Clearaudio Master Innovation Wood User Manual
UUppggrraaddee
IInnnnoovvaattiioonn ttoo MMaasstteerr IInnnnoovvaattiioonn
Hi-Fi Components clearaudio electronic
®
GmbH
Spardorfer Str. 150 D-91054 Erlangen Tel. +49 9131/40 300 100 FAX +49 9131/40 300 119
www.clearaudio.de www.analogshop.de info@clearaudio.de copyright clearaudio 2014
User manual
Upgrade
Innovation to Master Innovation
Version 1.2_02-04-14_E
Master Innovation Wood
with:
clearaudio tonearm „Universal“ and
clearaudio cartridge
„Goldfinger Statement“.
Made in Germany
Innovation Wood
Innovation Wood
with
clearaudio tonearm „Universal“ and
clearaudio cartridge „da Vinci“.
Master Innovation Wood
Upgrade
Innovation to Master Innovation
User manual
Page 1 clearaudio electronic GmbH 2014
Dear clearaudio customer,
Congratulations to your choice to upgrade your
Innovation
to a
Master Innovation
turntable,
a world class turntable, handmade in Germany by clearaudio electronic GmbH.
Like the model
Innovation
the
Master Innovation
has a resonance minimizing chassis
construction in a sandwich combination with the innovative motor unit (low noise level and
high turning moments), which guarantees total isolation of resonances from the turntable
chassis, providing the best music reproduction and authentic High End imaging.
The clearaudio patented CMB-Bearing-Technology, an inverted bearing with jewelled and
polished ceramic bearing shaft and a bronzed liner, provides frictionless analogue
enjoyment.
This user manual described the reconstruction from the turntable
Innovation
to the turntable
Master Innovation
. For more information regarding the
Master Innovation
you will get a
separate user manual.
We wish you a lot of musical enjoyments with your new
clearaudio
Master Innovation
-turntable.
clearaudio electronic GmbH
This section must be read before any connection is made to the mains supply.
CE-MARKING
The clearaudio
Master Innovation
meets the regulations concerning
electromagnetic disturbance (EMC) and low-voltage appliances.
EQUIPMENT MAINS WORKING SETTING
Your clearaudio product has been prepared to comply with the household power and safety
requirements that exist in your area. This product can be connected to 230 V or 110 V AC
(50 Hz and 60 Hz).
COPYRIGHT
Recording und reproduction of any sound-material may require the consent of the creator.
Please acknowledge the information given in the
- Copyright Act 1956,
- Dramatic and Musical Performers Act 1958,
- Performers Protection Acts 1963 and 1072,
- any more recent legal regulations.
WARNINGS
Don’t expose your turntable to rain or humidity.
Don’t handle the mains leads with wet hands.
Don’t place or insert anything into the equipment or through ventilation holes.
No naked flame sources, such as lighted candles, should be placed on the equipment.
Upgrade
Innovation to Master Innovation
User manual
Page 2 clearaudio electronic GmbH 2014
Contents
1. Packing overview 3
2. Part list 4
3. Reconstruction
Innovation
to
Master Innovation
6
4. Fine adjustment of the motor 15
5. Service and special instructions 16
6. Technical data 17
Warranty – information 18
Upgrade
Innovation to Master Innovation
User manual
Page 3 clearaudio electronic GmbH 2014
1. Packing overview
Box 1 of 2:
Box 2 of 2:
Drive unit,
already pre – mounted at
factory;
accessories
Stainless steel platter,
drive platter (38 mm)
Upgrade
Innovation to Master Innovation
User manual
Page 4 clearaudio electronic GmbH 2014
2. Part list
Clearaudio has developed a special and secure packing for your
Master Innovation
turntable that ensures a safe transportation.
Please keep this original packing, if you need to ship the turntable.
Below you find the part list of the clearaudio
Master Innovation
turntable:
1.
First drive unit, pre-mounted
(Box 1 of 2)
2.
Stainless steel sub-platter
(Box 2 of 2)
3.
Platter with magnets (38 mm)
(Box 2 of 2)
4.
Drive bearing
5.
Accessories:
Pulley, white gloves, 2 x drive belts,
allen wrench (# 8), bearing oil, user
manual, QCQ – Card, warranty card
1
2 3 4
5
Upgrade
Innovation to Master Innovation
User manual
Page 5 clearaudio electronic GmbH 2014
3. Reconstruction
Innovation
to
Master Innovation
The reconstruction of the turntable
Innovation
to Master Innovation is easy as most parts of
the turntable chassis are already pre-assembled and has been tested at the factory.
Please use the enclosed white gloves in order to avoid scratches or unwanted fingerprints on
the turntable parts or platters.
After the reconstruction the
Master Innovation
turntable requires a space for set-up of at
least (in inch): 18.9 x 19.3.
49 cm / 19.3
48 cm / 18.9
Pic. 1: Required set - up space (with clearaudio tonearm Unify)
Loading...
