Page 1
Vehicle Security System
Model 330X1 /330X2 /330X3
Owner’s Guide
Page 2
Limited consumer warranty
For a period of one calendar year from the date of purchase of this auto-security
device, Directed Electronics, (Directed) promises to the ORIGINAL PURCHASER to
repair or replace (at Directed's election) with a comparable reconditioned model, any
Directed unit (hereafter the "unit"), excluding without limitation the siren, the
remote transmitters, the associated sensors and accessories which proves to be
defective in workmanship or material under reasonable use, provided the following
conditions (herein "Conditions") are met: the unit was purchased from an authorized
Directed dealer; the unit was professionally installed and serviced by an authorized
Directed dealer; the unit will be professionally reinstalled in the vehicle in which it
was originally installed by an authorized Directed dealer; and the unit is returned to
Directed, shipping prepaid with a legible copy of the bill of sale or other dated proof
of purchase bearing the following information: consumer's name, telephone number
and address; the authorized dealer's name, telephone number and address; complete
product description, including accessories; the year, make and model of the vehicle;
vehicle license number and vehicle identification number. ALL UNITS RECEIVED BY
DIRECTED FOR WARRANTY REPAIR WITHOUT PROOF OF PURCHASE WILL BE DENIED.
After the first calendar year, from the date of purchase of the unit, Directed, promises
to the ORIGINAL PURCHASER to repair or replace, (at Directed's sole and absolute
discretion) with a comparable reconditioned model any unit which proves to be
defective in workmanship or material under reasonable use FOR A CHARGE OF $45.00,
SO LONG AS THE AFOREMENTIONED CONDITIONS HAVE BEEN MET. The unit must be
returned to Directed, postage pre-paid, along with a legible copy of the receipt
(including the information below) and a cashier's check or money order made payable
to Directed Electronics in the amount of $45.00.
This warranty is non-transferable and is automatically void if the unit has been
modified or used in a manner contrary to its intended purpose, or if the unit has been
damaged by accident, unreasonable use, neglect, improper service or other causes not
arising out of defects in materials or construction. This warranty does not cover
damage to the unit caused by installation or removal of the unit. This warranty does
not cover labor costs for the removal, diagnosis, troubleshooting or reinstallation of
the unit. For service on an out-of-warranty product a flat rate fee by model is
charged. Contact your authorized dealer to obtain the service charge for your unit.
These security systems are a deterrent against possible theft. Directed is not offering
a guarantee or insuring against vandalism, damage or theft of the automobile or its
parts or contents and Directed hereby disclaims any liability whatsoever, including
without limitation, liability for damage, vandalism and/or theft of the vehicle, parts
and/or its contents. Directed neither assumes nor authorizes any person or entity to
assume for it any duty, obligation or liability in connection with its products.
Directed disclaims and has absolutely no liability for any and all acts of third parties,
including its authorized dealers or installers. In the event of a claim or a dispute
involving Directed or its subsidiary, the venue shall be in San Diego, California.
© 2008 Directed Electronics - all rights reserved
i
Page 3
California state laws and applicable federal law shall apply and govern the dispute.
TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES ARE EXCLUDED,
INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY
OF MERCHANTABILITY AND/OR ANY AND ALL WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF NON-INFRINGEMENT OF
PATENTS, IN THE UNITED STATES OF AMERICA AND/OR ABROAD. THE MAXIMUM
RECOVERY UNDER ANY CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE
AUTHORIZED DIRECTED DEALER'S PURCHASE PRICE OF THE UNIT. DIRECTED SHALL NOT
BE RESPONSIBLE OR LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT
LIMITED TO ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, TOWING, REPAIR,
REPLACEMENT, DAMAGE TO VEHICLE, DAMAGES FOR LOSS OF TIME, LOSS OF EARNINGS,
COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE
OR REPAIR THE UNIT, SO LONG AS THE CONDITIONS ARE MET AS DESCRIBED HEREIN.
Some states do not allow limitations on how long an implied warranty will last or the
exclusion or limitation of incidental or consequential damages. This warranty gives
you specific legal rights, and you may also have other rights which vary from state
to state. This warranty is void if the unit has not been purchased from Directed, or
an authorized Directed dealer, or if the unit has been damaged by accident, unreasonable use, negligence, Acts of God, neglect, improper service, or other causes not
arising out of defect in materials or construction. This warranty is only valid for sale
of product(s) within the United States of America. Product(s) sold outside of the
United States of America are sold "AS-IS," and shall have NO WARRANTY, express or
implied.
This product warranty is automatically void if its date code or serial number is
defaced, missing, or altered. This warranty will not be valid unless you have
completed the warranty card and mailed it to Directed, within 10 days after purchase
to the address listed on the warranty registration card.
Make sure you have all of the following information from your authorized Directed
dealer: A clear copy of the sales receipt, showing the following:
o Date of purchase
o Your full name and address
o Authorized dealer's company name and address
o Type of system installed
o Year, make, model and color of the automobile
o Automobile license number
o Vehicle identification number
o All security options installed on automobile
ii
© 2008 Directed Electronics-all rights reserved
Page 4
Contents
Limited consumer warranty . . . . .i
Trademarks and copyrights . . . . .1
What is included . . . . . . . . . . . . .2
Important information . . . . . . . . .2
Using your system . . . . . . . . . . . .3
Arming your system . . . . . . . . .3
Armed protection . . . . . . . . . .4
Disarming . . . . . . . . . . . . . . . .5
Disarming without a transmitter
. . . . . . . . . . . . . . . . . . . . . . . .5
Panic mode . . . . . . . . . . . . . . .7
Nuisance Prevention Circuitry® . .9
Diagnostics . . . . . . . . . . . . . . . . .10
Arming diagnostics . . . . . . . .10
Disarming diagnostics . . . . . .10
Table of zones . . . . . . . . . . . .11
Rapid resume logic . . . . . . . . . . .11
Glossary of terms . . . . . . . . . . . .12
Notes . . . . . . . . . . . . . . . . . . . . . .13
Quick reference guide . . . . . . . .14
Trademarks and copyrights
Code-Hopping™, Directed®, Doubleguard®, FailSafe®, Nuisance Prevention Circuitry®, NPC®,
Silent Mode
Trademarks or Registered Trademarks of Directed Electronics, Inc.
© 2008 Directed Electronics - all rights reserved
™
, Soft Chirp®, Stealth Coding™, Stinger®, Valet®, and Warn Away®are all
1
Page 5
What is included
z
Control module and harness
z
Ultrasonic sensor
z
Valet®switch
z
Pre-wired Blue status LED
z
515 ESP Smart Self-Power siren
Important information
Congratulations on the purchase of your security system. Due to the
complexity of this system, it must be installed by an authorised dealer
only. Installation of this product by anyone other than an authorised
dealer voids the warranty. All dealers are provided with a preprinted
dealer certificate to verify that they are authorized.
By carefully reading this Owner's Guide prior to using your system, you
will maximize the use of this system and its features.
You can print additional or replacement copies of this manual by
accessing the Directed web site at www.xpressvip.com.
2
© 2008 Directed Electronics-all rights reserved
Page 6
Using your system
Arming your system
You can activate, or arm, the system by locking the doors with your fac-
tory keyless entry transmitter. When the system arms, you will hear a
short siren sound and see the indicator lights flash once.
While the system is armed, the status LED will flash about twice a sec-
ond, to indicate that the system is actively protecting your vehicle.
If you hear a second short siren sound after arming, and see the status
LED flashing in groups, this second short siren sound, a Bypass
Notification, means a zone such as a door, boot or bonnet is open. Refer
to the Diagnostics section for more information.
© 2008 Directed Electronics - all rights reserved
3
Page 7
Armed protection
When armed, your vehicle is protected as follows:
z
If a door is opened, the system will immediately start sounding the siren and flashing the indicator lights.
z
By turning on the ignition the siren pulses and the indicator
lights flash. Three seconds later the siren sound changes to
a continuous blast. This progressive response gives you time
to disarm the system using the Valet switch.
z
If equipped, the starter interrupt prevents the vehicle’s
starter from cranking.
z
If the Ultrasonic sensors detect interior movement, the system will immediately start sounding the siren and flashing
the indicator lights.
nnoottee::
The vehicle may already be equipped with a starter
interrupt relay from the factory.
4
© 2008 Directed Electronics-all rights reserved
Page 8
Disarming
To disarm the system, unlock the doors using your factory keyless transmitter. The siren will sound twice, and the indicator lights will flash
twice. If the siren sounds four or five times when disarming, this is
called Tamper Alert. Refer to the Diagnostics section of this guide.
Disarming without a transmitter
This feature allows you to override the system without the transmitter
should it be lost, damaged or disabled. To do this, you must have the vehicle's ignition key and know where the Valet®switch is located.
1. Turn the ignition to the "On" position.
2. Enter 4-digit PIN code by turning the ignition On.
3. Press the Valet
DRW-35
®
button the same number of times as the 1st digit.
4. Turn the ignition Off, and On.
© 2008 Directed Electronics - all rights reserved
5
Page 9
5. Press the button the same number of times as 2nd digit, the turn
the ignition Off and On.
6. Press the button same number of times as 3rd digit, then turn the
ignition Off and On.
7. Press the button same number of times as 4th digit, then turn the
ignition OFF.
If the code was correctly entered the system will disarm.
When armed, if a thief were to try to disarm the vehicle by entering
codes at random, the system locks out after the third failed try (indicat-
ed by a triple flash sequence of the LED), and then sounds the siren for
two minutes.
Attempts to enter the code are ignored, even a correct code entry is
ignored.
z
Press UNLOCK on the remote to silence the siren and disarm.
6
© 2008 Directed Electronics-all rights reserved
Page 10
Valet®mode
You can prevent your system from arming, by using Valet®Mode. This
is very useful when washing the vehicle or having it serviced. In Valet
Mode, the system will not arm, even with the transmitter, but all con-
venience functions (door locks, boot release, etc.) will work normally.
To enter or exit Valet® Mode with the Valet® switch:
1. Turn the ignition to ON position, and then turn it to the OFF
®
position.
®
2. Press and release the Valet
button within 10 seconds.
3. The status LED will light steady if you have entered Valet
Mode.
®
4. To exit Valet
off when exiting Valet
Mode, repeat the steps above. The LED will turn
®
Mode.
Panic mode
(If programmed On, above steps 3-4 )
If you are threatened in or near your vehicle, you can attract attention
by triggering the system with your transmitter! If your factory keyless
transmitter does not have a panic button, this system can be pro-
grammed to enable a panic feature.
®
© 2008 Directed Electronics - all rights reserved
7
Page 11
If enabled, Press the lock button on your factory keyless transmitter
two-times, and then press it again within 3 to 7 seconds to enter Panic
Mode. The siren will sound and the indicator lights will flash for 30 sec-
onds. To stop Panic Mode at any time, press the unlock button on your
factory transmitter.
nnoottee::
The system can also be programmed so that pressing
the lock button more than once within three and five seconds
will activate an optional accessory. If the unit is programmed
to activate an optional accessory, panic mode cannot be
activated.
8
© 2008 Directed Electronics-all rights reserved
Page 12
Nuisance Prevention Circuitry
®
Your system has Nuisance Prevention Circuitry®(NPC®). This circuitry
prevents annoying repetitive trigger sequences due to faulty door pin
switches or environmental conditions such as thunder, jackhammers,
airport noise, etc.
Here’s how it works:
The alarm triggers ten times. Each time, the same sensor or switch is
triggering the alarm. The ten triggers are within 60 minutes of each
other. Your system will interpret this pattern of triggers as false alarms.
After the tenth trigger, your system ignores, or bypasses that sensor or
switch (along with any other sensors or switches sharing the same
zone) for 60 minutes.
If the bypassed sensor tries to trigger the system while it is being
bypassed, the 60-minute bypass period will start over. This ensures that
a sensor that is continuously triggering will remain bypassed.
Doors are covered differently: If the alarm is triggered by an open door
for ten full cycles (one-and-one-half minutes), the doors will be
bypassed until the trigger ceases.
nnoottee::
Arming and disarming the system does not reset this
function! The only way to reset a bypassed zone is for it to
not trigger for 60 minutes, or to turn on the ignition. If testing
your system, it is important to remember that this circuitry can
cause zones to be bypassed and appear to stop working. If
five chirps are heard when disarming, false alarm protection
has engaged. If you wish to clear the memory, turn the ignition key on.
© 2008 Directed Electronics - all rights reserved
9
Page 13
Diagnostics
The microprocessor at the heart of your system is constantly monitor-
ing all of the switches and sensors connected to it. It detects any faulty
switches and sensors and prevents them from disabling the entire sys-
tem. The microprocessor will also record and report any triggers that
occurred during your absence.
Arming diagnostics
If the system is armed with an input active (door open, sensor trigger-
ing, etc.) the unit will chirp once when arming and then one more time
a few seconds later. This is called bypass notification.
nnoottee::
Bypass notification will not occur if chirps have been
programmed OFF.
The system will ignore the input that was active when it was armed until
it goes away. Three seconds later it will monitor that input normally.
Disarming diagnostics
When the siren sounds additional chirps when disarming, tamper alert
is active. If four chirps are heard when disarming, the system was trig-
gered in your absence. If five chirps are heard, a zone was triggered so
many times that false alarm prevention circuitry has bypassed that
zone. In either case, the status LED will indicate which zone was
involved (see Table of Zones section). The system will retain this infor-
mation in its memory, and chirp four or five times each time it is dis-
armed, until the next time the ignition key is turned on.
10
© 2008 Directed Electronics-all rights reserved
Page 14
Table of zones
The zone number is the number of LED flashes used by the system to
identify that input. The standard input assignments are listed below.
ZONE
(Number
LED Flashes) DESCRIPTION
1 Boot /bonnet opening
2 N/A
3 Door switch trigger
4 Ultrasonic sensor
5 Ignition input
6 Extra switch input (if installed)
The LED will not report if the Warn Away response is triggered.
Rapid resume logic
This system will store its current state to non-volatile memory. If power
is lost and then reconnected the system will recall the stored state from
memory. This means if the unit is in Valet®Mode and the battery is dis-
connected for any reason, such as servicing the car, when the battery
is reconnected the unit will still be in Valet®Mode. This applies to all
states of the system including arm, disarm, and Valet®Mode.
© 2008 Directed Electronics - all rights reserved
11
Page 15
Glossary of terms
Control Module: The “brain” of your system. Usually hidden under-
neath the dash area of the vehicle. It houses the microprocessor which
monitors your vehicle and controls all of the alarm’s functions.
Failsafe®Starter Kill (if equipped): An automatic switch controlled by
the security system which prevents the vehicle’s starter from cranking
whenever the system is armed. The vehicle is never prevented from
cranking when the system is disarmed, in Valet®Mode, or should the
starter kill switch itself fail. Your system is ready for this feature, how-
ever installation of this feature may require additional labor.
Input: Any physical connection to the security system. An input can be
provided through a sensor, pinswitch or by existing systems in the vehi-
cle, such as ignition or courtesy lights.
LED: The LED indicates the status of your system. It is also used to
report triggers and faults in the system or sensors.
Valet
the vehicle. The switch is used to override the alarm when a transmit-
ter is lost or damaged, or to put it into Valet®Mode.
Warn Away®Response: The Warn Away®Response will work if a dual
zone microwave was installed and the sensor is capable of detecting it.
Zone: A zone is a separate input that the alarm can recognize as
unique. Each input to the system is connected to a particular zone.
Often, two or more inputs may share the same zone.
®
Switch: A small push-button switch mounted somewhere in
12
© 2008 Directed Electronics-all rights reserved
Page 16
Notes
© 2008 Directed Electronics - all rights reserved
13
Page 17
QUICK REFERENCE GUIDE:
To arm the system
■ You can arm the system by locking the doors with your factory keyless entry
transmitter. When the system arms, your will hear a short chirp, and see the
indicator lights flash once.
To disarm the system
■ To disarm the system, unlock the doors using your factory keyless transmitter. You will hear two chirps, and the indicator lights will flash twice.
Disarming without a transmitter
■ Turn On the ignition.
1. Enter 4-digit PIN code by turning the ignition On, press the button the
same number of times as the 1st digit.
2. Turn the ignition Off, and On.
3. Press the button same number of times as 2nd digit, turn the ignition
Off and On.
4. Press the button same number of times as 3nd digit, then turn ignition
Off and On.
5. Press button same number of times as 4nd digit, then turn the ignition
OFF.
If the code was correctly entered the system will disarm.
✂✂
To enter or exit Valet®Mode
■ Turn ignition to “run” position, then turn to “Off” position. Press and release
the Valet®switch within 10 seconds. The status LED will light solid if you are
entering Valet® Mode, and it will go out when exiting Valet® Mode.
14
© 2008 Directed Electronics-all rights reserved
Cut along dotted line and fold for a quick and easy reference to keep in your purse or wallet.
✂✂
Page 18
© 2008 Directed Electronics - all rights reserved
15
Page 19
The company behind this system is Directed Electronics, Inc.
Since its inception, Directed Electronics has had one purpose, to provide consumers with
the finest vehicle security and car stereo products and accessories available. The recipient of
nearly 100 patents and Innovations Awards in the field of advanced electronic
technology, DIRECTED is ISO 9001 registered.
Quality Directed Electronics products are sold and serviced throughout North America
and around the world.
((880000)) 227744--00220000
Call
for more information about our products and services.
16
Directed Electronics is committed to delivering world class quality products
and services that excite and delight our customers.
Directed Electronics, Inc.
Vista, CA 92081
www.directed.com
© 2008 Directed Electronics, Inc. - All rights reserved
G330X 2008-02
© 2008 Directed Electronics-all rights reserved
Loading...
