Comdial Scout II User's Guide

Quick Q
Agent’s User Guide for the
Scout II Telephone
Comdial® strives to design the features in our communications systems to be fully interactive with one another. However, this is not always possible, as the combinations of accessories and features are too varied and extensive to insure total feature compatibility. Accordingly, some features identified in this publication will not operate if some other feature is activated. Comdial disclaims all liability relating to feature non-compatibility or associated in any way with problems which may be encountered by incompatible features. Notwithstanding anything contained in this publication to the contrary, Comdial makes no representation herein as to the compatibility of features.
GCA70-382 10/02 Printed in U.S.A.
QuickQ Agent’s User Guide-Scout II
Table of Contents
1. THE SCOUT II TELEPHONE FOR AGENTS................1
2. DESCRIPTION OF THE DISPLAY (IDLE DISPLAY) .3
3. INTERACTION WITH FX II ............................................4
4. SIGNING-IN TO QUICKQ................................................5
5. RECEIVING AN ACD CALL............................................7
6. TRANSFERRING AN ACD CALL ...................................8
7. REQUESTING HELP.........................................................9
Selecting Conferencing During Help..............................9
Selecting Hold During Help ..........................................10
8. WRAP-UP: DISCONNECTING FROM A CALL........11
9. PLACING OUTGOING CALLS .....................................12
Assigning an Account Code...........................................12
10. ALARM CONDITION....................................................13
11. THINGS TO REMEMBER ............................................14
12. LOG-IN PROCEDURE...................................................15
13. INCOMING CALL FLOWCHART..............................16
Log-In for Multiple Groups ..........................................17
Oct ‘02 Comdial i
Contents
This page is intentionally blank.
ii Comdial Oct ‘02
QuickQ Agent’s User Guide-Scout II
1. THE SCOUT II TELEPHONE F OR AGENTS
QuickQ versions using software release 3.0 (or later) allow the use of up to nine Scout II digital wireless telephones. Using these telephones provides users with maximum freedom to move about within the call center.
• The F1 button should be programmed as the OAI button (labeled ACD) on your Scout II telephone. This button enables you to sign into QuickQ. Buttons F2, F3, and F4 should be programmed to function the same as the three interactive buttons on the proprietary 12-button and 24-button telephones while QuickQ is active.
Oct 02 Comdial 1
The Scout II Telephone for Agents
• All displays shown in this guide are as seen on the 16-character (8 characters x two lines) Scout II display.
1. Ringer ON/OFF switch 9. Head Set Jack
2. Message Display 10. Volume (R/VOL) Button
3. Transfer/Conference (T/C) Button 11. MUTE Button
4. Talk Button 12. Hold Button
5. Numeric Keypad 13. Tap Button
6. Function Button 14. Redial Button
7. Function Button 15. Channel Button
8. Microphone 16. Function Button
17. Function Button
2 Comdial Oct, 02
QuickQ Agent’s User Guide-Scout II
2. DESCRIPTION OF THE DISPLAY (IDLE DISPLAY
Quick Q Group 01
This line indicates the function of the interactive buttons. Please refer to the following table for the interactive button definitions.
This line indicates your present status.
Scout Interactive Button Definitions
Scout
Display
Ab ABORT Ok OK
Ac ACC (account) Ot OUT
Ag AGENT Py PLAY
Al ALL Qt QUIT
As ANSWER Rd READY
By BUSY Rc RECORD
Cf CONF Rj REJECT
Cn CANCEL Rs RELEASE
Cr CLEAR Rp REPORT
Dy DAY Rt RETRY
Ex EXIT Rn RETURN
Hp HELP Sn SCAN
Hd HOLD Se SELECT
In IN Sk SKIP
Lg LOG Sp SPEC’L (special)
Lg LOGOUT St STOP
Mn MENU Tr TRANS (transfer)
Md MODE Vc VOICE
Ms MSG (message) Wp WRAPUP
Nt NIGHT Ys YES
No NO
Standard
Display
)
ByHpLg
Scout
Display
Standard
Display
Oct 02 Comdial 3
Interaction with FX II
3. INTERACTION WITH FX II
• To access FX-II features, press the ACD button to exit QuickQ, if enabled. Then, press F4 (intercom) followed by the desired code.
• Your telephone will respond normally when you access FXII features. During FX II operation, QuickQ will be suspended. This is indicated by a flashing red light above the ACD button. After completing the FX II feature, press the ACD button to resume ACD operation.
Do Not Disturb prevents your phone from ringing on non-ACD calls; that is, intecom calls and personal calls.
Call Forward forwards non-ACD cals only; that is, intercom calls and personal calls.
4 Comdial Oct, 02
QuickQ Agent’s User Guide-Scout II
4. SIGNING-IN TO QUICKQ
• Press the ACD (F1) button (OAI button).
Welcome ->QuickQ
This display notifies you that you are about to log into QuickQ.
Agt ID:
Rt Qt
This display prompts you to enter your ID number.
• Use the keypad to enter your ID number. Press the Rt (retry) Interactive button if you enter an incorrect digit.
Password:
Rt Qt
This display prompts you to enter your password.
Oct 02 Comdial 5
Signing-in to QuickQ
• Enter your password digits
QQ Group 01
ByHpLg
• The above display indicates you are now signed in as an ACD agent, ready to accept incoming calls. If it is necessary for you to leave your desk, press the By (busy) interactive button. This will prevent the ACD from sending calls to you when you are unable to answer.
Pressing Busy
Busy
CnHpLg
• The system will automatically set your telephone to Busy under the following conditions.
• if you do not answer an ACD call sent to you.
• if you place or answer an internal call
• if you answer a transferred call
• if you place an outgoing call during the wrap-up time
6 Comdial Oct, 02
QuickQ Agent’s User Guide-Scout II
5. RECEIVING AN ACD CALL
• When an ACD call is directed to you, your telephone will ring and the display will indicate the following:
Group 01
By
The group is identified on the display
Wt >T
MsRpAg
The time the call has waited is displayed
after 2 sec
• If you do not answer this call within the programmed redirect threshold time, the call will automatically go to another agent. When the call is redirected, the ACD wil automatically make your telephone busy.
• If you are unable to take this cal, press the By (busy) interactive button, and the system will redirect the call to another idle agent. If there are no availbable agents, your display will indicate “All Agents busy”. You must then answer to avoid losing the call.
• To answer the call, lift the Handset, or if using a headset, press TALK .
LinNameSupp
AcWpHp
• During your conversation, the display remains on your telephone.
Oct 02 Comdial 7
Transferring an ACD Call
6. TRANSFERRING AN ACD CALL
• When transferring a call, be aware that you are responsible for the transferred call until the intended party answers the call.
LineName Supp901
AcWpHp
• To transfer a call, press the T/C button.
• Announce the call to the intedned party (paging may be helpful for this).
LineName Supp901
AcWpHp
• Press the Wp (wrap-up) interactive button to disconnect from that call. Your display will enter the WRAP-UP mode (refer to page 10).
• If the transferred call is not answered, the call will automatically recall to your telephone (regardless of your activity).
8 Comdial Oct, 02
QuickQ Agent’s User Guide-Scout II
7. REQUESTING HELP
• The Help function calls the supervisor without interrupting your present conversation.
• During your conversation, press the HELP interactive button.
Reqt Help!
Cn
When the supervisor responds to your request
Super Redy
Cf Hd
After 2 seconds
Supp 901
Cf Hd
Supervisor’s Name
• You now have the option to add the supervisor to your conversation (CONFerence), or to place the caller on HOLD while you discuss the situation with your supervisor.
7.1 Selecting Conferencing During Help
• After requesting HELP, press the CONF interactive button to conference the supervisor, the caller and yourself.
Oct 02 Comdial 9
Requesting Help
LinName Supp901
Rs Tr
• The top line of the display identifies the line and supervisor, indicating a conference. Press the RELEASE interactive button to drop the supervisor from the call. Press the TRANS interactive button to send this call to the supevisor.
7.2 Selecting Hold During Help
• Press the Hp (hold) interactive button.
LinName Held!
CfRtTr
• This action places the caller on hold and connects you directly with your supervisor.
Cf (conference) Connects the supervisor, caller, and yourself.
Rt (return) Return to the caller and release the supervisor.
Tr (transfer) Transfer the caller to the supervisor and
disconnect yourself.
10 Comdial Oct, 02
After 2 seconds
QuickQ Agent’s User Guide-Scout II
8. WRAP-UP: DISCONNECTING FROM A CALL
• To complete a call, hang up the receiver. The system provides a preprogrammed wrap-up time to allow you to complete any after call work. During the wrap-up time, no calls will be directed to you.
Wrp-up--->000s
RdAcBy
Total Calls Waiting
Wt: 12 >T:03
RdAcBy
Calls beyond alarm
• The display indicates the number of calls holding and the number of calls waiting longer than the programmed acceptable time (alarm threshold).
• After the wrap-up time has expeired, your telephone will return to the IDLE display.
• You can bypass the wrap-up time by pressing the READY interactive button, or you can select the BUSY interactive button during the wrap-up time, should you requred more time or need to leave your desk.
Indicates which agent’s conversation you are monitoring.
Press Sn (scan) to have the system select another agent, or press Qt (quit) to enter another agent’s ID. Press Qt (quit) twice to return to the idle display.
Oct 02 Comdial 11
Placing Outgoing Calls
9. PLACING OUTGOING CALLS
• Select an outgoing line.
Outgoing
ApWpHp
Number dialed is display
After 2 seconds
9.1 Assigning an Account Code
• To assign an account code to a call, press the Ac (account) interactive button during or after the call. Account codes must be preset by the supervisor and can be used on both incoming and outgoing calls.
LinName Supp901
Ac Wp Hp
12 Comdial Oct, 02
WrpUp---> 000s
Acc Cd:___
Rt Ex
RdAcBy
QuickQ Agent’s User Guide-Scout II
• Enter the account code using the telephone key pad. If you press an incorrect digit, press the Rt (retry) interactive button.
AccDesc
Rt Ok
• If correct, press the Ok interactive button to return to the previous state.
• Calls can have more than one account code. To enter additional codes, repeat these steps for each.
10. ALARM CONDITION
• An alarm tone sounds on your telephone when waiting calls have exceeded the time on hold set by your supervisor.
Alarm Display Wt >T:
XX XX XX
• This alarm will sound regardless of your activitiy (idle, busy, or on a call).
Oct 02 Comdial 13
Things to Remember
11. THINGS TO REMEMBER
• If your display is blank, your telephone is either not logged-in, or the QuickQ is suspended. Press the QuickQ resume.
• QuickQ will automaticaly make your telephone Busy if you miss an ACD call.
• Quick Q will temporarily make your telephone Busy if you:
• Answer a transferred call
• Retrieve a parked call
• Answer or place an intercom call
• Answer or place a non-ACD call
• When you complete either of the above actions, the system will automatically return you to your previous state.
• Log out if you are leaving for the day.
button to
• You cannot log out if you are the last agent in the gorup. At the preset closing time, the system will automatically log you out.
• Remember to make your telephone Busy if you are leaving your desk or unable to answer ACD calls.
14 Comdial Oct, 02
QuickQ Agent’s User Guide-Scout II
12. LOG-IN PROCEDURE
Welcome >QuickQ
Agt ID:
Rt Qt
Password:
Rt Qt
QuickQ: Group01 By Hp Lg
Busy Cn Hp Lg
Log Procedure
By Cn Ot
Oct 02 Comdial 15
QuickQ Group 01
ByHpLg
Incoming Call FlowChart
13. INCOMING CALL FLOWCHART
16 Comdial Oct, 02
QuickQ Agent’s User Guide-Scout II
12.1 Log-In for Multiple Groups
Group 01
In Stock A1
QuickQ Group01
ByHpLg
Note: Each group that you belong to is displayed in the order of your priority in each one. For example, if you belong to three groups (1,2, and 3) and your priority is highest in group 3, group 3 is displayed first.
Oct 02 Comdial 17
Incoming Call FlowChart
This page is intentionally blank.
18 Comdial Oct, 02
This manual has been developed by Comdial Corporation (the “Company”) and is intended for the use of its customers and service personnel. The information in this manual is subject to change without notice. While every effort has been made to eliminate errors, the Company disclaims liability for any difficulties arising from the interpretation of the information contained herein.
The information contained herein does not purport to cover all details or variations in equipment or to provide for every possible contin gency to be met in connection with installation, operation, or mainte­nance. Should further information be desired, or should particular problems arise which are not covered sufficiently for the purchaser’s purposes, contact Comdial, Inside Sales Department, Sarasota, Florida 34232.
-
GCA70-382 10/02 Printed in U.S.A.
