Comnet CNFE1002M1A-A User Manual

INSTALLATION AND OPERATION MANUAL

CNFE100(X)-A

10/100 MBPS ETHERNET MEDIA CONVERTER
FOR AIGIS DOME

The series of Ethernet media converters are designed to transmit and receive 10/100

Mbps data over one multimode or single mode optical fiber. They are designed to be

mounted within an Aigis dome and provide optical Ethernet output.

The electrical interface will Auto-Negotiate to a 10 Mbps, or 100 Mbps Ethernet rate

without any adjustments. The optical interface operates at a 100 Mbps Ethernet rate.

The series is environmentally hardened to operate in extreme temperatures.

An LED indicator confirms equipment operating status. Figure 6 on Page 4 describes

the LED indicators for the unit.

The CNFE100(X)-A series media converters are designed to be mounted in an Aigis

dome camera. See Figure A on Page 5 for mounting instructions.

INS_CNFE100(X)-A_REV–

06/21/11

PAGE 1

INSTALLATION AND OPERATION MANUAL CNFE100(X)-A

FIGURE 1 – CNFE1002-A

One-Fiber ST Connector

MULTIMODE
OR SINGLE MODE
OPTICAL FIBER

Power Connector

Ethernet RJ-45

FIGURE 2 – CNFE1003-A

Two-Fiber SC Connector

MULTIMODE
OR SINGLE MODE
OPTICAL FIBER

Power Connector

Ethernet RJ-45

FIGURE 3 – CNFE1004-A

One-Fiber SC Connector

MULTIMODE
OR SINGLE MODE
OPTICAL FIBER

Power Connector

Ethernet RJ-45

FIGURE 4 – CNFE1005-A

Two-Fiber ST Connector

MULTIMODE
OR SINGLE MODE
OPTICAL FIBER

Power Connector

Ethernet RJ-45

TECH SUPPORT: 1.888.678.9427

INS_CNFE100(X)-A_REV–

06/21/11

PAGE 2
