Compal LA-B101P Schematic

A

B

C

D

E

For DIS

PCIe X1

1 1

NV N15V-GM
15W

VRAM DDR3L 1GB/2GB

Gen2

Memory Bus

Zϯ>ϭϯϯϯD,nj;ϭϯϱsͿ

Memory Bus

ͲĐŚZϯ>Ͳ^KͲ/DDyϭ

ͲĐŚZϯ>Ͳ^KͲ/DDyϭ

Zϯ>ϭϯϯϯD,nj;ϭϯϱsͿ

eDP X1

eDP Panel

CRT Conn.

HDMI Conn.

2 2

RJ45 Conn.

LAN

RTL8106E/RTL8111G
10/100/GIGA

PCIe Port 0

(2 Lanes)

CRT

DDI X1
(4 Lanes)

PCIe X1
(1 Lanes)

Intel Valleyview

SOC

25mm X 27mm

PCIe X1

NGFF

WLAN / BT

PCIe Port 1

3 3

Card Reader

Realtek
RTS 5229-GR

PCIe Port 2

(1 Lanes)

USB2.0 X1
(1 Lanes)

PCIe X1
(1 Lanes)

USB3.0 x1

USB2.0 x1

USB2.0 x1

USB2.0 x1

USB2.0 x1

SATA X1

SATA X1

HDA

Left USB3.0 x1

USB30 Port 0

Left USB2.0 x1

USB20 Port 1

Right USB2.0 x1

USB20 Port 2

USB Hub * 1

USB20 Port 3

HDD Conn.

SATA Port 4

ODD Conn.

SATA Port 5

Audio Codec

Realtek
ALC233

Right USB2.0 x1

USB HUB Port 1

For E14

Int. Camera

USB HUB Port 3

Touch Screen

USB HUB Port 1

For B14/B15

Bluetooth

USB HUB Port 4

Finger Printer

USB HUB Port 2

Sub-borad
15"

SPI ROM

8MB

EC

Nuvoton 288N

Int. MIC Conn. Int. Speaker Conn.

Audio Combo Jacks

HP & MIC

14"

DC IN/B

BATT/B

Thermal Sensor Touch Pad Int. KBD

Power/B

4 4

IO/B

A

ODD/B

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

B

C

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2013/04/12 2014/04/12

2013/04/12 2014/04/12

2013/04/12 2014/04/12

Compal Secret Data

Compal Secret Data

Compal Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

D

Compal Electronics, Inc.

Compal Electronics, Inc.

Compal Electronics, Inc.

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Intel BayTrail-M Platform

Intel BayTrail-M Platform

Intel BayTrail-M Platform

Date: Sheet

Date: Sheet

Date: Sheet

Block Diagrams

Block Diagrams

Block Diagrams

E

2 47Tuesday, February 18, 2014

2 47Tuesday, February 18, 2014

2 47Tuesday, February 18, 2014

of

of

of

0.1

0.1

0.1

A

B

C

D

E

Voltage Rails

S0 S3 S4/S5Power Plane Description

VIN

BATT+ 12V Battery power supply

B+

1 1

+RTCVCC RTC Battery Power

+1.0VALW

+1.8VALW +1.8v Always power rail

+3VALW +3.3v Always power rail

+5VALW

+SOC_VCC Core voltage for SOC

+SOC_VNN GFX voltage for SOC

+0.675VS +0.675V power rail for DDR3L Terminator

+1.0VS

+1.05VS

+1.35VS

2 2

+1.5VS

+1.8VS

+3VS

+5VS

19V Adapter power supply

AC or battery power rail for power circuit. (19V/12V)

+1.0v Always power rail

+5.0v Always power rail

+1.35V power rail for DDR3L+1.35V

+1.0v system power rail

+1.05v system power rail

+1.35v system power rail

+1.5v system power rail

+1.8v system power rail

+3.3v system power rail

+5.0v system power rail

ON

ON ON

ON ONON

ON ONON

ON ONON

ON ONON

ON ONON

ON ONON

ON ONON

ON ON

ON

ON

ON OFF OFF

ON OFF OFF

ON OFF OFF

ON OFF OFF

ON OFF OFF

ON OFF OFF

ON OFF OFF

ON OFF OFF

OFF

OFF OFF

OFF OFF

Board ID / SKU ID Table for AD channel

Vcc 3.3V +/- 5%
Ra/Rc/Re
Board ID

0
1
2
3
4
5
6
7

100K +/- 5%

Rb / Rd / Rf V min

0

8.2K +/- 5%
18K +/- 5%
33K +/- 5%
56K +/- 5%
100K +/- 5%
200K +/- 5%

NC

AD_BID

0 V

0.216 V 0.250 V 0.289 V

0.436 V

0.712 V

1.036 V

1.453 V 1.650 V 1.759 V

1.935 V

2.500 V

BOARD ID Table

Board ID

0
1
2
3
4
5
6

PCB Revision

V typ

AD_BID

V

AD_BID

0 V 0 V

0.503 V

0.819 V

0.538 V

0.875 V

1.185 V 1.264 V

2.200 V

3.300 V

2.341 V

3.300 V

BOM Option Table

Item BOM Structure

hŶƉŽƉ Λ
ŽŶŶĞĐƚŽƌ
yW;ĞďƵŐWŽƌƚͿ
DƌĞƋƵŝƌĞŵĞŶƚ

^ƌĞƋƵŝƌĞŵĞŶƚ
^ƌĞƋƵŝƌĞŵĞŶƚƵŶƉŽƉ

max

DΛ
yWΛ
DΛ
ΛDΛDƌĞƋƵŝƌĞŵĞŶƚƵŶƉŽƉ
^Λ
Λ^Λ
d^ΛdŽƵĐŚ^ĐƌĞĞŶ
ϭϰΛƐĞƌŝĞƐƐŬƵ

Note : ON* means that this power plane is ON only with AC power available, otherwise it is OFF.

ƐĞƌŝĞƐƐŬƵ
ƐĞƌŝĞƐƐŬƵ

ϭϱΛ
ϭϰΛ

EC SM Bus1 address

Device

3 3

Smart Battery

Charger

Address Address

0001 011X b

0b00010010 (0x12H)

EC SM Bus2 address

Device

GPU

Thermal

0x9E

1001_101xb

43 level BOM table

BOM Structure43 Level Description

SOC SM Bus address

Device Address

SO-DIMM A (JDIMM1)

SO-DIMM B (JDIMM2)

4 4

A0h

A2h

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

A

B

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

USOC1

USOC1

N2920@

N2920@

S IC FH8065301616203 SR1SF B3 1.86G C38!

S IC FH8065301616203 SR1SF B3 1.86G C38!

Part Number = SA00007E860

Part Number = SA00007E860

Compal Secret Data

Compal Secret Data

2013/04/12 2014/04/12

2013/04/12 2014/04/12

2013/04/12 2014/04/12

C

Compal Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

USOC1

USOC1

N3520@

N3520@

S IC FH8065301616103 SR1SE B3 2.17G C38!

S IC FH8065301616103 SR1SE B3 2.17G C38!

Part Number = SA00007E990

Part Number = SA00007E990

USOC1

USOC1

N2815@

N2815@

S IC FH8065301619509 SR1SJ B3 1.86G C38!

S IC FH8065301619509 SR1SJ B3 1.86G C38!

Part Number = SA00007EO50

Part Number = SA00007EO50

Compal Electronics, Inc.

Compal Electronics, Inc.

Title

Title

Title

Size Document Num ber Rev

Size Document Num ber Rev

Size Document Num ber Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

D

Date: Sheet

Compal Electronics, Inc.

Notes List

Notes List

Notes List

Intel BayTrail-M Platform

Intel BayTrail-M Platform

Intel BayTrail-M Platform

E

0.2

0.2

0.2

of

of

of

3 47T uesday, February 18, 2014

3 47T uesday, February 18, 2014

3 47T uesday, February 18, 2014
