Making Life Easier & Safer

Owner’s Manual

Nothing Comes Close To A Cobra

™

English

2-WAY RADIO MODEL

PR3000DX

Printed in Philippines

Part No. 480-049-P

Owner’s Manual

Nada se compara a Cobra

™

Español

PR3000 DX

Printed in Philippines

Part No. 480-049-P

Introduction

Staying in touch with your family and friends is convenient and easy when using your microTALK

radio. Some of the many uses you will discover include:

Communicating with others while hiking, biking, and working; keeping

track of family and friends at a crowded public event; checking with travel companions in another car; talking with neighbors; arranging meeting spots with others while shopping at the mall.

Secure your microTALK

radio while on the go.

Carrying your microTALK®radio with you is

easy when using the belt clip or wrist strap. The belt clip easily attaches to your belt, purse,

or backpack. Simply squeeze the clip and place it where you prefer.

For Assistance In the U.S.A.

In this user’s manual, you should find all the information you need

to operate your microTALK

radio. If you require further assistance

after reading this manual, Cobra

Electronics offers the following

customer assistance services:

Automated Help Desk

English only. 24 hours a day, 7 days a week 773-889-3087 (phone).

Customer Assistance Operators

English and Spanish. 8:00 a.m. to 6:00 p.m. CT,

Monday through Friday (except holidays) 773-889-3087 (phone).

Questions

English and Spanish. Faxes can be received at 773-622-2269 (fax).

Technical Assistance

English only. www.cobra.com (on-line: Frequently Asked Questions).

English and Spanish. productinfo

@cobra.com (e-mail).

For Assistance Outside the U.S.A.

Contact Your Local Dealer

Belt Clip

Wrist Strap

Customer Assistance

6500 West Cortland Street

Chicago, Illinois 60707 USA

www.cobra.com

RADIO

BIDIRECCIONAL

MODEL

Español

Una vida más sencilla y segura

Introducción

Es muy fácil y práctico mantenerse en contacto con su familia y

sus amigos cuando utiliza un radio microTALK

. Usted descubrirá

gran número de aplicaciones para el radio, como las siguientes:

comunicación con otras personas en excursiones, paseos el bicicleta o en el

trabajo; contacto con la familia y los amigos en concurridos eventos públicos,

comunicación con compañeros de viaje en otro automóvil; conversaciones

con los vecinos; ponerse de acuerdo en un punto de reunión durante una

visita al centro comercial.

Transporte el radio

microT ALK

con seguridad.

Es muy fácil transportar el radio microTALK

con

la pinza para cinturón o la correa para la muñeca.

La pinza se sujeta fácilmente al cinturón, un bolso

o una mochila. Sólo tiene que oprimir la pinza y

colocarla donde quiera.

Ayuda en los EE.UU.

En este manual para el usuario encontrará toda la información necesaria para

usar el radio microTALK

. Si después de leer este manual requiere ayuda

adicional, Cobra

Electronics ofrece los siguientes servicios de apoyo a clientes:

Centro automatizado de ayuda

Únicamente inglés. Disponible las 24 horas del día, todos los días del año,

llamando por teléfono al 773-889-3087.

Operadores de ayuda al cliente

Inglés y español. Disponibles de 8:00 a.m. a 6:00 p.m., hora del centro de

EE.UU., de lunes a viernes (excepto días festivos), llamando por teléfono al

773-889-3087.

Preguntas

Inglés y español. Puede enviar sus preguntas por fax al 773-622-2269.

Ayuda técnica

Únicamente inglés. www.cobra.com (en Internet: preguntas más frecuentes).

Inglés y español. Corre electrónico: productinfo@cobra.com

Ayuda fuera de los EE.UU.

Comuníquese con un distribuidor de productos Cobra

de su localidad.

6500 West Cortland Street

Chicago, Illinois 60707 USA

www.cobra.com

Pinza para el cinturón

Correa para la muñeca

Ayuda a clientes

Battery

Compartment

Battery Door

Latch

BeltClip

Wrist Strap

Connector

Operation

Customer Assistance

Warranty

Nothing comes close to a Cobra

™

Introduction

English

Product Features

English

Product Features

Introduction

Backlit

LCD Display

Channel

Up/Down

Buttons

Speaker/ Microphone

Call

Button

Mode

Button

Antenna

Key Lock

Button

Hi•Low

Power Button

External Speaker/ Microphone Jack

Light/

Max Range

Button

Talk

Button

On/Off

Volume

Knob

Charger

Jack

Introduction

Backlit LCD Display

Important FCC Licensing Information

This radio operates on General Mobile Radio

Service (GMRS) frequencies which require a Federal Communications Commission (FCC) license. See page 18 for licensing and other related information.

Receive/ Transmit

Tow er Icon

Hi•Low

Power Icon

Lock Icon

Keystroke T ones Icon

Call T ones and VibrAlert™Icon

Roger Beep Icon

Signal Strength

Meter Icon

Battery Level

Indicator

Main Channel

Numbers

Power Saver Icon

CTCSS Privacy Code Numbers

Scan Icon

Vox Icon

Features

• Two-Way Radio with up to a six (6)

mile (10 km) range

•

22 Channels

(7 shared with

FRS/GMRS, 7 FRS only, 8 GMRS only)

•

38 PRIVACY

Codes

• Hands-Free

Operation (VOX)

• VibrAlert

Silent Paging

• Signal

Strength Meter

• Scan (channel, privacy

code)

•

Selectable

Hi•Low Power

(in GMRS)

•

Backlit

LCD Display

• Call Alert (10 selectable

tones)

•

Lock

• Speaker/

Microphone Jack

• “Roger Beep” (selectable On/Off)

•

Battery/Power Saver

• Keystroke Tones (selectable On/Off)

•

Auto Squelch

• Maximum Range

Extender

• Belt Clip

• Wrist Strap

Caring for Your microTALK®Radio

•

Your microTALK®radio will give you years of trouble-free service if

cared for properly. Handle the radio gently. Keep the radio away from dust. Never put the radio in water or in a damp place. Avoid exposure to extreme temperatures.

Batteries

•

To Install or Replace Batteries:

1. Remove belt clip by releasing belt clip

latch and sliding clip up.

2. Pull down on the

Battery Door Latch to

remove the battery compartment cover.

3. Insert four (4) AAA batteries. (Always use high quality alkaline batteries.) Position batteries according to polarity markings.

4. Replace Battery Compartment cover and belt clip.

Contact your local Cobra

dealer

or Cobra

directly for optional

charger accessories.

Insert Batteries

Pull Down Lock Latch

Remove Belt Clip

The Basics to Get You Started

Your microTALK®radio is easy to use. To get started, simply:

1. Rotate the On/Off Volume knob to turn On your radio.

2. Press the

Channel Up or Channel Down

button to select a channel.

Both radios must be tuned to the same channel to communicate.

3. Press and hold the

Talk button while

speaking into the microphone.

4. When finished talking, release the

Talk

button and listen for a response.

Customer Assistance WarrantyIntroduction

Nothing comes close to a Cobra

™

Operation

English

Using Y our Radio

Turning On Your microTALK®Radio

•

To Turn On Your Radio:

1. Rotate the On/Off Volume knob clockwise

to turn On your radio and adjust the volume. A series of tones will indicate the radio is On.

Your microTALK

radio is now in Standby Mode, ready to receive transmissions. The radio is always in

Standby Mode, except when the

Talk, Call or Mode buttons are pressed.

Battery Low

•

Your microTALK®radio has a battery level meter

that shows when battery power is decreasing. The greater the number of ascending bars visible, the stronger the battery level. When the battery level is low, the last bar and “bALo” will flash indicating your batteries should be replaced or recharged, if using rechargeable batteries.

Auto Battery Save

•

Your microTALK®radio has a unique circuit

designed to extend battery life. If there are no transmissions within ten (10) seconds, the radio will automatically switch to

Battery

Save Mode

and Power Saver icon will flash

in the display. This will not affect the radio’s ability to receive incoming transmissions.

Communicating with Another Person

•

To Talk To Another Person:

1. Press and hold the Talk button.

2. With the microphone about two (2)

inches (5 cm) from your mouth, speak in a normal voice.

3. Release the

Talk button when you are

finished talking and listen for a response.

You cannot receive incoming calls while pressing the

Talk button.

Both radios must be tuned to the same channel to communicate.

Scrolling Through

the Mode Function

•

By scrolling through the Mode function, you will

be able to select or turn On preferred features of your microTALK

radio. When scrolling through the Mode function, your radio features will be displayed in the same predetermined order:

Set Privacy Codes Set VOX On/Off Set VOX Sensitivity Level Set Channel Scan Set Privacy Code Scan Set VibrAlert

and/or Call Alert Set Call Tones Set “Roger Beep” On/Off Set Keystroke Tones On/Off

Channels

•

To Select a Channel:

1. With the radio On, select any of the

22 channels by pressing the

Channel Up

or Channel Down button.

Both radios must be tuned to the same channel to communicate.

Channels 1 through 7 are shared with FRS/ GMRS. Channels 8 through 14 are FRS only. Channels 15 through 22 are GMRS only.

See page 17 for FRS/GMRS frequency allocations and compatibility charts.

On/Off Power

Battery Low

Battery Save Mode

Talk Button

Mode Button

Channel Button

Channel Number

Operation

2 inches (5 cm) From Mouth

Customer Assistance WarrantyIntroduction

Nothing comes close to a Cobra

™

Operation

English

Using Y our Radio

CTCSS Privacy Codes

•

CTCSS (Continuous Tone Coded Squelch System)

is an advanced tone coding system allowing you to select one of 38 privacy codes to reduce interference from other users on the channel.

If you are using a privacy code, both radios must be tuned to the same channel and privacy code to communicate. Each channel will remember the last privacy code you selected.

To Select a Privacy Code:

1. After selecting a channel, press the Mode button until the small numbers next to the

channel number flash on the LCD.

2. Press the

Channel Up or Channel Down button

to select a privacy code. You can hold the

or Down button for fast advance.

3. When your desired privacy code is displayed: a. Press the

Mode button to enter the new

setting and proceed to other functions.

b. Press the

Lock button to enter the new

setting and return to

Standby Mode.

c. Do not press any buttons for 15 seconds

to enter the new setting and return to

Standby Mode.

Listening for a Response

•

When You are Finished Talking:

1. Release the Talk button to receive incoming

transmissions. Your microTALK

radio is

always in

Standby Mode while the Talk or

Call buttons are not pressed.

Volume

•

To Adjust the Volume:

1. Rotate the On/Off Volume knob.

Call Button

•

To Alert Another Person That You Are Calling:

1. Press and release the Call button.

The other person will hear a two (2) second call tone. You cannot send or receive transmissions during the two (2) second call tone.

See page 13 on how to select between ten (10) call tone settings.

Selectable High•Low Power Output

•

When in close proximity to another party or during

favorable conditions, you can switch from High to Low Power to extend battery life.

This feature applies to GMRS channels 1 through 7 and 15 through 22 only. Channels 8 through 14 operate exclusively on Low Power.

To Switch from High to Low Power:

1. Press and release the Hi•Low button.

When in High Power and using channels 1 through 7 and 15 through 22, the

Hi icon

will be visible in the LCD display. When in Low Power and when using channels

8 through 14, the

Low icon will be visible in

the LCD display.

Mode Button

Channel Button

Privacy Code

Listening

Volume Knob

Call Button

Hi•Low Button

Low Power Icon

Hi Power Icon

Operation

38 Privacy Codes

Customer Assistance WarrantyIntroduction

Nothing comes close to a Cobra

™

Operation

English

Using Y our Radio

Voice Activated Transmit (VOX)

•

In VOX Mode, your microTALK®radio can be

used “hands-free,” automatically transmitting when you speak. You can set the VOX sensitivity level to fit the volume of your voice and avoid transmissions triggered by background noise.

To Turn VOX Mode On or Off:

1. Press the Mode button until the VOX icon

flashes on the LCD. The current On or Off setting is displayed.

2. Press the

Channel Up or Channel Down

button to turn VOX On or Off.

3. a. Press the

Mode button to enter the

selected On or Off setting and proceed to other functions.

b. Press the

Lock button to enter the

selected On or Off setting and return to

Standby Mode.

To Set the Sensitivity:

1. Press the Mode button until the VOX

icon flashes and the current sensitivity level is displayed.

The current sensitivity level is displayed with letters “LE” and a number 1 through 5, 5 being the most sensitive level and 1 being the least sensitive level.

2. Press the

Channel Up or Channel Down

button to change the setting.

3. a. Press the

Mode button to enter the selected

setting and proceed to other functions.

b. Press the

Lock button to enter the selected

setting and return to

Standby Mode.

VOXSensitivity Level

Operation

VOX Icon

Mode Button

Channel Button

Scan

•

Your microTALK®radio can automatically scan

main channels (1 through 22) or the privacy codes (00 through 38) within one (1) main channel.

To Scan Main Channels:

1. Press the Mode button until the Scan icon and

the main channel number flashes on the display.

2. Press the

Channel Up or Channel Down button

to begin scanning the main channels.

The radio ignores privacy codes while scanning main channels.

3. The Scan icon will continue to be displayed when scan is On. Your radio will continue to scan all main channels and stop if an incoming transmission is detected. Your radio will remain on that channel for ten (10) seconds. During this time, you can:

a. Press and hold the

Talk button to communicate

with others. Your radio will remain on that channel and return to

Standby Mode.

b. Press the

Channel Up or Channel Down

button to resume scanning channels.

c. Press the

Mode button to proceed to

privacy code scanning (see page 12 for further details).

If you press the

Talk button while scanning

and not within ten (10) seconds of receiving transmission, you will transmit on the last channel you transmitted or received on.

If you do not press any button within ten (10) seconds, your radio will automatically resume scanning main channels.

Scanning Channels

Mode Button

Channel Button

Customer Assistance WarrantyIntroduction

Nothing comes close to a Cobra

™

Operation

English

Using Y our Radio

To Scan Privacy Codes:

1. While in Standby Mode, press the Channel Up or Channel Down button to choose the main

channel you wish to scan.

2. Press the

Mode button until the Scan icon and

the privacy code number flashes on the display.

3. Press the

Channel Up or Channel Down button

and your radio will begin scanning privacy codes within the main channel you selected.

4. The Scan icon will continue to be displayed when scan is On. Your radio will continue to scan privacy codes and stop as incoming transmission is detected. Your radio will remain on that channel and privacy code for ten (10) seconds. During this time, you can:

a. Press and hold the

Talk button to

communicate with others. Your radio will remain on that channel and privacy code and return to

Standby Mode.

b. Press the

Channel Up or Channel Down

button to resume scanning privacy codes.

c. Press the

Mode button to proceed to next

available Mode function.

If you press the

Talk button while scanning

(see page 11 for further details) and not within ten (10) seconds of receiving transmission, you will transmit on the last channel you transmitted or received on.

If you do not press any button within ten (10) seconds, your radio will automatically resume scanning privacy codes.

Channel Button

Mode Button

Select Channel

Scan Privacy Codes

Operation

VibrAlert®and Call Tones

•

Your microTALK®radio can alert you to

incoming signals by sounding an audible call tone, by vibrating silently, or both.

To Change Call Settings:

1. Press the Mode button until the Call Setting

icon flashes on the LCD. The current setting (Vibrate + Ring, Vibrate Only, or Ring Only) is displayed.

2. Press the

Channel Up or Channel Down

button to change the call setting.

3. a. Press the

Mode button to enter the new

setting and proceed to other functions.

b. Press the

Lock button to enter the new

setting and return to

Standby Mode.

10 Call Tone Settings

•

You can choose between ten (10) different call

tone settings to transmit a unique call alert.

To Change a Call Tone Setting:

1. Press the Mode button until the letter “C”

and the current call tone number (1 through

10) is displayed. The current call tone will sound for one (1) second.

2. Press the

Channel Up or Channel Down

button to hear the other call tone settings.

3. a. Press the

Mode button to enter the new

setting and proceed to other functions.

b. Press the

Lock button to enter the new

setting and return to

Standby Mode.

Mode Button

VibrAlert®+ Ring

VibrAlert®Only

Ring Only

Channel Button

Mode Button

Call Tone Setting

Channel Button

English

Using Y our Radio

Customer Assistance WarrantyIntroduction

Nothing comes close to a Cobra

™

Operation

“Roger Beep” Confirmation Tone

•

Your listener will hear an audible tone when you

release the

Talk button. This alerts the other party

that you are finished talking and it is

OK for them

to speak. This feature can be turned On or Off.

To Turn “Roger Beep” On or Off:

When turning On your microTALK®radio

for the first time, “Roger Beep” will be On.

1. Press the

Mode button until the Roger

Beep icon flashes on the LCD. The current On or Off setting is displayed.

2. Press the

Channel Up or Channel Down button to select “Roger Beep” On or Off.

3. a. Press the

Mode button to enter the new

setting and proceed to other functions.

b. Press the

Lock button to enter the new

setting and return to

Standby Mode.

The setting you select will be saved when you turn your radio Off and On again. When the “Roger Beep” is On, the “Roger Beep” icon will be displayed.

Keystroke Tones

•

With Keystroke Tones turned On, your radio

will sound beeps each time you press a button or change a setting.

To Change Keystroke Tones:

1. Press the Mode button until the Keystroke

Tones icon flashes on the LCD. The current On or Off setting is displayed.

2. Press the

Channel Up or Channel Down

button to turn Keystroke Tones On or Off.

3. a. Press the

Mode button to enter the new

setting and proceed to other functions.

b. Press the

Lock button to enter the new

setting and return to

Standby Mode.

Operation

Mode Button

Roger Beep On

Channel Button

Mode Button

Keystroke Tones On

Channel Button

Display Illumination

•

To Illuminate Your Display:

1. Press and release the Light/Max Range button

to illuminate the display for ten (10) seconds.

Auto Squelch/Maximum Range

•

Your microTALK®radio is equipped with Auto Squelch,

which automatically shuts Off weak transmissions and unwanted noise due to terrain, conditions, or if you’ve reached your maximum range limit.

You can temporarily turn Off Auto Squelch or turn On Maximum Range Extender, allowing all signals to be received and extending the maximum range of your radio.

To Temporarily Turn Off Auto Squelch:

1. Press the Light/Max Range button less

than five (5) seconds.

If you hear two (2) beeps, you have turned the Maximum Range Extender On (see below).

To turn Maximum Range Extender On:

1. Press and hold the Light/Max Range button

for at least five (5) seconds until you hear two (2) beeps which indicates the Maximum Range Extender is On.

To Turn Maximum Range Extender Off:

1. Press and release the Light/Max Range button or change channels.

Lock Function

•

The Lock button locks the Channel, Mode, and Hi•

Low Power

buttons to prevent accidental operation.

To Turn the Lock Button On or Off:

1. Press and hold the Lock button for

two (2) seconds.

A double beep sound is used to confirm your Lock On or Off request. When in

Lock Mode, the Lock icon will be displayed.

Light/Max Range

Lock Button

Lock Mode

Customer Assistance WarrantyIntroduction

Nothing comes close to a Cobra

™

Operation

General Specifications

•

Nominal

Unit

Nominal

Unit

C.Transmitter

1. Power

GMRS . . . . . . . . . . . . . . . . . . . .W 2

FRS Only . . . . . . . . . . . . . . . . .mW 500

2. Carrier Frequency Stability . . . ±Hz 500

3. Modulation Limiting . . . . . . . . KHz 2.5

4. Carrier Attack Time . . . . . . . . . mS 80

5. Audio Frequency Response

@ 300 HZ . . . . . . . . . . . . . . . . . dB -12

@ 2500 HZ . . . . . . . . . . . . . . . . dB +6

6. Audio Distortion . . . . . . . . . . . . % 3

7. Hum Noise . . . . . . . . . . . . . . . . dB 30

8. Transient Frequency Behavior

a) TX On . . . . . . . . . . . . . . . . . mS 30

b) TX Off . . . . . . . . . . . . . . . . . mS 5

A. FRS/GMRS

Frequency Allocation and Compatibility

Important: Please note that Cobra®GMRS

models with 15 channels may designate different channel numbers for the same frequency.For example, a Cobra®15 channel GMRS model would need to be tuned to channel 11 in order to communicate with a 22 channel GMRS tuned to channel 15. Please refer to the chart below for channel/ frequency number compatibility.

A = Channel No. For

22 Channel GMRS Models

B = Channel No. For 15

Channel GMRS Models C = Type of Radio Service D = Frequency in MHz E = Power in Watts

a = 2.0/0.5 (selectable)

b = 0.5

A BC D E

1 1 FRS/GMRS 462.5625 a

2 2 FRS/GMRS 462.5875 a 3 3 FRS/GMRS 462.6125 a 4 4 FRS/GMRS 462.6375 a 5 5 FRS/GMRS 462.6625 a 6 6 FRS/GMRS 462.6875 a 7 7 FRS/GMRS 462.7125 a 8 FRS 467.5625 b

9 FRS 467.5875 b 10 FRS 467.6125 b 11 FRS 467.6375 b 12 FRS 467.6625 b 13 FRS 467.6875 b 14 FRS 467.7125 b 15 11 GMRS 462.5500 a 16 8 GMRS 462.5750 a 17 12 GMRS 462.6000 a 18 9 GMRS 462.6250 a 19 13 GMRS 462.6500 a 20 10 GMRS 462.6750 a 21 14 GMRS 462.7000 a 22 15 GMRS 462.7250 a

B. Receiver

1. Sensitivity

For 12 DB SINAD . . . . . . . . . . dBm -121

For Call Signal Detection . . . . dBm -121

2. Max. Audio Output

@10% THD . . . . . . . . . . . . . . . mW 200

3. Max. S/N Ratio

@ 1mV RF Input . . . . . . . . . . . dB 50

4. Squelch

a) Sensitivity . . . . . . . . . . . . . . dBm -121

b) Attack Time . . . . . . . . . . . . . mS 150

c) Closing Time . . . . . . . . . . . . mS 200

5. Audio Frequency Response

@ 300 HZ . . . . . . . . . . . . . . . . . dB -3

@ 2500 HZ . . . . . . . . . . . . . . . . dB -10

6. Signal Displacement BW . . . +/-KHz 5

7. Adjacent Channel Rejection . . . dB 60

8. Intermodulation Rejection . . . . dB 65

9. Spurious Response Rejection . dB 55

D.Power Supply

1. Battery Life (5:5:90 RATIO)

With Alkaline Batteries . . . . . . . HR 24

2. Battery Operating Range . . . . . . V 4.2 - 6.0

Nominal

Unit

English

Using Y our Radio

Speaker/Microphone Jack

•

Your microTALK®radio can be fitted with an

external Speaker/Microphone, freeing your hands for other tasks. See page 20 for optional accessories ordering information. Only Cobra

authorized accessories are recommended.

To attach your Speaker/Microphone:

1. Open the Speaker/Microphone tab on

top of your microTALK

radio.

2. Insert the plug into the

Speaker/

Microphone

jack.

Signal Strength Meter

•

Your microTALK®radio has a signal strength

meter that shows the strength of your incoming and outgoing transmissions. The ascending bars next to the signal strength indicate the strength of the signal. The greater the number of bars visible, the stronger the signal. The fewer number of bars visible, the weaker the signal.

microTALK®Range

•

Your microTALK®radio has a range of

up to six (6) miles (10 km). Your range will vary depending on terrain and conditions.

In flat, open country your radio will operate at maximum range.

Buildings and foliage in the path of the signal can reduce the range of the radio.

Dense foliage and hilly terrain will further reduce the range of the radio.

On FRS channels 8 through 14, your radio automatically switches to low power, which will limit the range the radio can communicate.

Remember, you can achieve maximum range by using Maximum Range Extender. See page 15 for details.

Speaker/Microphone

Signal Strength

Operation

Maximum Range

Reduced Range

Operation WarrantyIntroduction

Nothing comes close to a Cobra

™

Customer Assistance

English

Licensing,Assistance &Warranty

IMPORTANT NOTICE: FCC LICENSE REQUIRED

This two-way radio operates on GMRS (General Mobile Radio Service) frequencies which

require an FCC (Federal Communications Commission) license. A user must be licensed prior to operating on channels 1 through 7 or 15 through 22, which comprise the GMRS channels of this radio. Serious penalties could result for unlicensed use of GMRS channels, in violation of FCC rules, as stipulated in the Communications Act’s Sections 501 and 502 (amended).

Licensed users will be issued a call sign by the FCC, which should be used for station identification when operating this radio. GMRS users should also cooperate by engaging in permissible transmissions only, avoiding channel interference with other GMRS users, and being prudent with the length of their transmission time.

For licensing information and application forms, please call the FCC Hotline at 800-418-FORM. Request form #159 and form #605. Questions regarding the license application should be directed to the FCC at 888-CALL-FCC. Additional information is available on the FCC’s website at www.fcc.gov.

Safety Information for microTALK®Radios

Your wireless handheld portable transceiver contains a low power transmitter. When the Talk

button is pushed, it sends out radio frequency (RF) signals. The device is authorized to operate at a duty factor not to exceed 50%. In August 1996, the Federal Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for handheld wireless devices.

Important:

To maintain compliance with the FCC’s RF guidelines, hold the transmitter at least 2 inches

(5 centimeters) from your face and speak in a normal voice, with the antenna pointed up and away. If you wear the handset on your body while using the headset accessory, use only the Cobra®supplied belt clip for this product and ensure that the antenna is at least 1 inch (2.5 centimeters) from your body while transmitting. If the distance between the antenna and the body is LESS THAN 1.0 inch (2.5 cm), DO NOT USE THIS DEVICE IN THE BODY WORN CONFIGURATION. Use only the supplied antenna. Unauthorized antennas, modifications, or attachments could damage the transmitter and may violate FCC regulations.

Normal Position:

Hold the transmitter approximately 2 inches from your face and speak in a normal voice,

with the antenna pointed up and away.

Customer Assistance

If you have any questions about operation or installing your new Cobra

product, or if you are missing parts…

Please call Cobra

first! DO NOT RETURN THIS PRODUCT

TO THE STORE! See customer service on page 2.

Product Service Questions

If your product should require factory service, please call Cobra®first before sending your radio.

This will ensure the fastest turn-around time on your repair. You may be asked to send your radio to the Cobra®factory. It will be necessary to furnish the following to have the product serviced and returned.

1) For Warranty Repair include some form of proof-of-purchase, such as a mechanical reproduction or carbon of a sales receipt. If you send the original receipt, it cannot be returned; 2) Send the entire product; 3) Enclose a description of what is happening with the radio. Include a typed or clearly printed name and address of where the radio is to be returned; 4) Pack radio securely to prevent damage in transit. If possible, use the original packing material; 5) Ship prepaid and insured by way of a traceable carrier such as United Parcel Service (UPS) or First Class Mail to avoid loss in transit to Cobra®Factory Service, Cobra®Electronics Corporation, 6500 West Cortland Street, Chicago, Illinois 60707 USA; 6) If the radio is in warranty, upon receipt of your radio it will either be repaired or exchanged depending on the model. Please allow approximately 3 – 4 weeks before contacting Cobra®for status. If the radio is out of warranty, a letter will automatically be sent informing you of the repair charge or replacement charge. If you have any questions, please call

773-889-3087 for assistance.

Limited 1-Year W arrantyFor Products Purchased in the U.S.A.

Cobra®Electronics Corporation warrants that its Cobra®GMRS Radios, and the component parts

thereof, will be free of defects in workmanship and materials for a period of one (1) year from the date of first consumer purchase. This warranty may be enforced by the first consumer purchaser, provided that the product is utilized within the U.S.A. Cobra®will, without charge, repair or replace, at its option, defective GMRS radios, products or component parts upon delivery to the Cobra

Factory Service department, accompanied by proof of the date of first consumer purchase, such as a duplicated copy of a sales receipt. You must pay any initial shipping charges required to ship the product for warranty service, but the return charges will be at Cobra®’s expense, if the product is repaired or replaced under warranty. This warranty gives you specific legal rights, and you may also have other rights which may vary from state to state.

Exclusions: This limited warranty does not apply: 1) To any product damaged by accident;

2) In the event of misuse or abuse of the product or as a result of unauthorized alterations or repairs; 3) If the serial number has been altered, defaced, or removed; 4) If the owner of the product resides outside the U.S.A.

All implied warranties, including warranties of merchantability and fitness for a particular purpose are limited in duration to the length of this warranty. Cobra®shall not be liable for any incidental, consequential or other damages; including, without limitation, damages resulting from loss of use or cost of installation. Some states do not allow limitations on how long an implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations may not apply to you.

For products purchased outside the U.S.A., please contact your local dealer for

warranty information.

Warranty

This device complies with part 15 of the FCC Rules. Operation is subject to

the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Warnings:Replacement or substitution of transistors, regular diodes or other parts of a unique nature, with parts other than those recommended by Cobra®may cause a violation of the technical regulations of part 95 of the FCC Rules, or violation of type acceptance requirements of part 2 of the Rules.

English

Accessories & Order Form

Español

Customer Assistance

Name

Address (No P.O.Boxes)

City State/Province Zip Country

Telephone

Credit Card Number Type: ❒Visa ❒ Mastercard ❒ Discover Exp.Date

Customer Signature

Item # U.S. Cost Each Qty Amount

U.S. Subtotal

(Tax if Applicable)

Shipping/Handling

Total

Optional Accessories

You can find accessories at your local Cobra®dealer,

or in the U.S.A. you can order directly from Cobra.

Ordering From U.S.

Call 773-889-3087 for pricing or visit www.cobra.com. For credit card orders, complete and return this order

form to fax number 773-622-2269. Or call 773-889-3087 (Press 1 from the main menu) 8:00 a.m. to 6:00 p.m. CT, Monday through Friday.

Make check or money order payable to:

Cobra

Electronics, Attn: Accessories Dept.

6500 West Cortland Street, Chicago, IL 60707 USA

To order online, please visit our website: www.cobra.com

The Cobra

line of quality products includes:

CB Radios

microTALK

Radios Radar/Laser Detectors Safety Alert

Traffic

Warning Systems Accessories GPS (Global

Positioning System) HighGear

™

Accessories

Amount Shipping/Handling*

$10.00 or less . . . . . $3.00

$10.01-$25.00 . . . . . $5.50

$25.01-$50.00 . . . . . $7.50

$50.01-$90.00 . . . . $10.50

$90.01-$130.00 . . . $13.50 $130.01-$200.00 . . $16.50

$200.01 plus . . . . . 10% of

purchase

Tax Table

Ohio, Wisconsin add 5%

Indiana, Michigan add 6% Illinois add 8.75%

*For AK, HI and PR add additional $26.95 for FedEx Next Day or

$10.95 for FedEx 2nd Day. Excludes weekends and holidays shipments. Please allow 2-3 weeks for delivery in the U.S. Prices subject to change without notice.

•

Formularios de

pedidos y accesorios

Ayuda a clientes

Nombre

Dirección (no se aceptan apartados postales)

Ciudad Estado o provincia Código postal País

Teléfono

Número de tarjeta de crédito Tipo:❒Visa ❒ Mastercard ❒ Discover Fecha de vencimiento

Firma del cliente

Núm. artículo Costo unitario en EE.UU. Cantidad Importe

Subtotal en EE.UU.

(Impuesto,

de ser aplicable)

Manejo y envío

Total

Accesorios optativos

Encontrará accesorios de alta calidad con los distribuidores

Cobra

de su localidad. En Estados Unidos, también puede

colocar su pedido directamente con Cobra

Pedidos en los EE.UU.

Llame al 773-889-3087 para conocer los precios o visite

www.cobra.com.

Para pedidos con tarjeta de crédito,

llene este formulario de pedidos y envíelo por fax al

773-622-2269. También puede llamar al 773-889-3087

(marque 1 en el menú principal) de 8:00 a.m. a 6:00 p.m.,

hora del centro de EE.UU., de lunes a viernes.

Elabore el cheque o giro monetario a la orden de:

Cobra

Electronics, Attn: Accessories Dept.

6500 West Cortland Street, Chicago, IL 60707 USA

Para efectuar pedidos vía Internet,

visite nuestro sitio en www.cobra.com

La línea de

productos de

calidad Cobra

también incluye:

Radios de banda

ciudadana (CB)

radios microTALK

detectores de

radar y láser

sistemas de

advertencia de

tráfico Safety Alert

GPS

accesorios HighGear

™

Importe Manejo y envío*

$10,00 o menos. . . . $3,00

$10,01-$25,00 . . . . . $5,50

$25,01-$50,00 . . . . . $7,50

$50,01-$90,00 . . . . $10,50

$90,01-$130,00 . . . $13,50

$130,01-$200,00 . . $16,50

$200,01 plus. . . . . 10% de

la compra

Tabla de impuestos

Ohio y Wisconsin, agregue el 5%

Indiana y Michigan, agregue el 6%

Illinois, agregue el 8,75%

*Para envíos a Alaska, Hawaii y Puerto Rico, agregue $26,95 para envíos

por FedEx para el día siguiente o $10,95 para envíos por FedEx para el

día subsiguiente. Excluye los fines de semana y días festivos.

Plazo de entrega dentro de los EE.UU. será entre 2 y 3 semanas.

Los precios están sujetos a cambios sin aviso previo.

•

Cobra Electronics PR3000 Users manual

Specifications and Main Features

Frequently Asked Questions

User Manual
