Cobra DC1130 User Manual

DC1130

User Manual

Digital Camera

Off load images within a week or less

Keep battery charged

1

PROFILE OVERVIEW

SYSTEM REQUIREMENT

- Microsoft win98/2000/NT/ME/XP/VISTA operation system

- 125MB or above free hard disk space, 32MB or more ROM

- Usable USB interface and CD-ROM

- Color Monitor with at least 800 x600 24 net character or above

GETTING STARTED

This camera is equipped with standard accessories including instruction CD
and USB cable. The following sections explain how to use them on the camera.

POWER SUPPLY

Built-in li-ion battery.

TO RECHARGE THE BUILT-IN LI-ION BATTERY

Precautions

AUTOMATIC SHUT OFF FEATURE

To save battery power, the camera will automatically shut off when not used after 30 seconds.

30 seconds.

Digital Camera DC1130

Thank you for purchasing the DC1130 digital camera. This camera takes still, video,
and acts as a PC Webcam This camera is equipped with a 4M*16b built-in SCRAM.
Through the USB Cable provided, you can download the captured images to your
computer, or use the camera as a webcam for face-to-face online chat with your
friends the internet.

Always download the images from camera before the battery discharged, otherwise, the images will be deleted
automatically.

Connect camera to PC by the USB cable provided. When the battery is being charged, the indicator turns Red.
When the battery is fully charged, the indicator will be off.

2

INSTALLATION OF DRIVER

2. Installation of Driver

TURNING ON / OFF CAMERA

1.Press MODE button to turn on the camera ,the power indicator light will turn green .

2.Press the "Mode " button within 3 seconds to turn off the camera ,or the camera will automatically turn off
after 30 seconds without operation, the power indicator light will turn off .

Main Function & Settings

Press MODE button to turn on camera, then press MODE button again, you will see five icons on .
screen: the first for capturing mode ,second for photos resolutions ,third for compress files ,fourth
for Light frequency , fifth for delete all .

Main Function

Select the first icon to set up capturing mode (include still photos / video clip / self-time /

continue-capturing mode ) as following.

○ STILL PHOTOS MODE

1. press "Shutter" button to change icon into STILL PHOTOS mode ,press "MODE" button
to confirm.

Click <Install Camera Drive> and follow the step-by-step instructions to complete installation. After successful
installation of driver, restart your computer. A "Precision 801 V4" folder will appear on your desktop.

1. Make sure the camera is connected to your computer. Load the software CD to your PC.

3

2.Press the "Shutter" button to take photos.

3.The power indicator light will flicker when capturing.

○ SELF-TIME MODE

1. press "Shutter" button to change icon into SELF-TIME mode ,press "MODE" button to
confirm.

2. On the front of the camera adjacent to the lens is a small aiming mirror.

3. Hold camera at arms length and use mirror to center your portrait.

○ VIDEO MODE

1. press "Shutter" button to change icon into VIDEO CLIP mode ,press "MODE" button
to confirm.

2.Press "Shutter" button to start capturing, press again to stop capturing.

○ CONTINUOUS CAPTURE MODE

1. press "Shutter" button to change icon into CONTINUOUS CAPTURE mode ,press
"MODE" button to confirm.

2.Press the "Shutter" button to take three photos continuously.

3.The power indicator light will flicker per capturing.

Settings-DELETE ALL PHOTOS

1. Select the fifth icon and press "Shutter" button to enter "DELETE ALL" mode.

2.Select "YES" option to delete all files , and select "No" option to cancel.

Settings-HI RESOLUTION/LO RESOLUTION

The resolution governs how much detail is captured in each picture. The default resolution is Hi.

　　 1.Select the second icon to set up HI ☆☆/ LO ☆resolution.

　　 2.Press "Shutter" button to change the icon into HI or LO resolution.

4.Press"Shutter"button to self-time capturing.
