Compaq 61000101 User Manual

2.4 GHz Wireless Desktop Keyboard & Mouse

Item Number: 61000101

Installation & User’s Guide

All brand names and trademarks are the property of their respective owners.

Contents

1. Introduction ………………………………………………………………………….....3

2. Package Contents.……………………………………………………………………..3

3. System Requirements…………………………………………………………………3

4. Quick Installation Guide..…………………………………………………………..4-5

4-1. Programming the Hot Keys...…………………………………………………..6

4-2. Programming the Mouse Buttons……………………………………………..6

5. Features and Functions Descriptions……………………………………………..6

5-1. Description of Internet Keys……………………..……………………….……7

5-2. Description of Multimedia Keys.…………..……………………………….....7

5-3. Description of Application Keys.…..…………………………………………7

6. Troubleshooting……………………………………………………………………....8

7. FCC & CE Certification …...………………………………………………………....9

8. Service Procedure……………………………………………………………………10

9. Warranty………………………………………………………………………..………11

1. Introduction:

The 2.4 GHz Wireless Desktop with Keyboard and Mouse:

This keyboard and mouse was developed to provide greater efficiency and productivity when working with a PC. The keyboard has 8 hot keys including: Internet, Multimedia and System keys that will increase your productivity by providing direct access to your important applications by a simple press of the key.

The mouse has 2 keys located on the side which can be programmed in order to work more efficiently on your computer.

2.4 GHz wireless technology allows you to work up to 33ft away from your computer without having any interference to the signal.

Instant link technology connects your wireless keyboard and mouse to the USB receiver automatically. There is no need for you to re-synchronize the devices.

A 1000 DPI optical mouse sensor scans the surface to allow for the finest precision and accuracy while using your mouse.

The 2.4 GHz Wireless Desktop with Keyboard and Mouse is compatible with Microsoft Office® 2000 / XP / 2003 or later. It is compatible with Windows® 2000, XP and Vista® Operating Systems.

2. Package Contents:

• Wireless Keyboard

• Wireless Optical Mouse

• USB Wireless Receiver

• User’s Manual

• Installation CD

• 4-AAA batteries to power the mouse and keyboard

3. System Requirements:

• IBM PC or Compatible Computer

• Microsoft Windows® 2000, XP, Vista®.

• CD-ROM or DVD-ROM Drive to install the CD driver.

• An available USB port for the USB Wireless Receiver Connector.

Install the Software CD Driver that has been included and you may

2, Programming the Hot Keys on the

ng in

4. Quick Installation and Set Up:

Open the battery compartment located underneath the keyboard and install the 2 AAA batteries. Note the polarity signs in the battery compartment.

Open the battery compartment located underneath the mouse and install the 2 AAA batteries. Note the polarity signs in the battery compartment.

Turn on the power to your computer and make sure your Windows operating system is active.

now go on to section 4Keyboard and Mouse. Note: Install the Software before pluggi the receiver.

Insert the USB Receiver into an available USB port. Your computer will recognize the USB device and make the proper settings to enable you to operate your keyboard and mouse. Click on any key on your keyboard to connect with the receiver. Move the mouse over the surface to establish a connection with the receiver.

1) If the mouse and/or keyboard do not work, please see the Troubleshooting information on page 9 of this manual.

2) Caution: Before your mouse and keyboard can be connected, you need to position the devices within 6 feet of the receiver to establish the initial connection.
