1. Specifications
,
Electrical and plumbing connections must be made by a qualified service person who will comply with all available Federal
State, and Local Health, Electrical, Plumbing and Safety codes
1.1 Model AH/C
WATER CONSUMPTION
PER RACK 1.7 GAL. (6.45 L) PER HOUR 74 GPH (280.1 LPH)
OPERATING CYCLE
WASH TIME-SEC. 45 45 RINSE TIME-SEC. 30 30 DWELL TIME-SEC. 15 15 TOTAL CYCLE 90 SEC.* 90 SEC.* *Other cycle times are available
OPERATING CAPACITY
RACKS PER HOUR (NSF Rated) 40 40 WASH TANK CAPACITY 1.7 GAL. (6.45 L) PUMP CAPACITY 52 GPM (197 LPM)
WATER REQUIREMENTS
REQUIRED MINIMUM TEMP. 120°F (49°C) RECOMMENDED TEMP. 140°F (60°C) WATER INLET ¾” 1.9cm DRAIN CONNECTION 2” 5.1cm DIMENSIONS DEPTH 25 ¾” (65.4cm) WIDTH 25 ¾” (65.4 cm) HEIGHT 56-57” (142-144.8cm) HEIGHT (SCULLERY) 66”-67” (168-170 cm) MAX CLEARANCE FOR DISHES 17” MAX CLEARANCE FOR DISHES (S) 27” STANDARD TABLE HEIGHT 34” (86.36 cm) STANDARD DISH RACKS 19 ¾” x 19 ¾” (50 x 50 cm)
ELECTRICAL RATING
WASH PUMP MOTOR 1 HP
USA METRIC
(43.18 cm) (68,58”cm)
VOLTS
(60-Hz)
115
AMPS
16
SHIPPING WEIGHT APPROXIMATE 270# (122.5 kg) APPROXIMATE (SCULLERY) 295# (133.8 kg)
MODEL AH, B & C INSTALLATION & OPERATION MANUAL Rev. 1.00A Page
3
Electrical and plumbing connections must be made by a qualified service person who will comply with all available
,
Federal
State, and Local Health, Electrical, Plumbing and Safety codes

1.2 Model B

USA METRIC
WATER CONSUMPTION
PER CYCLE 3.0 GAL. (11.4 L) PER HOUR 118.4 GPH (448.2 LPH)
OPERATING CYCLE
WASH TIME-SEC. 45 45 RINSE TIME-SEC. 30 30 DWELL TIME-SEC. 15 15 TOTAL CYCLE 90 SEC.* 90 SEC.* *Other cycle times are available
OPERATING CAPACITY
RACKS PER HOUR (NSF Rated) 80 80 WASH TANK CAPACITY 3.0 GAL. (11.4 L) PUMP CAPACITY (two pumps) 104 GPM (393.68 LPM)
WATER REQUIREMENTS
REQUIRED MINIMUM TEMP. 120°F (49°C) RECOMMENDED TEMP. 140°F (60°C) WATER INLET ¾” 1.9cm DRAIN CONNECTION 2” 5.1cm DIMENSIONS DEPTH 25 ¼” (64 cm) WIDTH 44 ¼” (112 cm) HEIGHT 55 ½”-56 ½” (141-143.5 cm) HEIGHT (SCULLERY) 65-66” (165-168cm) MAX CLEARANCE FOR DISHES MAX CLEARANCE FOR DISHES (S) STANDARD TABLE HEIGHT 34” (86.36 cm) STANDARD DISH RACKS 19 ¾” x 19 ¾” (50 x 50 cm)
ELECTRICAL RATING
WASH PUMP MOTORS (2) 1 HP each
17” 27"
VOLTS
(60-Hz)
115
(43.18 cm)
(68,58cm)
AMPS
26
SHIPPING WEIGHT APPROXIMATE 352# (160 kg) APPROXIMATE (SCULLERY) 377# (171 kg)
MODEL AH, B & C INSTALLATION & OPERATION MANUAL Rev. 1.00A Page
4

1.3 AH, B and C Operational Cycle*

g
r
W
g
The AH, B and C Operational Cycle have a total cycle time of 90 seconds. The Timing Diagram and the steps listed below detail the individual functions that are executed during each Operational Cycle.
Seconds: 0 10 20 30 40 50 60 70 80 90
Cam 1
Cam 2
Cam 3
Cam 4
Cam 5
Cam 6
Cam 7
Cam 8
ASH
DRAIN
RINSE
Start/Stop
Cycle Reset
Drain/Rack
Counter
Flush/Fill
Deter
ent
Sanitize
Rinse Aid
Pump Motor
1. With the machine powered up, closing the doors begins a cycle.
4sec. delay to prevent chemical dama
e
