapped Bump Mapping
Plug-and-Play AGP 2X and AGP 4X0.18-micron technology (lower heat/power
consumption)
High-quality DVD playback with full access to Windows
DA-10843 North Americ a — Version 6 — October 1, 2001 27
QuickSpecs
Technical Specifications
Compaq Deskpro Workstation AP230
Matrox Millennium G450
DualHead Graphics
Controller (continued)
3D Features Single-cycle multi-texturing Yes
Environment-Mapped Bump Mapping Yes
Internal Rendering 32-bit
Source Textures Up to 32-bit
Maximum Texture Size 2048 x 2048
Hardware non-power-of- 2 textures Yes
32-bit Color Output Yes
32-bit Independent Z-buffer Yes
Stencil Buffering Yes
AGP Texturing Yes
Trilinear Filtering Yes
DirectX Support Yes
OpenGL Support Yes
DualHead Display
Features
Supported Modes
Multi-Display Mode Yes
DVD Max Mode Yes
DualHead Zoom Mode Yes
DualHead Clone Mode Yes
DualHead TV Output Mode Yes
Single Chip Multi-Monitor Support Yes
This list assumes setup to be DualHead multi-display running Microsoft Windows 98. If
using Windows NT 4.0 or Windows 2000 while in multi-display, primary CRT is limited to
modes suppo rt e d by second CRT.
Primary CRT Color
Depths
640 x 480 8, 16, 24, 32 60 Hz, 72 Hz, 75 Hz , 8 5 Hz
800 x 600 8, 16, 24, 32 60 Hz, 72 Hz, 75 Hz , 8 5 Hz
1024 x 768 8, 16, 24, 32 60 Hz, 70 Hz, 75 Hz, 85 Hz
1152 x 864 8, 16, 24, 32 75 Hz
1280 x 960 8, 16, 24, 32 60 Hz, 75 Hz, 85 Hz
1280 x 1024 8, 16, 24, 32 60 Hz, 75 Hz, 85 Hz
1600 x 1200 8, 16, 24, 32 60 Hz, 65 Hz, 70 Hz, 75 Hz, 85 Hz
1800 x 1440 8, 16, 24, 60 Hz, 72 Hz, 75 Hz, 85 Hz
1856 x 1392 8, 16, 24 60 Hz, 75 Hz, 85 Hz
1920 x 1440 8, 16, 24 60 Hz, 75 Hz, 85 Hz
2048 x 768 8, 16 60 Hz, 75 Hz
Secondary CRT Color
Depths
640 x 480 16,32 60 Hz, 72 Hz, 75 Hz, 85 Hz
800 X 600 16,32 60 Hz, 72 Hz, 75 Hz, 85 Hz
1024 x 768 16,32 60 Hz, 72 Hz, 75 Hz, 85 Hz
1152 x 864 16,32 75 Hz
1280 x 960 16,32 60 Hz, 72 Hz, 75 Hz, 85 Hz
1280 x1024 16,32 60 Hz, 72 Hz, 75 Hz, 85 Hz
1600 x 1200 16,32 60 Hz, 65 Hz, 70 Hz, 75 Hz, 85 Hz
Color Depths (bpp) Refresh Rates
Color Depths (bpp) Refresh Rates
DA-10843 North Americ a — Version 6 — October 1, 2001 28
QuickSpecs
Technical Specifications
Compaq Deskpro Workstation AP230
ELSA Synergy II Graphics
Controller
Dimensions (HxW) 3.25 x 6.25 in/8.3 x 15.9 cm
Resolution Maximum Colors
Supported
640 x 480 16.7M 120 Hz 29.1 MB
800 x 600 16.7M 120 Hz 27.1 MB
1024 x 768 16.7M 120 Hz 23.5 MB
1152 x 864 16.7M 120 Hz 21.1 MB
1280 x 1024 16.7M 120 Hz 17.9 MB
1600 x 1000 16.7M 75 Hz 14 MB
1600 x 1000 65K 85 Hz 14 MB
1600 x 1200 16.7M 75 Hz 10.2 MB
1600 x 1200 65K 85 Hz 10.2 MB
1600 x 1280 16.7M 75 Hz 8.7 MB
1600 x 1280 65K 85 Hz 8.7 MB
1920 x 1080 16.7M 75 Hz 8.4 MB
1920 x 1080 65K 85 Hz 8.4 MB
1920 x 1200 16.7M 75 Hz 5.7 MB
1920 x 1200 65K 75 Hz 5.7 MB
3D/2D Controller Nvidia TNT 2
VGA Controller Integrated
Bus Type AGP 2X/4X
RAMDAC
Memory Type SDRAM
Memory Amount 32 MB (Maximum)
Memory Speed 143 MHz
Controller Clock Speed 125 MHz
Color Planes 24 bits double buffered
Stencil Planes 8 bit
Alpha Planes 0
Z-buffer 24 bit
Total bits/pixel 96
Maximum Vertical Refresh Rate 120 Hz
Maximum Pixel Clock 300 MHz
Multi-display Support No
Operating Systems Windows 2000, Windows NT 4.0, Windows 98
Note: All drivers and enhanced software, including POWERdraft, ELSAview, and MAXtreme, can be found on the
Compaq Web site at: www.compaq.com/support/files/workstations/us/index.html.
Integrated 300 MHz
Maximum Refresh
Rate
Memory Dedicated to
Texture Support
DA-10843 North Americ a — Version 6 — October 1, 2001 29
QuickSpecs
Technical Specifications
Compaq Deskpro Workstation AP230
NVIDIA Quadro2 MXR Graphics
Controller
Dimensions (LxHxW)
Resolution
640 x 480 16.7 M 240 Hz 28.4 MB
800 x 600 16.7 M 240 Hz 26.4 MB
1024 x 768 16.7 M 200 Hz 22.8 MB
1152 x 864 16.7 M 170 Hz 20.3 MB
1280 x 1024 16.7 M 150 Hz 16.6 MB
1600 x 1000 64 K 120 Hz 22.6 MB
1600 x 1000 16.7 M 120 Hz 13.3 MB
1600 x 1200 64 K 100 Hz 20.8 MB
1600 x 1200 16.7 M 100 Hz 9.5 MB
1600 x 1280 64 K 100 Hz 20 MB
1600 x 1280 16.7 M 100 Hz 8 MB
1920 x 1080 64 K 85 Hz 19.9 MB
1920 x 1080 16.7 M 85 Hz 7.7 MB
1920 x 1200 64 K 85 Hz 18.5 MB
1920 x 1200 16.7 M 85 Hz 5 MB
3D/2D Controller
VGA Controller Integrated into the Quadro2 MXR GPU
Bus Type
RAMDAC
Memory Type
Memory Amount
Memory Speed
Controller Clock Speed
Color Planes
Overlay Planes
Stencil Planes
Alpha Planes
Z-buffer
Total bits/pixel
Maximum Vertical Refresh Rate
Maximum Pixel Clock
Multi-display support
Operating Systems
Note: All drivers and enhanced software, including ELSA POWERdraft, ELSA MAXtreme, and NVIDIA QuadroView,
can be found on the Compaq web site at: www.compaq.com/support/files/workstations/us/index.html.
Approximately 6.5 x 3.8 x 0.6 in/16.51 x 9.65 x 1.52 cm
Maximum Colors
Supported
Integrated Quadro2 MXR 2D/3D 128-bit graphics processor unit (GPU)
AGP 2X, 4X Graphics Bus
350 MHz
183 MHz SDR 2Mx32
32 MB
183 MHz
200 MHz
32-bit color buffer
1 16-bit Video overlay plane, software emulation for OpenGL overlay planes
8-bit stencil buffer
8-bit alpha buffer
24-bit Z buffer
64-bits
240 Hz
350 MHz
Yes
®
Microsoft
Windows® 2000, Windows NT 4.0 available from Compaq
Maximum Refresh Rate
Memory Dedicated to
Texture Support
DA-10843 North Americ a — Version 6 — October 1, 2001 30
QuickSpecs
Technical Specifications
Compaq Deskpro Workstation AP230
NVIDIA Quadro2 EX Graphics
Controller
Resolution Maximum Colors
Supported
640 x 480 16.7 M 240 Hz 28.4 MB
800 x 600 16.7 M 240 Hz 26.4 MB
1024 x 768 16.7 M 200 Hz 22.8 MB
1152 x 864 16.7 M 170 Hz 20.3 MB
1280 x 1024 16.7 M 150 Hz 16.6 MB
1600 x 1000 64 K 120 Hz 22.6 MB
1600 x 1000 16.7 M 120 Hz 13.3 MB
1600 x 1200 64 K 100 Hz 20.8 MB
1600 x 1200 16.7 M 100 Hz 9.5 MB
1600 x 1280 64 K 100 Hz 20 MB
1600 x 1280 16.7 M 100 Hz 8 MB
1920 x 1080 64 K 85 Hz 19.9 MB
1920 x 1080 16.7 M 85 Hz 7.7 MB
1920 x 1200 64 K 85 Hz 18.5 MB
1920 x 1200 16.7 M 85 Hz 5 MB
Dimensions (LxHxW) Approximately 6.5 x 3.8 x 0.6 in/16.51 x 9.65 x 1.52 cm
3D/2D Controller Integrated Quadro2 EX 2D/3D 128-bit graphics processor unit (GPU)
VGA Controller Integrated into the Quadro2 EX GPU
Bus Type AGP 2X, 4X Graphics Bus
RAMDAC 350 MHz
Memory Type 183 MHz SDR 2Mx32
Memory Amount 32 MB
Memory Speed 183 MHz
Controller Clock Speed 200 MHz
Color Planes 32-bit color buffer
Overlay Planes 1 16-bit Video overlay plane, software emulation for OpenGL overlay planes
Stencil Planes 8-bit stencil buffer
Alpha Planes 8-bit alpha buffer
Z-buffer 24-bit Z buffer
Total bits/pixel 64-bits
Maximum Vertical Refresh Rate 240 Hz
Maximum Pixel Clock 350 MHz
Multi-display support No
Operating Systems Microsoft® Windows® 2000, Windows NT 4.0 available from Compaq
Note: All drivers and enhanced software, including ELSA POWERdraft, , can be found on the Compaq web site at:
www.compaq.com/support/files/workstations/us/index.html.
Maximum Refresh Rate Memory Dedicated to
Texture Support
Compaq PCs use genuine Microsoft Windows
www.microsoft.com/piracy/howtotell
Compaq, Deskpro, registered United States Patent and Trademark Office.
Intel, the Intel Inside Logo, and Pentium are registered trademarks of Intel Corporation.
Microsoft, MS, Windows and Windows NT are registered trademarks of the Microsoft Corporation in the U.S. and
other countries.
Other product names mentioned herein may be trademarks and/or registered trademarks of their respective
companies.
©
2001 Compaq Computer Corporation.
DA-10843 North Americ a — Version 6 — October 1, 2001 31
Loading...
