Clevo W840AU User guide

V14.1.00

Preface

Notice

The company reserves the right to revise this publication or to change its contents without notice. Information
contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or
any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear
in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse)
of this publication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated, trans­mitted or reduced to any machine readable form without prior consent from the vendor, manufacturer or creators
of this publication, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or may not be copyrights and/or registered trade­marks of their respective companies. They are mentioned for identification purposes only and are not intended
as an endorsement of that product or its manufacturer.
©December 2014

Trademarks

Intel, Pentium and Intel Core are trademarks/registered trademarks of Intel Corporation.

I

Preface

R&TTE Directive

This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc­tive 1999/5/EC.

This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux­embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland,
United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov­enia.

ErP Off Mode Power Consumption Statement:

The figures below note the power consumption of this computer in compliance with European Commission (EC)
regulations on power consumption in off mode:

• Off Mode < 0.5W

II

Preface

CE Marking

This device has been tested to and conforms to the regulatory requirements of the European Union and has at­tained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies
to products regulated by certain European health, safety and environmental protection legislation. The CE Mark
is obligatory for products it applies to: the manufacturer affixes the marking in order to be allowed to sell his
product in the European market.

This product conforms to the essential requirements of the R&TTE directive 1999/5/EC in order to attain CE
Marking. A notified body has determined that this device has properly demonstrated that the requirements of the
directive have been met and has issued a favorable certificate of expert opinion. As such the device will bear the
notified body number 0560 after the CE mark.

The CE Marking is not a quality mark. Foremost, it refers to the safety rather than to the quality of a product.
Secondly, CE Marking is mandatory for the product it applies to, whereas most q uality marking s are vo lu ntary.

III

Preface

FCC Statement

(Federal Communications Commission)

You are cautioned that changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in­stalled and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Re orient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the service representative or an experienc ed radio/TV technician for help.

Operation is subject to the following two conditions:

1. This device may not cause interference.
And

2. This device must accept any interference, including interfer ence that may cause undesired operation of the

device.

IV

FCC RF Radiation Exposure Statement:



Warning

Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not ex­pressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the
equipment.

If your purchase option includes both Wireless LAN and 3G modules, then the appropriate antenna s will be installed. Note
that In order to comply with FCC RF exposure compliance requirements, the antenna must not be co -located or o perate in
conjunction with any other antenna or transmitter.

Important Notice - 3G & Bluetooth/Wireless LAN Modules

In order to comply with FCC regulations you should NOT operate the 3G module and the Bl uetoo th/Wirele ss LAN modules
at the same time as this may disrupt radio frequency, and cause interference. When the 3Gmodule is powered on, make sure
that the Bluetooth/Wireless LAN modules are powered off.

1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This

equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator
and your body.

Preface

V

Preface

IMPORTANT SAFETY INSTRUCTIONS

Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury
to persons when using any electrical equipment:

1. Do not use this product near water, for example n ear a ba th tub, wash bowl, kitchen sink or laundry tu b, in a wet

basement or near a swimming pool.

2. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There

may be a remote risk of electrical shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may

explode. Check with local codes for possible special disposal instructions.

5. This product is intended to be supplied by a Listed Power Unit as follows:

• AC Input of 100 - 240V, 50 - 60Hz, DC Output of 19V, 3.42A (65 Watts) minimum AC/DC Adapter.

VI

Preface

Instructions for Care and Operation

The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:

1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.

Do not expose the computer
to any shock or vibration.

Do not place it on an unstable
surface.

Do not place anything heavy
on the computer.

2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-

ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly dam­aged.

Do not expose it to excessive
heat or direct sunlight.

Do not leave it in a place
where foreign matter or mois­ture may affect the system.

Don’t use or store the com­puter in a humid environment.

Do not place the computer on
any surface that will block the
Vents/Fan Intakes.

VII

Preface

3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other

strong magnetic fields. These can hinder proper performance and damage your data.

4. Follow the proper workin g procedu res for t he computer. Shut the computer down properly and don’t forget

to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.

Do not turn off the power
until you properly shut down
all programs.

Do not turn off any peripheral
devices when the computer is
on.

5. Take care when using peripheral devices.

Use only approved brands of
peripherals.

VIII

Do not disassemble the com­puter by yourself.

Unplug the power cord befor e
attaching peripheral devices.

Perform routine maintenance
on your computer.

Power Safety



Power Safety

Warning

Before you undertake
any upgrade proce­dures, make sure that
you have turned off the
power, and discon­nected all peripherals
and cables (including
telephone lines and
power cord).

You must also remove
your battery in order to
prevent accidentally
turning the machine
on. Before removing

the battery discon­nect the AC/DC
adapter from the
computer.

The computer has specific power requirements:

• Only use a power adapter approved for use with this computer.

• Your AC/DC adapter may be designed for international travel but it still requires a

steady , uninterru pted power suppl y. If you are unsure of your local power specifications,
consult your service representative or local power company.

• The power adapter may have either a 2-prong or a 3-prong grounded plug. The third

prong is an important safety feature; do not defeat its purpose. If you do not have access
to a compatible outlet, have a qualified electrician install one.

• When you want to unplug the power cord, be sure to disconnect it by the plug head, not

by its wire.

• Make sure the socket and any extension cord(s) you use can support the total current

load of all the connected devices.

• Before cleaning the computer, make sure it is disconnected from any external power

supplies (i.e. AC/DC adapter or car adapter).

Do not plug in the power
cord if you are wet.

Do not use the power cord if
it is broken.

Do not place heavy objects
on the power cord.

Preface

IX

Preface

Polymer Battery Precautions

Note the following information which is specific to polymer batteries only, and where applicable, this overrides
the general battery precaution information overleaf.

• Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha-

nism and is not a cause for concern.

• Use proper handling procedures when using polymer batteries. Do not use polymer batteries in high ambient tempera-

ture environments, and do not store unused batteries for extended periods.

See also the general battery precautionary information overleaf for further information.

X

Battery Precautions



Battery Disposal & Caution

The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life,
under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with
your local solid waste officials for details in your area for recycling options or proper disposal.

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the
manufacturer. Discard used battery according to the manufacturer’s instructions.

• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.

• Do not remove any batteries from the computer while it is powered on.

• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even

if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly
result in fire.

• If you do not use the battery for an extended period, then remove the battery from the computer for storage.

• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.

• Do not try to repair a battery pack. Refer any battery pack repa ir or replacemen t to you r service repre sentati ve or qu al-

ified service personnel.

• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteri es

may explode or leak if exposed to fire, or improperly handled or discarded.

• Keep the battery away from metal appliances.

• Affix tape to the battery contacts before disposing of the battery.

• Do not touch the battery contacts with your hands or metal objects.

Preface

XI

Preface



Removal Warning

When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and
screw(s) before restoring power to the system.

Also note the following when the cover is removed:

• Hazardous moving parts.

• Keep away from moving fan blades.

Cleaning

Do not apply cleaner directly to the computer; use a soft clean cloth.
Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.

Servicing

Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the
computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the
power supply. Then refer servicing to qualified service personnel under any of the following conditions:

• When the power cord or AC/DC adapter is damaged or frayed.

• If the computer has been exposed to rain or other liquids.

• If the computer does not work normally when you follow the operating instructions.

• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).

• If there is an unusual odor, heat or smoke coming from your computer.

XII

Preface



Power Off Before Traveling

Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a
notebook which is powered on in a travel bag may cause the vent(s)/fan intake(s)/outlet(s) to be blocked. To prev ent your
computer from overheating make sure nothing blocks the vent(s)/fan intake(s)/outlet(s) while the computer is in use.

Travel Considerations

Packing

As you get ready for your trip, run through this list to make sure the system is ready to go:

1. Check that the battery pack and any spares are fully charged.

2. Power off the computer and peripherals.

3. Close the display panel and make sure it’s latched.

4. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.

5. The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,

check with your travel agent to see if you need any socket adapters.

6. Put the notebook in its carrying bag and secure it with the bag’s straps.

7. If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters

and/or cables.

8. Anticipate customs - Some jurisdictions may have import restrictions or req uire proof of ownersh ip for both hard -

ware and software. Make sure your documents are prepared.

XIII

Preface

On the Road

In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting,
keep these points in mind:

Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very
common. Don’t check it with normal luggage. Baggage handlers may not be sufficiently careful. Avoid knock­ing the computer against hard objects.

Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the com­puter, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and
disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note:
Some airports also scan luggage with these devices.

Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight.
These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make
sure it’s secure. Contents may shift and/or fall out when the compartment is opened.

Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies)
charged.

Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer.
Wait a few minutes before turning it on so that any moisture can evaporate.

XIV

Preface

Developing Good Work Habits

Developing good work habits is important if you need to work in fron t of the computer for long periods of time.
Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or
other joints. The following are some tips to reduce the strain:

• Adjust the height of the chair and /or desk so that the ke yboard is a t or slightly below the level

of your elbow. Keep your forearms, wrists, and hands in a relaxed position.

• Your knees should be slightly higher th an your hips. Place your feet flat on the floor or on a

footrest if necessary.

• Use a chair with a back and adjust it to support your lower back comfortably.

• Sit straight so that your knees, hips and elbows form approximately 90-degree angles when

you are working.

• Take periodic breaks if you are using the computer for long periods of time.

Remember to:

• Alter your posture frequently.

• Stretch and exercise your body several times a day.

• Take periodic breaks when you work at the computer for long periods of time. Frequent and

short breaks are better than fewer and longer breaks.

XV

Preface

Lighting

Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and
shoulders.

• Position the display to avoid glare or reflections from overhead lighting or outside sources of light.

• Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

• Position the display directly in front of you at a comfortable viewing distance.

• Adjust the display-viewing angle to find the best position.

LCD Screen Care

To prevent image persistence on LCD monitors (caused by the continuous display of graphics on the screen for
an extended period of time) take the following precautions:

• Set the Windows Power Plans to turn the screen off after a few minutes of screen idle time.

• Use a rotating, moving or blank screen saver (this prevents an image from being displayed too long).

• Rotate desktop background images every few days.

• Turn the monitor off when the system is not in use.

LCD Electro-Plated Logos

Note that in computers featuring a raised LCD electro-plated logo, the logo is covered by a protective adhesive.
Due to general wear and tear, this adhesive may deteriorate over time and the exposed logo may develop sharp
edges. Be careful when handling the computer in this case, and avoid touching the raised LCD electro-plated
logo. Avoid placing any other items in the carrying bag which may rub against the top of the computer during
transport. If any such wear and tear develops contact your distributor/supplier.

XVI

Preface

Contents

Notice .............................................................................................................................................................I

ErP Off Mode Power Consumption Statement: ...........................................................................................II

FCC Statement ............................................................................................................................................IV

FCC RF Radiation Exposure Statement: .....................................................................................................V

Instructions for Care and Operation ......................................................................................................... VII

Power Safety ...............................................................................................................................................IX

Polymer Battery Precautions .......................................................................................................................X

Battery Precautions .....................................................................................................................................XI

Cleaning .................................................................................................................................................... XII

Servicing ................................................................................................................................................... XII

Travel Considerations ..............................................................................................................................XIII

Quick Start Guide

Overview ....................................................................................................................................................1-1

Advanced Users .........................................................................................................................................1-2

Beginners and Not-So-Advanced Users ....................................................................................................1-2

Warning Boxes ..........................................................................................................................................1-2

Not Included ..............................................................................................................................................1-3

System Startup ...........................................................................................................................................1-4

System Software ........................................................................................................................................1-5

System Map: LCD Panel Open ..................................................................................................................1-6

XVII

Preface

LED Indicators ...........................................................................................................................................1-7

Keyboard ....................................................................................................................................................1-8

Keyboard Shortcuts ...................................................................................................................................1-9

Function/Hot Key Indicators ...................................................................................................................1-10

Control Center .........................................................................................................................................1-11

System Map: Front & Left Views ...........................................................................................................1-12

System Map: Right & Rear Views ..........................................................................................................1-13

System Map: Bottom View .....................................................................................................................1-14

3G/4G Module USIM Card Installation ..................................................................................................1-15

Windows 8.1 Control Panel .....................................................................................................................1-16

Windows 8.1 Start Screen & Desktop .....................................................................................................1-19

Apps & Tiles ............................................................................................................................................1-20

Desktop Application ................................................................................................................................1-21

The Charms Bar .......................................................................................................................................1-22

Windows 8.1 Taskbar ..............................................................................................................................1-24

Video Features .........................................................................................................................................1-25

Power Options .........................................................................................................................................1-28

Running Apps ..........................................................................................................................................1-29

Features & Components

Overview ....................................................................................................................................................2-1

Hard Disk Drive/Solid State Drive ............................................................................................................2-2

XVIII

Preface

Multi-In-1 Push-Push Card Reader ...........................................................................................................2-3

Touchpad and Buttons/Mouse ...................................................................................................................2-4

Touchpad Sensitivity .................................................................................................................................2-4

One-Finger .................................................................................................................................................2-8

Multi-Finger .............................................................................................................................................2-11

Additional ................................................................................................................................................2-13

Audio Features .........................................................................................................................................2-14

Setup for Audio Recording ......................................................................................................................2-15

Power Management

Overview ....................................................................................................................................................3-1

The Power Sources ....................................................................................................................................3-2

AC/DC Adapter .........................................................................................................................................3-2

Battery ........................................................................................................................................................3-2

Turning On the Computer ..........................................................................................................................3-3

Shutting the Computer Down ....................................................................................................................3-4

Power Plans ...............................................................................................................................................3-5

Power-Saving States ..................................................................................................................................3-7

Sleep ..........................................................................................................................................................3-7

Hibernate ....................................................................................................................................................3-8

Shut down ..................................................................................................................................................3-8

Configuring the Power Buttons .................................................................................................................3-9

XIX

Preface

Resuming Operation ................................................................................................................................3-11

Power Conservation Modes .....................................................................................................................3-12

Battery Information .................................................................................................................................3-14

Battery Power ..........................................................................................................................................3-14

Conserving Battery Power .......................................................................................................................3-15

Battery Life ..............................................................................................................................................3-16

New Battery .............................................................................................................................................3-16

Recharging the Battery with the AC/DC Adapter ...................................................................................3-16

Proper handling of the Battery Pack ........................................................................................................3-17

Battery FAQ .............................................................................................................................................3-18

Removing the Battery ..............................................................................................................................3-22

Drivers & Utilities

What to Install ............................................................................................................................................4-1

Module Driver Installation ........................................................................................................................4-1

Driver Installation ......................................................................................................................................4-2

Updating/Reinstalling Individual Drivers ..................................................................................................4-5

User Account Control ................................................................................................................................4-6

Windows Security Message .......................................................................................................................4-6

New Hardware Found ................................................................................................................................4-6

Driver Installation Procedure .....................................................................................................................4-7

Chipset .......................................................................................................................................................4-7

XX

Preface

Video (VGA) .............................................................................................................................................4-7

LAN ...........................................................................................................................................................4-7

CardReader ................................................................................................................................................4-7

Touchpad ...................................................................................................................................................4-7

Airplane .....................................................................................................................................................4-7

Hot Key ......................................................................................................................................................4-8

MEI Driver .................................................................................................................................................4-8

Audio .........................................................................................................................................................4-8

Optional Drivers ......................................................................................................................................4-10

BIOS Utilities

Overview ....................................................................................................................................................5-1

The Setup Utility ........................................................................................................................................5-2

Failing the POST .......................................................................................................................................5-3

Fatal Errors ................................................................................................................................................5-3

Non-Fatal Errors ........................................................................................................................................5-3

Setup Screens .............................................................................................................................................5-4

Main Menu .................................................................................................................................................5-5

System Time & Date (Main Menu) ...........................................................................................................5-5

SATA Port # (Main Menu) ........................................................................................................................5-6

CPU/System/Extended Memory: (Main Menu) ........................................................................................5-6

MB Series / BIOS Revision / KBC/EC firmware Revision / MAC Address ............................................5-6

XXI

Preface

Advanced Menu .........................................................................................................................................5-7

Advanced Chipset Control (Advanced Menu) ..........................................................................................5-7

Combo Slot

(Advanced Menu > Advanced Chipset Control) .......................................................................................5-8

Intel Smart Connect Technology (Advanced Menu) .................................................................................5-9

SATA Mode (Advanced Menu) ................................................................................................................5-9

Boot Logo (Advanced Menu) ....................................................................................................................5-9

Power On Boot Beep (Advanced Menu) ...................................................................................................5-9

Battery Low Alarm Beep (Advanced Menu) .............................................................................................5-9

Security Menu ..........................................................................................................................................5-10

Set Supervisor Password (Security Menu) ..............................................................................................5-10

Set User Password (Security Menu) ........................................................................................................5-11

Password on boot: (Security Menu) ........................................................................................................5-11

TPM Configuration (Security Menu) ......................................................................................................5-12

Secure Boot Control (Security Menu) .....................................................................................................5-13

Boot Menu ...............................................................................................................................................5-14

Boot Option Priorities (Boot Menu) ........................................................................................................5-15

UEFI Boot (Boot Menu) ..........................................................................................................................5-15

Exit Menu ................................................................................................................................................5-16

Modules & Options

Overview ....................................................................................................................................................6-1

XXII

Preface

PC Camera Module ....................................................................................................................................6-2

PC Camera Audio Setup ............................................................................................................................6-3

Camera App ...............................................................................................................................................6-4

Camera Options .........................................................................................................................................6-5

Taking Pictures/Capturing Video ..............................................................................................................6-6

Camera Roll ...............................................................................................................................................6-7

Wireless LAN Module .............................................................................................................................6-11

3rd Party 802.11b/g/n Driver Installation ................................................................................................6-12

Intel® WLAN Driver Installation ............................................................................................................6-12

WLAN Configuration in Windows .........................................................................................................6-13

Bluetooth & WLAN Combo Module ......................................................................................................6-16

3rd Party Bluetooth (V4.0) Combo Driver Installation ...........................................................................6-17

Intel Bluetooth Combo Driver Installation ..............................................................................................6-17

Bluetooth Configuration in Windows ......................................................................................................6-18

Intel® Rapid Storage Technology ...........................................................................................................6-21

IRST Driver Installation ..........................................................................................................................6-21

Intel® Smart Connect Technology ..........................................................................................................6-22

Intel® Smart Connect Technology Driver Installation ............................................................................6-22

Intel® Smart Connect Technology Configuration ...................................................................................6-23

Free Fall Data Protection .........................................................................................................................6-27

Free Fall Protection Driver Installation ...................................................................................................6-27

3G/4G Module .........................................................................................................................................6-31

XXIII

Preface

3G/4G Configuration in Windows ...........................................................................................................6-33

Trusted Platform Module .........................................................................................................................6-36

Enabling & Activating TPM ....................................................................................................................6-37

TPM Management in Windows ...............................................................................................................6-38

TPM Actions ............................................................................................................................................6-40

Wireless Display ......................................................................................................................................6-42

Wireless Display Configuration ..............................................................................................................6-43

Troubleshooting

Overview ....................................................................................................................................................7-1

Basic Hints and Tips ..................................................................................................................................7-2

Backup and General Maintenance .............................................................................................................7-3

Viruses .......................................................................................................................................................7-4

Upgrading and Adding New Hardware/Software ......................................................................................7-5

Problems and Possible Solutions ...............................................................................................................7-7

3G/4G Module PIN Code & Power-Saving ............................................................................................7-15

Resolving the “Insert a SIM” issue with the 3G/4G Module (Windows 8.1) .........................................7-17

Interface (Ports & Jacks)

Overview ...................................................................................................................................................A-1

Notebook Ports and Jacks .........................................................................................................................A-2

Control Center

XXIV

Preface

Overview ...................................................................................................................................................B-1

Video Driver Controls

Intel Video Driver Installation ..................................................................................................................C-1

Dynamic Video Memory Technology ......................................................................................................C-1

Intel® HD Graphics Control Panel ...........................................................................................................C-2

Display Devices & Options ....................................................................................................................C-16

Attaching Other Displays .......................................................................................................................C-17

Attaching Other Displays - Devices (Charms Bar) ................................................................................C-19

Configuring an External Display In Windows .......................................................................................C-20

HDMI Audio Configuration ...................................................................................................................C-22

Specifications

Processors .................................................................................................................................................D-2

Display ......................................................................................................................................................D-2

Memory .....................................................................................................................................................D-2

Video Adapter ...........................................................................................................................................D-2

Storage ......................................................................................................................................................D-2

Audio ........................................................................................................................................................D-2

Keyboard & Pointing Device ....................................................................................................................D-2

Interface ....................................................................................................................................................D-3

Card Reader ..............................................................................................................................................D-3

Mini Card Slots .........................................................................................................................................D-3

XXV

Preface

Communication .........................................................................................................................................D-3

Power ........................................................................................................................................................D-3

Battery .......................................................................................................................................................D-3

Power Management ..................................................................................................................................D-3

LED Indicators ..........................................................................................................................................D-3

BIOS .........................................................................................................................................................D-4

Security .....................................................................................................................................................D-4

Features .....................................................................................................................................................D-4

Operating System ......................................................................................................................................D-4

Environmental Spec ..................................................................................................................................D-4

Dimensions & Weight ..............................................................................................................................D-4

XXVI

Quick Start Guide

Chapter 1: Quick Start Guide

Overview

This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the
computer and to getting your system started. The remainder of the manual covers the following:

• Chapter 2 A guide to using some of the main features of the computer e.g. the storage devices (hard disk,

optical device, card reader), Touchpad/Mouse and Audio.

• Chapter 3 The computer’s power saving options.

• Chapter 4 The installation of the drivers and utilities essential to the operation or improvement of some of the

computer’s subsystems.

• Chapter 5 An outline of the computer’s built-in software or BIOS (Basic Input Output System).

• Chapter 7 A quick guide to the computer’s PC Camera, W ir eless LAN, Combo Bluetooth & WLAN, Intel,

TPM (security) and 3G/4G modules (some of which may be optional depending on your purchase
configuration).

• Chapter 7 A troubleshooting guide.

• Appendix A Definitions of the interface, ports/jacks which allow your computer to communicate with external

devices.

• Appendix B Information on Control Center.

• Appendix C Information on the video driver controls.

• Appendix D The computer’s specification.

1

Overview 1 - 1

1



Notes

Check the light colored
boxes with the mark
above to find detailed in­formation about the com­puter’s features.

Quick Start Guide

Advanced Users

If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful
to refer to “What to Install” on page 4 - 1, “BIOS Utilities” on page 5 - 1 and “Upgrading The Computer” on

page 6 - 1 in the reminder of the User’s Manual. You may also find the notes marked with a

 of interest to you.

Beginners and Not-So-Advanced Users

If you are new to computers (or do not have an advanced knowledge of them) then
the information contained in the Quick Start Guide should be enough to get you up
and running. Eventually you should try to look through all the documentation (more
detailed descriptions of the functions, setup and system controls are covered in the
remainder of the User’s Manual), but do not worry if you do not understand every­thing the first time. Keep this manual nearby and refer to it to learn as you go. You
may find it useful to refer to the notes marked with a

 as indicated in the margin.

For a more detailed description of any of the interface ports and jacks see “Interface

(Ports & Jacks)” on page A - 1.

Warning Boxes

No matter what your level please pay careful attention to the warning and safety information indicated by the

 symbol. Also please note the safety and handling instructions as indicated in the Preface.

1 - 2 Overview

Quick Start Guide



Drivers

If you are installing new system software, or are re-configuring your computer for a different system, you will need to install
the drivers listed in “Drivers & Utilities” on page 4 - 1. Drivers are programs which act as an interface between the com­puter and a hardware component e.g. a wireless network module. It is very important that you install the drivers in the order
listed. You will be unable to use most advanced controls until the necessary drivers and utilities are properly installed. If
your system hasn’t been properly configured (your service representative may have already done that for you); refer to

Chapter 4 for installation instructions.

Ports and Jacks

See “Notebook Ports and Jacks” on page A - 2 for a description of the interface (ports & jacks) which allow your com­puter to communicate with external devices, connect to the internet etc.

Not Included

Operating Systems (e.g. Windows 8.1) and applications (e.g. word processing, spreadsheet and database pro­grams) have their own manuals, so please consult the appropriate manuals.

1

Overview 1 - 3

1

127°



Shutdown

Note that you should al­ways shut your comput­er down by choosing
the Shut Down com­mand in Windows (see
page 1 - 28). This will
help prevent hard disk
or system problems.

Quick Start Guide

System Startup

1. Remove all packing materials.

2. Place the computer on a stable surface.

3. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports.

4. Attach the AC/DC adapter to the DC-In jack on the right of th e computer, then plug the AC power cord into an

outlet, and connect the AC power cord to the AC/DC ad apter ( it is recomme nded that you use the adap ter wh en
first setting up the computer).

5. Use one hand to raise the

hand to support the base of the computer (Note: Never lift the computer by the lid/LCD).

lid/LCD to a comfortable viewing angle (

do not exceed 127 degrees

);

use the other

Figure 1 - 1 - Opening the Lid/LCD & Computer with AC/DC Adapter Plugged-

1 - 4 System Startup

Quick Start Guide



Windows Versions

Note that the information included on the following pages is for Windows 8.1 only.

Windows OS

In order to run Windows 8.1 (64 bit) without limitations or decreased performance, your computer requires a minimum

2GB of system memory (RAM).

System Software

Your computer may already come with system software pre-installed. Where this is not the case, or where you
are re-configuring your computer for a different system, you will find the Windows 8.1 o perating system is sup­ported.

Note: In order to run Windows without limitations or decreased performance, your computer requires a mini-
mum 2GB of system memory (RAM).

1

System Startup 1 - 5

1

Figure 1 - 2

LCD Panel Open

1. Built-in PC Camera

2. PC Camera LED

3. Built-In Microphone

4. LCD

5. Power Button

6. Keyboard

7. Touchpad &
Buttons

7

Touchpad Buttons
(valid operation area)

Note that the Touchpad &
Buttons valid operational
area is that indicated within
the red dotted lines indicated
on the right.

3

5

1

7

4

6

2



Wireless Device

Operation Aboard

Aircraft

The use of any portable
electronic transmission
devices aboard aircraft is
usually prohibited. Make
sure the WLAN, Blue-

tooth and 3G/4G mod­ule(s) are OFF if you are

using the computer
aboard aircraft by putting
the system in to Airplane
Mode (see Table 1 - 3,

on page 1 - 10/).

Quick Start Guide

System Map: LCD Panel Open

1 - 6 System Map: LCD Panel Open

Quick Start Guide

LED Indicators

The LED indicators on the computer display helpful information about the current status of the computer.

Icon Color Description

Orange DC Power is Plugged In

Green The Computer is On

Blinking Green The Computer is in Sleep Mode

1

Slow (20 second intervals)

Blinking Green

Orange The Battery is Charging

Green The Battery is Fully Charged

Blinking Orange The Battery Has Reached Critically Low Power Status

Green Airplane Mode is ON (the WLAN, Bluetooth & 3G Modules are OFF)

Green Hard Disk Activity

The Computer is in Sleep Mode and *Intel Smart Connect is Enabled

Table 1 - 1 - LED Indicators

*Intel® Smart Connect Technology is enabled by default to periodically, and briefly, wake the computer from Sleep mode
in order to check email applications etc. Only certain Intel WLAN modules support this feature (see “Intel® Smart Con-

nect Technology” on page 6 - 23 for more information).

LED Indicators 1 - 7

1



Other Keyboards

If your keyboard is dam­aged or you just want to
make a change, you can
use any standard USB
keyboard. The system will
detect and enable it auto­matically. However spe­cial functions/hot-keys
unique to the system’s
regular keyboard may not
work.

NumLk & ScrLk

Hold down the Fn Key
and either NumLk or
ScrLk to enable number
or scroll lock, and check
the LED indicator for sta­tus.

Numerical

Play/Pause Key

Function Keys

NumLk &
ScrLk Keys

Fn Key

Keypad

Windows Logo Key

Menu/Application Key



Special Characters

Some software applications allow the number-keys to be used with Alt to produce special characters.
These special characters can only be produced by using the numeric keypad. Regular number keys (in
the upper row of the keyboard) will not work. Make sure that NumLk is on.

Quick Start Guide

Keyboard

The keyboard has an embedded numerical keypad for easy numeric data input, and
function keys to change operational features instantly.

Figure 1 - 3 - Keyboard

1 - 8 Keyboard

Keyboard Shortcuts



Windows Logo

Keyboard Shortcut

Use the Windows logo
key + D key com-
bination toto switch
from the Start screen
to the Windows Desk­top.

Menu/Application

Keyboard Shortcut

When the Desktop app
is running you can use
the Menu/Application
key on the key­board to act as a
mouse right-click. In
the Start screen this
function is useful to
quickly display Cus-
tomize Apps.

The following Windows Logo Key (Winkey) keyboard shortcuts are useful for navi­gation/operation in

Windows Logo

Key +

Tap Winkey

CDisplay Charms menu
D Switch to the Windows Desktop and toggle show Desktop

E

F Display file Search

I Open the Settings charm

K Open the Connect charm

L Lock the computer and display the Lock screen
P Display the Second Screen menu (see Figure 1 - 17 on page 1 - 25)
R Switch to the Windows Desktop and display the Run dialog box
Z Access the Customize Bar (see Figure 1 - 12 on page 1 - 20)

Windows 8.1

.

Description

Toggle between the Start screen and the foremost running app or the

Windows Desktop

Switch to the Windows desktop and launch Windows Explorer with

Computer displayed

Table 1 - 2 - Keyboard Shortcuts

Quick Start Guide

1

Keyboard 1 - 9

1

Quick Start Guide

Function/Hot Key Indicators

The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition
to the basic function key combinations; visual indicators are available when the hot key utility is installed.

Keys Function Keys Function

Fn +

Fn +

Fn +

Fn +

Fn +

Fn +

Fn +

Play/Pause (in Audio/Video Programs)

Fan Control Toggle

Automatic Fan Control

/ Full Power

Touchpad Toggle

(Press a key to or use Touchpad to turn on)

Turn LCD Backlight Off

Mute Toggle Fn + NumLk

Volume Decrease/Increase Fn + ScrLk

Display Toggle Caps Lock

Table 1 - 3 - Function & Hot Key Indicators

1 - 10 Function/Hot Key Indicators

Fn +

Fn +

Fn +

Fn +

Fn + Esc Control Center Toggle

Brightness Decrease/Increase

PC Camera

Power
Toggle

Airplane

Mode T oggle

Sleep Toggle

Number Lock

Toggle

Scroll Lock

Toggle

Caps Lock

Toggle

Quick Start Guide



Control Center Access

To run the Con­trol Center
press the Fn +
Esc key combi­nation, or dou­ble-click the
icon in the
notification area
of the taskbar.

Close the Control Center by clicking
the close icon in the top right of
the panel (move the cursor onto the
top right corner of the panel to high­light it).

Control Center

When in the Windows Desktop application (not in the Start screen) press the Fn + Esc key combination, or
double-click the icon
trol Center gives quick access to frequently used controls and enables you to quickly turn the camera/Touch

Pad on/off (see Appendix B for full details).

in the notification area of the taskbar to toggle the Control Center on/off. The Con-

Figure 1 - 4 - Control Center

Control Center 1 - 11

1

1

Figure 1 - 5

Front & Left Views

1. LED Power
Indicators

2. Security Lock Slot

3. Microphone-In
Jack

4. Headphone-Out
Jack

5. Vent/Fan Intake/
Outlet

6. Speaker

2

3

1

5

4



Overheating

To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake
while the computer is in use.

6

Quick Start Guide

System Map: Front & Left Views

1 - 12 System Map: Front & Left Views

System Map: Right & Rear Views

Figure 1 - 6

Right & Rear Views

1. Speaker

2. Multi-in-1 Push­Push Card
Reader

3. USB 3.0 Port

4. HDMI-Out Port

5. RJ-45 LAN Jack

6. DC-In Jack

7. Battery



Overheating

To prevent your comput­er from overheating
make sure nothing
blocks the Vent/Fan In­take while the computer
is in use.

6

3

2

4

1

W255EU

3

7

5



Multi-In-1 Push-Push Card Reader

The card reader allows you to use the most popular dig-

ital storage card formats:

MMC (MultiMedia Card) / RS MMC

SD (Secure Digital) / Mini SD / SDHC / SDXC

Optical Device Drives

To install applications and drivers etc. you will need to
attach an external optical CD/DVD device to the USB
ports.

5

Quick Start Guide

1

System Map: Right & Rear Views 1 - 13

1

Figure 1 - 7

Bottom View

1. Battery

2. Vent/Fan Intake/
Outlet

3. Speakers

4. Component Bay
Cover

5. HDD Bay Cover



CPU

The CPU is not a user
serviceable part.

Overheating

To prevent your comput­er from overheating
make sure nothing
blocks the Vent/Fan In­take while the computer
is in use.



Battery Information

Always completely dis­charge, then fully
charge, a new battery
before using it. Com­pletely discharge and
charge the battery at
least once every 30 days
or after about 20 partial
discharges (see “Bat-

tery Information” on
page 3 - 14).

2

1

3

2

3

4

5

2

2



Bottom Cover Removal Warning

Do not remove any cover(s) and /or screw(s) for the purposes of device upgrade as this
may violate the terms of your warranty.

If you need to replace/remove the hard disk or RAM for any reason, please contact your
distributor/supplier for further information.

Quick Start Guide

System Map: Bottom View

1 - 14 System Map: Bottom View

3G/4G Module USIM Card Installation



Bottom Cover

Removal Warning

Do not remove any cov­er(s) and /or screw(s) for
the purposes of device up­grade as this may violate
the terms of your warranty.

If you need to replace/re­move the hard disk or RAM
for any reason, please con­tact your distributor/suppli­er for further information.

USIM Card Orientation

Note that the USIM card’s
readable side (with the
gold-colored contacts)
should face upwards as il­lustrated.

Figure 1 - 8

Battery Removal &

USIM Card Insertion

12345

3

4

5

2

1

If you have included an optional 3G/4G module, follow the instructions below to in-
stall the USIM card (which will be provided by your service provider). See page 6 -

33 for configuration instructions.

1. Turn the computer off, remove the AC/DC adapter and turn it over.

2. Slide the latch in the direction of the arrow.

3. Slide the latch in the direction of the arrow, and hold it in place.

4. Grip the battery and remove it in the direction of arrow .

5. Insert the USIM card (at the rear of the battery compartment) as illustrated
below, until it clicks fully into position.

6. When reinserting the battery slide it in to the battery bay as illustrated .

Quick Start Guide

1

3G/4G Module USIM Card Installation 1 - 15

1



Windows Versions

Note that the informa­tion included on the fol­lowing pages is for the
latest updated version
of Windows 8.1 only.

Make sure you enable
Windows Update (see

“Windows Update” on
page 4 - 9) in order to

get all the latest security
updates etc.

Move the mouse to the bottom left

Start Screen

Desktop app

of the screen and right-click to
access the menu.

Quick Start Guide

Windows 8.1 Control Panel

Throughout this manual you will see an instruction to open the Control Panel.
R

ight-click the lower left hot corner to bring up the context menu (or use the Win-

dows Logo Key + X key combination)

Desktop app or Start screen.

and select Control Panel in both the

1 - 16 Windows 8.1 Control Panel

Figure 1 - 9 - Windows Context Menu

Quick Start Guide



Keyboard Shortcut to Control Panel

You can also use keyboard shortcuts to access the Contro l Pa nel. Press th e Win dows logo key and X to bring up
the context menu, and then press P to bring up the Control Panel. Alternatively press the Windows logo key and R
to bring up the Run dialog box, and then type “Control Panel” and press Enter to access the Control Panel.

The Control Panel can be accessed in a number of ways in Windows 8.1.

•Click Search in the Windows Charms Bar (see previous page) and the search pane will pop out. Type

Control Panel and select it from the results to the left.

• Click on This PC (in Apps, or you can to pin This PC to the Start screen), click on Computer in the

top menu and select Open Control Panel from the ribbon.

• When in the Desktop app (this does not apply to the Start screen) click on Settings in the Windows

Charms Bar and select Control Panel from the menu.

• Click the arrow at the bottom of the Start screen and click Control Panel in Apps (Windows System).

• Right-c lick the Start button to bring up the menu and select Control Panel (see Figure 1 - 10 on page 1

- 18).

1

Windows 8.1 Control Panel 1 - 17

1



Display Most

Recently Used

Apps

If you are in the Start
screen, Desktop or an
app you can move your
mouse to the upper left
corner of the screen to
get back to the most re­cently used app.

To view all the most re­cently used Apps hover
over the top left of the
screen and then move
the mouse down along
the left side of the
screen to display the
list.

Move the mouse to the bottom left of the screen

and right-click the Start button to access the menu.

Quick Start Guide

Right-click the Start button in the Desktop app (or use the Windows Logo Key

+ X key combination) to bring up an advanced context menu of useful features

such as Control Panel, Programs and Features, Power Options, Task Manager,
Search, File Explorer, Command Prompt, Device Manager and Network Connec­tions etc.

Figure 1 - 10 - Advanced Context Menu (Right-Click Start Button)

1 - 18 Windows 8.1 Control Panel

Quick Start Guide

Desktop App

Windows 8.1 Start Screen & Desktop

The Apps, control panels, utilities and programs within Windows are accessed from the Start screen and/or
Windows Desktop app. The Desktop (which runs as an app within the Start screen) can be accessed by clicking

the Desktop item in the Start screen (or by using the Windows Logo Key + D key combination). Click the
arrow at the bottom of the Start screen to access Apps.

1

Figure 1 - 11 - Windows Start Screen

Windows 8.1 Start Screen & Desktop 1 - 19

1

Click the arrow at the bottom of the
screen to access All Apps

Quick Start Guide

Apps & Tiles

The Start screen will contain a number of apps, and many more will be installed as you add more applications
etc. Not all of these apps can fit on one screen so you will often need use the slider at the bottom of the screen
in order to view all the necessary Apps.

Accessing Pining/Unpinning All Apps

You can add and remove the tiles for apps and control panels in the Start screen. Right-click on an app to bring
up the context menu and you pin the App to (or unpin from) the Start screen, or to the taskbar.

Figure 1 - 12 - Apps

1 - 20 Windows 8.1 Start Screen & Desktop

Quick Start Guide

Move the mouse to the bottom left of the screen and click to switch
back to the Start screen.

Desktop Application

When the Desktop app is running (click the app in the Start screen or use the Windows Logo Key + D key
combination) you can use lower left hot corner to switch between the Start screen and the Windows Desktop
app. To do so move your mouse to hover over the bottom left corner of the Desktop app and left-click.

1

Figure 1 - 13 - Desktop

Windows 8.1 Start Screen & Desktop 1 - 21

1

Move the mouse over a Charms Bar icon to activate the menu

Move the mouse to the top/lower right icons to activate the Charms Bar

Move the mouse to the top/lower right icons to activate the Charms Bar

Quick Start Guide

The Charms Bar

The right side of the screen (Start or Desktop) displays the Charms Bar. The Charms Bar contains the Search,
Share, Start, Devices and Settings menus. To access up the Charms Bar move the cursor to the upper or lower

right corners of the screen, and then hover over one of the items in the Charms Bar to activate it (the bar will
be black when it is active), or use the Windows Logo Key + C key combination.

Figure 1 - 14 - Start Screen with Charms Bar

1 - 22 Windows 8.1 Start Screen & Desktop

Quick Start Guide



Charms Bar - Touchpad Access

To quick access the Charms Bar using the touchpad:

1. Place your finger off the touchpad (slightly to the right of the
pad resting on the computer).

2. Move your finger across to the left on to the touchpad.

3. The Charms Bar will then pop-up.

Charms Bar Items

• Search : You can search for any file, application, Apps and control panel settings with instantaneous

results.

•Share : This button is used to share information with people via mail or social networks.

•Start : Click to bring up the Start screen (the same function as pressing the Windows Logo Key or click-

ing the bottom left of the screen).

• Devices : Click this button to change connected peripheral device settings e.g. an external display.

• Settings : This button gives instant access to the computer settings, such as Network, Audio, Notifica­tions, Power and Keyboard (click Change PC Settings to activate the PC Settings menu).

1

Figure 1 - 15 - Settings Menu

Windows 8.1 Start Screen & Desktop 1 - 23

1

Quick Start Guide

Windows 8.1 Taskbar

In many instances throughout this manual you will see an instruction to access the notification area of the task­bar (system tray). In Windows 8.1 the taskbar can be directly accessed from the Desktop application; if you

are in the Start screen you will need to move the cursor to the bottom of the screen to display the taskbar.
The taskbar is displayed at the bottom of the screen, and you can see the notification area (system tray) of the

taskbar in the bottom right of the screen. Some of the control panels and applications referred to during the
course of this manual can be accessed from here.

Figure 1 - 16 - Taskbar & Notification Area (System Tray)

You can pin/unpin apps to/from the taskbar in much the same way as you can to the Start screen (see “Accessing

Pining/Unpinning All Apps” on page 1 - 20).

1 - 24 Windows 8.1 Start Screen & Desktop

Quick Start Guide

Video Features

You can switch display devices, and configure display options, from the Display control panel (in Appearances
and Personalization) in Windows when running the Desktop app (see “Desktop Application” on page 1 - 21
and Appendix C). It is possible to quickly configure external displays from the Devices menu item in the
Charms Bar (see “The Charms Bar” on page 1 - 22).

To Configure Displays from Devices (Charms Bar):

1. Attach your display to the appropriate port, and turn it on.

2. Go the Charms Bar, select Devices.

3. Click Project (you may need to click Second Screen).

4. Click on any one of the options from the menu to select PC screen only, Duplicate, Extend or Second screen

only.

1

Figure 1 - 17- Devices (Project)

Video Features 1 - 25

1

3

2



Right-Click Desktop App

1. You can right­click the
desktop and
select Screen

resolution

(Figure 1

- 18).

2. Use the
dropbox to
select the
screen
Resolution (Figure 1 - 18).

3. Click Advanced settings (Figure

1 - 18) to bring up the Advanced

properties tabs.

123

1

Quick Start Guide

To access Display (Control Panel) and Screen Resolution in Windows 8:

1. Go to the Control Panel.

2. Click Display (icon) - In the Appearance and Personalization category.

3. Adjust resolution.

1 - 26 Video Features

Figure 1 - 18 - Screen Resolution

Quick Start Guide

3

4

4

To access the Intel(R) HD Graphics Control Panel:

1. Click Advanced settings (Figure 1 - 18 on page 1 - 26) in the Screen Resolution control panel in Win­dows.

2. Click the Intel(R)... tab and click Graphics Properties (button) (Figure 1 - 19 on page 1 - 27) .

OR

3. Right-click the desktop and select Graphics Properties from the menu.

OR

4. Click the icon in the notification area of the Desktop taskbar and select Graphics Properties from the menu.

1

Figure 1 - 19 - Intel Graphics Control Panel

Video Features 1 - 27

1

Charms Bar

Desktop App Start Screen

Power Button Start Screen

Quick Start Guide

Power Options

Power Options (Hardware and Sound) can be accessed from the Control Panel. The Power Menu item in Set-
tings in the Charms Bar in Windows 8.1 may be used to Shut down or Restart (you can also add Hibernate/
Sleep to the menu - see “Adding Hibernate/Sleep to the Power Menu” on page 3 - 10). You can also use the
context menu (Shut down or sign out) shut the computer down/restart etc.

1 - 28 Power Options

Figure 1 - 20 - Shut Down/Restart

Quick Start Guide



Screen Resolution for Apps

(Windows 8.1)

The minimum resolution in which Apps will run is 1024x768.
The minimum resolution required to support all the fe atures of

Windows 8 (including multitasking with snap) is 1366x768.
These specs are the minimum screen resolution that supports

all the features of Windows 8.1 on a useful physical size.

Running Apps

To run apps in Windows 8.1 you will need to check that the Screen Resolution and User Account Control Set­tings are compatible with the system requirements.

Screen Resolution Settings

1. Switch to the Windows Desktop (click the app or use the Windows logo key + D key combination).

2. Right-click a blank area of the Windows Desktop and select Screen Resolution. Adjust the Resolution to
make sure that it is at least 1024 * 768, although preferably 1366 * 768 or above (see sidebar).

1

Figure 1 - 21 - Screen Resolution

Running Apps 1 - 29

1

Quick Start Guide

User Account Control Settings

If your computer meets the minimum screen resolution requirements, and still you can't run apps, then that you
have to check the status of User Account Control (UAC). Apps may fail to open when the UAC is turned off.
To check whether the UAC is on or off, follow the instructions below.

1. Open the Control Panel.

2. Click on User Accounts and then click on Change User Account Control settings (or click System and
Security and click Change User Account Control Settings under Action Center).

3. If the slider is in the Never notify position, then the UAC is disabled.

4. To enable or turn on the UAC, move the slider to Always notif y or Notify me when apps try to make changes

to my computer (default) position, and then click OK.

1 - 30 Running Apps

Figure 1 - 22 - User Account Control

Features & Components

Chapter 2: Features & Components

Overview

Read this chapter to learn more about the following main features and components
of the computer:

• Hard Disk Drive/Solid State Drive

• Multi-In-1 Push-Push Card Reader

• Touchpad and Buttons/Mouse

• Audio Features

2

Overview 2 - 1

Features & Components



Bottom Cover

Removal Warning

Do not remove any cov­er(s) and /or screw(s) for
the purposes of device
upgrade as this may vio­late the terms of your
warranty.

If you need to replace/
remove the hard disk for
any reason, please con­tact your distributor/sup­plier for further
information.

2

Hard Disk Drive/Solid State Drive

The hard disk drive (HDD) and/or solid state drive (SSD) is used to store your data
in the computer. The hard disk can be taken out to accommodate other serial (SATA)
hard disk drives (see “Storage” on page D - 2 for specification information), how­ever you will need to contact your distributor/supplier to do this in order to avoid
violating the terms of your warranty.

2 - 2 Hard Disk Drive/Solid State Drive

Features & Components



Card Reader Cover

Make sure you keep the
rubber cover provided in
the card reader when
not in use. This will help
prevent foreign objects
and/or dust getting in to
the card reader.

Figure 2 - 1

Right View

1. Card Reader

• MMC (MultiMedia Card) / RS MMC

• SD (Secure Digital) / Mini SD / SDHC / SDXC

1

Multi-In-1 Push-Push Card Reader

The card reader allows you to use some of the latest digital storage cards. Push the
card into the slot and it will appear as a removable device, and can be accessed in
the same way as your hard disk (s). Make sure you install the card reader driver (see

“CardReader” on page 4 - 7.

Note: Some of these cards require PC adapters that are usually supplied with the
cards.

2

Multi-In-1 Push-Push Card Reader 2 - 3

Features & Components



Touchpad Active

Areas

Note that the pointing
active area is clearly
defined from the but­ton active area as il-

lustrated.

Figure 2 - 2

Touchpad

Sensitivity

2

Touchpad and Buttons/Mouse

The touchpad is an alternative to the mouse; however, you can also add a mouse to
your computer through one of the USB ports. The touchpad buttons function in
much the same way as a two-button mouse.

Touchpad Sensitivity

The mouse button zones at the bottom of the pad are defined by the line at the bot­tom of the pad, and the left and right buttons are divided roughly down the middle

as illustrated below. The active area of the touchpad/clickpad is that defined in the
diagram below. Press the left button zone for a left click, and right button zone for a
right click action.

2 - 4 Touchpad and Buttons/Mouse

Features & Components



Mouse Driver

If you are using an ex­ternal mouse your op­erating system may be
able to auto-configure
your mouse during its
installation or only en­able its basic functions.
Be sure to check the
device’s user docu­mentation for details.

Figure 2 - 3

Mouse Properties

(ELAN tab) &
Taskbar Icon

Elan Touchpad

Once you have installed the touchpad driver (see “Touchpad” on page 4 - 7) you
can configure the functions by double-clicking the touchpad driver icon in the
notification area of the taskbar (or from Options in the ELAN tab in the Mouse
control panel in Windows). You may then configure the gestures and options to your
preferences.

2

Touchpad and Buttons/Mouse 2 - 5

Features & Components

Figure 2 - 4

Smart-Pad Control

Panel (Button)

2

The Elan Smart-Pad control panel allows you to use a specific gesture (action) on
the surface of the touchpad to perform specific actions to manipulate documents, ob­jects and applications.

Click the menu tabs (One-finger, Multi-finger or Additional) and then the function
button on the left to access the Configuration controls in the right panel. Click the
check box to Enable most of the controls and click Apply to save the settings. Click
the close icon or Yes to close the control panel.

2 - 6 Touchpad and Buttons/Mouse

Click the Function Description button to get a detailed description of any func-

Figure 2 - 5

Smart-Pad Control

Panel with

Function

Description

tion.
Click the Default button to set any of the functions to the default setting.

Features & Components

2

Touchpad and Buttons/Mouse 2 - 7

Features & Components

Figure 2 - 6

Tapping

Figure 2 - 7

Clicking

2

One-Finger

Tapping

One-Finger tapping is equivalent to clicking the left mouse button to perform a
point/click/select function.

Clicking

You can configure actions for two-finger, three-finger and left or right corner
clicking actions from the clicking menu.

2 - 8 Touchpad and Buttons/Mouse

Drag and Drop

Figure 2 - 8

Drag and Drop

Figure 2 - 9

Edge Scroll

You can select the different drag and drop methods from the menu provided. The ob­ject can be released when you lift the finger off the touchpad, when you tap again or
after a set time delay.

Edge Scroll

Enable Vertical or Horizontal Scroll from this menu. You can configure the width
of the scrollable area by adjusting the slider accordingly. To scroll vertically, tap the
right edge of the touchpad and drag the finger up and down. To scroll horizontally,
tap the bottom edge of the touchpad and drag your finger left or right.

Features & Components

2

Touchpad and Buttons/Mouse 2 - 9

Features & Components

Figure 2 - 10

Edge Swipe

2

Edge Swipe

Enable Edge Swipe to use a single finger to scroll from the edges of the touchpad to
perform the designated function in Windows 8.1.

2 - 10 Touchpad and Buttons/Mouse

Features & Components

Figure 2 - 11

Zooming

Figure 2 - 12

Scrolling

Multi-Finger

Zooming

Place two fingers on the touchpad (for best results use the tips of the fingers) and
slide them apart to zoom in, or closer together to zoom out.

Scrolling

The Two-Finger scrolling feature works in most scrollable windows and allows you
to scroll horizontally and vertically. Tap the pad surface and slide both fingers in the
direction required (vertically or horizontally as long as the option is selected).

Note that the scrolling direction is opposite to that of a standard mouse wheel con­figuration.

2

Touchpad and Buttons/Mouse 2 - 11

Features & Components

Figure 2 - 13

Rotation

Figure 2 - 14

Swipe Page

2

Rotation

You can rotate objects by using a two-finger gesture. Touch and rotate using two fin­gers on the pad in the direction required. Alternatively place a finger down on the
pad and rotate the other finger around it in a circular motion (clockwise or counter­clockwise).

Three Finger Swipe

This gesture is used to activate a Page Up/Page Down operation. Swipe three fingers
quickly to the left to go to the previous page, or to the right to go to the next page.
After you release your fingers from the pad the page changes, and make sure to lift
your fingers immediately after the page change.

2 - 12 Touchpad and Buttons/Mouse

Features & Components

Figure 2 - 15

Palm Tracking

Figure 2 - 16

Sensitivity

Additional

Palm Tracking

This feature helps guard against accidental contact such as palms resting on the pad.
Use the slider to adjust the sensitivity of the feature as appropriate.

Sensitivity

Adjust the level of finger pressure required for the cursor to respond from this menu.

2

Touchpad and Buttons/Mouse 2 - 13

Features & Components



Sound Volume

Adjustment

The sound volume level
is set using the volume
control on the Windows
desktop (and the vol-

ume function keys F5/
F6 on the computer).

Click the volume icon in
the taskbar to check the
setting.

Figure 2 - 17

Realtek Audio

Manager

Right-click the icon
to access the menu
above.

Note that many keyboards have built-in controls to allow you to adjust the audio vol­ume.

2

Audio Features

You can configure the audio options on your computer from the Sound control
panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar
notification area/control panel (right-click the taskbar notification area icon to
bring up an audio menu). The volume may also be adjusted by means of the volume
icon in the taskbar or the audio slider in the Settings menu (see sidebar).

2 - 14 Audio Features

Features & Components

Figure 2 - 18

Realtek Audio

Manager -

Recording Setup

Setup for Audio Recording

To record audio sources on your computer at optimum quality follow the instruc­tions below:

1. Go to the

2. Click/tap Realtek HD Audio Manager (Hardware and Sound), or right-click the
taskbar icon and select Sound Manager.

3. Click/tap Microphone Effects (tab) in Microphone (tab), and then click/tap to
select Noise Suppression (button), or adjust the Recording Volume level to
around 60, to obtain the optimum recording quality.

4. Click/tap OK to close the control panel and save the settings.

Control Panel

.

2

Audio Features 2 - 15

Features & Components

2

2-16

Chapter 3: Power Management



OS Note

Power management
functions will vary slight­ly depending on your
operating system. For
more information it is
best to refer to the user’s
manual of your operat­ing system.

Power Management

Overview

To conserve power, especially when using the battery, your computer power man­agement conserves power by controlling individual components of the computer
(the monitor and hard disk drive) or the whole system. This chapter covers:

• The Power Sources

• Turning On the Computer

• Power Plans

• Power-Saving States

• Configuring the Power Buttons

• Battery Information

The computer uses enhanced power saving techniques to give the operating system
(OS) direct control over the power and thermal states of devices and processors. For
example, this enables the OS to set devices into low-power states based on user set­tings and information from applications.

3

Overview 3 - 1

3



Forced Off

If the system “hangs”,
and the Ctrl + Alt + Del
key combination doesn’t
work, press the power
button for 4 seconds, or
longer, to force the sys­tem to turn itself off.

Power Management

The Power Sources

The computer can be powered by either an AC/DC adapter or a battery pack.

AC/DC Adapter

Use only the AC/DC adapter that comes with your computer. The wrong type of AC/
DC adapter will damage the computer and its components.

3 - 2 The Power Sources

1. Attach the AC/DC adapter to the DC-in jack on the right of the computer.

2. Plug the AC power cord into an outlet, and then conne ct the AC power co rd to the
AC/DC adapter.

3. Raise the lid/LCD to a comfortable viewing angle.

4. Press the power button to turn “On”.

Battery

The battery allows you to use your computer while you are on the road or when an
electrical outlet is unavailable. Battery life varies depending on the applications and
the configuration you're using. To increase battery life, let the battery discharge
completely before recharging (see “Battery FAQ” on page 3 - 18).

We recommend that you do not remove the battery. For more information on the bat­tery, please refer to “Battery Information” on page 3 - 14.

Turning On the Computer



Power Button as Stand by or Hibernate Button

You can use the OS’s “Power Options” control panel to set the power button to send the
system into Stand by or Hibernate mode (see your OS’s documentation, or “Configuring

the Power Buttons” on page 3 - 9 for details).

Now you are ready to begin using your computer. To turn it on simply press the pow­er button on the front panel.

When the computer is on, you can use the power button as a Stand by/Hibernate/
Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and
holding the power button for longer than this will shut the computer down). Use
Power Options (Hardware and Sound) in the Windows control panel to configure
this feature.

Power Management

3

Turning On the Computer 3 - 3

Power Management

Figure 3 - 1

Shut Down/Restart

Charms Bar Desktop App Start Screen

Shutting the Computer Down

Note that you should always shut your computer down by choosing the Shut down

3

command as this will help prevent hard disk or system problems. Use the Shut down
or sign out item in the Context Menu (right-click the lower left corner of the screen

to bring up the menu).
You can also use the Power Menu in Settings in the Windows 8.1 Charms Bar. If

you want to add Hibernate/Sleep to the Power Menu see “Adding Hibernate/Sleep

to the Power Menu” on page 3 - 10.

3 - 4 Shutting the Computer Down

Power Plans



Resuming

Operation

See Table 3 - 1, on

page 3 - 11 for informa-

tion on how to resume
from a power-saving
state.

Password

It is recommended that
you enable a password
on system resume in or­der to protect your data.

Figure 3 - 2

Power Plan

Advanced Settings

The computer can be configured to conserve power by means of power plans. You
can use (or modify) an existing power plan, or create a new one.

The settings may be adjusted to set the display to turn off after a specified time, and
to send the computer into Sleep after a period of inactivity.

Click Change plan settings and then click Change advanced power settings to ac­cess further configuration options in Advanced Settings.

Power Management

3

Power Plans3-5

Power Management

Figure 3 - 3

Power Plans

Click to Show/Hide
additional
power plans

3

Each Windows power plan will also adjust the processor performance of your ma­chine in order to save power. This is worth bearing in mind if you are experiencing
any reduced performance (especially under DC/battery power).

Choose High performance (you may need to click Show additional plans to view
the High performance plan) for maximum performance when the computer is pow­ered from an AC power source. Choose the Power saver (bear in mind that this
scheme may slow down the overall performance of the computer in order to save
power) for maximum power saving when the computer is battery (DC power) pow­ered.

3 - 6 Power Plans

Power-Saving States



Wake On LAN

Support

Wake-On-LAN is only
supported from Sleep or

Hibernate states in
Windows.

If you require your com­puter to wake up from
network activity in Win­dows then make sure
that the computer is ei­ther in Sleep or Hiber-
nate.

Wake-On-LAN is not
supported from Shut­down states in Win-
dows.

You can use power-saving states to stop the computer’s operation and restart where
you left off. Win 8.1 uses the Sleep, Hibernate and Shut Down power-saving
states.

Sleep

In Sleep all of your work, settings and preferences are saved to memory before the
system sleeps. When you are not using your computer for a certain length of time,
which you specify in the operating system, it will enter Sleep to save power.

The PC wakes from Sleep within seconds and will return you to where you last left
off (what was on your desktop) without reopening the application(s) and file( s) you
last used.

If your mobile PC in Sleep is running on battery power the system will use only a
minimum amount of power. After an extended period the system will save all the
information to the hard disk and shut the computer down before the battery becomes
depleted.

To add Sleep to the Power Menu see “Adding Hibernate/Sleep to the Power

Menu” on page 3 - 10.

Power Management

3

Power-Saving States 3 - 7

Power Management

Figure 3 - 4

Power Menu

Hibernate

Hibernate uses the least amount of power of all the power-saving states and saves

3

all of your information on a part of the hard disk before it turns the system off. If a
power failure occurs the system can restore your work from the hard disk; if a power
failure occurs when work is saved only to memory, then the work will be lost. Hi-
bernate will also return you to where you last left off within seconds. You should
put your mobile PC into Hibernate if you will not use the computer for a period of
time, and will not have the chance to charge the battery. To add Hibernate to the
Power Menu see “Adding Hibernate/Sleep to the Power Menu” on page 3 - 10.

Shut down

You should Shut down the computer if you plan to install new hardware (don’t for­get to remove the battery and follow all the safety instructions in Chapter 6), plan
to be away from the computer for several days, or you do not need it to wake up and
run a scheduled task. Returning to full operation from Shut down takes longer than
from Sleep or Hibernate.

3 - 8 Power-Saving States

Configuring the Power Buttons



Password

Protection

It is recommended that
you enable a password
on wake up in order to
protect your data.

However you can dis­able this setting from the
Power Options menu
by clicking Require a

password on wakeup

in the left menu, and se­lecting the options (click

Change settings that
are currently unavail­able).

Figure 3 - 5

Power Options

Define Power

Buttons

The power/sleep button (Fn + F12 key combo) and closed lid may be set to send the
computer in to a power-saving state. Click Choose what the power buttons do on
the left menu in Power Options to bring up the menu.

Power Management

3

Configuring the Power Buttons 3 - 9

Power Management

Figure 3 - 6

Power Options

Define Power

Buttons - Shutdown

Settings

3

Adding Hibernate/Sleep to the Power Menu

Add Hibernate/Sleep to the Power Menu as follows.

1. Go to the Power Options (Hardware and Sound) control panel.

2. Click “Change settings that are currently unavailable” .

3. Click Choose what the power buttons do.

4. Click to put a tick in the Hibernate/Sleep box under Shutdown settings.

5. Click Save Changes and close the control panel.

3 - 10 Configuring the Power Buttons

Resuming Operation

Table 3 - 1

Resuming

Operation



Closing the Lid

If you have chosen to
send the computer to
Sleep when the lid is
closed, raising the lid
will wake the system up.



Power Button

When the computer is on, you can use the power button as a Sleep/Hibernate/Shut Down
hot key button when it is pressed for less than 4 seconds (pressing and holding the power
button for longer than this will force the computer to shut down).

You can resume operation from power-saving states by pressing the power button,
or in some cases pressing the sleep button (Fn + F12 key combo).

Power Status

Power Off Off Press the Power Button

Icon Color

To Resume

Power Management

3

Sleep Blinking Green

Press the Sleep Button (Fn + F4 Key Combo)

Off (battery)

Hibernate

Orange (AC/DC adapter)

Display Turned Off Green Press a Key or Move the Mouse/Touchpad

Press the Power Button

Press the Power Button

Configuring the Power Buttons 3 - 11

Power Management



Power Conservation

Modes

The Energy Star setting
will result in maximum
power saving, but with
the possible loss of
some performance.

Setting the mode to Bal-
ance will give power
saving matched with
performance.

Performance will give
optimum computer per­formance but with less
power conservation.

Note that the Energy
Star setting will put the
display into sleep after
no more than 15 min­utes of user inactivity.

Figure 3 - 7

Control Center

3

Power Conservation Modes

This system supports Energy Star power management features that place comput­ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period
of inactivity. Adjust Power Conservation Modes from the Control Center:

1. Press the Fn + Esc key combination to toggle the Control Center on/off.

2. Click either the Performance, Balanced or Energy Star button.

3 - 12 Configuring the Power Buttons

Ctrl + Alt + Delete Key Combination

Figure 3 - 8

Ctrl + Alt + Delete

Menu

You can use the CTRL + ALT + DEL key combination from almost any of the Win­dows 8 interfaces/Apps to bring up a full-screen displaying Lock, Switch User, Log

off, Change a password and Task Manager options. If you click the Power icon
in the lower right corner of the screen a power management option menu appears to
display Sleep, Shut down, and Restart.

Power Management

3

To fully control all the power options (including Hibernate mode) go to the Power
Options control panel and configure the power button, sleep button and lid to per-

form the function selected.

Configuring the Power Buttons 3 - 13

Power Management



Low Battery

Warning

When the battery is criti­cally low, immediately
connect the AC/DC
adapter to the computer
or save your work, oth­erwise, the unsaved
data will be lost when
the power is depleted.

Figure 3 - 9

Battery Icon

(Notification Area) &

Battery Advanced

Settings

3

Battery Information

Follow these simple guidelines to get the best use out of your battery.

Battery Power

Your computer’s battery power is dependent upon many factors, including the pro­grams you are running, and peripheral devices attached. You can set actions to be
taken (e.g. Shut down, Hibernate etc.), and set critical and low battery levels from
power plan Change plan settings > Change advanced power settings (see Figure

3 - 3 on page 3 - 6).

Click the battery icon in the notification area to see the current battery level and
charge status.

3 - 14 Battery Information

Conserving Battery Power



Windows Mobility

Center

The Windows Mobility
Center control panel

provides an easy point
of access for information
on battery status, power
plans used and wireless
device status etc.

Figure 3 - 10

Windows Mobility

Center

•Use a power plan that conserves power (e.g Power saver), however note that

this may have an affect on computer performance.

• Lower the brightness level of the LCD display. The system will decrease LCD
brightness slightly to save power when it is not powered by the AC/DC adapter.

• Reduce the amount of time before the display is turned off.

• Close wireless, Bluetooth, modem or communication applications when they are
not being used.

• Disconnect/remove any unnecessary external devices e.g. USB devices,
ExpressCards etc.

Power Management

3

Battery Information 3 - 15

Power Management

Battery Life

Battery life may be shortened through improper maintenance. To optimize the life

3

and improve its performance, fully discharge and recharge the battery at least
once every 30 days.

We recommend that you do not remove the battery yourself. If you do need to re­move the battery for any reason (e.g. long term storage or system upgrade) see “Re-

moving the Battery” on page 6 - 3.

New Battery

Always completely discharge, then fully charge, a new battery (see “Battery FAQ”

on page 3 - 18 for instructions on how to do this).

Recharging the Battery with the AC/DC Adapter

The battery pack automatically recharges when the AC/DC adapter is attached and
plugged into an electrical outlet. If the computer is powered on, and in use, it will
take several hours to fully recharge the battery. When the computer is turned off but
plugged into an electrical outlet, battery charge time is less. Refer to “LED Indica-

tors” on page 1 - 7 for information on the battery charge status, and to “Battery In­formation” on page 3 - 14 for more information on how to maintain and properly

recharge the battery pack.

3 - 16 Battery Information

Proper handling of the Battery Pack



Caution

Danger of explosion if
battery is incorrectly re­placed.

Replace only with the
same or equivalent type
recommended by the
manufacturer. Discard
used battery according
to the manufacturer’s in­structions.



Damaged Battery Warning

Should you notice any physical defects (e.g. the battery is bent ou t of shape after being
dropped), or any unusual smells emanating from the notebook battery, shut your computer
down immediately and contact your distributor/supplier. If the battery has been dropped we
do not recommend using it any further, as even if the comp uter continues to work with a
damaged battery in place, it may cause circuit damage, which may possibly result in fire. It
is recommended that you replace your computer battery every two years.

• DO NOT disassemble the battery pack under any circumstances

• DO NOT expose the battery to fire or high temperatures, it may explode

• DO NOT connect the metal terminals (+, -) to each other

Power Management

3

Battery Information 3 - 17

Power Management

Figure 3 - 11

Power Plan Create

3

Battery FAQ

How do I completely discharge the battery?

Use the computer with battery power until it shuts down due to a low battery. Don’t
turn off the computer even if a message indicates the battery is critically low, just let
the computer use up all of the battery power and shut down on its own.

1. Save and close all files and application s.

2. Create a power plan for discharging the battery and set all the options to Never.

3 - 18 Battery Information

3. Click Change plan settings (after creating it) and click Change plan settings >

Figure 3 - 12

Change Plan

Settings / Change

Advanced Power

Settings

Change advanced power settings.

Power Management

3

Battery Information 3 - 19

Power Management

Figure 3 - 13

Power Options

Advanced Settings -

Battery

3

4. Scroll down to Battery and click + to expand the battery options.

5. Choose the options below (click Yes if a warning appears):

• Low battery levels = 0%

• Critical battery Levels = 1%

• Low battery action = Do Nothing

• Critical battery action (On battery) = Shut Down

• Critical battery action (Plugged in) = Do Nothing

3 - 20 Battery Information

How do I fully charge the battery?

When charging the battery, don’t stop until the LED charging indicator light changes
from orange to green.

How do I maintain the battery?

Completely discharge and charge the battery at least once every 30 days or after
about 20 partial discharges.

Power Management

3

Battery Information 3 - 21

Power Management



Warranty Warning

Please check with your
service representative
before undertaking any
upgrade procedures to
find out if this will VOID
your warranty.

Figure 3 - 14

Battery Removal

123

4

1

2

3

4

3

Removing the Battery

We recommend that you do not remove the battery yourself. If you do need to re­move the battery for any reason (e.g. long term storage) see below.

1. Turn the computer off, and turn it over.

2. Slide the latch in the direction of the arrow.

3. Slide the latch in the direction of the arrow, and hold it in place.

4. Slide the battery out in the direction of the arrow .

5. Reinsert the battery as illustrated below

.

3 - 22 Removing the Battery

Chapter 4: Drivers & Utilities



Driver Installation &

Power

When installing driv­ers make sure your
computer is powered
by the AC/DC adapter
connected to a work­ing power source.

Some drivers draw a
significant amount of
power during the instal­lation procedure, and if
the remaining battery
capacity is not adequate
this may cause the sys­tem to shut down and
cause system problems
(note that there is no
safety issue involved
here, and the battery will
be rechargeable within 1
minute).

This chapter deals with installing the drivers and utilities essential to the operation or
improvement of some of the computer’s subsystems. The system takes advantage of
some newer hardware components for which the latest versions of most available op­erating systems haven’t built in drivers and utilities. Thus, some of the system com­ponents won’t be auto-configured with an appropriate driver or utility during
operating system installation. Instead, you need to manually install some system-re­quired drivers and utilities.

What to Install

You will need to attach an external DVD drive to install the drivers from th e Device

Drivers & Utilities + User’s Manual disc. Th e disc contains the drivers and utilities

necessary for the proper operation of the computer. Table 4 - 1, on page 4 - 4 lists
what you need to install and it is very important that the drivers are installed by
the method outlined in this chapter, and in the order indicated. Note that the in-
formation included on the following pages is for Windows 8.1 only.

Module Driver Installation

The procedures for installing drivers for the

tooth & WLAN Combo

Wireless LAN, Intel Technology

modules are provided in

and

Blue-

“Modules & Options” on page 6 - 1

Drivers & Utilities

4

.

What to Install 4 - 1

Drivers & Utilities

Driver Installation

1. Insert the Device Drivers & Utilities + User’s Manual disc into the attached DVD drive.

2. Click the message “Tap to choose what happens with this disc.”

3. Click Run autorun.exe.

4. Click Install Drivers (button), or Option Drivers (button) to access the Optional driver menu.

4

4 - 2 Driver Installation

Figure 4 - 1 - Drivers Installer Screen 1

Drivers & Utilities

5. Check the driver installation order from Table 4 - 1, on page 4 - 4 (the drivers must be installed in this order)

which is the same as that listed in the Drivers Installer menu below.

6. Click to select the driver you wish to install, (you should note down the drivers as you install them).

7. Follow the instructions for each individual driver installation procedure as listed on the following pages.

4

Figure 4 - 2 - Install Drivers

Driver Installation 4 - 3

Drivers & Utilities

Win 8.1 Driver Page # Win 8.1 Optional Items Page #

Chipset Page 4 - 7 PC Camera Module (No driver required) Page 6 - 2
Video (VGA) Page 4 - 7 Wire le ss LAN Module Page 6 - 11

4

LAN Page 4 - 7 Bluetooth & WLAN Combo Module Page 6 - 16
CardReader Page 4 - 7 Intel® Rapid Storage Technology Page 6 - 21
Touchpad Page 4 - 7 Intel® Smart Connect Technology Page 6 - 22
Airplane Page 4 - 7 Free F all Data Protection Page 6 - 27
Hot Key Page 4 - 8 3G/4 G Mod ule (No driver required) Page 6 - 31
MEI Driver Page 4 - 8 Trusted Platform Module (No driver required) Page 6 - 36
Audio Page 4 - 8 Wireless Display (No driver required) Page 6 - 42

All drivers provided are for the Windows 8.1 operating system. It is very important that the drivers are
installed by the method outlined in this chapter, and in the order indicated.

Table 4 - 1 - Driver Installation

Note that you need to install both the WLAN & Bluetooth drivers for Intel and 3rd party WLAN & Bluetooth
Combo modules.

4 - 4 Driver Installation
