INSTRUCTIONS MANUAL
Congratulations on choosing a Clay Paky product!
We thank you for your choice. Please note that this product,
as all the others in the rich Clay Paky range, has been
designed and manufactured with total quality to ensure
excellent performance and best meet your expectations and
requirements.
Carefully read this instruction manual in its entirety and keep it
safe for future reference.
It is essential to know the information and comply with the
instructions given in this manual in order to ensure the fitting is
installed, used and serviced correctly and safely.
CLAY PAKY S.p.A. disclaims all liability for damage to the
fitting or to the other property or persons deriving from
installation, use and maintenance that have not been carried
out in conformity with this instructions manual, which must
always accompany the fitting.
CLAY PAKY S.p.A. reserves the right to modify the
characteristics stated in this instructions manual at any time and
without prior notice.
GLOW UP
& FLIGHT CASE
C C71050
TW C71055
W C71060
F21230
®
ENGLISH
CONTENTS
Page
2
3
4
4
5
6
8
8
9
10
15
16
16
17
19
20
20
21
Contents
Safety information GLOW UP
Safety information FLIGHT CASE
Unpacking and preparation
Removal of the protective film
Installation and start-up
Control panel
Shortcut keys menu
Button function
Preset colors for Stand Alone “GLOWUP C”
Main menu
Operating Mode
RDM Controls implemented for GLOWUP series
Manual zoom - Aerial
Maintenance
Optional accessories
Technical data
Cause and solution of problems
Channel functions
Page 2
2
GLOW UP
• Installation
Make sure all parts for fixing the projector are in a good state of repair. Make sure the point of
a
nchorage is stable before positioning the projector.
The safety chain must be properly hooked onto the fitting and secured to the framework, so that,
if the primary support system fails, the fitting falls as little as possible. If the safety chain gets used,
it needs to be replaced with a genuine spare.
• Minimum distance of illuminated objects
The projector needs to be positioned so that the objects hit by the beam of light are at least 0.2
metres (8”) from the lens of the projector.
• Minimum distance from flammable materials
The projector must be positioned so that any flammable materials are at least 0.20 metres (8") from
e
very point on the surface of the fitting.
• Mounting surfaces
It is permissible to mount the fitting on normally flammable surfaces.
• Maximum ambient temperature
Do not use the project if ambient temperature (Ta) exceeds 40°C.
• IP65 protection rating
The equipment is fully protected against dust (first digit 6) and against jets of water (second digit 5).
• Protection against electrical shock
Connection must be made to a power supply system fitted with efficient earthing (Class I appliance
according to standard EN 60598-1).
It is, moreover, recommended to protect the supply lines of the projectors from indirect contact
and/or shorting to earth by using appropriately sized residual current devices.
• Connection to the power mains
A qualified electrician must perform connection to the power mains.
Check that the mains frequency and voltage correspond to the frequency and voltage for which the
projector was designed and indicated on the electrical data label.
This label also gives the input power. Refer to the latter to evaluate the maximum number of
devices to be connected to the mains to avoid overloads.
• External surface temperature
The maximum temperature that can be reached on the external surface of the fitting, in a thermally
steady state, is 90°C (320°F).
• Maintenance
Before starting any maintenance work or cleaning the projector, cut off power from the supply
mains. After switching off, do not remove any parts of the fitting for at least 10 minutes. The lenses
must be mounted and, if visibly damaged, they have to be replaced with genuine spares.
• Battery
This product contains a lithium iron tetraphosphate rechargeable battery. To protect the
environment, please discard the battery at the end of its life cycle according to current law.
S
AFETY INFORMATION GLOW UP
The products to which this manual refers comply with the European Directives pursuant to:
• 2006/95/EC - Safety of electrical equipment supplied at low voltage (LVD)
• 2004/108/EC - Electromagnetic Compatibility (EMC)
• 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS)
0.2
90°C
IP65
LiFePO4
