ClearOne Communications, Inc.~ 1825 Research Way, Salt Lake City, UT 84119 ~ tel 1-800-945-7730 ~ fax 1-800-933-5107
FlexCam
®
iCam Digital User Manual
FlexCam iCam Digital — Introduction
1
FlexCam iCam Digital — Table of Contents
ii
The FlexCam®iCam Digital is a user-friendly presentation camera that features S-video and
USB digital capabilities for enhanced flexibility in a wide variety of classroom applications.
This innovative camera is perfect for presenting objects, images, text or microscopic images
to a classroom. Using the USB connection and powerful software, students and teachers can
easily capture video, create video presentations and edit for special effects.
Service and support
If you need additional information on how to install, set up or operate your FlexCam iCam
Digital, please contact us. We welcome and encourage your comments so we can continue to
improve our products and serve your needs.
Product returns
All product returns require a return materials authorization (RA) number. Please contact
ClearOne Technical Support before attempting to return your product. Make sure you return
all the items that shipped with your product.
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760 Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Service and support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Product returns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Important safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Handling the camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Product overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Sofware drivers for Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Installing ArcSoft Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Using the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
General usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
VideoImpression for Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
PhotoStudio for Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
VideoImpression for Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
PhotoStudio on Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
FCC Part 15/ICES-003 Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
© 2004 ClearOne Communications, Inc.All rights reserved. No part of this document may be reproduced in any
form or by any means without written permission from ClearOne Communications.Printed in the United States
of America. ClearOne Communications reserves specific privileges. Information in this document is subject to
change without notice.
FlexCam®iCam Digital Installation and Operation Manual
ClearOne Part No. 800-171-102 May 2004 (Rev. 1.0)
Technical support Sales and customer service
Tel: 1-800-283 5936 (USA) or
1-801-974-3760
Tel: 1-800-945-7730 (USA) or
1-801-975-7200
Fax: 1-801-977-0087 Fax: 1-800-933-5107 (USA) or
1-801-977-0087
E-mail: tech.support@clearone.com
Web: www.clearone.com
E-mail: sales@clearone.com
Table of Contents Introduction
FlexCam iCam Digital — Introduction
3
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
FlexCam iCam Digital — Introduction
2
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
Unpacking
Carefully remove the FlexCam iCam Digital, cables and power supply from the packaging.
Ensure that you received the following items:
If any parts are missing, please call the Technical Support Group at
1-800-283-5936 (USA) or 1-801-974-3760.
ClearOne is not responsible for product damage incurred during shipment. You must make
claims directly with the carrier. Inspect your shipment carefully for obvious signs of damage.
If the shipment appears damaged, retain the original boxes and packing material for
inspection by the carrier. Contact your carrier immediately.
System requirements
FlexCam iCam Digital
• Pentium II 350 MHz or higher,
PowerPC Mac or higher
• Windows 98SE or later
Mac OS 8.6-9.2
• 64 MB RAM
• 1 free USB port
Important safeguards
Before operating the FlexCam iCam Digital camera, please read the entire manual
thoroughly.The FlexCam iCam Digital was designed, built and tested for use indoors. Using a
power supply other than the one provided or using the camera outside could damage the
camera or peripheral equipment and/or create a potentially unsafe operating condition.
• Do not operate the camera if the power cord is damaged or if the camera has been dropped
or damaged. A qualified service technician must examine the camera before operating.
• Position the cord so that it will not be tripped over, pulled on or come into contact with hot
surfaces.
• Always unplug the camera from the electrical outlet before cleaning or servicing.
• To reduce the risk of electric shock, do not immerse in water or other liquids.
Handling the camera
• All ClearOne cameras are for indoor use only.
• Do not use cameras next to food or beverages. Cameras have been tested and approved for
use in chemistry labs. However, be careful not to spill liquid or dry chemicals or solvents on
the camera.
• Do not use cameras right next to working TVs, radios, motors, transformers or magnetic
field s.
• Avoid touching the lens.To clear any dust, blow pressurized air onto the lens. Clean smears
or smudges by wiping with a lens cleaning cloth.
• Clean exterior of camera by wiping with a clean, damp cloth; do not use any abrasive
chemicals.
• Use both hands whenever adjusting the neck of the camera; this will avoid any unnecessary
strain on the camera base and will keep the camera from tipping over.
• Do not attempt to take the camera apart.There are no user-serviceable components inside.
• Do not direct the lens of the camera toward the sun.This may damage the camera.
• Do not store or operate the camera under the following conditions:
~ Outdoors or connec ted to outdoor or auxiliary power sources.
~ In environments with high humidity.
~ In inclement weather.
~ Under severe vibration.
USB Software and
Driver Disk
6' USB Cable6' USB Cable
12 VDC Power
Plug
FlexCam iCam Digital
S-video to Composite
Adapter
Microscope Couplers
26 mm, 28 mm and 34 mm
FlexCam iCam Digital
Manual
12' S-video
Figure 1. FlexCam iCam Digital and accessories
Video Impression 1.6
• 64 MB RAM
• 200 MB free hard disk space
• 16-bit (or higher) color display
• Apple Quick Time recommended
• CD-ROM drive
Photo Studio 5
• 64 MB RAM
• 50 MB free hard drive space
• 16-bit (or higher) color display
• CD-ROM drive
FlexCam iCam Digital — Introduction
5
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
Application examples
With simple S-video and USB connections , the FlexCam iCam Digital is the perfect addition
to any classroom. You can connect to a PC or a Mac using the USB connection to add still
images or movie clips to web sites, reports, and presentations.The S-video connection allows
you to display images and objects as well as share documents on a TV or LCD projector.You
can also use the camera with a microscope to capture lab experiments.
TV or Video Monito
r
Microscope
FlexCam iCam Digital
PC or Mac
LCD Projector
FlexCam iCam Digital
PC or Mac
USB
USB
S-video
S-video
S-video
FlexCam iCam Digital
FlexCam iCam Digital
VCR
Figure 3. Applications
FlexCam iCam Digital — Introduction
4
Product overview
A. Gooseneck. The gooseneck allows you to adjust the camera head/camera lens over the
object to be viewed. Do not bend the gooseneck more than 90° in any direction or attempt
to tie it in a knot. Do not attempt to repair any cracks in the vinyl coating.The gooseneck
is non-removable and should be replaced only by ClearOne.
B. Camera base.The camera base has power, USB and S-video connections.
C. Camera head. The head of the camera unit contains the camera lens, lens holder, focus ring
attachments, connections to gooseneck and all cables.
D. Camera lens and lens holder. The camera lens is held in place by the lens holder. If you
remove the lens, take care not to cross thread the lens when replacing it.
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
A
B
C
D
S-VIDEO
USB
POWER
DC 12V
Figure 2. FlexCam iCam Digital overview
FlexCam iCam Digital — Getting Started
7
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
Sofware drivers for Windows
Before you can use your FlexCam iCam Digital with a computer, you must install the proper
USB drivers on your PC.The drivers are found on the USB Software and Driver Disk that
came with your camera. Depending on the Windows version you are using, the installation
process may vary slightly. The new hardware screens on your computer may not look exactly
like the ones pictured in this section. If the Found New Hardware Wizard does not
automatically locate the drivers, you may need to manually direct your browser to the
NUVSION.sys file on the ArcSoft CD. After the drivers are properly installed you will need to
install the ArcSoft Software Suite that includes VideoImpressions and PhotoStudio. For
information on installing the ArcSoft Software Suite, please refer to page 11.
To install the drivers on Windows
1. Insert the
USB Software and Driver Disk
into the CD-ROM drive.
2. Plug in the FlexCam iCam Digital. The Found New Hardware Wizard will open.
3. Click
Next
.
Figure 6. Found new hardware
FlexCam iCam Digital — Getting Started
6
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
Connections
You can connect the FlexCam iCam Digital to a TV, a VCR or an LCD projector using the
included 12' S-video cable. If your video display device requires a composite signal, use the
provided S-video to composite adapter.
To connect to a TV, VCR or projector
1. Connect the S-video cable of the FlexCam iCam Digital to the video input on the display
device.
Note: If needed, use the S-video to composite video adapter.
2. Attach the power plug to the power jack on the back of the camera and plug the power
adapter into the wall.
To connect the camera to a computer
1. Connect the USB cable of the FlexCam iCam Digital to the USB input on the back of the
computer.
2. Attach the power plug to the power jack on the back of the camera and plug the power
adpater into the wall.
Getting Started
S-VIDEO
USB
POWER
DC 12V
FlexCam iCam Digital
To S -vid eo
Input
To S -vid eo
Input
Composite Adapter
To Composite
Figure 4. Connection to an S-video display device
S-VIDEO
USB
POWER
DC 12V
FlexCam iCam Digital
PC or Mac
To USB
Connector
To USB
Output
To Power
To Outlet
Figure 5. Connection to computer
FlexCam iCam Digital — Getting Started
9
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
FlexCam iCam Digital — Getting Started
8
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
6. Once the Wizard has found the drivers, click Next to start the installation.
7. During the installation, a Digital Signature Not Found window might open. Click Yes to
continue.
8. When installation is complete, click
Finish
to close the Found New Hardware Wizard.
Figure 9. Start installation
Figure 10. Completed Found New Hardware
4. Select Search for a suitable driver for my device (recommended).
5. Select CD-ROM drives.
Figure 7. Search for drivers
Figure 8. Locate drivers
FlexCam iCam Digital — Getting Started
11
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
FlexCam iCam Digital — Getting Started
10
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
Sofware drivers for Macintosh
Before you can connect your FlexCam iCam Digital to a Macintosh, you must install the
USB drivers.The drivers are found on the USB Software and Driver Disk that came with
your camera.The FlexCam iCam Digital is compatible with Mac OS 8.6 – 9.2.
To install USB drivers on a Mac
1. Insert the
USB Software and Driver Disk
into the CD-ROM drive.
2. Double-click the
USB Software and Driver Disk icon
to open the CD content window.
3. Double-click the
FlexCam iCam Digital folder
icon.
4. Double-click the correct operating system folder.
5. Click
iCam Digital
to install drivers. Once drivers are installed, restart the computer.
6. Plug the
USB cable
into a USB port on the Mac.
Figure 11. ArcSoft on Mac
Installing ArcSoft Software
To install ArcSoft Software on Windows
1. From My Computer, right-click the
ArcSoft CD
icon and select
Explore
.
2. Double-click
Setup.exe
.
3. Follow the on-screen prompts. Both programs are installed through the same installation
wizard.
4. Restart your computer.
To install ArcSoft Software on a Mac OS
1. Double-click the
Video Impression 1.6 Installer
icon (see Figure 11) and follow the
on-screen prompts.
2. When Video Impression finishes installing, double-click the
PhotoStudio Installer
and
follow the on-screen prompts.
3. Restart your computer.
Figure 13. Installing the ArcSoft programs
Figure 12. iCam Digital driver installer
General usage
To view images on a TV
1. Connect the camera to a TV.
2. Switch the TV to video mode by pressing the button on the TV front panel or remote
control (consult your owner's manual for further instructions).
Note: Not all TVs have video inputs. If your TV only has an antenna input, you will need a
modulator or a VCR with video inputs.
3. Turn camera on using the on/off switch located at the base of the gooseneck. You should see
an image on the television screen.
4. Position the camera.
5. Turn the focus ring to the left for close-up or to the right for distance.
To record images on a VCR
1. Connect the camera to a VCR using the S-video cable or composite adapter.
2. Switch the VCR to the video-in mode (consult your owner’s manual for instructions).
3. Turn camera on using the on/off switch located at the base of the gooseneck.
4. Turn the VCR/TV switch to VCR and the TV to either channel 3 or 4.
5. Position the camera.
6. Turn the focus ring to the left for close-up or to the right for distance.
7. Press record on the VCR.
To view images on a LCD projector
1. Connect the camera to a projector using the S-video cable or composite adapter.
2. Turn the projector on (consult your owner’s manual for further instructions).
3. Turn camera on using the on/off switch located at the base of the gooseneck.
4. Position the camera.
5. Turn the focus ring to the left for close-up or to the right for distance.
To use the microscope couplers
1. Slide the microscope coupler (26, 28 or 34 mm depending on the size of the microscope)
over the microscope eyepiece.
2. Adjust the camera to fit the camera lens into the coupler on the microscope.
FlexCam iCam Digital — Using the Camera
13
FlexCam iCam Digital — Using the Camera
12
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760 Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
VideoImpression for Windows
With ArcSoft VideoImpression you can create entertaining movies and slide shows that
incorporate photos, scene transitions and video clips.
To capture video in VideoImpression
1. Open
VideoImpression
by clicking the desktop icon or by selecting
VideoImpressio
n from
the
Start
menu.
2. Click
new
to access the video album screen.
3. If you have installed multiple cameras, click
Acquire
to open the Select Source window.
Choose ClearOne FlexCam iCam Digital and click
Select
.This will open a View Finder window that you can use to capture still images. Close the View Finder to return to the main
VideoImpression window.
Figure 14.VideoImpression start-up screen
Using the Camera
Figure 15. Selecting the camera
FlexCam iCam Digital — Using the Camera
15
8. Click Record to record the video. Click Pause or press the Esc key to stop.
9. Click save to choose the file format and save the file. After you save the file, you will be
prompted to add the file to the album. Click Yes to add the file.
For more information on using VideoImpression, click
the help button on the toolbar to
access the help file or visit www.arcsoft.com.
Note: The VideoImpression 1.6 version on this CD is manufactured specifically for ClearOne
products and may therefore differ from the standard version of Video Impression 1.6. Both
products have built-in help systems to help you make the most of your video and still captures.
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
FlexCam iCam Digital — Using the Camera
14
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
4. Click Capture to display the video capture screen. From this screen you can record, play or
pause video and make adjustments to the video settings.
5. Click the Source icon to open the Video Source window.
6. In the Capture Source tab, select ClearOne FlexCam iCam Digital from the Select a Video
Device drop down.
7. Click
Ok
to return to the main video capture window.
Figure 18.Video capture controls
Figure 17. Capture source
Figure 16. Source icon
FlexCam iCam Digital — Using the Camera
17
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
FlexCam iCam Digital — Using the Camera
16
5. The captured image appears in the PhotoStudio window.To save the image, select
Save As
from the File menu.
For more information on using PhotoStudio, click the help button on the toolbar to access the
help file or visit www.arcsoft.com.
Figure 21. Saving the image
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
PhotoStudio for Windows
ArcSoft PhotoStudio is an image capture program with a range of features to help you
easily capture, edit and print your photos.
To capture an image in PhotoStudio
1. Open
PhotoStudio
by clicking the desktop icon or selecting
PhotoStudio
from the
Start
menu.
2. If you have installed multiple cameras, choose
Select Source
from the File menu and select
the driver for the camera you are using.
3. Select
Acquire
from the File menu to open the View Finder window. In this window you can
make adjustments and capture the image.
4. Click
Capture
to capture the image.
Figure 19. Selecting the camera source in PhotoStudio
Figure 20. Image preview and capture screen
FlexCam iCam Digital — Using the Camera
19
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
FlexCam iCam Digital — Using the Camera
18
4. Click
Capture
to display the video capture screen.
The video capture window in the Mac version of VideoImpression is different from the
one found in the Windows version. Instead of being embedded in the VideoImpression
screen, it is a separate window.
5. Click
Capture Video
to record video or
Capture Photo
to take a picture. Click
Done
when
you are finished.
For more information on using VideoImpression, click the help button on the toolbar to
access the help file or visit www.arcsoft.com.
PhotoStudio on Macintosh
Mac operating systems do not support the image capture feature in PhotoStudio. Capture
images using VideoImpression and then open them in PhotoStudio for editing.
Figure 24.Video Capture screen
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
VideoImpression for Macintosh
To capture video in VideoImpression
1. Open
VideoImpression
by clicking the desktop icon.
2. Click
new
to access the video album screen.
3. If you have installed multiple cameras, click
Acquire
to open the Select Source window.
Choose the driver for the camera you are using and click
Select
.This will open a View
Finder window that you can use to capture still images. Close the View Finder to return to
the main VideoImpression window.
Figure 22.VideoImpression start-up screen
Figure 23.VideoImpression start-up screen
FlexCam iCam Digital — Appendix
21
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
FlexCam iCam Digital — Troubleshooting
20
Specifications
Gooseneck
20" (50.8 cm)
Weight
4 lb (1.81 kg)
Power Supply
12 VDC
Operating Temperature
32º F – 104º F (0º C – 40º C)
Image Sensor
1
/3" (8.5 mm) CMOS
No. of Effective Pixels
510(H) x 492(V), 251K pixels NTSC
628(H) x 582(V), 365K pixels PAL
Resolution
330 TV lines (horizontal)
Focus Range
1
/4" (6.35 mm) to infinity
Lens
8 mm (.32") D-mount glass lens
Gain Control
Auto
White Balance
Auto
Iris
Auto, electronic with flicker-free performance
Sensitivity
3 lux
S/N Ratio
>48 dB
Video Output
S-video and composite
USB
Video Format
NTSC
PAL
Exterior Color
Translucent blueberry with black accents
Cables
6' (1.83 m) USB cable
12' (3.65 m) S-video cable
Included Accessories
S-video to composite adapter
SCART adapter (PAL models)
Microscope couplers
Optional Accessories
910-171-320 FlexLite
™
910-171-327 Microscope eyepiece adapter
Part Numbers
910-171-102
910-171-102-PAL
Appendix
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
I’ve installed the FlexCam iCam Digital, but the picture doesn’t appear.
Connect the FlexCam iCam Digital to the computer using the supplied USB cable. Check to see that
the video source (S-video or composite) is set correctly. Ensure that the USB port is enabled in your
computer’s BIOS and in the Windows Control Panel/System Device Manager.
How do I know the driver for the FlexCam iCam Digital has been properly installed?
Right-click the My Computer icon on the desktop. Choose Properties. Click the Hardware tab, then
Device Manager. Click the plus sign next to the icon labeled Imaging. If the Imaging folder is missing,
you need to reinstall the drivers.
Why can’t I install the FlexCam iCam Digital with Windows 95?
Windows 95 does not support USB connections.You will need to upgrade to Windows 98 release II
(or a later version) to use the FlexCam iCam Digital.
Why can’t I install the FlexCam iCam Digital on Mac OS X?
The FlexCam iCam Digital is not compatible with Mac OS X.
Can I easily switch between multiple USB video capture devices on Mac OS?
No.To switch between devices, you must uninstall the driver(s) for one device and install the driver(s)
for the other.
Why doesn’t the FlexCam iCam Digital work after installing the drivers on Mac OS?
Connect the FlexCam iCam Digital to the computer using the supplied USB cable. Drivers may not be
properly installed or other USB video capture devices connected.
If you are experiencing other problems with your camera,
• Ensure all camera adapter/cable connections and electrical connections are done correctly and
completely.
• Check all equipment for faulty operation.
• Check all settings on your camera and adjust them for viewing conditions in the
presentation room.
If any component of any camera is damaged, contact ClearOne Technical Support for repair
information.
Troubleshooting
FlexCam iCam Digital — Appendix
23
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
FlexCam iCam Digital — Appendix
22
Warranty
ClearOne Communications, Inc. (Manufacturer) warrants that this product is free of defects in both
materials and workmanship. Should any part of this product be defective, the Manufacturer agrees,
at its option, to:
Repair or replace any defective part free of charge (except transportation charges) for a period of
two years from the date the end user is invoiced for the product, provided the end user returns the
product to ClearOne Communications or an authorized ClearOne dealer according to the Product
Return and Repair statement set forth below;
This warranty excludes assembled products not manufactured by the Manufacturer whether or not
they are incorporated in a Manufacturer product or sold under a Manufacturer part or model
number.
Product Return and Repair
1. Return to Seller if Purchased Through an Authorized Dealer
a. Proof of purchase date from reseller within warranty period must be provided by the end user.
b. Seller may,at its discretion, provide an immediate exchange or repair or may return the unit to
the Manufacturer for repair.
2. Return to Manufacturer
a. An RMA (return merchandise authorization) number must be issued to the end user from
ClearOne technical support.
b. The end us er must return the product to ClearOne with proof of purchase (showing purchase
date) for a warranty claim, and display the RMA number on the outside of the shipping package.
This warranty is void if:
A. The product has been damaged by negligence, accident, act of God, or mishandling, or has not
been operated in accordance with the procedures described in the operating and technical
instructions; or,
B. The product has been altered or repaired by other than the Manufacturer or an authorized
service representative of the Manufacturer; or,
C. Adaptations or accessories other than those manufactured or provided by the Manufacturer
have been made or attached to the product which, in the determination of the Manufacturer,
shall have affected the performance, safety or reliability of the product; or,
D. The product's original serial number has been modified or removed.
NO OTHER WARRANTY, EXPRESS OR IMPLIED,INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR USE, APPLIES TO THE PRODUCT.
MANUFACTURER'S MAXIMUM LIABILITY HEREUNDER SHALL BE THE AMOUNT PAID
BY THE END USER FOR THE PRODUCT. No person or entity authorized to assume any obligation
or other liability in connection with the products. No action, regardless of form, arising out of or
relating to the product or this warranty, may be brought by end user more than two (2) years after
the cause of action has accrued.
Manufacturer shall not be liable for punitive, consequential, or incidental damages, expens es, or loss
of revenue or property, inconvenience, or interruption in operation experienced by the end user due to
a malfunction in the purchased product. No warranty service performed on any product shall extend
the applicable warranty period.
In case of unsatisfactory operation, the end user shall promptly notify the Manufacturer at the
address set forth below in writing, giving full particulars as to the defects or unsatisfactory operation. Upon receipt of such notice, the Manufacturer will give instructions respecting the shipment of
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
Optional accessories
Contact your ClearOne Reseller for more information on the following accessories.
FlexLite
TM
The FlexLite is designed for use with any flexible camera. Dual flexneck top lights attach to
the base of your FlexCam to provide adequate lighting for all subjects. Available in 110 V
(NTSC) and 220 V (PAL) versions.
Microscope eyepiece adapter
Create a secure connection between your camera and microscope with the microscope eyepiece adapter. Simply remove the original eyepiece of the microscope and replace with the
adapter for a tighter fit between camera and microscope.
To use the microscope adapter
1. Remove the microscope eyepiece.
2. Replace the original eyepiece with the custom eyepiece adapter by sliding the narrow end
into place on the microscope.
3. Gently push the camera into position.
Original eyepiece
Eyepiece adapter
Connection to the camer
a
Figure 25. Connecting to the microscope
FlexCam iCam Digital — Appendix
25
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
FlexCam iCam Digital — Appendix
24
Standard(s) to which Conformity is declared:
89/336/EEC "Electromagnetic Compatibility (EMC) Directive":
EN 55022: 1994 (Emissions) Specification for limits and methods of measurement of
radio interference characteristics of information
technology equipment
EN 61000-3-2:1995/A1/A2:1998 Part 3: Limits - Section 2: Limits for harmonic current
emissions.
EN 61000-3-3:1995 Section 3: Limitation of voltage fluc tuations and flicker in low
voltage supply systems for equipment with rated current
up to and including 16 A
EN 55024: 1998 (Immunity) Information technology equipment -
Immunity characteristics - Limits and
methods of measurement
EN 61000-4-2: 1995/A1:1998 Electrostatic Discharge
EN 61000-4-3: 1996/A1:1998 Radiated RF Immunity
EN 61000-4-4: 1995 Electrical Fast Transients
EN 61000-4-5: 1995 Lighting Surge
EN 61000-4-6: 1996 Conducted RF Immunity
EN 61000-4-11: 1994 Voltage Dips and Voltage Interruptions
73/23/EEC "Low Voltage Directive (LVD)":
IEC 60950-1: 2003 Safety of Information Technology
Equipment, Including Electrical Business
Equipment
We, the undersigned, hereby declare that the equipment specified above conforms to the above
Directives and Standards.
Manufacturer
Signature
Roger J. Midgley
Full Name
Project Manager
Position
Legal Representative in Europe
Signature
Martin Offwood
Full Name
Managing Director EMEA North
Position
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
the product, or such other matters as it elects to honor this warranty as above provided.This
warranty does not cover damage to the product during shipping and the Manufacturer assumes no
responsibility for such damage. All shipping costs shall be paid by the customer.
This warranty extends only to the original end user and is not assignable or transferable.This
warranty is governed by the laws of the State of Utah, without regard to the conflicts of interests
provisions thereof.
ClearOne Communications Inc.
1825 Research Way
Salt Lake City,Utah 84119
FCC Part 15/ICES-003 Compliance
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC rules and Industry Canada ICES-003. Thes e limits are designed to
provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment.This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause harmful interference
to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at his/her own
expense.
Operation is subject to the following two conditions: (1) This device may not cause interference, and
(2) This device must accept any interference including interference that may cause undesired operation of the device.
Changes or modifications not expressly approved by ClearOne Communications could void the user's
authority to operate the equipment.
European Compliance
This equipment has been approved in accordance with Council Directive 1999/5/EC "Radio
Equipment and Telecommunications Equipment". Compliance of the equipment with the Directive is
attested by the application of the CE mark on the equipment.
EC Declaration of Conformity
Application of Council Directive(s): 1999/5/EC Radio equipment and Telecommunications
Terminal Equipment (R&TTE) Directive
Manufacturer's Name: ClearOne Communications
Manufacturer's Address: 1825 West Research Way Salt Lake City, Utah 84119 U.S.A.
Model No.: FlexCam iCam 910-171-101-PAL and
FlexCam iCam Digital 910-171-102-PAL
Loading...
