Page 1
POLISHING KIT
MODEL NO: CBK150C, CBK200C
PART NO: 3052015, 3052025
OPERATION & MAINTENANCE
INSTRUCTIONS
ORIGINAL INSTRUCTIONS GC08/23 rev 1
Page 2
INTRODUCTION
Thank you for purchasing this CLARKE Polishing Kit.
Before use, read this manual thoroughly and follow all instructions given.
The polishing kit it is designed to fit to a bench mounted grinder (not supplied).
and is intended for polishing steel, brass, copper, nickel, chrome or silver
objects.
BENCH GRINDER REQUIRED SPECIFICATIONS
1. The maximum speed of the bench grinder must not exceed 3500 rpm.
2. The 6” polishing kit requires a bench grinder with a 12.7 mm spindle.
3. The 8” polishing kit requires a bench grinder with a 16 mm spindle.
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of
12 months from the date of purchase. Please keep your receipt as proof of
purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
WHAT IS SUPPLIED
The polishing kit is supplied with
• 1 tapered shaft
• 1 stick of polishing compound
• 1 polishing wheel
• 1 buffing wheel
2
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
Page 3
PPE REQUIRED
During use, you must wear the following PPE.
Wear eye protection Wear a mask
Wear protective
gloves
WARNINGS
1. Do not use to polish dangerous items like knifes.
2. Ensure adequate ventilation during use.
3. Always wear protective clothing which includes safety goggles, dust mask
and gloves when working with this kit.
4. Make sure that your work surface has been properly assessed for any
potential hazards before starting work.
FIRST AID MEASURES (POLISHING COMPOUND)
After inhalation Supply fresh air, consult doctor in case of complaints.
After skin contact Wash with soap and water and rinse thoroughly.
After eye contact Rinse the opened eye for several minutes under running
water. If symptoms persist, consult a doctor.
After swallowing Rinse out mouth and drink plenty of water.
3
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
Page 4
SETUP
FITTING THE POLISHING WHEEL TO THE BENCH GRINDER
1. Remove the wheel and all guards from the left hand side of your bench
grinder.
• Consult the bench grinder user manual for instruction of how to do this.
• The inner guards are normally held on with 3 or 4 screws.
• When you revert the bench grinder back to normal use, ALL GUARDS
MUST BE REFITTED.
2. Slide the tapered shaft over the
spindle as shown and screw on by
hand.
3. Whilst holding the tapered shaft
with one hand screw the polishing
wheel onto the sharp end of the
tapered shaft by hand.
4. To remove the polishing wheel,
simply screw the polishing wheel
in the opposite direction whist
holding the tapered shaft with
your other hand.
BUFFING WHEEL.
The buffing wheel is fitted in the same way as above.
4
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
Page 5
ADDING COMPOUND TO THE POLISHING WHEEL
1. Turn on the bench grinder.
2. When the wheel has reached
maximum speed, apply the
polishing compound to the wheel
(at the 4 o’clock position) as
shown.
3. Turn off the bench grinder and
allow it to come to a stop.
4. The polishing wheel is now ready
for use.
USING THE POLISHING KIT
1. Turn on the bench grinder.
2. When the wheel has reached
maximum speed, apply the item
you want to polish to the wheel
(at the 4 o’clock position) as
shown.
3. Remove the polishing wheel and
replace it with the buffing wheel.
4. Repeat step 2 to buff the item to a
fine finish.
REPLACEMENT POLISHING COMPOUND
Replacement polishing compound is available from you local CLARKE dealer.
5
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
Page 6
SUITABLE CLARKE BENCH GRINDERS
The following Clarke bench grinders are suitable for use with this product.
SUITABLE FOR CBK150C SUITABLE FOR CBK200C
Clarke CBG6RP 6" Bench Grinder Clarke CBG8370L 8” Bench Grinder
with Lamp
SUITABLE FOR CBK150C SUITABLE FOR CBK200C
Clarke CBG6250LW 6” Bench Grinder
with Lamp & Wire Wheel
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
Clarke CBG8370LW 8” Bench Grinder
with Lamp & Wire Wheel
6
Page 7
OTHER BUFFERS IN THE CLARKE RANGE
CBB150 250W 6'' Bench Buffer/ Polisher
Part Number: 6500485
The Clarke CBB150 is ideal for buffing and
polishing metal and composite surfaces.
This unit features a robust cast iron base with
rubber feet which reduces vibration, and this
model can also be bolted to a work bench to
make it even easier to use.
Completing this handy machine is a reliable
build and 2x polishing mops included (1x
stitched 1x open style) to get started.
CHDB500 6” Heavy Duty Bench Buffer /
Polisher
Part Number: 6500492
The heavy duty CHDB500 is ideal for buffing
and polishing metal and composite surfaces
to a bright lustred finish.
This unit features a robust cast iron base with
rubber feet which reduces vibration, and this
model can also be bolted to a work bench to
make it even easier to use.
With its built-in motor delivering 500W of
power combined with its bearing balanced
precision machined shafts, this buffer offers
excellent performance.
For added safety, a front mounted on/off
switch makes the polisher easy to switch off,
and easy fitment and removal of polishing
mops makes for efficient working.
Completing this handy machine is a reliable
build, with 1x stitched and 1x open style
polishing mops included to get you started.
7
