Cobra Electronics PRO 7080 User Manual

6 BAND RADAR/LASER DETECTOR WITH EXTRA SENSORY DETECTION
®
PRO 7080
Nothing comes close to a Cobra
®
Printed in China
Part No. 480-131-P
English
Intr
oduction
Important Information And Customer Assistance
Important Information
Federal Laws Governing The Use Of Radar Detectors
It is not against federal law to receive radar transmissions with your Cobra radar/ laser detector. The Communications Act of 1924 guarantees your right to receive radio transmissions on any frequency. Local laws that contravene this Act, while illegal, may be enforced by your local law enforcement officials until and unless they are prohibited from doing so by federal court action.
Safety Alert
Use of this product is not intended to, and does not, ensure that motorists or passengers will not be involved in traffic accidents. It is only intended to alert the motorist that an emergency vehicle equipped with a Cobra Safety Alert transmitter is within range as defined by that product. Please call local fire and police departments to learn if coverage exists in your area.
Safe Driving
Motorists, as well as operators of emergency or service vehicles, are expected to exercise all due caution while using this product, and to obey all applicable traffic laws.
Security Of Your Vehicle
Before leaving your vehicle, always remember to conceal your radar detector in order to reduce the possibility of break-in and theft.
Customer Assistance
A1
English
Intr
oduction
Controls, Indicators And Connections
Intr
oduction
Display And Product Features
Intr
oduction
Table Of Contents
Controls, Indicators And Connections
Windshield
Bracket Mount
Windshield Bracket
Release Button
12V DC Power Jack
On-Off/ Volume Control
A2
English
Allows you to adjust the volume of the tone alerts.
Mute Button
For manual mute or auto mute of audio alerts.
ARNING
W
Modifications or parts substitutions not approved by Cobra Electronics Corporation may violate FCC Rules and v this equipment.
LaserEye
For 360° detection of laser and strobe signals.
Speaker
City Button
For City or Highway modes to reduce false alerts.
ity to oper
our author
oid y
ate
Display
Power Indicator
City/ Highway Mode Indicators
Introduction
Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A1
Customer Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A1
Controls, Indicators And Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . A2
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A3
Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A3
XK⁄KaLV⁄
S Cty
Your Detector
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Highway/City Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Muting An Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Auto Mute Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Radar
Indicators
VG-2 And Safety Indicators
Laser Indicator
NOTE: In This Manual
When steady, the display will
be shown:
XK⁄Ka LV⁄S Cty
Signals Detected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Product Features
Congratulations! You’ve made a smart choice by purchasing the PRO 7080 radar/laser detector from Cobra. Just look at some of the sophisticated features and capabilities your new unit includes:
Detection And Separate Alerts For:
Radar signals (X, K and Ka bands, with signal strength indicated), laser and VG-2 signals
LaserEye
For 360° detection of laser and strobe signals
Instant-On Ready
Detects radar guns with “instant-on” (very fast) speed monitoring capabilities
Tone Alerts
With adjustable volume
UltraBright Data Display
Easy-to-read with adjustable brightness
City Or Highway
Modes to reduce false alerts
Safety Alert
Traffic warning system distinguishes important safety alerts from other K band signals
Manual Mute Or Auto Mute
A mute function of audio alerts
Mounting
Mounts easily on windshield
Audio Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Visual Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Instant-On Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Responding To Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Understanding Radar And Laser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Warranty
Limited 1-Year Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Customer Assistance
Product Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Trademark Acknowledgement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Order Form . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
or dashboard
This booklet describes the simple steps for mounting and setting up your detector. It also provides helpful information about how radar and laser guns are used and how you can interpret the alerts you receive.
Nothing comes close to a Cobra
®
A3
Nothing comes close to a Cobra
®
1
our Detector
Y
Installation
our Detector
Y
Installation
Installation
Where To Mount Your Unit
You will get optimum performance from your detector if you Mount it at a point approximately in the center of the vehicle, as low as possible on the front windshield without obstructing the unit’s view of the road either to the front or rear. You can also mount it directly on the dashboard.
The unit’s lens must not be blocked and the LaserEye should have a clear view out the back window to allow 360° detection.
Radar and laser signals pass through glass but not through other materials and objects. Objects that can block or weaken incoming signals include:
n
Windshield wiper blades
n
Mirrored sun screens
n
Dark tinting at the top of the windshield
n
Heated windshields currently available on some vehicles (Instaclear for Ford, Electriclear for GM.) Consult your dealer to see if you have this option.
1. Attach the rubber
cups to the bracket.
2. Make sure the rubber cups and your windshield are clean.
3. Push the bracket firmly
onto the windshield.
2
English
Nothing comes close to a Cobra
®
3
our Detector
Y
Installation
our Detector
Y
Getting Started
1. Place the detector on the dashboard to find a location
where the unit has a clear, level view of the road. The angle can NOT be adjusted after mounting.
2. Remove the paper backing
from one (1) side of the hook-and-loop fastener.
Getting Started
To Turn On The Unit And Adjust The Audio Volume
Rotate the On-Off/ Volume control
clockwise (away from you).
Tone
Visual Display
Three (3) beeps The power indicator will light
up in the display indicating that the power is On
.
4
English
Nothing comes close to a Cobra
®
5
our Detector
Y
Settings
our Detector
Y
Settings
Settings
When changing the Settings on your detector, please keep in mind:
n
All settings will be stored in memory when the power is turned
Off and recalled when the power is turned back On.
Highway/City Mode
Setting your detector to City mode delays all X band audio alerts at lower signal strength levels. (A single beep will sound when the signal is first detected.) This will reduce false alerts while you are driving in, or near, urban areas where there are many sources for conflicting X band signals such as microwave towers and automatic door openers.
To change settings, follow the procedure listed below, which indicates what you will see and hear as you complete each step. The factory setting
Highway mode.
is
6
English
Nothing comes close to a Cobra
®
7
our Detector
Y
Detection
our Detector
Y
Detection
Detection
Signals Detected
The tables on the following pages show you the types of Signals your detector will detect, as well as the visual alerts it provides for each of them.
Audio Alerts
A distinctly different Alert tone is used for each type of signal detected (including separate tones for each laser signal). For X, K and Ka band radar signals, the tones will repeat faster as you approach the signal source. The repeat rate of the tones gives you useful information about the signal detected. (See responding to alerts on page 11.)
Visual Display
An indication of the type of signal detected will appear in the UltraBright data
Display.
During radar alerts the letters Xor K⁄Ka will appear.
XK⁄KaLV⁄
S Cty
During laser alerts the letter Lwill appear.
Laser Signal Detected
XK⁄KaLV⁄
S Cty
During VG-2 and Safety Alerts, the letters V⁄S
VG-2 Alert Signal Detected
K Signal DetectedX Signal Detected
XK⁄KaLV⁄
Safety Alert Signal Detected
S Cty
Ka Signal Detected
XK⁄KaLV⁄
will appear.
S Cty
Radar Signals And Visual Displays
Type of Signal Visual Display
X Band Radar X is Steady K Band Radar Ka Band Radar
X Signal Detected
XK⁄KaLV⁄
S Cty
K Signal Detected
XK⁄KaLV⁄
K
Ka is Steady
K
Ka is Steady
S Cty
Ka Signal Detected
XK⁄KaLV⁄
S Cty
Laser Signals And Visual Displays
Type of Signal Visual Display
LTI 20-20* L is Steady LTI Ultra-Lyte* L is Steady Kustom Signals ProLaser* L is Steady Kustom Signals ProLaser III* L is Steady
* Your detector provides 360˚ detection of these signals.
Laser Signal Detected
XK⁄KaLV⁄
S Cty
8
XK⁄KaLV⁄
English
S Cty
XK⁄KaLV⁄
S Cty
Nothing comes close to a Cobra
®
9
our Detector
Y
Detection
Safety Alert Signals And Visual Displays
Type of Signal Visual Display
Emergency Vehicles Road Hazards Trains
V
S is Steady
V
S is Steady
V
S is Steady
our Detector
Y
Detection
VG-2 Alert Signal And Visual Display
Type of Signal Visual Display
Interceptor VG-2
English
10
V
S is Steady
Description Interpretation
Tone repeats slowly at first, then speeds up rapidly.
Tone sounds one (1) time only.
Tone instantly begins repeating rapidly.
Tone repeats slowly as you approach a hill or bridge, then speeds up sharply as you reach it.
Tone repeats slowly for a short period.
Any type of laser alert. Laser alerts are
Yxercise caution
Any Safety Alert. You are nearing an
Probably police radar FULL ALERT
Probably a false alarm, but possibly pulsed radar or VG-2 nearby
Radar or VG-2 nearby has been activated suddenly
Probably police radar beyond the hill or bridge
Probably a false alarm Exercise caution
never false alarms
emergency vehicle,
Recommended Response
Exercise caution
FULL ALERT
FULL ALERT
FULL ALERT
Nothing comes close to a Cobra
®
11
our Detector
Y
Understanding Radar And Laser
our Detector
Y
Understanding Radar And Laser
Understanding Radar And Laser
Radar Speed Monitoring Systems
Three (3) band frequencies have been approved by the Federal Communications Commission (FCC) for use by speed monitoring radar equipment:
X band 10.525 GHz K band 24.150 GHz Ka band 33.400 – 36.00 GHz
Your detector detects signals in all three (3) radar bands.
VG-2
VG-2 is a “detector detector” that works by detecting low-level signals emitted by most radar detectors. Your detector does not emit signals that can be detected by VG-2, but does detect VG-2 signals and will alert you when a device is in use near your vehicle.
Safety Alert Traffic Warning System
FCC-approved Safety Alert transmitters emit microwave radar signals that indicate the presence of a safety-related concern. Depending on the frequency of the signal emitted, it can indicate a speeding emergency vehicle or train, or a stationary road hazard.
Because these microwave signals are within the K band frequency, most conventional radar detectors will detect Safety Alert signals as standard K band radar. Your detector, however, is designed to differentiate between standard K band and Safety Alert signals, and give separate alerts for each.
Safety Alert technology is relatively new. Safety Alert transmitters can be found in limited numbers in all 50 states, but the number is growing. Depending on your location, you may not receive these alerts regularly and may often encounter emergency vehicles, trains and road hazards without being alerted. As the number of transmitters increases, these alerts will become more common.
When you receive such an alert, please watch for emergency vehicles ahead of you, on cross streets and behind you. If you see an emergency vehicle approaching, please pull over to the right side of the road and allow it to pass.
LIDAR (Laser)
The correct name for the technology that most people refer to as laser is actually
LIDAR, which stands for Light Detection and Ranging.
LIDAR operates much like radar. Its signal spreads out like a radar signal, though not as widely. Unlike radar, LIDAR must have a clear line of sight to its target vehicle throughout the entire measurement interval. Obstructions such as sign posts, utility poles, tree branches, etc., will prevent valid speed measurement.
Some common questions about LIDAR include:
n Does weather have any affect on LIDAR?
Yes. Rain, snow, smoke, fog, or airborne dust particles will reduce the effective range of LIDAR and can, if dense enough, prevent its operation.
n Can LIDAR operate through glass?
Yes. Newer LIDAR guns can obtain readings through most types of glass. However, the laser pulse also can be received through glass to trigger an alarm by your detector.
n Can LIDAR operate while in motion?
No. Because LIDAR operates by line of sight, the person using it cannot drive the vehicle, aim and operate the gun all at the same time.
n Is LIDAR legal to use?
Yes. It is legal in all 50 states.
12
English
Nothing comes close to a Cobra
®
13
our Detector
Y
Maintenance And Specifications
W
arranty
Warranty And Product Service
Maintenance
Maintenance Of Your Radar Detector
Your detector is designed and built to give you years of trouble-free performance without the need for service. No routine
Maintenance is required.
If your unit does not appear to be operating properly, please follow these troubleshooting steps:
n Make sure the power cord is properly connected. n Make sure the socket of your vehicle’s cigarette lighter is clean
and free of corrosion.
n Make sure the power cord’s cigarette lighter adapter is firmly
seated in your cigarette lighter.
n Check the power cord fuse. (Unscrew the ribbed end cap
of the cigarette lighter adapter and examine the fuse. If required, replace it with a 2-amp fuse only.)
Specifications
Band And Frequencies
Band Frequencies
X Band 10.525 ± 0.050 GHz K Band 24.125 ± 0.125 GHz Safety Alert 24.070 ± 0.010 GHz
Traffic Warning 24.110 ± 0.010 GHz System 24.190 ± 0.010 GHz
Ka Band 34.700 ± 1.300 GHz Laser 910 ± 50 nm
Unit Dimensions And Weight
Dimensions* Weight*
11⁄4" x 23⁄4" x 37⁄8" 4.26 oz. (33 mm x 70 mm x 98 mm) (121 g)
* Dimensions and weight measurements are approximate.
This radar detector is covered by one or more of the following U.S. patents: 5,497,148; 5,594,432; 5,612,685; 6,078,279; 6,094,148. Additional patents may be listed inside the product or pending.
English
14
24.230 ± 0.010 GHz
Limited 1-Year Warranty
For Products Purchased In The U.S.A.
Cobra Electronics Corporation warrants that its Cobra 6 Band Radar/Laser Detectors, and the component parts thereof, will be free of defects in workmanship and materials for period of one (1) year from the date of first consumer purchase. This warranty may be enforced by the first consumer purchaser, provided that the product is utilized within the U.S.A.
Cobra will, without charge, repair or replace, at its option, defective 6 Band Radar/Laser Detectors, products or component parts upon delivery to the Cobra Factory Service Department, accompanied by proof of the date of first consumer purchase, such as a duplicated copy of a sales receipt.
You must pay any initial shipping charges required to ship the product for warranty service, but the return charges will be at Cobra’s expense, if the product is repaired or replaced under warranty.
This warranty gives you specific rights, and you may also have other rights which vary from state to state.
Exclusions: This limited warranty does not apply: 1) To any product damaged by accident.
2) In the event of misuse or abuse of the product or as a result of unauthorized alterations or repairs.
3) If the serial number has been altered, defaced or removed. 4) If the owner of the product resides
outside the U.S.A. All implied warranties, including warranties of merchantability and fitness for a particular purpose
are limited in duration to the length of this warranty. Cobra shall not be liable for any incidental, consequential or other damages; including,
without limitation, damages resulting from loss of use or cost of installation. Some states do not allow limitations on how long an implied warranty lasts and/or do not allow the exclusion
or limitation of incidental or consequential damages, so the above limitations may not apply to you.
Customer Assistance
Product Service
If you have any questions about operation or installing your new Cobra product, or if you are missing parts…
Please call Cobra first! DO NOT RETURN THIS PRODUCT TO THE STORE! See customer assistance on page A1.
If you suspect that your unit requires service, please call 773-889-3087 BEFORE shipping it to Cobra. This will ensure that you receive service as quickly as possible.
If you are asked to send your unit to the Cobra factory, please follow these steps: complete unit, including power cord. (It is not necessary to include the mounting bracket.) warranty repair, enclose some form of proof-of-purchase, such as a photocopy or carbon copy of a sales receipt. If you send the original receipt, it cannot be returned. written description of the problem you are having with your unit, plus the name and address where you want the unit returned. use the original packing materials. United Parcel Service (UPS), Federal Express, or Priority mail with delivery confirmation. Ship to: Cobra Factory Service, Cobra Electronics Corporation, 6500 West Cortland Street, Chicago, IL 60707
6) Please allow three (3) to four (4) weeks before contacting us about the status of your
U.S.A. service. Call 773-889-3087 for assistance. If your unit is under warranty, it will either be repaired or replaced upon receipt, depending on the model. If your unit is out of warranty, you will receive a letter informing you of the repair or replacement charge.
4) Pack the unit securely to prevent damage during transit. If possible,
5) Ship prepaid and insured using a traceable carrier such as
3) Enclose a typed or clearly
Nothing comes close to a Cobra
1) Send the
2) For
®
15
Customer Assistance
Order Form
Order Form
Name
Address (No P.O. Boxes)
City State/Province Zip Country
Telephone
Credit Card Number Type: r Visa r MasterCard r Discover Exp. Date
Customer Signature
Item # Description U.S.Cost Each Qty Amount
420-030-N-001 Straight 12V Power Cord 420-026-N-001 Coiled 12V Power Cord 545-139-N-001 Windshield Mounting Bracket CLP-2B Dual Port Power Adapter
Amount Shipping/Handling*
$10.00 or less
$10.01-$25.00 . . . . . $5.50
$25.01-$50.00
$50.01-$90.00 . . . . $10.50
$90.01-$130.00 . . . $13.50 $130.01-$200.00 . . $16.50
$200.01 plus . . . . . 10% of
$3.00
. . . . .
. . . . . $7.50
purchase
Tax Table
Wisconsin add 5% Indiana, Michigan,
Ohio add 6% California add 7.25% Illinois add 8.75%
*For AK, HI and PR add additional $26.95 for FedEx Next Day or
$10.95 for FedEx 2nd Day Please allow two (2) to three (3) weeks for delivery in the U.S.A. Prices subject to change without notice.
. Excludes weekends and holidays shipments.
U.S. Subtotal
(Tax if Applicable)
Shipping/Handling
Total
Ordering From U.S.A.
Call 773-889-3087 for pricing or visit www.cobra.com.
For Credit Card Orders
Complete and return this order form to fax number 773-622-2269. Or call 773-889-3087 [Press one (1) from the main menu] 8:00 a.m. to 6:00 p.m. CT, Monday through Friday.
Make Check or Money Order Payable To
Cobra Electronics, Attn: Accessories Dept., 6500 West Cortland Street, Chicago, IL 60707 U.S.A.
To Order Online
Please visit our website: www.cobra.com
Nothing comes close to a Cobra
®
17
The Cobra line of quality products includes:
CB Radios microTALK Radar/Laser Detectors Safety Alert Accessories GPS (Global Positioning System) HighGear CobraMarine Power Inverters
®
Radios
®
Traffic Warning Systems
®
Accessories
VHF Radios
For more information or to
order any of our products,
please visit our website:
www.cobra.com
Nothing comes close to a Cobra
®
English
Loading...
