SWING ARM MAGNIFYING LAMP
MODEL No: SAM 75
Part No: 5460520
OPERATING & MAINTENANCE
INSTRUCTIONS
LS1113
Page 2
Thank you for purchasing your new CLARKE swing arm magnifying lamp, which is ideal for, fine
detail assembly and repair work, stamp collectors, model makers, jewellers, etc.
Before using this product, read this leaflet thoroughly, and follow the instructions carefully.
Although the product is of rugged construction, it should nevertheless be used with care and
consideration, you can then look forward to it giving long and reliable service.
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from
the date of purchase. Your receipt is required as proof of purchase. This guarantee is invalid if
the product is found to have been abused, or tampered with in any way, or not used for the
purpose for which it was intended.
Faulty goods should be returned to their place of purchase, no product can be returned to us
without prior permission. This guarantee in no way effects your statutory rights under common
law.
ELECTRICAL CONNECTIONS
This product is supplied with a 13 amp, BS 1363 plug, for connection to a domestic 240 Volt
(50Hz) electrical supply. Should it be necessary to renew the plug at any time, ensure the
replacement is of identical specification.
IMPORTANT: The wires in the mains lead are coloured in accordance with the following code:
Green & Yellow -Earth Blue - Neutral Brown - Live
As the colours of the flexible cord of this appliance may not correspond with the coloured
markings identifying terminals in your plug proceed as follows:
Connect GREEN & YELLOW cable to terminal marked with a letter “E” or Earth
symbol “
Connect BROWN cable to terminal marked with a letter “L” or coloured RED.
Connect BLUE cable to terminal marked with a letter “N” or coloured BLACK.
In the event that this product is fitted with a plug which is moulded onto the electric cable (i.e..
non-rewirable) please note:
1. The plug must be thrown away if it is cut from the electric cable. There is a danger of
electric shock if it is subsequently inserted into a socket outlet.
2. Never use the plug without the fuse cover fitted.
3. Should you wish to replace a detachable fuse carrier, ensure that the correct replacement
is used (as indicated by marking or colour code).
4. Replacement fuse covers can be obtained from your local dealer or most electrical
stockists. 5. If the mains cable becomes frayed or damaged in any way, do not use the
lamp until it has been replaced. Contact your local dealer for a replacement part.
Fuse Rating. The fuse in the plug is 3 amps, and must be replaced with one of the same rating
and ASTA approved to BS 1362.
” or coloured GREEN or GREEN & YELLOW.
2
Page 3
ASSEMBLY AND OPERATION
Your magnifying lamp is in two parts, the lamp and Adjustable arms, (carrying the power lead),
and the Mounting Clamp assembly. This comprises a pair of clamps, the larger one of which
(A), mounts on top of a work surface, and supports the swinging arm and lamp. The steel
adjuster bracket (C), also locates into the side of the upper clamp, and on to which is located
the lower clamp (B). This holds the complete assembly firm by gripping the underside of the
work surface when the adjuster screw (D) is tightened.
The clamp assembly may also be mounted on a vertical surface, and a second mounting hole
in the upper lamp (A), at right angles to the main mounting hole, allows the swinging arm to be
mounted vertically, and operate in the normal way.
Always which OFF using the switch on the mains cable.
SETTING UP
lt is possible to move the lamp to any required position, by first slackening off the pivot pinch
bolts to allow the arms to move freely. Tighten the pinch bolts using the large Adjuster Knobs
provided (item 4 ), so that they are firm, but DO NOT OVER TIGHTEN. When the pivots are
correctly tightened, the lamp should be capable of maintaining stability in any position,
without the need to keep readjusting.
MAINTENANCE
The unit requires minimum maintenance, and is limited to a bulb change when necessary, and
cleaning the lens.
IMPORTANT: Always switch the lamp OFF, and unplug from the mains before changing the bulb.
A 60 watt candle bulb, with a Small Edison Screw type bulb (E 14 ), should be used.
When cleaning the lens, always switch off the lamp and allow the bulb to cool beforehand,
Use a clean soft cloth. lt is permissible to use a liquid glass cleaner, but use sparingly, and do
not wet the bulb or electrical components.
PARTS LIST & DIAGRAM
Item Description Part No.
1 Lens vs 7501
2 Cable Assy vs 7502
3 Spring vs 7503
4 Adjuster Knob vs 7504
5 Clamp Assembly vs 7505
6 Bulb Holder vs 7506
