QuickSpecs
Overview
HP Compaq 6720t Mobile Thin Client
1.
Volume Mute Button with LED
2.
Volume Down Button
3.
Volume Up Button
4.
Stereo Speakers
5.
Integrated Optical Drive (optional)
6.
2 USB 2.0 Ports
7.
Microphone Jack
8.
Headphone Jack
9.
Right Touchpad Button
10.
Left Touchpad Button
11.
Internal Storage Activity LED
12.
Battery Charging LED
13.
Power/Standby LED
14.
Wireless On/Off LED
15.
Touchpad with scroll zone
16.
Power Button with LED
17.
Wireless On/Off Button with LED
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 1
QuickSpecs
Overview
1.
Kensington Lock Slot
2.
RJ-45 Port (NIC)
3.
RJ-11 Port (Modem)
4.
USB 2.0 Port
HP Compaq 6720t Mobile Thin Client
5.
PC Card Slot
6.
PC Card Eject Button
7.
VGA/External Monitor Port
8.
Power Connector
At A Glance
Genuine Windows XP Embedded
Sleek light-weight design starting at 5.4 lb (2.45 kg) and 1.2 inch (30 mm) thin at front
15.4-inch wide screen display
Intel® Celeron® M processor
Mobile Intel 945GM Express Chipset
1GB of 667 MHz DDR2 SDRAM
Intel Graphics Media Accelerator 950
1 GB Flash Module
Optional DVD-ROM Drive
802.11 a/b/g wireless LAN module
Protected by a one-year standard parts and labor warranty – certain restrictions and exclusions apply.
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 2
QuickSpecs
Standard Features
HP Compaq 6720t Mobile Thin Client
Processors
Operating System
Chipset
Graphics
Display
Intel Celeron M Processor 423* (1.06-GHz, 1-MB L2 cache, 533-MHz FSB)
* Intel's numbering is not a measurement of higher performance.
NOTE:
battery optimization mode.
Preinstalled
Mobile Intel 945GM Express Chipset
Intel Graphics Media Accelerator 950 with up to 224-MB shared system memory
Microsoft DirectX 9 capable
Internal
External
Processor speed denotes maximum performance mode; processors will run at lower speeds in
Genuine Windows XP Embedded
15.4-inch WXGA display with 1280 x 800 resolution
Up to 32-bit per pixel color depth
VGA
port supports resolutions up to 2048 x 1536 at 75 Hz, and
lower resolutions at up to 100 Hz
NOTE:
and color depth settings.
Resolutions are dependent upon monitor capability, and resolution
Memory
Communications
Standard
Maximum
NOTE:
branded memory to ensure compatibility.
Integrated Broadcom 10/100 Ethernet PCI Controller
56K V.92 modem* with digital line guard
* Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability
is subject to country regulatory approval.
Due to the non-industry standard nature of some third-party memory modules, we recommend HP
1024-MB 667-MHz DDR2 SDRAM SODIMM; one SODIMM slot
Supports up to 2048-MB maximum
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 3
QuickSpecs
Standard Features
HP Compaq 6720t Mobile Thin Client
Integrated wireless LAN
Keyboard
One-Touch Productivity
Buttons
Broadcom 4311AG WiFi
Adapter
The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop
keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right
control and alt keys, and 12 function keys. US and International key layouts are available. Other features
include an integrated numeric keypad, hotkeys for instant access to power conservation, brightness, and
other features, 19-mm x 19-mm key pitch (center-to-center spacing), 2.5-mm stroke, comfort-dished
keycaps, and bright key legends for improved visibility in low light conditions.
Provide one-touch access to the following features: Wireless On/Off, Volume down, Volume up, and
Volume Mute.
Integrated support for 802.11 a, b and g
Up to 54-mbps data rate
Wi-Fi certified for WPA2, WMM
Cisco Compatible Extensions support (Version 4.0)
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support s
Dual antennas integrated in the display enclosure
Pointing Device
Expansion Card Slots
Internal Storage
Touchpad with scroll zone and two soft-touch buttons
One Type I/II PC Card
slot
Primary Storage
Optional Fixed Optical
Drive
Supports 32-bit CardBus and 16-bit PC Cards
1 GB Flash Module
DVD-ROM
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 4
QuickSpecs
Standard Features
HP Compaq 6720t Mobile Thin Client
Interfaces
Audio
PC Card Slot
External Monitor
External Microphone
Headphone/Line out
Power Connector
RJ-11
(Modem)
RJ-45
(NIC)
USB 2.0
Docking Connector
Accessory Battery
Connector
LED Status Indicators
ADI1981HD High Definition CODEC
Integrated 16-bit Sound Blaster Pro compatible audio
24-bit DAC
Integrated stereo speakers
External volume up, volume down, and mute buttons
Stereo headphone/line out
Stereo microphone in
One – Type I/II
One – VGA
One
One
One
One
One
Three
One
One
Nine
Software
SMBIOS Version 2.4
Preinstalled Software
Additional software
available from the Web
System Management BIOS, previously known as DMI BIOS, is used to store system management
information.
Enhanced Write Filter
Altiris Deployment Client
HP ThinState Tools
HP Session Allocation Manager
Microsoft RDP
Citrix ICA
HP Quick Launch Buttons
TeemNT Terminal Emulation
PDF Complete
Intervideo WinDVD
HP RGS Graphics Compression Client
HP OpenView Client Configuration Manager
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 5
QuickSpecs
Standard Features
HP Compaq 6720t Mobile Thin Client
Security
Power Supply
*Fast Charge Technology recharges your battery up to 90% within 90 minutes when the system is off. Fast Charge Technology does
not apply to 12-cell Ultra-Capacity batteries.
Battery
Standard Features
External 65-watt Smart AC adapter, 6-foot (1.8-meter) power cord included.
Total length including External AC adapter is 12 feet (3.66 meter).
HP Fast Charge Technology*
Primary Battery
Optional 8-Cell Extended
Life Battery
Optional HP 12-Cell Ultra-
Capacity Battery
Configuration Control Hardware
Memory Change Alert
Ownership Tag
Setup Password
Power-On Password
Kensington Lock Slot
6-cell (47Wh) high capacity Lithium-Ion
8-cell (52Wh) high capacity Lithium-Ion
12-cell (95Wh) high capacity Lithium-Ion
Battery Life
System Standby Time
Power Conservation
Primary Battery
Primary Battery and
optional HP 8-Cell
Extended Life Battery
Primary Battery and
optional HP 12-Cell UltraCapacity Battery
NOTE:
Professional. Battery life will vary depending on the product configuration, product model, applications
loaded on the product, power management settings of the product, and the product features used by the
customer. As with all batteries, the maximum capacity of this battery will decrease with time and usage.
Up to 1 week
Standby
ACPI compliance
The listed battery life measurements were taken on models running Microsoft Windows XP
Up to 5 hours
Up to 10 hours and 45 minutes
Up to 14 hours and 30 minutes
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 6
QuickSpecs
Standard Features
HP Compaq 6720t Mobile Thin Client
Docking
Service and Support
Select Model(s)
6720t
KL145AA#ABA (English)
KL145AA#ABC (Fr CAN)
Regional
HP Docking Station
HP's shared docking solution provides simple and convenient port replication and cable management.
Supported features include 10/100 Ethernet NIC pass through, modem pass through, legacy parallel
and serial ports, USB 2.0 ports, and integrated security mechanism.* This docking solution is compatible
across multiple Business Notebook platforms enabling a lower total cost of ownership.
*HP/Kensington Cable Lock required (purchased separately)
HP Services includes a one-year standard parts and labor warranty, pick-up or carry-in, and toll-free 7 x
24 hardware technical phone support (depending on model). On-site service and warranty upgrades are
also available.
NOTE:
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp
Processor
Operating System
System Memory
Internal Storage
Display
Graphics
Audio
Communications
Integrated Wireless
Pointing Device
Optical Drive
Battery
Power
Warranty
* Intel's numbering system is not a measurement of higher performance.
Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
.
Intel Celeron M Processor 423 (1.06 GHz)
Genuine Windows XP Embedded
1024MB 667MHz DDR2 SDRAM (1 DIMM)
1 GB Flash Module
15.4-inch diagonal WXGA anti-glare
Intel GMA 950, up to 224MB shared system memory
ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Integrated Broadcom 10/100 Ethernet Controller
56K V.92 modem
Broadcom 4311AG 802.11a/b/g
Touchpad with scroll zone
none
6-cell (43 WHr) Lithium-Ion
External 65W adapter
1/1/0
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 7
QuickSpecs
Standard Features
HP Compaq 6720t Mobile Thin Client
6720t
KL145AT#ABA (English)
KL145AT#ABC (Fr CAN)
Smart Buy
Processor
Operating System
System Memory
Internal Storage
Display
Graphics
Audio
Communications
Integrated Wireless
Pointing Device
Optical Drive
Battery
Power
Warranty
* Intel's numbering system is not a measurement of higher performance.
Intel Celeron M Processor 423 (1.06 GHz)
Genuine Windows XP Embedded
1024MB 667MHz DDR2 SDRAM (1 DIMM)
1 GB Flash Module
15.4-inch diagonal WXGA anti-glare
Intel GMA 950, up to 224MB shared system memory
ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Integrated Broadcom 10/100 Ethernet Controller
56K V.92 modem
Broadcom 4311AG 802.11a/b/g
Touchpad with scroll zone
none
6-cell (43 WHr) Lithium-Ion
External 65W adapter
1/1/0
6720t
KL147AA#ABA (English)
KL147AA#ABC (Fr CAN)
Regional
Processor
Operating System
System Memory
Internal Storage
Display
Graphics
Audio
Communications
Integrated Wireless
Pointing Device
Optical Drive
Battery
Power
Warranty
* Intel's numbering system is not a measurement of higher performance.
Intel Celeron M Processor 423 (1.06 GHz)
Genuine Windows XP Embedded
1024MB 667MHz DDR2 SDRAM (1 DIMM)
1 GB Flash Module
15.4-inch diagonal WXGA anti-glare
Intel GMA 950, up to 224MB shared system memory
ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Integrated Broadcom 10/100 Ethernet Controller
56K V.92 modem
Broadcom 4311AG 802.11a/b/g
Touchpad with scroll zone
8x DVD
6-cell (43 WHr) Lithium-Ion
External 65W adapter
1/1/0
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 8
QuickSpecs
Standard Features
HP Compaq 6720t Mobile Thin Client
6720t
KL147AT#ABA (English)
KL147AT#ABC (Fr CAN)
Smart Buy
Processor
Operating System
System Memory
Internal Storage
Display
Graphics
Audio
Communications
Integrated Wireless
Pointing Device
Optical Drive
Battery
Power
Warranty
* Intel's numbering system is not a measurement of higher performance.
Intel Celeron M Processor 423 (1.06 GHz)
Genuine Windows XP Embedded
1024MB 667MHz DDR2 SDRAM (1 DIMM)
1 GB Flash Module
15.4-inch diagonal WXGA anti-glare
Intel GMA 950, up to 224MB shared system memory
ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Integrated Broadcom 10/100 Ethernet Controller
56K V.92 modem
Broadcom 4311AG 802.11a/b/g
Touchpad with scroll zone
8x DVD
6-cell (43 WHr) Lithium-Ion
External 65W adapter
1/1/0
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 9
QuickSpecs
Options
HP Compaq 6720t Mobile Thin Client
Memory
Other Storage
Expansion Solutions
Power
1-GB 667-MHz DDR2 SDRAM
2-GB 667-MHz DDR2 SDRAM
HP USB Diskette Drive
HP Docking Station
HP Monitor Stand
HP Adjustable Notebook Stand
HP 1-bay Battery Charging Station
HP 5-bay Battery Charging Station
Battery Adapter Kit
65W Smart AC Adapter
90W Smart AC Adapter
90W Smart Auto Adapter
65W Air/Auto/AC Smart Combo Adapter
6-cell 47Whr Li Ion Battery
HP 8-cell Extended Life Battery
HP 12-cell Ultra-Capacity Battery
EM994AA
EM995AA
DC361B
EN488AA#ABA
PA507A
PA508A
RW635AA#ABA
RW636AA#ABA
RW637AA
ED494AA#ABA
ED495AA#ABA
ED493AA
ED993AA#ABA
TBD
PB993A
EJ092AA
Carrying Cases
Security
Input/Output Devices
HP Basic Carrying Case
HP Value Nylon Case
HP Universal Nylon Case
HP Executive Leather Case
HP Deluxe Nylon Backpack
HP Deluxe Roller Case
HP/Kensington MicroSaver Security Lock
USB/PS2 Optical Mouse
HP USB Optical Travel Mouse
AJ078AA
RR314AA
RR315AA
RR316AA
RR317AA
GD405AA
PC766A
DC369A
RH304AA
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 10
QuickSpecs
Memory
Supports up to 2048 MB* of 667-MHz DDR2 SDRAM
One DIMM slots
DIMM sizes supported: 1024 MB and 2048 MB
Standard Memory
1024 MB (1024 MB x 1)
HP Compaq 6720t Mobile Thin Client
Optional Memory Upgrades
NOTE:
memory modules to ensure compatibility.
Memory Upgrades
Due to the non-industry standard nature of some third-party memory modules, we strongly recommend using only HP branded
Support for up to 2048 MB* of memory is available (with the installation of optional DDR2 SDRAM
memory kit). Memory slot is user accessible. Please refer to the Hardware and Software Guide for
installation procedures.
Up to
2048 MB 2048 MB
2-GB 667-MHz DDR2 SDRAM
Slot 1
EM995AA
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 11
QuickSpecs
Storage
Removable Media Drive Support
HP Compaq 6720t Mobile Thin Client
DVD-ROM Drive
Quantity Supported
One
Internal Storage Support
Primary Hard Drives
1 GB Flash Module
Quantity Supported
One
Drive Bay
Fixed optical drive bay
Drive Bay
Flash Drive Bay
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 12
QuickSpecs
Technical Specifications
HP Compaq 6720t Mobile Thin Client
System Unit
Dimensions
Weight
NOTE:
includes 6-cell battery, 1 GB memory, 1 GB flash module, 802.11 wireless communications module.
Weight varies by configuration and components.
Stand-Alone Power
Requirements
Temperature
Relative Humidity
Shock
Random Vibration
Altitude
(unpressurized)
Industry Standard
Certifications
(HxWxD)
Height varies depending upon where on the notebook the measurement is made. Weight
1.2 in (at front) x 14.1 in x 10.2 in
30 mm (at front) x 357 mm x 260 mm
5.4 lb (2.45 kg)
Normal Operating Voltage
Average Operating Power
Max Operating Power
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
UL
CSA
FCC Compliance
ICES
Australia / NZ A-Tick
Compliance
CCC
Japan VCCI Compliance
MIC
BSMI
19 V
25 W
< 65 W
32° to 95° F (0° to 35° C)
-4° to 140° F (-20° to 60° C)
10% to 90%, non-condensing
5% to 95%, 101.6° F (38.7° C) maximum wet
bulb temperature
125 G, 2 ms, half-sine
200 G, 2 ms, half-sine
0.75 grms
1.50 grms
-50 to 10,000 ft (-15.24 to 3,048 m)
-50 to 40,000 ft (-15.24 to 12,192 m)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 13
QuickSpecs
Technical Specifications
HP Compaq 6720t Mobile Thin Client
HP 65W Smart AC
Adapter
Dimensions
Weight
Input
Output
Connector
Environmental Design
EMI and Safety
Certifications
Option Kit Contents
4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)
0.62 lb (280 g)
100 to 240 VAC
Input Efficiency
Input frequency range
Input AC current
Output power 65W
DC output
Hold-up time
Output current limit
3 pin/grounded, mates with interchangeable cords
Operating temperature
Non-operating (storage)
temperature
Altitude
Humidity
Storage Humidity
CE Mark – full compliance with LVD and EMC directives; Worldwide safety
standards – IEC60950, EN60950, UL60950, Class1, SELV; Agency
approvals – C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class
B, CISPR22 Class B, CCC, NOM-1 NYCE; MTBF – over 200,000 hours at
25°C ambient condition.
65W AC Adapter, power cable, warranty booklet
83% min at 115 VAC
47 to 63 Hz
1.7 A at 90 VAC, 0.85 A at 180 VAC
65W
18.5V
5 msec at 115 VAC input
<11A, Over voltage protection- 29V max
automatic shutdown
32° to 104° F (0° to 40° C)
-4° to 149° F (-20° to 65° C)
0 to 10,000 ft (0 to 3,048 m)
20% to 80%
10% to 90%
47Wh Primary 6-Cell
Battery
Dimensions
Weight
Cells/Type
Energy
Temperature
Battery Re-Charge Time
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
(H x W x L)
0.8 x 1.9 x 10.6 in (2.0 x 4.8 x 27.0 cm)
0.74 lb (0.336 kg)
6-cell Lithium-Ion
Watt-hour Capacity
Operating (Charging)
Operating (Discharging)
Non-operating
System in OFF mode or
Standby
System ON
HP Fast Charge
Technology
47Wh
32° to 113° F (0° to 45° C)
14° to 140° F (–10° to 60° C)
–4° to 140° F (–20° to 60° C)
2.5 hours
3 to 5 hours (depending on system power
consumption)
Charges the battery up to 90% within 1.5 hours
when system is OFF
Page 14
QuickSpecs
Technical Specifications
HP Compaq 6720t Mobile Thin Client
Optional HP 8-Cell
Extended Life Battery
Optional HP 12-Cell UltraCapacity Battery
Dimensions
Weight
Cells/Type
Energy
Temperature
Battery Re-Charge Time
Fuel Gauge
Dimensions
Weight
Cells/Type
Energy
Temperature
Battery Re-Charge Time
Fuel Gauge
(H x W x L)
(H x W x L)
1.0 x 3.9 x 8.7 in (2.5 x 10.0 x 22.0 cm)
1.00 lb (0.455 kg)
8-cell Lithium-Ion
Watt-hour Capacity
Operating (Charging)
Operating (Discharging)
Non-operating
System in OFF mode or
Standby
System ON
HP Fast Charge
Technology
When pressed, LEDs light indicating level of charge remaining on battery
1.3 x 6.0 x 10.6 in (3.33 x 15.25 x 26.88 cm)
1.77 lb (0.803 kg)
12-cell Lithium-Ion
Watt-hour Capacity
Operating (Charging)
Operating (Discharging)
Non-operating
System in OFF mode or
Standby
System ON
When pressed, LEDs light indicating level of charge remaining on battery
52Wh
32° to 113° F (0° to 45° C)
14° to 140° F (–10° to 60° C)
–4° to 140° F (–20° to 60° C)
3 hours
3 to 5 hours (depending on system power
consumption)
Charges the battery up to 90% within 90 minutes
when system is OFF
95Wh
32° to 113° F (0° to 45° C)
14° to 140° F (–10° to 60° C)
–4° to 140° F (–20° to 60° C)
3 to 4 hours
4 to 5 hours (depending on system power
consumption)
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 15
QuickSpecs
Technical Specifications
HP Compaq 6720t Mobile Thin Client
15.4-inch Color TFT
WXGA Display
Internal Storage
1 GB Flash Module Drive
(PATA)
Active Area (W x H)
Diagonal Size
Surface Treatment
Contrast Ratio
Refresh Rate
Brightness
Pixel Resolution
Backlight
PPI
Viewing Angle
Interface
Connector
Capacities
Transfer mode
Sustained Read/Write
Performance
ECC Support
Low Power Consumption
(3.3V/5.0V)
Security function
Product types
Orientation
13.0 x 8.1 in (33.1 x 20.7 cm)
15.4 in (39.1 cm)
Anti-glare
300:1 (typical)
60 Hz
170 nit (typical)
Pitch
Format
Configuration
CCFL
98
±45° Horizontal, ±25° Vertical (typical)
Standard ATA / IDE
40-pin (2.54mm pitch) / 44-pin (2.00mm pitch)
64MB~8GB
PIO Mode-4; MWDMA Mode-2
11 / 7 (MB/sec)
3 random 12 bit symbol ECC per 512 bytes (RS)
Active mode: 35mA/55mA
Sleep mode: 100µA/150µA
Write protection jumper (Optional)
Factory-programmed, up to 20-byte unique ID (Software Protect mechanism)
Protection Zone (Optional)
Standard, Low-profile, Housing, Through Pin, Dual Through Pin
90D, 180D, 270D
0.259 mm
1280 x 800
RGB stripe
Removable Storage Drives – Fixed Bay
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 16
QuickSpecs
Technical Specifications
HP Compaq 6720t Mobile Thin Client
DVD-ROM Drive
PremierSound Audio
Hardware
Access Times
Max Data Transfer Rate
Transfer Mode
Interface
Supported Media
Supported Media
Max Media Capacity
(read)
Transport
Implementation
Volume Controls
Full Duplex
Sound Blaster Pro
compatible
Microphone Jack
Headphone/Line Out Jack
(read)
(write)
Random
24X CD-ROM
8X-DVD
Multiword DMA Mode 2
EIDE
CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED
MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (PhotoCD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5,
DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW
None
4.7 GB
Tray Loading
ADI1981HD High Definition CODEC
Up, down, and mute buttons
Yes
Yes
Stereo or mono
Stereo
<116 ms CD
<125 ms DVD
3,600 KB/s
10,800 KB/s
Audio Output Quality
Internal Speakers
Communications
Frequency Response
Signal to Noise Ratio
Total Harmonic Distortion
Noise Floor
Play/Record Sampling
Rate
(s)
DAC
ADC
Power Rating
Impedance
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
20 Hz – 20 kHz
>85 dB
0.01%
-110 dB
8 kHZ – 48kHz
16, 20 or 24-bit
16 or 20-bit
2 Watts
4 Ohms
Page 17
QuickSpecs
Technical Specifications
HP Compaq 6720t Mobile Thin Client
Integrated Broadcom
10/100 Ethernet PCI
Controller
V.92 56K Data/Fax
Modem
(BCM4401)
Ethernet Features
Power Management
Manageability
Interface
NIC Device Driver Name
Form Factor
Power Management
Support
Approvals/
Certifications
Data Mode Capabilities
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-
30)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100
Mbit/s
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
ACPI compliant -- multiple power modes
Situation-sensitive features reduce power consumption
Wake-on-LAN from standby (configurable; Magic Packet and Microsoft)
Wake-Up Frame)PXE 2.1 Remote Boot
Statistics Gathering (RMON, Ethernet-like MIB, Ethernet MIB (802.3x, clause
30)
Comprehensive diagnostic and configuration software suite
32-bit PCI, 33-MHz
Broadcom 440X 10/100 Integrated Controller
MDC 1.5 Daughtercard
APM Revision 1.2, ACPI
UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC Part
15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian ACA, CE
Mark, Other Countries
V.92 data
V.8bis
V.80
V44, V.42bis, MNP5 (Compression)
V.42 (LAPM, MNP2-4) (Error Correction)
Optional symbol rates:
2800, 3429
Asymmetric Symbol rates
Synchronous primary channel data signaling rates:
3600, 31200
Automatic rate re-negotiation
V.34
V.32bis
V.32
V.23
V.22bis
V.22
V.21
Bell 212A
Bell 103J
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 18
QuickSpecs
Technical Specifications
HP Compaq 6720t Mobile Thin Client
Broadcom 4311AG
802.11a/b/g WiFi
Adapter
Fax Mode Capabilities
Command Set
Wireless LAN Standards
Interoperability
Frequency Band
Data Rates
Modulation
Security
1
TIA/EIA-578-B (Class 1)
T.30, T.4 (Group 3)
V.17
V.29
V.27ter
V.21 Channel 2
V.250 (Partial)
TIA-602
Identification: +GMI, +GMM, +GMR
Port control: +IPR, +ICF, +IFC, +ILRR
Modulation: +MS, +MR, +MA
Error control: +ES, +ER, +EB, +ESR, +ETBM
Data compression: +DS, +DR
V.251
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
Wi-Fi certified
Cisco Compatible Extensions Program compliant
(details at:
2.4 GHz and 5 GHz
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES,
802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAPMSCHAPv2, LEAP, EAP-FAST, EAP-SIM.
www.hp.com/go/notebooks/WLAN
)
Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program
Version 4).
Sub-channels
Media Access Protocol
Network Architecture
Models
Roaming
Output Power
Output Power
power varies by data
2
rate)
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
(for CKK)217.5 dBm
(for OFDM;
Multinational support with frequency bands and channels compliant to local
regulations.
CSMA/CA (Collision Avoidance) with ACK
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
IEEE 802.11 compliant roaming between access points
15 dBm
Page 19
QuickSpecs
Technical Specifications
HP Compaq 6720t Mobile Thin Client
Power Consumption
Power Management
Receiver Sensitivity
Antenna type
Range
Form Factor
Weight
Dimensions
Operating Voltage
Temperature
Humidity
Altitude
Configuration Utility
Transmit: 2.0 W (max)
Receive: 1.5 W (max)
Idle mode3: 390 mW (nominal)
Sleep mode: 20 mW (max)
ACPI compliant power management
802.11 compliant power saving mode
4
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
802.11 a – Typical
(@6 Mbps)
802.11 b – Typical
(@1 Mbps)
802.11 g – Typical
(@1 Mbps)
PCI-Express MiniCard
0.026 lb (12 g)
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
3.3v +/- 10%
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
5
Choice of Configuration Utility:
600 feet – Outdoor Open Area
150 feet – Indoor, Office environment
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
32° to 176° F (0° to 80° C)
-40° to 176° F (-40° to 80° C)
10% to 90% (non-condensing)
5% to 95% (non-condensing)
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco
Compatible Extensions support)
LED Activity
1
Check latest software/driver release for updates on supported security features.
2
Maximum output power may vary by country according to local regulations.
3
In Power Save Polling mode.
4
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
5
WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN may also be
compatible with certain third-party software supplicants.
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
LED Off – Radio OFF; Solid LED On – Radio ON
Page 20
QuickSpecs
Technical Specifications
HP Compaq 6720t Mobile Thin Client
Environmental Data
Copyright © 2008 Hewlett-Packard Development Company, L.P.
All rights reserved. Microsoft, Windows, and Windows XP are registered trademarks or trademarks of Microsoft Corporation in the
U.S. and/or other countries. Celeron is a registered trademark of Intel Corporation in the U.S. and/or other countries. All other
product names mentioned herein may be trademarks of their respective companies.
The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The
warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should
be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained
herein.
Eco-Label Certifications
System Configuration
This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these marks:
(NEED CERTIFICATIONS)
The configuration used for the Energy Consumption and Declared Noise
Emissions data is based on [add configuration here]
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008
Page 21
Loading...
