05-04-06
MODEL CA100
REMOTE CONTROL AUTO ALARM SYSTEM
INSTALLATION & OPERATION INSTRUCTIONS
WIRING DIAGRAM
6 Pin White Mini Connector
Black Antenna Wire
6 Pin
White
Valet Switch
2 Pin
Blue
2 Pin
White
2 Pin
White
5 Pin
White
MAIN 5 PIN WIRE HARNESS:
1. Red / White Wire: Parking Light Relay Power Input
2. White Wire: Parking Light Relay Output
3. Black Wire: Ground to Vehicle FRAME
4. Brown Wire: Positive out
5. Red Wire: +12V To Constant Battery Source
ut To Siren
6 PIN MINI CONNECTOR WIRE HARNESS:
1. Violet Wire: Positive Door Pin Switch Input
Blue Wire: (-) 200mA Unlock Pulse
Green Wire: (-) 200mA Lock Pulse
Main 5 Pin White harness
12V
LE D In d ica to r
15A Fuse
2. Blue Wire: Instant Trigger Ground Input
3. Green Wire: Negative Door Pin Switch Input
4. Pink Wire: To I
5. Orange Wire: 200mA Grounded when armed
6. Tan Wire: (-) 200mA Programmable Output
Channel 3 / 2 Step Door Unlock.
nition Switched + 12V
Cut
Red wire
Yellow wire
30
87a
85
86
To start solenoidFrom ignition switch
White wire
Orange
wire
12V
A. PROGRAMMING TRANSMITTER:
This mode will only retain the last 4 remote transmitters programmed. If the transmitter memory is
Note:
exceeded, the security system will start deleting transmitters from memory in chronological order.
1. Turn the Ignition 'switch ‘OFF/ON’ 3 TIME S an d st ay in ON position. Within 15 seconds.
2. Push the Valet switch 3 times and holding in on
switch. You are now in the Transmitter programming mode.
3. Press and hold any button of the transmitter until the siren responds with a confirming chirp, indicating the
signal has been stored into memory.
4. If you have additional transmitters (up to 4) that need to be programmed, repeat step 3 for each transmitter.
CA100
push until a long chirp is hear d then release the valet
3rd
1
Turn Ignition to 'OFF' position, or leave it for 15 seconds. Thr ee long c hirps & Three p arking light flashes
Exit:
confirm exit.
05-04-06
B. ALARM FEATURES PROGRAMMING:
ALARM FEATURE “I” PRORAMMING:
1. Turn the Ignition 'switch ‘ON/OFF’ 3 TIMES and stay in OFF position.
2. Push the Valet switch 2 times and holding in on
then release the valet switch. You are now in the Alarm feature
3. Press and release the transmitter button ‘A’ corresponding to the feature ‘A’ you want to change.
The siren chirps and LED pause will indicate new setting.
a.
The system would advance to [2] LED flash, [2] chirp. (The factory default setting is always [1] LED flash,
b.
[1] chirp.)
4 Depress the transmitter button ‘A’ again to change the feature again. Simply keep re-depressing the
transmitter button ‘A’ again until the module advances to your desired setting.
5. Depress the transmitter button ‘B’ corresponding to the feature ‘B’ you want to program.
Press
Transmitter
Button
1
2
3 +
Turn Ignition to 'ON' position, or leave it for 15 seconds. Three long chirps to confirm exit.
Exit
:
One Chirp /
LED one pulse
Factory Default Setting
Chirps on Chirps off
Automatic Rearm On Automatic Rearm Off
Instantly Door Ajar Warning. 45 seconds Delay Door Ajar error chirp.
nd
push until
2
short chirp with one long chirp is heard
one
programming mode.
‘I’
Two Chirps /
LED two pulse
ALARM FEATURE “II” PRORAMMING:
1 Turn the Ig nition 'switch ‘ON/OFF’ 3 TIMES and stay in OFF position.
2 Push the Valet switch 4 times and holding in on the
release the valet switch. You are now in th e Alarm feature
3 Press and release the transmitter button ‘A’ corresponding to the feature ‘A’ you want to program.
Press
Transmitter
Button
1
2
3 +
Turn Ignition to 'ON' position, or leave it for 15 seconds. Three long chirps to confirm exit.
Exit
:
One Chirp /
LED one pulse
Factory Default Setting
0.9-second Door lock
pulses.
Active arming Passive arming without
Ignition controlled door locks
& unlocks
Two Chirps /
LED two pulse
3.0-second Door lock pulse. Double pulse unlock
passive door locking
Without ignition controlled
door locks & unlocks
th
push until
4
chirps with a long ch ir p is he ar d the n
two
programming mode.
‘II’
Three Chirps /
LED three pulse
Passive arming with passive
door locking.
ALARM FEATURE “III” PRORAMMING:
1 Turn the Ig nition 'switch ‘ON/OFF’ 3 TIMES and stay in OFF position.
2 Push the Valet switch 6 times and holding in on the
then release the valet switch. You are now in the Alarm feature ‘III’ programming mode.
3 Press and release the transmitter button ‘A’ corresponding to the feature ‘A’ you want to program.
Press
Transmitter
Button
1
2
3 +
Turn Ignition to 'ON' position, or leave it for 15 seconds. Three long chirps to confirm exit.
Exit
:
One Chirp /
LED one pulse
Factory Default Setting
Shock Sensor Program Mode
Tan Wire = Trunk (Channel 3) Output Gray Wire = Two Step Door Unlock Output
Car Jacking Off Car Jacking On
ADJEST AND TEST THE SENSITIVITY LEVEL OF THE SHOCK SENSOR
1. Turn the Ignition 'switch ‘ON/OFF’ 3 TIMES and stay in OFF position.
2. Push the Valet switch 6 times and holdin g in on the 6th push un til th ree c hir ps w ith a long c h irp is heard then
release the valet switch. You are now in the Alarm feature ‘Shock Sensor’ programming mode.
3. Press an d hold
adjustments for the
4. Press
made the siren chirp will respond with [1] chirp, while 2 chirp indicates the minimum of sensitivity.
5. Press
the siren/horn chirp will respond with [1] chir p, while 2 chirp indicates the maximum of sen sit ivity.
button on the transmitter once will decrease sensitivity level by one, each time an decrease is
button on the transmitter once will increase sensitivity level by one, each time an increase is made
button for 2 seconds. One long siren chirp to indicate the unit is ready to accept
second stage of the shock sensor (full alarm).
th
push until three chirps with a lon g chirp is heard
6
Two Chirps /
LED two pulse
CA100
2
6. Hit the bumper or strong metal part of the vehicle to test the threshold level of the sensor.
a). Activate the warn-away (first stage the shock sensor), the siren will emit a short chirp.
b). Activate the full alarm (second st age the shock sensor), the siren will emit a long chir p.
7. When you are satisfied with the
at the same time for 2 seconds. Two long siren chirps to indicate the unit is ready to accept adjustments of
the
first stage the shock sensor (warn-away
8. Follow the step 4, 5 and 6 to adjust the warn-a wa y se nsitivity.
9. When you are satisfied with th e setting, press
indicates the unit has locked in the adjustment.
Note: If 30 seconds of inactivity expire, or turn on the ignition during of above steps, the unit will exit the
program mode and return to the disarmed mode. Three long chirps will confirm exit.
second stage the shock sensor
).
and buttons at the same time. One long siren chirp to
setting, press and hold
05-04-06
and button
OPERATION MANUAL
TRANSMITTER OPERATIO N:
Transmitter Button System Function Remark
-
(3 seconds)
-
(2 seconds)
+ (2 seconds)
Arm & Lock door
Arm & Delete The Shock Sensor Press twice within 3 seconds.
Car Locator Upon Armed.
Panic function Press and hold for 3 seconds
Disarm & Unlock Door
Disarm &Two Steps Door Unlock Press twice within 3 seconds.
Disarm & Pop Trunk Release Press and Hold for 2 seconds
Activate Car-Jacking Upon Ignition on
LED INDICATORS:
LED Function LED Function
Off Disarmed 2 flashes... pause Trigger on trunk/hood
Slow flash Armed 3 flashes... pause Trigger on door switch
Fast flash Passive arming 4 flashes... pause Trigger on Dual Zone Shock Sensor
On (solid) Valet mode 5 flashes... pause Trigger on Ignition switch
CHIRP INDICATORS: PARKING LIGHT:
Chirp Function Parking light Function
1 chirp Arm 1 flash Arm
2 chirps Disarm 2 flashes Disarm
3 chirps Ajar Warning 3 flashes Disarm / Intrusion
4 chirps Disarm / Intrusion 12 flashes Car Locator
6 chirps Car Locator
ACTIVE ARMING – LOCK & ARM:
1. Press button on transmitter.
2. The siren will chirp once and parking light will flash once indicating that the system is now armed. The
vehicle doors will lock upon arming when in terfaced with the security system.
Ajar Warning:
Silent Arming / Disarming:
No chirp sound will be heard, arm / disarm confirmation will be through the vehicles parking lights only.
Shock Sensor By-Pass:
shock sensor. The system will chirp one additional time to confirm the sensor bypass mode was activated. The
sensor bypass feature is programmed to activate for one arming cycle only. The security system will return to
normal operation during the next arming cycle.
If the siren sounds 3 chirps, then you h av e le ft a door, trunk, or hood lid ajar.
Press the and buttons at same time will arm or disarm your security system,
Press the
button twice within 3 seconds will arm the security system, by-pass the
PASSIVE ARMING:
Active arming / disarming is controlling your security system via the remote transmitter. This security system is
equipped with an optional Passive Arming feature, which allows the security system to arm 30 seconds after
the last door is closed. Operation is as follows.
1. Turn the ignition to the “OFF” posi tion and exit the vehicle.
2. After all entrances are closed , t he secur i ty system LED will flash fast for 30 second s. If you reopen any door /
hood / trunk, the security system LED will stop flashing. It will begin flashing again once the vehicle all
entrances are closed.
3. After 30-second timer has elapsed, the security system will automatically “ARM”. The siren will chirp [1] time
and the parking lights will flash [1] time.
PASSIVE DOOR LOCKING:
CA100
3
05-04-06
The vehicle doors will automatically lock aft er passive arming cycle has been completed.
ACTIVE DISARMING – UNLOCK & DISARM:
1. Press button on the transmitter.
2. The siren will chirp twice and parking light will flash twice to indicating that the security system is now
disarmed. The vehicle doors will unlock disarming when inte rfaced with the security system.
Tamper Disarm
Two Step Door Unlock
security system. Pushing the
: If alarm triggered, upon disa rm t he system, siren chirp 4 times, parking light fl ash 3 times.
: This feature will independently unlock the drives door only when disarming the
button on the transmitter a second time within 3 seconds will unlock the entire
vehicle.
Automatic Re-Arm
: If this feature is selected, the security system will automatically re-arm itself 60 seconds
after disarming with remote transmitter. Automatic rearm will cancel if any door is opened before the 60
seconds timer has elapsed.
DISARMING WITHOUT A TRANSMITTER
The Override function may be used if the remote transmitter is lost or inoperative.
1. Enter the vehicle and turn the ignition switch to 'ON’ position. (Alarm will sound.)
2. Within 10 seconds push and release the valet switch
The alarm will stop sounding a nd ent er the disarm mode. You can now start and op era te the vehicle normally.
VALET MODE:
The valet switch allows you to temporarily bypass all alarm function, eliminating the need to hand your
transmitter to parking attendants or garage mechanics. When the system is in valet mode, all alarm function is
bypassed, however the remote panic feature and remote door locks will remain operational.
Enter Valet Mode:
1. Turn the ignition to “ON” position.
2. Push and hold valet switch for 2 seconds until the LED turns on. The LED wills
remain on as long as the system is in 'valet mode'.
Exit Valet Mode:
1. Return to normal operation, turn ignition 'ON'.
2. Push and hold valet switch for 2 seconds, The LED wills turns off indicate the
system are exiting the valet mode.
PANIC FUNCTION:
The transmitter can be used as a remote panic switch to manually trigger the alarm in case emergency.
1. Press and hold
2. To stop the alarming press and hold
button on the transmitter for 3 second s. Th e ala rm will immediately sound.
button on the transmitter for 3 seconds.
3. If the button is not pressed, the alarm will automatically stop after 30 seconds.
TRIGGER THE SYSTEM
When armed, your vehicle is protected as follows:
1. Light impacts will trigger the warn-away signal. A long chirp from siren/horn.
2. Heavy impacts / Doors open / Hood open / Trunk open / Turns on the ignition switch will trigger the
programmed sequence.
The starter disable relay (if installed) prevents the vehicle’s starter from cranking. The siren and parking lights
will turn on to alerting of an intrusion for 30 seconds. Then it will stop and automatic reset and re-arm. If the one
of sensors or detectors still active, the alarm system will sound a maximum of 6 times of 30 seconds cycles.
ANTI CAR - JACKING
Warning: If you don't need the car jacking function in this alarm system, be sure to set car jacking feature “OFF”. This
system is default setting car jacking “OFF”.
Active A nti Car Jacking:
1. Upon ignition is “On”, press and hold the transmitter
will turns on for 1.5 seconds to indicate the system enters the car-jacking mode.
2. Once the system in car-jacking mode, If you are forced from the vehicle, the system will be trigger when the door is
opened and closed while the ignition is “ON”.
Trigger The Car Jack Mode:
a). 50 seconds after the system has been triggered. The siren will start chirping for 15 seconds.
b). During this 15 seconds period of chirping, you will be alerting to push the valet switch once to turn off the car-jacking
feature. If not, it will enter second timer car jacking.
c). 65 seconds after the system has beer triggered. The siren starts alarming and the parking light starts flashing.
d). 90 seconds after the system has beer triggered
1. The siren still alarming and the parking light flashing, and
2. The starter disable will activate to prevent the vehicle from starting.
3. It will remain active until the vehicle's battery pow er exhausted.
Override The System To Turn Off Car Jacking:
valet switch, the siren will stop and the system disarmed
CAR LOCATOR:
Upon armed, press button on the transmitter to active car locator function. The siren will chirp 6 times. The parking li ght
will flash 12 times, for you to easily locate your car.
and buttons at the same time for 2 seconds. The parking lights
Turn the ignition switch from OFF to ON, and within 10 seconds push
CA100
4
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions.
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
05-04-06
CA100
5
Loading...
