NetStreams DigiLinX

™

Writing StreamNet Device Drivers

™

Title: Writing StreamNet Device Drivers Document Number: 020014A Original Publication Date: August 14, 2006 Revision Date: February 27, 2007

All brand names, product names, and trademarks are properties of their

respective owners.

3600 W. Parmer Lane, Suite 100

Austin, TX 78727

USA

Phone: +1 512.977.9393

Fax: +1 512.977.9398

Toll Free Technical Support 1-866-353-3496

Contents

Chapter 1: Introduction ................................................................................................................1-1

Introduction to Lua .................................................................................................................. 1-2

Chapter 2: Activating Drivers within DigiLinX Dealer Setup ....................................................2-1

Chapter 3: Handling Commands .................................................................................................3-1

Handling Commands ................................................................................................................ 3-2

Example: Handle_Set ........................................................................................................... 3-2

Chapter 4: Handling Communications ........................................................................................4-1

Chapter 5: Configuration ..............................................................................................................5-1

Chapter 6: Installing the Driver ....................................................................................................6-1

Useful Development Tips .......................................................................................................... 6-7

Chapter 7: Generating Status Reports ........................................................................................7-1

Chapter 8: Diagnostic Messages .................................................................................................8-1

Chapter 9: Reference ....................................................................................................................9-1

Syntax ......................................................................................................................................... 9-1

Control ....................................................................................................................................... 9-1

default_handle_command (command) ................................................................................. 9-1

handle_command(command) ................................................................................................ 9-2

aNode = getSubNode(strNodeName) ................................................................................... 9-2

setStatus(strField, value) ....................................................................................................... 9-3

aString = getStatus(strField, value) ...................................................................................... 9-3

SubNode ..................................................................................................................................... 9-3

aSubNode = createSubNode(strName) ................................................................................. 9-3

aTable = subNodes ................................................................................................................ 9-3

aString = aSubNode.name .................................................................................................... 9-3

aStatus = aSubNode.status .................................................................................................... 9-3

aSubNode:setStatus(strField, value) ..................................................................................... 9-3

aString = aSubNode:getStatus(strField, value) ..................................................................... 9-4

aSubNode:default_handle_command(command) ................................................................. 9-4

aSubNode:handle_command(command) .............................................................................. 9-4

AsciiCommand .......................................................................................................................... 9-4

aString = command.command .............................................................................................. 9-4

aTable = command.params ................................................................................................... 9-4

aString = command.to ...........................................................................................................9-5

iii

Writing Streamnet Device Drivers

aString = command.toNode .................................................................................................. 9-5

aString = command.toSubNode ............................................................................................ 9-5

aString = command.from ...................................................................................................... 9-5

aString = command.fromNode ............................................................................................. 9-5

aString = command.fromSubNode ....................................................................................... 9-5

Stream ........................................................................................................................................ 9-5

aStream = createStream(strPort) ........................................................................................... 9-6

aString = stream:read(max) .................................................................................................. 9-7

stream:write(aString) ............................................................................................................ 9-7

anInteger = stream:available() .............................................................................................. 9-7

stream:startAsyncInput(aFunction, options) ......................................................................... 9-8

stream:stopAsyncInput() ....................................................................................................... 9-8

Status ..........................................................................................................................................9-9

aStatus = createStatus() ......................................................................................................... 9-9

aStatus = status ...................................................................................................................... 9-9

status:setField(field, value) ................................................................................................... 9-9

aString = aStatus:getField(field) ........................................................................................... 9-9

Timer ........................................................................................................................................9-10

aTimer = createTimer(nMS, aFunction) ............................................................................. 9-10

anInteger = aTimer.duration ............................................................................................... 9-10

aTimer:cancel() ................................................................................................................... 9-10

aTimer:queue(nMS) ............................................................................................................ 9-11

Debug ....................................................................................................................................... 9-11

debug(category, …) ............................................................................................................ 9-11

setDebug(category, <”on”|”off”|”toggle”>) ........................................................................ 9-11

Appendix A:Lua 5.0 License ......................................................................................................... A-1

Appendix B:Editing Environments ............................................................................................... B-1

Appendix C:Control Driver Example ............................................................................................ C-1

Appendix D:Audio Driver Example ............................................................................................... D-1

Chapter

Introduction

NetStreams® ships drivers for a variety of third party systems with the DigiLinX™ system. These drivers include Lutron® for lighting, Aprilaire® for HVAC, and GE Concord® for security. Custom installers can use these included drivers with a ControLinX™ to enable DigiLinX control of external systems. Sometimes, the

specific needs of a job require DigiLinX to control different third party systems. The

NetStreams StreamNet™ device driver Application Programming Interface (API) is

designed to enable programmers to interface RS-232 and network devices with the NetStreams DigiLinX system. This gives custom installers the flexibility they need for their jobs.

The DigiLinX system is a combination of hardware, software, and firmware. To understand how to interface third party systems with DigiLinX, programmers must understand the architecture of the system (see Figure 1-1).

User Interface

API

Configuration

Driver

Software

Firmware

Hardwar e

Figure 1-1 DigiLinX Hardware/Software model

In the DigiLinX system, the hardware layer is controlled by firmware. Firmware is controlled and updated by software, which in turn is controlled by configuration files, and drives the User Interface. NetStreams’ engineering team has created an API that

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

1-1

Writing StreamNet Device Drivers

enables DigiLinX to control and be controlled by third party systems using a driver (seeFigure 1-2 ).

Figure 1-2 Connecting 3rd Party Systems to DigiLinX

Device drivers allow two-way interaction with third party hardware devices over a communications subsystem, such as RS-232. The ControLinX device includes the hardware needed to control external systems.

The DigiLinX API is written in a programming language called Lua. Lua is a free, lightweight, procedural language that is designed to be fast and easy to learn for most programmers. Third party drivers must be written in Lua to work with the DigiLinX API.

Third party drivers are composed of objects called Controls. These Controls are represented by all of the functions and variables in the driver’s code. Drivers may also contain code to control subcomponents, called subNodes. DigiLinX treats subNodes as logical entities for both accepting commands and producing status messages. For example, in a lighting system, a subNode might represent a specific lighting load. Commands addressed to this subNode would then only affect that lighting load and all status messages related to the load would be addressed from the subNode.

Introduction to Lua

Lua is a byte-code interpreted language, similar to Java. It provides a small scripting and user-customizable interface to a subset of an application written in C or C++.

Where Java is primarily focused on providing all of the tools necessary to write a complete application, Lua is focused on providing minimal system interfaces and a tightly coupled interface to an underlying application.

The benefits of Lua include:

1-2

 Extension Language – Lua is designed from the ground up to be an extension

language. This is a language solely used to extend the functionality of a larger application. This means there is a two-way interface that easily allows Lua code to invoke native subroutines and vice-versa. The vast majority of the functional

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Introduction

portion of the control system can be written in C/C++ while a minimum of device specific code is written in interpreted Lua.

 Minimal System Interface and Dependence – The Lua virtual machine and its

associated parser/compiler are written in ANSI-standard C with a minimum system interface. There is no operating system (OS) interface defined at the script level.

 Native String Manipulation – The bulk of the necessary string operations

(concatenation, searching, formatting, regular expressions, etc.) are implemented in ANSI C, rather than being implemented in the script language. This provides for substantially improved performance given that the majority of control applications are string parsing and generation.

 Virtual Machine (VM) implementation – The Lua scripting language is compiled

(either at runtime or in advance) into a VM-interpreted language that is subsequently run on a virtual machine designed with the language constraints in mind. This substantially improves performance over similar languages that are fully interpreted.

 Object-oriented – While Lua is not an object-oriented language, there are sufficient

language features that it can be treated as such.

The Lua script engine and its associated tools are licensed under a MIT-style license, which states that it is copyrighted material but free license is granted for commercial and non-commercial usage.

For the full Lua license see Appendix A, Lua 5.0 License on page A-1. Further information on Lua is available either from the web site http://www.lua.org or

Programming in Lua by Roberto Lerusalimschy.

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

1-3

Writing StreamNet Device Drivers

1-4

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Chapter

Activating Drivers within DigiLinX Dealer Setup

Starting with version 1.70, DigiLinX Dealer Setup uses an intelligent lookup to determine if there are custom written drivers present in the system.

In order to load custom written drivers through DigiLinX Dealer Setup, you must first create a new folder called “drivers” under your DigiLinX Dealer Setup install directory and copy the .lua driver file to this directory. In most cases, the directory will be:

C:\Program Files\DigiLinX Dealer Setup\drivers\yourdriverfile.lua

After you have created this folder and copied your driver file into the folder, build your project normally in DigiLinX Dealer Setup. Add a ControLinX or MediaLinX to your project, selecting the GUI type from the dropdown menu (for example, Tuner, Lutron, etc.). When you enter the details for your ControLinX or MediaLinX, Dealer Setup will detect the custom driver in the drivers folder and present the option to select a new .lua driver file.

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

2-1

Writing StreamNet Device Drivers

2-2

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Chapter

Handling Commands

The generation and processing of ASCII-formatted commands is central to the interaction between various StreamNet devices and hence, the heart of a device driver is how it receives and process ASCII commands. Figure 3-1 shows how the StreamNet commands flow.

User Presses GUI

Button

Figure 3-1 StreamNet command flow

GUI code generates a

StreamNet ASCII

command and sends it

to the StreamNet device

StreamNet device

receives and parses

command and sends it to

the Lua driver

StreamNet command is

routed to the appropriate

section of the Lua driver

code

As commands are received by the host StreamNet device, they are parsed to separate out the various addressing fields, ASCII command, and command parameters. Once the command is completely parsed, it is passed to the device driver for handling by the appropriate Lua code. Refer to Figure 3-2 to see how commands are routed within the driver.

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

3-1

Writing StreamNet Device Drivers

NOTE

Streamnet command is routed to the appropriate section of the Lua driver code

Start

Handling Commands

It is always possible to define an appropriate command-specific handler, so that the default_command_hand ler is not needed. Programming bestpractices state that a fallback default_command_hand ler should be defined even if it is not intended for use.

Is the command

addressed to a

subnode?

YesYes

Is there a subnode specific command

handler?

Call subnode specific

command handler

Is there a Control specific command

handler?

Yes

Call Control specific

command handler

Is there a subnode

default command

handler?

Yes

Call subnode default

command handler

Call Control default

command handler

Is there a Control specific c o mmand

handler?

Yes

Call Control specific

command handler

Call Control def ault

command handler

Figure 3-2 Command routing within the driver

For a device driver to receive and handle commands, it is necessary to define Lua functions with predefined names based on the command to be handled. The routine that needs to be defined is “handle_<command>” (where <command> is replaced with the lower cased version of the ASCII command). For example, if a driver needs to handle #SET commands, it needs to define a function handle_set within the driver. As a fall-back mechanism, if no command-specific function is defined, the function “default_command_handler” will be invoked if defined.

If the command is generic to the entire device, the necessary function should be defined in the outermost control scope of the Lua file, and will be invoked with only the command as a parameter.

Example: Handle_Set

function handle_set(cmd) if(cmd.params[1] == “heat”) then

… handle the #set heat command

end end function default_command_handler(cmd)

3-2

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Handling Commands

NOTE

if(cmd.command == “debug”) then

… handle the #debug command

end end

If the command is specific to a particular subNode of the driver, it should be defined as an element in the subNode. It will be passed the subNode itself as its only argument.

subNode.handle_set = function(self, cmd)

if(cmd.params[1] == “heat”) then

… handle the #set heat… command

end end

subNode.default_command_handler = function(self, cmd)

if(cmd.command == “debug”) then

… handle the #debug command

end end

In the previous example, Lua provides a convenient short-cut notation with identical functionality:

function subNode:handle_set(cmd) if(cmd.params[1] == “heat”) then

…

end

3-3

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

3-4

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

NOTE

Chapter

Handling Communications

Most device drivers will need some mechanism for talking to a controlled device. In the StreamNet system, that capability is provided by a generalized I/O Stream mechanism.

A stream can be created using a string-based configuration string, the precise format of which depends on the details of the connection. Once the stream is created, the details of the underlying transport mechanism (such as RS-232, TCP/IP, or some other mechanism) is identical for all streams. This allows the same driver and code to be used to control a device regardless of the physical connection type.

Use the “:” syntax to pass the stream as an argument to the read and write functions.

A stream is created with the createStream function:

stream = createStream(“comm:// 0;baud=9600;parity=n”);

Once created, the stream can be read from and written to using the read and write functions:

input = stream:read() stream:write(input)

Many devices have asynchronous outputs, i.e., outputs that are not in direct response to some command being sent down. The preferred mechanism of dealing with such responses is to define and enable an asynchronous response handler:

function input(stream, line) … handle async response in “line” end

stream:startAsyncInput(input, {endString = “\n”})

4-1

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

4-2

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Chapter

Configuration

As for any other StreamNet service, a StreamNet service with a Lua driver is configured by including an appropriate service tag within the config_current.xml file. In the case of standard StreamNet device types, the clause will be automatically generated, but in the case of custom device types, the clause may need to be manually generated.

<service serviceNumber=”2” serviceName=”AprilAire”

serviceType=”gpio” enabled=”1”> <control controlType=”SCRIPT”>

<SCRIPT_DATA>

-- lines here are passed to the lua interpreter before

-- the driver file is loaded config = {}; config.port = “comm://0;baud=9600”;

</SCRIPT_DATA>

</SCRIPT> </control> </service>

The SCRIPT_DATA block defines a section of Lua that will be passed to the interpreter before the driver is loaded, allowing for installation specific parameters, such as the port settings above, to be passed to the driver.

NOTE: The serviceType in this example is currently required to be “gpio,” and the

serviceNumber is a device specific constant (always 2 in the case of a CL100 or CL100A)

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

5-1

Writing StreamNet Device Drivers

5-2

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Chapter

Installing the Driver

After writing a driver, you must load it for use with the DigiLinX network. This chapter provides step by step procedures for installing and running an example driver

for a Panamax® power conditioner. If you have any questions concerning DigiLinX Dealer Setup, refer to the DigiLinX Dealer Setup Manual located on the Dealer Documents page of the NetStreams website.

WARNING! You can only load drivers with DigiLinX Dealer Setup versions 1.5 or

higher.

1. Add a ControLinX configured for General Purpose Driver, Serial (see Figure 6-1).

Figure 6-1 Add a ControLinX

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

6-1

Writing StreamNet Device Drivers

2. Using Windows Explorer, copy the driver you have written to C:\Program

NOTE: In this case you are copying to \07_17_2006\drivers.

Files\DigiLinX Dealer Setup\upgrades\<latest folder date>\drivers.

Figure 6-2 Copying the driver to the hard drive

From DigiLinX Dealer Setup, highlight the ControLinX and select the IR/RS-232

tab.

4. Enter the filename of your driver file in the driver file text box of your ControLinX

configuration:

6-2

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Figure 6-3 Entering the driver file name

Installing the Driver

Select Labels and enter button presets.

NOTE: This procedure creates the individual buttons that will control this device. The

ID field corresponds to the driver subNode, while the Button Label is the first label that appears on the GUI buttons.

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

6-3

Writing StreamNet Device Drivers

Figure 6-4 Entering Button Presets

Select the Menu tab and select Enable a Menu for this Room.

NOTE: Ensure that rooms requiring control of this device have this menu enabled.

6-4

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Installing the Driver

Figure 6-5 Enable menu for rooms

Select the button to send the configuration to all devices (see Figure 6-6).

NOTE: Wait for the ControLinX to restart.

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

6-5

Writing StreamNet Device Drivers

Figure 6-6 Sending configuration to all devices

The Control icon (see Figure 6-7) and buttons (see Figure 6-7) display.

Figure 6-7 Control icon

6-6

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Figure 6-8 Buttons

Useful Development Tips

Installing the Driver

 Always compile your script (using your editor’s compile option, or luac.exe)

before transferring the driver to the ControLinX. While this only checks syntax errors, it will save time when they appear.

 Use the categorized debug logging to filter your messages, and turning on only the

level you need.

 If you have communication problems, even if they are only in one direction, verify

that you are using the right COM port parameters, and that you don’t need a null modem adapter.

 Y ou can add the attribute autoStart to the SCRIPT block in config_current.xml

and set it equal to 0 to keep the script from loading automatically.

 You can send the ASCII commands #script start and #script stop to

the service for your driver to start and stop the service. This is useful for starting the script with autoStart=0. You can also stop your script, copy a new version, and then start it again to run the new version without restarting the device. Something to keep in mind when using this method is that global variables are kept between stop and start. Although this can be useful (your current debug filter settings are kept for example) you need to take care when performing operations that modify the global state.

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

6-7

Writing StreamNet Device Drivers

6-8

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Chapter

Generating Status Reports

In almost all cases, the generation of the status reports used by the User Interface is automated. A status report takes the form of a #report ASCII command:

#report {{<report type=”state” field=value…}}

To update the generated status report is to update the responsible status object with the appropriate field/value pairs. The status report is then generated and transmitted.

As examples, if the base device needs to generate status reports with a time stamp field, include the code:

setStatus(“timeStamp”, os.uptime())

Care is automatically taken to insure that excessive status reports are not generated, rather they are specifically only generated as the status itself is modified.

As another example, if a subNode needs to report a status containing a temperature field, include the code:

zone:setStatus(“temperature”, zone.currentTemperature)

NOTE: When a subNode is modifying its status variables it should use the “:” notation

to insure that the zone is passed to the setStatus routine.

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

7-1

Writing StreamNet Device Drivers

7-2

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Chapter

Diagnostic Messages

Diagnostic messages can be output to the debug viewer using the debug function. The debug function operates similarly to print when only one parameter is passed. When two or more parameters are passed, the first argument is converted to a string and use to a filter the display of that message, based on the current filter settings. Filter settings can be changes using the setDebug function or the #debug ASCII command. Filtering for all categories defaults to off.

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

8-1

Writing StreamNet Device Drivers

8-2

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Syntax

Chapter

Reference

This section defines the StreamNet extensions to the standard Lua function calls defined in the Lua manual, which can be found at http://www.lua.org/manual/5.1/.

In the descriptions below, the following notations are used:

 aType = indicates that the function returns an item of the indicate type, or that a

variable is of the indicated type

Control

default_handle_command (command)

 aType: indicates the indicated function should be invoked or defined with the

“:” operator as the “self” argument of type “aType” must always be

given.

 aType. indicates the standard lua table lookup rules apply

For purposes of simplicity, all the basic control functions are directly defined in the outer scope of a Lua driver. In most cases, the only required entries here are the handle_command entries necessary to handle the commands important to the driver itself.

default_handle_command is the last effort command handler and is used only if there is no handle_command function defined to specifically handle a given command.

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

9-1

Writing StreamNet Device Drivers

NOTE

Strictly speaking, this function need never be defined or used since any command will first be handled by the type specific handler.

handle_command(command)

The single argument is an AsciiCommand table as documented in Chapter 2, Handling

Commands on page 3-1. The driver can define a handle_command method to handle

the incoming ASCII command “#command …”. The driver can define a handle_command method to handle the incoming ASCII command “#command …”command method to handle the incoming ASCII command “#command …”

The single argument is an AsciiCommand table as documented in Chapter 2, Handling

Commands on page 3-1.

For more information on command handling see Chapter 2, Handling Commands on page 3-1.

The driver can define a handle_command method to handle the incoming ASCII command “#command …”

The single argument is an AsciiCommand table as documented in The driver can define a handle_command method to handle the incoming ASCII command “#command …”. The driver can define a handle_command method to handle the incoming ASCII command “#command …”_command method to handle the incoming ASCII command “#command …”

9-2

The single argument is an AsciiCommand table as documented in Chapter 2, Handling

Commands on page 3-1.

aNode = getSubNode(strNodeName)

Returns the node associated with strNodeName by fetching subNodes[strNodeName]. Device drivers may replace this routine with one of their own if they wish to create

nodes on the fly as they are addressed by commands. Such an implementation might look like:

function getSubNode(strNodeName) if(subNodes[strNodeName] == nil) then

node = createSubNode(strNodeName) … do some more initialization here

else

node = subNodes[strNodeName] end return node end

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

setStatus(strField, value)

aString = getStatus(strField, value)

SubNode

aSubNode = createSubNode(strName)

Reference

This extension updates the value of a particular field in the associated status object. This is shorthand for status.setField(field, value). A status field can be deleted by setting it’s value to nil.

Returns the value for the field specified, or nil if the field has not yet been defined.

createSubNode is invoked to create a new named subNode. The newly created subNode is automatically registered with the control by placing it in the subNodes table using strName as an index. The newly created subNode will have an empty status object associated with it and only minimal commands will be handled.

aTable = subNodes

subNodes is a table containing each of the subNodes created with createSubNode, indexed by subNode name.

aString = aSubNode.name

Holds the name of the subNode as set in createSubNode. Once created the name of the subNode should not be altered.

aStatus = aSubNode.status

This extension holds the status object for the subNode. Under normal circumstances the setStatus and getStatus methods should be used in lieu of directly accessing the status object.

aSubNode:setStatus(strField, value)

Updates or creates a status report field with the indicated value. If the value is actually being changed this will trigger the automatic generation of a status report when the execution of the current command, timer, or async input function is completed. A field that is no longer appropriate can be deleted by calling aSubNode:setStatus(strField, nil)

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

9-3

Writing StreamNet Device Drivers

aString = aSubNode:getStatus(strField, value)

Fetch the most recently assigned value of a status report field. If the report field is currently undefined, nil will be returned.

aSubNode:default_handle_command(command)

default_handle_command is the last effort command handler and is used only if there is no handle_command function defined to specifically handle a given command. Strictly speaking, this function need never be defined or used since any command will first be handled by the type specific handler.

The single argument is an AsciiCommand table as documented in Chapter 2, Handling

Commands on page 3-1. The driver can define a handle_command method to handle

the incoming ASCII command “#command …”command method to handle the incoming ASCII command “#command …”

The single argument is an AsciiCommand table as documented in Chapter 2, Handling

Commands on page 3-1.

aSubNode:handle_command(command)

The driver can define a handle_command method to handle the incoming ASCII command “#command …”

The single argument is an AsciiCommand table as documented in Chapter 2, Handling

Commands on page 3-1.

AsciiCommand

An AsciiCommand object contains the information and parameters contained in an incoming ASCII command.

aString = command.command

The lower-cased string version of the command itself. For example, in the case of “#SET FAN,OFF” command.command would contain “set”.

aTable = command.params

A 1-based vector of the parameters specified to the command; e.g., in the case of “#SET FAN,OFF”, command.params would contain:

command.params = {

[1] = “FAN”,

[2] = “OFF” }

9-4

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Individual parameters can be referenced as command.params[n] where n is between 1 and the number of command specified.

aString = command.to

The entire to address as specified in the original command. Contains nil if no address was specified.

aString = command.toNode

The node portion only of the address specified in the original command. If the to address given was “@Aprilaire~zone1”, then toNode would contain “Aprilaire”. Contains nil if no address was specified.

aString = command.toSubNode

The subNode portion of the address specified in the original command. If the to address given was “@Aprilaire~zone1”, then toNode would contain “zone1”. Contains nil if no address was specified or if no subNode was specified in the original address.

Reference

aString = command.from

aString = command.fromNode

aString = command.fromSubNode

Stream

The entire from address as specified in the original command. Contains nil if no address was specified.

The node portion only of the from address specified in the original command. If the from address given was “:Aprilaire~zone1”, then fromNode would contain “Aprilaire”. Contains nil if no address was specified.

The subNode portion of the from address specified in the original command. If the from address given was “:Aprilaire~zone1”, then fromNode would contain “zone1”. Contains nil if no address was specified or if no subNode was specified in the original address.

Creating a stream allows a device driver to communicate with an external device by RS-232 or TCP/IP. More connection types may be defined in the future. Once the stream has been created, data can be read from or written to the stream with no regard

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

9-5

Writing StreamNet Device Drivers

for the underlying transport mechanism. Facilities are also provided for handling of asynchronous streams with defined message boundaries with no need on the drivers’ part for explicitly polling the stream.

aStream = createStream(strPort)

Creates a new stream from the string specification in strPort. The form of strPort is:

Where protocol and address are taken from the table below:

comm 0 .. # of supported device ports Opens an RS-232 serial connection

{protocol}://{address}[;{options}…]

Protocol Address Comments

socket {host}:{port} Opens a TCP/IP connection to the indicated

host and port.

9-6

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

NOTE

aString = stream:read(max)

Mixing synchronous input via read and asynchronous input via startAsyncInput will yield inconsistent and variable results. If mixing is required, async input should always be stopped via stopAsyncInput before read is used.

Reference

In the case of the socket protocol, no options are currently supported. In the case of the comm protocol, the following options may be specified:

Key Value Default

baud 300,1200,2400,9600,19200 9600 parity odd,even,none None bits 8 8 stop 1 1

Reads data from the stream and returns it in the form of a string. If max is specified, no more than max characters will be returned. This call will never block, but rather will return whatever data is immediately available up to the specified maximum.

stream:write(aString)

Writes data from a string to the stream.

anInteger = stream:available()

Returns the number of bytes of data immediately available on the port.

9-7

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

NOTE

stream:startAsyncInput(aFunction, options)

Enables asynchronous input on the associated stream. Has completed “messages” are received aFunction will be invoked with the stream and message as parameters. The options parameter contains an optional table that can be used to define a “message”:

Key Default Notes

endString Nil If non-nil defines a string which will be used to recognize the end of a

message. Common values might be “\r”, “\n”, or “\r\n” Completed messages will contain all the data between endString terminators and the terminator itself.

timeout 0 If > 0 specifies the maximum time to wait for any input. Every “timeout” ms

any available data will be passed to the input function.

readIdle 0 If > 0 specifies the maximum time to wait while no data is being received. If

the readIdle timeout elapses with no new data being received any available data will be passed to the input function.

maxRead 1024 The maximum # of characters to process before invoking the input

function.

trailing 0 If > 0 specifies that additional data should be returned after a message has

be recognized based on an endString. So specifying an endString of “\n” and a trailing of 2 would return the all text up to and including the newline and the following two characters.

Asynchronous input is not truly asynchronous as the input function will never interrupt execution of an asynchronous stream handler, command handler, or timer handler.

stream:stopAsyncInput()

The options parameter is in the form of a table, such as:

Stream:startAsyncInput(onInput, {

endString = “\r”, trailing = 2

})

Stops asynchronous input previously started with startAsyncInput.

9-8

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Status

aStatus = createStatus()

aStatus = status

status:setField(field, value)

Reference

Creates and initializes a new status object. Under normal circumstances this function is unneeded by the developer since the

status objects for the control and subNodes are automatically created.

Contains the status object for the control.

Updates a field in the status report and triggers status report generation “soon” Assigning a field the value of nil will remove it from the report.

aString = aStatus:getField(field)

Returns the value of a field in the status report.

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

9-9

Writing StreamNet Device Drivers

NOTE

Timer

Timers are used to schedule a function to be called at some predetermined time in the future.

Due to the scheduling inconsistencies in a multi-tasking environment, the only guarantee that can be made about when the timer will be executed is that it will be executed no sooner than the time specified in the createTimer call. No real guarantees can be placed on the maximum time that will elapse before the timer is executed.

Timers are not truly asynchronous events as they will never interrupt execution of an asynchronous stream handler, command handler, or another timer handler.

aTimer = createTimer(nMS, aFunction)

anInteger = aTimer.duration

Creates a timer object and schedules it for execution in nMS milliseconds. When the timer executes it will invoke aFunction with the timer itself as it’s sole parameter. If the timer function returns a non-zero value, the return value will be used to reschedule the timer at another future time.

The duration last specified for the timer, either in createTimer, queue, or as a return value from timer execution.

aTimer:cancel()

Cancels the timer and prevents any future execution until queue is called.

9-10

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

NOTE

aTimer:queue(nMS)

Debug

debug(category, …)

Reference

Queues the timer object to be executed in nMS milliseconds subject to the vagaries of operating system scheduling. If the timer is already queued for execution, the timeout will be rescheduled.

The category is coerced to a lower case string before any processing is done. The special category “all” controls all categories. The default filtering for all messages is off.

setDebug(category, <”on”|”off”|”toggle”>)

Displays in the Debug Viewer the remaining (…) parameters if debug filtering is on for category. If there is only one parameter, it is always displayed in the debug viewer. Parameters are displayed concatenated with a tab character.

Enables, disables or toggles display of messages for the given category. If the given category is “all” then the operation will apply to all messages. The equivalent ASCII command is:

#@Service#debug category <on|off|toggle>

9-11

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

9-12

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Lua 5.0 License

Appendix

Lua 5.0 License

software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions:

The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software.

THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

A-1

Writing StreamNet Device Drivers

A-2

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Editing Environments

Appendix

Editing Environments

There are a number of editors with varying degrees of support for editing Lua. Some include:

Name URL Notes

Gnu emacs

Lua Edit

UltraEdit

http://www.gnu.org/software/emacs/emacs.html

http://luaforge.net/projects/lua-mode/

http://www.luaedit.net/ http://www.ultraedit.com/

http://lua-users.org/files/wiki_insecure/editors/ UltraEdit_wordfile_Lua5.txt

For UNIX

Designed for Lua

Very powerful and commercial developer’s editor.

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

B-1

Writing StreamNet Device Drivers

B-2

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Control Driver Example

Appendix

Control Driver Example

This example shows how to control a Panamax MAX 5410 Pro AC power source via its RS-232 interface. The driver will create six control subNodes which will represent six buttons, each having a distinct function. These buttons can then be displayed on the DigiLinX GUI. The subNodes will represent the following functions:

subNode Function Description

1 Power On Initiates power-on sequence 2 Power Off Initiates power-off sequence 3 Switched Cycles power to the switched outlets 4 High Current Cycles power to the high current outlets 5 All Off Turns off all outlets 6 Cycle Initiates a power-cycle sequence The example uses a user created function, createButton, to encapsulate the repetitive

tasks for creating each of the button subNodes. Each subNode will have four variables, Name, the name of the subNode used for addressing, xmit, the RS-232 string to transmit when the button is pressed, Label, the text that will appear on the GUI button face, and indicatorState, which will determine whether or not the indicator LED on the GUI button will be on or off. Each subNode will also contain one function, handle_button, which is called whenever the corresponding GUI button is pressed.

Because of the way Lua parses the source files, the functions that the example uses must be defined before they are actually used, so that is why the functions will appear first.

C-1

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

The example also uses two timer driven functions, pollResponse and queryStatus. The first function, pollResponse, reads data from the serial port every second looking for messages from the device. Depending on what the response is, the driver may turn the indicatorState variable on or off (1 or 0 respectively). The second function queryStatus will send a query to the device every 10 seconds to ensure that the driver stays in sync with the device. These functions are created by calling the createTimer function.

-- The service itself is set up with a subNode for

each of the switchable

-- power supplies (switchable outlets and high power

outlets) and a subNode

-- for all power. Each zone responds to a #BUTTON

PRESS by sending out

-- the requested command and then issuing an

?OUTLETSTAT to find out which

-- outlets are on.

-- To allow the GUI to display an appropriate label

on the button, each

-- subNode also reports status in the common form:

-- <report type="indicatorState" label="<label

text>" indicatorState="<0/1>" />

-- We have to create our functions first then we can

use them below

-- function createButton( Name, Label, xmitString )

-- create a button node

function createButton( Name, Label, xmitString )

-- create a subNode for each button

local node = createSubNode(Name)

-- the serial to xmit string that dealer setup writes

for us

-- has escape sequences so that special characters

like newlines

-- and nulls can be embedded in the string to

send. Each escape

C-2

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Control Driver Example

-- consists of %XX where XX is two hexadecimal characters. We

-- have to replace each escape with it's corresponding single

-- character

if(xmitString) then

node.xmit = decodeString(xmitString)

end

-- set the newly created button up to handle the #BUTTON command

function node:handle_button(cmd)

-- we just handle #BUTTON PRESS by sending our

string

if(cmd.params[1]:upper() == "PRESS" and

self.xmit ~= nil) then

g_serial:write(self.xmit)

-- Only change to the button set up

routine is to call

-- queryStatus after sending the text

to find out what

-- state the panamax is currently in pollResponse()

end

-- set the label field in the status report

node:setStatus("label", Label)

-- assume an initial "off" state

node:setStatus("indicatorState", "0") end

-- function pollResponse()

-- Function that checks to see if there is anything on the COM port

function pollResponse()

-- read and parse the response

C-3

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

local response = g_serial:read()

if(response ~= nil) then

if(response:find("MAINACON")) then

getSubNode("1"):setStatus("indicatorState", "1")

getSubNode("2"):setStatus("indicatorState", "0")

elseif(response:find("MAINACOFF")) then

getSubNode("1"):setStatus("indicatorState", "0")

getSubNode("2"):setStatus("indicatorState", "1")

end

if(response:find("SWITCHEDON")) then

getSubNode("3"):setStatus("indicatorState", "1")

elseif(response:find("SWITCHEDOFF")) then

getSubNode("3"):setStatus("indicatorState", "0")

end

if(response:find("HICURRENTON")) then

getSubNode("4"):setStatus("indicatorState", "1")

elseif(response:find("HICURRENTOFF")) then

C-4

getSubNode("4"):setStatus("indicatorState", "0")

end

-- check for responses again in a second

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Control Driver Example

return 200

end

-- function queryStatus()

-- query the Panamax to see if anything has changed

function queryStatus()

-- request the status so we know the initial state of everything

g_serial:write("?OUTLETSTAT\r");

-- try again in a second if this is from a timer

return 10000

end

-- Now run the main code

-- Check to see if the COM port has been overridden by Dealer Setup

if( config == nil ) then

config = {} end

-- If the COM port doesn't exist, setup the default

if( config.port == nil ) then

config.port = "comm://0;baud=9600;parity=none" end

-- open the serial port and ready it for writing

g_serial = createStream(config.port)

if(g_serial == nil) then

print("Unable to open stream \""..config.port.."\"")

return

end

-- Create buttons

createButton("1", "Power On","POWERON\r")

C-5

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

createButton("2", "Power Off","POWEROFF\r") createButton("3", "Switched","CYCLESW\r") createButton("4", "High Current","CYCLEHC\r") createButton("5", "All Off","ALLOFF\r") createButton("6", "Cycle","CYCLE\r")

-- create a timer to call queryStatus every 10 seconds

createTimer(10000, queryStatus)

-- every one second call pollResponse to check for asynchronous responses

-- (stuff it sends without being asked)

createTimer(1000, pollResponse)

C-6

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Audio Driver Example

Appendix

Audio Driver Example

The following example audio and control drivers in commented code-form are available as further resources.

All drivers can be found in your DigiLinX Dealer Setup folder under the ./upgrades/ [MM-DD-YYYY]/drivers/ folder. Open the .lua file with your preferred text editor to see the complete commented code created by NetStreams engineers.

Parasound zTuner

-- zTuner.lua

-- driver for Parasound Ztuner V1 and V2

-- file version 1.0.0

-- There are many places where we check to see if we are a V1 or V2 tuner

since their protocols

-- are different. The V2 protocol is more straight forward than the V1 as

will be evident in

-- how much extra work is required to setup the outgoing tune commands and

with the extra work

-- required to know what piece of information we are currently expecting

back from the tuner

-- (this is the FREQUENCY_FIRST, LAST, BAND, etc stuff)

-- DigiLinX command handler:

-- function handle_band(command)

-- function handle_clear(command)

-- function handle_key(command)

-- function handle_next(command)

-- function handle_preset(command)

-- function handle_prev(command)

-- function handle_scan(command)

-- function handle_seek(command)

-- function handle_tune(command)

-- Other functions:

-- function CheckPower()

-- Send command to check power state of tuner

-- function OnAsyncInput(stream, message)

D-1

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

-- Get and Process Input from Serial Port

-- function PerformReset()

-- Perform a soft reset of the zTuner when we seem to have lost

communications

-- function QueryStatus()

-- Periodically query for the frequency of the tuner. This is more

important with V1 tuners that have no unsolicited messages

-- function RefreshFrequency()

-- Send command to get the frequency from tuner

-- function RequestV2Status()

-- Send command to refresh the V2 tuner's status info

-- function SendPower(bOn)

-- Send command to power the tuner on (or off)

-- function WriteMessage(message)

-- Decode and send commands to the tuner

-- uncomment the next line for any hope of debugging startup issues

-- setDebug("all", "on")

setDebug("error", "on")

debug("Driver loading")

-- setup our constants

IDLE = 0

FREQUENCY_FIRST = 1

FREQUENCY_LAST = 2

BAND = 3

POWER_STATE = 4

FM = 0

AM = 1

BANDNAME = {

[FM] = "FM ",

[AM] = "AM "

}

-- setup our module variables

serialPort = nil

bIsV2 = false;

szFreq = "---.-"

nResponseTimeout = 0

nExpectedRX = IDLE

nRefreshPowerTimeout = 5

nRefreshFreqTimeout = 0

nTimeouts = 0

nBand = FM

szInput = ""

szPwrOn = "0"

D-2

-- We have to create our functions first then we can use them below

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

-- function OnAsyncInput(stream, message)

-- Diego Alfarache

-- 09-20-2006

-- Get Input from Serial Port

function OnAsyncInput(stream, message)

debug("verbose", message)

local start = 0

if( message == nil ) then

return

end

if( message:find("[*]")) then

bIsV2 = true

local Power = message:match("PW(.)")

local Band = message:match("BD(.)")

local Frequency = message:match("FR(......)")

local Preset = message:match("PR(..)")

Audio Driver Example

if( Power ) then

debug("verbose", "Power = "..Power)

if( Power == "0" ) then

-- power is off

bPwrOn = "0"

SendPower( true )

else

bPwrOn = "1"

end

if( Band ) then

debug("verbose", "Band = "..Band)

if( Band == "1" ) then

nBand = FM

elseif( Band == "2" ) then

nBand = AM

end

if( Frequency ) then

-- skip past any leading zeros

local start = Frequency:find("[123456789]")

Frequency = Frequency:sub(start,-1)

if( nBand == AM ) then

szFreq = "AM "..Frequency

D-3

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

elseif( nBand == FM ) then

szFreq = "FM "..Frequency

else

szFreq = Frequency

end

setCaption(szFreq)

debug("verbose", "Frequency is "..szFreq)

end

else

-- This is all V1 Stuff

if( nExpectedRX == FREQUENCY_FIRST ) then

if( message:len() >= 2 ) then

message = message:match("%d+")

local nMessage = tonumber(message)

then we assume that the band is AM

end

nExpectedRX = FREQUENCY_LAST

elseif( nExpectedRX == FREQUENCY_LAST ) then

-- if the first part of the frequency is less than 20

if( nMessage < 20 ) then

nBand = AM

szFreq = "AM "

else

nBand = FM

szFreq = "FM "

end

szFreq = szFreq..message

D-4

if( message:len() > 2 ) then

message = message:match("%d%d")

if( nBand == AM ) then

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

szFreq = szFreq..message

else

szFreq = szFreq.."."..message

end

setCaption(szFreq)

end

nExpectedRX = IDLE

nResponseTimeout = 0

nTimeouts = 0

elseif( nExpectedRX == POWER_STATE ) then

if( message:find("[0]") ) then

SendPower( true )

end

nExpectedRX = IDLE

nResponseTimeout = 0

nTimeouts = 0

else

Audio Driver Example

debug("verbose", "Unexpected Response "..message)

end

UpdateSongReport()

end

-- function UpdateSongReport()

-- Cristian Prundeanu

-- 10/23/2006

function UpdateSongReport()

local songReport = songReportInstance()

local strCaption = BANDNAME[nBand] or ""

songReport:setField("band", strCaption)

strCaption = strCaption..szFreq

-- currently, the only used field in the zTuner GUI is "caption"

songReport:setField("caption", strCaption)

songReport:setField("frequency", szFreq)

songReport:setField("pwrOn", szPwrOn)

end

D-5

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

-- function WriteMessage(message)

-- Diego Alfarache

-- 09-20-2006

-- Decode string and write to the stream (serial port)

function WriteMessage(message)

debug("verbose", "Sending "..message)

-- call decodeString() to convert %XX to actual ASCII values

xmitMessage = decodeString(message)

serialPort:write(xmitMessage)

end

-- function handle_tune(command)

-- Diego Alfarache

-- 09-20-2006

-- Receive and process #TUNE commands

function handle_tune(command)

if( command == nil ) then

return

end

local AsciiMessage = ""

local dir = command.params[1]:upper()

if( dir == "DN" ) then

if( bIsV2 == true ) then

AsciiMessage = "W 1 6 4%0D"

else

AsciiMessage = "W 1 7 4%0D"

end

elseif( dir == "UP" ) then

if( bIsV2 == true ) then

AsciiMessage = "W 1 6 3%0D"

else

AsciiMessage = "W 1 7 3%0D"

end

D-6

else

-- look to see if the frequency has a dot in it. If it does, assume it

is FM

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

local dot = command.params[1]:find("[.]")

if( bIsV2 == true ) then

AsciiMessage = "W 1 7 "

else

AsciiMessage = "W 1 6 "

end

if( dot ~= nil) then

-- FM --

AsciiMessage = AsciiMessage..command.params[1]:sub(1,dot-1)

if( bIsV2 ) then

AsciiMessage = AsciiMessage.."."

else

AsciiMessage = AsciiMessage.." "

end

AsciiMessage = AsciiMessage..command.params[1]:sub(dot+1,-1)

-- Check to see if we need a trailing zero

if( command.params[1]:len() < dot + 2 ) then

AsciiMessage = AsciiMessage.."0"

end

Audio Driver Example

AsciiMessage = AsciiMessage.."%0D"

else

-- AM --

if( bIsV2 ) then

AsciiMessage = AsciiMessage..command.params[1]

else

if( command.params[1]:len() < 4 ) then

AsciiMessage =

AsciiMessage..command.params[1]:sub( 1, 1 ).." "..command.params[1]:sub( 2, 4 )

else

AsciiMessage =

AsciiMessage..command.params[1]:sub( 1, 2 ).." "..command.params[1]:sub( 3, 5 )

end

AsciiMessage = AsciiMessage.."%0D"

end

WriteMessage(AsciiMessage)

-- if we are a V1 we need to update the frequency

if( false == bIsV2 ) then

D-7

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

nRefreshFreqTimeout = 0

RefreshFrequency()

end

-- function handle_seek(command)

-- Diego Alfarache

-- 09-20-2006

-- Receive and process #SEEK commands

function handle_seek(command)

if( command == nil ) then

return

end

local AsciiMessage = ""

local dir = command.params[1]:upper()

if( dir == "DN" ) then

if( bIsV2 == true ) then

AsciiMessage = "W 1 6 2%0D"

else

AsciiMessage = "W 1 7 2%0D"

end

elseif( dir == "UP" ) then

if( bIsV2 == true ) then

AsciiMessage = "W 1 6 1%0D"

else

AsciiMessage = "W 1 7 1%0D"

end

WriteMessage(AsciiMessage)

-- if we are a V1 we need to update the frequency

if( false == bIsV2 ) then

nRefreshFreqTimeout = 0

RefreshFrequency()

end

D-8

-- function handle_scan(command)

-- Diego Alfarache

-- 09-20-2006

-- Receive and process #SCAN commands

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Audio Driver Example

-- since the Parasound Ztuner doesn't have a scan feature we will just call

our seek function

function handle_scan(command)

handle_seek(command)

end

-- function handle_preset(command)

-- Diego Alfarache

-- 09-20-2006

-- Receive and process #PRESET commands

function handle_preset(command)

if( command == nil ) then

return

end

local AsciiMessage = ""

local dir = command.params[1]:upper()

if( dir == "DN" ) then

AsciiMessage = "W 1 3 4%0D"

elseif( dir == "UP" ) then

AsciiMessage = "W 1 3 3%0D"

end

WriteMessage(AsciiMessage)

-- if we are a V1 we need to update the frequency

if( false == bIsV2 ) then

nRefreshFreqTimeout = 0

RefreshFrequency()

end

-- function handle_next(command)

-- Diego Alfarache

-- 09-20-2006

-- Receive and process #NEXT commands

function handle_next(command)

if( command == nil ) then

return

end

D-9

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

local AsciiMessage = "W 1 3 3%0D"

WriteMessage(AsciiMessage)

-- if we are a V1 we need to update the frequency

if( false == bIsV2 ) then

nRefreshFreqTimeout = 0

RefreshFrequency()

end

-- function handle_prev(command)

-- Diego Alfarache

-- 09-20-2006

-- Receive and process #PREV commands

function handle_prev(command)

if( command == nil ) then

return

end

local AsciiMessage = "W 1 3 4%0D"

WriteMessage(AsciiMessage)

-- if we are a V1 we need to update the frequency

if( false == bIsV2 ) then

nRefreshFreqTimeout = 0

RefreshFrequency()

end

-- function handle_band(command)

-- Diego Alfarache

-- 09-20-2006

-- Receive and process #BAND commands

function handle_band(command)

if( command == nil ) then

return

end

local AsciiMessage = ""

D-10

if( command.params[1] == "a" or command.params[1] == "A" ) then

AsciiMessage = "W 1 8 2%0D";

elseif( command.params[1] == "f" or command.params[1] == "F" ) then

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

AsciiMessage = "W 1 8 1%0D";

else

AsciiMessage = "W 1 8 10%0D";

end

WriteMessage(AsciiMessage)

-- if we are a V1 we need to update the frequency

if( false == bIsV2 ) then

nRefreshFreqTimeout = 0

RefreshFrequency()

end

-- function handle_key(command)

-- Diego Alfarache

-- 09-20-2006

-- Receive and process #KEY commands

Audio Driver Example

function handle_key(command)

if( command == nil or command.params[1] == nil) then

return

end

local keyvalue = command.params[1]:upper();

if( szInput:len() > 6 ) then

szInput = szInput:sub(2,-1)

end

szInput = szInput..keyvalue

end

-- function handle_key(command)

-- Diego Alfarache

-- 09-22-2006

-- Receive and process #CLEAR commands

function handle_clear( command )

szInput = ""

end

D-11

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

-- function handle_enter(command)

-- Diego Alfarache

-- 09-20-2006

-- Receive and process #ENTER commands

function handle_enter(command)

if( command == nil ) then

return

end

debug("verbose", "szInput is "..szInput)

local AsciiMessage = ""

if( bIsV2 ) then

AsciiMessage = "W 1 7 "

else

AsciiMessage = "W 1 6 "

end

if( nBand == AM ) then

if( bIsV2 ) then

AsciiMessage = AsciiMessage..szInput

else

if( szInput:len() < 4 ) then

"..szInput:sub( 2, 3 )

else

"..szInput:sub( 3, 4 )

end

else

if( szInput:sub(1,1) == "1" ) then

AsciiMessage = AsciiMessage..szInput:sub( 1, 1 ).."

AsciiMessage = AsciiMessage..szInput:sub( 1, 2 ).."

D-12

if( bIsV2 ) then

AsciiMessage = AsciiMessage..szInput:sub( 1, 3

).."."..szInput:sub( 4, 6 )

else

AsciiMessage = AsciiMessage..szInput:sub( 1, 3 ).."

"..szInput:sub( 4, 6 )

end

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

-- make sure we have enough trailing zeros

if( AsciiMessage:len() < 12 ) then

AsciiMessage = AsciiMessage.."0"

end

else

if( bIsV2 ) then

AsciiMessage = AsciiMessage..szInput:sub( 1, 2

).."."..szInput:sub( 3, 5 )

else

AsciiMessage = AsciiMessage..szInput:sub( 1, 2 ).."

"..szInput:sub( 3, 5 )

end

-- make sure we have enough trailing zeros

if( AsciiMessage:len() < 11 ) then

AsciiMessage = AsciiMessage.."0"

end

Audio Driver Example

end

-- clear out szInput

szInput = ""

AsciiMessage = AsciiMessage.."%0D"

WriteMessage(AsciiMessage)

-- if we are a V1 we need to update the frequency

if( false == bIsV2 ) then

nRefreshFreqTimeout = 0

RefreshFrequency()

end

-- function handle_menu_list(command)

-- Cristian Prundeanu

-- 10-23-2006

-- handler for #MENU_LIST indexStart, indexEnd, path, searchParams

-- path format: "PRESET"|"MEDIA"|"MEDIA2" [ ">" <submenu1> [ ">" <submenu2>

[...] ] ]; ex: "MEDIA>ALLDISCS>Disc_10>Title_5>Chapter_2"

function handle_menu_list(command)

debug("verbose", "handle_menu_list: command=",command)

debug("verbose", '#MENU_LIST '..

(command.params[1] and ('"'..command.params[1]..'"') or 'nil')..', '..

(command.params[2] and ('"'..command.params[2]..'"') or 'nil')..', '..

(command.params[3] and ('"'..command.params[3]..'"') or 'nil')..', '..

D-13

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

(command.params[4] and ('"'..command.params[4]..'"') or 'nil')

)

if (#command.params > 4) then

debug("warning", "Extended #MENU_LIST params received: ",

command.params)

end

local nStart = tonumber(command.params[1])

local nEnd = tonumber(command.params[2])

if (command.vPath[1]:upper() == "PRESETS") then

-- default preset handling is sufficient

defaultHandleMenuListPresets(command, nStart, nEnd)

elseif (command.vPath[1]:upper() == "MEDIA" or

command.vPath[1]:upper() == "MEDIA2") then

debug("error", "Media menus not supported in zTuner")

command:sendFinalMenuResp()

else

debug("error", "Unknown root node in #MENU_LIST: ",command.params[3] )

end

-- function handle_menu_sel(command)

-- Cristian Prundeanu

-- 10-24-2006

-- handler for #MENU_SEL path

-- path format: see handle_menu_list

handle_menu_sel = function(command)

debug("verbose", '#MENU_SEL '..

(command.params[1] and ('"'..command.params[1]..'"') or 'nil')

)

if (#command.params > 1) then

debug("warning", "Extended #MENU_SEL params received: ", command.params)

end

if(command.vPath[1]:upper() == "PRESETS") then

-- handle "#MENU_SEL {{presets>...}}" commands, where the

-- presets are stored in the table passed by the dealer setup

command:handlePresetMenuSel(command.vPath[2])

elseif (command.vPath[1]:upper() == "MEDIA" or

command.vPath[1]:upper() == "MEDIA2") then

debug("error", "Media menus not supported in zTuner")

end

D-14

-- function handle_menu_set(command)

-- Cristian Prundeanu

-- 10-24-2006

-- handler for #MENU_SET index

handle_menu_set = function(command)

debug("verbose", '#MENU_SET '..

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Audio Driver Example

(command.params[1] and ('"'..command.params[1]..'"') or 'nil')

)

if (#command.params > 1) then

debug("warning", "Extended #MENU_SET params received: ", command.params)

end

local strDisplay = (BANDNAME[nBand] or "")..szFreq

command:handlePresetMenuSet(strDisplay, "#TUNE "..szFreq)

-- permanently save presets

presetSaveOverrides()

end

-- function handle_user(command)

-- Cristian Prundeanu

-- 10-18-2006

-- handler for #USER functioncall [functioncall [...]] - Lua-execute one or

more functioncalls and print each result

setDebug("USER", "on")

function handle_user(command)

local f

for i = 1, #command.params do

local strLine = string.format('debug("USER", "statement %d result: ",

%s) ', i, command.params[i])

f = loadstring(strLine)

if (not f) then

f = loadstring(command.params[i])-- this enables execution of

assignments and declarations

else

command.params[i] = strLine

end

if (not f) then

command.params[i])

end

-- loading all statements as one chunk enables local variable/scope usage

f = loadstring(string.format(string.rep('%s ',#command.params),

unpack(command.params)))

if (f) then

f()

end

debug("USER", "execution finished")

end

-- function default_command_handler(command)

-- Cristian Prundeanu

-- 10/23/2006

function default_command_handler(command)

debug("error", "Unhandled command received: ", command)

debug("USER", "error: could not load string: ",

D-15

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

end

-- function CheckPower()

-- Diego Alfarache

-- 09/21/2006

function CheckPower()

-- Ignore commands if we are waiting on a response

if(true == bIsV2 or nResponseTimeout ~= 0) then

return

end

WriteMessage("R 1 1%0D")

nResponseTimeout = 5

nExpectedRX = POWER_STATE

nRefreshPowerTimeout = 5

end

-- function PerformReset()

-- Diego Alfarache

-- 09/21/2006

-- Note: This uses an undocumented command sequence to request a

-- hard reset of the zTuner.

function PerformReset()

WriteMessage("W 1 20 1%0D")

nTimeouts = 0

nResponseTimeout = 0

nRefreshPowerTimeout = 10

nRefreshFreqTimeout = 12

end

-- function CheckPower()

-- Diego Alfarache

-- 09/21/2006

function RequestV2Status()

D-16

WriteMessage("R 1 13%0D")

nRefreshFreqTimeout = 5

end

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

-- function RefreshFrequency()

-- Diego Alfarache

-- 09/21/2006

function RefreshFrequency()

-- Ignore commands if we are waiting on a response

if(nResponseTimeout ~= 0) then

return

end

if( false == bIsV2 ) then

WriteMessage("R 1 6%0D")

nExpectedRX = FREQUENCY_FIRST;

nResponseTimeout = 5

nRefreshFreqTimeout = 5

else

RequestV2Status()

end

Audio Driver Example

end

-- function SendPower(bOn)

-- Diego Alfarache

-- 09/21/2006

function SendPower( bOn )

debug("warning", "Setting Power state to %d", bOn)

local szPower = ""

local nPower = 0;

if( true == bOn ) then

nPower = 1

end

szPower = string.format("W 1 1 %d%%0D", nPower)

WriteMessage(szPower)

nRefreshPowerTimeout = 5;

nRefreshFreqTimeout = 6;

end

D-17

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

-- function QueryStatus()

-- Diego Alfarache

-- 09-21-2006

-- Do a periodic check for status

function QueryStatus()

-- request the status so we know the initial state of everything

if( nResponseTimeout ~= 0 ) then

nResponseTimeout = nResponseTimeout - 1

if(nResponseTimeout <= 0) then

nTimeouts = nTimeouts + 1

-- errorLog(&SystemLog, "CControlZTuner: Timeout waiting ZTuner

response, %d, %d", m_nExpectedRX, m_nTimeouts);

nRefreshPowerTimeout = 0

if(nTimeouts >= 10) then

PerformReset()

else

CheckPower()

RequestV2Status()

end

else

if(nRefreshPowerTimeout > 0) then

nRefreshPowerTimeout = nRefreshPowerTimeout - 1

end

if(nRefreshFreqTimeout > 0) then

nRefreshFreqTimeout = nRefreshFreqTimeout - 1

end

if(nRefreshFreqTimeout <= 0) then

RefreshFrequency()

elseif(nRefreshPowerTimeout <= 0) then

D-18

CheckPower()

end

-- try again in 5 seconds if this is from a timer

return 5000

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Audio Driver Example

end

-- Now we can run our main code

-- Check to see if the COM port has been overridden by Dealer Setup

if( config == nil ) then

config = {}

end

-- If the COM port doesn't exist, setup the default

if( config.port == nil ) then

config.port = "comm://0;baud=9600;parity=none"

end

-- open the serial port and ready it for writing

serialPort = createStream(config.port)

if(serialPort == nil) then

debug("error", "Unable to open stream \""..config.port.."\"")

return

end

-- setup the stream to call OnAsyncInput whenever a carrige return is

detected

serialPort.startAsyncInput(serialPort, OnAsyncInput, {endString = "\r"})

-- load saved presets and add them to the ones defined in SCRIPT_DATA

presetLoadOverrides()

-- create our timer to call QueryStatus every 5 seconds

createTimer(5000, QueryStatus)

D-19

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

Writing StreamNet Device Drivers

D-20

Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496

3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.

ClearOne Writing StreamNet User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
