Cobra Electronics XRS-9530 Instruction Manual

Important Information and Customer Assistance

Introduction

English

Important Information

•

Federal Laws Governing the Use of Radar Detectors

It is not against federal law to receive radar transmissions with your Cobra radar/ laser detector. The Communications Act of 1924 guarantees your right to receive radio transmissions on any frequency. Local laws that contravene this Act, while illegal, may be enforced by your local law enforcement officials until and unless they are prohibited from doing so by federal court action.

Safety Alert

Use of this product is not intended to, and does not, ensure that motorists or passengers will not be involved in traffic accidents. It is only intended to alert the motorist that an emergency vehicle equipped with a Cobra Safety Alert transmitter is within range as defined by that product. Please call local fire and police departments to learn if coverage exists in your area.

Safe Driving

Motorists, as well as operators of emergency or service vehicles, are expected to exercise all due caution while using this product, and to obey all applicable traffic laws.

Security of Your Vehicle

Before leaving your vehicle, always remember to conceal your radar detector in order to reduce the possibility of break-in and theft.

Customer Assistance

•

Should you encounter any problems with this product, or not understand its many features, please refer to this owner’s manual. If you require further assistance after reading this manual, Cobra Electronics offers the following customer assistance services:

For Assistance in the U.S.A.

Automated Help Desk English only. 24 hours a day, 7 days a week 773-889-3087 (phone).

Customer Assistance Operators English and Spanish. 8:00 a.m. to 6:00 p.m. Central Time

Mon. through Fri. (except holidays) 773-889-3087 (phone).

Questions English and Spanish. Faxes can be received at 773-622-2269 (fax).

Technical Assistance English only. www.cobra.com (on-line: Frequently Asked

Questions). English and Spanish. productinfo@cobra.com (e-mail).

For Assistance Outside the U.S.A.

Contact Your Local Dealer

6500 West Cortland Street

Chicago, Illinois 60707 USA

www.cobra.com

Customer Assistance

XRS 9530

12 BAND

™

HIGH-PERFORMANCE DIGITAL RADAR/LASER DETECTOR WITH XTREME RANGE SUPERHETERODYNE

TECHNOLOGY

Nothing Comes Close to a Cobra

English

Operating Instructions

Printed in China

Part No. 480-232-P

Version C

Nothing Comes Close to a Cobra

English

For more information or to

order any of our products,

please visit our website:

www.cobra.com

CB Radios

microTALK

Radios

Radar/Laser Detectors

Safety Alert

Traffic Warning Systems

Handheld GPS Receivers

Mobile GPS Navigation Systems

HighGear

Accessories

CobraMarine

VHF Marine Radios

CobraMarine

Power Inverters

Accessories

The Cobra line of quality products includes:

9494- XRS 9530-D-B2 4/10/06 11:57 AM Page F1

Important Information and Customer Assistance

Introduction

Nothing Comes Close to a Cobra

Customer Assistance

Display and Product Features

Introduction

Nothing Comes Close to a Cobra

Xtreme Range Superheterodyne Technology

With super-fast sweep circuitry, XRS provides extra detection range and the best possible advance warning to even the fastest radar guns

Detection and Separate Alerts For:

Radar signals (X, K,Ka and Ku bands, with signal strength indicated), laser signals, Safety Alert signals, Strobe Alert signals, Spectre 1 signals, VG-2 signals

LaserEye

For 360° detection of laser and strobe signals

Instant-On Ready

Detects radar guns with “instant-on” (very fast) speed monitoring capabilities

Tone Alert or Voice Alert

With adjustable volume

DigiView Data Display

With easy-to-read alpha/numeric dot matrix text readout

City or Highway

Modes to reduce false alerts

Safety Alert

Traffic warning system distinguishes important safety alerts from other K band signals

Strobe Alert

Emergency vehicle warning system

Manual Mute or Auto Mute

A mute function of audio alerts

IntelliMute

A mute function which automatically reduces false alerts by sensing engine RPMs

Mounting

Mounts easily on windshield or dashboard

Product Features

•

Congratulations! You’ve made a smart choice by purchasing a high performance radar/laser detector from Cobra. Just look at some of the sophisticated features and capabilities your new unit includes:

Display

•

This booklet describes the simple steps for mounting and setting up your detector. It also provides helpful information about how radar and laser guns are used and how you can interpret the alerts you receive.

Alpha/Numeric Dot Matrix Text Display

See pages 6 – 16 for more information about display features.

Controls, Indicators and Connections

Introduction

English

Controls, Indicators and Connections

•

12V DC Power Jack

On-Off/

Volume Control

Allows you to adjust the

volume of the tone alerts.

IntelliMute Button

Engine RPM sensing mute function

which reduces false alerts. Button

turns IntelliMute on and off.

(Also enters IntelliMute setting mode.*)

LaserEye

For 360° detection of laser and strobe signals.

Windshield Bracket

Release Button

Mute Button

For manual mute or auto mute of audio alerts. (Also turns Voice Alert on and off.*)

* Press and hold for two seconds to

access these functions.

Windshield

Bracket Mount

WARNING

Modifications or parts substitutions not approved by Cobra Electronics Corporation may violate FCC Rules and void your authority to operate this equipment.

Dim Button

Allows you to adjust

the DigiView Data Display

brightness for easy reading.

(Also turns Spectre 1 and VG-2

alerts on and off.*)

Audio Jack

City Button

For City or Highway modes to reduce false alerts.

Speaker

AAcccceessssoorriieess OOrrddeerr IInnffoo

OOrrddeerriinngg FFrroo mm UU..SS..AA ..

Call 773-889-3087 for pricing or visit www.cobra.com.

For Credit Card Orders

Call 773-889-3087 [Press one from the main menu] 8:00 a.m. to 6:00 p.m. Central Time, Monday through Friday.

Make Check or Money Order Payable To

Cobra Electronics, Attn: Accessories Dept., 6500 West Cortland Street, Chicago, IL 60707 U.S.A.

To Order Online

Please visit our website: www.cobra.com

IItt eemm ## DD eessccrriipp ttii oonn

420-030-N-001 Straight 12V Power Cord 420-026-N-001 Coiled 12V Power Cord 545-139-N-001 Windshield Mounting Bracket CLP-2B Dual Port Power Adapter

9494- XRS 9530-D-B2 4/10/06 11:57 AM Page A2

Nothing Comes Close to a Cobra

Contents

Introduction

Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A1

Customer Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A1

Controls, Indicators and Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . A2

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A3

Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A3

Your Detector

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Highway/City Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

DigiView Data Display Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Muting an Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Auto Mute Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

IntelliMute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Voice/Tone Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Spectre 1 and VG-2 Alert Audio Settings . . . . . . . . . . . . . . . . . . . . . . . . 13

K Band & Ku Band Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Signals Detected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Audio Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Visual Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Instant-On Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Responding to Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Understanding Radar and Laser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Warranty

Limited 1-Year Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Customer Assistance

Product Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Trademark Acknowledgement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Order Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

9494- XRS 9530-D-B2 4/10/06 11:57 AM Page 1

Nothing Comes Close to a Cobra

Installation

Your Detector

Installation

Your Detector

English

Installation

•

Where to Mount Your Unit

You will get optimum performance from your detector if you Mount it at a point approximately in the center of the vehicle, as low as possible on the front windshield without obstructing the unit’s view of the road either to the front or rear. Make sure the unit is level with the road. You can also mount it directly on the dashboard.

The unit’s lens must not be blocked and the LaserEye should have a clear view out the back window to allow 360° detection.

Radar and laser signals pass through glass but not through other materials and objects. Objects that can block or weaken incoming signals include:

■

Windshield wiper blades

■

Mirrored sun screens

■

Dark tinting at the top of the windshield

■

Heated windshields currently available on some vehicles (Instaclear for Ford, Electriclear for GM.) Consult your dealer to see if you have this option.

1. Attach the rubber

cups to the bracket.

2. Make sure the rubber cups and your windshield are clean.

3. Push the bracket firmly

onto the windshield.

4. Attach the detector to the bracket. Check the angle of the unit.

5. To adjust the angle if necessary, gently push or pull on the bracket to bend it. DO NOT use the detector to bend the bracket.

6. Plug the power cord into the detector.

7. Plug the cigarette lighter adapter on the power cord into your vehicle’s cigarette lighter.

8. You can temporarily remove the detector whenever you wish by pressing the bracket release button and sliding it off the bracket.

Windshield Mounting

The LaserEye Should Have a Clear View

Windshield Mounting Dashboard Mounting

9494- XRS 9530-D-B2 4/10/06 11:57 AM Page 2

Getting Started and Settings

Getting Started

•

Your Detector

Nothing Comes Close to a Cobra

Installation

Your Detector

English

1. Place the detector on the dashboard to find a location

where the unit has a clear, level view of the road. The angle can NOT be adjusted after mounting.

2. Remove the paper backing from one side of the hookand-loop fastener.

3. Attach the pad to the dashboard at your chosen location and remove the other paper backing.

4. Attach the detector to the

hook-and-loop fastener. You can remove and reattach the unit as often as you like.

5. Plug the power cord

into the detector.

6. Plug the cigarette lighter

adapter on the power cord into your vehicle’s cigarette lighter.

Dashboard Mounting

System Ready

Power On

Testing

Voice Alert

On-Off/

Volume Control

Rotate clockwise

(away from you)

NOTE

In some vehicles, power is supplied to the cigarette lighter even while the ignition is off. If this is the case with your vehicle, you should turn off or unplug your detector when parking for lengthy periods.

To Turn On the Unit and Adjust the Audio Volume

Rotate the On-Off/ Volume control

clockwise (away from you).

Tone Voice

Visual Display

Three beeps Testing, then

three beeps

System Ready, then

Voice Alert

The display will cycle through and show the user modes.

Start-up is complete when the display continuously shows the letters indicating the current user settings (c = City mode, h = Highway mode, i = IntelliMute on)

Start-Up Complete

Settings

•

When changing the Settings on your detector, please keep in mind:

■

Buttons can have multiple functions.

■

Depending on your choice of Voice Alert or Tone Alert mode, you will hear either voice messages or tones confirming changes in settings.

■

All settings will be stored in memory when the power is turned off and recalled when the power is turned back on.

9494- XRS 9530-D-B2 4/10/06 11:57 AM Page 4
