Cobra 200GTL DX Parts List
Trrii
T
Preliminary Information
c
c
k
k
s..
s
c
c
o
o
m
m
Thank you for any support you can give.
http://www.cbtricks.com/
1
Page 2
Cobra 200GTL DX
PCB EL Driver ASSY 8
Ref # Description Part #
L8
C20
C254
C260
C261
C264
C266
C270
C275
C280
C289
Ref # Description Part #
D4
D57
D61
Ref # Description Part #
IC9
IC12
Ref # Description Part #
R198
R237
R240
R241
R261
R300
R301
R308
R310
R320
R330
R334
R336
R337
R338
R339
Ref # Description Part #
T1
Q45
Q48
Ref # Description Part #
COVER ASSY AMR-00002-COA
MAIN BODY ASSY AMR-00002-MBA
MIC ASSY AMR-00002-MCA
MIC DYNAMIC DM-3516 MCN-52WDF-AA
CONNECTER HEADER PL TCK-16-4(P) NCH-04HD1-TA
PUSH SWITCH(MIC PTT) SKPS-2210C SPU-221OC-SA
WIRE AWG24 3-7 BLACK 70 W12-4BO70-MA
CURL CORD 370mm & BUSHING WPO-6B370-FA
PCB SUB 75x82.6x1.6T 1/1 HALL PFS-00037-BA
COIL CHOKE 1mH BCH-102UK-FA
CHIP CERAMIC 1608 100pF C16-IOIZJ-AB
ELECT CAPACITOR RMS16V 100uF 5x11 CEF-101ZM-GC
CHIP CERAMIC 1608 100pF C16-IOIZJ-AB
ELECT CAPACITOR RMS16V 100uF 5x11 CEF-101ZM-GC
CHIP TANTALUM l0uF 16V CTC-100AM-FA
ELECT CAPACITOR RMS16V 470uF 8x11.5 CEF-471ZM-GA
MYLAR CAPACITOR 683PF 100V CMB-683ZJ-PA
CHIP CERAMIC 1608 100pF C16-IOIZJ-AB
CHIP TANTALUM l0uF 16V CTC-100AM-FA
CHIP TANTALUM l0uF 16V CTC-100AM-FA
DIODE ZENER CHIP KDZ5.lEV USM DZC-5115E-AA
DIODE KDS160 DSC-Sl60S-AA
DIODE KDS160 DSC-Sl60S-AA
IC HIGH VOLTAGE EL HV823 IEL-HV823-DA
IC REGULATOR KIA7805AF(D-PAK) IRG-7805D-KB
FILM CHIP RESISTOR 470 R16-471AJ-AA
FILM CHIP RESISTOR 10 R16-100AJ-AA
FILM CHIP RESISTOR 560 R16-561AJ-AA
FILM CHIP RESISTOR 560 R16-561AJ-AA
FILM CHIP RESISTOR 560K R16-564AJ-AA
FILM CHIP RESISTOR 1.8M R16-185AJ-AA
FILM CHIP RESISTOR 10 R16-100AJ-AA
FILM CHIP RESISTOR 1K RC1608 R16-102AJ-AA
FILM CHIP RESISTOR 1K RC1608 R16-102AJ-AA
FILM CHIP RESISTOR 10 R16-100AJ-AA
FILM CHIP RESISTOR 2.7K R16-272AJ-AA
FILM CHIP RESISTOR 2.7K R16-272AJ-AA
FILM CHIP RESISTOR 1K RC1608 R16-102AJ-AA
FILM CHIP RESISTOR 470 R16-471AJ-AA
FILM CHIP RESISTOR 8.2K R16-822AJ-AA
FILM CHIP RESISTOR 47K R16-473AJ-AA
TRANSISTOR KTC3875Y TRC-3875Y-AA
TRANSISTOR EPITAXIAL KTC4377(SOT-89) TRC-43770-AA
TRANSISTOR EPITAXIAL KTC4377(SOT-89) TRC-43770-AA
2
http://www.cbtricks.com/
Page 3
Cobra 200GTL DX
PCB Display ASSY 1
Ref # Description Part #
DIS1
DIS2
DIS3
DIS4
DIS5
DIS6
DIS7
LED1
LED3
PCB Front Panel ASSY 2
Ref # Description Part #
VR4
VR101
VR103
VR105
PCB Channel Sel. ASSY 3
Ref # Description Part #
SW1
PCB Switch ASSY 4
Ref # Description Part #
SW5
SW17
PCB Switch ASSY 5
Ref # Description Part #
MIC1
SW2
SW3
SW8
SW14
PCB Rotary Switch ASSY 6
Ref # Description Part #
SW4
SW12
EL ASSY
Ref # Description Part #
EL1
LED DISPLAY LSD032BSR-1 0 (HIGH RED) AEP-D032B-VA
LED DISPLAY LSD032BSR-1 0 (HIGH RED) AEP-D032B-VA
LED DISPLAY LSD032BSR-1 0 (HIGH RED) AEP-D032B-VA
LED DISPLAY LSD032BSR-1 0 (HIGH RED) AEP-D032B-VA
LED DISPLAY LSD032BSR-1 0 (HIGH RED) AEP-D032B-VA
LED DISPLAY LSD032BSR-1 0 (HIGH RED) AEP-D032B-VA
LED DISPLAY LDD40TSR-10 (SUPER RED) AEP-040TR-VA
LED GN/RD,3mm,LEAD LTL-1BEHJ 3mm, GN/RD AMN-00001-AA
LED LAMP LI2840 & 3 RED AMN-12840-BA
VARIABLE RESISTER TPNN1255-30SP-R1:B5K, R2 RVB-503AM-MD
VARIABLE RESISTER TPNN1255-30SP-R1:B50K, R RVB-503AM-MB
VARIABLE RESISTER TPNN1251-30SP-R1:B50K, R RVB-503AM-MC
VARIABLE RESISTER TPNN1251-30SP-R1:B50K, R RVB-503AM-MC
PCB MAIN 249.95x186.8x1.6(T) PFM-0090G-BA
PULSE SWITCH TRS1301-20SP SPL-T1301-TA
PCB MAIN 249.95xl86.8xl.6(T) PFM-0090E-BA
PUSH SWITCH SKPS-22003 SPU-22003-SA
PUSH SWITCH SKPS-22003N SPU-22003-SB
CONNECTER SOCKET MI TCN-16-4R(PCB) NCS-04HDI-TB
PUSH SWITCH SKPS-22003 SPU-22003-SA
PUSH SWITCH SKPS-22003 SPU-22003-SA
PUSH SWITCH SKPS-22003 SPU-22003-SA
PUSH SWITCH SKPS-22003 SPU-22003-SA
PCB MAIN 249.95x186.8xl.6(T) 1/1 H PFM-00901-BA
SWITCH ROTARY TRS2401-15SP(2C-4P) SRO-2415H-TA
SWITCH ROTARY TRS2501-15SP(2C-5P) SRO-2515H-TA
EL BACK LIGHT PH3470RGEN(RED GREEN) AEL-3470R-AA
