Code Alarm CA-670 User Manual

Remote Vehicle Control System

CA-670

Owner's Manual

Deluxe Vehicle Security and Remote

Start System with Two Way

Confirming LCD Remote Control

IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is

applicable to most vehicles. However, due to the configuration of some vehicles, some functions AND/OR SAFETY

PRECAUTIONS may not apply. Please see your installing dealer for more information.

Table of Contents

Using Your Remote Control ......................................................... 3

Arming the security system
Pre-arm mode
Disarming the security system
Disabling/Enabling confirmation chirps
Attempted intrusion identification
Two stage door unlock*
Activating the trunk release feature*

Using Your Remote Control, continued .................................... 4

Turning on the vehicle’s headlights*
Activating optional channel 2*
Activating optional channel 3*
Activating optional channel 4*
Activating optional channel 5*
Using the progressive car finder feature
Using the personal protection alarm
Using the transmitter flashlight feature

Using Your Remote Vehicle Starter .................................5

Remote starting your vehicle
Entering your vehicle while it is running via remote vehicle start
Using the safety (red handled) control switch
Preheating or Precooling the vehicle’s interior
Turning on the rear window defroster (optional)*
Using the “quick-stop” feature

Using Your Remote Vehicle Starter, continued ...................... 6

Operating the 2 / 4 hour start up timer mode
Operating the temperature start mode

Using Your Remote Vehicle Starter, continued ...................... 7

Operating the daily start timer
Remote start safety features
Using valet mode

Using the Optional Turbo Timer Feature* ................................ 7

Additional LCD Remote Control Features .............................. 8

LCD Remote Control Functions .............................................. 9

LCD Remote Control Icons and Their Indications ................ 10

Optional Songbird Feature* .................................................... 11

Replacing Remote Control Batteries .................................... 11

Emergency Override Procedure ........................................... 12

Emergency Override Procedure

Code Systems, Inc. Limited Lifetime Warranty .................... 13

2

* May require additional installation labor, components and installation cost

Using Your Remote Control

Arming the Security System

To arm the system, exit the vehicle, close all doors, then press the LOCK
icon button on the remote control. The system will sound twice and the
parking lights will flash twice, indicating the system is armed. The doors will
also lock at this time (if equipped and connected). The status indicator (blue
warning light on the dash) will blink steadily, once per second. To arm the
system silently, press and hold the LOCK icon button for 1 second. The
parking lights will flash 2 times indicating the system is armed and has locked
the doors (if equipped and connected). The status indicator (blue warning light
on the dash) will blink steadily, once per second.

Pre-arm Mode

If the horn system sounds and the parking lights flash only once, this indicates
that the vehicle’s interior light is on or an entrance is left open. Check to see that
all doors hood and trunk are closed properly. Once all entrances are secured (and
the interior light is off), this system will sound/flash again. The system is now fully
armed. (If the entrance is not secured within 4 minutes, the system will arm and
ignore the unsecured entrance until it is closed.)

Disarming the Security System

To disarm the system press the UNLOCK icon button. The system will sound, the
parking lights will flash once and the doors will unlock (if equipped and
connected). To disarm the system silently, press and hold the UNLOCK icon button for 1 second. The
parking lights will flash, indicating the system is disarmed and has unlocked the doors (if equipped
and connected).

Disabling/Enabling Confirmation Chirps

1. Turn the ignition key ON then OFF.

2. Within 10 seconds push and release the valet/override button 3 times.

3. The system will sound 2 times to disable confirmation chirps or 1 time to enable confirmation
chirps.

. Attempted Intrusion Identification

This system will inform you if an intrusion attempt has occurred while you were away from the vehicle. If
an intrusion attempt occurred, the system will sound 4 times and the parking lights will flash 3 times
when disarming the system. Enter the vehicle an observe the dash mounted status LED to Identify
which zone was triggered.

1. IT-s Sensor- 1 flash, pause 1 flash, etc.

2. Hood or Trunk Pin switch- 2 flashes, pause 2 flashes, etc.

3. Door Entry- 3 flashes, pause 3 flashes, etc.
The intrusion warning indicators are stored in the system’s memory and will be erased when the ignition
key is turned on.

Two Stage Door Unlock (Optional)

If this feature is enabled on your system, pressing the UNLOCK icon button one time on the remote
control will unlock only the driver’s door. Press disarm again to unlock the remaining doors.

Activating the Trunk Release Feature (Optional)

If this feature is enabled on your system, pressing and holding the TRUNK icon button on the remote
control for 2 seconds will open the vehicle’s trunk or hatch.

*Throughout this manual, ‘press’ refers to pressing for less than 1 second; ‘press and hold’ refers to pressing for more
than 2 seconds.

3

Using Your Remote Control, continued

Turning on the Vehicle’s Headlights (Optional)

If this feature is enabled on your system, pressing and holding the LOCK icon button on the remote
control for 2 seconds will turn on the vehicle’s headlights for 30 seconds.

Activating Optional Channel 2 (Optional)

If this feature is enabled on your system, pressing and holding the LOCK icon button and the TRUNK
icon button on the remote control simultaneously will activate an optional feature. This feature can be
programmed for a wide range of functions like power window or sunroof automation, please consult
your installing dealer to determine functionality of your system.

Activating Optional Channel 3 (Optional)

If this feature is enabled on your system, pressing and holding the OPT button on the remote control
will activate an optional feature. Optional channel 3 is generally used to turn on the rear window
defroster after the vehicle has been remote started, but can also be programmed for a wide range of
functions, please consult your installing dealer to determine functionality of your system.

Activating Optional Channel 4 (Optional)

If this feature is enabled on your system, pressing and holding the LOCK icon button and the OPT
button on the remote control simultaneously will activate an optional feature. This feature can be
programmed for a wide range of functions like power window or sunroof automation, please consult
your installing dealer to determine functionality of your system.

Activating Optional Channel 5 (Optional)

If this feature is enabled on your system, pressing and holding the UNLOCK icon button and the OPT
button on the remote control simultaneously will activate an optional feature. This feature can be
programmed for a wide range of functions like power window or sunroof automation, please consult
your installing dealer to determine functionality of your system.

Using the Progressive Car Finder Feature

2-way LCD Remote Control:

Press the LOCK icon button and the UNLOCK icon button on the remote control to locate your vehicle.
The system will sound 5 times at low volume increasing in volume each of 3 times the button is
pressed.

1-way Six Button Remote Control:

Press the icon button on the remote control to locate your vehicle. The system will sound 5 times at
low volume increasing in volume each of 3 times the button is pressed.

Using the Personal Protection Alarm (Panic)

2-way LCD Remote Control:

Press and hold the LOCK icon button and the UNLOCK icon button on the remote control for 2
seconds to activate the personal protection alarm. The system will sound for 30 seconds. Pressing
any button on the remote control will turn the personal protection alarm off.

1-Way Six Button Remote Control:

Press and hold the icon button on the remote control for 2 seconds to activate the personal
protection alarm. The system will sound for 30 seconds. Pressing any button on the remote control
will turn the personal protection alarm off.

Using the Transmitter Flashlight Feature

The (1) 6 button (non-confirming) remote control included with your system has a flashlight bulb built
into the top of the remote control. Pressing and holding the LIGHT icon button on the remote control
will activate the flashlight until the button is released.

*

*

4

Using Your Remote Vehicle Starter

Remote Starting Your Vehicle

To activate the remote vehicle start function, press and release the OPT button on the remote control two (2)
times within 2 seconds. The system will sound, the parking lights will flash 1 time and the system will check
the vehicle to ensure it is safe to start, if all safety parameters are correct, the vehicle will start within 5
seconds (diesel vehicles will take longer). The vehicle’s parking lights will turn on (or flash depending on
system settings) as a visual indication that the vehicle has started and is running. Press and release the
OPT button on the remote control two (2) times within 2 seconds again to turn the vehicle off.

If your vehicle stalls or does not start, the system will pause 5 seconds, then try 2 more times to start the
vehicle (a total of 3 attempts). The system will pause 5 seconds between each start attempt. If the vehicle
does not start after the fourth attempt, the system will abort the remote vehicle start process.

Entering the Vehicle While it is Running via Remote Vehicle Start

1. Unlock the vehicle’s doors.

2. Enter the vehicle. DO NOT PRESS THE BRAKE PEDAL!

3. Insert the key into the ignition switch and turn to the ON or RUN position.

4. Press the brake pedal. The remote vehicle starter will disengage and the vehicle will operate normally.

Using the Safety (Red Handled) Control Switch

The safety (red handled) control switch allows you to temporarily disable the remote vehicle starter feature,
this is especially helpful when having your vehicle serviced or valet parked. To disable the remote start,
move the safety (red handled) control switch to the OFF position.

Preheating or Precooling the Vehicle’s interior

Before exiting the vehicle, set the temperature controls to the desired setting and operation. After the
system starts the vehicle, the heater or air conditioning will activate and heat or cool the vehicle’s interior to
your setting.

Turning on the Rear Window Defroster (Optional)

While the vehicle is running via remote vehicle start, press and hold the OPT button on the remote control
for 2 seconds. The rear window defroster will turn on for 10 minutes or the vehicles preset time limit.

Using the “Quick-stop” Feature

If you want to make a short stop and keep your vehicle running (to keep the interior warm or cool), the
quick-stop feature allows you to do this while keeping your vehicle secure and your keys with you.

To engage quick stop:

1. Stop the vehicle and place the transmission in PARK.

2. With your foot off the brake pedal, press and release the OPTION button on
the remote control two (2) times within 2 seconds. The parking lights will turn
on indicating the vehicle is now running via remote vehicle start.

3. Remove the keys from the ignition and exit the vehicle. Press the LOCK icon
button on the remote control to lock the vehicle’s doors if desired.

Note: Do not leave children or animals unattended in the vehicle when using the

quick-stop feature.

5
